Fastener Tightening Specifications (Off Vehicle)
| Application | Ref No.* | Quantity | Size | Specification | |
|---|---|---|---|---|---|
| Metric | English | ||||
| A/Trans Auxiliary Fluid Pump Outlet Bolt (Hybrid Models) | 350 | 4 | 22 N.m | 16 lb ft | |
| A/Trans Auxiliary Fluid Pump Bolt (Hybrid Models) | 355 | 1 | 22 N.m | 16 lb ft | |
| A/Trans Auxiliary Fluid Pump (Pump to Motor) Bolt (Hybrid Models) | 370 | 4 | 10-12 N.m | 89-106 lb in | |
| A/Trans Fluid Pump Bolt to Converter Housing | |||||
| First Pass | 200 | 7 - 6T30, 8 - 6T40/45/50 | M8x33 | 10 N.m | 89 lb in |
| Final Pass | 200 | M8x33 | 45° | ||
| A/Trans Fluid Pump Cover Bolt | 302 | 3 - 6T30, 23 - 6T40/45/50 | M6x25 | 12 N.m | 106 lb in |
| A/Trans Fluid Pump Cover Bolt | 320 | 20 - 6T30 | M6x21.5 | 12 N.m | 106 lb in |
| Control Solenoid Valve Assembly (w/TCM and Body) to Case Bolt | 4 | 12 | M6x97 | 10 N.m | 89 lb in |
| Control Solenoid Valve Assembly (w/TCM and Body) to Case Bolt | 6 | 3 | M5x40.5 | 7 N.m | 62 lb in |
| Control Valve Body Assembly (Complete) Bolt | 400 | 1 | M5x40.5 | 7 N.m | 62 lb in |
| Control Valve Body to Case Bolt | 9 | 2 | M6x53 | 11 N.m | 97 lb in |
| Control Valve Body to Case Bolt | 10 | 9 | M6x60 | 11 N.m | 97 lb in |
| Control Valve Body Cover Bolt | 1 | 13 | M6x30 | 12 N.m | 106 lb in |
| Drain Plug | 64 | 1 | 1/8"-27 NPTF | 12 N.m | 106 lb in |
| Fluid Level Hole Plug | 63 | 1 | 1/8"-27 NPTF | 12 N.m | 106 lb in |
| Fluid Pressure Test Hole Plug | 51 | 1 | 1/8"-27 NPTF | 12 N.m | 106 lb in |
| Front Differential Carrier Baffle Bolt - Converter Housing | 204 | 2 | M6x25 | 12 N.m | 106 lb in |
| Front Differential Carrier Baffle Bolt - Case | 61 | 2 | M6x18.5 - 6T30, M6x16 - 6T40/45/50 | 12 N.m | 106 lb in |
| Input Shaft Support Bolt | 57 | 3 | M6x50 | 12 N.m | 106 lb in |
| Input Speed Sensor Bolt | 21 | 1 | M6x23 | 9 N.m | 80 lb in |
| Manual Shift Detent Spring | 17 | 1 | M6x16 | 12 N.m | 106 lb in |
| Output Speed Sensor Bolt | 15 | 1 | M6x18 | 9 N.m | 80 lb in |
| Torque Converter and Differential Housing Bolt | |||||
| First Pass | 27 | 14 - 6T30, 15 - 6T40/45/50 | M8x30 | 10 N.m | 89 lb in |
| Final Pass | 27 | M8x30 | 50° | ||
| *Reference number refers to the component callout number in Disassembled Views | |||||
Fastener Tightening Specifications (Off Vehicle)
Fastener Tightening Specifications (On Vehicle)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| A/Trans Control Bolt | 9 N.m | 80 lb in |
| A/Trans Flex Plate Bolt | 60 N.m | 45 lb ft |
| Rear Trans Brace Bolt - Inboard | 50 N.m | 37 lb ft |
| Rear Trans Brace Bolt - Outboard | 100 N.m | 74 lb ft |
| Torque Converter to Flywheel Bolt | 60 N.m | 45 lb ft |
| Transmission Bolt (1, 2, 3) - 6T40 | 75 N.m | 56 lb ft |
| Transmission Bolt (4, 5) - 6T40 | 50 N.m | 37 lb ft |
| Transmission Bolt (1, 2, 3, 4) - 6T45 | 75 N.m | 56 lb ft |
| Transmission Bolt (5) - 6T45 | 50 N.m | 37 lb ft |
| Transmission Fluid Cooler Outlet Pipe Nut | 22 N.m | 17 lb ft |
| Transmission Fluid Cooler Pipe Inlet Nut | 22 N.m | 17 lb ft |
