Scheme 228
Scheme 228: X100 Forward Lamp Harness to Front Bumper Harness (UD5)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 15465945 Service Connector: 13580112 Description: 8-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Front Bumper OEM Connector: 15326840 Service Connector: Service by Harness - See Part Catalog Description: 8-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 BK/BU | 5214 | Low Reference | A | 0.5 BK/BU | 5214 | Low Reference |
| B | 0.5 VT/WH | 5215 | Front Parking Left Corner Sensor | B | 0.5 VT/WH | 5215 | Front Parking Left Corner Sensor |
| C | 0.5 YE/GY | 5216 | Front Parking Left Mid Sensor | C | 0.5 YE/GY | 5216 | Front Parking Left Mid Sensor |
| D | 0.5 VT/GY | 5218 | Front Parking Right Mid Sensor | D | 0.5 VT/GY | 5218 | Front Parking Right Mid Sensor |
| E | 0.5 YE/VT | 5213 | Front Parking Left/Right/Mid Sensor | E | 0.5 YE/VT | 5213 | Front Parking Left/Right/Mid Sensor |
| F | 0.5 WH/GY | 5217 | Front Parking Right Corner Sensor | F | 0.5 WH/GY | 5217 | Front Parking Right Corner Sensor |
| G-H | | | Not Used | G-H | | | Not Used |
X100 Forward Lamp Harness to Front Bumper Harness (UD5)
X105 Power Steering Harness to Forward Lamp Harness (NV7 or NXC)
| Connector Part Information Harness Type: Power Steering OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Forward Lamp OEM Connector: 15326806 Service Connector: 19151499 Description: 2-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: 13575397 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 BN/GN | 1295 | Variable Effort Steering Solenoid Control | A | 0.5 BN/GN | 1295 | Variable Effort Steering Solenoid Control |
| B | 0.5 BK/YE | 6641 | Low Reference | B | 0.5 BK/YE | 6641 | Low Reference |
X105 Power Steering Harness to Forward Lamp Harness (NV7 or NXC)
X110 Forward Lamp Harness to Headlamp - Left Harness
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 9134900 Service Connector: 88988927 Description: 10-Way F 2.8 Timer Series, Sealed (BK) | Connector Part Information Harness Type: HeadLamp - Left OEM Connector: 1394396-1 Service Connector: Service by Component Assembly Description: 10-Way M 2.8 Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 1.5 BK | 1350 | Ground | 1 | 0.75 BK | 50 | Ground |
| 2 | 1.5 WH | 711 | Left Headlamp High Beam Supply Voltage | 2 | 0.75 BK | 711 | Left Headlamp High Beam Supply Voltage |
| 3 | 1.5 YE | 712 | Left Headlamp Low Beam Supply Voltage (T4A) | 3 | 0.75 BK | 712 | Left Headlamp Low Beam Supply Voltage |
| 1.5 YE | 1201 | Headlamp Low Beam (T4F) |
| 4 | 0.5 VT/GY | 709 | Left Park Lamp Supply Voltage (T4A) | 4 | 0.75 BK | 709 | Left Park Lamp Supply Voltage (T4A) |
| 0.5 GY/BU | 7538 | Left Front DRL Supply Voltage (T4F) | 0.75 BK | 709 | Left Front DRL Supply Voltage (T4F) |
| 5 | 0.5 BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage | 5 | 0.75 BK | 1314 | Left Front Turn Signal Lamp Supply Voltage |
| 6 | | | Not Used | 6 | | | Not Used |
| 7 | 0.5 VT/GY | 709 | Left Park Lamp Supply Voltage | 7 | 0.75 BK | 709 | Left Park Lamp Supply Voltage |
| 8-9 | | | Not Used | 8-9 | | | Not Used |
| 10 | 1.5 BK | 1150 | Ground (T4F) | 10 | 0.75 BK | 50 | Ground (T4F) |
X110 Forward Lamp Harness to Headlamp - Left Harness
Scheme 229
Scheme 229: X115 Engine Harness to Body Harness (LEA)
| Connector Part Information Harness Type: Engine OEM Connector: 13603185 Service Connector: 13576549 Description: 40-Way F 1.5/2.8 Series, Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 13262025 Service Connector: 13317817 Description: 40-Way M 2.8 ATS DSQ 1.5 Series, Sealed |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 19206848/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 964269-3/32 Core/Insulation Crimp: E/1 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.5 BK/D-BU | 1271 | Low Reference | 2 | 0.5 BK/BU | 1271 | Low Reference |
| 3 | 0.5 WH/RD | 1164 | 5 Volt Reference | 3 | 0.5 WH/RD | 1164 | 5 Volt Reference |
| 4 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) | 4 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) |
| 5 | 0.5 BK/VT | 1272 | Low Reference | 5 | 0.5 BK/VT | 1272 | Low Reference |
| 6 | 0.5 BN/RD | 1274 | 5 Volt Reference | 6 | 0.5 BN/RD | 1274 | 5 Volt Reference |
| 7 | 0.5 L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) | 7 | 0.5 GN/WH | 1162 | Accelerator Pedal Position Signal (2) |
| 8 | 0.5 WH/D-BU | 6311 | Cruise/ETC/TCC Brake Signal | 8 | 0.5 WH/BU | 6311 | Cruise/ETC/TCC Brake Signal |
| 9 | | | Not Used | 9 | 0.5 GY/RD | 6109 | Clutch Apply Sensor Voltage Reference |
| 10 | | | Not Used | 10 | 0.5 BK/GY | 6110 | Low Reference |
| 11 | | | Not Used | 11 | 0.5 YE | 6111 | Clutch Apply Sensor Signal |
| 12 | 0.5 BU | 2500 | High Speed GMLAN Serial Data (+) (1) | 12 | 0.5 BU | 2500 | High Speed GMLAN Serial Data (+) (1) |
| 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) | 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) |
| 14 | 0.5 VT/YE | 5985 | Accessory Wakeup Serial Data | 14 | 0.5 GN/VT | 206 | Accessory/Run/Crank Ignition 0 Voltage |
| 15 | 0.5 WH | 1310 | EVAP Canister Vent Solenoid Control | 15 | 0.75 WH | 1310 | EVAP Canister Vent Solenoid Control |
| 16-17 | | | Not Used | 16-17 | | | Not Used |
| 18 | 0.5 D-BU/WH | 890 | Fuel Tank Pressure Sensor Signal | 18 | 0.5 BU/WH | 890 | Fuel Tank Pressure Sensor Signal |
| 19 | 0.5 YE/RD | 2709 | 5 Volt Reference | 19 | 0.5 YE/RD | 2709 | 5 Volt Reference |
| 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control | 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control |
| 21 | 0.5 D-BU/L-GN | 1936 | Primary Fuel Level Sensor Signal | 21 | 0.5 BU/VT | 1589 | Primary Fuel Level Sensor Signal |
| 22 | | | Not Used | 22 | | | Not Used |
| 23 | 0.5 BK/L-GN | 6281 | Low Reference | 23 | 0.5 BK/GN | 6281 | Low Reference |
| 24 | | | Not Used | 24 | | | Not Used |
| 25 | 0.75 L-GN/GY | 465 | Fuel Pump Primary Relay Control (Late Prodution) | 25 | 0.75 GN/GY | 465 | Fuel Pump Primary Relay Control |
| 26-28 | | | Not Used | 26-28 | | | Not Used |
| 29 | 0.5 D-BU | 7573 | Electric Variable Displacement Supply | 29 | 0.5 BU/BN | 7573 | Electric Variable Displacement Supply |
| 30 | 0.5 D-BU/L-GN | 7574 | Electric Variable Displacement Control | 30 | 0.5 BU/YE | 7574 | Electric Variable Displacement Control |
| 31 | 0.5 VT/BK | 2139 | Run/Crank Ignition 1 Voltage | 31 | 0.75 VT/BU | 739 | Run/Crank Ignition 1 Voltage |
| 32-40 | | | Not Used | 32-40 | | | Not Used |
X115 Engine Harness to Body Harness (LEA)
Scheme 230
Scheme 230: X115 Engine Harness to Body Harness (LHU)
| Connector Part Information Harness Type: Engine OEM Connector: 13257309 Service Connector: 13576549 Description: 40-Way F ATS 2.8/DSQ 1.5 Series, Sealed | Connector Part Information Harness Type: Body OEM Connector: 13262025 Service Connector: 13317817 Description: 40-Way M 2.8 ATS DSQ 1.5 Series, Sealed |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 19206848/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 964269-3/32 Core/Insulation Crimp: E/1 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.5 BN | 1271 | Low Reference | 2 | 0.5 BK/VT | 1271 | Low Reference |
| 3 | 0.5 WH/BK | 1164 | 5 Volt Reference | 3 | 0.5 WH/RD | 1164 | 5 Volt Reference |
| 4 | 0.5 BU | 1161 | Accelerator Pedal Position Signal (1) | 4 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) |
| 5 | 0.5 VT | 1272 | Low Reference | 5 | 0.5 BK/VT | 1272 | Low Reference |
| 6 | 0.5 WH | 1274 | 5 Volt Reference | 6 | 0.5 BN/RD | 1274 | 5 Volt Reference |
| 7 | 0.5 BU | 1162 | Accelerator Pedal Position Signal (2) | 7 | 0.5 GN/WH | 1162 | Accelerator Pedal Position Signal (2) |
| 8 | 0.5 BU/WH | 6311 | Cruise/ETC/TCC Brake Signal | 8 | 0.5 WH/BU | 6311 | Cruise/ETC/TCC Brake Signal |
| 9 | 0.5 BU/WH | 7361 | Manual Transmission Clutch Position Sensor Supply | 9 | 0.5 GY/RD | 6109 | Clutch Apply Sensor Voltage Reference |
| 10 | 0.5 OG/GN | 7360 | Manual Transmission Clutch Position Sensor Return | 10 | 0.5 BK/GY | 6110 | Low Reference |
| 11 | 0.5 GN | 6338 | Manual Transmission Clutch Position Sensor Signal Position | 11 | 0.5 YE | 6111 | Clutch Apply Sensor Signal |
| 12 | 0.5 WH/BK | 2500 | High Speed GMLAN Serial Data (+) (1) | 12 | 0.5 BU | 2500 | High Speed GMLAN Serial Data (+) (1) |
| 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) | 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) |
| 14 | 0.5 YE | 143 | Accessory Voltage | 14 | 0.5 VT/YE | 5985 | Accessory Wakeup Serial Data |
| 15 | 0.5 WH | 1310 | EVAP Canister Vent Solenoid Control | 15 | 0.75 WH | 1310 | EVAP Canister Vent Solenoid Control |
| 16-17 | | | Not Used | 16-17 | | | Not Used |
| 18 | 0.5 GN | 890 | Fuel Tank Pressure Sensor Signal | 18 | 0.5 BU/WH | 890 | Fuel Tank Pressure Sensor Signal |
| 19 | 0.5 GY | 2709 | 5 Volt Reference | 19 | 0.5 YE/RD | 2709 | 5 Volt Reference |
| 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control | 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control |
| 21 | 0.5 BU | 1936 | Primary Fuel Level Sensor Signal | 21 | 0.5 BU/VT | 1589 | Primary Fuel Level Sensor Signal |
| 22 | 0.5 BU | 1937 | Secondary Fuel Level Sensor Signal | 22 | | | Not Used |
| 23 | 0.5 WH | 2759 | Low Reference | 23 | 0.5 BK/GN | 6281 | Low Reference |
| 24 | | | Not Used | 24 | | | Not Used |
| 25 | 0.5 GN/WH | 465 | Fuel Pump Primary Relay Control | 25 | 0.75 GN/GY | 465 | Fuel Pump Primary Relay Control |
| 26-28 | | | Not Used | 26-28 | | | Not Used |
| 29 | 0.75 BN/GN | 7573 | Electric Variable Displacement Supply | 29 | 0.5 BU/BN | 7573 | Electric Variable Displacement Supply |
| 30 | 0.75 YE/BU | 7574 | Electric Variable Displacement Control | 30 | 0.5 BU/YE | 7574 | Electric Variable Displacement Control |
| 31 | 0.5 BK | 39 | Run/Crank Ignition 1 Voltage | 31 | 0.75 VT/BK | 739 | Run/Crank Ignition 1 Voltage |
| 32-40 | | | Not Used | 32-40 | | | Not Used |
X115 Engine Harness to Body Harness (LHU)
X115 Engine Harness to Body Harness (LUK)
| Connector Part Information Harness Type: Engine OEM Connector: 13603185 Service Connector: 13576549 Description: 40-Way F 1.5/2.8 Series, Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 13262025 Service Connector: 13317817 Description: 40-Way M 2.8 ATS DSQ 1.5 Series, Sealed |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 19206848/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 964269-3/32 Core/Insulation Crimp: E/1 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.5 BK/D-BU | 1271 | Low Reference | 2 | 0.5 BK/BU | 1271 | Low Reference |
| 3 | 0.5 WH/RD | 1164 | 5 Volt Reference | 3 | 0.5 WH/RD | 1164 | 5 Volt Reference |
| 4 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) | 4 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) |
| 5 | 0.5 BK/VT | 1272 | Low Reference | 5 | 0.5 BK/VT | 1272 | Low Reference |
| 6 | 0.5 BN/RD | 1274 | 5 Volt Reference | 6 | 0.5 BN/RD | 1274 | 5 Volt Reference |
| 7 | 0.5 L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) | 7 | 0.5 GN/WH | 1162 | Accelerator Pedal Position Signal (2) |
| 8 | 0.5 WH/D-BU | 6311 | Cruise/ETC/TCC Brake Signal | 8 | 0.5 WH/BU | 6311 | Cruise/ETC/TCC Brake Signal |
| 9 | | | Not Used | 9 | 0.5 GY/RD | 6109 | Clutch Apply Sensor Voltage Reference |
| 10 | | | Not Used | 10 | 0.5 BK/GY | 6110 | Low Reference |
| 11 | | | Not Used | 11 | 0.5 YE | 6111 | Clutch Apply Sensor Signal |
| 12 | 0.5 BU | 2500 | High Speed GMLAN Serial Data (+) (1) | 12 | 0.5 BU | 2500 | High Speed GMLAN Serial Data (+) (1) |
| 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) | 13 | 0.5 WH | 2501 | High Speed GMLAN Serial Data (-) (1) |
| 14 | 0.5 VT/YE | 5985 | Accessory Wakeup Serial Data | 14 | 0.5 GN/VT | 206 | Accessory/Run/Crank Ignition 0 Voltage |
| 15 | 0.5 WH | 1310 | EVAP Canister Vent Solenoid Control | 15 | 0.75 WH | 1310 | EVAP Canister Vent Solenoid Control |
| 16-17 | | | Not Used | 16-17 | | | Not Used |
| 18 | 0.5 D-BU/WH | 890 | Fuel Tank Pressure Sensor Signal | 18 | 0.5 BU/WH | 890 | Fuel Tank Pressure Sensor Signal |
| 19 | 0.5 YE/RD | 2709 | 5 Volt Reference | 19 | 0.5 YE/RD | 2709 | 5 Volt Reference |
| 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control | 20 | 0.5 BN/WH | 419 | Check Engine Indicator Control |
| 21 | 0.5 D-BU/L-GN | 1936 | Primary Fuel Level Sensor Signal | 21 | 0.5 BU/VT | 1589 | Primary Fuel Level Sensor Signal |
| 22 | | | Not Used | 22 | | | Not Used |
| 23 | 0.5 BK/L-GN | 6281 | Low Reference | 23 | 0.5 BK/GN | 6281 | Low Reference |
| 24 | | | Not Used | 24 | | | Not Used |
| 25 | 0.75 L-GN/GY | 465 | Fuel Pump Primary Relay Control (Late Prodution) | 25 | 0.75 GN/GY | 465 | Fuel Pump Primary Relay Control |
| 26-28 | | | Not Used | 26-28 | | | Not Used |
| 29 | 0.5 D-BU | 7573 | Electric Variable Displacement Supply | 29 | 0.5 BU/BN | 7573 | Electric Variable Displacement Supply |
| 30 | 0.5 D-BU/L-GN | 7574 | Electric Variable Displacement Control | 30 | 0.5 BU/YE | 7574 | Electric Variable Displacement Control |
| 31 | 0.5 VT/BK | 2139 | Run/Crank Ignition 1 Voltage | 31 | 0.75 VT/BU | 739 | Run/Crank Ignition 1 Voltage |
| 32-40 | | | Not Used | 32-40 | | | Not Used |
X115 Engine Harness to Body Harness (LUK)
Scheme 231
Scheme 231: X116 Cooling Fan Harness to Forward Lamp Harness
