Instrument Panel System Displays, Gauges and Console Buick Rendezvous I

Fastener Tightening Specifications

Fastener Tightening Specifications

Fuel Level Specifications

The information in this table is intended for use with the J 33431-C Signal Generator and Instrument Panel Tester. See Special Tools and Equipment . The fuel level sensor values represent the test values to be used on the Signal Generator to drive the fuel gage display to the indicated positions. Vehicles that require more than one fuel level sensor calculate gage position from many possible resistance combinations of fuel levels between the two tanks. Therefore, the values in the table may not correlate directly to readings taken from the vehicle primary or secondary sending units.

The values in the table are approximate values based on information obtained from properly operating vehicles. Actual results may vary slightly.

Fuel Level Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Instrument Panel, Gages, and Console Connector End Views

Ambient Air Temperature Sensor (UH9/CJ2) Connector End Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT GRN/BLK 735 Ambient Air Temperature Sensor Signal B YEL 61 Low Reference

Driver Information Center (DIC) Switch (UH9) Connector End Connector Part Information 12064993 6-Way F Micro-Pack 100 Series (BLK) Pin Wire Color Circuit No. Function 5 GRY 8 Instrument Panel Lamp Supply Voltage 6 BLK 1450 Ground 7 BLK 1550 Ground 8 PNK 893 DIC Select Menu Switch Signal 9 DK GRN/ WHT 1358 DIC Switch Signal 10 - - Not Used

Head Up Display (HUD) Switch (UH9) Connector End Connector Part Information 12064978 6-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function 1 GRY 8 Instrument Panel Lamp Supply Voltage 2 BLK 1450 Ground 3 BLK 1550 Ground 4 YEL 621 HUD Image Up Signal 5 BRN 620 HUD Image Down Signal 6 WHT 717 Illuminated Display Signal

Head Up Display (HUD) (UH9) Connector Part Information 12064799 12-Way F Micro-Pack 100 Series (BLK) Pin Wire Color Circuit No. Function A BLK 1550 Ground B BLK 1450 Ground C ORN 5240 Battery Positive Voltage D LT BLU 14 Left Turn Signal Lamps Supply Voltage E DK BLU 15 Right Turn Signal Lamps Supply Voltage F WHT 717 Illuminated Display Signal G BLK 9936 Class 2 Serial Data H YEL 621 HUD Image Up Signal J BRN 620 HUD Image Down Signal K-L - - Not Used M BRN 241 Ignition 3 Voltage

Instrument Panel Cluster (IPC) Connector End - Pontiac Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1 - - Not Used A2 BRN/WHT 419 MIL Control A3 DK BLU 15 Right Turn Signal Lamps Supply Voltage A4 LT BLU 14 Left Turn Signal Lamps Supply Voltage A5 TAN/WHT 33 Brake Fluid Level Switch Signal A6 DK GRN/ WHT 1358 DIC Switch Signal (UH9) A7 PNK 893 DIC Select Menu Switch Signal (UH9) A8 TAN 185 Low Washer Fluid Indicator Signal A9-A11 - - Not Used A12 LT GRN/BLK 735 Ambient Air Temperature Sensor Signal (UH9) B1 ORN 640 Battery Positive Voltage B2 YEL 61 Low Reference (UH9) B3 BLK 1550 Ground B4 PPL 1500 Ignition 0 Voltage B5-B6 - - Not Used B7 BLK 1450 Ground B8 GRY 8 Instrument Panel Lamp Supply Voltage B9 GRY 1036 IPC Class 2 Serial Data B10-B12 - - Not Used

Instrument Panel Cluster (IPC) Connector End - Buick Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1 DK BLU 15 Right Turn Signal Lamps Supply Voltage A2 TAN/WHT 33 Brake Fluid Level Switch Signal A3 TAN 185 Low Washer Fluid Indicator Signal A4 PNK 893 DIC Select Menue Switch Signal A5 DK GRN/WHT 1358 DIC Switch Signal A6-A8 - - Not Used A9 LT GRN/BLK 735 Ambient Air Temperature Sensor Signal A10 LT BLU 14 Left Turn Signal Lamps Supply Voltage A11 BRN/WHT 419 MIL Control A12 - - Not Used B1 GRY 1036 IPC Class 2 Serial Data B2 - - Not Used B3 GRY 8 Instrument Panel Lamp Supply Voltage B4 - - Not Used B5 BLK 1450 Ground B6 - - Not Used B7 PPL 1500 Ignition 0 Voltage B8 - - Not Used B9 BLK 1550 Ground B10 YEL 61 Low Reference B11 - - Not Used B12 ORN 640 Battery Positive Voltage

Ignition Key Alarm Switch Connector End Connector Part Information 12059254 2-Way M Metri-Pack 150 Series (LT GRN) Pin Wire Color Circuit No. Function A LT GRN 80 Key In Ignition Switch Signal B BLK 1550 Ground

Diagnostic Starting Point - Instrument Panel, Gages and Console

Begin the IP or DIC system diagnosis with Diagnostic System Check - Instrument Cluster , the HUD system diagnosis with Diagnostic System Check - Head Up Display , or the audible warning system diagnosis with Diagnostic System Check - Audible Warnings . The Diagnostic System Check will provide the following information

1. The identification of the control module(s) which command the system.
2. The ability of the control module(s) to communicate through the serial data circuit.
3. The identification of any stored diagnostic trouble codes (DTCs) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The number(s) below refer to the step number(s) on the diagnostic table.

1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 3: The symptom list in Symptoms will determine the correct diagnostic procedure to use.
3. 4: The presence of DTCs which begin with "U" indicate that loss of Class 2 communications has occurred.

Diagnostic System Check - Instrument Cluster

The number(s) below refer to the step number(s) on the diagnostic table.

1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 3: The symptom list in Symptoms will determine the correct diagnostic procedure to use.
3. 4: The presence of DTCs which begin with "U" indicate that loss of Class 2 communications has occurred.

Diagnostic System Check - Head Up Display

The number(s) below refer to the step number(s) on the diagnostic table.

1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 3: The symptom list in Symptoms will determine the correct diagnostic procedure to use.
3. 4: The presence of DTCs which begin with "U" indicate that loss of Class 2 communications has occurred.

Diagnostic System Check - Audible Warnings

Scan Tool Output Controls

Scan Tool Output Controls

Scan Tool Data List

The scan tool data list(s) contain all the instrument panel, gages, and console related parameters that are available on the scan tool. The parameters in the list are arranged in order, as they appear on the scan tool. The data list column indicates the location of the parameter within the scan tool menu selections.

Use the scan tool data list(s) as directed by a diagnostic table or in order to supplement the diagnostic procedures. Begin all of the diagnostic procedures with Diagnostic System Check - Instrument Cluster , Diagnostic System Check - Head Up Display , or Diagnostic System Check - Audible Warnings .

Use the scan tool data list(s) only after the following is determined

1. There is no published DTC procedure nor published symptom procedure for the customer concern.
2. The DTC or symptom procedure indicated by the diagnostic system check does not resolve the customer concern.

The typical data values are obtained from a properly operating vehicle under the conditions specified in the first row of the scan tool data list table. Comparison of the parameter values from the suspect vehicle with the typical data values may reveal the source of the customer concern.

Body Control Module (BCM)

Instrument Panel Cluster (IPC)

Powertrain 3.4L

Powertrain 3.6L

Diagnostic Trouble Code (DTC) List

Diagnostic Trouble Code (DTC) List

Circuit Description

The instrument panel cluster (IPC) monitors the ignition 0 voltage circuit when the ignition switch is in either the ON position or the OFF position. If the IPC senses that the ignition 0 voltage circuit is low for greater than 3 seconds, DTC B1369 is set.

Conditions for Running the DTC

1. The ignition switch is ON.
2. At least 3 seconds has elapsed since the ignition switch was cycled ON.

Conditions for Setting the DTC

The ignition 0 input is low during power up or while in RUN for greater than 3 seconds.

Action Taken When the DTC Sets

1. The IPC stores DTC B1369 in memory.
2. The IPC will store conditions which were present when the DTC set as Failure Records data only. The information will not be stored as Freeze Frame data.

Conditions for Clearing the DTC

1. A current DTC B1369 will clear when the malfunction is no longer present and the ignition switch is cycled.
2. A history DTC B1369 will be cleared after 100 ignition cycles with no current codes active during the 100 ignition cycles.
3. The IPC receives the clear code command from the scan tool.

Diagnostic Aids

If the DTC is a history DTC, the problem may be intermittent. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

The number below refers to the step number on the diagnostic table.

1. 3: This step determines if the ignition 0 voltage circuit is open or shorted to ground.

DTC B1369

The instrument panel cluster (IPC) monitors the signal circuit of the internal trip odometer reset switch in order to change odometer displays and to reset the odometer value. The IPC detects a switch activation when the signal circuit is low.

The IPC must have normal operating battery voltage.

The IPC detects that the trip odometer reset switch signal circuit is low for greater than 60 seconds.

The IPC ignores the trip odometer reset switch signal circuit. The IPC sets DTC B2823.

1. A history DTC B2823 will clear after a complete ignition cycle.
2. The IPC receives the clear code command from the scan tool.

1. The IPC will store the code as current only as long as the failure exists. An intermittent failure will be stored as a history DTC B2823.
2. If DTC B2823 is set only in history, press and release the trip reset switch several times in order to verify the customer concern.

DTC B2823 or B3574

The instrument panel cluster (IPC) monitors the DIC mode switch and the DIC reset switch in order to perform certain functions. The IPC detects a switch activation when the signal circuit is low.

The IPC must have normal operating battery voltage.

B2838

The IPC detects that the reset switch signal circuit is low for greater than 60 seconds.

B3564

The IPC detects that the mode switch signal circuit is low for greater than 60 seconds.

The IPC ignores the DIC mode switch or the DIC reset switch.

1. A current DTC B3564 or B2838 will clear after a complete ignition cycle if the fault is no longer present.
2. The IPC receives the clear code command from the scan tool.

1. The IPC will store the code as current only as long as the failure exists. An intermittent failure will be stored as a history DTC B3564 or B2838.
2. If DTC B3564 or B2838 is set only in history, press and release the DIC mode (B3564) or reset (B2838) switch several times in order to verify the customer concern.

