Instrument Panel Trim and Console Trim Buick Regal V

Exterior/interior Trim 37 illustrations ~381 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Dash Panel Brace9 N.m80 lb in

Scheme 15

Scheme 15: Instrument Panel Lower Trim Panel Insulator Replacement
Scheme 15: Instrument Panel Lower Trim Panel Insulator Replacement
CalloutComponent Name
1Instrument Panel Lower Trim Panel Insulator Push-Pin Fasteners (Qty: 2)
2Instrument Panel Lower Trim Panel Insulator Procedures Flex the insulator panel enough to manipulate it out from beneath the instrument panel assembly. Disconnect the electrical connections, if applicable. When replacing the instrument panel lower trim panel insulator, transfer all necessary components.

Instrument Panel Lower Trim Panel Insulator Replacement

Scheme 16

Scheme 16: Instrument Panel Lower Extension Compartment Panel Replacement
Scheme 16: Instrument Panel Lower Extension Compartment Panel Replacement
CalloutComponent Name
1Instrument Panel Lower Extension Compartment Panel Retainer (Qty: 3)
2Instrument Panel Lower Extension Compartment Panel Procedures Disconnect electrical connections, if applicable. When replacing the instrument panel lower extension compartment panel, transfer all necessary components.

Instrument Panel Lower Extension Compartment Panel Replacement

Scheme 17

Scheme 17: Instrument Panel Compartment Lamp Switch Actuator Replacement
Scheme 17: Instrument Panel Compartment Lamp Switch Actuator Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel compartment lamp. Refer to Instrument Panel Compartment Lamp Replacement Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement
1Instrument Panel Compartment Lamp Switch Actuator Procedure Push in the retainers to release the lamp switch actuator from the instrument panel compartment.

Instrument Panel Compartment Lamp Switch Actuator Replacement

Scheme 18

Scheme 18: Instrument Panel Outer Compartment Replacement
Scheme 18: Instrument Panel Outer Compartment Replacement
CalloutComponent Name
1Instrument Panel Outer Compartment Retainer (Qty: 2)
2Instrument Panel Outer Compartment

Instrument Panel Outer Compartment Replacement

Scheme 19

Scheme 19: Instrument Panel Upper Molding Replacement
Scheme 19: Instrument Panel Upper Molding Replacement
CalloutComponent Name
1Instrument Panel Upper Molding Retainer (Qty: 5) TIP: Use a flat-bladed plastic trim tool to release the instrument panel upper molding from the instrument panel.
2Instrument Panel Upper Molding

Instrument Panel Upper Molding Replacement

Scheme 20

Scheme 20: Instrument Panel Upper Center Trim Panel Replacement
Scheme 20: Instrument Panel Upper Center Trim Panel Replacement
CalloutComponent Name
1Instrument Panel Upper Center Trim Panel Procedure Use a flat bladed plastic trim panel in order to release the retainer clips securing the upper center trim panel to the instrument panel assembly. Disconnect electrical connections. When replacing the instrument panel upper center trim panel, transfer all necessary components.

Instrument Panel Upper Center Trim Panel Replacement

Scheme 21

Scheme 21: Instrument Panel Outer Trim Cover Replacement - Right Side
Scheme 21: Instrument Panel Outer Trim Cover Replacement - Right Side
CalloutComponent Name
1Inflatable Restraint Disable Switch, if equipped. Procedure Disconnect the electrical connection.
2Instrument Panel Outer Trim Cover Procedure Use a flat-bladed plastic trim tool to aid in the removal of the outer trim cover. When replacing the instrument panel outer trim cover, transfer the inflatable restraint disable switch, if equipped.

Instrument Panel Outer Trim Cover Replacement - Right Side

Scheme 22

Scheme 22: Instrument Panel Outer Trim Cover Replacement - Left Side
Scheme 22: Instrument Panel Outer Trim Cover Replacement - Left Side
CalloutComponent Name
1Instrument Panel Outer Trim Cover TIP: Use a flat-bladed plastic trim tool to aid in the removal of the outer trim cover.