| Connector Part Information Harness Type: Cooling Fan OEM Connector: 13161013 Service Connector: Service by Harness- See Part Catalog Description: 4-Way F 4.8 9.5 Series, Sealed (BK) | Connector Part Information Harness Type: Forward Lamp OEM Connector: 13212505 Service Connector: 13316148 Description: 4-Way M 5.8 9.5 Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: 1, 4 Terminated Lead: Pending Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness- See Part Catalog Core/Insulation Crimp: Not Available Pins: 2, 3 Terminated Lead: Pending Release Tool: 12093647 Diagnostic Test Probe: J-35616-40 (BU) Terminal/Tray: 60040451/21 Core/Insulation Crimp: A/3 | Terminal Part Information Pins: 1, 4 Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending Pins: 2, 3 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: NA Terminal/Tray: 964314-1/ NA Core/Insulation Crimp: Pending |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 4 RD/WH | 532 | Cooling Fan Motor Supply Voltage (2) (LEA) | 1 | 4 GY | 532 | Cooling Fan Motor Supply Voltage (2) (LEA) |
| 6 RD/WH | 1040 | Battery Positive Voltage (LHU) | 6 RD/WH | 1040 | Battery Positive Voltage (LHU) |
| 2 | 0.75 VT/BU | 5290 | Powertrain Main Relay Fused Supply (1) (LHU) | 2 | 0.75 VT/BU | 5290 | Powertrain Main Relay Fused Supply (1) (LHU) |
| 3 | 4 BK/GN | 504 | Cooling Fan Motor Return (LEA) | 3 | 4 GN/BK | 504 | Cooling Fan Motor Return (LEA) |
| 0.75 BN/YE | 5128 | Cooling Fan Relay Coil Control (LHU) | 0.75 BN/YE | 5128 | Cooling Fan Relay Coil Control (LHU) |
| 4 | 4 RD/YE | 409 | Cooling Fan Motor Supply Voltage (1) (LEA) | 4 | 4 WH/BU | 409 | Cooling Fan Motor Supply Voltage (1) (LEA) |
| 6 GN | 7625 | Cooling Fan Motor Supply Voltage (4) (LHU) | 6 GN | 7625 | Cooling Fan Motor Supply Voltage (4) (LHU) |
X116 Cooling Fan Harness to Forward Lamp Harness
X117 Cooling Fan Harness to Forward Lamp Harness
| Connector Part Information Harness Type: Cooling Fan OEM Connector: 88986902 Service Connector: 19151498 Description: 5-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Forward Lamp OEM Connector: 15326827 Service Connector: 13504593 Description: 5-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 BK/BN | 5514 | Low Reference | A | 0.5 BK/BN | 5514 | Low Reference |
| B | 0.5 BN/RD | 2700 | 5 Volt Reference | B | 0.5 BN/RD | 2700 | 5 Volt Reference |
| C | 0.5 GN | 380 | A/C Refrigerant Pressure Sensor Signal | C | 0.5 GN | 380 | A/C Refrigerant Pressure Sensor Signal |
| D-E | | | Not Used | D-E | | | Not Used |
X117 Cooling Fan Harness to Forward Lamp Harness
Scheme 232
Scheme 232: X118 Cooling Fan Harness to Forward Lamp Harness (LHU)
| Connector Part Information Harness Type: Cooling Fan OEM Connector: 24452452 Service Connector: 24452452 Description: 2-Way F 9.5 Series, Sealed (BK) | Connector Part Information Harness Type: Forward Lamp OEM Connector: 24413501 Service Connector: 13579007 Description: 2-Way M 9.5 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness- See Part Catalog Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 6 YE | 5358 | Cooling Fan Motor Supply Voltage (3) | 1 | 6 YE | 5358 | Cooling Fan Motor Supply Voltage (3) |
| 2 | 6 RD/WH | 1040 | Battery Positive Voltage | 2 | 6 RD/WH | 1040 | Battery Positive Voltage |
X118 Cooling Fan Harness to Forward Lamp Harness (LHU)
X120 Forward Lamp Harness to Headlamp - Right Harness
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 9134900 Service Connector: 88988927 Description: 10-Way F 2.8 Timer Series, Sealed (BK) | Connector Part Information Harness Type: HeadLamp - Right OEM Connector: 1394396-1 Service Connector: Service by Component Assembly Description: 10-Way M 2.8 Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 1.5 BK | 1050 | Ground (T4A) | 1 | 0.75 BK | 50 | Ground |
| 1.5 BK | 1350 | Ground (T4F) |
| 2 | 1.5 WH | 311 | Right Headlamp High Beam Supply Voltage | 2 | 0.75 BK | 311 | Right Headlamp High Beam Supply Voltage |
| 3 | 1.5 YE | 312 | Right Headlamp Low Beam Supply Voltage (T4A) | 3 | 0.75 BK | 312 | Right Headlamp Low Beam Supply Voltage |
| 4 | 0.5 GY/BN | 309 | Right Park Lamp Supply Voltage (T4A) | 4 | 0.75 BK | 309 | Right Park Lamp Supply Voltage (T4A) |
| 0.5 BU/BN | 7539 | Right Front DRL Supply Voltage (T4F) | 0.75 BK | 309 | Right Front DRL Supply Voltage (T4F) |
| 5 | 0.5 GN/VT | 1315 | Right Front Turn Signal Lamp Supply Voltage | 5 | 0.75 BK | 1315 | Right Front Turn Signal Lamp Supply Voltage |
| 6 | | | Not Used | 6 | | | Not Used |
| 7 | 0.5 GY/BN | 309 | Right Park Lamp Supply Voltage | 7 | 0.75 BK | 309 | Right Park Lamp Supply Voltage |
| 8-9 | | | Not Used | 8-9 | | | Not Used |
| 10 | 1.5 BK | 1050 | Ground (T4F) | 10 | 0.75 BK | 50 | Ground (T4F) |
X120 Forward Lamp Harness to Headlamp - Right Harness
Scheme 233
Scheme 233: X122 Engine Harness to Body Harness (NU6)
| Connector Part Information Harness Type: Engine OEM Connector: 12147067 Service Connector: 89046640 Description: 2-Way F Ducon 6.3 Series, Sealed (GY) | Connector Part Information Harness Type: Body OEM Connector: 90414950 Service Connector: Pending Description: 2-Way M Sealed |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 12147474/24 Core/Insulation Crimp: G/F/3 | Terminal Part Information Terminated Lead: 13505808 Release Tool: J-38125-11A Diagnostic Test Probe: J-35616-43 (RD) Terminal/Tray: 15344631/19 Core/Insulation Crimp: F/3 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 4 BN/YE | 78 | Air Injection Reaction Pump Supply Voltage | 1 | 4 BN/YE | 78 | Air Injection Reaction Pump Supply Voltage |
| B | | | Not Used | 2 | | | Not Used |
X122 Engine Harness to Body Harness (NU6)
X125 Engine Harness to A/C Compressor Harness
| Connector Part Information Harness Type: Engine OEM Connector: 12052644 (LEA) OEM Connector: 90414940 (LHU) Service Connector: 15306302 (LEA) Service Connector: Pending (LHU) Description: 2-Way F Metri-Pack 150 Series Sealed (GY) | Connector Part Information Harness Type: A/C Compressor OEM Connector: 12162343 Service Connector: 12162343 Description: 2-Way M Sealed (GY) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Service by Harness- See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness- See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-BU/L-GN | 7574 | Electric Variable Displacement Control (LEA) | A | 0.5 BK | 7574 | Electric Variable Displacement Control |
| 0.5 YE/BU | 7574 | Electric Variable Displacement Control (LHU) |
| B | 0.5 D-BU | 7573 | Electric Variable Displacement Supply (LEA) | B | 0.5 BK | 7573 | Electric Variable Displacement Supply |
| 0.5 BN/GN | 7573 | Electric Variable Displacement Supply (LHU) |
X125 Engine Harness to A/C Compressor Harness
Scheme 234
Scheme 234: X130 Forward Lamp Harness to Suspension - Left Front Harness (F45)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 13147089 Service Connector: 13316191 10-Way F 1.6 Series, Sealed (BK) | Connector Part Information Harness Type: Suspension - Left Front OEM Connector: ZMW 7-2 Service Connector: Service by Harness - See Part Catalog Description: 10-Way M Sealed (GY) |
|---|
| Terminal Part Information Terminated Lead: 13578874 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Service By Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Service By Harness - See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 1 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
| 2 | 0.5 WH | 1100 | Left Front Wheel Damping Accelerometer Signal | 2 | 0.5 WH | 1100 | Left Front Wheel Damping Accelerometer Signal |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | 4 | 0.5 YE | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 5 | 0.75 BN/WH | 1107 | Left Front Damping Servo Control | 5 | 0.75 GN/RD | 1107 | Left Front Damping Servo Control |
| 6 | 0.5 GY | 830 | Wheel Speed Sensor Signal Left Front | 6 | 0.5 BU/WH | 830 | Wheel Speed Sensor Signal Left Front |
| 7 | 0.5 GY/WH | 7064 | Left Front Wheel Speed Sensor Low Reference | 7 | 0.5 BK/BU | 873 | Left Front Wheel Speed Sensor Low Reference |
| 8-9 | | | Not Used | 8 | | | Not Used |
| 10 | 0.75 GY/BU | 113 | Left Front Damping Servo Control | 10 | 0.75 GY/BU | 113 | Left Front Damping Servo Control |
X130 Forward Lamp Harness to Suspension - Left Front Harness (F45)
Scheme 235
Scheme 235: X131 Left Front Suspension Components to Left Front Suspension Harness (F45)
Scheme 236
| Connector Part Information Harness Type: Left Front Suspension Components - Left Front Wheel Speed Sensor OEM Connector: 24466107 Service Connector: Service by Component Assembly - See Part Catalog Description: 2-Way F (L-GY) Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available Connector Part Information Harness Type: Left Front Suspension Components - Left Front Shock Absorber Actuator OEM Connector: 24466109 Service Connector: Service by Component Assembly - See Part Catalog Description: 2-Way F (BK) Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available Connector Part Information Harness Type: Left Front Suspension Components - Left Front Vertical Suspension Acceleration Sensor OEM Connector: 24466110 Service Connector: Service by Component Assembly - See Part Catalog Description: 3-Way F (WH) | Connector Part Information Harness Type: Left Front Suspension OEM Connector: ZMW 7-1 Service Connector: Service by Harness - See Part Catalog Description: 9-Way M (GY) |
|---|
| Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BU/WH | 830 | Wheel Speed Sensor Signal Left Front | 1 | 0.5 RD | 830 | Wheel Speed Sensor Signal Left Front |
| 2 | 0.5 BK/BU | 873 | Left Front Wheel Speed Sensor Low Reference | 2 | 0.5 YE | 873 | Left Front Wheel Speed Sensor Low Reference |
| 3-4 | | | Not Available | 3-4 | | | Not Available |
| 1 | 0.75 GY/BU | 1113 | Left Front Damping Servo Control | 5 | 0.5 GN | 1113 | Left Front Damping Servo Control |
| 2 | 0.75 GN/RD | 1107 | Left Front Damping Servo Supply Voltage | 6 | 0.5 BN | 1107 | Left Front Damping Servo Supply Voltage |
| 1 | 0.5 GN | 1817 | Left Front Wheel Accelerometer Voltage Reference | 7 | 0.5 PU | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 2 | 0.5 WH | 1100 | Left Front Wheel Damping Accelerometer Signal | 8 | 0.5 BU | 1100 | Left Front Wheel Damping Accelerometer Signal |
| 3 | 0.5 BU/BK | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 9 | 0.5 OG | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
X131 Left Front Suspension Components to Left Front Suspension Harness (F45)
X140 Forward Lamp Harness to Suspension - Right Front Harness (F45)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 13147089 Service Connector: 13316191 10-Way F 1.6 Series, Sealed (BK) | Connector Part Information Harness Type: Suspension - Right Front OEM Connector: ZMW 7-2 Service Connector: Service by Harness - See Part Catalog Description: 10-Way M Sealed (GY) |
|---|
| Terminal Part Information Terminated Lead: 13578874 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Service By Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Not Available Terminal/Tray: Service By Harness - See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK/BN | 1099 | Right Front Wheel Damping Accelerometer Low Reference | 1 | 0.5 BK/BN | 1099 | Right Front Wheel Damping Accelerometer Low Reference |
| 2 | 0.5 WH | 1106 | Right Front Wheel Damping Accelerometer Signal | 2 | 0.5 WH | 1106 | Right Front Wheel Damping Accelerometer Signal |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.5 YE/RD | 1817 | Right Front Wheel Accelerometer Voltage Reference | 4 | 0.5 YE | 1817 | Right Front Wheel Accelerometer Voltage Reference |
| 5 | 0.75 BN/BU | 1116 | Right Front Damping Servo Control | 5 | 0.75 GY/RD | 1116 | Right Front Damping Servo Control |
| 6 | 0.5 RD/BU | 872 | Wheel Speed Sensor Signal Right Front | 6 | 0.5 RD/BU | 872 | Wheel Speed Sensor Signal Right Front |
| 7 | 0.5 GY/BN | 7065 | Wheel Speed Sensor Low Reference Right Front | 7 | 0.5 BK/YE | 833 | Wheel Speed Sensor Low Reference Right Front |
| 8-9 | | | Not Used | 8-9 | | | Not Used |
| 10 | 0.75 GY/WH | 1117 | Right Front Damping Servo Control | 10 | 0.75 GY/WH | 1117 | Right Front Damping Servo Control |
X140 Forward Lamp Harness to Suspension - Right Front Harness (F45)
X141 Right Front Suspension Components to Right Front Suspension Harness (F45)
| Connector Part Information Harness Type: Right Front Suspension Components - Right Front Wheel Speed Sensor OEM Connector: 24466107 Service Connector: Service by Component Assembly - See Part Catalog Description: 2-Way F (L-GY) Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available Connector Part Information Harness Type: Right Front Suspension Components - Right Front Shock Absorber Actuator OEM Connector: 24466109 Service Connector: Service by Component Assembly - See Part Catalog Description: 2-Way F (BK) Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available Connector Part Information Harness Type: Right Front Suspension Components - Right Front Vertical Suspension Acceleration Sensor OEM Connector: 24466110 Service Connector: Service by Component Assembly - See Part Catalog Description: 3-Way F (WH) | Connector Part Information Harness Type: Right Front Suspension OEM Connector: ZMW 7-1 Service Connector: Service by Harness - See Part Catalog Description: 9-Way M (GY) |
|---|
| Terminal Part Information Terminated Lead: Service by Component Assembly - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Component Assembly - See Part Catalog Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 RD/BU | 872 | Wheel Speed Sensor Signal Right Front | 1 | 0.5 RD | 872 | Wheel Speed Sensor Signal Right Front |