DTC B2838, B3564, B3569, or B3752

The body control module (BCM) uses a key in ignition input in order to control certain features in the vehicle. These features are in the following systems

1. Content Theft Deterrent, if equipped
2. Audible Warnings
3. Automatic Door Locks

The ignition switch switches the key in ignition input circuit to ground when you fully insert the ignition key into the ignition switch. This in turn pulls the BCM key in ignition input low.

The ignition is on.

1. The ignition 0 input is active, high signal and the key in ignition input is inactive, high signal.
2. The conditions above must be present for more than 0.3 seconds.

The BCM stores DTC B2961 in memory.

1. The DTC becomes history when the fault is no longer present.
2. A history DTC will clear after 100 consecutive ignition cycles if the condition for the malfunction is no longer present.
3. The BCM receives the clear code command from the scan tool.

DTC B2961

The fuel level sender changes resistance based on fuel level. The engine control module (ECM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the ECM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the ECM senses a low signal voltage. The ECM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel percent in the tank. The ECM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and EVAP diagnostics.

This diagnostic tests for a stuck primary fuel level sensor signal. The ECM sets this DTC if the primary fuel level sensor signal appears to be stuck based on a lack of signal variation expected during normal operation.

1. The engine is running.
2. No other fuel level sensor signal failure is present.

1. The ECM does not detect a change in fuel level in the primary fuel tank of at least 1.0L (0.246 gal).
2. The difference between fuel consumed by the engine and a change in fuel level signal exceeds 46%.
3. The above condition is present for at least 300 seconds.

1. The fuel gage defaults to empty.
2. The driver information center (DIC) displays the FUEL LEVEL LOW message.
3. The ECM records the operating conditions at the time that the diagnostic test fails. The ECM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives the clear code command from the scan tool.

1. Use the Freeze Frame/Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame/Failure Records data may help in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also help in determining the number of ignition cycles that the diagnostic test reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions, including those for RPM, for engine load, for vehicle speed, for temperature, and for others. This will isolate at what point the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

DTC P0461

The fuel level sender changes resistance based on fuel level. The powertrain control module (PCM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the PCM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the PCM senses a low signal voltage. The PCM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel (percent) in the tank. The PCM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and evaporative emission (EVAP) diagnostics.

1. The ignition is ON.
2. The system voltage is between 11-16 volts.

1. The fuel level signal is less than 0.4 volts.
2. The above condition is present for at least 10 seconds.

1. The fuel gage defaults to empty.
2. The check gages indicator illuminates.
3. The PCM records the operating conditions at the time the diagnostic fails. The PCM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The PCM receives the clear code command from the scan tool.

1. Use the Freeze Frame and/or Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame and/or Failure Records data may aid in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also aid in determining the number of ignition cycles that the diagnostic reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions (RPM, engine load, vehicle speed, temperature, etc.). This will isolate when the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

The number below refers to the step number on the diagnostic table.

1. 3: Tests for the proper operation of the circuit in the high voltage range.

DTC P0462 (LA1)

The fuel level sender changes resistance based on fuel level. The engine control module (ECM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the ECM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the ECM senses a low signal voltage. The ECM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel (percent) in the tank. The ECM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and evaporative emission (EVAP) diagnostics.

1. The engine is running.
2. The system voltage is between 10.5-18 volts.

1. The fuel level signal is less than 0.25 volts.
2. The above condition is present for at least 60 seconds.

1. The fuel gage defaults to empty.
2. The check gages indicator illuminates.
3. The ECM records the operating conditions at the time the diagnostic fails. The ECM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives the clear code command from the scan tool.

1. Use the Freeze Frame and/or Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame and/or Failure Records data may aid in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also aid in determining the number of ignition cycles that the diagnostic reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions (RPM, engine load, vehicle speed, temperature, etc.). This will isolate when the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

The number below refers to the step number on the diagnostic table.

1. 3: Tests for the proper operation of the circuit in the high voltage range.

DTC P0462 (LY7)

The fuel level sender changes resistance based on fuel level. The powertrain control module (PCM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the PCM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the PCM senses a low signal voltage. The PCM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel (percent) in the tank. The PCM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and evaporative emission (EVAP) diagnostics.

1. The ignition is ON.
2. The system voltage is between 11-16 volts.

1. The fuel level signal is greater than 3 volts.
2. The above condition is present for at least 10 seconds.

1. The fuel gage defaults to empty.
2. The check gages indicator illuminates.
3. The PCM records the operating conditions at the time the diagnostic fails. The PCM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The PCM receives the clear code command from the scan tool.

1. Use the Freeze Frame and/or Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame and/or Failure Records data may aid in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also aid in determining the number of ignition cycles that the diagnostic reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions (RPM, load, vehicle speed, temperature, etc.). This will isolate when the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

The number below refers to the step number on the diagnostic table.

1. 3: Tests for the proper operation of the circuit in the low voltage range.

DTC P0463 (LA1)

The fuel level sender changes resistance based on fuel level. The engine control module (ECM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the ECM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the ECM senses a low signal voltage. The ECM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel (percent) in the tank. The ECM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and evaporative emission (EVAP) diagnostics.

1. The engine is running.
2. The system voltage is between 10.5-18 volts.

1. The fuel level signal is greater than 3.2 volts.
2. The above condition is present for at least 60 seconds.

1. The fuel gage defaults to empty.
2. The check gages indicator illuminates.
3. The ECM records the operating conditions at the time the diagnostic fails. The ECM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives the clear code command from the scan tool.

1. Use the Freeze Frame and/or Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame and/or Failure Records data may aid in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also aid in determining the number of ignition cycles that the diagnostic reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions (RPM, load, vehicle speed, temperature, etc.). This will isolate when the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.

The number below refers to the step number on the diagnostic table.

1. 3: Tests for the proper operation of the circuit in the low voltage range.

DTC P0463 (LY7)

The engine oil pressure (EOP) switch is a normally closed switch that opens with the proper oil pressure. With the ignition switch turned ON and the engine not running, the powertrain control module (PCM) should detect a low signal voltage input. With the engine running, the pressure switch opens, and the PCM should detect a high signal voltage input. The PCM tests the state of the EOP circuit with the ignition switch turned ON, and the engine turned OFF. If the PCM detects a high voltage input on the EOP signal circuit, DTC P1189 will set.

1. The ignition is ON, with the engine OFF.
2. DTCs P0117, P0118, P1111, and P1114 are not set.

1. The PCM detects that the EOP switch signal circuit is high.
2. The above condition is present for greater than 10 seconds.

1. The PCM will not illuminate the malfunction indicator lamp (MIL).
2. The PCM will store conditions which were present when the DTC set as Fail Records data only. The information will not be stored as Freeze Frame data.

Conditions for Clearing the MIL/DTC

1. A history DTC will clear after 40 consecutive warm-up cycles have occurred without a malfunction.
2. The PCM receives the clear code command from the scan tool.

DTC P0520

The engine oil pressure (EOP) sensor changes resistance based on engine oil pressure. The engine control module (ECM) monitors the signal circuit of the EOP sensor. When the oil pressure is high, the sensor resistance is high, and the ECM senses a high signal voltage. When the oil pressure is low, the sensor resistance is low, and the ECM senses a low signal voltage. The ECM sends the EOP information to the instrument panel cluster (IPC) via the class 2 serial data circuit.

The engine is running.

The ECM does not detect a change in the EOP of at least 34.5 kPa (5.0 psi) over a predetermined variance of the engine speed.

1. The ECM records the operating conditions at the time the diagnostic test fails. The ECM displays this information in the Failure Records on the scan tool.
2. The IPC illuminates the EOP indicator.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives a clear code command from the scan tool.

Using the Failure Records data may help locate an intermittent condition. If you cannot duplicate the DTC, the information in the Failure Records can help determine how many miles since the DTC set. The Fail Counter and Pass Counter can help determine how many ignition cycles that the diagnostic test reported a pass and/or a fail.

Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

DTC P0521

The engine oil pressure (EOP) sensor changes resistance based on engine oil pressure. The engine control module (ECM) monitors the signal circuit of the EOP sensor. When the oil pressure is high, the sensor resistance is high, and the ECM senses a high signal voltage. When the oil pressure is low, the sensor resistance is low, and the ECM senses a low signal voltage. The ECM sends the EOP information to the instrument panel cluster (IPC) via the class 2 serial data circuit.

The engine is running.

1. The ECM detects that the EOP sensor signal circuit is less than 0.4 volts.
2. The above condition is present for greater than 10 seconds.

1. The ECM records the operating conditions at the time the diagnostic test fails. The ECM displays this information in the Failure Records on the scan tool.
2. The IPC illuminates the EOP indicator.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives a clear code command from the scan tool.

Using the Failure Records data may help locate an intermittent condition. If you cannot duplicate the DTC, the information in the Failure Records can help determine how many miles since the DTC set. The Fail Counter and Pass Counter can help determine how many ignition cycles that the diagnostic test reported a pass and/or a fail.

Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step tests for the proper operation of the circuit in the high voltage range.

DTC P0522

The engine oil pressure (EOP) sensor changes resistance based on engine oil pressure. The engine control module (ECM) monitors the signal circuit of the EOP sensor. When the oil pressure is high, the sensor resistance is high, and the ECM senses a high signal voltage. When the oil pressure is low, the sensor resistance is low, and the ECM senses a low signal voltage. The ECM sends the EOP information to the instrument panel cluster (IPC) via the class 2 serial data circuit.

The engine is running.

1. The ECM detects that the EOP sensor signal circuit is greater than 4.6 volts.
2. The above condition is present for greater than 9 seconds.

The ECM records the operating conditions at the time that the diagnostic test fails. The ECM displays this information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC is cleared after 40 malfunction-free warm-up cycles.
3. The ECM receives the clear code command from the scan tool.

Using the Failure Records data may help locate an intermittent condition. If you cannot duplicate the DTC, the information in the Failure Records can help in determining how many miles since the DTC set. The Fail Counter and the Pass Counter can help determine how many ignition cycles that the diagnostic test reported a pass and/or a fail.

Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step tests for the proper operation of the circuit in the low voltage range.

DTC P0523

The fuel level sender changes resistance based on fuel level. The engine control module (ECM) monitors the signal circuit of the fuel level sender in order to determine fuel level. When the fuel tank is full, the sender resistance is high and the ECM senses a high signal voltage. When the fuel tank is empty, the sender resistance is low and the ECM senses a low signal voltage. The ECM uses the signal circuit of the fuel level sender in order to calculate the total remaining fuel percent in the tank. The ECM sends the fuel level percent via the class 2 serial data circuit to the instrument cluster in order to control the fuel gage. The fuel level information is also used for misfire and EVAP diagnostics.

This diagnostic tests for a stuck primary fuel level sensor signal. The ECM sets this DTC if the primary fuel level sensor signal appears to be stuck based on a lack of signal variation expected during normal operation.

1. The engine is running.
2. No other fuel level sensor signal failure is present.

1. The ECM does not detect a change in fuel level in the primary fuel tank of at least 1.0L (0.246 gal).
2. The difference between fuel consumed by the engine and a change in fuel level signal exceeds 46%.
3. The above condition is present for at least 300 seconds.

1. The fuel gage defaults to empty.
2. The driver information center (DIC) displays the FUEL LEVEL LOW message.
3. The ECM records the operating conditions at the time that the diagnostic test fails. The ECM displays the failure information in the Failure Records on the scan tool.

1. The DTC becomes history when the conditions for setting the DTC are no longer present.
2. The history DTC clears after 40 malfunction free warm-up cycles.
3. The ECM receives the clear code command from the scan tool.

1. Use the Freeze Frame/Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame/Failure Records data may help in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also help in determining the number of ignition cycles that the diagnostic test reported a pass and/or fail. Operate the vehicle within the same freeze frame conditions, including those for RPM, for engine load, for vehicle speed, for temperature, and for others. This will isolate at what point the DTC failed.
2. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.
3. For diagnosis refer to «DTC P0461»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

Symptoms - Instrument Panel, Gages and Console

1. Perform the «Diagnostic System Check - Instrument Cluster»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) , the «Diagnostic System Check - Head Up Display»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) , or the «Diagnostic System Check - Audible Warnings»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The modules can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following: «Instrument Panel Cluster (IPC) Description and Operation»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) «Indicator/Warning Message Description and Operation»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__indicatorwarning-message-description-and-operation) «Driver Information Center (DIC) Description and Operation»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__driver-information-center-dic-description-and) «Head Up Display (HUD) Description and Operation»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__head-up-display-hud-description-and) «Audible Warnings Description and Operation»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__audible-warnings-description-and-operation)

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the instrument cluster, the driver information display, or the audible warnings. Refer to «Checking Aftermarket Accessories»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__checking-aftermarket-accessories) in Wiring Systems.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.
3. For any indicator or message relating to fluid level, perform a visual inspection of the fluid level before beginning diagnosis.
4. Verify that the indicators and message display works properly during the displays check.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

Audible Warnings

1. «Chime Always On»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__chime-always-on)
2. «Chime Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__chime-inoperative)

Driver Information Center (DIC)

1. «Driver Information Center (DIC) Temperature Display Always Reads SC»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__driver-information-center-dic-temperature-display)
2. «Driver Information Center (DIC) Temperature Display Always Reads OC»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__driver-information-center-dic-temperature-display)
3. «Outside Air Temperature Display Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console)
4. «Driver Information Center (DIC) Compass Inaccurate or C Displayed»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__driver-information-center-dic-compass-inaccurate)
5. «Driver Information Center (DIC) Switch(es) Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__driver-information-center-dic-switches-inoperative)

Gages

1. «Engine Coolant Temperature Gage Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__engine-coolant-temperature-gage-inaccurate-or)
2. «Fuel Gage Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console)
3. «Odometer Trip/Reset Switch Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__odometer-tripreset-switch-inoperative)
4. «Speedometer and/or Odometer Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console)
5. «Tachometer Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__tachometer-inaccurate-or-inoperative)

Heads Up Display

1. «Head Up Display (HUD) Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__head-up-display-hud-inoperative)
2. «Head Up Display (HUD) Turn Signal Indicator Inoperative - Left/Right»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__head-up-display-hud-turn-signal)
3. «Head Up Display (HUD) Image Adjustment Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__head-up-display-hud-image-adjustment)
4. «Head Up Display (HUD) Intensity Does Not Vary»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__head-up-display-hud-intensity-does)

Indicators

1. «ABS Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
2. «ABS Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
3. «Air Bag Indicator Circuit Malfunction»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) in SIR
4. «Brake Warning Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/mechanical-hydraulic/#hydraulic-brake-system) in Hydraulic Brakes
5. «Brake Warning Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/mechanical-hydraulic/#hydraulic-brake-system__brake-warning-indicator-inoperative) in Hydraulic Brakes
6. «Change Engine Oil Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__change-engine-oil-indicator-always-on)
7. «Change Engine Oil Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__change-engine-oil-indicator-inoperative)
8. «Charge Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system__charge-indicator-always-on) in Engine Electrical
9. «Charge Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system__charge-indicator-inoperative) in Engine Electrical
10. «Door Ajar Indicator Malfunction»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-ajar-indicator-malfunction) in Doors
11. «Engine Coolant Temperature Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/cooling-fan/#engine-cooling-system__engine-coolant-temperature-indicator-always-on) in Engine Cooling
12. «Engine Oil Pressure Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__engine-oil-pressure-indicator-always-on)
13. «High Beam Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems__high-beam-indicator-inoperative) in Lighting Systems
14. «Low Engine Oil Level Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__low-engine-oil-level-indicator-always)
15. For LOW FUEL indicator refer to «Fuel Gage Inaccurate or Inoperative»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console)
16. «Low Traction Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
17. «Low Traction Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
18. «Low Washer Fluid Indicator Malfunction»(/buick/rendezvous/i-2001-2007/remont/wiperwasher-systems/#wiper-system-washer-system__low-washer-fluid-indicator-malfunction) in Wipers/Washer Systems
19. «Malfunction Indicator Lamp (MIL) Always On»(/buick/rendezvous/i-2001-2007/remont/testing-diagnostics/#engine-controls-34l-troubleshooting) in Engine Controls
20. «Malfunction Indicator Lamp (MIL) Inoperative»(/buick/rendezvous/i-2001-2007/remont/testing-diagnostics/#engine-controls-34l-troubleshooting) in Engine Controls
21. «Park Lamp Out Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems__park-lamp-out-indicator-inoperative) in Lighting Systems
22. «Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-ajar-indicator-malfunction-aztek) or «Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-ajar-indicator-malfunction-rendezvous) in Body Rear End
23. «Seat Belt Indicator Circuit Malfunction»(/buick/rendezvous/i-2001-2007/remont/restraints-control-systems/#seat-belt-system__seat-belt-indicator-circuit-malfunction) in Seat Belts
24. «Security Indicator LED Inoperative»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#theft-deterrent-system__security-indicator-led-inoperative) in Theft Deterrent
25. «Traction Off Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
26. «Traction Off Indicator Inoperative»(/buick/rendezvous/i-2001-2007/remont/anti-locktraction-control/#antilock-brake-system-and-traction-control-system) in ABS
27. «Turn Signal Lamps and/or Indicators Inoperative»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems__turn-signal-lamps-andor-indicators-inoperative) in Lighting Systems

Engine Coolant Temperature Gage Inaccurate or Inoperative

Engine Coolant Temperature Gage Inaccurate or Inoperative

1. Ensure that the fuel level is in the same range as the customer concern.
2. For intermittent diagnosis, refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.
3. Refer to «Fuel Level Specifications»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console__fuel-level-specifications) in order to verify the correct fuel level sender readings. The Fuel Level Sensor parameter is available on the scan tool in the ECM/PCM EVAP Data list.

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step tests for a high resistance in the signal circuit and the low reference circuit of the fuel level sender.
2. 13: DTCs will be set in the engine control module (ECM)/powertrain control module (PCM) when you perform this diagnostic table.

Fuel Gage Inaccurate or Inoperative

Odometer Trip/Reset Switch Inoperative

Odometer Trip/Reset Switch Inoperative

The number below refers to the step number on the diagnostic table.

1. 5: This test procedure may cause DTCs to set, which may cause other systems to be inoperative or disabled.

Speedometer and/or Odometer Inaccurate or Inoperative

Tachometer Inaccurate or Inoperative

Tachometer Inaccurate or Inoperative

Change Engine Oil Indicator Always On

Change Engine Oil Indicator Always On

Change Engine Oil Indicator Inoperative

Change Engine Oil Indicator Inoperative

Engine Oil Pressure Indicator Always On

Engine Oil Pressure Indicator Always On

Low Engine Oil Level Indicator Always On

Low Engine Oil Level Indicator Always On

Driver Information Center (DIC) Temperature Display Always Reads SC

Driver Information Center (DIC) Temperature Display Always Reads SC

Driver Information Center (DIC) Temperature Display Always Reads OC

Driver Information Center (DIC) Temperature Display Always Reads OC

Driver Information Center (DIC) Compass Inaccurate or C Displayed

Driver Information Center (DIC) Compass Inaccurate or C Displayed

Driver Information Center (DIC) Switch(es) Inoperative

Driver Information Center (DIC) Switch(es) Inoperative

The numbers below refer to the step numbers on the diagnostic table.

1. 3: This step tests for a high resistance in the signal circuit and the ground circuit of the ambient air temperature sensor.
2. 10: DTCs may be set in the IPC when you perform this diagnostic table.

Outside Air Temperature Display Inaccurate or Inoperative

Head Up Display (HUD) Inoperative

Head Up Display (HUD) Inoperative

Head Up Display (HUD) Turn Signal Indicator Inoperative - Left/Right

Head Up Display (HUD) Turn Signal Indicator Inoperative - Left/Right

Head Up Display (HUD) Image Adjustment Inoperative

Head Up Display (HUD) Image Adjustment Inoperative

Head Up Display (HUD) Intensity Does Not Vary

Head Up Display (HUD) Intensity Does Not Vary

Chime Always On

Chime Always On

Chime Inoperative

Chime Inoperative

Tools Required

J 38778 Door Trim Pad Clip Remover. See Special Tools and Equipment .

