Interior Trim and Interior Paneling Buick Regal V

Exterior/interior Trim 28 illustrations ~933 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Assist Handle Screws2.5 N.m22 lb in
Cargo Tie Down Hook Fastener20 N.m15 lb ft
Front Side Door Armrest Pull Cup Fastener1.8 N.m15 lb in
Front Side Door Inside Handle Fastener1.8 N.m15 lb in
Rear Side Door Armrest Pull Cup Fastener1.8 N.m15 lb in
Rear Side Door Inside Handle Fastener1.8 N.m15 lb in
Sunshade Support Screw2.5 N.m22 lb in
Sunshade Screws2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 52

Scheme 52: Front Side Door Pull Handle Cover Replacement
Scheme 52: Front Side Door Pull Handle Cover Replacement
CalloutComponent Name
1Front Side Door Pull Handle Cover TIP: Use a small flat-bladed tool to release the front side door handle cover.

Front Side Door Pull Handle Cover Replacement

Scheme 53

Scheme 53: Rear Side Door Pull Handle Cover Replacement
Scheme 53: Rear Side Door Pull Handle Cover Replacement
CalloutComponent Name
1Rear Side Door Pull Handle Cover TIP: Use a small flat-bladed tool to release the rear side door handle cover.

Rear Side Door Pull Handle Cover Replacement

Scheme 54

Scheme 54: Front Side Door Outside Rearview Mirror Filler Replacement
Scheme 54: Front Side Door Outside Rearview Mirror Filler Replacement
CalloutComponent Name
1Front Side Door Outside Rearview Mirror Filler Procedure Disconnect the electrical connector. TIP: Use a small flat-bladed tool to remove the front side door outside rearview mirror filler.

Front Side Door Outside Rearview Mirror Filler Replacement

Removal Procedure

  1. Remove the front side door outside rearview mirror filler. Refer to «Front Side Door Outside Rearview Mirror Filler Replacement»(/buick/regal/v-2009-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  2. Use a small flat bladed tool in the corner (1) to release the front side door handle cover.
  3. Remove the front side door handle cover (2).
  4. Use a small flat bladed tool to release the front side door pull handle cover in the area (1).
  5. Remove the front side door pull handle cover (2).
  6. Remove the three front side door trim panel fasteners (1).
  7. Release the 8 front side door trim panel retainers (1). Start releasing front side door trim panel retainer at the bottom.
  8. Release the door lock retainer cable to disengage.
  9. Disconnect the electrical connector.
  10. Remove the front side door trim panel (2).

Installation Procedure

  1. Install the front side door trim panel (2). Use five new blue retainers and three new green retainers.
  2. Connect the electrical connector.
  3. Install the door lock retainer cable to engage.
  4. Install the three front side door trim panel fasteners (1).
  5. Install the front side door handle cover (1).
  6. Install the front side door pull handle cover (2).
  7. Install the front side door outside rearview mirror filler. Refer to «Front Side Door Outside Rearview Mirror Filler Replacement»(/buick/regal/v-2009-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  1. Use a small flat bladed tool in the corner (1) to release the rear side door handle cover.
  2. Remove the rear side door handle cover (2).
  3. Use a small flat bladed tool to release the rear side door pull handle cover in the area (1).
  4. Remove the rear side door pull handle cover (2).
  5. Remove the 3 rear side door handle cover fasteners (1).
  6. Release the 6 rear side door trim panel retainers (1). Start releasing rear side door trim panel retainer at the bottom.
  7. Release the door lock retainer cable to disengage.
  8. Disconnect the electrical connector.
  9. Remove the rear side door trim panel (2).
  1. Install the rear side door trim panel (2). Use 4 new blue retainers and 2 new green retainers.
  2. Connect the electrical connector.
  3. Install the door lock retainer cable to engage.
  4. Install the 3 rear side door trim panel fasteners (1).
  5. Install the rear side door handle cover (1).
  6. Install the rear side door pull handle cover (2).

