Door System, Mirror System & Window System Buick LeSabre VIII

FASTENER TIGHTENING SPECIFICATIONS

Fastener Tightening Specifications

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

DIAGNOSTIC STARTING POINT - DOORS

Begin the system diagnosis with the DIAGNOSTIC SYSTEM CHECK - DOOR SYSTEMS . The Diagnostic System Check will provide the following information

1. The identification of the control module(s) which command the system.
2. The ability of the control module(s) to communicate through the serial data circuit.
3. The identification of any stored Diagnostic Trouble Codes (DTCs) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

1. 2 Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition. Enabling the headlamps in this step verifies that a door module is not using an alternate path to ground through the switch illumination circuit.
2. 4 The symptom list in Symptoms will determine the correct diagnostic procedure to use.
3. 5 The presence of DTCs U1161, U1162, U1163 or U1170 indicate one or more of the door modules is not communicating on the power door serial data circuits.
4. 6 The presence of other DTCs which begin with "U" indicate some other system control module is not communicating. The specified procedure will compile all the available information before tests are performed.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

SCAN TOOL DATA DEFINITIONS

1. 8 Digit GM Part Number The scan tool displays the part number for the Driver Door Module (DDM).
2. Battery Voltage # The scan tool displays 9.0-15.0 volts. This is the current battery voltage.
3. Calibration ID The scan tool displays the calibration or program revision level used in the PROM.
4. Component Serial # The scan tool displays the first partition of the serial number.
5. Component Serial # The scan tool displays the second partition of the serial number.
6. Component Serial # The scan tool displays the third partition of the serial number.
7. Component Serial # The scan tool displays the last partition of the serial number.
8. Driver Door Ajar Sw. The scan tool displays Off/On. This is the state of the driver door ajar switch as detected by the driver door module. When the driver door is open, the switch closes and the scan tool displays On. When the driver door is closed, the switch opens and the scan tool displays Off.
9. Driver Door Cylinder Sw. The scan tool displays Idle/Unlock. This is the state of the driver door lock cylinder switch as detected by the driver door module. When the door key is inserted into the driver door lock cylinder and turned to the Unlock position, the scan tool displays Unlock. When the driver door lock cylinder is not being turned to the Unlock position, the scan tool displays Idle.
10. Driver Door Jamb Sw. The scan tool displays Off/On. This is the state of the driver door jamb switch as detected by the driver door module. When the driver door is open, the switch closes and the scan tool displays On. When the driver door is closed, the switch opens and the scan tool displays Off.
11. Driver Door Lock Output The scan tool displays Idle/Lock/Unlock. When the driver door module commands the driver door lock actuator to lock, the scan tool displays Lock. When the driver door module commands the driver door lock actuator to unlock, the scan tool displays Unlock. When the driver door module is not commanding the driver door lock actuator to, either lock or unlock, the scan tool displays Idle.
12. Driver Door Lock Sw. The scan tool displays Idle/Lock/Unlock. This is the state of the driver door lock switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA sends this switch status to the driver door module via the power door serial data circuit.
13. Driver LF Window Sw. The scan tool displays Idle/Up/Down/Express Down. This is the state of the driver door window switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA sends this switch status to the driver door module via the power door serial data circuit.
14. Driver LR Window Sw. The scan tool displays Idle/Up/Down. This is the state of the driver left rear window switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA sends this switch status to the driver door module via the power door serial data circuit.
15. Driver Mirror Outputs The scan tool displays Idle/Up/Down/Left/Right/Heated Mirror. When the driver door module commands the driver door mirror vertical motor to move the mirror in either the up or down direction, the scan tool displays the corresponding direction. When the driver door module commands the driver door mirror horizontal motor to move the mirror in either the left or right direction, the scan tool displays the corresponding direction. When the driver door module commands the driver door mirror to heat, the scan tool displays Heated Mirror. When the driver door module is not commanding the driver door mirror to heat, or to move in any direction, the scan tool displays Idle.
16. Driver Mirror Selectors The scan tool displays Driver/Off/Passenger. This indicates which mirror, if any, the operator has selected for adjustment. The Driver Door Switch Assembly (DDSA) detects the position of this switch and sends the information to the driver door module via the power door serial data circuit.
17. Driver Mirror Switches The scan tool displays Idle/Up/Down/Right/Left. This is the state of the mirror switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA reports this switch status to the driver door module via the power door serial data circuit. When the mirror switch is operated in the Up, Down, Right, or Left directions, the scan tool displays the corresponding direction. When the mirror switch is not being operated, the scan tool displays Idle.
18. Driver RF Window Sw. The scan tool displays Idle/Up/Down/Express Down. This is the state of the driver right front window switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA sends this switch status to the driver door module via the power door serial data circuit.
19. Driver RR Window Sw. The scan tool displays Idle/Up/Down. This is the state of the driver right rear window switch as detected by the Driver Door Switch Assembly (DDSA). The DDSA sends this switch status to the driver door module via the power door serial data circuit.
20. Driver Window Output The scan tool displays Idle/Up/Down. When the driver door module commands the driver door window motor to move the window up, the scan tool displays Up. When the driver door module commands the driver door window motor to move the window down, the scan tool displays Down. When the driver door module is not commanding the driver door window to move the window in either direction, the scan tool displays Idle.
21. Julian Date Of Build The scan tool displays the day of the year the module was built.
22. L. R. Door Lock Outputs The scan tool displays Idle/Lock/Unlock. When the left rear door module commands the left rear door lock actuator to lock, the scan tool displays Lock. When the left rear door module commands the left rear door lock actuator to unlock, the scan tool displays Unlock. When the left rear door module is not commanding the left rear door lock actuator to, either lock or unlock, the scan tool displays Idle.
23. L. R. Door Window Output The scan tool displays Idle/Up/Down. When the left rear door module commands the left rear door window motor to move the window up, the scan tool displays Up. When the left rear door module commands the left rear door window motor to move the window down, the scan tool displays Down. When the left rear door module is not commanding the left rear door window motor to move the window in either direction, the scan tool displays Idle.
24. Left Rear Door Ajar Sw. The scan tool displays Off/On. This is the state of the left rear door ajar switch as detected by the left rear door module. When the left rear door is open, the switch closes and the scan tool displays On. When the left rear door is closed, the switch opens and the scan tool displays Off.
25. Left Rear Door Jamb Sw. The scan tool displays Off/On. This is the state of the left rear door jamb switch as detected by the left rear door module. When the left rear door is open, the switch closes and the scan tool displays On. When the left rear door is closed, the switch opens and the scan tool displays Off.
26. Lt. Horiz. Mirror Pos. The scan tool displays 0.25-4.75 volts. This is the mirror horizontal position sensor feedback voltage to the driver door module. The voltage varies directly with the horizontal position of the driver outside rearview mirror.
27. Lt. Rear Door Window Sw. The scan tool displays Idle/Up/Down. This is the state of the left rear door window switch as detected by the left rear door module.
28. Lt. Vertical Mirror Pos. The scan tool displays 0.25-4.75 volts. This is the mirror vertical position sensor feedback voltage to the driver door module. The voltage varies directly with the vertical position of the driver outside rearview mirror.
29. Memory Recall Switches The scan tool displays Idle/Memory 1/Memory 2/Exit. When the memory function switch is operated, the scan tool displays the function selected.
30. Pass. Door Ajar Sw. The scan tool displays Off/On. This is the state of the passenger front door ajar switch as detected by the passenger front door module. When the passenger front door is open, the switch closes and the scan tool displays On. When the passenger front door is closed, the switch opens and the scan tool displays Off.
31. Pass. Door Cylinder Sw. The scan tool displays Idle/Unlock. This is the state of the passenger front door lock cylinder switch as detected by the passenger front door module. When the door key is inserted into the passenger front door lock cylinder and turned to the Unlock position, the scan tool displays Unlock. When the passenger front door lock cylinder is not being turned to the Unlock position, the scan tool displays Idle.
32. Pass. Door Jamb Sw. The scan tool displays Off/On. This is the state of the passenger front door jamb switch as detected by the passenger front door module. When the passenger front door is open, the switch closes and the scan tool displays On. When the passenger front door is closed, the switch opens and the scan tool displays Off.
33. Pass. Door Lock Outputs The scan tool displays Idle/Lock/Unlock. When the passenger front door module commands the passenger front door lock actuator to lock, the scan tool displays Lock. When the passenger front door module commands the passenger front door lock actuator to unlock, the scan tool displays Unlock. When the passenger front door module is not commanding the passenger front door lock actuator to, either lock or unlock, the scan tool displays Idle.
34. Pass. Door Lock Sw. The scan tool displays Idle/Lock/Unlock. This is the state of the passenger front door lock switch as detected by the passenger front door module.
35. Pass Door Window Output The scan tool displays Idle/Up/Down. When the passenger front door module commands the passenger front door window motor to move the window up, the scan tool displays Up. When the passenger front door module commands the passenger front door window motor to move the window down, the scan tool displays Down. When the passenger front door module is not commanding the passenger front door window motor to move the window in either direction, the scan tool displays Idle.
36. Pass Door Window Sw. The scan tool displays Idle/Up/Down/Express Down. This is the state of the passenger front door window switch as detected by the passenger front door module.
37. Passenger Mirror Output The scan tool displays Idle/Up/Down/Left/Right/Heated Mirror. When the passenger front door module commands the passenger front door mirror vertical motor to move the mirror in either the up or down direction, the scan tool displays the corresponding direction. When the passenger front door module commands the passenger front door mirror horizontal motor to move the mirror in either the left or right direction, the scan tool displays the corresponding direction. When the passenger front door module commands the passenger front door mirror to heat, the scan tool displays Heated Mirror. When the passenger front door module is not commanding the mirror to heat, or to move in any direction, the scan tool displays Idle.
38. Personalization Option This is the state of the personalization option as it is stored in the Dash Integration Module (DIM). The scan tool displays the directions to activate or deactivate the personalization option. An asterisk beside the option indicates that the option is activated. The personalization option is normally set to the activated state during assembly of the vehicle.
39. PROM This displays the four digit number of the PROM incorporated into the Driver Door Module (DDM).
40. R. R. Door Lock Outputs The scan tool displays Idle/Lock/Unlock. When the right rear door module commands the right rear door lock actuator to lock, the scan tool displays Lock. When the right rear door module commands the right rear door lock actuator to unlock, the scan tool displays Unlock. When the right rear door module is not commanding the right rear door lock actuator to, either lock or unlock, the scan tool displays Idle.
41. R. R. Door Window Output The scan tool displays Idle/Up/Down. When the right rear door module commands the right rear door window motor to move the window up, the scan tool displays Up. When the right rear door module commands the right rear door window motor to move the window down, the scan tool displays Down When the right rear door module is not commanding the right rear door window motor to move the window in either direction, the scan tool displays Idle.
42. Right Rear Door Ajar Sw. The scan tool displays Off/On. This is the state of the right rear door ajar switch as detected by the right rear door module. When the right rear door is open, the switch closes and the scan tool displays On. When the right rear door is closed, the switch opens and the scan tool displays Off.
43. Rt. Horiz. Mirror Pos. The scan tool displays 0.25-4.75 volts. This is the mirror horizontal position sensor feedback voltage to the passenger front door module. The voltage varies directly with the horizontal position of the passenger outside rearview mirror.
44. Rt. Rear Door Jamb Sw. The scan tool displays Off/On. This is the state of the right rear door jamb switch as detected by the right rear door module. When the right rear door is open, the switch closes and the scan tool displays On. When the right rear door is closed, the switch opens and the scan tool displays Off.
45. Rt. Rear Door Window Sw. The scan tool displays Idle/Up/Down. This is the state of the right rear door window switch as detected by the right rear door module.
46. Rt. Vertical Mirror Pos. The scan tool displays 0.25-4.75 volts. This is the mirror vertical position sensor feedback voltage to the passenger front door module. The voltage varies directly with the vertical position of the passenger outside rearview mirror.
47. Window Lockout Sw. The scan tool displays Idle/Active. The scan tool will display Idle until the window lockout switch is operated. Each time the window lockout switch is operated, the scan tool momentarily displays Active, followed by Idle. The Driver Door Switch Assembly (DDSA) detects the operation of the window lockout switch and reports the activity to the driver door module via the power door serial data circuit. When the window lockout function is activated, the LED on the window lockout switch button will be illuminated and the passenger door windows programmed for lockout will operate only from the drivers door window switches. When the window lockout function is deactivated, the LED on the window lockout switch button will not be illuminated and the passenger door windows can then be operated from their locally mounted window switches, as well as from the drivers door window switches.
48. Year Module Built This displays the four digit year of build.

