Scheme 218
Scheme 218: Case and Associated Parts
| Callout | Component Name |
|---|
| 1 | Control Valve Body Cover Bolt |
| 2 | Control Valve Body Cover Assembly |
| 3 | Control Valve Body Cover Gasket |
| 4 | Control Valve Body Bolt |
| 5 | Control Valve Body Cover Hole Seal |
| 6 | Control Solenoid Valve Heat Sink Bolt |
| 7 | Control Solenoid (w/Body and TCM) Valve Assembly |
| 8 | Control Valve Body Filter Plate Assembly |
| 9 | Control Valve Body Bolt |
| 10 | Control Valve Body Bolt |
| 11 | Control Valve Body Assembly |
| 12 | Control Valve Body Spacer Plate Assembly |
| 13 | A/Trans Fluid Level Control Valve |
| 14 | A/Trans Fluid Level Control Valve Gasket |
| 15 | A/Trans Output Speed Sensor Bolt |
| 16 | A/Trans Output Speed Sensor Assembly |
| 17 | Manual Shaft Detent Spring Bolt |
| 18 | Manual Shaft Detent Lever Spring Assembly |
| 19 | A/Trans Input Speed Sensor Assembly |
| 20 | A/Trans Input Speed Sensor Assembly O-Ring Seal |
| 21 | A/Trans Input Speed Sensor Bolt |
| 22 | Fill Cap |
| 23 | Fill Cap Seal |
| 24 | Torque Converter Housing Gasket |
| 25 | A/Trans Fluid Pump Seal Assembly |
| 26 | Torque Converter with Fluid Pump Housing Assembly |
| 27 | Torque Converter and Differential Housing Bolt |
| 28 | A/Trans Fluid Fill Tube Plug Assembly |
| 29 | Torque Converter Assembly |
Scheme 219
Scheme 219: Transmission Case Assembly - 6T30
| Callout | Component Name |
|---|
| 50 | A/Trans Case Assembly |
| 51 | A/Trans Fluid Pressure Test Hole Plug |
| 53 | Transmission Case Cover Locator Pin |
| 55 | A/Trans Fluid Check Ball |
| 56 | Input Shaft Support |
| 57 | Input Shaft Support Bolt |
| 58 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring |
| 59 | Drive Link Lube Fluid Seal |
| 60 | Drive Link Lube Scoop |
| 61 | Front Differential Carrier Baffle Bolt |
| 62 | Front Differential Carrier Baffle |
| 63 | Oil Level Plug |
| 64 | Drain Plug |
| 65 | Drive Shaft Oil Seal Assembly |
| 66 | Control Valve Body Locator Pin |
| 67 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 68 | Drive Link Lube Fluid Seal |
| 69 | Baffle Retainer |
Scheme 220
Scheme 220: Transmission Case Assembly - 6T40/6T45/6T50 - Gen 1
| Callout | Component Name |
|---|
| 50 | A/Trans Case Assembly |
| 51 | A/Trans Fluid Pressure Test Hole Plug |
| 53 | Transmission Case Cover Locator Pin |
| 55 | A/Trans Fluid Check Ball |
| 56 | Input Shaft Support |
| 57 | Input Shaft Support Bolt |
| 58 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring |
| 59 | Drive Link Lube Fluid Seal |
| 60 | Drive Link Lube Scoop |
| 61 | Front Differential Carrier Baffle Bolt |
| 62 | Front Differential Carrier Baffle |
| 63 | Oil Level Plug |
| 64 | Drain Plug |
| 65 | Drive Shaft Oil Seal Assembly |
| 66 | Control Valve Body Locator Pin |
| 67 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 68 | Drive Link Lube Fluid Seal |
Scheme 221
Scheme 221: Transmission Case Assembly - 6T40/6T45/6T50 - Gen 2
| Callout | Component Name |
|---|
| 50 | A/Trans Case Assembly |
| 51 | A/Trans Fluid Pressure Test Hole Plug |
| 53 | Transmission Case Cover Locator Pin |
| 55 | A/Trans Fluid Check Ball |
| 56 | Input Shaft Support |
| 57 | Input Shaft Support Bolt |
| 58 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring (Qty: 3) |