Scheme 55

Scheme 55: Front Side Door Water Deflector Replacement
Scheme 55: Front Side Door Water Deflector Replacement
CalloutComponent Name
Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement .
1Front Side Door Water Deflector Procedure Guide electrical connectors and door lock cable through the water deflector while removing it from the door.

Front Side Door Water Deflector Replacement

Scheme 56

Scheme 56: Rear Side Door Water Deflector Replacement
Scheme 56: Rear Side Door Water Deflector Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear door trim panel. Refer to Rear Side Door Trim Panel Replacement
1Rear Side Door Water Deflector TIP: Guide electrical connectors and door lock cable through the rear side door water deflector while removing it from the door.

Rear Side Door Water Deflector Replacement

Scheme 57

Scheme 57: Front Side Door Window Frame Garnish Molding Replacement
Scheme 57: Front Side Door Window Frame Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement .
1Front Side Door Window Frame Garnish Molding Retainer (Qty: 2) Procedure Pull the inner front side door window frame garnish molding away from the inner window flange to remove.
2Front Side Door Window Frame Garnish Molding Procedure When installing the new front side door window frame garnish molding, start at the upper inside corner of the door frame.

Front Side Door Window Frame Garnish Molding Replacement

Scheme 58

Scheme 58: Rear Side Door Window Frame Garnish Molding Replacement
Scheme 58: Rear Side Door Window Frame Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim panel. Refer to Rear Side Door Trim Panel Replacement .
1Rear Side Door Window Frame Garnish Molding Fastener (Qty: 2)
2Rear Side Door Window Frame Garnish Molding Procedure Pull the inner rear side door window frame garnish molding away from the inner window flange to remove. When installing the new rear side door window frame garnish molding, start at the upper inside corner of the door frame.

Rear Side Door Window Frame Garnish Molding Replacement

Scheme 59

Scheme 59: Front and Rear Side Door Sill Trim Plate Replacement
Scheme 59: Front and Rear Side Door Sill Trim Plate Replacement
CalloutComponent Name
1Front and Rear Side Door Sill Trim Plate Retainer (Qty: 6)
2Front and Rear Side Door Sill Trim Plate Procedure Use a small flat-bladed tool to carefully disengage 3 integral clips that mate the center pillar lower trim panel to the front and rear side door sill trim plate. Disconnect the electrical connector.

Front and Rear Side Door Sill Trim Plate Replacement

Scheme 60

Scheme 60: Rear Compartment Side Trim Panel Replacement (HP6, Left Side)
Scheme 60: Rear Compartment Side Trim Panel Replacement (HP6, Left Side)
CalloutComponent Name
Preliminary Procedure Remove the rear compartment floor panel trim (with battery cover, HP6) Refer to Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6) , Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6) . Fold down rear seat to access retainer.
1Rear Compartment Side Trim Panel Retainer (Qty: 4)
2Rear Compartment Side Trim Panel Assembly

Rear Compartment Side Trim Panel Replacement (HP6, Left Side)

Scheme 61

Scheme 61: Rear Compartment Side Trim Panel Replacement (HP6, Right Side)
Scheme 61: Rear Compartment Side Trim Panel Replacement (HP6, Right Side)
CalloutComponent Name
Preliminary Procedure Remove the rear compartment floor panel trim (with blower cover, HP6). Refer to Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6) , Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6) .
1Rear Compartment Side Trim Panel Retainer (Qty: 5)
2Rear Compartment Side Trim Panel Assembly

Rear Compartment Side Trim Panel Replacement (HP6, Right Side)

Scheme 62

Scheme 62: Rear Compartment Side Trim Panel Replacement (without HP6)
Scheme 62: Rear Compartment Side Trim Panel Replacement (without HP6)
CalloutComponent Name
Preliminary Procedure Fold down rear seat to access retainer. Remove the rear end trim finish panel. Refer to Rear End Trim Finish Panel Replacement .
1Rear Compartment Side Trim Panel Retainer (Qty: 2)
2Rear Compartment Side Trim Panel