Scheme 67

Circuit Description

The switch that failed and generated this Diagnostic Trouble Code (DTC) is part of the Driver Door Switch Assembly (DDSA). This assembly contains a microprocessor which takes the signal generated by this switch and assigns a digital message to the switch signal. The DDSA then sends this message over the power door serial data link to the Driver Door Module (DDM). The DDM then either moves the left mirror or sends commands over the power door serial data link to the right front door module to move the right mirror.

Conditions For Running The DTC

The DDM must be powered for this DTC to set.

Conditions For Setting The DTC

If the driver door module receives the message that a mirror switch is closed for more than 30 continuous seconds, the driver door module sets a DTC.

Action Taken When The DTC Sets

The DDM ignores the continuous message from the driver door switch assembly for this switch. The DDM will not respond to the invalid mirror switch message as a command for either door mirror. The DDM will respond to all other valid switch messages.

Conditions For Clearing The DTC

When the switch message status changes, the DDM clears this current DTC and stores it as history. The history DTC will clear either after 50 OFF/ON ignition switch cycles without a repeated failure or in response to a scan tool command.

Scheme 68

The mirror position sensors are potentiometers powered by the door module for the mirror. The Driver Door Module (DDM) and the front Passenger Door Module (PDM), determine the horizontal and vertical position of their respective mirrors based on the signal voltages from the mirror position sensors. Each mirror has a vertical position sensor and a horizontal position sensor.

The DDM and the PDM must be powered, in communications with each other, and cannot have B1327 or B1328 set.

These DTCs will set if

1. A mirror position sensor signal voltage is below 0.25 V for 2 seconds.
2. A mirror position sensor signal voltage is above 4.75 V for 2 seconds.

Memory movements are disabled. Manual movements are not disabled.

The current DTC clears when the door module no longer senses the failure. The DTC is stored as a history DTC. The history DTC will clear either after 50 OFF/ON ignition cycles without a repeated failure or in response to a scan tool command.

Diagnostic Aids

If the Personalization Option in the Dash Integration Module (DIM) is activated on a vehicle that does not have the A45 Memory Mirrors option, DTCs B1583, B1593, B1613, and B1623 will be erroneously set. If these DTCs are set on a vehicle that does not have A45, refer to BODY CONTROL MODULE (BCM) PROGRAMMING/RPO CONFIGURATION (DIM) or BODY CONTROL MODULE (BCM) PROGRAMMING/RPO CONFIGURATION (IPM) or BODY CONTROL MODULE (BCM) PROGRAMMING/RPO CONFIGURATION (RIM) in Body Control System to deactivate the option.

After readjusting the mirror positions, be sure to set the mirror memory switch to the new positions.

Scheme 69

Scheme 70

The switch that failed and generated this Diagnostic Trouble Code (DTC) is wired to either the Driver Door Switch Assembly (DDSA) or the Passenger Door Module (PDM). The DDSA or the PDM includes the switch state in the message it sends to the Driver Door Module (DDM) via the power door serial data circuit. The DDM sends the switch message to the Rear Integration Module (RIM), which is the master of all lock operations, as a Class 2 message. The RIM checks all conditions and if all conditions are correct, sends its OK to the DDM. When the OK message is received, the DDM sends the required signal to all other door modules via the power door serial data message system.

The DDM and PDM must be powered, in communications with each other and cannot have B1327-Battery Voltage Low or B1328-Battery Voltage High set for these DTCs to set.

If the DDM receives the message that either a passenger door lock switch circuit is closed for more than 30 continuous seconds or a DDSA lock switch circuit is closed for more than 255 seconds (4.25 minutes), the DDM sets a lock switch circuit DTC.

The DDM ignores any message from the lock switch designated by the DTC and prevents lock movement from the switch. The DDM will respond to other lock switch messages.

The DDM clears this current DTC when the switch message is no longer received and stores a history DTC. The history DTC will clear either after 50 OFF/ON ignition switch cycles without a repeated failure or in response to a scan tool command.

The numbers below refer to the step numbers on the diagnostic table.

1. 2 Check the module input state using the normal input status.
2. 3 Check to see that the input is seen by the module.
3. 4 Check to see that the signal lines to the module are open with the switch removed.
4. 5 Determine that the signal circuits are not shorted.

Scheme 71

The switch that failed and generated this Diagnostic Trouble Code (DTC) is wired to one of the passenger door modules. These modules contain a microprocessor which takes the signal generated by this switch and assigns a digital message to the switch signal. The door module then sends this message over the power door serial data link to the Driver Door Module (DDM).

The DDM and the passenger door modules all must both be powered and cannot have B1327-Battery Voltage Low or B1328-Battery Voltage High set for one of these DTCs to set. If one of the DTCs indicating a loss of communications with a door module is set, the setting of DTCs from that module is prohibited.

If the Driver Door Module (DDM) receives a message indicating that a window switch is closed for more than 15 continuous seconds from a passenger door module, the DDM sets the DTC.

The action taken depends on which switch is closed

1. If an UP switch is closed for more than 15 seconds, both UP and DOWN movement is prohibited until the UP switch is no longer closed, or, the power mode changes from OFF to RUN.
2. If a DOWN switch is closed for more than 15 seconds, the DOWN movement is prohibited until the DOWN switch is no longer closed, or, the power mode changes from OFF to RUN. UP movements are permitted regardless of the DOWN switch state.