Instrument Panel Outer Trim Cover Replacement - Left Side

Scheme 23

Scheme 23: Instrument Panel Lower Trim Panel Replacement - Left Side
Scheme 23: Instrument Panel Lower Trim Panel Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Remove the left instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement - Left Side . Remove the headlamp switch. Refer to Headlamp Switch Molding Replacement . Remove the instrument panel outer compartment. Refer to Instrument Panel Outer Compartment Replacement . Remove the instrument panel molding - drivers side. Refer to Instrument Panel Molding Replacement - Driver Side . Remove the steering column upper trim panel. Refer to Steering Column Trim Cover Replacement . Remove the front floor console left extension panel. Refer to Front Floor Console Extension Panel Replacement . Remove the instrument panel ashtray housing. Refer to Instrument Panel Ashtray Housing Replacement .
1Instrument Panel Lower Trim Panel Fasteners (Qty: 5) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Trim Panel Assembly Procedures Disconnect the data link connector. Disconnect the electrical connections, if applicable. When replacing the instrument panel lower trim panel, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Replacement - Left Side

Scheme 24

Scheme 24: Instrument Panel Lower Center Trim Panel Replacement
Scheme 24: Instrument Panel Lower Center Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel upper center trim panel. Refer to Instrument Panel Upper Center Trim Panel Replacement . Remove the instrument panel molding - drivers side. Refer to Instrument Panel Molding Replacement - Driver Side . Remove the instrument panel molding - passenger side. Refer to Instrument Panel Molding Replacement - Passenger Side .
1Radio Control Module Bracket Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Center Trim Panel Procedures Disconnect the electrical connections. When replacing the instrument panel lower center trim panel, transfer all necessary components
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Center Trim Panel Replacement

Scheme 25

Scheme 25: Instrument Panel Ashtray Housing Replacement
Scheme 25: Instrument Panel Ashtray Housing Replacement
CalloutComponent Name
Preliminary Procedures Remove both front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement .
1Ashtray
2Instrument Panel Ashtray Housing Procedure Use a flat-bladed plastic trim tool to release the I/P ashtray housing from the instrument panel. Disconnect the electrical connections. If replacing the I/P panel ashtray housing, transfer all necessary components.

Instrument Panel Ashtray Housing Replacement

Scheme 26

Scheme 26: Instrument Panel Compartment Replacement
Scheme 26: Instrument Panel Compartment Replacement
CalloutComponent Name
Preliminary Procedures Remove the right outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement - Right Side . Remove the instrument panel lower extension compartment panel. Refer to Instrument Panel Lower Extension Compartment Panel Replacement .
1Instrument Panel Compartment Assembly Fastener (Qty: 4) CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Replacement

Scheme 27

Scheme 27: Instrument Panel Compartment Door Assembly Replacement
Scheme 27: Instrument Panel Compartment Door Assembly Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement . Disconnect the compartment door dampener. Refer to Instrument Panel Compartment Door Dampener Replacement .
1Instrument Panel Compartment Door Hinge Pin (Qty: 2) Procedure Use an appropriate tool in order to remove the door hinge pins.
2Instrument Panel Compartment Door Assembly

Instrument Panel Compartment Door Assembly Replacement

Scheme 28

Scheme 28: Instrument Panel Compartment Door Dampener Replacement
Scheme 28: Instrument Panel Compartment Door Dampener Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement .
1Instrument Panel Compartment Door Dampener Fastener CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Door Dampener Procedure Twist and pull the compartment door dampener from the instrument panel compartment assembly.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Door Dampener Replacement

Scheme 29

Scheme 29: Headlamp Switch Molding Replacement
Scheme 29: Headlamp Switch Molding Replacement
CalloutComponent Name
1Instrument Panel Headlamp Switch Molding Fastener (Qty: 4) Procedure Open instrument panel outer compartment. TIP: Use a flat-bladed plastic trim tool to release the headlamp switch molding from the instrument panel. Disconnect the electrical connections.
2Instrument Panel Headlamp Switch Molding Procedure If replacing the instrument panel headlamp switch molding, transfer the headlamp switch.

Headlamp Switch Molding Replacement

Scheme 30

Scheme 30: Instrument Panel Molding Replacement - Driver Side
Scheme 30: Instrument Panel Molding Replacement - Driver Side
CalloutComponent Name
Preliminary Procedures Remove instrument panel ashtray housing. Refer to Instrument Panel Ashtray Housing Replacement .
1Instrument Panel Molding TIP: Use a flat-bladed plastic trim tool to release the instrument panel molding from the instrument panel.