| 2 | 0.5 BK/YE | 833 | Wheel Speed Sensor Low Reference Right Front | 2 | 0.5 YE | 833 | Wheel Speed Sensor Low Reference Right Front |
| 3-4 | | | Not Available | 3-4 | | | Not Available |
| 1 | 0.75 GY/WH | 1117 | Right Front Damping Servo Control | 5 | 0.5 GN | 1117 | Right Front Damping Servo Control |
| 2 | 0.75 GY/RD | 1116 | Right Front Damping Servo Supply Voltage | 6 | 0.5 BN | 1116 | Right Front Damping Servo Supply Voltage |
| 1 | 0.5 YE | 1817 | Right Front Wheel Accelerometer Voltage Reference | 7 | 0.5 PU | 1817 | Right Front Wheel Accelerometer Voltage Reference |
| 2 | 0.5 WH | 1106 | Right Front Wheel Damping Accelerometer Signal | 8 | 0.5 BU | 1106 | Right Front Wheel Damping Accelerometer Signal |
| 3 | 0.5 PK/BK | 1099 | Right Front Wheel Damping Accelerometer Low Reference | 9 | 0.5 OG | 1099 | Right Front Wheel Damping Accelerometer Low Reference |
X141 Right Front Suspension Components to Right Front Suspension Harness (F45)
X150 Forward Lamp Harness to Body Harness
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 13603185 Service Connector: 13576549 Description: 40-Way F 1.5/2.8 Series, Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 13603205 Service Connector: 13576552 Description: 40-Way M 1.5/2.8 Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: 1 Terminated Lead: 13327156 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Pins: 2, 9-10, 22, 24, 34 Terminated Lead: 13327181 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (D-GN) Pins: 3-15, 18-21, 23, 25, 26-31, 35-36, 38-39 Terminated Lead: 13327180 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (D-GN) Pins: 16 Terminated Lead: 13327154 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Pins: 17, 32-33 Terminated Lead: 13327155 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) | Terminal Part Information Pins: 1 Terminated Lead: 13327146 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Pins: 2 Terminated Lead: 15482325 Release Tool: - Diagnostic Test Probe: - Pins: 3-15, 18-19, 21-31, 34-36, 38-39 Terminated Lead: Sealed: 13575380 Unsealed: 13327190 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Pins: 16 Terminated Lead: 13327097 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Pins: 17, 32-33 Terminated Lead: 15327890 Release Tool: - Diagnostic Test Probe: - Pins: 20 Terminated Lead: 15482323 Release Tool: - Diagnostic Test Probe |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 2.5 L-GN/WH | 2968 | Transmission Auxiliary Oil Pump Control (HP6) | 1 | 2.5 L-GN/WH | 2968 | Transmission Auxiliary Oil Pump Control (HP6) |
| 2 | 1 RD/L-GN | 3140 | Battery Positive Voltage (HP6) | 2 | 1 RD/L-GN | 3140 | Battery Positive Voltage (HP6) |
| 3 | 0.5 RD/D-BU | 872 | Wheel Speed Sensor Signal Right Front | 3 | 0.5 RD/D-BU | 872 | Wheel Speed Sensor Signal Right Front |
| 4 | 0.5 BK/YE | 7065 | Wheel Speed Sensor Supply Voltage Right Front (F45) | 4 | 0.5 BK/YE | 833 | Right Front Wheel Speed Sensor Low Reference |
| 5 | 0.5 GY | 830 | Wheel Speed Sensor Signal Left Front | 5 | 0.5 GY | 830 | Wheel Speed Sensor Signal Left Front |
| 6 | 0.5 GY/WH | 7064 | Wheel Speed Sensor Supply Voltage Left Front (F45) | 6 | 0.5 GY/WH | 873 | Left Front Wheel Speed Sensor Low Reference |
| 7 | 0.5 OG/YE | 354 | Left Front Discriminating Sensor Signal | 7 | 0.5 OG/YE | 354 | Left Front Discriminating Sensor Signal |
| 8 | 0.5 BK/OG | 5045 | Left Front Discriminating Sensor Low Reference | 8 | 0.5 BK/OG | 5045 | Left Front Discriminating Sensor Low Reference |
| 9 | 0.5 D-BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage | 9 | 0.5 D-BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage |
| 10 | 0.5 L-GN/VT | 1315 | Right Front Turn Signal Lamp Supply Voltage | 10 | 0.5 L-GN/VT | 1315 | Right Front Turn Signal Lamp Supply Voltage |
| 11 | 0.5 VT/GY | 709 | Left Park Lamp Control | 11 | 0.5 VT/GY | 709 | Left Park Lamp Control (TT4) |
| 12 | 0.5 GY/BN | 309 | Right Park Lamp Supply Voltage (TT4) | 12 | 0.5 GY/BN | 309 | Right Park Lamp Supply Voltage (TT4) |
| 13 | 0.5 OG/L-GN | 1409 | Right Front Discriminating Sensor Signal | 13 | 0.5 OG/L-GN | 1409 | Right Front Discriminating Sensor Signal |
| 14 | 0.5 BK/OG | 5600 | Low Reference | 14 | 0.5 BK/OG | 5600 | Low Reference |
| 15 | 0.5 YE | 5530 | Hood Open Switch Signal | 15 | 0.5 YE | 5530 | Hood Open Switch Signal |
| 16 | | | Not Used | 16 | | | Not Used |
| 17 | 2.5 RD/VT | 1940 | Battery Positive Voltage (BTM) | 17 | 2.5 RD/VT | 1940 | Battery Positive Voltage (BTM) |
| 18 | 0.5 BN/L-GN | 196 | Windshield Wiper Motor Park Switch Signal | 18 | 0.5 BN/L-GN | 196 | Windshield Wiper Motor Park Switch Signal |
| 19 | 0.5 VT | 185 | Low Washer Fluid Indicator Control | 19 | 0.5 VT | 185 | Low Washer Fluid Indicator Control |
| 20-22 | | | Not Used | 20-22 | | | Not Used |
| 23 | 0.5 BN/L-GN | 109 | Hood Ajar Switch Signal | 23 | 0.5 BN/L-GN | 109 | Hood Ajar Switch Signal |
| 24 | 0.5 BN/L-GN | 1295 | Variable Effort Steering Solenoid Control (NV7) | 24 | 0.5 BN/L-GN | 1295 | Variable Effort Steering Solenoid Control (NV7) |
| 25 | 0.5 BK/YE | 6641 | Low Reference (NV7) | 25 | 0.5 BK/YE | 6641 | Low Reference (NV7) |
| 26-29 | | | Not Used | 26-29 | | | Not Used |
| 30 | 0.5 BN | 6305 | Brake Vacuum Switch Signal | 30 | 0.5 BN | 6305 | Brake Vacuum Switch Signal |
| 31 | | | Not Used | 31 | | | Not Used |
| 32 | 1.5 YE | 712 | Left Headlamp Low Beam Supply Voltage (T4A) | 32 | 1.5 YE | 712 | Left Headlamp Low Beam Supply Voltage (T4A) |
| 1.5 GY/D-BU | 7538 | Left Front DRL Supply Voltage (T4F) |
| 33 | 0.5 YE | 312 | Right Headlamp Low Beam Supply Voltage (T4A) | 33 | 0.5 YE | 312 | Right Headlamp Low Beam Supply Voltage (T4A) |
| 1.5 D-BU/BN | 7539 | Right Front DRL Supply Voltage (T4F) |
| 34 | 0.5 L-GN/VT | 2032 | Coolant Temperature Sensor Signal | 34 | 0.5 L-GN/VT | 2032 | Coolant Temperature Sensor Signal |
| 35 | 0.5 BK/YE | 407 | Low Reference | 35 | 0.5 BK/YE | 407 | Low Reference |
| 36 | | | Not Used | 36 | | | Not Used |
| 37 | 0.5 WH | 1579 | Fuel Temperature/Composition Signal | 37 | 0.5 WH | 1579 | Fuel Temperature/Composition Signal |
| 38 | 0.5 D-BU/GY | 636 | Outside Ambient Air Temperature Sensor Signal | 38 | 0.5 D-BU/GY | 636 | Outside Ambient Air Temperature Sensor Signal |
| 39 | 0.5 BK/D-BU | 61 | Outside Ambient Temperature Sensor Low Reference | 39 | 0.5 BK/D-BU | 61 | Outside Ambient Temperature Sensor Low Reference |
| 40 | 0.5 VT/D-BU | 5294 | Powertrain Main Relay Fused Supply (5) | 40 | 0.5 VT/D-BU | 5294 | Powertrain Main Relay Fused Supply (5) |
X150 Forward Lamp Harness to Body Harness
Scheme 237
Scheme 237: X151 Forward Lamp Harness to Body Harness (F45)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 13603186 Service Connector: 13576550 Description: 40-Way F 1.5 2.8 Series, Sealed (GY) | Connector Part Information Harness Type: Body OEM Connector: 13603206 Service Connector: 13576553 Description: 40-Way M 1.5/2.8 Series, Sealed (GY) |
|---|
| Terminal Part Information Pins: 2-6, 11-12, 14-15, 22-23 Terminated Lead: 13327181 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Pins: 18-21, 24-29 Terminated Lead: 13327180 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Pins: 16-17 Terminated Lead: 13327154 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) | Terminal Part Information Pins: 2-15, 18-29 Terminated Lead: Sealed: 13575380 Unsealed: 13327190 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Pins: 16-17 Terminated Lead: 13327097 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK/D-BU | 5214 | Low Reference (UD5) | 1 | 0.5 BK/D-BU | 5214 | Low Reference (UD5) |
| 2 | 0.5 VT/WH | 5215 | Front Parking Left Corner Sensor (UD5) | 2 | 0.5 VT/WH | 5215 | Front Parking Left Corner Sensor (UD5) |
| 3 | 0.5 YE/GY | 5216 | Front Parking Left Mid Sensor (UD5) | 3 | 0.5 YE/GY | 5216 | Front Parking Left Mid Sensor(UD5) |
| 4 | 0.5 VT/GY | 5218 | Front Parking Right Mid Sensor (UD5) | 4 | 0.5 VT/GY | 5218 | Front Parking Right Mid Sensor (UD5) |
| 5 | 0.5 YE/VT | 5213 | Front Parking Sensor + (UD5) | 5 | 0.5 YE/VT | 5213 | Front Parking Sensor + (UD5) |
| 6 | 0.5 WH/GY | 5217 | Front Parking Right Corner Sensor (UD5) | 6 | 0.5 WH/GY | 5217 | Front Parking Right Corner Sensor (UD5) |
| 7-13 | | | Not Used | 7-13 | | | Not Used |
| 14 | 0.75 GY/WH | 1117 | Right Front Damping Servo Control | 14 | 0.75 GY/WH | 1117 | Right Front Damping Servo Control |
| 15 | 0.75 GY/RD | 1116 | Right Front Damping Servo Control | 15 | 0.75 GY/RD | 1116 | Right Front Damping Servo Control |
| 16 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 16 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
| 17 | 0.5 WH | 1106 | Right Front Wheel Damping Accelerometer Signal | 17 | 0.5 WH | 1106 | Right Front Wheel Damping Accelerometer Signal |
| 18 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | 18 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 19 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 19 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
| 20 | 0.5 WH/BN | 3253 | Right Front Accelerometer Signal | 20 | 0.5 WH/BN | 3253 | Right Front Accelerometer Signal |
| 21 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | 21 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 22 | 0.75 BN/WH | 1107 | Left Front Damping Servo Control | 22 | 0.75 BN/WH | 1107 | Left Front Damping Servo Control |
| 23 | 0.75 GY/D-BU | 1113 | Left Front Damping Servo Control | 23 | 0.75 GY/D-BU | 1113 | Left Front Damping Servo Control |
| 24 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 24 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
| 25 | 0.5 WH | 1100 | Left Front Wheel Damping Accelerometer Signal | 25 | 0.5 WH | 1100 | Left Front Wheel Damping Accelerometer Signal |
| 26 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | 26 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 27 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference | 27 | 0.5 BK/BN | 1099 | Left Front Wheel Damping Accelerometer Low Reference |
| 28 | 0.5 WH/VT | 3259 | Left Front Accelerometer Signal | 28 | 0.5 WH/VT | 3259 | Left Front Accelerometer Signal |
| 29 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference | 29 | 0.5 YE/RD | 1817 | Left Front Wheel Accelerometer Voltage Reference |
| 30-40 | | | Not Used | 30-40 | | | Not Used |
X151 Forward Lamp Harness to Body Harness (F45)
Scheme 238
Scheme 238: X160 Engine Harness to Fuel Rail Harness
Scheme 239
| Connector Part Information Harness Type: Engine OEM Connector: 13595088 (LEA) OEM Connector: 33472-1216 (LHU) Service Connector: Pending (LEA) Service Connector: 19150019 (LHU) Description: 12-Way F MX150 Series, Sealed (BK) | Connector Part Information Harness Type: Fuel Rail OEM Connector: 33482-1206 Service Connector: Service by Harness - See Part Catalog Description: 12-Way M MX150 Series Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: J-38125-217 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 33012-3002/26 Core/Insulation Crimp: E/2 | Terminal Part Information Terminated Lead: Service by Connector Assembly - 33482-1206 Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Connector Assembly - 33482-1206 Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BN | 4801 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 | 1 | 0.8 BN | 4801 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 |
| 2 | 0.5 D-BU | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 (LEA) | 2 | 0.8 D-BU | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 |
| 0.5 BU | 4802 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 2 (LHU) |
| 3 | 0.5 L-GN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 (LEA) | 3 | 0.8 D-GN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 |
| 0.5 GN | 4803 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 3 (LHU) |
| 4 | 0.5 GY/D-BU | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 (LEA) | 4 | 0.8 L-BU | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 |
| 0.5 BU | 4804 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 4 (LHU) |
| 5 | 0.5 BK/D-BU | 808 | Sensor Low Reference (LEA) | 5 | 0.5 TN | 808 | Sensor Low Reference |
| 0.5 WH | 808 | Sensor Low Reference (LHU) |
| 6 | | | Not Available | 6 | | | Not Available |
| 7 | 0.5 BN/WH | 4901 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 | 7 | 0.8 BN/WH | 4901 | Direct Fuel Injector (DFI) High Voltage Control Cylinder 1 |
| 8 | 0.5 D-BU/GY | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 (LEA) | 8 | 0.8 D-BU/WH | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 |
| 0.5 BU/WH | 4902 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 2 (LHU) |
| 9 | 0.5 L-GN/GY | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 (LEA) | 9 | 0.8 D-GN/WH | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 |
| 0.5 GN/WH | 4903 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 3 (LHU) |
| 10 | 0.5 D-BU/WH | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 (LEA) | 10 | 0.8 L-BU/WH | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 |
| 0.5-BU/WH | 4904 | Direct Fuel Injector (DFI) High Voltage Supply Cylinder 4 (LHU) |
| 11 | 0.5 GY/RD | 598 | 5-Volt Reference (LEA) | 11 | 0.5 GY | 598 | 5-Volt Reference |