Removal Procedure

1. Open the hood.
2. Remove the right headlamp assembly. Refer to «Headlamp Assembly or Headlamp Bulb Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) or «Headlamp Assembly or Headlamp Bulb Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
3. Disconnect the electrical connector from the ambient air temperature sensor.
4. Use J 38778 in order to remove the push-in retainer which secures the ambient air temperature sensor to the radiator core support. See «Special Tools and Equipment»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
5. Remove the ambient air temperature sensor from the vehicle.

Installation Procedure

1. Align the ambient air temperature sensor to the vehicle.
2. Install the push-in retainer which secures the ambient air temperature sensor to the radiator core support.
3. Connect the electrical connector to the ambient air temperature sensor.
4. Install the right headlamp assembly. Refer to «Headlamp Assembly or Headlamp Bulb Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) or «Headlamp Assembly or Headlamp Bulb Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
5. Close the hood.

1. Open the hood.
2. Remove the clip from the hood latch.
3. Disconnect the electrical connector from the sensor.
4. Remove the ambient air temperature gage sensor from the electrical harness clip.

1. Connect the electrical connector to the ambient air temperature gage sensor.
2. Install the sensor to the electrical harness clip.
3. Install the clip to the hood latch.
4. Close the hood.

1. Remove the front floor console. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the I/P accessory trim plate. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
3. Remove the bolts from the switch assembly.
4. Remove the electrical connectors from the switch assembly.
5. Remove the switch assembly.

1. Install the electrical connections to the switch assembly.
2. Install the bolts to the switch assembly of the rear object alarm module. Tighten: Tighten the bolts to 2 N.m (18 lb in)
3. Install the I/P accessory trim plate. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
4. Install the front floor console. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

Compass Calibration

To calibrate the compass depress and hold the Set button for 3 seconds while the DIC is in the Compass/Temperature mode. The DIC then displays ZONE XX PRESS AND HOLD SET TO CHANGE. Press the set button to change the variation zone. Then press the Mode button. The DIC displays PRESS SET TO CALIBRATE COMPASS. Press the Set button. Then the DIC displays DRIVE VEHICLE IN CIRCLES. Drive the vehicle in 3 complete circles at least 5 mph in a magnetically clean area. While driving the vehicle in circles the DIC will display CALIBRATING. When the calibration is completed the DIC displays the normal mode of compass/temperature.

Scheme 14

Compass variation is the difference between magnetic north and geographic north. In some areas of the country the difference is great enough to cause the compass to give a false reading. If this occurs, the compass variance must be set. View the Variance Zone Display to determine the correct zone. The zones are numbered 1-15. Depress and hold both the MODE and the SET buttons simultaneously while the DIC is in the Compass/Temperature mode for 5 seconds. After 5 seconds, the DIC will display the current variation setting. Release the buttons and adjust to the correct variation number using the MODE button. Consult the map for variation zone numbers. When the desired variation is reached press the Set button to accept.

You cannot reset the Compass/Temperature mode. This mode is retained during ignition OFF.

1. Use a small, Flat Based Tool to remove the driver information center, head up display switch from the cluster trim plate.
2. Remove the electrical connectors from the switch.
3. Remove the switch.

1. Install the electrical connectors to the head up display switch.
2. Install the head up display switch to the cluster trim plate.
3. Push the switch assembly to the cluster trim plate until seated.

1. Use a flat-bladed tool to press down and release the clip at the top of the Driver Information Center Switch.
2. Disconnect the electrical connectors.
3. Remove the driver information center switch.

1. Connect the electrical connectors to the switch.
2. Install the driver information center switch to the IP trim plate.
3. Push the switch assembly to the IP trim plate until the assembly is fully seated.

1. Remove the IP upper trim pad. Refer to «Trim Pad Replacement - Instrument Panel (I/P) Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Pad Replacement - Instrument Panel (I/P) Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Disconnect the electrical connectors.
3. Remove the bolts that secure the heads up display module to the IP.
4. Remove the heads up display module.

1. Install the heads up display module.
2. Install the bolts that secure the heads up display module to the IP. Tighten: Tighten the bolts to 2 N.m (18 lb in).
3. Connect the electrical connectors.
4. Install the IP upper trim pad. Refer to «Trim Pad Replacement - Instrument Panel (I/P) Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Pad Replacement - Instrument Panel (I/P) Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the push-in retainers from the IP insulator to instrument panel.
2. Remove the press-on retainers from the IP insulator to dash mat.
3. Unsnap the IP courtesy lamp from the IP insulator.
4. Remove the IP insulator from the instrument panel.

1. Snap the IP courtesy lamp into the IP insulator.
2. Position the IP insulator to the instrument panel.
3. Install the push-in retainers to the IP insulator to instrument panel.
4. Install the press-on retainers to the IP insulator to dash mat.

1. Remove the push-in retainers from the IP insulator to instrument panel.
2. Remove the press-on retainers from the IP insulator to dash mat.
3. Unsnap the IP courtesy lamp from the IP insulator.
4. Remove the IP insulator from the instrument panel.

1. Snap the IP courtesy lamp into the IP insulator.
2. Position the IP insulator to the instrument panel.
3. Install the push-in retainers to the IP insulator to instrument panel.
4. Install the press-on retainers to the IP insulator to dash mat.

1. Remove the IP insulator. Refer to «Closeout/Insulator Panel Replacement - Right»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) and «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the bolts from the bottom of the knee bolster.
3. Pull on the knee bolster in order to release the upper clips.

1. Perform the following steps in order to install the knee bolster to the instrument panel: Align the clips with the slots in the instrument panel. Push in, in order to secure the knee bolster.
2. Install the bolts to the bottom of the knee bolster. Tighten: Tighten the bolts/screws to 2.5 N.m (22 lb in).
3. Install the IP insulator. Refer to «Closeout/Insulator Panel Replacement - Right»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) and «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Position the floor shifter in the Drive position.
2. Remove the front floor console. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
3. Remove 2 screws from the lower trim plate.
4. Remove the instrument panel (I/P) accessory trim plate by releasing the retainers.

1. Align the retainers on the I/P accessory trim plate to the slots in the I/P.
2. Install the retainers into the slots until the retainers are fully seated.
3. Install the 2 screws to the lower trim plate. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Install the front floor console. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the screws from the I/P cluster trim plate at the assist handle.
3. Pull out the I/P cluster trim plate in order to release from the retainers.
4. From the back side disconnect the driver information center (DIC) from the I/P cluster trim plate panel.
5. Loosen the steering column bracket and lower the steering column.
6. Remove the I/P cluster trim plate.

1. Align the I/P cluster trim plate to the instrument panel retainers.
2. Connect the DIC to the I/P cluster trim plate panel.
3. Install the I/P cluster trim plate. Press into place until fully seated.
4. Install the screws to the I/P cluster trim plate at the assist handle. Tighten: Tighten the screws to 2 N.m (18 lb in).
5. Install the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
6. Tighten the bolts which secure the steering column bracket. Tighten: Tighten the bolts to 6 N.m (53 lb in).

1. Remove the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the driver information center (DIC) switch from the trim plate bezel. Refer to «Driver Information Center Switch Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Driver Information Center Switch Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
3. Loosen the steering column bracket. Lower the steering column.
4. Remove the trim plate bezel from the instrument panel cluster.

1. Install the trim plate bezel. Press the bezel into place until seated.
2. Tighten the steering column bracket nuts. Tighten: Tighten the nuts to 24 N.m (18 lb ft).
3. Install the DIC switch to the trim plate bezel. Refer to «Driver Information Center Switch Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Driver Information Center Switch Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
4. Install the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

Scheme 15

1. Remove the instrument panel (IP) trim cover by pulling outward to disengage the retainers.
2. Remove the IP trim cover.

1. Align the tabs on the IP trim cover to slots in the IP retainers.
2. Install the IP trim cover by pressing into the retainers until fully seated.

1. Open the instrument panel compartment.
2. Remove the bolts from the instrument panel compartment hinge.
3. Remove the instrument panel compartment from the instrument panel.

1. Align the instrument panel compartment to the instrument panel.
2. Install the bolts to the instrument panel compartment hinge. Tighten: Tighten the instrument panel compartment hinge bolts to 4 N.m (35 lb in).
3. Close the instrument panel compartment.

1. Open the instrument panel (IP) compartment.
2. Remove the bolts that secure the IP compartment striker.
3. Remove the IP compartment striker.

1. Install the IP compartment striker and bolts. Tighten: Tighten the fasteners to 2 N.m (18 lb in).
2. Close the IP compartment.
3. Inspect the IP compartment for the proper alignment and adjust as necessary.

1. Open the instrument panel (I/P) compartment.
2. Remove the screws from the I/P compartment hinge.
3. Remove the I/P compartment door from the I/P.
4. Remove the lower I/P compartment trim panel.
5. Drill out the rivets holding the I/P compartment hinge to the I/P panel.
6. Remove the I/P compartment hinge.

1. Fasten the hinge to the lower compartment trim panel with new rivets.
2. Install the lower I/P compartment trim panel.
3. Align the I/P compartment door with the hinge assembly and secure with the I/P compartment screws. Tighten: Tighten the screws to 4 N.m (3 lb in)
4. Verify the alignment of the I/P compartment door.
5. Close the I/P compartment door.

1. Open the instrument panel (I/P) compartment door assembly.
2. Remove the screws retaining the I/P compartment door latch to the door.
3. Remove the door handle.

1. Install the door handle into position in the I/P compartment door.
2. Install the I/P compartment door latch retaining screws. Tighten: Tighten the IP compartment door latch retaining screws to 2 N.m (18 lb in).
3. Close the I/P compartment door assembly.

1. Open the instrument panel (I/P) compartment door.
2. Remove the I/P compartment handle screws. Refer to «Handle Replacement - Instrument Panel (I/P) Compartment (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
3. Remove the I/P compartment handle from the I/P compartment.
4. Insert the key into the I/P compartment door lock cylinder.
5. Insert a small diameter tool into the slot on the upper side of the door handle cylinder housing. Depress and hold the lock cylinder retainer.
6. While the lock cylinder retainer is still depressed, turn the key clockwise to the 3 o'clock position.
7. Pull to remove the lock cylinder.