| Transmission Front Mount Through Bolt | 100 N.m | 74 lb ft |
| Transmission Front Mount to Transmission Bolts | 62 N.m | 46 lb ft |
| Transmission Mount Bolt - Left Side to Frain Rail | 22 N.m | 16 lb ft |
| Transmission Mount Bolt - Left Side to Transmission | 50 N.m + 60-75° | 37 lb ft + 60-75° |
| Transmission Mount Nut - Left Side to Body | 22 N.m | 16 lb ft |
| Transmission Rear Mount Through Bolt | 105 N.m | 747 lb ft |
| Transmission Rear Mount to Cradle | 100 N.m+ 120-130° | 74 lb ft + 120-130° |
| Transmission Rear Mount to Transmission | 100 N.m | 74 lb ft |
| Transmission Range Selector Cable Bracket Bolt | 18 N.m | 14 lb ft |
| Transmission Range Selector Lever Nut | 20 N.m | 15 lb ft |
Fastener Tightening Specifications (On Vehicle)
Transmission General Specifications (6T40/6T45/6T50)
| Name | 6T40/6T45/6T50 |
|---|---|
| RPO Codes | MH8, MH7, MHK, MHH, MHC, MHJ |
| Production Location | Korea/China/Mexico/Toledo |
| Transmission Drive | Front Wheel Drive |
| Reverse Gear Ratio | 2.94 |
| 1st Gear Ratio | 4.584 |
| 2nd Gear Ratio | 2.964 |
| 3rd Gear Ratio | 1.912 |
| 4th Gear Ratio | 1.446 |
| 5th Gear Ratio | 1.000 |
| 6th Gear Ratio | 0.746 |
| Effective Final Drive Gear Ratio | 2.64/2.89/3.23/3.53/3.87 |
| Torque Converter Size- Diameter of Torque Converter Turbine | 236 mm |
| Pressure Taps Line | Pressure |
| Transmission Fluid Type | DEXRON VI® |
| Transmission Fluid Capacity | 8.0 L/8.5 Quarts |
| Transmission Type: 6 | Six Forward Gears |
| Transmission Type: T | Transverse Mount |
| Transmission Type: 40/45/50 | Product Series |
| Position Quadrant | P, R, N, D, * *(Refer to the applicable owner's manual) |
| Case Material | Die Cast Aluminum |
| Transmission Net Weight | 81/86 kg (178/190 lbs) |
| Maximum Trailer Towing Capacity | N/A |
| Maximum Gross Vehicle Weight (GVW) | 6T40 - 2000 kg (4, 409 lbs) 6T45 - 2200 kg (4, 850 lbs) 6T50 - 2500 kg (5, 511 lbs) |
Transmission General Specifications (6T40/6T45/6T50)
Adhesives, Fluids, Lubricants, and Sealers
| Application | Type of Material | GM Part Number | |
|---|---|---|---|
| United States | Canada | ||
| Torque Converter Bolts | Threadlock | 12345382 | 10953489 |
Adhesives, Fluids, Lubricants, and Sealers
Fluid Capacity Specifications (6T40/45/50)
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Valve Body Cover Removal - Approximate Capacity | 5.0-7.0 liters | 5.3-7.4 quarts |
| Fluid Change - Drain Plug - Approximate Capacity | 4.0-6.0 liters | 4.2- 6.3 quarts |
| Overhaul - Approximate Capacity | 8.0-8.5 liters | 8.5-9.0 quarts |
Fluid Capacity Specifications (6T40/45/50)
Fluid Pump Selective Specifications
| Fluid Pump Body Pocket Depth | Fluid Pump Gear Thickness | ||
|---|---|---|---|
| Metric | English | Metric | English |
| 12.617-12.625 mm | 0.4967-0.4970 in | 12.580-12.588 mm | 0.4952-0.4955 in |
| 12.626-12.636 mm | 0.4970-0.4974 in | 12.589-12.599 mm | 0.4956-0.4960 in |
| 12.637-12.645 mm | 0.4975-0.4978 in | 12.600-12.608 mm | 0.4960-0.4963 in |