| 59 | Drive Link Lube Fluid Seal |
| 60 | Drive Link Lube Scoop |
| 61 | Front Differential Carrier Baffle Bolt |
| 62 | Front Differential Carrier Baffle |
| 63 | Oil Level Plug |
| 64 | Drain Plug |
| 65 | Drive Shaft Oil Seal Assembly |
| 66 | Control Valve Body Locator Pin |
| 67 | 1-2-3-4 and Low Reverse Clutch Fluid Passage Seal |
| 68 | Drive Link Lube Fluid Seal |
Scheme 222
Scheme 222: Torque Converter and Fluid Pump Housing Assembly- 6T30
| Callout | Component Name |
|---|
| 200 | A/Trans Fluid Pump Bolt |
| 201 | A/Trans Fluid Pump Assembly |
| 202 | Torque Converter and Differential Housing Seal |
| 203 | A/Trans Fluid Filter Assembly |
| 204 | Front Differential Carrier Baffle Bolt |
| 205 | Front Differential Carrier Baffle |
| 206 | Front Differential Ring Gear Retainer |
| 207 | Front Differential Ring Gear |
| 208 | Torque Converter and Differential Housing |
| 209 | Front Wheel Drive Shaft Oil Seal Assembly |
| 210 | A/Trans Fluid Filter Seal |
| 233 | Front Differential Carrier Bearing Assembly |
Scheme 223
Scheme 223: Torque Converter and Fluid Pump Housing Assembly- 6T40/6T45/6T50
| Callout | Component Name |
|---|
| 200 | A/Trans Fluid Pump Bolt |
| 201 | A/Trans Fluid Pump Assembly |
| 202 | Torque Converter and Differential Housing Seal |
| 203 | A/Trans Fluid Filter Assembly |
| 204 | Front Differential Carrier Baffle Bolt |
| 205 | Front Differential Carrier Baffle |
| 206 | Front Differential Ring Gear Retainer |
| 207 | Front Differential Ring Gear |
| 208 | Torque Converter and Differential Housing |
| 209 | Front Wheel Drive Shaft Oil Seal Assembly |
Scheme 224
Scheme 224: Drive Link Assembly
| Callout | Component Name |
|---|
| 50 | A/Trans Case |
| 220 | Park Gear Retainer Ring |
| 221 | Park Gear |
| 222 | Output Carrier Transfer Drive Gear Hub |
| 223 | Drive Sprocket Bearing Assembly |
| 224 | Drive Sprocket |
| 225 | Drive Link Assembly |
| 226 | Drive Sprocket Thrust Washer |
| 227 | Drive Sprocket Retainer Ring |
| 228 | Driven Sprocket Bearing Assembly |
| 229 | Driven Sprocket |
| 230 | Final Drive Sun Gear |
| 232 | Differential Carrier Assembly |
| 233 | Front Differential Carrier Bearing Assembly |
Scheme 225
Scheme 225: Oil Pump Assembly- 6T30
| Callout | Component Name |
|---|
| 300 | Torque Converter Fluid Seal Retainer |
| 301 | Torque Converter Fluid Seal Assembly |
| 302 | A/Trans Fluid Pump Cover Bolt |
| 303 | A/Trans Fluid Pump Body |
| 304 | Pump Blowoff Ball Valve |
| 305 | Pump Blowoff Valve Spring |
| 306 | Pressure Regulator Valve Bore Plug Retainer |
| 307 | Pressure Regulator Valve Bore Plug |
| 308 | Pressure Regulator Valve Spring |
| 309 | Pressure Regulator Valve |
| 310 | Torque Converter Clutch Blowoff Ball Valve |
| 311 | Torque Converter Clutch Blowoff Ball Valve Spring |
| 312 | Torque Converter Clutch Control Valve |
| 313 | Torque Converter Clutch Control Valve Spring |
| 314 | Torque Converter Clutch Control Valve Spring Retainer |
| 315 | A/Trans Fluid Pump Drive Gear |
| 316 | A/Trans Fluid Pump Driven Gear |
| 318 | A/Trans Fluid Pump Cover Assembly |
| 319 | Torque Converter Fluid Seal Assembly |
| 320 | A/Trans Fluid Pump Cover Bolt |
Scheme 226
Scheme 226: Oil Pump Assembly- 6T40/6T45/6T50- Gen 1