1. Insert the key into the lock cylinder.
2. Align the lock cylinder in the same position used for removal. Push the cylinder in place to seat fully.
3. Turn the key counterclockwise to secure the lock cylinder retainer.
4. Remove the key from the lock cylinder.
5. Inspect the operation of the lock cylinder. The lock cylinder should only allow a 1/4 turn and should be securely retained in the door handle.
6. Align and install the I/P compartment handle to the I/P compartment. Refer to «Handle Replacement - Instrument Panel (I/P) Compartment (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
7. Close the I/P compartment door.

1. Remove the instrument panel (I/P) cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the nuts from the assist handle and remove the assist handle.

1. Install the assist handle to the instrument panel. Install the assist handle nuts. Tighten: Tighten the nuts to 8 N.m (71 lb in).
2. Install the I/P cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Lift the instrument panel (I/P) upper trim panel approximately 51 mm (2.0 in) and pull rearward to release the retainers.
3. Remove the DRL ambient light sensor. Refer to «Daytime Running Lamps (DRL) Ambient Light Sensor Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
4. If equipped, remove the sun load sensor.
5. Remove the I/P upper trim panel.

1. Align the locating pins and the retainers from the upper trim panel to the slots in the I/P.
2. Install the DRL ambient light sensor. Refer to «Daytime Running Lamps (DRL) Ambient Light Sensor Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
3. If equipped, install the sun load sensor.
4. Push forward and down on the upper trim panel to lock into place.
5. Install the windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

1. Remove the windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Lift the upper trim panel approximately 51 mm (2.0 in) and pull rearward to release the upper trim panel retainers from the instrument panel (I/P).
3. Remove the DRL ambient light sensor. Refer to «Daytime Running Lamps (DRL) Ambient Light Sensor Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
4. If equipped, remove the sun load sensor.
5. Remove the I/P upper trim panel.

1. Align the locating pins and the retainers from the upper trim panel to the slots in the I/P.
2. Install the DRL ambient light sensor. Refer to «Daytime Running Lamps (DRL) Ambient Light Sensor Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
3. If removed, install the sun load sensor.
4. Push forward and down on the I/P upper trim panel to lock into place.
5. Install the windshield garnish molding. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

1. Use a flat-bladed tool to pry the cover of the driver information center panel from the instrument panel.
2. Disconnect the electrical connectors from the driver information center panel.
3. Remove the driver information center panel from the instrument panel.

1. Connect the electrical connectors to the driver information center panel.
2. Install the driver information center panel to the instrument panel. Press firmly into place until fully seated.

1. Use a flat-bladed tool to press down and release the clip at the top of the Driver Information Center Switch.
2. Disconnect the electrical connectors.
3. Remove the driver information center switch.

1. Connect the electrical connectors to the switch.
2. Install the driver information center switch to the IP trim plate.
3. Push the switch assembly to the IP trim plate until the assembly is fully seated.

1. Remove the instrument panel (I/P) cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the screws from the I/P cluster.
3. Disconnect the electrical connectors from the I/P cluster.
4. Remove the I/P cluster.

1. Connect the electrical connectors to the I/P cluster.
2. Install the I/P cluster.
3. Install the screws to the I/P cluster. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Install the I/P cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
5. Calibrate the electronic compass. Refer to «Electronic Compass Calibration»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Disconnect the battery negative cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LA1)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) or «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
2. Disable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or to «SIR Disabling and Enabling Zone 5»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling-zone-5) in SIR.
3. Remove the covers from the right and the left access holes on the instrument panel (I/P). Refer to «Instrument Panel (I/P) Outer Trim Cover Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
4. Remove the I/P insulators. Refer to «Closeout/Insulator Panel Replacement - Right»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) and to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
5. Remove the data link connector (DLC). Refer to «Data Link Connector Replacement»(/buick/rendezvous/i-2001-2007/remont/communication-devices/#data-link-communication-system) in Data Link Communications.
6. Remove the side upper garnish moldings from the windshield. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
7. Remove the upper trim pad from the I/P. Refer to «Trim Pad Replacement - Instrument Panel (I/P) Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Pad Replacement - Instrument Panel (I/P) Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
8. Remove the front floor console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
9. Remove the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
10. Remove the bolts from the lower steering column.
11. Remove the nuts from the upper steering column.
12. Lower the steering column.
13. Remove the hood release handle. Refer to «Hood Latch Release Handle Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-front-end) in Body Front End.
14. Remove the accessory trim plate from the I/P. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
15. Remove the I/P cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
16. Remove the I/P cluster. Refer to «Instrument Panel Cluster (IPC) Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
17. Remove the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) in Entertainment.
18. Remove the heater A/C control. Refer to «HVAC Control Module Replacement (Buick)»(/buick/rendezvous/i-2001-2007/remont/manual-hvac-system/#hvac-systems-manual) or «HVAC Control Module Replacement (Pontiac)»(/buick/rendezvous/i-2001-2007/remont/manual-hvac-system/#hvac-systems-manual) in HVAC Systems - Manual.
19. Remove the I/P compartment. Refer to «Compartment Replacement - Instrument Panel (I/P)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
20. Remove the I/P compartment lamp switch. Refer to «Instrument Panel (I/P) Compartment Lamp Switch Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) .
21. Remove the I/P mounting screws.
22. Reposition the I/P wiring harness.
23. Remove the instrument panel.

1. Align the instrument panel to the vehicle.
2. Reposition the I/P wiring harness.
3. Install the I/P mounting bolts at the cluster pocket. Tighten: Tighten the mounting bolts to 5.0 N.m (44 lb in).
4. Install the I/P mounting bolts at the windshield. Tighten: Tighten the mounting bolts to 5.0 N.m (44 lb in).
5. Install the I/P mounting bolts to the compartment. Tighten: Tighten the mounting bolts to 2.0 N.m (18 lb in).
6. Install the I/P compartment lamp switch. Refer to «Instrument Panel (I/P) Compartment Lamp Switch Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) .
7. Install the I/P compartment. Refer to «Compartment Replacement - Instrument Panel (I/P)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
8. Install the I/P cluster. Refer to «Instrument Panel Cluster (IPC) Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
9. Install the heater A/C control. Refer to «HVAC Control Module Replacement (Buick)»(/buick/rendezvous/i-2001-2007/remont/manual-hvac-system/#hvac-systems-manual) or «HVAC Control Module Replacement (Pontiac)»(/buick/rendezvous/i-2001-2007/remont/manual-hvac-system/#hvac-systems-manual) in HVAC Systems - Manual.
10. Install the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) in Entertainment.
11. Install the I/P cluster trim plate bezel. Refer to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
12. Install the I/P accessory trim plate. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
13. Install the hood release handle. Refer to «Hood Latch Release Handle Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-front-end) in Body Front End.
14. Raise the steering column.
15. Install the nuts to the upper steering column. Tighten: Tighten the nuts to 25 N.m (18 lb ft).
16. Install the bolts to the lower steering column. Tighten: Tighten the bolts to 25 N.m (18 lb ft).
17. Install the knee bolster panel. Refer to «Knee Bolster Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
18. Install the front floor console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
19. Install the I/P upper trim panel. Refer to «Trim Pad Replacement - Instrument Panel (I/P) Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Pad Replacement - Instrument Panel (I/P) Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
20. Install the windshield side upper garnish moldings. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
21. Install the I/P insulators. Refer to «Closeout/Insulator Panel Replacement - Right»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) and to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
22. Install the data link connector. Refer to «Data Link Connector Replacement»(/buick/rendezvous/i-2001-2007/remont/communication-devices/#data-link-communication-system) in Data Link Communications.
23. Install the I/P access hole covers. Refer to «Instrument Panel (I/P) Outer Trim Cover Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
24. Enable the SIR system. Refer to «SIR Disabling and Enabling Zone 3»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system) or to «SIR Disabling and Enabling Zone 5»(/buick/rendezvous/i-2001-2007/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling-zone-5) in SIR.
25. Connect the battery negative cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LA1)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) or «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.

1. Remove the instrument panel (I/P) trim pad. Refer to «Instrument Panel (I/P) Assembly Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the brake pedal bracket and the reinforcement. Refer to «Brake Pedal Assembly Replacement»(/buick/rendezvous/i-2001-2007/remont/mechanical-hydraulic/#hydraulic-brake-system) .
3. Reroute the transmission shift cable through the I/P carrier. Refer to «Automatic Transmission Range Selector Cable Adjustment»(/buick/rendezvous/i-2001-2007/remont/automatic-trans/#automatic-transaxle-4t65-e-introduction-service-replacement__automatic-transmission-range-selector-cable-adjustment) in Automatic Transmission.
4. Release the retaining clips from the I/P wiring harness and reposition the wiring harness out of the way.
5. Remove the bolts retaining the HVAC module to the I/P carrier.
6. Remove the left cross vehicle ground wire.
7. Remove the right cross vehicle ground wires.
8. Unbolt the cross vehicle anchor tether (1) and let the tether hang.
9. Unclip the antenna cable from the I/P carrier.
10. Remove the HVAC bracket from the I/P carrier bracket.
11. Remove the heads up display (HUD) bracket, if equipped. Refer to «Head Up Display Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
12. Remove the bolts retaining the I/P carrier to the left hinge pillar.
13. Remove the bolts retaining the I/P carrier to the right hinge pillar.
14. If you cannot remove the inner bolt because of interference with the windshield, gently bend the bolt stem when you remove the bolt from the I/P carrier. DISCARD the bolt.
15. Remove the I/P carrier from the vehicle through the main wire harness.
16. Remove the front defroster duct.