Fluid Pump Selective Specifications
Clutch & Band Application
| Range | Park | Reverse | Neutral | Drive | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1st Braking | 1st | 2nd | 3rd | 4th | 5th | 6th | ||||
| 1-2-3-4 Clutch | Applied | Applied | Applied | Applied | Applied | |||||
| 3-5 Reverse Clutch | Applied | Applied | Applied | |||||||
| 4-5-6 Clutch | Applied | Applied | Applied | |||||||
| 2-6 Clutch | Applied | Applied | ||||||||
| Low and Reverse Clutch | Applied* | Applied | Applied* | Applied | ||||||
| Low Clutch Assembly (OWL) | Holding | Holding | ||||||||
| * = Applied with NO load | ||||||||||
Range Reference
Shift Solenoid Valve State and Gear Ratio
| Gear | Shift SOL 1 | 1-2-3-4 CL PC SOL 5 N.L. | 2-6 CL PC SOL 4 N.L. | 3-5 REV CL PC SOL 2 N.H. | LOW REV 4-5-6 CL PC SOL 3 N.H. | Gear Ratio |
|---|---|---|---|---|---|---|
| Park | ON | OFF | OFF | OFF | ON | |
| Reverse | ON | OFF | OFF | ON | ON | 2.940 |
| Neutral | ON | OFF | OFF | OFF | ON | |
| 1st Braking | ON | ON | OFF | OFF | ON | 4.584 |
| 1st | OFF | ON | OFF | OFF | OFF | 4.584 |
| 2nd | OFF | ON | ON | OFF | OFF | 2.964 |
| 3rd | OFF | ON | OFF | ON | OFF | 1.912 |
| 4th | OFF | ON | OFF | OFF | ON | 1.446 |
| 5th | OFF | OFF | OFF | ON | ON | 1.000 |
| 6th | OFF | OFF | ON | OFF | ON | 0.746 |
| Effective Final Drive Ratio - 6T40/45 - 3.17/3.87 For shift solenoid 1, "ON" = Solenoid Energized (Pressurized) "OFF" = Solenoid De-energized (No Pressure). For pressure control solenoids, "ON" = Pressurized, "OFF" = No Pressure | ||||||
Shift Solenoid Valve State and Gear Ratio
Transmission Fluid Pressure Switch Logic
| Gear | TFP Switch States | |||
|---|---|---|---|---|
| TFP SW1 | *TFP SW3 | TFP SW4 | TFP SW5 | |
| Park | Low | Low | Low | Low |
| Reverse | Low | Low | Low | Low |
| Neutral | Low | Low | Low | Low |
| Drive 1st - Engine Braking | Low | High | Low | Low |
| Drive 1st | High | High | Low | High |
| Drive 2nd | High | Low | Low | High |
| Drive 3rd | Low | High | Low | High |
| Drive 4th | High | High | Low | Low |
| Drive 5th | Low | High | High | Low |
| Drive 6th | High | Low | High | Low |
| High = 12V (Switch Open or Pressurized) Low = 0V (Switch Closed or No Pressure) Note: All TFP switches are normally closed (NC) *TFP switch 2 does not exist | ||||
Transmission Fluid Pressure Switch Logic
Transmission Internal Mode Switch Logic
| Gear Selector Position | Signal A | Signal B | Signal C | Signal P |
|---|---|---|---|---|
| Park | LOW | HI | HI | LOW |
| Park/Reverse | LOW | LOW | HI | LOW |
| Reverse | LOW | LOW | HI | HI |
| Reverse/Neutral | HI | LOW | HI | HI |
| Neutral | HI | LOW | HI | LOW |
| Neutral/Drive 6 | HI | LOW | LOW | LOW |
| Drive 6 | HI | LOW | LOW | HI |
| Drive 6/Drive 4 | LOW | LOW | LOW | HI |
| Drive 4 | LOW | LOW | LOW | LOW |
| Drive 4/Drive 3 | LOW | HI | LOW | LOW |
| Drive 3 | LOW | HI | LOW | HI |
| Drive 3/Drive 2 | HI | HI | LOW | HI |
| Drive 2 | HI | HI | LOW | LOW |
| Open | HI | HI | HI | HI |
| Invalid | HI | HI | HI | LOW |
| Invalid | LOW | HI | HI | HI |