| 0.5 GY | 598 | 5-Volt Reference (LHU) |
| 12 | 0.5 D-BU/WH | 2918 | Fuel Rail Pressure Sensor Signal (LEA) | 12 | 0.5 YE | 2918 | Fuel Rail Pressure Sensor Signal |
| 0.5 YE | 2918 | Fuel Rail Pressure Sensor Signal (LHU) |
X160 Engine Harness to Fuel Rail Harness
X190 Forward Lamp Harness to Fuel Composition Sensor Harness (FHS)
| Connector Part Information Harness Type: Forward Lamp OEM Connector: 13519047 Service Connector: Pending Description: 3-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Fuel Composition Sensor OEM Connector: 13122327 Service Connector: 88952839 Description: 4-Way M 2.8 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness- See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness- See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 PK/BK | 5294 | Powertrain Main Relay Fused Supply (5) | A | 0.5 PK/BK | 5294 | Powertrain Main Relay Fused Supply (5) |
| B | 0.5 BK/WH | 1350 | Ground | B | 0.5 BK/WH | 1350 | Ground |
| C | 0.5 WH | 1579 | Fuel Temperature/ Composition Signal | C | 0.5 WH | 1579 | Fuel Temperature/ Composition Signal |
X190 Forward Lamp Harness to Fuel Composition Sensor Harness (FHS)
X205 Instrument Panel Harness to Passenger Instrument Panel Air Bag Harness
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 19153434 Service Connector: 19178096 Description: 5-Way F 0.64 Series (YE) | Connector Part Information Harness Type: Passenger Instrument Panel Air Bag OEM Connector: 19153435 Service Connector: Service by Harness - See Part Catalog Description: 5-Way M 0.64 Series Unsealed (YE) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 19178096 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Service by Connector Assembly - 19178096 Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-65B (L-BU) Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 YE/OG | 3025 | Passenger IP Module Stage 1 High Control | 1 | 0.5 YE | | Passenger IP Module Stage 1 High Control |
| 2 | 0.5 OG/WH | 3024 | Passenger IP Module Stage 1 Low Control | 2 | 0.5 OG | | Passenger IP Module Stage 1 Low Control |
| 3 | 0.5 BK | 2450 | Ground | 3 | 0.5 BN | | Ground |
| 4 | 0.5 GY/OG | 3027 | Passenger IP Module Stage 2 High Control | 4 | 0.5 GY | | Passenger IP Module Stage 2 High Control |
| 5 | 0.5 OG/VT | 3026 | Passenger IP Module Stage 2 Low Control | 5 | 0.5 PU | | Passenger IP Module Stage 2 Low Control |
X205 Instrument Panel Harness to Passenger Instrument Panel Air Bag Harness
Scheme 240
Scheme 240: X210 Instrument Panel Harness to Body Harness
Scheme 241
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 24414905 Service Connector: 13574784 Description: 102-Way F 1.5, 2.5, 9.5 Series (BK) | Connector Part Information Harness Type: Body OEM Connector: 13315893 Service Connector: 13574781 Description: LOCKING COMB GN |
|---|
| Terminal Part Information Pins: 1-12, 14-22, 26, 27, 31, 32, 34-44, 47-52, 54, 56-65, 67-70, 73-75, 78-81, 83, 88 Terminated Lead: 13327144 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Pins: 66, 76, 77, 84-87, 89, 90 Terminated Lead: Service by Harness - See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 91, 95, 101 Terminated Lead: 13327182 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 2-964284-1/25 Core/Insulation Crimp: E/A Pins: 92, 94, 98, 99 Terminated Lead: 13327183 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: 4/A | Terminal Part Information Pins: 1-16, 18-22, 24-26, 28, 32, 37, 38, 40, 43, 47, 48, 50-52, 54, 56-58, 61-65, 67-75, 78-81, 83, 88 Terminated Lead: 13327150 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 1-7, 9-11, 13-16, 18, 19, 21, 24-26, 28, 32, 37, 38, 40, 47, 48, 50-52, 54, 58, 61-65, 67-75, 78-81, 88: E/2 Core/Insulation Crimp: Pins: 8, 17, 20, 22, 43, 83: E/C Core/Insulation Crimp: Pins: 12, 56, 57: C/A Pins: 31, 39, 44, 66, 76, 77, 84-87 Terminated Lead: 13327174 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: E/2 Pins: 49, 59, 60 Terminated Lead: 13579964 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: Not Stocked in Kit/le Core/Insulation Crimp: 2/C Pins: 92, 94, 98, 99 Terminated Lead: 13327152 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: Not Stocked in Kit/le Core/Insulation Crimp: Pin: 92: C/A Core/Insulation Crimp: Pins: 94, 98, 99: C/4 Pins: 91, 95, 101 Terminated Lead: 13327151 Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK/D-BU | 1271 | Low Reference | 1 | 0.5 BK/D-BU | 1271 | Low Reference |
| 2 | 0.5 WH/RD | 1164 | 5 Volt Reference | 2 | 0.5 WH/RD | 1164 | 5 Volt Reference |
| 3 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) | 3 | 0.5 YE/WH | 1161 | Accelerator Pedal Position Signal (1) |
| 4 | 0.5 BK/VT | 1272 | Low Reference | 4 | 0.5 BK/VT | 1272 | Low Reference |
| 5 | 0.5 BN/RD | 1274 | 5 Volt Reference | 5 | 0.5 BN/RD | 1274 | 5 Volt Reference |
| 6 | 0.5 L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) | 6 | 0.5 L-GN/WH | 1162 | Accelerator Pedal Position Signal (2) |
| 7 | 0.5 L-GN/BN | 2087 | Combined Vehicle Inertial Sensor Supply Voltage | 7 | 0.5 L-GN/BN | 2087 | Combined Vehicle Inertial Sensor Supply Voltage |
| 8 | 0.75 WH/D-BU | 3266 | Child Security Lock Motor Unlock Control | 8 | 0.75 WH/D-BU | 3266 | Child Security Lock Motor Unlock Control |
| 9 | 0.5 GY/L-GN | 328 | Interior Lamp Defeat Switch Signal | 9 | 0.5 GY/L-GN | 328 | Interior Lamp Defeat Switch Signal |
| 10 | 0.5 VT/YE | 3267 | Child Security Lock Relay Control | 10 | 0.5 VT/YE | 3267 | Child Security Lock Relay Control |
| 11 | 0.5 GY | 5127 | After Boil Heater Relay Control | 11 | 0.5 GY | 5127 | After Boil Heater Relay Control |
| 12 | 0.5 WH/BN | 6815 | Inadvertent Power Control | 12 | 0.5 WH/BN | 6815 | Inadvertent Power Control |
| 13 | 0.5 D-GN/BK | 3558 | Passive Start Switch Signal 2 | 13 | 0.5 D-GN/BK | 3558 | Passive Start Switch Signal 2 |
| 14 | 0.5 WH/VT | 5905 | Key Capture/Column Lock Shift Position Signal | 14 | 0.5 WH/VT | 5905 | Key Capture/Column Lock Shift Position Signal |
| 15 | 0.5 D-BU/GY | 636 | Outside Ambient Air Temperature Sensor Signal | 15 | 0.5 D-BU/GY | 636 | Outside Ambient Air Temperature Sensor Signal |
| 16 | 0.5 BK/ D-BU | 61 | Outside Ambient Temperature Sensor Low Reference | 16 | 0.5 BK/D-BU | 61 | Outside Ambient Temperature Sensor Low Reference |
| 17 | 0.75 GY | 295 | Door Lock Actuator Lock Control | 17 | 0.75 GY | 295 | Door Lock Actuator Lock Control |
| 18 | 0.5 VT | 185 | Low Washer Fluid Indicator Control | 18 | 0.5 VT | 185 | Low Washer Fluid Indicator Control |
| 19 | 0.5 BN/VT | 193 | Rear Defog Relay Control | 19 | 0.5 BN/VT | 193 | Rear Defog Relay Control |
| 20 | 0.75 VT/BK | 3 | Run/Crank Ignition 1 Voltage | 20 | 0.75 VT/BK | 3 | Run/Crank Ignition 1 Voltage |
| 21 | 0.5 VT/YE | 4 | Accessory Voltage | 21 | 0.5 VT/YE | 4 | Accessory Voltage |
| 22 | 0.75 RD/VT | 542 | Battery Positive Voltage | 22 | 0.75 RD/VT | 542 | Battery Positive Voltage |
| 23 | | | Not Used | 23 | | | Not Used |
| 24 | 0.5 D-BU | 3554 | Passive Start Interior Antenna 2 Signal Hi | 24 | 0.5 D-BU | 3554 | Passive Start Interior Antenna 2 Signal Hi |
| 25 | 0.5 GN/WH | 3555 | Passive Start Interior Antenna 2 Signal Lo | 25 | 0.5 GN/WH | 3555 | Passive Start Interior Antenna 2 Signal Lo |
| 26 | 0.5 BN/VT | 5486 | Run Relay Coil Control | 26 | 0.5 BN/VT | 5486 | Run Relay Coil Control |
| 27 | | | Not Used | 27 | | | Not Used |
| 28 | 0.5 BK/GY | 3559 | Passive Start Switch 2 Low Reference | 28 | 0.5 BK/GY | 3559 | Passive Start Switch 2 Low Reference |
| 29 | | | Not Used | 29 | | | Not Used |
| 30 | | | Not Used | 30 | | | Not Used |
| 31 | 0.5 WH/RD | 5381 | Brake Position Sensor 5 Volt Reference | 31 | 0.5 WH/RD | 5381 | Brake Position Sensor 5 Volt Reference |
| 32 | 0.5 GY | 1903 | AAS Wheel Speed Sensor Signal Left Front (UYS) | 32 | 0.5 GY | 1903 | AAS Wheel Speed Sensor Signal Left Front (UYS) |
| 33 | | | Not Used | 33 | | | Not Used |
| 34 | 0.5 BK/GY | 6110 | Low Reference (MR6) | 34 | 0.5 GY/RD | 6110 | Low Reference (MR6) |
| 35 | 0.5 GY/RD | 6109 | Clutch Apply Sensor Voltage Reference (MR6) | 35 | 0.5 BK/GY | 6109 | Clutch Apply Sensor Voltage Reference (MR6) |
| 36 | 0.5 YE | 6111 | Clutch Apply Sensor Signal (MR6) | 36 | 0.5 YE | 6111 | Clutch Apply Sensor Signal (MR6) |
| 37 | 0.5 VT/BK | 2939 | Run/Crank Ignition 1 Voltage | 37 | 0.5 VT/BK | 2939 | Run/Crank Ignition 1 Voltage |
| 38 | 0.5 VT/WH | 1139 | Run/Crank Ignition 1 Voltage | 38 | 0.5 VT/WH | 1139 | Run/Crank Ignition 1 Voltage |
| 39 | 0.35 WH | 5380 | Brake Position Sensor Signal | 39 | 0.35 WH | 5380 | Brake Position Sensor Signal |
| 40 | 0.5 RD/GY | 402 | Battery Positive Voltage | 40 | 0.5 RD/GY | 402 | Battery Positive Voltage |
| 41 | 0.5 BK | 9382 | Sport Mode Indicator Control (URC) | 41 | 0.5 BK | 9382 | Sport Mode Indicator Control (URC) |
| 42 | 0.5 BK/WH | 9381 | Tour Mode Indicator Control (URC) | 42 | 0.5 BK/WH | 9381 | Tour Mode Indicator Control (URC) |
| 43 | 0.75 RD/GY | 2340 | Battery Positive Voltage (UD7) | 43 | 0.75 RD/GY | 2340 | Battery Positive Voltage (UD7) |
| 44 | 0.5 BK/BN | 5382 | Brake Position Sensor Low Reference | 44 | 0.5 BK/BN | 5382 | Brake Position Sensor Low Reference |
| 45 | | | Not Used | 45 | | | Not Used |
| 46 | | | Not Used | 46 | 1 BN/BU | 118 | Not Used |
| 47 | 0.5 L-GN/WH | 2514 | Keypad Signal | 47 | 0.5 L-GN/WH | 2514 | Keypad Signal |
| 48 | 0.5 GY/WH | 3272 | Remote Function Actuator Supply Voltage | 48 | 0.5 GY/WH | 3272 | Remote Function Actuator Supply Voltage |
| 49 | 0.5 D-BU/WH | 3275 | Remote Function Actuator Receive Signal | 49 | 0.5 D-BU/WH | 3275 | Remote Function Actuator Receive Signal |
| 50 | 0.5 YE/RD | 7683 | Park Brake Release Switch Voltage Reference | 50 | 0.5 YE/RD | 7683 | Park Brake Release Switch Voltage Reference |
| 51 | 0.5 D-GN/BK | 2515 | Keypad Supply Voltage | 51 | 0.5 D-GN/BK | 2515 | Keypad Supply Voltage |
| 52 | 0.5 YE/VT | 2516 | Keypad Green LED | 52 | 0.5 YE/VT | 2516 | Keypad Green LED |
| 53 | | | Not Used | 53 | | | Not Used |
| 54 | 0.5 YE | 1492 | Park Brake Switch Supply Voltage | 54 | 0.5 YE | 1492 | Park Brake Switch Supply Voltage |
| 55 | | | Not Used | 55 | | | Not Used |
| 56 | 1 L-GN | 199 | Left Rear Speaker (+) (U65) | 56 | 1 D-GN | 199 | Left Rear Speaker (+) (U65) |
| 57 | 1 L-GN/BK | 116 | Left Rear Speaker Signal (-) (U65) | 57 | 1 D-GN/BK | 116 | Left Rear Speaker Signal (-) (U65) |
| 0.5 BN | 1999 | Left Rear Low Level Audio (-) (UQA) | 0.35 BN | 1999 | Left Rear Low Level Audio (-) (UQA) |
| 58 | 0.5 BN/WH | 2517 | Keypad Red LED | 58 | 0.5 BN/WH | 2517 | Keypad Red LED |
| 59 | 0.5 YE/L-GN | 3274 | Remote Function Actuator Transmit Signal | 59 | 0.5 YE/D-GN | 3274 | Remote Function Actuator Transmit Signal |
| 60 | 0.5 GY | 3273 | Remote Function Actuator Return | 60 | 0.5 GY | 3273 | Remote Function Actuator Return |
| 61 | 0.5 BN/YE | 780 | Driver Door Lock Switch Lock Signal | 61 | 0.5 BN/YE | 780 | Driver Door Lock Switch Lock Signal |
| 62 | 0.5 BN/WH | 781 | Driver Door Lock Switch Unlock Signal | 62 | 0.5 BN/WH | 781 | Driver Door Lock Switch Unlock Signal |
| 63 | 0.5 L-GN/GY | 6135 | Linear Interconnect Network Bus 4 | 63 | 0.5 L-GN/GY | 6135 | Linear Interconnect Network Bus 4 |
| 64 | 0.5 L-GN/D-BU | 6133 | Linear Interconnect Network Bus 2 (MDK or MH8) | 64 | 0.5 L-GN/D-BU | 6133 | Linear Interconnect Network Bus 2 (MDK or MH8) |
| 65 | 0.5 D-BU/YE | 7574 | Electric Variable Displacement Control | 65 | 0.5 D-BU/YE | 7574 | Electric Variable Displacement Control |
| 66 | 0.35 GY/ D-BU | 7564 | Humidity Sensor Signal | 66 | 0.35 GY/ D-BU | 7564 | Humidity Sensor Signal |
| 67 | 0.5 D-BU/BN | 7573 | Electric Variable Displacement Supply | 67 | 0.5 D-BU/BN | 7573 | Electric Variable Displacement Supply |
| 68 | 0.5 D-BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) | 68 | 0.5 BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) |
| 69 | 0.5 WH | 6106 | High Speed GMLAN Serial Data (-) (2) | 69 | 0.5 WH | 6106 | High Speed GMLAN Serial Data (-) (2) |
| 70 | 0.5 D-BU/VT | 1134 | Park Brake Switch Signal | 70 | 0.5 D-BU/VT | 1134 | Park Brake Switch Signal |
| 71 | 0.5 WH | 3553 | Passive Start Interior Antenna 1 Signal Lo | 71 | 0.5 WH | 3553 | Passive Start Interior Antenna 1 Signal Lo |
| 72 | 0.5 BN/BK | 3552 | Passive Start Interior Antenna 1 Signal Hi | 72 | 0.5 BN/BK | 3552 | Passive Start Interior Antenna 1 Signal Hi |
| 73 | 0.5 BN/WH | 419 | Check Engine Indicator Control | 73 | 0.5 BN/WH | 419 | Check Engine Indicator Control |
| 74 | 0.5 VT/BK | 7553 | Park Lock Solenoid Control (MDK or MH8) | 74 | 0.5 VT/BK | 7553 | Park Lock Solenoid Control (MDK or MH8) |
| 75 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 | 75 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 |
| 76 | 0.35 YE/D-BU | 3197 | Humidity Temperature Sensor Signal | 76 | 0.35 YE/D-BU | 3197 | Humidity Temperature Sensor Signal |
| 77 | 0.35 GY/ D-GN | 7565 | Windscreen Temp Sensor Signal | 77 | 0.35 GY/ D-GN | 7565 | Windscreen Temp Sensor Signal |
| 78 | 0.5 GY/L-GN | 2555 | Rear Park Assist Disable Signal (UD7) | 78 | 0.5 GY/D-GN | 2555 | Rear Park Assist Disable Signal (UD7) |
| 79 | 0.5 L-GN/BN | 5852 | Rear Park Assist LED Disable Signal (UD7) | 79 | 0.5 D-GN/BN | 5852 | Rear Park Assist LED Disable Signal (UD7) |
| 80 | 0.5 GY/RD | 7684 | Park Brake Apply Switch Voltage Reference | 80 | 0.5 GY/RD | 7684 | Park Brake Apply Switch Voltage Reference |