1. Install the front defroster duct.
2. Install the I/P carrier to the vehicle through the main wire harness.
3. If you had to bend the I/P carrier bolt during removal, perform the following procedure: Discard the bent bolt. Shorten a NEW bolt 4-5 mm (3/16 in) by cutting off the guide feature (1) as shown. if necessary, clean the threads prior to installation using a die. When installed, 5-6 threads of the bolt should protrude through the fastener.
4. Loosely install the bolts which secure the I/P carrier to the right hinge pillar.
5. Loosely install the bolts which secure the I/P carrier to the left hinge pillar.
6. Tighten all the bolts which secure the I/P carrier to the pillars. Tighten: Tighten the bolts to 25 N.m (18 lb ft).
7. Install the HVAC module to the I/P carrier with the retaining bolts. Tighten: Tighten the bolts to 10 N.m (89 lb in).
8. Install the bolts which retain the HVAC module to the center support bracket. Tighten: Tighten the bolts to 10 N.m (89 lb in).
9. Install the I/P wiring harnesses into position and secure the retaining clips.
10. Install the cross vehicle anchor tether (1).
11. Clip the antenna cable to the I/P carrier.
12. Install the HVAC bracket to the I/P carrier bracket.
13. Install the HUD bracket, if equipped. Refer to «Head Up Display Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
14. Install the brake pedal bracket and the reinforcement. Refer to «Brake Pedal Assembly Replacement»(/buick/rendezvous/i-2001-2007/remont/mechanical-hydraulic/#hydraulic-brake-system) .
15. Install the I/P trim pad. Refer to «Instrument Panel (I/P) Assembly Replacement»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
16. Install the front floor console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the console armrest. Refer to «Console Armrest Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Remove the screws from the armrest.
3. Pull on the armrest to separate the front of the armrest from the door frame.
4. Pull the latch from the door frame.
5. Remove the latch.

1. Install the latch to the door frame.
2. Press the latch onto the door frame until the latch is fully seated.
3. Install the armrest to the door frame with screws. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Install the armrest to the console. Refer to «Console Armrest Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Open the armrest.
2. Remove the two screws that hold the trim plate.
3. Pull on the trim plate to release the clips.
4. Disconnect the trim plate electrical connections.
5. Remove the trim plate.

1. Connect the electrical connections.
2. Press the trim plate to the console until the plate is fully seated.
3. Install the trim plate screws. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Close the armrest.

1. Remove the front floor console trim plate. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Disconnect the electrical connectors.
3. Remove the nuts from the front of the front floor console.
4. Remove the nuts from the back of the front floor console.
5. Recline the seats to gain clearance.
6. Lift straight up on the front floor console and pull back in order to remove the console from the vehicle.

1. Align the front floor console to the floor.
2. Connect the required electrical connectors.
3. Install the nuts to the front of the front floor console. Tighten: Tighten the nuts to 6 N.m (53 lb in).
4. Install the nuts to the rear of the front floor console. Tighten: Tighten the nuts to 6 N.m (53 lb in).
5. Install the front floor console trim plate. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the front floor console trim plate. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Disconnect the electrical connectors.
3. Remove the nuts from the side of the front floor console.
4. Remove the nuts from the rear of the front floor console.
5. Lift straight up on the front floor console and pull back in order to remove the console from the vehicle.

1. Align the front floor console to the floor.
2. Connect the required electrical connectors.
3. Install the nuts to the side of the front floor console. Tighten: Tighten the nuts to 6 N.m (53 lb in).
4. Install the nuts to the rear of the front floor console. Tighten: Tighten the nuts to 6 N.m (53 lb in).
5. Install the front floor console trim plate. Refer to «Trim Plate Replacement - Front Floor Console (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Replacement - Front Floor Console (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Remove the front floor console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .
2. Disconnect the console electrical center from the floor-console bracket and move aside, out of the way.
3. Remove the upper bolts (2) from the instrument panel (I/P).
4. Remove the lower nuts (1) from the floor.
5. Remove the front floor console bracket from the floor.

1. Align the front floor console bracket to the floor.
2. Install the lower nuts (1) to the front floor console bracket. Tighten: Tighten the nuts to 10 N.m (89 lb in).
3. Install the upper bolts/screws (2) to the I/P. Tighten: Tighten the bolts/screws to 2.5 N.m (22 lb in).
4. Install the console electrical center to the original location.
5. Install the front floor console. Refer to «Console Replacement - Front Floor (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Console Replacement - Front Floor (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) .

1. Raise the armrest.
2. Remove the screws from the armrest hinge assembly.
3. Remove the armrest.

1. Align the armrest to the hinge assembly.
2. Install the screws to the armrest assembly. Tighten: Tighten the screws to 2 N.m (18 lb in).
3. Inspect the armrest position for proper alignment.

1. Remove rear cup holder liner and remove the screw.
2. Pull up on the trim plate to release the retainer clips.
3. Lift the trim plate and turn sideways in order to lift the trim plate over the transaxle shift lever.
4. Remove the trim plate from the front floor console.

1. Align the trim plate to the front floor console.
2. Position the trim plate over the transaxle shift lever.
3. Install the trim plate to the front floor console and snap into place.
4. Install the rear trim plate screw and insert the cup holder liner. Tighten: Tighten the screw to 2 N.m (18 lb in).

1. Lift the armrest cover and place the cover in the locked position.
2. Remove the cup holder liners.
3. Remove the cup holder screws.
4. Remove the power accessory liner.
5. Remove the liner screws.
6. Disconnect the electrical connectors from the trim plate.
7. Remove the trim plate assembly.

Scheme 16

1. Connect the electrical connectors to the trim plate.
2. Install the trim plate assembly.
3. Install the trim plate screws. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Install the cup liners.
5. Install the power accessory liners.
6. Close the armrest cover.

Displays Test

Certain instrument panel cluster (IPC) features are tested when the ignition is turned ON in order to verify the features are working properly. The following occurs at key up

1. The air bag indicator flashes 7 times.
2. The ANTI-LOCK indicator illuminates for 3 seconds.
3. The battery/charge indicator turns ON and stays ON.
4. The BRAKE indicator illuminates for 3 seconds.
5. The odometer displays all segments and the word TRIP for 3 seconds.
6. The seat belt indicator stays ON steady for 20 seconds and then flashes for 50 seconds then turns OFF. If the ignition is OFF and the seat belt is buckled, this indicator will not illuminate during bulb check.
7. The SERVICE ENGINE SOON indicator turns ON and stays ON.

Indicators and Warning Messages

Refer to Indicator/Warning Message Description and Operation .

Engine Coolant Temperature Gage

The instrument panel cluster (IPC) displays the engine coolant temperature (ECT) as determined by the engine control module (ECM) or the powertrain control module (PCM). The IPC receives a class 2 message from the ECM/PCM indicating the ECT. The range on the ECT gage is between 60-125°C (140-260°F). The ECT gage defaults to 60°C (140°F) or below if the ECM/PCM detects a malfunction in the ECT sensor circuit. Refer to Cooling System Description and Operation in Engine Cooling.

Fuel Gage

The instrument panel cluster (IPC) displays the fuel level as determined by the engine control module (ECM)/powertrain control module (PCM). The IPC receives a class 2 message from the ECM/PCM indicating the fuel level percent. The fuel gage defaults to E (empty) if the ECM/PCM detects a malfunction in the fuel level sensor circuit. Refer to Fuel System Description in Engine Controls.

When the fuel level is less than 11 percent (less than 1/16 tank) of a tank of gas, the LOW FUEL message illuminates in the message center.

Odometer

The instrument panel cluster (IPC) contains a season odometer and a trip odometer. Press the trip/reset switch for 1 second on the IPC in order to toggle between the season odometer and the trip odometer. The IPC displays the vehicle mileage and trip mileage as determined by the IPC. The IPC calculates the mileage based on the vehicle speed signal circuit from the engine control module (ECM)/powertrain control module (PCM). The odometer will display ERROR if an internal IPC memory malfunction is detected or there is a class 2 communication fault. The odometer displays either miles or kilometers as requested by the activation of the english/metric button on the driver information center (DIC). The associated indicator (km or mi) illuminates.

Season Odometer

1. The season odometer is capable of displaying 99999.9 miles. When the season odometer hits 99999.9 miles it will not roll over to 00000.0, it stays at its maximum level of 99999.9.
2. The season odometer cannot be reset.
3. The season odometer is functional with the ignition OFF. With the ignition OFF and the driver door closed, press the trip/reset button and the season odometer stays on for 5 seconds and then turns OFF. When the ignition is OFF and the driver door is open, the season odometer stays ON for 15 seconds.

Trip Odometer

1. The trip odometer is capable of displaying 99999.9 miles. When the trip odometer hits 99999.9 miles it will roll over to 00000.0.
2. Press the trip/reset switch for greater than 1 second, while the trip odometer is displayed, in order to reset the trip odometer.

Speedometer

The instrument panel cluster (IPC) displays the vehicle speed as determined by the engine control module (ECM)/powertrain control module (PCM). The ECM/PCM converts the data from the vehicle speed sensor to a 4,000 pulses/mile signal. The IPC uses the vehicle speed signal circuit (4,000 pulses/mile), class 2 message from the ECM/PCM in order to calculate the vehicle speed. If the IPC detects a malfunction in the vehicle speed signal circuit from the ECM/PCM, the IPC uses the class 2 message from the EBCM, indicating the vehicle speed as a backup. If the speedometer reaches (108 mph) the fuel will shut-off, and it will turn back ON when the speedometer is at (106 mph). The speedometer displays either miles or kilometers as requested by the activation of the english/metric button on the driver information center (DIC). The associated indicator (km/h or mph) illuminates.

Tachometer

The instrument panel cluster (IPC) displays the engine speed as determined by the engine control module (ECM)/powertrain control module (PCM). The IPC receives a class 2 message from the ECM/PCM indicating the engine speed. The IPC is capable of displaying between 0-7,000 RPM. The tachometer will default to 0 RPM if the ECM/PCM detects a malfunction in the engine speed sensor signal circuit.