| HI = Ignition voltage LOW = 0 volts | ||||
Transmission Internal Mode Switch Logic
Solenoid Valve Pressure (Gen 1)
| Requested Pressure (kPa) | Actual Pressure | |
|---|---|---|
| Metric | English | |
| None | 345-550 kPa | 50-80 psi |
| 200 | 690-900 kPa | 100-130 psi |
| 400 | 1100-1310 kPa | 160-190 psi |
| 600 | 1520-1725 kPa | 220-250 psi |
| 800 | 1860-2275 kPa | 270-330 psi |
| 1000 | 1860-2275 kPa | 270-330 psi |
| 1200 | 1860-2275 kPa | 270-330 psi |
| 1400 | 1860-2275 kPa | 270-330 psi |
| 1600 | 1860-2275 kPa | 270-330 psi |
| 1800 | 1860-2275 kPa | 270-330 psi |
| 2000 | 1860-2275 kPa | 270-330 psi |
Line PC Solenoid Valve Pressure
Solenoid Valve Pressure (Gen 2)
| Requested Pressure (kPa) | Actual Pressure | |
|---|---|---|
| Metric | English | |
| None | 172-379 kPa | 25-55 psi |
| 200 | 662-869 kPa | 96-126 psi |
| 400 | 1145-1351 kPa | 166-196 psi |
| 600 | 1634-1841 kPa | 237-267 psi |
| 800 | 2117-2324 kPa | 307-337 psi |
| 1000 | 2117-2324 kPa | 307-337 psi |
| 1200 | 2117-2324 kPa | 307-337 psi |
| 1400 | 2117-2324 kPa | 307-337 psi |
| 1600 | 2117-2324 kPa | 307-337 psi |
| 1800 | 2117-2324 kPa | 307-337 psi |
Line PC Solenoid Valve Pressure
Scheme 98
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 20 | 3 | A/Trans Input Speed Sensor Assembly O-Ring Seal |
A/Trans Seal Kit (Gen 1& 2) 24251028
Scheme 99
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 209 | 1 | Front Wheel Drive Shaft Oil Seal Assembly |
Front Wheel Seal Kit (Gen 1& 2) 19258415
Scheme 100
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 65 | 1 | Drive Shaft Oil Seal Assembly |
Front Wheel Seal Kit (Gen 1& 2) 19258416
Scheme 101
| Callout | Quantity | Component Name |
|---|---|---|
| 3 | 1 | Control Valve Body Cover Gasket |
| 24 | 1 | Torque Converter Housing Gasket |
| 58 | 4 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring |
| 65 | 1 | Drive Shaft Oil Seal Assembly |
| 202 | 1 | Torque Converter and Differential Housing Seal |
| 209 | 1 | Front Wheel Drive Shaft Oil Seal Assembly |
| 301 | 1 | Torque Converter Fluid Seal Assembly |
| 319 | 1 | Torque Converter Fluid Seal Assembly |
| 504 | 1 | 3-5-Reverse Clutch Piston Inner Seal |
| 505 | 1 | 3-5-Reverse Clutch Piston Inner Seal |
| 506 | 1 | 3-5-Reverse Clutch Piston Dam Seal |
| 518 | 1 | 4-5-6 Clutch Piston Outer Seal |
| 519 | 1 | 4-5-6 Clutch Piston Outer Seal |
| 521 | 1 | 4-5-6 Clutch Piston Inner Seal |
A/Trans Seal Kit (Gen 1) 24251353 (1 of 2)
Scheme 102
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 5 | 1 | Control Valve Body Cover Hole Seal |
| 8 | 1 | Control Valve Body Filter Plate Assembly |
| 12 | 1 | Control Valve Body Spacer Plate Assembly |
| 14 | 1 | A/Trans Fluid Level Control Valve Gasket |
| 20 | 3 | A/Trans Input Speed Sensor Assembly O-Ring Seal |
| 25 | 1 | A/Trans Fluid Pump Seal Assembly |
| 59 | 1 | Drive Link Lube Fluid Seal |
| 67 | 1 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 203 | 1 | A/Trans Fluid Filter Assembly |