Instrument Panel Molding Replacement - Driver Side

Scheme 31

Scheme 31: Instrument Panel Molding Replacement - Passenger Side
Scheme 31: Instrument Panel Molding Replacement - Passenger Side
CalloutComponent Name
Preliminary Procedure Remove instrument panel ashtray housing. Refer to Instrument Panel Ashtray Housing Replacement .
1Instrument Panel Molding TIP: Use a flat-bladed plastic trim tool to release the instrument panel molding from the instrument panel.

Instrument Panel Molding Replacement - Passenger Side

Scheme 32

Scheme 32: Instrument Panel Lower Extension Side Trim Panel Replacement
Scheme 32: Instrument Panel Lower Extension Side Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove instrument panel compartment. Refer to Instrument Panel Compartment Replacement . Remove the instrument panel molding - passenger side. Refer to Instrument Panel Molding Replacement - Passenger Side .
1Instrument Panel Lower Extension Side Trim Panel Fastener (Qty: 3)
2Instrument Panel Lower Extension Side Trim Panel Procedure Grasp the trim panel assembly and pull rearward disengaging the retainer securing it to the instrument panel.

Instrument Panel Lower Extension Side Trim Panel Replacement

Scheme 33

Scheme 33: Windshield Defroster Nozzle Grille Replacement
Scheme 33: Windshield Defroster Nozzle Grille Replacement
CalloutComponent Name
1Windshield Defroster Nozzle Grille Retainer (Qty: 8) Procedure Use a flat-bladed plastic trim tool to aid in the removal of the windshield defroster nozzle grille. Disconnect the electrical connections.
2Sun Load Temperature and Headlamp Automatic Control Ambient Light Sensor
3Windshield Defroster Nozzle Grille

Windshield Defroster Nozzle Grille Replacement

Scheme 34

Scheme 34: Dash Panel Brace Replacement
Scheme 34: Dash Panel Brace Replacement
CalloutComponent Name
Preliminary Procedure Remove the air inlet panel. Refer to Air Inlet Grille Panel Replacement .
1Dash Panel Brace Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 22 N.m (16 lb ft)
2Dash Panel Brace
CAUTION
Refer to Fastener Caution .

Dash Panel Brace Replacement

Scheme 35

Scheme 35: Instrument Panel Assembly Replacement
Scheme 35: Instrument Panel Assembly Replacement
CalloutComponent Name
WARNING: Refer to SIR Warning . Preliminary Procedures Disable the SIR system. Remove the instrument panel lower extension side trim panel. Refer to Instrument Panel Lower Extension Side Trim Panel Replacement . Remove the instrument panel lower trim panel insulator. Refer to Instrument Panel Lower Trim Panel Insulator Replacement . Remove the radio assembly. Refer to Radio Replacement . Remove the HVAC remote control assembly. Refer to Heater and Air Conditioning Remote Control Replacement . Remove the radio front speaker. Refer to Radio Front Speaker Replacement . Remove the front floor console. Refer to Front Floor Console Replacement . Remove the steering column trim covers. Refer to Steering Column Trim Cover Replacement . Remove the instrument cluster. Refer to Instrument Cluster Replacement . Remove both windshield side garnish moldings. Refer to Windshield Side Garnish Molding Replacement .
1Instrument Panel Assembly Fastener (Qty: 7) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2Instrument Panel Assembly Procedures Disconnect the wiring harness from the I/P assembly. With the aid of an assistant, remove the I/P assembly from the vehicle. If replacing the I/P assembly, transfer all necessary components.
WARNING
Refer to SIR Warning .
CAUTION
Refer to Fastener Caution .

Instrument Panel Assembly Replacement

Scheme 36

Scheme 36: Instrument Panel Tie Bar Replacement
Scheme 36: Instrument Panel Tie Bar Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel (I/P) assembly. Refer to Instrument Panel Assembly Replacement . Remove both front and rear side door still trim plates. Refer to Front and Rear Side Door Sill Trim Plate Replacement . Remove the steering column. Refer to Steering Column Replacement . Remove the body control module bracket. Refer to Body Control Module Bracket Replacement . Remove the fasteners securing the brake and accelerator pedal assembly to the tie bar. Refer to Brake and Accelerator Pedal Assembly Replacement . Remove the instrument panel electrical center from the tie bar.
1Instrument Panel Tie Bar Assembly Fastener (Qty: 10) CAUTION: Refer to Fastener Caution . Tighten 22 N.m (16 lb ft)
2Heater and Air Conditioning Evaporator and Blower Module Fastener (Qty: 3) Procedure Release the heater and air conditioning evaporator and blower module from the I/P tie bar and secure the module at the body. Tighten 5 N.m (44 lb in)
3Instrument Panel Tie Bar Assembly Procedures Remove the hood release handle. Note location and routing of the I/P wiring harness prior to removal of the I/P tie bar assembly to ensure proper reinstallation. Disconnect the wiring harness from the I/P tie bar assembly. With the aid of an assistant, remove the I/P tie bar assembly from the vehicle. If replacing the I/P tie bar assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Tie Bar Replacement