| Callout | Component Name |
|---|
| 300 | Torque Converter Fluid Seal Retainer |
| 301 | Torque Converter Fluid Seal Assembly |
| 302 | A/Trans Fluid Pump Cover Bolt |
| 303 | A/Trans Fluid Pump Body |
| 304 | Pump Blowoff Ball Valve |
| 305 | Pump Blowoff Valve Spring |
| 306 | Pressure Regulator Valve Bore Plug Retainer |
| 307 | Pressure Regulator Valve Bore Plug |
| 308 | Pressure Regulator Valve Spring |
| 309 | Pressure Regulator Valve |
| 310 | Torque Converter Clutch Blowoff Ball Valve |
| 311 | Torque Converter Clutch Blowoff Ball Valve Spring |
| 312 | Torque Converter Clutch Control Valve |
| 313 | Torque Converter Clutch Control Valve Spring |
| 314 | Torque Converter Clutch Control Valve Spring Retainer |
| 315 | A/Trans Fluid Pump Drive Gear |
| 316 | A/Trans Fluid Pump Driven Gear |
| 318 | A/Trans Fluid Pump Cover Assembly |
| 319 | Torque Converter Fluid Seal Assembly |
Scheme 227
Scheme 227: Oil Pump Assembly- 6T40/6T45/6T50- Gen 2
| Callout | Component Name |
|---|
| 300 | Torque Converter Fluid Seal Retainer |
| 301 | Torque Converter Fluid Seal Assembly |
| 302 | A/Trans Fluid Pump Cover Bolt |
| 303 | A/Trans Fluid Pump Body |
| 304 | Pump Blowoff Ball Valve |
| 305 | Pump Blowoff Valve Spring |
| 306 | Pressure Regulator Valve Bore Plug Retainer |
| 307 | Pressure Regulator Valve Bore Plug |
| 308 | Pressure Regulator Valve Spring |
| 309 | Pressure Regulator Valve |
| 310 | Torque Converter Clutch Blowoff Ball Valve |
| 311 | Torque Converter Clutch Blowoff Ball Valve Spring |
| 312 | Torque Converter Clutch Control Valve |
| 313 | Torque Converter Clutch Control Valve Spring |
| 314 | Torque Converter Clutch Control Valve Spring Retainer |
| 315 | A/Trans Fluid Pump Drive Gear |
| 316 | A/Trans Fluid Pump Driven Gear |
| 318 | A/Trans Fluid Pump Cover Assembly |
| 319 | Torque Converter Fluid Seal Assembly |
Scheme 228
Scheme 228: Auxiliary Fluid Pump and Hybrid Components - Hybrid Models
| Callout | Component Name |
|---|
| 350 | A/Trans Auxiliary Fluid Pump Outlet Bolt (Qty: 4) |
| 351 | A/Trans Auxiliary Fluid Pump Outlet Pipe Assembly |
| 352 | A/Trans Auxiliary Fluid Pump Outlet Pipe Seal Assembly |
| 353 | A/Trans Auxiliary Fluid Pump Assembly |
| 354 | A/Trans Auxiliary Fluid Pump Bolt |
| 355 | Pressure Regulator Valve Spring Retainer |
| 356 | Pressure Regulator Valve Spring Spacer |
| 357 | Pressure Regulator Valve Spring |
| 358 | Pressure Regulator Valve |
| 359 | A/Trans Auxiliary Fluid Pump Cover |
| 360 | A/Trans Auxiliary Fluid Pump Cover Hole Plug |
| 361 | A/Trans Auxiliary Fluid Pump Gasket |
| 362 | A/Trans Auxiliary Fluid Pump Seal |
| 363 | A/Trans Auxiliary Fluid Pump Cover Seal |
| 364 | A/Trans Auxiliary Fluid Pump Outer Rotor |
| 365 | A/Trans Auxiliary Fluid Pump Inner Rotor |
| 366 | A/Trans Auxiliary Fluid Pump Body |
| 367 | A/Trans Auxiliary Fluid Pump Motor Cover Seal - O-ring |
| 368 | A/Trans Auxiliary Fluid Pump Motor Assembly |
| 369 | A/Trans Auxiliary Fluid Pump (Pump to Motor) Bolt (Qty: 4) |
| 370 | Torque Converter and Differential Housing |
| 371 | A/Trans Auxiliary Fluid Inlet Pump Seal |
| 372 | A/Trans Fluid Pump Assembly |
| 373 | A/Trans Fluid Trough Check Ball |
| 374 | A/Trans Case |
Scheme 229