The DDM clears this current DTC when the switch message is not received, or when the module power mode changes from OFF to RUN, and stores the DTC as history. The history DTC will clear either after 50 OFF/ON ignition switch cycles without a repeated failure, or in response to a scan tool command.

The numbers below refer to the step numbers on the diagnostic table.

1. 2 Check the module input state using the normal input status.
2. 3 Check to see that the input is seen by the module
3. 4 Check to see that the signal lines to the module are open with the switch removed.
4. 5 Check to see that the signal circuits are not shorted.

Scheme 72

The switch that failed and generated this Diagnostic Trouble Code (DTC) is part of the Driver Door Switch Assembly (DDSA). The DDSA contains a microprocessor which takes the signal generated by this switch and assigns a digital message to it. The DDSA then sends this message over the power door serial data circuit to the Driver Door Module (DDM).

The DDM must be powered and cannot have DTCs B1327-Battery Low Voltage or B1328-Battery High Voltage set for this DTC to set.

If the Driver Door Module (DDM) receives the message that a DDSA window switch is closed for more than 15 continuous seconds the DDM sets this DTC.

1. If the UP switch is closed for more than 15 seconds, both UP and DOWN movement is prohibited from the DDSA.
2. If the DOWN switch is closed for more than 15 seconds, DOWN movement is prohibited while UP movement is permitted from the DDSA.
3. If an express switch DTC is set, express function is disabled but regular window functions are not affected.
4. All windows will operate normally from their associated passenger door window switch.

The DDM clears this current DTC when the switch signal is no longer received. The DTC is stored as a history DTC. The history DTC will clear either after 50 OFF/ON cycles of the ignition switch without a repeated failure, or in response to a scan tool command.

The numbers below refer to the step numbers on the diagnostic table.

1. 2 Check the module input state using the normal input status.
2. 3 Check to see that the input is seen by the module.

Scheme 73

The switch that failed and generated this Diagnostic Trouble Code (DTC) is part of the Driver Door Switch Assembly (DDSA). The DDSA contains a microprocessor which takes the signal generated by this switch and assigns a digital message to it. The DDSA then sends this message over the power door serial data circuit to the Driver Door Module (DDM).

The DDM must be powered and cannot have DTCs B1327-Battery Low Voltage or B1328-Battery High Voltage set for this DTC to set.

If the Driver Door Module (DDM) receives the message that the lockout switch is closed for more than 30 continuous seconds the DDM sets this DTC.

When the lockout switch DTC is set, the DDSA and DDM default to the last valid switch input. If the last valid input was to enable lock out, the indicator LED will be lit and the passenger windows will not operate from the passenger window switches. If the last valid input was to disable lock out, the indicator LED will not be lit and the passenger windows will operate from the passenger window switches.

The DDM clears this current DTC when the switch signal is no longer received. The DTC is stored as a history DTC. The history DTC will clear either after 50 OFF/ON cycles of the ignition switch without a repeated failure or in response to a scan tool command.

The number below refers to the step number on the diagnostic table.

1. 2 Checks the existing state of the driver door window switch assembly passenger window lockout switch by using the current state of the input parameter.

Scheme 74

The power door serial data circuit provides a means for information exchange among the vehicle door modules. Door module information on inputs and commanded outputs are converted to power door serial data for exchange among the door modules. The Drivers Door Module (DDM) can also take information from modules connected to the class 2 serial data circuit and relay the command to the power door serial data link. The vehicle power mode message (ignition switch position) from the DIM is an example. The DDM periodically addresses each module on the power door serial data circuit. When a module does not respond to the DDM, the DTC for that module is set.

1. Diagnostic trouble codes B1327, B1328, U1300, and U1301 do not have a current status.
2. The driver door module has power.
3. The driver door module has received an input, a power door serial data message, or a class 2 "wake-up" message.

A response from a door module on the power door serial data circuit is not received by the DDM within 2 seconds of the DDM request for a response from a door module or the Driver Door Switch Assembly (DDSA).

1. A current DTC will clear when a response message from the failed door module is detected or at the end of the current ignition cycle.
2. A history DTC will clear upon receipt of a scan tool Clear DTCs command or after 50 OFF/ON ignition switch cycles without a repeat of a communications failure.

The numbers below refer to the step numbers on the diagnostic table.

1. 1 Diagnostic trouble codes U1161, U1162, U1163, and U1170 set simultaneously indicate a total malfunction of the power door serial data circuit.
2. 2 When DTCs U1161, U1162, and U1163 set simultaneously but U1170 does not set, the malfunction is likely to be caused by an open in the power door serial data circuit between the DDM and splice S302.
3. 4 The open in the power door serial data circuit is between the DDM and splice S302.
4. 5 Loss of communications with individual modules may be due to an unpowered module. This includes the Driver Door Switch Assembly (DDSA), which is also a module. The rear door modules each have a separate battery positive voltage circuit (connectors C1), but they are both fed by the same 10 amp RRDRMDL fuse in the rear fuse block. A short to ground in either one of the rear door module battery positive voltage circuits (connectors C1) may open the fuse and cause DTCs 1)1162 and U1163 to be set simultaneously.
5. 6 Loss of communications with individual modules may be due to an ungrounded module. This includes the Driver Door Switch Assembly (DDSA), which is also a module.
6. 8 The power door serial data circuit is shorted to voltage or ground, The condition may be due to the wiring or due to a malfunction in one of the modules. When testing the wiring for a short, make sure there is not a module connected to the wire being tested.
7. 10 Operating the window and locks from the scan tool via the class 2 serial data circuit proves that the DDM is capable of controlling the driver door functions and isolates the cause of the malfunction to the power door serial data circuit.
8. 11 The Driver Door Switch Assembly (DDSA) processes driver door window and lock switch signals to the DDM. Since the DDM was proven capable in step 10, the malfunction must be due to the DDSA.
9. 12 The following steps isolate the door module which is preventing power door serial data communications.

Scheme 75

Scheme 76

Scheme 77

SYMPTOMS - DOORS

Note. The following steps must be completed before using the symptom tables.

1. Perform «DIAGNOSTIC SYSTEM CHECK - DOOR SYSTEMS»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following: «POWER WINDOWS DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «POWER DOOR LOCKS DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «DOOR AJAR INDICATOR DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) «OUTSIDE MIRROR DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)

Visual/Physical Inspection

1. Inspect for aftermarket devices which could affect the operation of the power windows, power door locks, or power mirrors. Refer to «CHECKING AFTERMARKET ACCESSORIES»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__checking-aftermarket-accessories) .
2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT & POOR CONNECTIONS .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «POWER WINDOWS INOPERATIVE - ALL»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
2. «POWER WINDOWS INOPERATIVE - LOCKOUT FUNCTION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
3. «POWER WINDOW INOPERATIVE FROM MASTER SWITCH»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
4. «POWER WINDOW INOPERATIVE - PASSENGER DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
5. «DOOR AJAR INDICATOR MALFUNCTION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
6. «POWER DOOR LOCKS INOPERATIVE - KEY CYLINDER SWITCHES»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
7. «POWER DOOR LOCKS INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
8. «AUTOMATIC DOOR LOCKS INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
9. «POWER MIRRORS INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
10. «POWER MIRRORS - MEMORY RECALL POSITION INACCURATE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
11. «MIRRORS - OUTSIDE AUTOMATIC DAY-NIGHT FEATURE INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
12. «POWER MIRRORS - MIRROR TILT INOPERATIVE IN REVERSE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
13. «HEATED MIRRORS INOPERATIVE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)

CHECKING AFTERMARKET ACCESSORIES

Do not connect aftermarket accessories into the following circuits

1. SIR circuits, all such circuits are indicated on circuit diagrams with the SIR symbol.
2. OBD II circuits, all such circuits are indicated on circuit diagrams with the OBD II symbol.

Always check for aftermarket accessories (non-OEM) as the first step in diagnosing electrical problems. If the vehicle is so equipped, disconnect the system to verify that these add-on accessories are not the cause of the problems.

Possible causes of vehicle problems related to aftermarket accessories include

1. Power feeds connected to points other than the battery.
2. Antenna location.
3. Transceiver wiring located too close to vehicle electronic modules or wiring.
4. Poor shielding or poor connectors on antenna feed line.
5. Check for recent service bulletins detailing installation guidelines for aftermarket accessories.

The numbers below refer to the step numbers on the diagnostic table.

1. 2 Determines if this is the correct chart for the symptom.
2. 6 This step determines if a door module is internally shorted to ground, or the door module battery positive voltage circuit is shorted to ground.

Scheme 78

The numbers below refer to the step numbers on the diagnostic table.

1. 3 This step determines if the DDM receives the lockout switch request from the Driver Door Switch Assembly (DDSA).
2. 4 This step determines if the indicator is operating properly.

Scheme 79

Scheme 80

Scheme 81

The numbers below refer to the step numbers on the diagnostic table.