Scheme 37

Scheme 37: Front Floor Console Wiring Harness Replacement
Scheme 37: Front Floor Console Wiring Harness Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement . Remove the front floor console rear cover. Refer to Front Floor Console Rear Cover Replacement . Remove the front floor upper console trim plate. Refer to Front Floor Upper Console Trim Plate Replacement . Remove the front floor console side covers. Refer to Front Floor Console Side Cover Replacement .
1Front Floor Console Wiring Harness Procedure Release the front floor console wiring harness from the lower console. When replacing the front floor console wiring harness, compare the wiring harnesses and transfer all necessary attaching parts.

Front Floor Console Wiring Harness Replacement

Scheme 38

Scheme 38: Front Floor Console Cover Replacement
Scheme 38: Front Floor Console Cover Replacement
CalloutComponent Name
Preliminary Procedures Remove both front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement . Remove instrument panel ashtray housing. Refer to Instrument Panel Ashtray Housing Replacement .
1Front Floor Console Cover Retainer (Qty: 4) TIP: Use a flat-bladed plastic trim tool to release the front floor console cover from the front floor upper console trim plate.
2Front Floor Console Cover

Front Floor Console Cover Replacement

Scheme 39

Scheme 39: Front Floor Console Front Compartment Replacement
Scheme 39: Front Floor Console Front Compartment Replacement
CalloutComponent Name
1Front Floor Console Front Compartment TIP: Use a flat-bladed plastic trim tool in order to release the retaining clips securing the front floor console front compartment to the front floor console assembly.

Front Floor Console Front Compartment Replacement

Scheme 40

Scheme 40: Front Floor Console Cup Holder Replacement
Scheme 40: Front Floor Console Cup Holder Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor upper console trim plate. Refer to Front Floor Upper Console Trim Plate Replacement .
1Front Floor Console Cup Holder Fastener (Qty: 6)
2Front Floor Console Cup Holder Procedure When replacing the front floor console cup holder, transfer all necessary components.

Front Floor Console Cup Holder Replacement

Scheme 41

Scheme 41: Front Floor Console Compartment Replacement
Scheme 41: Front Floor Console Compartment Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor upper console trim plate. Refer to Front Floor Upper Console Trim Plate Replacement .
1Front Floor Console Compartment Fastener (Qty: 4)
2Front Floor Console Compartment

Front Floor Console Compartment Replacement

Scheme 42

Scheme 42: Front Floor Upper Console Trim Plate Replacement
Scheme 42: Front Floor Upper Console Trim Plate Replacement
CalloutComponent Name
Preliminary Procedures Remove the transmission control lever knob. Refer to Transmission Control Lever Knob Replacement . Remove the transmission control lever boot. Refer to Transmission Control Lever Boot Replacement . Remove the front floor console transmission shift opening bezel. Refer to Front Floor Console Transmission Shift Opening Bezel Replacement . Remove the front floor console cover. Refer to Front Floor Console Cover Replacement . Position the front floor console armrest in it full open position.
1Front Floor Upper Console Trim Panel Assembly Procedures Lift upward releasing the front floor upper console trim plate from the console assembly. Disconnect the electrical connections. When replacing the front floor upper console trim plate, transfer all necessary components.

Front Floor Upper Console Trim Plate Replacement

Scheme 43

Scheme 43: Front Floor Console Side Cover Replacement
Scheme 43: Front Floor Console Side Cover Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement . Remove the front floor upper console trim plate. Refer to Front Floor Upper Console Trim Plate Replacement . Remove the front floor console rear cover. Refer to Front Floor Console Rear Cover Replacement . Remove the front floor console armrest. Refer to Front Floor Console Armrest Replacement .
1Front Floor Console Side Cover Procedure Lift upward on the console side covers releasing them from the lower console assembly.