Rear Compartment Side Trim Panel Replacement (without HP6)

Scheme 63

Scheme 63: Roof Rail Front Assist Handle Replacement
Scheme 63: Roof Rail Front Assist Handle Replacement
CalloutComponent Name
1Roof Rail Front Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to release the cover to access the fastener.
2Roof Rail Front Assist Handle
CAUTION
Refer to Fastener Caution .

Roof Rail Front Assist Handle Replacement

Scheme 64

Scheme 64: Inside Rearview Mirror Mount Plate Cover Replacement
Scheme 64: Inside Rearview Mirror Mount Plate Cover Replacement
CalloutComponent Name
1Inside Rearview Mirror Mount Plate Cover Retainer (Qty: 4) TIP: Use a small flat-bladed tool to release the locking retainer from the inside rearview mirror mount plate cover, left and right side.
2Inside Rearview Mirror Mount Plate Cover

Inside Rearview Mirror Mount Plate Cover Replacement

Scheme 65

Scheme 65: Sunshade Replacement
Scheme 65: Sunshade Replacement
CalloutComponent Name
Preliminary Procedure Lower the front of the headlining trim panel to access the sunshade electrical connector, if necessary.
1Sunshade Support Fastener Cover
2Sunshade Fastener (Qty: 3) CAUTION: Refer to Fastener Caution .
3Sunshade Assembly Procedure Disconnect the electrical connector. Remove the sunshade anchor from the roof by unsnapping, if needed.
CAUTION
Refer to Fastener Caution .

Sunshade Replacement

Scheme 66

Scheme 66: Sunshade Support Replacement
Scheme 66: Sunshade Support Replacement
CalloutComponent Name
1Sunshade Support Fastener CAUTION: Refer to Fastener Caution . Procedure Pull cover downward to access fastener.
2Sunshade Support
CAUTION
Refer to Fastener Caution .

Sunshade Support Replacement

Scheme 67

Scheme 67: Theft Deterrent Sensor Opening Trim Plate Replacement
Scheme 67: Theft Deterrent Sensor Opening Trim Plate Replacement
CalloutComponent Name
1Theft Deterrent Sensor Opening Molding Procedure Carefully use a flat bladed tool, and release the retainer from the theft deterrent sensor opening molding to the roof console.

Theft Deterrent Sensor Opening Trim Plate Replacement

CAUTIONIf a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.
CAUTIONUse care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/regal/v-2009-2013/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. First release the upper side of the windshield side garnish molding (1).
  3. Pull and release gently the upper side of the windshield side garnish molding (2).
  4. Cut the retainer at the cutline (3).
  5. Remove the rest of the windshield side garnish molding retainer (1) by releasing the clip (3) and sliding the retainer (1) upward out of the windshield side garnish molding (2).
  6. Remove the windshield side garnish molding retainer (4) out of the body hinge pillar inner panel by doing the following: Remove the retainer (4) from the bodyside. Slide a small flat-bladed tool on the outboard side to disengage the center retainer (5), maintain pressure on the tab. Slide another small flat-bladed tool on the opposite side of the retainer to depress the outer tabs (6), maintain pressure on the tabs. Rotate the retainer out parallel to the upper reinforcement body hinge pillar.
  1. Install the new windshield side garnish molding retainer (1) at the windshield side garnish molding.
  2. Install the new windshield side garnish molding clip (3) to the windshield side garnish molding (2).
  3. Position the windshield side garnish molding (4) with the aid of the guide retainer (2).
  4. Clip in the lower windshield side garnish molding retainer (3).
  5. Push gently the upper side of the windshield side garnish molding to the body hinge pillar panel.
  6. The windshield side garnish molding retainer (1) has to be in correct position to audible engage when connecting to the body hinge pillar panel.