| 81 | 0.5 BN | 6107 | Park Brake Apply Switch Signal | 81 | 0.5 BN | 6107 | Park Brake Apply Switch Signal |
| 82 | | | Not Used | 82 | | | Not Used |
| 83 | 0.75 GY/L-GN | 3271 | Door Lock Control (2) | 83 | 0.75 GY/D-GN | 3271 | Door Lock Control (2) |
| 84 | 0.35 YE/RD | 597 | 5 Volt Reference | 84 | 0.35 YE/RD | 597 | 5 Volt Reference |
| 85 | 0.35 BK/D-BU | 7566 | Low Reference | 85 | 0.35 BK/D-BU | 7566 | Low Reference |
| 86 | 0.35 D-BU | 655 | Cellular Telephone Microphone Signal | 86 | 0.35 D-BU | 655 | Cellular Telephone Microphone Signal |
| 87 | 0.35 BARE* | 654 | Low Reference | 87 | 0.35 BARE* | 654 | Low Reference |
| 88 | 0.5 D-BU/BK | 6108 | Park Brake Release Switch Signal | 88 | 0.5 D-BU/BK | 6108 | Park Brake Release Switch Signal |
| 89 | 10 RD/BK | 5140 | Battery Positive Voltage | 89 | 10 RD/BK | 5140 | Battery Positive Voltage |
| 90 | 10 RD/D-BU | 5140 | Battery Positive Voltage | 90 | 10 RD/ BU | 5140 | Battery Positive Voltage |
| 91 | 0.5 GY | 157 | Interior Lamp Control | 91 | 0.75 GY | 157 | Interior Lamp Control |
| 92 | 1.5 GY/VT | 691 | Headlamp Low Beam Relay Control | 92 | 1.50 GY/VT | 691 | Headlamp Low Beam Relay Control |
| 93 | | | Not Used | 93 | | | Not Used |
| 94 | 2.5 RD/D-BU | 1340 | Battery Positive Voltage (KI6) | 94 | 2.5 RD/D-BU | 1340 | Battery Positive Voltage (KI6) |
| 95 | 0.5 GY/VY | 755 | RAP Relay Coil Control | 95 | 0.5 GY/VY | 755 | RAP Relay Coil Control |
| 96-97 | | | Not Used | 96-97 | | | Not Used |
| 98 | 2.5 RD/D-BU | 702 | Battery Positive Voltage | 98 | 2.5 RD/D-BU | 702 | Battery Positive Voltage |
| 99 | 2.5 RD/VT | 740 | Battery Positive Voltage | 99 | 2.5 RD/VT | 740 | Battery Positive Voltage |
| 100 | | | Not Used | 100 | | | Not Used |
| 101 | 0.5 RD/VT | 340 | Flash To Pass Relay Control | 101 | 0.5 RD/VT | 340 | Flash To Pass Relay Control |
| 102 | | | Not Used | 102 | | | Not Used |
| BARE wires may have an insulation material at the point the wire enters the connector cavity that protects adjacent wires from potential short circuits. These insulators may extend into the harness bundle and the bare wire may not be noticeably visible. |
X210 Instrument Panel Harness to Body Harness
X220 Instrument Panel Harness to Body Harness (UQA)
| Connector Part Information Harness Type: Instrument Panel OEM Connector: 24414905 Service Connector: 13574784 Description: 102-Way F 1.5, 2.5, 9.5 Series (BK) | Connector Part Information Harness Type: Body OEM Connector: 13315893 Service Connector: 13574781 Description: 102-Way M 1.5, 2.5, 9.5 Series (BK) |
|---|
| Terminal Part Information Pins: 15-18, 26-29, 32, 33, 37-40, 43, 44, 48, 49, 51, 54, 55, 59, 62 Terminated Lead: 13327144 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Pins: 99, 102 Terminated Lead: Service by Harness - See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available Pins: 100, 101 Terminated Lead: 13327183 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: C/A | Terminal Part Information Pins: 15-18, 26-29, 32, 33, 37-40, 43, 44, 48, 49, 51, 59, 62 Terminated Lead: Pins: 15, 26-29, 37-40: 13327174 Terminated Lead: Pins: 16-18, 32, 33, 43, 44, 48, 49, 51, 59, 62: 13327150 Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 15, 16, 26-29, 32, 33, 37-40, 43, 44, 48, 49, 59: E/2 Core/Insulation Crimp: Pins: 17, 18, 51, 62: C/A Pins: 99-102 Terminated Lead: 13327151 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: Not Stocked in Kit Core/Insulation Crimp: C/A |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1-14 | | | Not Used | 1-14 | | | Not Used |
| 15 | 0.5 L-GN/YE | 7066 | Entertainment Remote Enable Signal (without UDY) | 15 | 0.35 D-GN/YE | 7066 | Entertainment Remote Enable Signal (without UDY) |
| 0.75 L-GN/YE | 7066 | Entertainment Remote Enable Signal (with UDY) | 0.35 D-GN/YE | 7066 | Entertainment Remote Enable Signal (with UDY) |
| 16 | 0.5 VT/D-BU | 6978 | Amplifier Control | 16 | 0.5 VT/D-BU | 6978 | Amplifier Control |
| 17 | 1 D-BU/YE | 1960 | Front Center Speaker (-) | 17 | 1 D-BU/YE | 1960 | Front Center Speaker (-) |
| 18 | 1 YE/WH | 1860 | Front Center Speaker (+) | 18 | 1 YE/WH | 1860 | Front Center Speaker (+) |
| 19-25 | | | Not Used | 19-25 | | | Not Used |
| 26 | 0.5 BK/D-BU | 1946 | Right Rear Low Level Audio (-) | 26 | 0.35 BK/D-BU | 1946 | Right Rear Low Level Audio (-) |
| 27 | 0.5 BN/WH | 546 | Right Rear Low Level Audio Signal | 27 | 0.35 BN/WH | 546 | Right Rear Low Level Audio Signal |
| 28 | 0.5 BN/D-BU | 1947 | Left Front Low Level Audio (-) | 28 | 0.35 BN/D-BU | 1947 | Left Front Low Level Audio (-) |
| 29 | 0.5 D-BU | 511 | Front Center Speaker (+) | 29 | 0.35 D-BU | 511 | Front Center Speaker (+) |
| 30-31 | | | Not Used | 30-31 | | | Not Used |
| 32 | 0.5 WH | 3553 | Passive Start Interior Antenna 1 Signal Lo | 32 | 0.5 WH | 3553 | Passive Start Interior Antenna 1 Signal Lo |
| 33 | 0.5 BN/BK | 3552 | Passive Start Interior Antenna 1 Signal Hi | 33 | 0.5 BN/BK | 3552 | Passive Start Interior Antenna 1 Signal Hi |
| 34-36 | | | Not Used | 34-36 | | | Not Used |
| 37 | 0.5 BK/L-GN | 599 | Left Rear Low Level Audio Signal | 37 | 0.35 BK/D-GN | 599 | Left Rear Low Level Audio Signal |
| 38 | 0.5 BN/VT | 1999 | Left Rear Low Level Audio (-) | 38 | 0.5 BN/VT | 1999 | Left Rear Low Level Audio (-) |
| 39 | 0.5 D-BU/BN | 1546 | Front Low Level Audio (-) | 39 | 0.35 D-BU/BN | 1546 | Front Low Level Audio (-) |
| 40 | 0.5 YE | 512 | Right Front Low Level Audio Signal | 40 | 0.5 YE | 512 | Right Front Low Level Audio Signal |
| 41-42 | | | Not Used | 41-42 | | | Not Used |
| 43 | 0.5 D-BU | 3554 | Passive Start Interior Antenna 2 Signal Hi | 43 | 0.5 D-BU | 3554 | Passive Start Interior Antenna 2 Signal Hi |
| 44 | 0.5 GY/BK | 3555 | Passive Start Interior Antenna 2 Signal Lo | 44 | 0.5 GY/BK | 3555 | Passive Start Interior Antenna 2 Signal Lo |
| 45-47 | | | Not Used | 45-47 | | | Not Used |
| 48 | 0.5 D-BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) | 48 | 0.5 D-BU/YE | 6105 | High Speed GMLAN Serial Data (+) (2) |
| 49 | 0.5 WH/D-BU | 5986 | Serial Data Communication Enable | 49 | 0.5 WH/D-BU | 5986 | Serial Data Communication Enable |
| 50 | | | Not Used | 50 | | | Not Used |
| 51 | 1 D-BU/BK | 115 | Right Rear Speaker Signal (-) | 51 | D-BU/BK | 115 | Right Rear Speaker Signal (-) |
| 52-53 | | | Not Used | 52-53 | | | Not Used |
| 54 | 0.5 BK/GY | 3559 | Passive Start Switch 2 Low Reference | 54 | 0.5 BK/GY | 3559 | Passive Start Switch 2 Low Reference |
| 55 | 0.5 L-GN/BK | 3558 | Passive Start Switch Signal 2 | 55 | 0.5 L-GN/BK | 3558 | Passive Start Switch Signal 2 |
| 56-58 | | | Not Used | 56-58 | | | Not Used |
| 59 | 0.5 WH | 6106 | High Speed GMLAN Serial Data (-) (2) | 59 | 0.5 WH | 6106 | High Speed GMLAN Serial Data (-) (2) |
| 60-61 | | | Not Used | 60-61 | | | Not Used |
| 62 | 1 WH | 46 | Hazard Indicator Supply Voltage | 62 | 1 WH | 46 | Hazard Indicator Supply Voltage |
| 63-98 | | | Not Used | 63-98 | | | Not Used |
| 99 | 1 D-BU | 201 | Left Front Speaker (+) (1) | 99 | 1 D-BU | 201 | Left Front Speaker (+) (1) |
| 100 | 1 BN/D-BU | 118 | Left Front Speaker Signal (-) (1) | 100 | 1 BN/D-BU | 118 | Left Front Speaker Signal (-) (1) |
| 1 BN/D-BU | 118 | Left Front Speaker Signal (-) (1) |
| 101 | 1 YE | 200 | Right Front Speaker (+) (1) | 101 | 1 YE | 200 | Right Front Speaker (+) (1) |
| 1 YE | 200 | Right Front Speaker (+) (1) |
| 102 | 1 YE/BK | 117 | Right Front Speaker Signal (-) (1) | 102 | 1 YE/BK | 117 | Right Front Speaker Signal (-) (1) |
X220 Instrument Panel Harness to Body Harness (UQA)
Scheme 242
Scheme 242: X300 Floor Console Harness to Instrument Panel Harness
| Connector Part Information Harness Type:Floor Console OEM Connector: 13254941 Service Connector: Service by Harness - See Part Catalog Description: 52-Way F (BK) | Connector Part Information Harness Type: Instrument Panel OEM Connector: 13262033 Service Connector: 13578578 Description: 52-Way M 0.64/2.8 Series (BK) |
|---|
| Terminal Part Information Pins: 4-6, 22, 24-31, 43-47 Terminated Lead: Pending Release Tool: 12094429 Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: Pins: 4-6, 22, 24-31: J/J Core/Insulation Crimp: Pins: 43-47 : H/H Pins: 17, 18, 51, 52 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: Pending | Terminal Part Information Pins: 17, 18, 51, 52 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 2-964296-1/31 Core/Insulation Crimp: Pending Pins: 22, 24-31, 43-47 Terminated Lead: Pending Release Tool: 12094429 Diagnostic Test Probe: J-35616-65B (L-BU) Terminal/Tray: 963716-2/7 Core/Insulation Crimp: Pins: 22, 24-31: J/J Core/Insulation Crimp: Pins: 43-47: H/H |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1-3 | | | Not Used | 1-3 | | | Not Used |
| 4 | 0.75 RD/GN | 3140 | Battery Positive Voltage (KRJ) | 4 | 0.75 RD/GN | 3140 | Battery Positive Voltage (KRJ) |
| 5 | 0.75 BK | 1750 | Ground (KRJ) | 5 | 0.75 BK | 1750 | Ground (KRJ) |
| 6 | 0.75 GY | 937 | Linear Interconnect Network Bus (KRJ) | 6 | 0.75 GY | 937 | Linear Interconnect Network Bus (KRJ) |
| 7-16 | | | Not Used | 7-16 | | | Not Used |
| 17 | 2.5 BK | 2150 | Ground | 17 | 2.5 BK | 1950 | Ground |
| 18 | 2.5 VT | 2101 | Retained Accessory Power Fuse Supply Voltage | 18 | 2.5 VT | 2101 | Retained Accessory Power Fuse Supply Voltage |
| 19-21 | | | Not Used | 19-21 | | | Not Used |
| 22 | 0.5 GY/VT | 755 | RAP Relay Coil Control (KI6) | 22 | 0.5 GY/VT | 755 | RAP Relay Coil Control (KI6) |
| 23 | | | Not Used | 23 | | | Not Used |
| 24 | 0.5 BK | 1650 | Ground | 24 | 0.5 BK | 1850 | Ground |
| 25 | 0.5 YE | 1492 | Park Brake Switch Supply Voltage | 25 | 0.5 YE | 1492 | Park Brake Switch Supply Voltage |
| 26 | 0.5 YE/RD | 7683 | Park Brake Release Switch Voltage Reference | 26 | 0.5 YE/RD | 7683 | Park Brake Release Switch Voltage Reference |
| 27 | 0.5 BU/BK | 6108 | Park Brake Release Switch Signal | 27 | 0.5 BU/BK | 6108 | Park Brake Release Switch Signal |
| 28 | 0.5 BN | 6107 | Park Brake Apply Switch Signal | 28 | 0.5 BN | 6107 | Park Brake Apply Switch Signal |
| 29 | 0.5 GY/RD | 7684 | Park Brake Apply Switch Voltage Reference | 29 | 0.5 GY/RD | 7684 | Park Brake Apply Switch Voltage Reference |
| 30 | 0.5 BU/VT | 1134 | Park Brake Switch Signal | 30 | 0.5 BU/VT | 1134 | Park Brake Switch Signal |
| 31 | 0.5 YE | 6817 | LED Backlight Dimming Control | 31 | 0.5 YE | 6817 | LED Backlight Dimming Control |
| 32-42 | | | Not Used | 32-42 | | | Not Used |
| 43 | 0.35 BU | 2060 | Auxiliary Detection Signal | 43 | 0.35 BU | 2060 | Auxiliary Detection Signal |
| 44 | 0.35 GY | 5839 | Left Auxiliary Audio Signal (2) | 44 | 0.35 GY | 5839 | Left Auxiliary Audio Signal (2) |
| 45 | 0.35 GN | 5841 | Right Auxiliary Audio Signal (2) | 45 | 0.35 GN | 5841 | Right Auxiliary Audio Signal (2) |
| 46 | 0.35 VT | 5843 | Auxiliary Audio Common Signal | 46 | 0.35 VT | 5843 | Auxiliary Audio Common Signal |
| 47 | 0.35 BARE* | 5842 | Auxiliary Audio Screen (2) | 47 | 0.35 BARE* | 5842 | Auxiliary Audio Screen (2) |
| 48-50 | | | Not Used | 48-50 | | | Not Used |
| 51 | 2.5 BK | 1950 | Ground (KI6) | 51 | 2.5 BK | 1950 | Ground (KI6) |
| 52 | 2.5 RD/WH | 1340 | Battery Positive Voltage (KI6) | 52 | 2.5 RD/WH | 1340 | Battery Positive Voltage (KI6) |
| BARE wires may have an insulation material at the point the wire enters the connector cavity that protects adjacent wires from potential short circuits. These insulators may extend into the harness bundle and the bare wire may not be noticeably visible. |
X300 Floor Console Harness to Instrument Panel Harness
Scheme 243
Scheme 243: X310 Body Harness to Driver Seat Harness
Scheme 244
| Connector Part Information Harness Type: Body OEM Connector: 13257303 Service Connector: 13576546 Description: 48-Way F 1.5/2.8/6.3 Timer Series (BK) | Connector Part Information Harness Type: Driver Seat OEM Connector: 13257304 Service Connector: Service by Harness - See Part Catalog Description: 48-Way M 1.5/2.8/6.3 Timer Series (BK) |
|---|
| Terminal Part Information Pins: 1, 48 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 2, 47 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: Pending Pins: 20, 22, 24, 26 Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending Pins: 25, 34, 36-40, 43 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 2.5 RD/BN | 702 | Battery Positive Voltage | 1 | 2.5 RD/GN | 240 | Battery Positive Voltage |
| 2 | 2.5 RD/WH | 2040 | Battery Positive Voltage | 2 | 2.5 RD/WH | 140 | Battery Positive Voltage |
| 3-19 | | | Not Used | 3-19 | | | Not Used |
| 20 | 0.5 GN/OG | 3069 | Driver Side Impact Module Low Control | 20 | 0.5 BU | 2138 | Left Front Side Impact Module Low Control |
| 21 | | | Not Used | 21 | | | Not Used |
| 22 | 0.5 OG/BU | 3068 | Driver Side Impact Module High Control | 22 | 0.5 OG/BU | 2137 | Left Front Side Impact Module High Control |
| 23 | | | Not Used | 23 | | | Not Used |
| 24 | 0.5 YE/OG | 3482 | Driver Seat Belt Anchor Pretensioner Low Control | 24 | 0.5 OG/BK | 3482 | Driver Seat Belt Anchor Pretensioner Low Control |
| 25 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data | 25 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data |
| 26 | 0.5 OG/YE | 3481 | Driver Seat Belt Anchor Pretensioner High Control | 26 | 0.5 OG/YE | 3481 | Driver Seat Belt Anchor Pretensioner High Control |
| 27 | | | Not Used | 27 | GN | 5060 | Low Speed GMLAN Serial Data |