1. 3 This step checks to see that the door module associated with the inoperative window recognizes the switch input. Enabling the headlamps in this step eliminates the possibility of the window switch using an alternative path to ground through the switch illumination circuit, which could cause the scan tool to display incorrect window switch states.
2. 4 This step determines if the Express Down function of the window switch, if applicable, has failed.
3. 5 This step eliminates the battery positive voltage and ground circuits associated with door module connector C3 for the front passenger door, or, associated with door module connector C2 for a rear door as the cause.
4. 9 This step eliminates the window switch as the cause of the malfunction.
5. 14 This step eliminates the switch ground circuit as the cause.
6. 15 This step eliminates the switch Up or Down signal circuits as the cause.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

The numbers below refer to the step numbers on the diagnostic table.

1. 3 This step determines if there is a rear door lock actuator control circuit shorted to ground, a condition which could open the RRDR MDL fuse located in the rear fuse block and set DTCs U1162 and U1163 simultaneously current when the rear door lock actuator is actuated.
2. 4 Turning ON the headlamps in this step eliminates the possibility of the inoperative door lock switch finding an alternative path to ground through the switch illumination circuit, a condition which could result in the scan tool displaying incorrect lock switch states.
3. 5 This step begins to determine if the lock switch or lock switch circuits are the cause of the malfunction. If the 3 amp jumper wire fuse opens when the jumper wire is connected, test the appropriate lock switch signal circuits for a short to battery voltage.
4. 7 This step determines if the door lock actuator unlock circuit may be the cause of the malfunction. If the test lamp is already illuminated before operating the lock switch to Unlock, test the door lock actuator unlock circuit for a short to battery voltage.
5. 8 This step determines if the door lock actuator lock circuit may be the cause of the malfunction. If the test lamp is already illuminated before operating the lock switch to Lock, test the door lock actuator lock circuit for a short to battery voltage.
6. 16 This step directs you to, either inspect for poor connections at the passenger door module, or, at the driver door switch assembly as a pre-requisite to replacing the passenger door module or driver door switch assembly. This is because lock switch signals for the driver door are detected and processed by the driver door switch assembly, while lock switch signals for the passenger door are detected and processed by the passenger door module.
7. 21 This step directs you to, either replace the passenger door module or driver door switch assembly. This is because lock switch signals for the driver door are detected and processed by the driver door switch assembly, while lock switch signals for the passenger door are detected and processed by the passenger door module.

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

The numbers below refer to the step numbers on the diagnostic table.

1. 3 This step verifies that the Personalization Option is activated.
2. 4 This step determines if the mirror sensors are capable of sensing mirror position changes.
3. 6 This step verifies that the door module has the appropriate voltage available at both the horizontal and vertical sensor signal circuit pins. With the inoperative mirror harness connector disconnected from the associated door module, both the horizontal and vertical sensor signal circuits within the module should return to their highest value of 4.5 to 5.5 volts.

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Removal Procedure

1. Insert a flat bladed tool under the front edge of the window switch plate (2).
2. Gently pry the switch plate upwards in order to release the plate from the door trim panel.
3. Slide the switch plate forward in order to release the rear retainer tabs.
4. Disconnect the electrical connector.
5. Remove the switch plate.
6. Gently pry the switch plate away from the tabs on the window switch using a small flat bladed tool.
7. Remove the switch from the switch plate.

Installation Procedure

1. Snap the power window switch into the switch plate.
2. Connect the electrical connectors.
3. Install the rearward edge of the switch plate into the door trim panel.
4. Press down on the front edge of the switch plate in order to engage the retainer clip.

1. Remove the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Disconnect the electrical connector.
3. Remove the power door lock switch by releasing the lock tabs on the door handle bezel with a small flat bladed tool.

1. Snap the door lock switch into the door handle bezel.
2. Connect the electrical connector.
3. Install the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Insert a flat bladed tool under the front edge of the switch plate (2).
2. Gently pry upwards in order to release the front edge of the switch plate (2) from the door trim panel (1).
3. Slide the switch plate forward in order to release the rear retainer tabs.
4. Disconnect the electrical connectors.
5. Remove the switchpack (2) from the switch plate (1) by releasing the retainer tabs with a small flat bladed tool.

1. Snap the switchpack into the switch plate.
2. Connect the electrical connectors.
3. Install the rear end of the switch plate into the door trim panel.
4. Press down on the front of the switch plate in order to engage the retainer clip.

Note. The front inside door handle bezel has electrical connectors, the rear does not.

1. Insert a flat bladed tool (3) behind the forward edge of the door handle bezel (2).
2. Gently pry the bezel away from the door trim panel.
3. Pull the door handle (2) about half way open.
4. Pull the bezel (4) forward over the inside door handle.
5. Disconnect the electrical connector.

1. Connect the electrical connectors, if any, to the inside door handle bezel (4). (Scheme 112)
2. Pull the door handle (2) about half way open.
3. Slide the inside door handle (2) through the opening in the door handle bezel (4).
4. Insert the tabs at the rear of the bezel behind the door trim panel.
5. Snap the front of the door handle bezel (4) into place.

TRIM PANEL REPLACEMENT - SIDE FRONT DOOR

Note. Tools Required: Clip Zip Clip Removal Tool (J 36796) and Door Trim Pad Clip Remover (J 38778).

Scheme 101

1. Remove the upper door trim panel (1). Use the J 38778 in order to release the push in retainer at the top of the upper door trim panel (1). Lift upwards in order to remove. Disconnect the electrical connector to the tweeter.
2. Remove the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the fastener (1) located in the inside door handle opening.
4. Remove the door reflector using a small flat bladed tool inserted between the reflector and the door trim panel and gently prying it out.
5. Remove the fastener located at the rear of the door reflector opening (2).
6. Use the J 36796 in order to release the retainers (3) around the outside edges of the door trim panel (1).
7. Slide the door trim panel upwards in order to disengage the door trim panel from the window inner belt seal strip.
8. Disconnect the door trim panel wiring harness.
9. Remove the door trim panel from the vehicle.

1. Connect the door wiring harness to the door trim panel wiring harness.
2. Install the door trim panel with the 3 load assist fasteners at the lower edge of the door panel.
3. Secure the door trim panel around the outside edges with the retainers (3). (Scheme 115)
4. Press outboard midway between the top of the door trim panel and the armrest in order to secure the door trim panel to the window inner belt seal strip. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Install the fastener at the rear of the door reflector opening (2). Tighten the fastener to 2 N.m (18 in lbs).
6. Install the fastener (1) in the inside door handle opening. Tighten the fastener to 2 N.m (18 in lbs). (Scheme 114)
7. Install the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system). CAUTION: Use a new push in fastener when reinstalling the upper door trim panel (1). (Scheme 113) This prevents the upper door trim panel from rattling against the door frame.
8. Install the upper door trim panel (1). Connect the wire harness to the tweeter. Insert the tabs into the slots on the door trim panel. Insert the push in retainer into the hole in the door frame.

TRIM PANEL REPLACEMENT - SIDE REAR DOOR

Note. Tools Required: Clip Zip Clip Removal Tool (J 36796) and Door Trim Pad Clip Remover (J 38778).

1. Remove the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the fastener (1) located in the inside door handle opening.
3. Use a small flat bladed tool, inserted at the rear edge, in order to remove the door reflector.
4. Remove the fastener located at the rear of the door reflector opening (2).
5. Use the J 38778 in order to release the retainers (3) around the outside edges of the door trim panel (1).
6. Slide the door trim panel upwards in order to disengage the door trim panel from the window inner belt seal strip.
7. Disconnect the door trim panel wiring harness.
8. Remove the door trim panel from the vehicle.

1. Install the door trim panel (1) with the two load assist fasteners at the lower edge of the door trim panel. (Scheme 117)
2. Connect the electrical connector.
3. Secure the outside edges of the door trim panel by pushing in the retainers (3).
4. Press outboard midway between the top of the door trim panel and the armrest in order to secure the door trim panel to the window inner belt seal strip. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Install the fastener at the rear of the door reflector opening (2). Tighten the fastener to 2 N.m (18 in lbs).
6. Install the fastener (1) in the inside door handle opening. Tighten the fastener (1) to 2 N.m (18 in lbs). (Scheme 116)
7. Snap the door reflector into the door trim panel.
8. Install the inside door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) or «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Disconnect the electrical connectors.
3. Remove the door control module fasteners.
4. Remove the door control module.

Scheme 102

1. Install the door control module. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the fasteners. Tighten the fasteners to 7 N.m (62 in lbs).
3. Install the electrical connectors.
4. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) or «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .

Scheme 103

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Pull back the rear of the water deflector off far enough to access the energy absorber. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Cut the push pins that fasten the inner energy absorber to the door.
4. Remove the inner energy absorber.
5. Remove the lower rear door quarter panel energy absorber (1). Remove the fastener. Tilt the absorber outward. Remove the energy absorber by lifting.

1. Install the lower rear door quarter panel energy absorber bracket (2) into the hole in the door. (Scheme 120) CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the fastener. Tighten the fastener to 2 N.m (18 in lbs).
3. Install the inner energy absorber to the door with new push-in fasteners. (Scheme 119)
4. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Push the wiring harness through the hole in the water deflector.
4. Remove the retainers at the upper corners of the water deflector.
5. Gently peel the water deflector away from the door, being careful not to damage the sealer.
6. Remove the water deflector.