Scheme 229: Control Valve Body Assembly (1 of 2 - Gen 1)
| Callout | Component Name |
|---|
| 400 | Control Valve Body Bolt |
| 401 | Control Solenoid Valve Support |
| 402 | Valve Channel Plate |
| 403 | Channel Plate to Valve Body Spacer Plate Assembly |
| 404 | Control Valve Body Ball Check Valve |
| 405 | Control Valve Body Assembly |
Scheme 230
Scheme 230: Control Valve Body Assembly (2 of 2 - Gen 1)
| Callout | Component Name |
|---|
| 410 | Reverse and 4-5-6 Clutch Regulator Valve Spring |
| 411 | Reverse and 4-5-6 Clutch Regulator Valve |
| 412 | Clutch Valve Bore Plug |
| 413 | Valve Spring Retainer |
| 414 | 1-2-3-4 Clutch Boost Valve |
| 415 | 1-2-3-4 Clutch Boost Valve Spring |
| 416 | 1-2-3-4 Clutch Regulator Valve Spring |
| 417 | 1-2-3-4 Clutch Regulator Valve |
| 418 | 2-6 Clutch Regulator Valve Spring |
| 419 | 2-6 Clutch Regulator Valve |
| 420 | 3-5-Reverse Clutch Regulator Valve Spring |
| 421 | 3-5-Reverse Clutch Regulator Valve |
| 422 | Clutch Piston Dam Feed Regulator Valve |
| 423 | Clutch Piston Dam Feed Regulator Valve Spring |
| 424 | Torque Converter Clutch Regulator Apply Valve Spring |
| 425 | Torque Converter Clutch Regulator Apply Valve |
| 426 | Torque Converter Clutch Regulator Apply Shuttle Valve |
| 427 | Clutch Select Valve Spring |
| 428 | Clutch Select Valve |
| 429 | Default Override Shuttle Valve |
| 430 | Actuator Feed Limit Valve |
| 431 | Actuator Feed Limit Valve Spring |
| 432 | Manual Valve |
| 433 | Control Valve Body Assembly |
Scheme 231
Scheme 231: Control Valve Body Assembly (1 of 2 - Gen 2)
| Callout | Component Name |
|---|
| 400 | Control Valve Body Bolt |
| 401 | Control Solenoid Valve Support |
| 402 | Valve Channel Plate |
| 403 | Channel Plate to Valve Body Spacer Plate Assembly |
| 404 | Control Valve Body Ball Check Valve (Qty:6) |
| 405 | Control Valve Body Assembly |
| 406 | Control Valve Body Spacer Plate Retainer (Qty: 2) |
| 407 | Actuator Feed Accumulator Spring (Qty: 5) |
| 408 | Actuator Feed Accumulator Piston (Qty: 5) |
| 409 | Variable Hi and 2-3-4 Clutch Housing Valve Ball |
| 434 | Control Valve Channel Plate Ball Spring Assembly |
Scheme 232
Scheme 232: Control Valve Body Assembly (2 of 2 - Gen 2)
| Callout | Component Name |
|---|
| 410 | Low-Reverse and 4-5-6 Clutch Regulator Valve Spring |
| 411 | Low-Reverse and 4-5-6 Clutch Regulator Valve |
| 412 | Clutch Valve Bore Plug |
| 413 | Valve Spring Retainer |
| 414 | 1-2-3-4 Clutch Boost Valve |
| 415 | 1-2-3-4 Clutch Boost Valve Spring |
| 416 | 1-2-3-4 Clutch Regulator Valve Spring |
| 417 | 1-2-3-4 Clutch Regulator Valve |
| 418 | 2-6 Clutch Regulator Valve Spring |
| 419 | 2-6 Clutch Regulator Valve |
| 420 | 3-5-Reverse Clutch Regulator Valve Spring |
| 421 | 3-5-Reverse Clutch Regulator Valve |
| 422 | Default Override Valve |
| 423 | Defualt Override Valve Spring |
| 424 | Torque Converter Clutch Regulator Apply Valve Spring |
| 425 | Torque Converter Clutch Regulator Apply Valve |
| 426 | Torque Converter Clutch Regulator Apply Shuttle Valve |
| 427 | Clutch Select Valve Spring |
| 428 | Clutch Select Valve |
| 429 | Clutch Select (Shuttle) Valve |
| 430 | Actuator Feed Limit Valve |
| 431 | Actuator Feed Limit Valve Spring |
| 432 | Manual Valve |