Scheme 68

Scheme 68: Center Pillar Upper Garnish Molding Replacement
Scheme 68: Center Pillar Upper Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the roof rail front assist handle. Refer to Roof Rail Front Assist Handle Replacement . Release the front seat belt retractor. Refer to Driver or Passenger Seat Retractor Side Belt Replacement . Remove the front and rear side door sill trim plate. Refer to Front and Rear Side Door Sill Trim Plate Replacement . Move seat to full forward position.
1Center Pillar Upper Garnish Molding Procedure Remove the center pillar upper and lower garnish molding assembly as one piece. Release the locking retainer on the rear side of the center pillar upper garnish molding to separate the upper from the lower.

Center Pillar Upper Garnish Molding Replacement

Scheme 69

Scheme 69: Center Pillar Lower Trim Panel Replacement
Scheme 69: Center Pillar Lower Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove the front and rear side door sill trim plate. Refer to Front and Rear Side Door Sill Trim Plate Replacement . Remove the roof rail front assist handle. Refer to Roof Rail Front Assist Handle Replacement . Move seat to full forward position.
1Center Pillar Lower Trim Panel Retainer (Qty: 3) Procedure Remove the center pillar upper and lower garnish molding assembly as one piece. Release the locking retainer on the rear side of the center pillar upper garnish molding to separate the upper from the lower.
2Center Pillar Lower Trim Panel

Center Pillar Lower Trim Panel Replacement

Scheme 70

Scheme 70: Body Lock Pillar Upper Trim Panel Replacement (Sedan)
Scheme 70: Body Lock Pillar Upper Trim Panel Replacement (Sedan)
CalloutComponent Name
Preliminary Procedure Disable the SIR system. Refer to SIR Disabling and Enabling .
1Body Lock Pillar Upper Trim Panel Retainer TIP: Use a small flat-bladed tool to release the retainer from the body lock pillar upper trim panel.
2Body Lock Pillar Upper Trim Panel

Body Lock Pillar Upper Trim Panel Replacement (Sedan)

Scheme 71

Scheme 71: Rear Window Panel Stowage Compartment Cover Replacement (with HP6)
Scheme 71: Rear Window Panel Stowage Compartment Cover Replacement (with HP6)
CalloutComponent Name
Preliminary Procedures Remove the rear window panel trim. Refer to Rear Window Panel Trim Replacement (with HP6) , Rear Window Panel Trim Replacement (without HP6) .
1Rear Window Panel Stowage Compartment Cover Retainers (Qty: 3) Procedure Use a trim removal tool to aid in the removal of the retainers.
2Rear Window Panel Stowage Compartment Cover Retainers (Qty: 4) Procedures Open rear compartment lid to access retainers. Use a trim removal tool to aid in the removal of the retainers.
3Rear Window Panel Stowage Compartment Cover Procedure Disconnect electrical connector.

Rear Window Panel Stowage Compartment Cover Replacement (with HP6)

Scheme 72

Scheme 72: Rear Window Panel Trim Replacement (with HP6)
Scheme 72: Rear Window Panel Trim Replacement (with HP6)
CalloutComponent Name
Preliminary Procedure Fold down the rear seat back cushions. Remove the rear seat back cushion bolsters. Refer to Rear Seat Back Cushion Bolster Replacement .
1Rear Window Panel Trim Retainer (Qty: 3)
2Rear Window Panel Trim Assembly Procedure Remove the seat belt guides and slide the belt through the slots in the panel. Disconnect the electrical connector. When replacing the rear window panel trim assembly, transfer all necessary components.