Indicator/Warning Message Description and Operation

Indicator/Warning Message Description and Operation Symbol Description (Canada) ANTI-LOCK (USA) ABS: Refer to ABS Description and Operation in Antilock Brake System Air Bag: Refer to SIR System Description and Operation in SIR (Canada) BRAKE (USA) Brake: Refer to Brake Warning System Description and Operation in Hydraulic Brakes (Canada) CHANGE ENGINE OIL (USA) Change Engine Oil: Refer to Change Engine Oil in Indicator/Warning Message Description and Operation Charge: Refer to Charging System Description and Operation in Engine Electrical (Canada) DOOR AJAR (USA) Door Ajar: Refer to Door Ajar Indicator Description and Operation in Doors (Canada HOT COOLANT TEMP (USA Engine Coolant Temperature: Refer to Cooling System Description and Operation in Engine Cooling Fasten Safety Belt: Refer to Seat Belt System Description and Operation in Seat Belts High Beam: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems (Canada) HIGH BEAM OUT (USA) High Beam Out: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems (Canada) KEY FOB BATTERY LOW (USA) Key Fob Battery Low: Refer to Keyless Entry System Description and Operation in Keyless Entry (Canada) LOW BRAKE FLUID (USA) Low Brake Fluid : Refer to ABS Description and Operation in Antilock Brake System (Canada) LOW ENG OIL LEVEL (USA) Low Engine Oil Level: Refer to Low Engine Oil Level in Indicator/Warning Message Description and Operation (Canada) LOW FUEL (USA) Low Fuel: Refer to Low Fuel in Indicator/Warning Message Description and Operation (Canada) LOW OIL PRESSURE (USA) Low Engine Oil Pressure: Refer to Low Oil Pressure in Indicator/Warning Message Description and Operation (Canada) LOW WASHER FLUID (USA) Low Washer Fluid: Refer to Wiper/Washer System Description and Operation in Wipers/Washer Systems (Canada) SERVICE ENGINE SOON (USA) Malfunction Indicator Lamp (MIL) : Refer to Powertrain Control Module (PCM) Description in Engine Controls (Canada) PARK LAMP OUT (USA) Park Lamp Out: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems (Canada) PROGRAM MODE (USA) Program Mode: Refer to Driver Personalization in Personalization (Canada) REAR HATCH AJAR (USA) Rear Hatch Ajar: Refer to Rear Hatch/Gate Description and Operation (Aztek) or Rear Hatch/Gate Description and Operation (Rendezvous) in Body Rear End (Canada) REDUCED ENGINE POWER (USA) Reduced Engine Power: Refer to Engine Control Module (ECM) Description in Engine Control - 3.6L (Canada) SECURITY (USA) Security: Refer to Theft Systems Description and Operation in Theft Deterrent (Canada) SERVICE TRACTION SYSTEM (USA) Service Traction Control: Refer to ABS Description and Operation in Antilock Brake System (Canada) SERVICE VEHICLE SOON (USA) Service Vehicle Soon: Refer to Service Vehicle Soon in Indicator/Warning Message Description and Operation (Canada) TRAC ACTIVE (USA) Traction Control On: Refer to ABS Description and Operation in Antilock Brake System (Canada) TRAC OFF (USA) Traction Control Off: Refer to ABS Description and Operation in Antilock Brake System Turn Signals: Refer to Exterior Lighting Systems Description and Operation in Lighting Systems

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

CHANGE ENGINE OIL

The instrument panel cluster (IPC) illuminates the CHANGE ENGINE OIL indicator in the message center when the powertrain control module (PCM) determines that the engine oil should be changed. The IPC receives a class 2 message from the PCM indicating the remaining oil life percent. Once the oil is changed, perform the engine oil monitor reset procedure in order to clear the CHANGE ENGINE OIL indicator. Refer to GM Oil Life System - Resetting in Maintenance and Lubrication.

LOW FUEL

The IPC illuminates the LOW FUEL indicator in the message center when the fuel level is less than 11 percent (1/16) of a tank. The IPC receives a class 2 message from the engine control module (ECM) or the powertrain control module (PCM) indicating fuel level percent.

LOW ENG OIL LEVEL

The IPC illuminates the LOW ENG OIL LEVEL indicator in the message center when the ECM/PCM detects a low engine oil condition, the signal circuit is high. The IPC receives a class 2 message from the ECM/PCM requesting illumination.

LOW OIL PRESSURE

The IPC illuminates the LOW OIL PRESSURE indicator in the message center when the ECM/PCM detects a low oil condition, the signal circuit is low. The IPC receives a class 2 message from the ECM/PCM requesting illumination.

SERVICE VEHICLE SOON

The IPC illuminates the SERVICE VEHICLE SOON indicator in the message center when the ECM/PCM or the body control module (BCM) detects certain non-emissions related malfunctions. The IPC receives a class 2 message from the ECM/PCM or from the BCM requesting illumination.

Driver Information Center (DIC) Description and Operation

The driver information center (DIC) displays PONTIAC or BUICK for 3 seconds and then the most recently used key fob when it first powers up. The DIC returns to the last display status after displaying the key fob number. The DIC can be displayed in English or French. In order to change between English/French press and hold the Mode button for more than 3 seconds.

There are 2 buttons on the DIC

1. Set button
2. MODE button

Set Button

The Set button allows options to be reset in the driver information center (DIC). Options can be reset by depressing and holding the Set button for 3 seconds.

Mode Button

The display format for each mode is indicated in the following table

Driver Information Center (DIC) Description and Operation

Pressing the MODE button changes the modes of operation for the driver information center. There are ten display modes available.

1. Off - No driver information is displayed in this mode of operation.
2. Compass/Temperature - displays for all modes, except personalization
3. Personalization
4. Average Fuel Economy (AFE)
5. Instantaneous Fuel Economy (IFE)
6. Fuel Range
7. Fuel Used
8. Average Speed
9. Oil Life Left
10. English/Metric Display

Compass/Temperature

This mode displays an 8 point compass heading on the left hand side of the driver information center (DIC). The compass will display the current vehicle direction relative to one of 8 compass headings using N,NE,E,SE,S,SW,W, and NW for the readout. The compass display is updated once every 2 seconds. The DIC will always display the compass reading and outside temperature. On Buick vehicles with automatic HVAC (RPO CJ2) the DIC will not display temperature, the ambient temperature will only be found on the HVAC control head display.

When the compass requires calibration, C or CALIBRATE COMPASS displays. For compass calibration and compass magnetic variation adjustment refer to Electronic Compass Calibration .

Ambient Air Temperature Sensor

The ambient air temperature sensor is a 2-wire negative temperature co-efficient thermistor. A 5-volt reference and signal circuit enables the sensor to operate. As the air temperature surrounding the sensor increases, the sensor resistance decreases. The sensor signal varies between 0-5 volts. The IPC receives input from the ambient air temperature sensor and converts the signal to a working temperature range.

The ambient temperature range is between -40°C (-40°F) and 60°C (140°F). If the ambient temperature is below 3°C (37°F), the temperature display will toggle every 8 seconds for 2 minutes between the outside temperature and the word ICE. After 2 minutes the ICE feature is disabled. When the temperature is less than -40°C (-40°F) or when there is an open in the circuit for more than 2 seconds, OC displays. When the temperature is above 60°C (140°F) or when there is a short in the circuit for more than 2 seconds, SC displays.

The ambient air temperature sensor is mounted in the forward engine area of the vehicle. In this position, it is exposed to the airflow through the grill before it reaches the radiators.

The DIC displays the ambient air temperature value that it receives from the instrument panel cluster (IPC). The ambient air temperature is updated or displayed under the following conditions

Driver Information Center (DIC) Description and Operation

Personalization

For personalization features refer to Personalization Description and Operation in Personalization.

Average Fuel Economy (AFE)

AFE is calculated as the ratio between the following values

1. AFE = Distance/Fuel
2. Distance = The accumulated distance since the last AFE reset
3. Fuel = The accumulated fuel consumption since the last AFE reset

You can reset the AFE mode by depressing and holding the Set button for more than 3 seconds. The value of this mode is retained during ignition OFF.

Instantaneous Fuel Economy (IFE)

Instantaneous fuel economy is calculated as the ratio between the following values

1. IFE = Distance/Fuel
2. Distance = The accumulated distance since last update
3. Fuel = The accumulated fuel delivered since last update

You cannot reset the IFE mode. The value of this mode is not retained during ignition OFF.

Fuel Range

Fuel Range is calculated between the following values

1. Fuel Range = AFE x Fuel Remaining
2. Fuel Remaining = Fuel sender value of available fuel

When a low fuel condition exists, the DIC displays FUEL RANGE LOW.

You can not reset the Fuel Range mode. The value of this mode is retained during ignition OFF.

Fuel Used

The DIC calculates and displays the total amount of fuel used since the last reset operation.

You can reset the Fuel Used mode by depressing and holding the Set button for more than 3 seconds. The value of this mode is retained during ignition OFF.

Average Speed

Average speed is calculated as the ratio between the following values

1. Average Speed = Distance/Ignition On
2. Distance = Accumulated distance since last reset
3. Ignition On = Accumulated ignition on time since last reset, ignition on is defined as run power mode with engine RPM greater than 100.

Ignition On time is measured from the time that the ignition is turned ON to the time when the ignition is turned OFF.

You can reset the Average Speed mode by depressing and holding the Set button for more than 3 seconds. The value of this mode is retained during ignition OFF.

Oil Life Left

Oil life left percentage is based on the information the DIC receives from a class 2 message from the PCM. The DIC displays the current percentage of the GM Oil Life System. When the oil needs changing the change engine oil indicator in the message center turns ON. When the engine oil is changed, reset the oil life left. Refer to GM Oil Life System - Resetting in Maintenance and Lubrication.

Low Tire Pressure

Tire pressure is based on the information the DIC receives from a class 2 message from the EBCM. The DIC displays NORMAL when the tire pressure is normal. When there is low tire pressure, the DIC displays LOW TIRE PRESSURE HOLD SET TO RESET. In order to reset the low tire pressure, press and hold the Set button for 3 seconds. When the tire pressure has been reset, the DIC displays TIRE PRESSURE RESET for 3 seconds.

English/Metric Display

While in this mode pressing the Set button changes the units in the DIC and HUD from English to Metric and vice versa.

Head Up Display (HUD) Description and Operation

The head-up display (HUD) is a secondary display system that optically projects critical vehicle information onto the windshield. The HUD system has an electric tilt adjust that is controlled by the HUD up/down switch. Moving this switch directs the motor to move the HUD image up or down on the windshield. The HUD is also equipped with automatic dimming which gives the HUD the ability to sense outside light conditions, via a photo-cell and automatically adjusts the brightness levels. You may manually adjust the HUD image brightness by moving the HUD dim switch.