| 433 | Control Valve Body Assembly |
| 435 | Control Valve Body Bore Plug Retainer |
| 436 | Low-Reverse and 4-5-6 Clutch Boost Valve |
| 437 | Low-Reverse and 4-5-6 Clutch Boost Valve Spring |
| 438 | 3-5 Reverse Clutch Regulator (Shuttle) Valve |
Scheme 233
Scheme 233: 3-5 Reverse Clutch Assembly - Gen 1
| Callout | Component Name |
|---|
| 500 | A/Trans Input Shaft Speed Sensor Reluctor Wheel Retainer Ring |
| 501 | A/Trans Input Shaft Speed Sensor Reluctor Wheel |
| 502 | 3-5-Reverse Clutch Piston |
| 503 | 3-5-Reverse Clutch Piston Return Spring Assembly |
| 504 | 3-5-Reverse Clutch Piston Inner Seal |
| 505 | 3-5-Reverse Clutch Piston Inner Seal |
| 506 | 3-5-Reverse Clutch Piston Dam Seal |
| 507 | 3-5-Reverse Clutch Apply Plate |
| 508 | 3-5-Reverse Clutch Plate |
| 509 | 3-5-Reverse Clutch (w/Friction Material) Plate Assembly |
| 510 | 3-5-Reverse Clutch Backing Plate |
| 511 | 3-5-Reverse Clutch Backing Plate Retainer Ring |
Scheme 234
Scheme 234: 3-5 Reverse Clutch Assembly - Gen 2
| Callout | Component Name |
|---|
| 500 | A/Trans Input Shaft Speed Sensor Reluctor Wheel Retainer Ring |
| 501 | A/Trans Input Shaft Speed Sensor Reluctor Wheel |
| 502 | 3-5-Reverse Clutch Piston |
| 503 | 3-5-Reverse Clutch Piston Return Spring Assembly |
| 504 | 3-5-Reverse Clutch Piston Inner Seal |
| 505 | 3-5-Reverse Clutch Piston Inner Seal |
| 506 | 3-5-Reverse Clutch Piston Dam Seal |
| 507 | 3-5-Reverse Clutch Apply Plate |
| 508 | 3-5-Reverse Clutch Plate |
| 509 | 3-5-Reverse Clutch (w/Friction Material) Plate Assembly |
| 510 | 3-5-Reverse Clutch Backing Plate |
| 511 | 3-5-Reverse Clutch Backing Plate Retainer Ring |
Scheme 235
Scheme 235: 4-5-6 Clutch Assembly - Gen 1
| Callout | Component Name |
|---|
| 515 | Turbine Shaft Retainer Ring |
| 516 | 3-5-Reverse and 4-5-6 Clutch Housing Assembly |
| 517 | Turbine Shaft |
| 518 | 4-5-6 Clutch Piston Outer Seal |
| 519 | 4-5-6 Clutch Piston Outer Seal |
| 520 | 4-5-6 Clutch Piston |
| 521 | 4-5-6 Clutch Piston Inner Seal |
| 522 | 4-5-6 Clutch Piston Return Spring Assembly |
| 523 | 4-5-6 Clutch Piston Fluid Dam Assembly |
| 524 | 4-5-6 Clutch Piston Fluid Dam Retainer Ring |
| 525 | 4-5-6 Clutch (Waved) Plate |
| 526 | 4-5-6 Clutch Apply Plate |
| 527 | 4-5-6 Clutch (w/Friction Material) Plate Assembly |
| 528 | 4-5-6 Clutch Plate |
| 529 | 4-5-6 Clutch Backing Plate |
| 530 | Reaction Carrier Hub Thrust Bearing Assembly |
| 531 | Reaction Carrier Hub Assembly |
| 532 | 4-5-6 Clutch Backing Plate Retainer Ring |
Scheme 236
Scheme 236: 4-5-6 Clutch Assembly - Gen 2
| Callout | Component Name |
|---|
| 515 | Turbine Shaft Retainer Ring |
| 516 | 3-5-Reverse and 4-5-6 Clutch Housing Assembly |
| 517 | Turbine Shaft |
| 518 | 4-5-6 Clutch Piston Outer Seal |
| 519 | 4-5-6 Clutch Piston Outer Seal |
| 520 | 4-5-6 Clutch Piston |
| 521 | 4-5-6 Clutch Piston Inner Seal |
| 522 | 4-5-6 Clutch Piston Return Spring Assembly |
| 523 | 4-5-6 Clutch Piston Fluid Dam Assembly |
| 524 | 4-5-6 Clutch Piston Fluid Dam Retainer Ring |
| 527 | 4-5-6 Clutch (w/Friction Material) Plate Assembly Gen 1 (Qty: 4), Gen 2 (Qty: 5) |
| 528 | 4-5-6 Clutch Plate - Gen 1 (Qty: 3), Gen 2 (Qty: 5) |
| 529 | 4-5-6 Clutch Backing Plate |
| 530 | Reaction Carrier Hub Thrust Bearing Assembly |