Scheme 104

1. Clean the water deflector to the inner door panel mating surface with denatured alcohol or the equivalent.
2. Route the wiring harness through the hole in the water deflector.
3. Align the water deflector to the door assembly.
4. Install the retainers at the upper comers of the water deflector.
5. Seat the water deflector to the door using a rolling tool.
6. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the retainers at the upper corners of the water deflector.
4. Push the wiring harness through the hole in the water deflector.
5. Carefully peel the water deflector away from the door, being careful not to damage the sealer.

Scheme 105

1. Clean the water deflector to the inner door panel mating surface with denatured alcohol or the equivalent.
2. Route the wiring harness through the hole in the water deflector.
3. Align the water deflector to the door assembly.
4. Install the retainers at both upper corners.
5. Seat the water deflector to the door using a rolling tool.
6. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .

DOOR ADJUSTMENT

Scheme 106

1. Loosen the hinge fasteners in order to adjust the door at the door hinge pillar in the following directions: Up or down. In or out.
2. Reposition the door as needed.
3. Adjust for a limited up or down movement at the body side hinge attachments. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Position the door fore or aft at the body hinge pillar attachment. Perform the following steps as needed: Loosen the fasteners. Reposition the door. Tighten the fasteners. Tighten the fasteners to 34 N.m (25 lb ft).
5. Adjust the lock striker. Refer to «LOCK STRIKER ADJUSTMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__lock-striker-adjustment-door) .
6. If more adjustment is needed, remove the door.
7. Remove the hinges from the pillar and the door.
8. Ream the stud holes in the pillar side of the hinges in order to allow for more adjustment.
9. Reinstall the hinges to the pillar and the door. Leave the nuts on the pillar side of the hinge loose.
10. Align the door as needed.
11. Position the door fore or aft at the body hinge pillar attachment. Perform the following steps as needed: Loosen the fasteners. Reposition the door. Tighten the fasteners. Tighten the fasteners to 34 N.m (25 lb ft).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the window inner belt seal strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Remove the outside rear view mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power) .
7. Remove the window outer belt seal strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
8. Remove the window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-front-door) .
9. Remove the window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
10. Remove the door frame applique. Refer to «DOOR FRAME APPLIQUE REPLACEMENT - FRONT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
11. Remove the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
12. Remove the rear window channel. Refer to «WINDOW CHANNEL REPLACEMENT - FRONT SIDE REAR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
13. Remove the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
14. Remove the door latch. Refer to «LATCH REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
15. Remove the upper auxiliary weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR UPPER AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
16. Remove the door bottom auxiliary weatherstrip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR BOTTOM AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
17. Insert a small flat bladed tool between the door wire harness conduit (2) and the hinge pillar in order to depress and release the tab (3)
18. Remove the door wire harness from the hinge pillar.
19. Disconnect the door wire harness from the body wire harness.
20. Remove the wiring harness clips (2) from the inner door panel.
21. Remove the rubber conduit and the wiring harness (1) from the door.
22. Remove all the plastic nuts and retainers from the door shell.
23. Remove the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
24. Remove the intermediate hinge fasteners (1) from both hinges.
25. With the aid of an assistant, lift the door to remove.
26. Remove the door hinges. Refer to «HINGE REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

1. Install the door hinges to the door. Refer to «HINGE REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
2. With the aid of an assistant, align the door hinge halves and lower the door until the hinge halves mate together. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. NOTE: Use Loctite® Blue GM P/N 12345382, or an equivalent, prior to the fastener installation.
3. Install the intermediate door hinge fasteners. Tighten the intermediate front door hinge fasteners (1) to 24 N.m (18 lb ft). (Scheme 128)
4. Install the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Touch up any paint damage to the intermediate front door hinge fasteners with body color paint.
6. Install all the plastic nuts and the retainers into the door shell that were removed during disassembly.
7. Route the wiring harness and the conduit into the door.
8. Install the door wiring harness clips (2) to the inner door panel. (Scheme 127)
9. Connect the door wiring harness electrical connector to the body wiring harness electrical connector. (Scheme 126)
10. Install the wire harness connectors into the hinge pillar.
11. Install the door bottom auxiliary weatherstrip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR BOTTOM AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
12. Install the upper auxiliary weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR UPPER AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
13. Install the door latch. Refer to «LATCH REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
14. Install the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
15. Install the rear window channel. Refer to «WINDOW CHANNEL REPLACEMENT - FRONT SIDE REAR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
16. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
17. Install the door frame applique. Refer to «DOOR FRAME APPLIQUE REPLACEMENT - FRONT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
18. Install the window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
19. Install the window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-front-door).
20. Install the window outer belt seal strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
21. Install the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power).
22. Install the window inner belt seal strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
23. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
24. Adjust the door if needed. Refer to «DOOR ADJUSTMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-adjustment).
25. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
26. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
27. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).
28. Inspect for proper door adjustment. Refer to «DOOR ADJUSTMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-adjustment).

1. Mark the location of the hinges (upper and lower) on the door.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
4. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Remove the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Remove the window inner belt seal strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Remove the window outer belt seal strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Remove the door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door).
10. Remove the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
11. Remove the stationary window. Refer to «WINDOW/DIVISION CHANNEL - REAR DOOR STATIONARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
12. Remove the door frame applique. Refer to «DOOR FRAME APPLIQUE REPLACEMENT - REAR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
13. Remove the door bottom auxiliary sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR BOTTOM AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
14. Remove the front window run channel. Refer to «WINDOW CHANNEL REPLACEMENT - REAR DOOR FRONT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
15. Remove the door latch. Refer to «LATCH REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
16. Remove the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
17. Remove the upper auxiliary weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - REAR DOOR UPPER AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
18. Remove the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
19. Open the front door.
20. Insert a small flat bladed tool between the door wire harness conduit (2) and the hinge pillar in order to depress and release the tab (3)
21. Remove the door wire harness from the hinge pillar.
22. Disconnect the door wire harness from the body wire harness.
23. Remove the wiring harness clips (2).
24. Remove the rubber conduit and wiring harness from the door.
25. Remove the intermediate hinge fasteners (1) from both hinges. (Scheme 129)
26. With the aid of an assistant, lift the door to remove.
27. Remove the door hinges. Refer to «HINGE REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).

1. Install the door hinges to the pillar and the door. Refer to «HINGE REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
2. With the aid of an assistant, align the door hinge halves and lower the door so the hinge halves mate together. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Apply Loctite® Blue GM P/N 12345382, or Canadian P/N 10953489, or an equivalent to the intermediate door hinge fasteners. Install the intermediate door hinge fasteners (1). Tighten the fasteners to 24 N.m (18 lb ft). (Scheme 129)
4. Install the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Touch up any paint damage to the intermediate rear door hinge fasteners with body color paint.
6. Route the wiring harness and conduit into the door.
7. Install the door wiring harness clips (2) to the inner door panel. (Scheme 131)
8. Connect the door wiring harness electrical connector to the body wiring harness electrical connector. (Scheme 130)
9. Install the upper auxiliary weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - REAR DOOR UPPER AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Install the door latch. Refer to «LATCH REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
11. Install the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
12. Install the front window run channel. Refer to «WINDOW CHANNEL REPLACEMENT - REAR DOOR FRONT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
13. Install the door bottom auxiliary sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR BOTTOM AUXILIARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
14. Install the door frame applique. Refer to «DOOR FRAME APPLIQUE REPLACEMENT - REAR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
15. Install the stationary window. Refer to «WINDOW/DIVISION CHANNEL - REAR DOOR STATIONARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
16. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
17. Install the door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door).
18. Install the window outer belt seal strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
19. Install the window inner belt seal strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
20. Install the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
21. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
22. Check the door for proper adjustment. Refer to «DOOR ADJUSTMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-adjustment).
23. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
24. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
25. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Open the front door.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Disconnect the door latch electrical connectors (1).
5. Disconnect the power window motor electrical connector.
6. Remove the door wiring harness retainers (2) from the door.
7. Pull the door wire harness out of the door.
8. Remove the door check link fasteners from the body.
9. Remove the intermediate hinge fasteners (1) from both hinges.
10. Lift the door to remove, with the aid of an assistant.
11. Mark the position of the hinge half (2) on the body.
12. Mark the position of the hinge half on the door.
13. Remove the hinge fasteners (1) from the pillar.
14. Remove the hinge half from the pillar. CAUTION: Be careful to secure the studplate within the door, when removing the hinge half from the door. The studplate is not attached to the door and could fair into the door.
15. Remove the hinge fasteners from the door.
16. Remove the hinge half from the door.