The HUD displays the following images

1. The speedometer reading (speed up to 120 mph)
2. The turn signal indicators
3. The high beam indicator
4. The low fuel indicator
5. The check gages indicator
6. The radio frequency, including AM, FM, CD, and Tape
7. Backup vehicle speed
8. Values in English or metric units

The speedometer is shown on the head-up display (HUD) as a 3-digit display. The HUD speedometer is capable of displaying up to 120 mph. The HUD receives a class 2 message from the engine control module (ECM) or the powertrain control module (PCM) indicating vehicle speed. If the class 2 message from the ECM/PCM is invalid the HUD will use a class 2 message from the electronic brake control module (EBCM) instead.

LH Turn Signal and RH Turn Signal Indicator Inputs

The left and right turn indicators are driven by hardware inputs from the exterior lighting system. The signal is active when the circuit is high (12 volts) and inactive when circuit is open. During hazard mode, both the right and left turn signal circuits are active high, causing both the right and left turn signal indicators to illuminate at the same time.

High Beam Indicator Input

The head-up display (HUD) receives a class 2 message from the body control module (BCM) that the high beams have been requested.

The head-up display (HUD) receives a class 2 message from the (IPC) indicating low fuel.

CHECK GAGES Inputs

The instrument panel cluster (IPC) monitors different inputs and vehicle messages and sends the information to the head-up display (HUD), via a class 2 message. The HUD illuminates the CHECK GAGES indicator when it receives certain information from the IPC.

The HUD will illuminate the Check Gages indicator for the following messages

1. Brake failure
2. Charging system/generator fault
3. Coolant temp hot
4. Low brake fluid level
5. Low oil pressure
6. Low tire pressure
7. Parking brake
8. Voltage

Radio

1. The head-up display (HUD) displays the following radio information depending on the current radio settings: Frequency Band CD Track # Current Disk # (for multiple disk player) Cassette icon (when cassette is playing) MP3 (folder name and track #) Rear Seat Entertainment (RSE) (ON/OFF)
2. When the radio station, CD, or cassette are changed, the HUD displays the new information for 5 seconds.
3. The HUD receives a class 2 message indicating a change in the setting from the radio.
4. The HUD image blanks when the radio is seeking or scanning.

Navigation

The navigation system displays the following information

1. The direction/maneuver arrow and destinations symbols
2. Arbitrary text for directions
3. The distance to next maneuver
4. The distance count down bar
5. The compass heading

Backup Vehicle Speed

The head-up display (HUD) receives a class 2 message from the body control module (BCM) indicating backup vehicle speed.

HUD English/Metric Input

The head-up display (HUD) illuminates the speedometer in either english (mph) or metric (km/h) units depending upon the class 2 message received from the instrument panel cluster (IPC).

Audible Warnings Description and Operation

The audible warnings alert the driver of a system concern or a critical vehicle condition. The radio generates the audible warnings through the left front speaker. The radio receives audible warning requests via the class 2 serial data line from the IPC or body control module (BCM). If the radio receives multiple audible warning requests, the warning with the highest priority sounds first. The following lists the audible warning priority and the pulse rate

1. Fast rate chime-200 pulses per minute
2. Medium rate chime-150 pulses per minute
3. Slow rate chime-50 pulses per minute
4. Single chime

Fasten Safety Belt Warning

The radio activates the fasten safety belt audible warning as requested by the IPC. The IPC sends a class 2 message to the radio indicating the chime frequency, slow rate and duration (5 pulses). The fasten safety belt warning sounds and the fasten safety belt indicator illuminates when the following occurs

1. The ignition switch transitions to ON.
2. The inflatable restraint sensing and diagnostic module (SDM) detects that the driver's seat belt is not buckled, signal is low. The IPC receives a class 2 message from the SDM indicating the driver's seat belt status.

If the seat belt is buckled when the ignition is turned on, the chime does not sound. If the seat belt is buckled while the chime is sounding, the chime stops. If the seat belt is unbuckled after the initial transition to ON, the chime does not sound.

Headlamps On Warning

The radio activates the headlamps on warning as requested by the body control module (BCM). The BCM sends a class 2 message to the radio indicating the chime frequency, fast rate and duration, continuous. The headlamps on warning sounds when the following occurs

1. The ignition is OFF.
2. The BCM determines that the driver's door is open, signal is low.
3. The BCM determines that the headlamp switch is in the park or head position.

Key-In-Ignition Warning

The radio activates the key-in-ignition audible warning as requested by the BCM. The BCM sends a class 2 message to the radio indicating the chime frequency, medium rate and duration, continuous. The key-in-ignition warning sounds when the following occurs

1. The ignition switch is OFF.
2. The body control module (BCM) determines that the driver's door is open, signal is low.
3. The BCM determines that the key-in-ignition switch is closed, signal is low.

Turn Signal Reminder

The radio activates the turn signal warning as requested by the IPC. The IPC sends a class 2 message to the radio indicating the chime frequency, medium rate and duration, continuous. The turn signal warning sounds when the following occurs

1. The ignition switch is in the RUN position.
2. The turn signal switch is in either turn position, sensing, within 1 second, an open to B+ transition in the turn signal control circuit, left or right turn.
3. The vehicle has traveled a distance of 1.2 km (3/4 mi) by counting pulses on the vehicle speed input circuit.

The IPC turns OFF the turn signal reminder when either the ignition switch is turned to the OFF position, or the turn signal switch returns to the OFF position, sensing, within 1 second, no transitions from open to B+ in either of the turn signal control circuits, left turn or right turn.

Additional Chimes

The following chimes will turn ON when an associated indicator/message turns ON in the IPC/DIC

1. ABS indicator
2. AWD Disable indicator
3. Battery/Charge indicator
4. Brake indicator
5. Change Engine Oil indicator
6. Door Ajar indicator
7. Hot Coolant Temp indicator
8. Low Brake Fluid indicator
9. Low Fuel indicator
10. Low Oil Level indicator
11. Low Oil Pressure indicator
12. Low Tire Pressure indicator/reset
13. Low Washer Fluid indicator
14. MIL (Service Engine Soon) indicator
15. Oil Life Reset
16. Park Lamp Out indicator
17. Rear Hatch Ajar indicator
18. Service Traction System indicator
19. Service Vehicle Soon indicator
20. TRAC OFF indicator

For a description of an indicator refer to Indicator/Warning Message Description and Operation .

For diagnosis of an indicator refer to Symptoms - Instrument Panel, Gages and Console .

Special Tools

Special Tools Illustration Tool Number/Description J 35616-A Connector Test Adapter Kit J 33431-C Signal Generator and Instrument Panel Tester J 38778 Door Trim Pad Clip Remover

Scheme 33

Scheme 34

Scheme 35

See also:
• Scan Tool Does Not Power Up
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• DTC B0008
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List/Type
• Diagnostic Trouble Code (DTC) List
• Testing for Intermittent Conditions and Poor Connections
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Ignition Switch Replacement
• Fuel Level Sensor Replacement
• Fuel Level Sensor Replacement (Prior to VIN 4S558922 (100mm Sender))
• Powertrain Control Module (PCM) Replacement
• Engine Oil Pressure Sensor and/or Switch Replacement
• Engine Oil Pressure Sensor and/or Switch Replacement
• Battery Negative Cable Disconnect/Connect Procedure (LA1)
• Checking Aftermarket Accessories
• ABS Indicator Always On
• Air Bag Indicator Circuit Malfunction
• Brake Warning Indicator Always On
• Brake Warning Indicator Inoperative
• Charge Indicator Always On
• Charge Indicator Inoperative
• Door Ajar Indicator Malfunction
• Engine Coolant Temperature Indicator Always On
• High Beam Indicator Inoperative
• Low Washer Fluid Indicator Malfunction
• Malfunction Indicator Lamp (MIL) Always On
• Park Lamp Out Indicator Inoperative
• Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)
• Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)
• Seat Belt Indicator Circuit Malfunction
• Security Indicator LED Inoperative
• Turn Signal Lamps and/or Indicators Inoperative
• Lifting and Jacking the Vehicle
• GM Oil Life System - Resetting
• Diagnostic System Check - Engine Controls
• Diagnostic System Check - Lighting Systems
• Courtesy Lamps Inoperative
• Speakers Inoperative - One or More
• Radio Replacement
• Fastener Notice
• Garnish Molding Replacement - Windshield Pillar
• SIR Caution
• SIR Disabling and Enabling Zone 5
• Hood Latch Release Handle Replacement
• HVAC Control Module Replacement (Buick)
• Automatic Transmission Range Selector Cable Adjustment
• Cooling System Description and Operation
• Door Ajar Indicator Description and Operation
• Seat Belt System Description and Operation
• Keyless Entry System Description and Operation
• Wiper/Washer System Description and Operation
• Driver Personalization
• Rear Hatch/Gate Description and Operation (Aztek)
• Rear Hatch/Gate Description and Operation (Rendezvous)
• Theft Systems Description and Operation
• Special Tools and Equipment
• Symptoms - Instrument Panel, Gages and Console
• Diagnostic Trouble Code (DTC) List
• Indicator/Warning Message Description and Operation
• Driver Information Center (DIC) Description and Operation
• Head Up Display (HUD) Description and Operation
• Audible Warnings Description and Operation
• Chime Always On
• Chime Inoperative
• Driver Information Center (DIC) Temperature Display Always Reads SC
• Driver Information Center (DIC) Compass Inaccurate or C Displayed
• Driver Information Center (DIC) Switch(es) Inoperative
• Engine Coolant Temperature Gage Inaccurate or Inoperative
• Odometer Trip/Reset Switch Inoperative
• Tachometer Inaccurate or Inoperative
• Head Up Display (HUD) Inoperative
• Head Up Display (HUD) Turn Signal Indicator Inoperative - Left/Right
• Head Up Display (HUD) Image Adjustment Inoperative
• Head Up Display (HUD) Intensity Does Not Vary
• Change Engine Oil Indicator Always On
• Change Engine Oil Indicator Inoperative
• Engine Oil Pressure Indicator Always On
• Low Engine Oil Level Indicator Always On
• Fuel Level Specifications