| 403 | 1 | Channel Plate to Valve Body Spacer Plate Assembly |
| 604 | 1 | Manual Shift Shaft Seal |
| 605 | 1 | Park Pawl Actuator Guide Seal |
A/Trans Seal Kit (Gen 1) 24251353 (2 of 2)
Scheme 103
| Callout | Quantity | Component Name |
|---|---|---|
| 3 | 1 | Control Valve Body Cover Gasket |
| 24 | 1 | Torque Converter Housing Gasket |
| 58 | 3 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring |
| 65 | 1 | Drive Shaft Oil Seal Assembly |
| 202 | 1 | Torque Converter and Differential Housing Seal |
| 209 | 1 | Front Wheel Drive Shaft Oil Seal Assembly |
| 301 | 1 | Torque Converter Fluid Seal Assembly |
| 319 | 1 | Torque Converter Fluid Seal Assembly |
| 504 | 1 | 3-5-Reverse Clutch Piston Inner Seal |
| 505 | 1 | 3-5-Reverse Clutch Piston Inner Seal |
| 506 | 1 | 3-5-Reverse Clutch Piston Dam Seal |
| 518 | 1 | 4-5-6 Clutch Piston Outer Seal |
| 519 | 1 | 4-5-6 Clutch Piston Outer Seal |
| 521 | 1 | 4-5-6 Clutch Piston Inner Seal |
| 524 | 1 | 4-5-6 Clutch Piston Fluid Dam Retainer Ring |
A/Trans Seal Kit (Gen 2) 24260603 (1 of 2)
Scheme 104
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 5 | 1 | Control Valve Body Cover Hole Seal |
| 8 | 1 | Control Valve Body Filter Plate Assembly |
| 12 | 1 | Control Valve Body Spacer Plate Assembly |
| 14 | 1 | A/Trans Fluid Level Control Valve Gasket |
| 20 | 3 | A/Trans Input Speed Sensor Assembly O-Ring Seal |
| 23 | 1 | Fill Cap Seal |
| 25 | 1 | A/Trans Fluid Pump Seal Assembly |
| 59 | 1 | Drive Link Lube Fluid Seal |
| 67 | 1 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 203 | 1 | A/Trans Fluid Filter Assembly |
| 403 | 1 | Channel Plate to Valve Body Spacer Plate Assembly |
| 407 | 5 | Actuator Feed Accumulator Spring |
| 408 | 5 | Actuator Feed Accumulator Piston |
| 604 | 1 | Manual Shift Shaft Seal |
| 605 | 1 | Park Pawl Actuator Guide Seal |
A/Trans Seal Kit (Gen 2) 24260603 (2 of 2)
Scheme 105
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 523 | 1 | 4-5-6 Clutch Piston Fluid Dam Assembly |
| 524 | 1 | 4-5-6 Clutch Piston Fluid Dam Retainer Ring |
| 531 | 1 | Reaction Carrier Hub Assembly |
Transmission Kit (Gen 1) 24260701
Scheme 106
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 3 | 1 | Control Valve Body Cover Gasket |
| 5 | 1 | Control Valve Body Cover Hole Seal |
| 8 | 1 | Control Valve Body Filter Plate Assembly |
| 12 | 1 | Control Valve Body Spacer Plate Assembly |
| 14 | 1 | A/Trans Fluid Level Control Valve Gasket |
| 67 | 2 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 403 | 1 | Channel Plate to Valve Body Spacer Plate Assembly |
Control Valve Body Kit (Gen 1) 24248473
Scheme 107
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 3 | 1 | Control Valve Body Cover Gasket |
| 5 | 1 | Control Valve Body Cover Hole Seal |
| 8 | 1 | Control Valve Body Filter Plate Assembly |
| 12 | 1 | Control Valve Body Spacer Plate Assembly |
| 14 | 1 | A/Trans Fluid Level Control Valve Gasket |
| 67 | 2 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 403 | 1 | Channel Plate to Valve Body Spacer Plate Assembly |