Front Floor Console Side Cover Replacement

Scheme 44

Scheme 44: Front Floor Console Transmission Shift Opening Bezel Replacement
Scheme 44: Front Floor Console Transmission Shift Opening Bezel Replacement
CalloutComponent Name
1Front Floor Console Transmission Shift Opening Bezel Procedure Open the ashtray housing and pull off the shift opening bezel from the upper console trim plate. TIP: Use a flat-bladed plastic trim tool in order to release the front floor console transmission shift opening bezel from the front floor upper console trim plate.

Front Floor Console Transmission Shift Opening Bezel Replacement

Scheme 45

Scheme 45: Front Floor Console Extension Panel Replacement
Scheme 45: Front Floor Console Extension Panel Replacement
CalloutComponent Name
1Front Floor Console Extension Panel Procedure Grasp the extension panel and pull outward disengaging the retainer clips securing the panel to the front floor console.

Front Floor Console Extension Panel Replacement

Scheme 46

Scheme 46: Front Floor Console Replacement
Scheme 46: Front Floor Console Replacement
CalloutComponent Name
Preliminary Procedures Remove the transmission control lever boot. Refer to Transmission Control Lever Boot Replacement . Remove the front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement . Remove the instrument panel ashtray housing. Refer to Instrument Panel Ashtray Housing Replacement .
1Front Floor Console Fastener (Qty: 6) CAUTION: Refer to Fastener Caution . Procedure Move the front seats forward or backward in order to access the fasteners for removal.
2Front Floor Console Assembly Procedures Disconnect the electrical connections. When replacing the front floor console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement

Scheme 47

Scheme 47: Front Floor Lower Console Replacement
Scheme 47: Front Floor Lower Console Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement . Remove the front floor upper console trim plate. Refer to Front Floor Upper Console Trim Plate Replacement . Remove the front floor console side covers. Refer to Front Floor Console Side Cover Replacement . Remove the front floor console rear air duct. Refer to Front Floor Console Rear Air Duct Replacement . Remove the front floor console armrest. Refer to Front Floor Console Armrest Replacement . Remove the front floor console wiring harness. Refer to Front Floor Console Wiring Harness Replacement .
1Front Floor Lower Console Procedure When replacing the front floor lower console, transfer all necessary components.

Front Floor Lower Console Replacement

Scheme 48

Scheme 48: Front Floor Console Armrest Replacement
Scheme 48: Front Floor Console Armrest Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console rear cover. Refer to Front Floor Console Rear Cover Replacement .
1Front Floor Console Armrest Assembly Pin (Qty: 2)
2Front Floor Console Armrest Procedure Release the front floor console armrest from the armrest dampener.

Front Floor Console Armrest Replacement

Scheme 49

Scheme 49: Front Floor Console Rear Cover Replacement
Scheme 49: Front Floor Console Rear Cover Replacement
CalloutComponent Name
Preliminary Procedure Remove front floor console rear air outlet deflector housing. Refer to Front Floor Console Rear Air Outlet Deflector Housing Replacement .
1Front Floor Console Rear Cover Procedure Release the front floor console rear cover. Disconnect the electrical connectors.

Front Floor Console Rear Cover Replacement

Scheme 50

Scheme 50: Roof Console Replacement
Scheme 50: Roof Console Replacement
CalloutComponent Name
Preliminary Procedure Remove the roof console reading lamp bezel. Refer to Roof Console Reading Lamp Bezel Replacement .
1Roof Console Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2Roof Console Assembly Procedure Use a flat-bladed plastic trim tool to release the retainers along the forward edge of the console assembly releasing the roof console from the headliner. Pull the roof console assembly forward releasing the alignment tabs along the rear edge of the console assembly. Disconnect the electrical connections. When replacing the roof console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Roof Console Replacement

Scheme 51

Scheme 51: Roof Console Reading Lamp Bezel Replacement
Scheme 51: Roof Console Reading Lamp Bezel Replacement
CalloutComponent Name
1Roof Console Reading Lamp Bezel TIP: Carefully use a flat-bladed tool to release the retainer from the roof console reading lamp bezel to the dome and reading lamp.

Roof Console Reading Lamp Bezel Replacement

More articles — Body & Frame