| 531 | Reaction Carrier Hub Assembly |
| 532 | 4-5-6 Clutch Backing Plate Retainer Ring |
Scheme 237
Scheme 237: 2-6, Low and Reverse and 1-2-3-4 Clutch Plate Assemblies - Gen 1
| Callout | Component Name |
|---|
| 50 | A/Trans Case |
| 535 | 2-6 Clutch Piston Assembly |
| 536 | 2-6 Clutch Spring |
| 537 | 2-6 Clutch Spring Retainer Ring |
| 538 | 3-5-Reverse and 4-5-6 Clutch Housing Thrust Bearing |
| 539 | 3-5-Reverse and 4-5-6 Clutch Housing Assembly |
| 540 | 2-6 Clutch Apply (Waved) Plate |
| 541 | 2-6 Clutch Plate |
| 542 | 2-6 Clutch (w/Friction Material) Plate Assembly |
| 543 | Low and Reverse Clutch Assembly |
| 544 | Low and Reverse Clutch Backing Plate |
| 545 | Low and Reverse Clutch (w/Friction Material) Plate Assembly |
| 546 | Low and Reverse Clutch Plate |
| 547 | Low and Reverse Clutch Apply (Waved) Plate |
| 548 | Low and Reverse Clutch Spring Retainer |
| 549 | Low and Reverse Clutch Spring |
| 550 | Low and Reverse Clutch Piston |
| 551 | Low and Reverse and 1-2-3-4 Clutch Housing |
| 552 | 1-2-3-4 Clutch Piston |
| 553 | 1-2-3-4 Clutch Spring |
| 554 | 1-2-3-4 Clutch Piston Retainer |
| 555 | Output Sun Gear Assembly |
| 556 | Output Sun Thrust Bearing Assembly |
| 557 | 1-2-3-4 Clutch (Waved) Plate |
| 558 | 1-2-3-4 Clutch Plate |
| 559 | 1-2-3-4 Clutch (w/Friction Material) Plate Assembly |
| 560 | 1-2-3-4 Clutch Backing Plate |
| 561 | 1-2-3-4 Clutch Backing Plate Retainer Ring |
Scheme 238
Scheme 238: 2-6, Low and Reverse and 1-2-3-4 Clutch Plate Assemblies - Gen 2
| Callout | Component Name |
|---|
| 50 | A/Trans Case |
| 535 | 2-6 Clutch Piston Assembly |
| 536 | 2-6 Clutch Spring |
| 537 | 2-6 Clutch Spring Retainer Ring |
| 538 | 3-5-Reverse and 4-5-6 Clutch Housing Thrust Bearing |
| 539 | 3-5-Reverse and 4-5-6 Clutch Housing Assembly |
| 540 | 2-6 Clutch Apply (Waved) Plate |
| 541 | 2-6 Clutch Plate (Qty: 2) |
| 542 | 2-6 Clutch (w/Friction Material) Plate Assembly (Qty: 2) |
| 543 | Low and Reverse Clutch Assembly |
| 544 | Low and Reverse Clutch Backing Plate |
| 545 | Low and Reverse Clutch (w/Friction Material) Plate Assembly (Qty: 3) |
| 546 | Low and Reverse Clutch Plate (Qty: 3) |
| 547 | Low and Reverse Clutch Apply (Waved) Plate |
| 548 | Low and Reverse Clutch Spring Retainer |
| 549 | Low and Reverse Clutch Spring |
| 550 | Low and Reverse Clutch Piston |
| 551 | Low and Reverse and 1-2-3-4 Clutch Housing |
| 552 | 1-2-3-4 Clutch Piston |
| 553 | 1-2-3-4 Clutch Spring |
| 554 | 1-2-3-4 Clutch Piston Retainer |
| 555 | Output Sun Gear Assembly |
| 556 | Output Sun Thrust Bearing Assembly |
| 557 | 1-2-3-4 Clutch (Waved) Plate |
| 558 | 1-2-3-4 Clutch Plate (Qty: 2) |
| 559 | 1-2-3-4 Clutch (w/Friction Material) Plate Assembly (Qty: 2) |
| 560 | 1-2-3-4 Clutch Backing Plate |
| 561 | 1-2-3-4 Clutch Backing Plate Retainer Ring |
Scheme 239
Scheme 239: Input, Output and Reaction Gearsets- 6T30/6T40
| Callout | Component Name |
|---|
| 565 | Reaction Sun Gear Thrust Bearing Assembly |
| 566 | Reaction Sun Gear Assembly |
| 567 | Reaction Carrier Assembly |
| 568 | Input Carrier Thrust Bearing Assembly |
| 569 | Input Sun Gear Thrust Bearing Assembly |
| 570 | Input Carrier Assembly |
| 571 | Input Sun Gear |
| 572 | Input Sun Gear Thrust Bearing Assembly |