1. Align the hinge half (2) to the body. see scheme 135 CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the hinge to body fasteners. Tighten the fasteners to 35 N.m (26 lb ft).
3. Align the door half of the hinge with the marks made on the door during removal.
4. Install the hinge to the door fasteners (1). Tighten the hinge to door fasteners (1) to 34 N.m (24 lb ft).
5. Align the door hinge halves.
6. Lower the door so the hinge halves mate together.
7. Apply Loctite® Blue GM P/N 12345382 or (Canadian P/N 10953489), or equivalent to the intermediate door hinge fasteners (1). see scheme 134
8. Install the intermediate door hinge fasteners. Tighten the intermediate front door hinge fasteners (1) to 24 N.m (18 lb ft).
9. Install the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Touch up any paint damage to the hinge and the check link fasteners with body color paint.
11. Install the door wire harness through the opening in the front of the door.
12. Install the wiring harness retainers (2) into the holes in the door. (Scheme 132)
13. Connect the power window motor electrical connector.
14. Install the door latch electrical connectors (2).
15. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
16. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front). CAUTION: Striker alignment is a crucial part of door latch operation. Do not use the door striker to adjust the door to the vehicle. Failure to properly adjust the striker can result in damage to the door latch and the striker.
17. Adjust the door for proper alignment. Refer to «DOOR ADJUSTMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-adjustment).

1. Open the rear and the front doors.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
4. Remove the center pillar garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim__garnish-molding-replacement-center-pillar) in Interior Trim.
5. Disconnect the door wire harness from the body wire harness.
6. Remove the door wire harness connector (3) from the center pillar.
7. Remove the door check link fasteners from the pillar.
8. Remove the intermediate hinge fasteners (1) from both hinges. see scheme 136
9. Lift the door to remove, with the aid of an assistant.
10. Mark the position of the hinge on the body with a grease pencil.
11. Remove the hinge to body fasteners. NOTE: Be careful to secure the studplate within the door, when removing the hinge half from the door. The studplate is not attached to the door and could fall into the door.
12. Mark the position of the hinge on the door with a grease pencil.
13. Remove the hinge to door fasteners (1).

1. Align the body side half of the hinge to the marks made on the pillar during removal. see scheme 138
2. Install the hinge half to the body. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the fasteners. Tighten the hinge to body fasteners to 35 N.m (26 lb ft).
4. Align the door half of the hinge to the marks made on the door during removal.
5. Install the fasteners (1). Tighten the hinge to door fasteners to 34 N.m (24 lb ft). see scheme 139
6. With the aid of an assistant, align the door hinge halves and lower the door so the hinge halves mate together.
7. Apply Loctite® Blue GM P/N 12345382 or (Canadian P/N 10953489), or equivalent to the intermediate hinge fasteners (1). see scheme 136
8. Install the intermediate door hinge fasteners (1). Tighten the fasteners to 24 N.m (18 lb ft).
9. Install the door check link. Refer to «DOOR CHECK LINK REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Connect the door wire harness to the body wire harness.
11. Install the door wire harness connector to the hinge pillar.
12. Install the center pillar garnish molding. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim__garnish-molding-replacement-center-pillar) in Interior Trim.
13. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
14. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).
15. Adjust the door for proper alignment. Refer to «DOOR ADJUSTMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-adjustment).
16. Touch up any damage to the hinge. Compare the link fasteners with the body color paint.

1. Open the door.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) or «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the check link to pillar fasteners.
6. Remove the close-out grommet.
7. Remove the check link to door fasteners.
8. Remove the door check link through the inside of the door.

1. Install the check link into the door. see scheme 143
2. Load the check link studs through the access holes on the door inner panel. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the check link to door fasteners. Tighten the fasteners to 9 N.m (80 in lbs).
4. Install the check link arm to the door hinge pillar fasteners. Tighten the check link arm fasteners to 9 N.m (80 in lbs). see scheme 141
5. Install the close-out grommet. see scheme 142
6. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) or «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Place window in the full up position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).
3. Remove the right rear push in retainer on the water deflector.
4. Pull back the water deflector far enough in order to access the outside door handle.
5. Disconnect the lock cylinder rod from the door latch.
6. Disconnect the outside door handle rod (1) by opening the retainer (2) at the door latch.
7. Remove the door handle fasteners. see scheme 144
8. Remove the handle with handle and lock rods attached, by applying an upward and outward force.
9. Remove the handle and lock cylinder rods from the outside door handle.

Scheme 107

Scheme 108

1. Install the handle and lock cylinder rods to the outside door handle.
2. Install the handle and rods into the door. Rotate them into a horizontal position. Insert the rods through cut out. Rotate the handle into position. Apply up and inward pressure. Slide the handle downward until the door metal engages into the two lower retaining tabs on the handle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the outside door handle fasteners. Tighten the fasteners to 7 N.m (62 in lbs). see scheme 144
4. Connect the lock cylinder rod to the door latch. see scheme 145
5. Connect the door handle rod to the latch. Insert the rod (1) into the clip (2) on the door latch assembly. Close the clip. NOTE: Inspect for the proper operation of the door handle and lock cylinder before installing the water deflector and the door trim panel.
6. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Place the window in the full up position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the water deflector just far enough to access the outside door handle. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Disconnect the outside door handle latch rod (1) by opening the retainer (2) on the door latch.
5. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Remove the door latch. Refer to «LATCH REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Remove the outside door handle fasteners through the access holes (1).
8. Remove the handle, with latch rod attached, by lifting up and out.
9. Remove the rod from the door handle.

Scheme 109

1. Install the door handle rod to the outside door handle.
2. Install the door handle and rod into the door. see scheme 152 Rotate them into a horizontal position. Insert the rods through cut out. Rotate the handle into position. Apply up and inward pressure. Slide the handle downward until the door metal engages into the two lower retaining tabs on the handle. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the outside door handle fasteners through the access holes (1). Tighten the fasteners to 7 N.m (62 in lbs). see scheme 151
4. Install the door latch. Refer to «LATCH REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Connect the door handle rod to the latch. Insert the rod (1) into the clip (2) on the door latch assembly. Close the clip. NOTE: Inspect for the proper operation of the door handle and lock cylinder before installing the water deflector and the door trim panel.
7. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

Scheme 110

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the door handle fastener (2).
5. Snap the lock and latch rods out of rod guide.
6. Slide handle assembly forward to release the retainer tabs (1)
7. Tilt the handle and remove the rods from the handle in the following sequence: Lock knob rod (1). Handle lever rod (2).

1. Install the rods to the inside door handle in the following sequence: Handle lever rod (2). see scheme 157 Lock knob rod (1).
2. Align the retainer tabs (1) to the slots in the door and slide the door handle rearward. see scheme 156
3. Snap the lock and latch rods into the rod guide. see scheme 155 CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. 4. Install the inside door handle fastener (2). Tighten the fastener to 2 N.m (18 in lbs). see scheme 156
5. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the fastener (2) from the inside door handle.
5. Install the lock and latch release rods to the guide clip.
6. Slide the inside door handle forward in order to release the tabs (4) from the door.
7. Tilt the handle and remove the rods from the handle in the following sequence: Lock knob rod (1). Handle lever rod (2).

1. Install the rods to the inside door handle in the following sequence: Handle lever rod (2). see scheme 160 Lock knob rod (1).
2. Guide the tabs (4) on the inside door handle into the slots in the door.
3. Slide the inside door handle rearward in order to engage the tabs.
4. Install the latch and lock rods into the guide clip. see scheme 159 CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Install the inside door handle fastener (2). Tighten the fastener to 2 N.m (18 in lbs). see scheme 158
6. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Place the window in the full up position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
3. Peel the rear of the water deflector far enough away from the door in order to access the outside door handle. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the E-clip (3) on the lock cylinder in order to remove the lock rod and arm (2).
6. Spread the omega clip (1).
7. Remove the lock cylinder from the backside of the door handle (4).

1. Install the lock cylinder to the outside door handle from the back side.
2. Install the lock cylinder rod and arm (2) to the lock cylinder with the E-clip (3). see scheme 161
3. Install the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
4. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Place window in the full up position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
4. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Disconnect the electrical connectors.
7. Disconnect the lock cylinder rod from the door latch.
8. Disconnect the outside door handle rod (1) from the door latch by opening the clip (2).
9. Remove the door latch fasteners. see scheme 163
10. Remove the window run channel fastener.
11. Position window run channel out of the way.
12. Remove the door latch from the door with the inside door handle and lock rods attached.
13. Remove the handle and lock rods from the door latch.

1. Install the inside door handle and lock rods to the door latch.
2. Install the door latch into the door. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the door latch fasteners. Tighten the fasteners to 10 N.m (89 in lbs). see scheme 163
4. Install the outside door handle rod (1) into the latch clip (2).
5. Close the clip.
6. Install the lock cylinder rod into the door latch. see scheme 164
7. Install the window run channel fastener. Tighten the window run channel fastener to 9 N.m (80 in lbs).
8. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Connect the electrical connectors.
10. Inspect for proper operation of the door handles and lock cylinder before installing the water deflector and the door trim panel.
11. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
12. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
13. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Disconnect the outside door handle rod (1) from the door latch by opening the clip (2) on the door latch.
6. Remove the door latch fasteners.
7. Remove the door latch with the inside door handle latch and lock rods attached.
8. Disconnect the electrical connectors.
9. Remove the handle and lock rods from the door latch.