| 28-33 | | | Not Used | 28-33 | | | Not Used |
| 34 | 0.5 WH/GY | 2434 | Passenger Heated Seat NTC Signal | 34 | 0.5 WH/GY | 2434 | Passenger Heated Seat NTC Signal |
| 35 | | | Not Used | 35 | | | Not Used |
| 36 | 0.5 OG/BN | 238 | Driver Seat Belt Switch Signal | 36 | 0.5 BN/WH | 238 | Driver Seat Belt Switch Signal |
| 37 | 0.5 BK/GY | 2435 | Low Reference | 37 | 0.5 BK/GY | 2435 | Low Reference |
| 38 | 1 RD/VT | 1640 | Battery Positive Voltage | 38 | 1 RD/WH | 340 | Battery Positive Voltage |
| 39 | 0.5 BK/OG | 1363 | Low Reference | 39 | 0.5 BK/VT | 1363 | Low Reference |
| 40 | 1 BN/BU | 2479 | Passenger Heated Seat Element Supply Voltage | 40 | 1 BN/BU | 2479 | Passenger Heated Seat Element Supply Voltage |
| 41-42 | | | Not Used | 41-42 | | | Not Used |
| 43 | 1 BU/BK | 2433 | Passenger Heated Back Element Return | 43 | 1 BK/BU | 2433 | Passenger Heated Back Element Return |
| 44-46 | | | Not Used | 44-46 | | | Not Used |
| 47 | 2.5 BK | 2150 | Ground | 47 | 2.5 BK | 150 | Ground |
| 48 | 2.5 BK | 2150 | Ground | 48 | 2.5 BK | 250 | Ground |
X310 Body Harness to Driver Seat Harness
X320 Body Harness to Passenger Seat Harness
| Connector Part Information Harness Type: Body OEM Connector: 13257303 Service Connector: 13576546 Description: 48-Way F 1.5/2.8/6.3 Timer Series (BK) | Connector Part Information Harness Type: Passenger Seat OEM Connector: 13257304 Service Connector: Service by Harness - See Part Catalog Description: 48-Way M 1.5/2.8/6.3 Timer Series (BK) |
|---|
| Terminal Part Information Pins: 1, 48 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 4, 7, 13, 34, 35, 36, 37, 38, 40, 43, 39 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964274-2/16 Core/Insulation Crimp: E/1 Pins: 20, 22, 24, 26 Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending Pins: 47 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-965999-1/25 Core/Insulation Crimp: Pending | Terminal Part Information Terminated Lead: Pending Release Tool: - Diagnostic Test Probe: - Terminal/Tray: - Core/Insulation Crimp |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 2.5 RD/YE | 740 | Battery Positive Voltage | 1 | 2.5 RD/GN | 240 | Battery Positive Voltage (AG2) |
| 1.5 RD/GN | 240 | Battery Positive Voltage (A6C) |
| 2-3 | | | Not Used | 2-3 | | | Not Used |
| 4 | 0.5 RD/GY | 402 | Battery Positive Voltage | 4 | 0.5 RD/GN | 1040 | Battery Positive Voltage |
| 5-6 | | | Not Used | 5-6 | | | Not Used |
| 7 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data | 7 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data |
| 8-9 | | | Not Used | 8-9 | | | Not Used |
| 10 | | | Not Used | 10 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data |
| 11-12 | | | Not Used | 11-12 | | | Not Used |
| 13 | 0.5 BK | 2450 | Ground | 13 | 0.5 BK | 1050 | Ground |
| 14-19 | | | Not Used | 14-19 | | | Not Used |
| 20 | 0.5 BN/OG | 3067 | Passenger Side Impact Module Low Control | 20 | 0.5 YE | 2136 | Right Front Side Impact Module Low Control |
| 21 | | | Not Used | 21 | | | Not Used |
| 22 | 0.5 OG/GY | 3066 | Passenger Side Impact Module High Control | 22 | 0.5 OG/YE | 2135 | Right Front Side Impact Module High Control |
| 23 | | | Not Used | 23 | | | Not Used |
| 24 | 0.5 GY/OG | 3480 | Passenger Seat Belt Anchor Pretensioner Low Control | 24 | 0.5 GY/BK | 3480 | Passenger Seat Belt Anchor Pretensioner Low Control |
| 25 | | | Not Used | 25 | | | Not Used |
| 26 | 0.5 OG/BN | 3479 | Passenger Seat Belt Anchor Pretensioner High Control | 26 | 0.5 OG/BN | 3479 | Passenger Seat Belt Anchor Pretensioner High Control |
| 27-33 | | | Not Used | 27-33 | | | Not Used |
| 34 | 0.5 WH/GY | 2434 | Passenger Heated Seat NTC Signal | 34 | 0.5 WH/GY | 2434 | Passenger Heated Seat NTC Signal |
| 35 | 0.5 OG/BU | 5056 | Passenger Seat Position Switch Signal | 35 | 0.5 OG/D-BU | 5056 | Passenger Seat Position Switch Signal |
| 36 | 0.5 OG/VT | 1362 | Passenger Seat Belt Switch Signal | 36 | 0.5 BU | 1362 | Passenger Seat Belt Switch Signal |
| 37 | 0.5 BK/GY | 2435 | Low Reference | 37 | 0.5 BK/GY | 2435 | Low Reference |
| 38 | 1 RD/VT | 1640 | Battery Positive Voltage (APH) | 38 | 1 RD/WH | 340 | Battery Positive Voltage (APH) |
| 39 | 0.5 BK/OG | 1361 | Low Reference | 39 | 0.5 BK/BU | 1361 | Low Reference |
| 40 | 1 BN/BU | 2479 | Passenger Heated Seat Element Supply Voltage | 40 | 1 BN/BU | 2479 | Passenger Heated Seat Element Supply Voltage |
| 41-42 | | | Not Used | 41-42 | | | Not Used |
| 43 | 1 BK/BU | 2433 | Passenger Heated Back Element Return | 43 | 1 BK/BU | 2433 | Passenger Heated Back Element Return |
| 44-46 | | | Not Used | 44-46 | | | Not Used |
| 47 | 2.5 BK | 2150 | Ground (APH) | 47 | 2.5 BK | 150 | Ground (APH) |
| 48 | 2.5 BK | 2150 | Ground | 48 | 2.5 BK | 250 | Ground (AG2) |
| 1.5 BK | 250 | Ground (A6C) |
X320 Body Harness to Front Passenger Seat Harness
X330 Body Harness to Body Harness
| Connector Part Information Harness Type: Body OEM Connector: 19153434 Service Connector: 19178096 Description: 5-Way F 0.64 Series (YE) | Connector Part Information Harness Type:Body OEM Connector: 19153435 Service Connector: Service by Harness - See Part Catalog Description: 5-Way M 0.64 Series (YE) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 19178096 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BN/OG | 3477 | Driver Seat Belt Retractor Pretensioner High Control | 1 | 0.5 BN/OG | 3477 | Driver Seat Belt Retractor Pretensioner High Control |
| 2 | 0.5 BK/OG | 3478 | Driver Seat Belt Retractor Pretensioner Low Control | 2 | 0.5 BK/OG | 3478 | Driver Seat Belt Retractor Pretensioner Low Control |
| 3 | 0.5 OG/GN | 5019 | Left Front Head Curtain Module High Control | 3 | 0.5 OG/GN | 5019 | Left Front Head Curtain Module High Control |
| 4 | 0.5 GN | 5020 | Left Front Head Curtain Module Low Control | 4 | 0.5 GN | 5020 | Left Front Head Curtain Module Low Control |
| 5 | | | Not Used | 5 | | | Not Used |
X330 Body Harness to Body Harness
X340 Body Harness to Body Harness
| Connector Part Information Harness Type: Body OEM Connector: 19153434 Service Connector: 19178096 Description: 5-Way F 0.64 Series (YE) | Connector Part Information Harness Type: Body OEM Connector: 19153435 Service Connector: Service by Component Assembly Description: 5-Way M 0.64 Series (YE) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 19178096 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Not Available Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Harness - See Part Catalog Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 OG/GY | 3475 | Passenger Seat Belt Retractor Pretensioner High Control | 1 | 0.5 OG/GY | 3475 | Passenger Seat Belt Retractor Pretensioner High Control |
| 2 | 0.5 BU | 3476 | Passenger Seat Belt Retractor Pretensioner Low Control | 2 | 0.5 BU | 3476 | Passenger Seat Belt Retractor Pretensioner Low Control |
| 3 | 0.5 OG/GY | 5021 | Right Front Head Curtain Module High Control | 3 | 0.5 OG/GY | 5021 | Right Front Head Curtain Module High Control |
| 4 | 0.5 GY | 5022 | Right Front Head Curtain Module Low Control | 4 | 0.5 GY | 5022 | Right Front Head Curtain Module Low Control |
| 5 | | | Not Used | 5 | | | Not Used |
X340 Body Harness to Body Harness
Scheme 245
Scheme 245: X350 Fuel Tank Harness to Body Harness
| Connector Part Information Harness Type: Fuel Tank OEM Connector: 15326084 Service Connector: 15306348 Description: 16-Way F GT 150 280 Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 15326085 Service Connector: 19181245 Description: 16-Way M GT 150 280 Sealed (BK) |
|---|
| Terminal Part Information Pins: A (NU6), S (NU6) Terminated Lead: 13575392 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304720/19 Core/Insulation Crimp: 4/5 Pins: B, D-F, K-L, R Terminated Lead: 13578895 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Pin: H Terminated Lead: Service by Harness - See Part Catalog Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-4A (PU) Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5 Pins: M (NU6), N Terminated Lead: 13579741 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 | Terminal Part Information Pins: A, S Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304732/8 Core/Insulation Crimp: A/5 Pins: B, D-G, K-N, R Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: Pins: G, K-N : E/1 Core/Insulation Crimp: Pins: B, D-F, R : E/4 Pin: H Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 15304731/19 Core/Insulation Crimp: C/5 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 2.5 GY | 120 | Fuel Pump Supply Voltage (without NU6) | A | 2.5 GY | 120 | Fuel Pump Supply Voltage |
| 2 GY | | Fuel Pump Supply Voltage (NU6) |
| B | 0.5 BU/VT | 1589 | Primary Fuel Level Sensor Signal (without NU6) | B | 0.5 BU/VT | 1589 | Primary Fuel Level Sensor Signal |
| 0.5 BU/VT | | Primary Fuel Level Sensor Signal (NU6) |
| C | | | Not Used | C | | | Not Used |
| D | 0.5 BN/RD | 2709 | 5 Volt Reference (without NU6) | D | 0.5 YE/RD | 2709 | 5 Volt Reference |
| 0.5 BN/RD | | 5 Volt Reference (NU6) |
| E | 0.5 BU/WH | 890 | Fuel Tank Pressure Sensor Signal (without NU6) | E | 0.5 BU/WH | 890 | Fuel Tank Pressure Sensor Signal |
| 0.5 BU/WH | | Fuel Tank Pressure Sensor Signal (NU6) |
| F | 0.5 BK/WH | 6281 | Low Reference (without NU6) | F | 0.5 BK/GN | 6281 | Low Reference |
| 0.5 BK/WH | | Low Reference (NU6) |
| G | | | Not Used | G | | | Not Used |
| H | 0.5 BN/RD | 7445 | 5 Volt Reference (without NU6) | H | 0.75 BN/RD | 7445 | 5 Volt Reference |
| 0.5 BN/RD | | 5 Volt Reference (NU6) |
| J | | | Not Used | J | | | Not Used |
| K | 0.5 BU/BN | 7446 | Fuel Line Pressure Sensor Signal (without NU6) | K | 0.75 BU/WH | 7446 | Fuel Line Pressure Sensor Signal |
| 0.5 BU/BN | | Fuel Line Pressure Sensor Signal (NU6) |
| L | 0.5 BK/YE | 7447 | Low Reference (without NU6) | L | 0.75 BK/YE | 7447 | Low Reference |
| 0.5 BK/YE | | Low Reference (NU6) |
| M | 0.75 RD/BU | A40 | Canister Valve Solenoid (without NU6) | M | 0.75 BU | 5372 | Canister Valve Solenoid |
| 0.8 RD/BU | | Canister Valve Solenoid (NU6) |
| N | 1 WH | 1310 | EVAP Canister Vent Solenoid Control (without NU6) | N | 0.75 WH | 1310 | EVAP Canister Vent Solenoid Control |
| 1 WH | | EVAP Canister Vent Solenoid Control (NU6) |
| P | | | Not Used | P | | | Not Used |
| R | 0.5 BK/GN | 6281 | Low Reference (without NU6) | R | 0.5 BK/GN | 6281 | Low Reference |
| 0.5 BK/GN | | Low Reference (NU6) |
| S | 2.5 BK/GN | 1580 | Low Reference (without NU6) | S | 2.5 BK/GN | 1580 | Low Reference |
| 2 BK/GN | | Low Reference (NU6) |
X350 Fuel Tank Harness to Body Harness
X370 Body Harness to Seat Air Bag - Left Rear Harness (AW7)
| Connector Part Information Harness Type: Body OEM Connector: 19153434 Service Connector: 19178096 Description: 5-Way F 0.64 Series (YE) | Connector Part Information Harness Type: Side Air Bag - Left Rear OEM Connector: Pending Service Connector: Service by Component Assembly Description: 5-Way M 0.64 Series (YE) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 19178096 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Service by Connector Assembly - 19178096 Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 OG/BK | 5223 | Left Rear Side Impact SIR Inflator Supply Voltage | 1 | WH | | Left Rear Side Impact SIR Inflator Supply Voltage |
| 2 | 0.5 BN/OG | 5224 | Left Rear Side Impact SIR Inflator Control | 2 | OG | | Left Rear Side Impact SIR Inflator Control |
| 3 | 0.5 BK | 2450 | Ground | 3 | BN | | Ground |
| 4-5 | | | Not Used | 4-5 | | | Not Used |
X370 Body Harness to Seat Air Bag - Left Rear Harness (AW7)
X380 Body Harness to Seat Air Bag - Right Rear Harness (AW7)
| Connector Part Information Harness Type: Body OEM Connector: 19153434 Service Connector: 19178096 Description: 5-Way F 0.64 Series (YE) | Connector Part Information Harness Type: Seat Air Bag - Right Rear OEM Connector: Pending Service Connector: Service by Component Assembly Description: 5-Way M 0.64 Series (YE) |
|---|
| Terminal Part Information Terminated Lead: Service by Connector Assembly - 19178096 Release Tool: J-38125-215A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: Service by Connector Assembly - 19178096 Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 VT/OG | 5225 | Right Rear Side Impact SIR Inflator Supply Voltage | 1 | WH | | Right Rear Side Impact SIR Inflator Supply Voltage |
| 2 | 0.5 OG/GY | 5226 | Right Rear Side Impact SIR Inflator Control | 2 | OG | | Right Rear Side Impact SIR Inflator Control |
| 3 | 0.5 BK | 2450 | Ground | 3 | BN | | Ground |
| 4-5 | | | Not Used | 4-5 | | | Not Used |
X380 Body Harness to Seat Air Bag - Right Rear Harness (AW7)
Scheme 246
Scheme 246: X400 Headliner Harness to Body Harness
| Connector Part Information Harness Type: Headliner OEM Connector: 24444119 Service Connector: 13578579 Description: 18-Way F 0.64 Micro Quadlok Series (BK) | Connector Part Information Harness Type: Body OEM Connector: 24444120 Service Connector: 13578580 Description: 18-Way M 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Pending Core/Insulation Crimp: Pending | Terminal Part Information Terminated Lead: Pending Release Tool: 12094429 Diagnostic Test Probe: J-35616-65B (L-BU) Terminal/Tray: 963716-2/7 Core/Insulation Crimp: Pins: 1-6, 11-16: J/J Core/Insulation Crimp: Pins: 7, 8: H/H |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 GY | 157 | Interior Lamp Control | 1 | 0.5 GY | 157 | Interior Lamp Control |