Rear Window Panel Trim Replacement (with HP6)

Scheme 73

Scheme 73: Rear Window Panel Trim Replacement (without HP6)
Scheme 73: Rear Window Panel Trim Replacement (without HP6)
CalloutComponent Name
Preliminary Procedures Fold the rear seat back forward to gain access to the retainers. Remove the body lock pillar upper trim panel. Refer to Body Lock Pillar Upper Trim Panel Replacement (Sedan) .
1Rear Window Trim Finish Panel Retainer (Qty: 3)
2Rear Window Trim Finish Panel Assembly Procedure Disconnect the electrical connector.

Rear Window Panel Trim Replacement (without HP6)

Scheme 74

Scheme 74: Rear End Trim Finish Panel Replacement
Scheme 74: Rear End Trim Finish Panel Replacement
CalloutComponent Name
Preliminary Procedure Reposition the rear compartment lid weatherstrip to access the rear end trim finish panel. Refer to Rear Compartment Lid Weatherstrip Replacement .
1Rear End Trim Finish Panel Retainer (Qty: 8)
2Rear End Trim Finish Panel NOTE: Rear end sill plate seats over D-rings.
NOTE
Rear end sill plate seats over D-rings.

Rear End Trim Finish Panel Replacement

Scheme 75

Scheme 75: Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6)
Scheme 75: Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6)
CalloutComponent Name
1Rear Compartment Side Trim Panel (Push-In) Retainer (Qty: 4) Procedure Pull the rear seat back cushion latch release located on the top of the rear seat back cushion, and fold the rear seat back cushion forward to access two of the (Push-in) retainers. The other two can be accessed thru the rear compartment. NOTE: When reinstalling lower interior push-in retainer, lift seat 40-45 degrees above flat to gain sufficient hand room to get retainer seated.
2Rear Compartment Floor Panel Trim Assembly (with Blower Cover, HP6)
NOTE
When reinstalling lower interior push-in retainer, lift seat 40-45 degrees above flat to gain sufficient hand room to get retainer seated.

Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6)

Scheme 76

Scheme 76: Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6)
Scheme 76: Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6)
CalloutComponent Name
Preliminary Procedure Remove the rear compartment floor panel trim (with blower cover, HP6). Refer to Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6) , Rear Compartment Floor Panel Trim Replacement (with Blower Cover, HP6) .
1Rear Compartment Side Trim Panel (Push-In) Retainer Procedure Pull the rear seat back cushion latch release located on the top of the rear seat back cushion, and fold the rear seat back cushion forward to access the rear compartment side trim panel (Push-In) retainer.
2Rear Compartment Floor Panel Trim Assembly (with Battery Cover, HP6)

Rear Compartment Floor Panel Trim Replacement (with Battery Cover, HP6)

Scheme 77

Scheme 77: Rear Compartment Lid Inner Panel Trim Replacement
Scheme 77: Rear Compartment Lid Inner Panel Trim Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear compartment lid latch cover. Refer to Rear Compartment Lid Latch Cover Replacement .
1Rear Compartment Lid Inner Panel Trim Retainer (Qty: 9)
2Rear Compartment Lid Inner Panel Trim Procedure Disengage the pull handle from the compartment lid, transfer handle if necessary.

Rear Compartment Lid Inner Panel Trim Replacement

Scheme 78

Scheme 78: Rear Compartment Lid Latch Cover Replacement
Scheme 78: Rear Compartment Lid Latch Cover Replacement
CalloutComponent Name
1Rear Compartment Lid Latch Cover TIP: Use a small flat-bladed tool to pull and release the rear compartment lid latch cover.

Rear Compartment Lid Latch Cover Replacement

Scheme 79

Scheme 79: Quarter Outer Panel Pressure Relief Valve Replacement
Scheme 79: Quarter Outer Panel Pressure Relief Valve Replacement
CalloutComponent Name
Preliminary Procedures Remove the rear bumper fascia. Refer to Rear Bumper Fascia Replacement . Reposition any wiring to gain access to pressure relief valve.
1Pressure Relief Valve

Quarter Outer Panel Pressure Relief Valve Replacement

More articles — Body & Frame