| 573 | Output Carrier Thrust Bearing Assembly |
| 574 | Output Carrier Assembly |
Scheme 240
Scheme 240: Input, Output and Reaction Gearsets- 6T45/6T50
| Callout | Component Name |
|---|
| 565 | Reaction Sun Gear Thrust Bearing Assembly |
| 566 | Reaction Sun Gear Assembly |
| 567 | Reaction Carrier Assembly |
| 568 | Input Carrier Thrust Bearing Assembly |
| 569 | Input Sun Gear Thrust Bearing Assembly |
| 570 | Input Carrier Assembly |
| 571 | Input Sun Gear |
| 572 | Input Sun Gear Thrust Bearing Assembly |
| 573 | Output Carrier Thrust Bearing Assembly |
| 574 | Output Carrier Assembly |
Scheme 241
Scheme 241: Front Differential Carrier Assembly (2 Pinion)
| Callout | Component Name |
|---|
| 580 | Differential Sun Gear to Differential Housing Bearing Assembly |
| 581 | Final Drive Retainer |
| 582 | Differential Carrier Assembly |
| 583 | Final Drive Pinion Pin |
| 584 | Final Drive Inner and Outer Washer |
| 585 | Final Drive Roller |
| 586 | Pinion Final Drive Gear |
| 587 | Front Differential Pinion Gear Shaft |
| 588 | Front Differential Pinion Gear Shaft Pin |
| 589 | Front Differential Pinion Gear Thrust Washer |
| 590 | Front Differential Pinion Gear |
| 591 | Front Differential Side Gear Thrust Washer |
| 592 | Front Differential Side Gear |
Scheme 242
Scheme 242: Front Differential Carrier Assembly (4 Pinion)
| Callout | Component Name |
|---|
| 700 | Front Differential Pinion Gear Shaft |
| 701 | Differential Carrier Assembly |
| 702 | Front Differential Pinion Gear Shaft |
| 703 | Front Differential Pinion Gear Shaft |
| 704 | Front Differential Pinion Thrust Washer |
| 705 | Front Differential Pinion Gear |
| 706 | Front Differential Side Gear |
| 707 | Front Differential Side Gear Thrust Washer |
| 708 | Front Differential Carrier Cover |
| 709 | Front Differential Carrier Cover Bolts |
| 710 | Front Differential Pinion Gear Shaft Washer |
| 711 | Front Differential Drive Pinion Gear |
| 712 | Front Differential Carrier Pinion Gear Bearing Rollers |
| 713 | Front Differential Pinion Gear Shaft Pin |
| 714 | Front Differential Pinion Gear Shaft Retainer |
| 715 | Front Differential Bearing |
Scheme 243
Scheme 243: Park System Components
| Callout | Component Name |
|---|
| 50 | A/Trans Case |
| 600 | Park Pawl Shaft |
| 601 | Park Pawl Spring |
| 602 | Park Pawl |
| 603 | Park Pawl Actuator Guide Pin |
| 604 | Manual Shift Shaft Seal |
| 605 | Park Pawl Actuator Guide Seal |
| 606 | Park Pawl Actuator Guide |
| 607 | Park Pawl Actuator Assembly |
| 608 | Manual Shift Detent Lever Shaft |
| 609 | Manual Shift Detent (w/Shaft Position Switch) Lever Assembly |
| 610 | Manual Shift Detent Lever Pin |
| 611 | Manual Shift Shaft Pin |
Scheme 244
Scheme 244: Component Location
| Callout | Component Name |
|---|
| 1 | Reaction Carrier Assembly |
| 2 | Control Valve Body Assembly |
| 3 | Input Carrier Assembly |
| 4 | Valve Channel Plate |
| 5 | Output Carrier Assembly |
| 6 | Park Gear |
| 7 | Control Solenoid (w/Body and TCM) Valve Assembly |
| 8 | Drive Link Assembly |
| 9 | Drive Sprocket |
| 10 | Torque Converter Assembly |
| 11 | A/Trans Fluid Pump Assembly |
| 12 | Differential Carrier Assembly |
| 13 | Front Differential Ring Gear |
| 14 | Driven Sprocket |