| 2 | 0.75 WH/BN | 6815 | Inadvertent Power Control | 2 | 0.75 WH/BN | 6815 | Inadvertent Power Control |
| 3 | 0.75 BK | 1550 | Ground | 3 | 0.75 BK | 1550 | Ground |
| 4 | 0.5 GY/GN | 328 | Interior Lamp Defeat Switch Signal | 4 | 0.5 GY/GN | 328 | Interior Lamp Defeat Switch Signal |
| 5 | 0.5 GY | 156 | Courtesy Lamp Switch Signal | 5 | 0.5 GY | 156 | Courtesy Lamp Switch Signal |
| 6 | 0.75 YE | 6817 | LED Backlight Dimming Control | 6 | 0.75 YE | 6817 | LED Backlight Dimming Control |
| 7 | 0.5 BARE* | 654 | Low Reference | 7 | 0.35 BARE* | 654 | Low Reference |
| 8 | 0.5 BU | 655 | Cellular Telephone Microphone Signal | 8 | 0.35 BU | 655 | Cellular Telephone Microphone Signal |
| 9 | | | Not Used | 9 | | | Not Used |
| 10 | 0.5 BK/GY | 128 | Low Reference | 10 | 0.5 BK/GY | 128 | Low Reference (CF5) |
| 11 | 0.5 D-BU/VT | 5027 | Sunroof Switch Data (1) | 11 | 0.5 BU/VT | 5027 | Sunroof Switch Data (1) (CF5) |
| 12 | 0.5 WH/GN | 3031 | Sunroof Vent Switch Signal (CF5) | 12 | 0.5 WH/GN | 3031 | Sunroof Vent Switch Signal (CF5) |
| 13-18 | | | Not Used | 13-18 | | | Not Used |
| BARE wires may have an insulation material at the point the wire enters the connector cavity that protects adjacent wires from potential short circuits. These insulators may extend into the harness bundle and the bare wire may not be noticeably visible. |
X400 Headliner Harness to Body Harness
X410 Body Harness to Tail Lamp Assembly - Left Harness
| Connector Part Information Harness Type: Body OEM Connector: 19115421 Service Connector: 88988944 Description: 6-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Tail Lamp Assembly - Left OEM Connector: 15326833 Service Connector: 15326833 Description: 6-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: A-D Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins: A, C- D: E/1 Core/Insulation Crimp: Pins: B: 2/1 Pins: F Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: C/1 | Terminal Part Information Terminated Lead: Service by Connector Assembly - 15326833 Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Service by Connector Assembly - 15326833 Core/Insulation Crimp: Service by Harness |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 VT/GY | 709 | Left Park Lamp Supply Voltage | A | 0.75 BK | 709 | Left Park Lamp Supply Voltage |
| B | 0.75 BU/WH | 1334 | Left Rear Turn Signal and Stop Lamp Supply Voltage | B | 0.75 BK | 1334 | Left Rear Turn Signal and Stop Lamp Supply Voltage |
| C | | | Not Used | C | | | Not Used |
| D | 0.5 GN/WH | 24 | Backup Lamp Supply Voltage | D | 0.75 BK | 24 | Backup Lamp Supply Voltage |
| E | | | Not Used | E | | | Not Used |
| F | 1.50 BK | 2550 | Ground | F | 0.75 BK | 50 | Ground |
X410 Body Harness to Tail Lamp Assembly - Left Harness
Scheme 247
Scheme 247: X415 Rear Bumper Harness to Body Harness (UD5 or UD7 without HP6)
| Connector Part Information Harness Type: Rear Bumper OEM Connector: 15471110 Service Connector: Service by Harness - See Part Catalog Description: 16-Way F 2.8 DSQ 1.5 Series, Sealed (GY) | Connector Part Information Harness Type: Body OEM Connector: 15471080 Service Connector: 13212499 Description: 16-Way M 1.5 2.8 Series, Sealed (GY) |
|---|
| Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Pins: 2-10 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 | Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 1-962915-3/15 Core/Insulation Crimp: E/1 Pins: 2, 4-7, 9, 10 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 969079-2/32 Core/Insulation Crimp: 2/C |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 YE/VT | 2378 | Right Rear Corner Object Sensor Signal | 1 | 0.5 YE/VT | 2378 | Right Rear Corner Object Sensor Signal |
| 2 | 0.5 YE/WH | 2377 | Right Rear Middle Object Sensor Signal | 2 | 0.5 YE/WH | 2377 | Right Rear Middle Object Sensor Signal |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.5 BN/WH | 2374 | Object Sensor Supply Voltage | 4 | 0.5 BN/WH | 2374 | Object Sensor Supply Voltage |
| 5 | 0.5 YE | 2375 | Left Rear Corner Object Sensor Signal | 5 | 0.5 YE | 2375 | Left Rear Corner Object Sensor Signal |
| 6 | 0.5 BK/GY | 2379 | Low Reference | 6 | 0.5 BK/GY | 2379 | Low Reference |
| 7 | 0.5 GN/YE | 6846 | Rear License Lamp Supply Voltage | 7 | 0.5 GN/YE | 6846 | Rear License Lamp Supply Voltage |
| 8 | | | Not Used | 8 | | | Not Used |
| 9 | 0.5 BK | 2550 | Ground | 9 | 0.5 BK | 2550 | Ground |
| 10 | 0.5 YE/BU | 2376 | Left Rear Middle Object Sensor Signal | 10 | 0.5 YE/BU | 2376 | Left Rear Middle Object Sensor Signal |
| 11-16 | | | Not Used | 11-16 | | | Not Used |
X415 Rear Bumper Harness to Body Harness (UD5 or UD7 without HP6)
X415 Rear Bumper Harness to Rear Body Harness (UD7 with HP6)
| Connector Part Information Harness Type: Rear Bumper OEM Connector: 15471110 Service Connector: Service by Harness - See Part Catalog Description: 16-Way F 2.8 DSQ 1.5 Series, Sealed (GY) | Connector Part Information Harness Type: Rear Body OEM Connector: 15471080 Service Connector: 13212499 Description: 16-Way M 1.5 2.8 Series, Sealed (GY) |
|---|
| Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Pins: 2-10 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 | Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-5 (PU) Terminal/Tray: 1-962915-3/15 Core/Insulation Crimp: E/1 Pins: 2, 4-7, 9, 10 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 969079-2/32 Core/Insulation Crimp: 2/C |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 YE/VT | 2378 | Right Rear Corner Object Sensor Signal | 1 | 0.5 YE/VT | 2378 | Right Rear Corner Object Sensor Signal |
| 2 | 0.5 YE/WH | 2377 | Right Rear Middle Object Sensor Signal | 2 | 0.5 YE/WH | 2377 | Right Rear Middle Object Sensor Signal |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.5 BN/WH | 2374 | Object Sensor Supply Voltage | 4 | 0.5 BN/WH | 2374 | Object Sensor Supply Voltage |
| 5 | 0.5 YE | 2375 | Left Rear Corner Object Sensor Signal | 5 | 0.5 YE | 2375 | Left Rear Corner Object Sensor Signal |
| 6 | 0.5 BK/GY | 2379 | Low Reference | 6 | 0.5 BK/GY | 2379 | Low Reference |
| 7 | 0.5 GN/YE | 6846 | Rear License Lamp Supply Voltage | 7 | 0.5 GN/YE | 6846 | Rear License Lamp Supply Voltage |
| 8 | | | Not Used | 8 | | | Not Used |
| 9 | 0.5 BK | 2550 | Ground | 9 | 0.5 BK | 2550 | Ground |
| 10 | 0.5 YE/BU | 2376 | Left Rear Middle Object Sensor Signal | 10 | 0.5 YE/BU | 2376 | Left Rear Middle Object Sensor Signal |
| 11-16 | | | Not Used | 11-16 | | | Not Used |
X415 Rear Bumper Harness to Rear Body Harness (UD7 with HP6)
X420 Body Harness to Tail Lamp Assembly - Right Harness
| Connector Part Information Harness Type: Body OEM Connector: 19115421 Service Connector: 88988944 Description: 6-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Tail Lamp Assembly - Right OEM Connector: 15326833 Service Connector: 15326833 Description: 6-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: A-D Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins: A, C- D: E/1 Core/Insulation Crimp: Pins: B: 2/1 Pins: F Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: C/1 | Terminal Part Information Terminated Lead: Service by Connector Assembly - 15326833 Release Tool: Pending Diagnostic Test Probe: Pending Terminal/Tray: Service by Connector Assembly - 15326833 Core/Insulation Crimp: Service by Harness |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY/BN | 309 | Right Park Lamp Supply Voltage | A | 0.75 BK | 309 | Right Park Lamp Supply Voltage |
| B | 0.75 BU/VT | 1335 | Right Rear Turn Signal and Stop Lamp Supply Voltage | B | 0.75 BK | 1335 | Right Rear Turn Signal and Stop Lamp Supply Voltage |
| C | | | Not Used | C | | | Not Used |
| D | 0.5 GN/WH | 24 | Backup Lamp Supply Voltage | D | 0.75 BK | 24 | Backup Lamp Supply Voltage |
| E | | | Not Used | E | | | Not Used |
| F | 1.50 BK | 2550 | Ground | F | 0.75 BK | 50 | Ground |
X420 Body Harness to Tail Lamp Assembly - Right Harness
X430 Suspension- Left Rear Harness to Body Harness (F45)
| Connector Part Information Harness Type: Suspension- Left Rear OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 15326806 Service Connector: 19151499 Description: 2-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 | Terminal Part Information Terminated Lead: 13327138 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/1 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.75 BU/GY | 1114 | Left Rear Damping Servo Supply Voltage | A | 0.75 BU/GY | 1114 | Left Rear Damping Servo Supply Voltage |
| B | 0.75 GN/VT | 1115 | Left Rear Damping Servo Control | B | 0.75 GN/VT | 1115 | Left Rear Damping Servo Control |
X430 Suspension- Left Rear Harness to Body Harness (F45)
X440 Suspension- Right Rear Harness to Body Harness (F45)
| Connector Part Information Harness Type: Suspension- Right Rear OEM Connector: 15326801 Service Connector: 19179278 Description: 2-Way F GT 150 Series, Sealed (BK) | Connector Part Information Harness Type: Body OEM Connector: 15326806 Service Connector: 19151499 Description: 2-Way M GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: 15315247 Diagnostic Test Probe: J-35616-2A (GY) Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 | Terminal Part Information Terminated Lead: 13327138 Release Tool: J-38125-553 Diagnostic Test Probe: J-35616-3 (GY) Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/1 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| A | 0.75 BU/GY | 1114 | Right Rear Damping Servo Supply Voltage | A | 0.75 BU/GY | 1118 | Right Rear Damping Servo Supply Voltage |
| B | 0.75 GN/VT | 1115 | Right Rear Damping Servo Control | B | 0.75 GN/GY | 1119 | Right Rear Damping Servo Control |
X440 Suspension- Right Rear Harness to Body Harness (F45)
X450 Body Harness to Rear Body Harness (HP6)
| Connector Part Information Harness Type: Body OEM Connector: 13579269 Service Connector: Pending Description: 52-Way F 2.8 DSQ 64 Series | Connector Part Information Harness Type: Rear Body OEM Connector: 13610684 Service Connector: Service by Harness - See Part Catalog Description: 52-Way M 2.8 DSQ 64 Series |
|---|
| Terminal Part Information Pins: 2 Terminated Lead: 13575784 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Pins: 5-6, 9, 13, 26, 38-40, 43-45 Terminated Lead: 13575782 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Pins: 51 Terminated Lead: 13327182 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 2-964284-1/25 Core/Insulation Crimp: E/A | Terminal Part Information Pins: 2 Terminated Lead: 13575784 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Pins: 5-6, 9, 13, 26, 38-40, 43-45 Terminated Lead: 13575782 Release Tool: J-38125-12A Diagnostic Test Probe: J-35616-64B (L-BU) Terminal/Tray: 928999-5/15 Core/Insulation Crimp: J/J Pins: 51 Terminated Lead: 13327182 Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-35 (VT) Terminal/Tray: 2-964284-1/25 Core/Insulation Crimp: E/A |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.75 D-BU/WH | 1334 | Left Rear Turn Signal Lamp Supply Voltage | 2 | 0.75 D-BU/WH | 1334 | Left Rear Turn Signal Lamp Supply Voltage |
| 3-4 | | | Not Used | 3-4 | | | Not Used |
| 5 | 0.5 BK | 2350 | Ground | 5 | 0.5 BK | 2350 | Ground |
| 6 | 0.5 BK | 2550 | Ground | 6 | 0.5 BK | 2550 | Ground |
| 7-12 | | | Not Used | 7-12 | | | Not Used |
| 13 | 0.5 GY/D-GN | 2555 | Rear Park Assist Disable Signal | 13 | 0.5 GY/D-GN | 2555 | Rear Park Assist Disable Signal |
| 14-25 | | | Not Used | 14-25 | | | Not Used |
| 26 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data | 26 | 0.5 GN | 5060 | Low Speed GMLAN Serial Data |
| 27-37 | | | Not Used | 27-37 | | | Not Used |
| 38 | 0.5 D-GN/GY | 3569 | Passive Entry Rear Closure Antenna Signal Lo | 38 | 0.5 D-GN/GY | 3569 | Passive Entry Rear Closure Antenna Signal Lo |
| 39 | 0.5 BN/D-GN | 3568 | Passive Entry Rear Closure Antenna Signal Hi | 39 | 0.5 BN/D-GN | 3568 | Passive Entry Rear Closure Antenna Signal Hi |
| 40 | 0.5 D-GN/BN | 5852 | Rear Park Assist LED Disable Signal | 40 | 0.5 D-GN/BN | 5852 | Rear Park Assist LED Disable Signal |
| 41-42 | | | Not Used | 41-42 | | | Not Used |
| 43 | 0.5 D-GN/YE | 6846 | Rear License Lamp Supply Voltage | 43 | 0.5 D-GN/YE | 6846 | Rear License Lamp Supply Voltage |
| 44 | 0.5 D-GN/YE | 6846 | Rear License Lamp Supply Voltage | 44 | 0.5 D-GN/YE | 6846 | Rear License Lamp Supply Voltage |
| 45-50 | | | Not Used | 45-50 | | | Not Used |
| 51 | 0.75 RD/YE | 2340 | Ground | 51 | 0.75 RD/YE | 2340 | Ground |
| 52 | | | Not Used | 52 | | | Not Used |
X450 Body Harness to Rear Body Harness (HP6)
Scheme 248
Scheme 248: X500 Driver Door Harness to Body Harness
Scheme 249
| Connector Part Information Harness Type: Driver Door OEM Connector: 13254913 Service Connector: Service by Harness - See Part Catalog Description: 41-Way F 4.8 Timer Series (GY) | Connector Part Information Harness Type: Body OEM Connector: 13254914 Service Connector: 13576548 Description: 41-Way M DSQ 1.5 2.8 Series (GY) |
|---|
| Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 964328-1/25 Core/Insulation Crimp: 4/B Pins: 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 3-18, 21, 22-28, 31-41 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 962943-5/16 Core/Insulation Crimp: Pins: 3-18, 21, 22-25, 26-28, 31-41: E/A Core/Insulation Crimp: Pins: 26 : Pending | Terminal Part Information Pins: 1, 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: NA Terminal/Tray: 964308-1/ NA Core/Insulation Crimp: Pending Pins: 3-6, 10, 11, 16-18, 23, 24, 26, 35, 36, 38 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 24, 35, 36: E/C Core/Insulation Crimp: Pins: 10, 11 : C/A Core/Insulation Crimp: Pins: 3-6, 16-18, 23, 26, 38: E/2 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 4 BK | 1550 | Ground | 1 | 4 BK | 1550 | Ground |
| 2 | 2.5 RD/GN | 1540 | Battery Positive Voltage | 2 | 2.5 RD/GN | 1540 | Battery Positive Voltage |
| 3 | 0.5 GY | 157 | Interior Lamp Control | 3 | 0.5 GY | 157 | Interior Lamp Control |
| 4 | 0.5 YE/VT | 3397 | Co-Driver Mirror Motor Up (+) Down (-) Control | 4 | 0.5 YE/VT | 3397 | Co-Driver Mirror Motor Up (+) Down (-) Control |
| 5 | | | Not Used | 5 | 0.5 YE/WH | 1690 | Automatic Day/Night Mirror Signal |
| 6 | | | Not Used | 6 | 0.5 BK/YE | 1691 | Low Reference |
| 7-9 | | | Not Used | 7-9 | | | Not Used |
| 10 | 1 BU | 201 | Left Front Speaker (+) (1) | 10 | 1 BU | 201 | Left Front Speaker (+) (1) |
| 11 | 1 BN/BU | 118 | Left Front Speaker Signal (-) (1) | 11 | 1 BN/BU | 118 | Left Front Speaker Signal (-) (1) |
| 12-15 | | | Not Used | 12-15 | | | Not Used |
| 16 | 0.5 GN/YE | 6134 | Linear Interconnect Network Bus 3 | 16 | 0.5 GN/YE | 6134 | Linear Interconnect Network Bus 3 |
| 17 | 0.5 WH | 3398 | Co-Driver Mirror Motor Common Control | 17 | 0.5 WH | 3398 | Co-Driver Mirror Motor Common Control |
| 18 | 0.5 GN/BK | 3396 | Co-Driver Mirror Motor Right (+) Left (-) Control | 18 | 0.5 GN/BK | 3396 | Co-Driver Mirror Motor Right (+) Left (-) Control |
| 19-22 | | | Not Used | 19-22 | | | Not Used |
| 23 | 0.5 RD/GY | 2840 | Battery Positive Voltage | 23 | 0.5 RD/GY | 2840 | Battery Positive Voltage |
| 24 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage | 24 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage |
| 25 | | | Not Used | 25 | | | Not Used |
| 26 | 0.5 YE | 6817 | LED Backlight Dimming Control | 26 | 0.5 YE | 6817 | LED Backlight Dimming Control |
| 27-34 | | | Not Used | 27-34 | | | Not Used |
| 35 | 0.75 GY | 5911 | Door Lock Actuator Lock Control 2 | 35 | 0.75 GY | 5911 | Door Lock Actuator Lock Control 2 |
| 36 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control | 36 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control |
| 37 | | | Not Used | 37 | | | Not Used |
| 38 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 | 38 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 |
| 39-41 | | | Not Used | 39-41 | | | Not Used |
X500 Driver Door Harness to Body Harness
X510 Driver Door Harness to Outside Rearview Mirror - Driver Harness
| Connector Part Information Harness Type: Driver Door OEM Connector: 24444119 Service Connector: Service by Harness - See Part Catalog Description: 18-Way F 0.64 Micro Quadlok Series (BK) | Connector Part Information Harness Type: Outside Rearview Mirror - Driver OEM Connector: 24444120 Service Connector: Service by Component Assembly Description: 18-Way M 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.5 VT/BU | 3390 | Driver Mirror Motor Up (+) Down (-) Control | 2 | GN/VT | | Outside Left Mirror Vertical Position Control |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.75 BK | 1550 | Ground | 4 | BK | | Ground |
| 5 | | | Not Used | 5 | | | Not Used |
| 6 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage | 6 | BK | | Mirror Heating Element Supply Voltage |
| 7 | 0.5 BN/BK | 3389 | Driver Mirror Motor Right (+) Left (-) Control | 7 | VT/WH | | Left Mirror Motor Right Control |
| 8 | 0.5 YE/BN | 3391 | Driver Mirror Motor Common Control | 8 | WH/BN | | Left Mirror Motor Supply Voltage |
| 9-18 | | | Not Used | 9-18 | | | Not Used |
X510 Driver Door Harness to Outside Rearview Mirror - Driver Harness
X600 Passenger Door Harness to Body Harness
| Connector Part Information Harness Type: Passenger Door OEM Connector: 13254913 Service Connector: Service by Harness - See Part Catalog Description: 41-Way F 4.8 Timer Series (GY) | Connector Part Information Harness Type: Body OEM Connector: 13254914 Service Connector: 13576548 Description: 41-Way M DSQ 1.5 2.8 Series (GY) |
|---|
| Terminal Part Information Pins: 1 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 964328-1/25 Core/Insulation Crimp: 4/B Pins: 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 3-18, 21-26, 28, 31-38, 40, 41 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 962943-5/16 Core/Insulation Crimp: Pins: 3-18, 21-25, 28, 31-38, 40, 41: E/A Core/Insulation Crimp: Pins: 26 : Pending | Terminal Part Information Pins: 1, 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: NA Terminal/Tray: 964308-1/ NA Core/Insulation Crimp: Pending Pins: 3, 4, 10, 11, 16-18, 24, 26, 35, 36, 38 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 24, 35, 36: E/C Core/Insulation Crimp: Pins: 10, 11 : C/A Core/Insulation Crimp: Pins: 3, 4, 16-18, 26, 38: E/2 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 4 BK | 2050 | Ground | 1 | 4 BK | 2050 | Ground |
| 2 | 2.5 RD/GN | 1540 | Battery Positive Voltage | 2 | 2.5 RD/GN | 1540 | Battery Positive Voltage |
| 3 | 0.5 GY | 157 | Interior Lamp Control | 3 | 0.5 GY | 157 | Interior Lamp Control |
| 4 | 0.5 YE/VT | 3397 | Co-Driver Mirror Motor Up (+) Down (-) Control | 4 | 0.5 YE/VT | 3397 | Co-Driver Mirror Motor Up (+) Down (-) Control |
| 5-9 | | | Not Used | 5-9 | | | Not Used |
| 10 | 1 YE | 200 | Right Front Speaker (+) (1) | 10 | 1 YE | 200 | Right Front Speaker (+) (1) |
| 11 | 1 YE/BK | 117 | Right Front Speaker Signal (-) (1) | 11 | 1 YE/BK | 117 | Right Front Speaker Signal (-) (1) |
| 12-15 | | | Not Used | 12-15 | | | Not Used |
| 16 | 0.5 GN/YE | 6134 | Linear Interconnect Network Bus 3 | 16 | 0.5 GN/YE | 6134 | Linear Interconnect Network Bus 3 |
| 17 | 0.5 WH | 3398 | Co-Driver Mirror Motor Common Control | 17 | 0.5 WH | 3398 | Co-Driver Mirror Motor Common Control |
| 18 | 0.5 GN/BK | 3396 | Co-Driver Mirror Motor Right (+) Left (-) Control | 18 | 0.5 GN/BK | 3396 | Co-Driver Mirror Motor Right (+) Left (-) Control |
| 19-23 | | | Not Used | 19-23 | | | Not Used |
| 24 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage | 24 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage |
| 25 | | | Not Used | 25 | | | Not Used |
| 26 | 0.35 YE | 6817 | LED Backlight Dimming Control | 26 | 0.35 YE | 6817 | LED Backlight Dimming Control |
| 27-34 | | | Not Used | 27-34 | | | Not Used |
| 35 | 0.75 GY | 295 | Door Lock Actuator Lock Control | 35 | 0.75 GY | 295 | Door Lock Actuator Lock Control |
| 36 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control | 36 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control |
| 37 | | | Not Used | 37 | | | Not Used |
| 38 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 | 38 | 0.5 WH/YE | 7557 | LED Ambient Lighting Control 1 |
| 39 | 0.5 OG/BK | 5996 | Driver Outside Rear View Mirror Puddle Lamp Supply Voltage | 39 | | | Not Used |
| 40-41 | | | Not Used | 40-41 | | | Not Used |
X600 Passenger Door Harness to Body Harness
X610 Passenger Door Harness to Outside Rearview Mirror - Passenger Harness
| Connector Part Information Harness Type: Passenger Door OEM Connector: 24444119 Service Connector: Service by Harness - See Part Catalog Description: 18-Way F 0.64 Micro Quadlok Series (BK) | Connector Part Information Harness Type: Outside Rearview Mirror - Passenger OEM Connector: 24444120 Service Connector: Service by Component Assembly Description: 18-Way M 0.64 Micro Quadlok Series (BK) |
|---|
| Terminal Part Information Terminated Lead: Pending Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available | Terminal Part Information Terminated Lead: Service by Component Assembly Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Not Available Core/Insulation Crimp: Not Available |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used | 1 | | | Not Used |
| 2 | 0.5 YE/VT | 3397 | Co-Driver Mirror Motor Up (+) Down (-) Control | 2 | GN/VT | | Outside Right Mirror Vertical Position Control |
| 3 | | | Not Used | 3 | | | Not Used |
| 4 | 0.75 BK | 2050 | Ground | 4 | BK | | Ground |
| 5 | | | Not Used | 5 | | | Not Used |
| 6 | 0.75 BN/YE | 2267 | Mirror Heating Element Supply Voltage | 6 | BK | | Mirror Heating Element Supply Voltage |
| 7 | 0.5 GN/BK | 3396 | Co-Driver Mirror Motor Right (+) Left (-) Control | 7 | VT/WH | | Right Mirror Motor Right Control |
| 8 | 0.5 WH | 3398 | Co-Driver Mirror Motor Common Control | 8 | WH/BN | | Right Mirror Motor Supply Voltage |
| 9-18 | | | Not Used | 9-18 | | | Not Used |
X610 Passenger Door Harness to Outside Rearview Mirror - Passenger Harness
Scheme 250
Scheme 250: X700 Left Rear Door Harness to Body Harness
| Connector Part Information Harness Type: Left Rear Door OEM Connector: 13254911 Service Connector: Service by Harness - See Part Catalog Description: 20-Way F 1.5 Series (GY) | Connector Part Information Harness Type: Body OEM Connector: 13254912 Service Connector: 13576560 Description: 20-Way M 5.8 TTS 1.5 Series (GY) |
|---|
| Terminal Part Information Pins: 1, 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 3, 8, 9, 14, 15 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 962943-5/16 Core/Insulation Crimp: Pins: 3, 5-16: E/A Core/Insulation Crimp: Pins: 4 : Pending | Terminal Part Information Pins: 1, 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: NA Terminal/Tray: 964308-1/ NA Core/Insulation Crimp: Pending Pins: 3, 8, 9, 14, 15 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 8, 9: E/C Core/Insulation Crimp: Pins: 14, 15 : C/A Core/Insulation Crimp: Pins: 3: E/2 |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 2.5 RD/BN | 2940 | Battery Positive Voltage | 1 | 2.5 RD/BN | 2940 | Battery Positive Voltage |
| 2 | 2.5 BK | 2350 | Ground | 2 | 4 BK | 2350 | Ground |
| 3 | | | Not Used | 3 | 0.5 GN/GY | 6135 | Linear Interconnect Network Bus 4 |
| 4-6 | | | Not Used | 4-6 | | | Not Used |
| 7 | 0.75 VT/YE | 3267 | Child Security Lock Relay Control | 7 | 0.75 WH/BU | 3266 | Child Security Lock Motor Unlock Control |
| 8 | 0.75 GY | 295 | Door Lock Actuator Lock Control | 8 | 0.75 GY | 295 | Door Lock Actuator Lock Control |
| 9 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control | 9 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control |
| 10-13 | | | Not Used | 10-13 | | | Not Used |
| 14 | 1 GN | 199 | Left Rear Speaker (+) | 14 | 1 GN | 199 | Left Rear Speaker (+) |
| 15 | 1 GN/BK | 116 | Left Rear Speaker Signal (-) | 15 | 1 BK/GN | 116 | Left Rear Speaker Signal (-) |
| 16 | 0.75 BN/WH | 3269 | Child Security Lock Motor Status Signal Left Rear | 16 | 0.5 BN/WH | 3269 | Child Security Lock Motor Status Signal Left Rear |
| 17-20 | | | Not Used | 17-20 | | | Not Used |
X700 Left Rear Door Harness to Body Harness
X800 Right Rear Door Harness to Body Harness
| Connector Part Information Harness Type: Right Rear Door OEM Connector: 13254911 Service Connector: Service by Harness - See Part Catalog Description: 20-Way F 1.5 Series (GY) | Connector Part Information Harness Type: Body OEM Connector: 13254912 Service Connector: 13576560 Description: 20-Way M 5.8 TTS 1.5 Series (GY) |
|---|
| Terminal Part Information Pins: 1, 9, 14, 15 Terminated Lead: Pending Release Tool: Not Available Diagnostic Test Probe: Pending Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Not Available Pins: 2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: J-35616-42 (RD) Terminal/Tray: 927837-1/25 Core/Insulation Crimp: A/D Pins: 3, 8 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 962943-5/16 Core/Insulation Crimp: Pins: 3, 5-8, 10-13, 16 : E/A Core/Insulation Crimp: Pins: 4 : Pending | Terminal Part Information Pins: 3, 8, 9, 14, 15 Terminated Lead: Pending Release Tool: J-38125-560 Diagnostic Test Probe: J-35616-14 (GN) Terminal/Tray: 964265-2/28 Core/Insulation Crimp: Pins: 8, 9 : E/C Core/Insulation Crimp: Pins: 14, 15 : C/A Core/Insulation Crimp: Pins: 3 : E/2 Terminated Lead: Pending Release Tool: J-38125-36 Diagnostic Test Probe: NA Terminal/Tray: 964308-1/ NA Core/Insulation Crimp: Pending |
| Pin | Wire | Circuit | Function | Pin | Wire | Circuit | Function |
|---|
| 1 | 2.5 RD/BN | 2940 | Battery Positive Voltage | 1 | 2.5 RD/BN | 2940 | Battery Positive Voltage |
| 2 | 2.5 BK | 2050 | Ground | 2 | 4 BK | 2050 | Ground |
| 3 | 0.5 GN/GY | 6135 | Linear Interconnect Network Bus 4 | 3 | 0.5 GN/GY | 6135 | Linear Interconnect Network Bus 4 |
| 4-6 | | | Not Used | 4-6 | | | Not Used |
| 7 | 0.75 VT/YE | 3267 | Child Security Lock Relay Control | 7 | 0.75 WH/BU | 3266 | Child Security Lock Motor Unlock Control |
| 8 | 0.75 GY | 295 | Door Lock Actuator Lock Control | 8 | 0.75 GY | 295 | Door Lock Actuator Lock Control |
| 9 | 1.50 BN/YE | 294 | Door Lock Actuator Unlock Control | 9 | 0.75 BN/YE | 294 | Door Lock Actuator Unlock Control |
| 10-13 | | | Not Usedl | 10-13 | | | Not Used |
| 14 | 1 WH | 46 | Right Rear Speaker (+) | 14 | 1 WH | 46 | Right Rear Speaker (+) |
| 15 | 1 BU/BK | 115 | Right Rear Speaker Signal (-) | 15 | 1 BU/BK | 115 | Right Rear Speaker Signal (-) |
| 16 | 0.5 GY/BK | 3268 | Child Security Lock Motor Status Signal Right Rear | 16 | 0.5 GY/BK | 3268 | Child Security Lock Motor Status Signal Right Rear |
| 17-20 | | | Not Used | 17-20 | | | Not Used |
X800 Right Rear Door Harness to Body Harness