| 407 | 5 | Actuator Feed Accumulator Spring |
| 408 | 5 | Actuator Feed Accumulator Piston |
Control Valve Body Kit (Gen 2) 24260702
Scheme 108
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 509 | 3 | 3-5 Reverse Clutch (w/Friction Material) Plate Assembly |
| 527 | 4 | 4-5-6 Clutch (w/Friction Material) Plate Assembly |
| 542 | 2 | 2-6 Clutch (w/Friction Material) Plate Assembly |
| 545 | 3 | Low and Reverse Clutch (w/Friction Material) Plate Assembly |
| 559 | 2 | 1-2-3-4 Clutch (w/Friction Material) Plate Assembly |
Clutch Plate Package (Gen 1) 24249460
Scheme 109
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 509 | 3 | 3-5 Reverse Clutch (w/Friction Material) Plate Assembly |
| 527 | 5 | 4-5-6 Clutch (w/Friction Material) Plate Assembly |
| 542 | 2 | 2-6 Clutch (w/Friction Material) Plate Assembly |
| 545 | 3 | Low and Reverse Clutch (w/Friction Material) Plate Assembly |
| 559 | 2 | 1-2-3-4 Clutch (w/Friction Material) Plate Assembly |
Clutch Plate Package (Gen 2) 24260695
Scheme 110
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 527 | 5 | 4-5-6 Clutch (w/Friction Material) Plate Assembly |
4-5-6 Plate Assembly (Gen 2) 24260700
Scheme 111
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 545 | 3 | Low and Reverse Clutch (w/Friction Material) Plate Assembly |
Low and Reverse Plate Assembly (Gen 2) 24260696
Scheme 112
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 509 | 3 | 3-5 Reverse Clutch (w/Friction Material) Plate Assembly |
3-5 Reverse Plate Assembly (Gen 2) 24260697
Scheme 113
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 542 | 2 | 2-6 Clutch (w/Friction Material) Plate Assembly |
2-6 Plate Assembly (Gen 2) 24260698
Scheme 114
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 559 | 2 | 1-2-3-4 Clutch (w/Friction Material) Plate Assembly |
1-2-3-4 Plate Assembly (Gen 2) 24260699
Scheme 115
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 352 | 2 | A/Trans Auxiliary Fluid Pump Outlet Pipe Seal Assembly |
| 356 | 1 | Pressure Regulator Valve Spring Spacer |
| 361 | 1 | A/Trans Auxiliary Fluid Pump Gasket |
| 362 | 1 | A/Trans Auxiliary Fluid Pump Seal |
| 363 | 1 | A/Trans Auxiliary Fluid Pump Cover Seal |
| 367 | 1 | A/Trans Auxiliary Fluid Pump Motor Cover Seal- O-Ring |
| 371 | 1 | A/Trans Auxiliary Fluid Inlet Pump Seal |
| 373 | 1 | A/Trans Fluid Trough Check Ball |
A/Trans Seal Kit (Gen 2) 24260704
Scheme 116
Note. Callouts with boxes around them indicate part is included in the service kit. Callouts without boxes are shown for relationship purposes only.
| Callout | Quantity | Component Name |
|---|---|---|
| 352 | 2 | A/Trans Auxiliary Fluid Pump Outlet Pipe Seal Assembly |
| 356 | 1 | Pressure Regulator Valve Spring Spacer |
| 361 | 1 | A/Trans Auxiliary Fluid Pump Gasket |
| 362 | 1 | A/Trans Auxiliary Fluid Pump Seal |
| 363 | 1 | A/Trans Auxiliary Fluid Pump Cover Seal |
| 367 | 1 | A/Trans Auxiliary Fluid Pump Motor Cover Seal- O-Ring |
A/Trans Auxiliary Seal Kit (Gen 2) 24260705