| 15 | 1-2-3-4 Clutch Assembly |
| 16 | Low and Reverse Clutch Assembly |
| 17 | 2-6 Clutch Assembly |
| 18 | 3-5 Reverse Clutch Assembly |
| 19 | 4-5-6 Clutch Assembly |
| 20 | A/Trans Input Speed Sensor Assembly |
| 21 | Reaction Sun Gear Assembly |
Scheme 245
Scheme 245: Bushing, Bearing, and Washer Locations (Gen 2/Hybrid)
| Callout | Component Name |
|---|
| 211 | Front Differential Carrier Bearing Assembly - AWD Models |
| 223 | Drive Spocket Bearing Assembly |
| 226 | Drive Sprocket Thrust Washer |
| 228 | Drive Sprocket Bearing Assembly |
| 231 | Differential Sun Gear to Differential Housing Bearing Assembly |
| 233 | Front Differential Carrier Bearing Assembly |
| 530 | Reaction Carrier Hub Thrust Bearing Assembly |
| 538 | 3-5-Reverse and 4-5-6 Clutch Housing Thrust Bearing |
| 556 | Output Sun Thrust Bearing Assembly |
| 565 | Reaction Sun Gear Thrust Bearing Assembly |
| 568 | Input Carrier Thrust Bearing Assembly |
| 569 | Input Sun Gear Thrust Bearing Assembly |
| 572 | Input Sun Gear Thrust Bearing Assembly |
| 573 | Output Carrier Thrust Bearing Assembly |
Scheme 246
Scheme 246: Seal Locations (1 of 2)
| Callout | Component Name |
|---|
| 3 | Control Valve Body Cover Gasket |
| 24 | Torque Converter Housing Gasket |
| 58 | 3-5-Reverse and 4-5-6 Clutch Fluid Seal Ring (Qty: 3) |
| 65 | Drive Shaft Oil Seal Assembly |
| 202 | Torque Converter and Differential Housing Seal |
| 209 | Front Wheel Drive Shaft Oil Seal Assembly |
| 301 | Torque Converter Fluid Seal Assembly |
| 319 | Torque Converter Fluid Seal Assembly |
| 504 | 3-5-Reverse Clutch Piston Inner Seal |
| 505 | 3-5-Reverse Clutch Piston Inner Seal |
| 506 | 3-5-Reverse Clutch Piston Dam Seal |
| 518 | 4-5-6 Clutch Piston Outer Seal |
| 519 | 4-5-6 Clutch Piston Outer Seal |
| 521 | 4-5-6 Clutch Piston Inner Seal |
| 535 | 2-6 Clutch Piston Assembly |
| 550 | Low and Reverse Clutch Piston |
| 552 | 1-2-3-4 Clutch Piston |
Scheme 247
Scheme 247: Seal Locations (2 of 2)
| Callout | Component Name |
|---|
| 5 | Control Valve Body Cover Hole Seal |
| 20 | A/Trans Input Speed Sensor Assembly O-Ring Seal |
| 23 | Fill Cap Seal |
| 25 | A/Trans Fluid Pump Seal Assembly |
| 59 | Drive Link Lube Fluid Seal |
| 67 | 1-2-3-4 and Low Reverse Clutch Fluid Passage |
| 68 | Drive Link Lube Fluid Seal |
| 604 | Manual Shift Shaft Seal |
| 605 | Park Pawl Actuator Guide Seal |
Scheme 248
Scheme 248: Auxiliary Fluid Pump and Hybrid Seals - Hybrid Models
| Callout | Component Name |
|---|
| 352 | A/Trans Auxiliary Fluid Pump Outlet Pipe Seal Assembly |
| 361 | A/Trans Auxiliary Fluid Pump Gasket |
| 362 | A/Trans Auxiliary Fluid Pump Seal |
| 363 | A/Trans Auxiliary Fluid Pump Cover Seal |
| 367 | A/Trans Auxiliary Fluid Pump Motor Cover Seal - O-ring |
| 371 | A/Trans Auxiliary Fluid Inlet Pump Seal |
Scheme 249
Scheme 249: Ball Check Valve Locations (Gen 2/Hybrid)
| I.D. | Input Oil | Input Oil | Output Oil |
|---|
| 1 | Latch | 456 CL | Latch |
| 2 | 35 Rev CL FD | Drive 1-6 | 35 Rev CL FD/Drive 1-6 |
| 3 | 35 Rev CL FD/Drive 1-6 | | 35 Rev CL FD/Drive 1-6 |
| 4 | Act FD LM | | 35 Rev CL |
| 5 | Drive | | Drive |
| 6 | Line (Hybrid Only) | Auxiliary Line (Hybrid Only) | Line (Hybrid Only) |
Ball Check Valve Locations (Gen 2/Hybrid)
