Garage Door Opener System Buick Rendezvous I

Fastener Tightening Specifications

Fastener Tightening Specifications

Scheme 1

Scheme 2

Garage Door Opener Connector End Views

Garage Door Opener Connector End Connector Part Information 12162335 3-Way (WHT) Pin Wire Color Circuit No. Function 1 ORN 640 Battery Positive Voltage 2 GRY 8 Instrument Panel Lamp Supply Voltage 3 BLK 650 Ground

Diagnostic Starting Point - Garage Door Opener

Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure to use when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Garage Door Opener in order to identify the correct procedure for diagnosing the system and where the procedure is located.

Symptoms - Garage Door Opener

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the garage door opener. Refer to «Checking Aftermarket Accessories»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__checking-aftermarket-accessories) in Wiring Systems.
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to Garage Door Opener Inoperative in order to diagnose the symptom.

Garage Door Opener Inoperative

Garage Door Opener Inoperative

Scheme 3

Scheme 4

Scheme 5

1. Release the barbed tab at the center of the access panel.
2. Swing the panel down and forward in order to access the module.
3. Disconnect the electrical connector from the module and switch assembly.
4. Remove the screws that retain the garage door opener and the to the console.
5. Remove the opener and the switch assembly from the console.

Installation Procedure

1. Align the LED indicator with the hole in the access panel when setting the opener into place.
2. Install the opener and the switch assembly to the console. NOTE: Refer to Fastener Notice in Cautions and Notices.
3. Install the screws that retain the opener and the switch assembly to the console. Tighten: Tighten the screws to 2 N.m (18 lb in).
4. Connect the electrical connector to the opener and the switch assembly.
5. Swing the access panel up and rearward in order to close the access panel.
6. Snap the barbed tab into place in the console.

Garage Door Opener Programming

The GDO is programmed by using the customer's hand-held transmitter(s).

Turn the ignition OFF while programming the GDO transmitter. Follow these steps to program up to 3 channels

1. If you have previously programmed a transmitter, proceed to Step 2. Otherwise, hold down the 2 outside buttons on the GDO transmitter for approximately 20 seconds, until the light on the GDO transmitter begins to flash rapidly. Then release the buttons. This procedure erases any previous settings and initializes the memory for all 3 channels.
2. Decide which of the 3 channels you want to program to the transmitter you have.
3. Hold the end of the hand-held transmitter against the front surface of the GDO (less than 1 inch) so you can still see the light.
4. Using both hands, press the hand-held transmitter button and the desired button on the GDO transmitter. Continue to hold both buttons through Step 5. IMPORTANT: The GDO is compatible with most, but not all, types and brands of transmitters. If the GDO light does not flash rapidly after 90 seconds, there may be a compatibility conflict with the transmitter used to program the GDO. Call HomeLink™ at 1-800-355-3515 in order to address this problem.
5. Hold down the buttons on both transmitters until you see the light on the GDO transmitter flash slowly and then rapidly. The rapid flashing, which could take up to 90 seconds, indicates that the GDO transmitter has been programmed. Release the buttons on both transmitters when the light starts to flash rapidly.

Training the GDO for Rolling Code Receivers

This procedure is for training the customer's rolling code garage door openers to their GDO transmitter. The GDO must already be programmed to its hand-held transmitter. The training process below must be completed within 30 seconds or it must be repeated.

1. Locate the train button on the garage door opener receiver. Refer to the operator's manual for the garage door opener (or call HomeLink™ at 1-800-355-3515 for assistance). Follow instructions for the garage door opener in order to determine when the unit is in train mode.
2. Return to the GDO transmitter in the vehicle, and press the button that you want trained for rolling codes 3 times, for 1 second each time. If not successfully programmed, try 2-5 seconds each time.
3. Press the button used again in order to verify that the GDO transmitter has been programmed.

You may use either the hand-held transmitter or the GDO to open the garage door.

The GDO is compatible with most, but not all, types and brands of transmitters. If the GDO light does not flash rapidly after 90 seconds, there may be a compatibility conflict with the transmitter used to program the GDO. Call HomeLink™ at 1-800-355-3515 in order to address compatibility concerns.

Erasing Channels

To erase programmed channels, hold down the 2 outside buttons until the light on the GDO transmitter begins to flash. Individual channels cannot be erased, but can be reprogrammed using the Garage Door Opener Programming and the Training GDO for Rolling Code Receivers procedures.

Non-Compatible Garage Door Openers

Garage Door Opener Description and Operation

The garage door opener is located in the overhead console. The valet switch provides battery voltage to the garage door opener. If battery voltage is lost due to a condition such as a dead battery, the garage door opener unit relies on the non-servicable internal power backup supply. The unit is programmed using the customer's hand-held transmitters for the garage doors, electric entrance gates, or lighting and security systems.

The garage door opener is rolling code capable. Rolling code is a system that allows the code that the customers receiver receives from the garage door opener to change every time the garage door opener is used within operating range of the receiver. When the receiver and the garage door opener are initially programmed together, a code is established, a new code is created for every new transmission. The software in the receiver recognizes the garage door opener and accepts the new code.

The garage door opener is compatible with most, but not all types and brands of transmitters. If a problem should occur with a compatibility conflict with a transmitter, call HomeLink™ at 1-800-355-3515.

The garage door opener is a transmitter operating between 288-399 MHz. The power and range of the transmitter is limited to comply with laws governing the generation of radio frequency interference (RFI). The transmitter is programmed by the user to accept the signal generated by the user's transmitters, refer to Garage Door Opener Programming - Universal .

The garage door opener has 3 buttons that may be programmed for individual transmitter/receiver combinations to control up to 3 garage door openers, security gates, and lighting systems. Each button represents a transmitter code section of the transmitter, which operates separately from any other button, and may be considered a separate transmitter. Operation consists of simply pressing a button to activate the corresponding transmitter.

Battery voltage is provided to the garage door opener from the IGN SEN fuse in the IP fuse block. The garage door opener is grounded through G400. Inadvertent power is supplied from the body control module (BCM).

Special Tools

Special Tools Illustration Tool Number/Description J 41540 HomeLink Tester