Scheme 111

1. Install the inside door handle and lock rods to the door latch.
2. Connect the electrical connectors. see scheme 168
3. Install the door latch into the door. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the door latch fasteners. Tighten the fasteners to 10 N.m (89 in lbs).
5. Connect the outside door handle latch rod to the door latch. Insert the rod (1) into the clip (2) on the door latch assembly. Close the clip.
6. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system). NOTE: Inspect for the proper operation of the door handles before installing the water deflector and the door trim panel.
7. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

Note. Observe the striker location and the number of spacers before removing the striker fasteners.

1. Mark the location of the door striker on the pillar with a grease pencil.
2. Remove the door striker fasteners (1).
3. Remove the striker (2), spacer (3) and washer.

1. Assemble the washer, spacer (3), and striker (2). see scheme 170
2. Position the striker on the lock pillar, with the narrow part of the striker facing outward, to the marks made on the door pillar during removal.
3. Secure the striker fasteners (1).
4. Align the door striker. Refer to «LOCK STRIKER ADJUSTMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__lock-striker-adjustment-door). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Tighten the striker fasteners. Tighten the striker fasteners to 28 N.m (21 lb ft).

LOCK STRIKER ADJUSTMENT - DOOR

Note. Tools Required: Mini-Wedge Door Striker Aligner (J 39346-A).

1. Loosen the 2 mini-wedge striker fasteners (1).
2. Pull the striker outboard to the end of the adjustment travel.
3. Tighten the 2 striker fasteners so that the striker can still be moved.
4. Place the J 39346-A over the striker.
5. Hold the outside door handle out and gently push the door flush against the body in order to locate the striker.
6. Slowly open the door.
7. Remove the J 39346-A. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
8. Secure the striker assembly. Tighten the striker fasteners to 28 N.m (21 lb ft).
9. After adjusting the striker, touch up any exposed or unpainted surfaces.

1. Remove the door striker. Refer to «STRIKER REPLACEMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the center pillar trim panel. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim__garnish-molding-replacement-center-pillar) in Interior Trim.
3. Remove the anchor plate (1) from the center pillar chute.

Scheme 112

1. Load the anchor plate (1) into the center pillar chute.
2. Install the door striker. Refer to «STRIKER REPLACEMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Install the center pillar trim panel. Refer to «GARNISH MOLDING REPLACEMENT - CENTER PILLAR»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim__garnish-molding-replacement-center-pillar) in Interior Trim.
4. Adjust the lock striker. Refer to «LOCK STRIKER ADJUSTMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__lock-striker-adjustment-door) .

1. Remove the door striker. Refer to «STRIKER REPLACEMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
2. Remove the rear seat back. Refer to «SEAT BACK REPLACEMENT - REAR»(/buick/lesabre/viii-2000-2005/remont/seats/#power-seat-system) in Seats.
3. Remove the anchor plate (1) from the rear pillar chute.

Scheme 113

1. Load the anchor plate (1) into the rear pillar chute.
2. Install the door striker. Refer to «STRIKER REPLACEMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Install the seat back. Refer to «SEAT BACK REPLACEMENT - REAR»(/buick/lesabre/viii-2000-2005/remont/seats/#power-seat-system) in Seats.
4. Adjust the lock striker. Refer to «LOCK STRIKER ADJUSTMENT - DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__lock-striker-adjustment-door) .

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Peel the water deflector down far enough in order to access the window clamp bolts. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Tape the window in place.
4. Through the access holes in the inner door panel, loosen the window clamp attachment bolts 4 revolutions.
5. Lower the window regulator 3/4 of the way down.
6. Disconnect the electrical connector from the window regulator motor.
7. Remove the window regulator to inner door panel fasteners (1, 2, 3).
8. Remove the window regulator.

1. Install the window regulator into the door. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the window regulator fasteners in the following order: Tighten the fastener (1) to 9 N.m (80 in lbs). see scheme 175 Tighten the fastener (3) to 9 N.m (80 in lbs). Tighten the fastener (2) to 9 N.m (80 in lbs).
3. Remove the tape holding the window up.
4. Lower the window into the window regulator clamps ensuring that the glass is fully rearward into the window channel when it is seated in the window clamps.
5. Connect the power window motor electrical connector. NOTE: Start the vehicle in order to ensure maximum power to the window motor. This is required to fully seat the window for adjustment.
6. Raise the window to the full up position. Tighten the window clamp fasteners to 11 N.m (95 in lbs).
7. Inspect the window for proper operation and a tight seal around the glass before installing the water deflector and the trim panel.
8. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Tape the window in the closed position.
5. Loosen the window regulator to window clamp fasteners 4 revolutions.
6. Lower the window regulator about 1/2 way down.
7. Disconnect the electrical connector from the power window motor.
8. Remove the window regulator to inner door panel fasteners (1, 2, 3).
9. Remove the window regulator. Tilt the motor end of the window regulator to the forward end of the door. Tilt the top of the regulator toward the lower, rear corner of the door. Remove the regulator through the front access hole in the door panel.

1. Install the window regulator into the door through the front access hole in the door panel. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the window regulator fasteners in the following order: Tighten the fastener (1) to 9 N.m (80 in lbs). see scheme 176 Tighten the fastener (3) to 9 N.m (80 in lbs). Tighten the fastener (2) to 9 N.m (80 in lbs).
3. Remove the tape from the window.
4. Lower the window into the window regulator clamps.
5. Connect the power window motor electrical connector. NOTE: Start the vehicle to ensure maximum power to the window motor. This is required to fully seat the window for adjustment.
6. Raise the window to the fully closed position. Tighten the window clamp fasteners to 11 N.m (95 in lbs).
7. Inspect the window for proper operation and a tight seal before installing the water deflector and the trim panel.
8. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Close the window.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
3. Peel the water deflector down far enough in order to access the window clamp bolts. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the window regulator (1). Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the power window motor to window regulator fasteners (2).
6. Remove the power window motor (1).

1. Install the power window motor (1) to the window regulator (3). see scheme 178 CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power window motor to regulator fasteners (2). Tighten the window motor fasteners to 4 N.m (62 in lbs).
3. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
4. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Peel the lower portion of the water deflector up in order to gain access to the window motor fasteners. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . NOTE: There is a binding effect on the power window motor drive when the window is in the fully closed or open position.
3. Partially open the window.
4. Disconnect the power window motor electrical connector.
5. Remove the 3 fasteners securing the power window motor to the window regulator.
6. Remove the power window motor.

Scheme 114

1. Install the power window motor to the window regulator. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the power window motor to regulator fasteners. Tighten the power window motor fasteners to 4 N.m (35 in lbs).
3. Connect the power window motor electrical connector.
4. Inspect for proper operation of the window motor and a tight seal around the glass before installing the water deflector and the trim panel.
5. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .

WINDOW REPLACEMENT - FRONT DOOR

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the door control module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Peel the water deflector down far enough in order to access the window clamp bolts. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the window inner belt molding. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Reconnect the power window switch.
6. Tape the window in the closed position.
7. Loosen the window regulator to window clamp fasteners 4 revolutions.
8. Lower the window regulator in order to separate the window from the clamps.
9. Remove the tape.
10. Remove the window by tilting the window forward then pulling the window up and out of the door.

Scheme 115

Note. The window regulator should be at least 1/2 way down before installing the window.

1. Install the window down into the door.
2. Locate the window into the 2 window regulator clamps. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. NOTE: Start the vehicle to ensure maximum power to the window motor. This is required in order to fully seat the window for adjustment.
3. Raise the window to the fully closed position. Tighten the window clamp fasteners to 11 N.m (98 in lbs).
4. Install the window inner belt molding. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Ensure proper operation and tight seal of the window.
6. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Install the door control module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .

WINDOW REPLACEMENT - REAR DOOR

1. Lower the window all the way down.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Raise the window to the full closed position.
6. Tape the window in the closed position.
7. Remove the water deflector to gain access to the window clamp fasteners. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
8. Loosen the window regulator to window clamp fasteners 4 revolutions.
9. Lower the window regulator to the full open position.
10. Remove the window by lifting up, flexing forward, and then out.

Scheme 116

1. Install the window down into the door assembly ensuring that the front of the window is in the front run channel and the rear is outboard of the division post.
2. Grasp the window at the top.
3. Shift the window forward in order to snap the rear of the window into the division post.
4. Locate the window into the 2 window regulator to window clamps.
5. Install the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Install the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. NOTE: Start the vehicle in order to ensure maximum power to the window motor. This is required to fully seat the window for adjustment.
7. Raise the window to the fully closed position. Tighten the window clamp fasteners to 11 N.m (98 in lbs).
8. Install water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
9. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .

1. Lower the door window to the full down position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
3. Peel back the rearward half of the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the window inner belt seal. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Pull the lower rear portion of the window weatherstrip out of the door frame far enough in order to gain access to the lower fastener of the door frame applique.
6. Remove the upper run channel fastener (1), which is also the lower door applique fastener.
7. Reinstall the window weatherstrip into the door frame.
8. Connect the door trim panel wire harness.
9. Run the window up until there is a 25.4 mm (1 in) opening at the top.
10. Remove the lower run channel fastener (2).
11. Pull the run channel down in order to clear the window.
12. Remove the run channel.

1. Insert the run channel into the door through the rear access hole.
2. Slide the run channel up along the window, ensuring that the upper bracket is under the door frame applique. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the lower fastener (2). Tighten the fastener to 9 N.m (80 in lbs). see scheme 183
4. Lower the window to the full down position.
5. Pull out enough of the lower rear edge of the window seal in order to install the upper fastener in the run channel and door applique.
6. Ensure that the window channel bracket is under the door applique.
7. Install the upper fastener. Tighten the fastener to 2 N.m (18 in lbs). NOTE: When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.
8. Install the window weatherstrip into the door frame. see scheme 182
9. Install the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
11. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Lower the window to the full down position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Remove the door window inner belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Remove the door window outer belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
8. Remove the rear door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door) .
9. Remove the fastener (1) from the division post (2).
10. Remove the rear door stationary window and window weatherstrip assembly (3) from the door. Pull the window weatherstrip out of the door frame. Grasp the division post and pull the assembly forward.

Note. When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.

Scheme 117

1. Install the rear door stationary window into the door. Seat the stationary window back into the door frame. Insert the window weatherstrip into the door frame. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the division post fastener (1). Tighten the division post fastener to 9 N.m (80 in lbs). see scheme 185
3. Install the rear door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door).
4. Install the rear door window outer belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the rear door window inner belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Install the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Raise the window to the full closed position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Loosen the lower fastener (3).
6. Remove the upper fastener (1), which is also the door applique lower fastener.
7. Slide the window channel assembly down far enough so that the upper bracket clears the door applique.
8. Remove the front window channel (1) from the door.

Scheme 118

1. Install the front window channel (1) into the door, top end first.
2. Insert the lower fastener into the keyhole slot.
3. Rotate the top of the front window channel rearward and align on the lower edge of the window. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the upper fastener. Tighten the upper fastener to 2 N.m (18 in lbs).
5. Install the lower fastener. Tighten the front window channel lower fastener to 9 N.m (80 in lbs).
6. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .

1. Put the window in the down position. Grasp the window weatherstrip at the lower rear corner.
2. Pull up and forward in order to release the window weatherstrip from the door frame far enough to expose the door applique fasteners.
3. Remove the door applique fasteners.
4. Detach the rear portion of the outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the door applique by sliding rearward, outward, and down.

Note. When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.

Scheme 119

1. Prep the weatherstrip for installation.
2. Install the applique. see scheme 190 Hold the outer belt molding away from the door. Insert the bottom edge of the applique onto the door frame. Roll the applique forward, while being careful not to damage the upper auxiliary molding, until fully seated onto the door frame. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the applique fasteners. Tighten the applique fasteners to 2 N.m (18 in lbs). see scheme 189
4. Install the rear portion of the window weatherstrip (1). Slide the end down into the door frame, ensuring that the window (2) is in the run channel. Squeeze and push the remaining portion of the window weatherstrip into the door frame.
5. Install the rear portion of outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door window outer belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Grasp the front, lower end of the window weatherstrip (3) and pull the weatherstrip (3) out of the door frame, far enough to reveal the door applique fasteners.
4. Remove the applique fasteners.
5. Roll the rear of the applique outward then forward in order to remove.

1. Slide the door applique up under the auxiliary weatherstrip and rearward over the door frame. see scheme 194
2. Install the door applique fasteners. NOTE: When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.
3. Reinstall the front portion of the door window weatherstrip.
4. Install the door window outer belt molding. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
5. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Remove the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power) .
2. Lower the front door window.
3. Remove the front door outer belt sealing strip from the door pinchweld flange. Lift upwards, starting at the rear, in order to disengage the sealing strip clips. Slide the sealing strip rearward in order to clear the upper auxiliary molding.

Scheme 120

1. Install the front door outer belt sealing strip to the pinchweld flange. Align the sealing strip to the door. Slide the strip forward and under the upper auxiliary molding. Ensure that the end cap is flush to the door cutline. Rotate the sealing strip downward. Align the sealing strip clips to the slots in the door pinchweld flange. Push the sealing strip down in order to fully seat and secure to the door pinchweld flange.
2. Install the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power) .
3. Raise the front door window.

1. Lower the rear door window. NOTE: Do not distort the strip.
2. Remove the rear door outer belt sealing strip from the rear door pinchweld flange by gently pulling up.

Scheme 121

1. Install the rear door outer belt sealing strip to the rear door pinchweld flange. Align the sealing strip clips to the slots in the pinchweld flange of the door. Push the sealing strip down in order to fully seat and secure the strip to the door.
2. Raise the rear door window.

1. Lower the window all the way down.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
3. Starting at one end of the window inner belt seal strip (1), pull upward in order to release the seal strip.
4. If further disassembly of the door is required, remove the auxiliary water deflector. Gently remove the folded portion of the deflector from the door flange. Lift the deflector up and out of the door.

1. If the auxiliary water deflector was removed during disassembly, install the water deflector to the front door inner panel. see scheme 199 Insert the deflector through the belt line, inboard of the window. Position the deflector against the mirror patch. Fold the perforated portion of the deflector over the door flange. Press in order to secure the water deflector to the door flange. NOTE: When reusing the window belt seal strip, the flange mounting area (2) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (3) back together. see scheme 198
2. Work from one end of the seal strip to the other.
3. Position the door window inner belt seal strip over the flange of the door inner panel. NOTE: Do not distort the seal strip.
4. Press down in order to engage the door window inner belt seal strip the entire length of the door.
5. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Lower the window.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Starting at one end of the door window inner belt seal strip (1), pull upward in order to release the seal strip.
4. If further disassembly of the door is required, remove the auxiliary water deflector. Gently remove the folded portion of the deflector from the door flange. Lift the deflector up and out of the door.

1. If the auxiliary water deflector was removed during disassembly, install the deflector. see scheme 201 Insert the water deflector into the rear portion of the door, inboard of the window. Fold the perforated part of the deflector over the door flange. Press in order to secure the water deflector to the door flange. NOTE: When reusing the window belt seal strip, the flange mounting area (2) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (3) back together. see scheme 200
2. Work from one end of the seal strip to the other.
3. Position the door window belt seal strip over the flange of the door inner panel.
4. Position the notch in the window belt seal strip to the rear stationary window frame. NOTE: Do not distort the seal strip.
5. Press down in order engage the door window inner belt seal strip the entire length of the door.
6. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. With the door open, remove the front door bottom sealing strip retainers.
2. Remove the front door bottom sealing strip.

Scheme 122

1. Install the front door bottom sealing strip on to the inside lower door edge.
2. Secure the front door bottom sealing strip by inserting the retainers into the holes in the lower door panel.

1. Remove the rear door bottom sealing strip retainers.
2. Remove the rear door bottom sealing strip.

Scheme 123

1. Install the rear door bottom sealing strip on to the inside lower door edge.
2. Secure the rear door bottom sealing strip by inserting the retainers into the holes in the lower door panel.

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power) .
6. Remove the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Remove the window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-front-door) .
8. Remove the fasteners from the front window channel (2).
9. Carefully pull the window weatherstrip (1) and channel (2) from the door.

Scheme 124

Note. When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.

Scheme 125

1. Prep the weatherstrip for installation.
2. Install the window weatherstrip (1) to the door starting in the top corner working out in both directions. see scheme 204
3. Firmly seat the window weatherstrip to the door. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the window channel fasteners. Tighten the window channel fasteners to 9 N.m (80 in lbs).
5. Install the door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-front-door).
6. Install the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power).
7. Install the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
11. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Move the window to the full down position.
2. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
3. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Remove the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Remove the rear door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door) .
8. Remove the fastener (1) from the division post (2).
9. Remove the rear door stationary window and window weatherstrip assembly (3) from the door. Pull the window weatherstrip out of the door frame. Grasp the division post and pull the assembly forward.
10. Remove the weatherstrip and the rear door stationary window as an assembly.

Note. When reusing the window weatherstrip, the flange mounting area (1) must be pinched together in order to counteract the splaying effect when removed. Use a thumb and an index finger in order to pinch the carrier (2) back together. Work from one end of the weatherstrip to the other.

Scheme 126

1. Prep the weatherstrip for installation.
2. Install the weatherstrip and stationary window into the door. Seat the stationary window into the door frame. Insert the window weatherstrip into the door frame. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the division post fastener (1). Tighten the fastener to 9 N.m (80 in lbs). see scheme 206
4. Install the rear door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door).
5. Install the window outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
6. Install the window inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
9. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Remove the upper door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
2. Remove the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power) .
3. Partially remove the window weatherstrip to access the upper auxiliary molding screws.
4. Remove the auxiliary weatherstrip screws (1-7).
5. Carefully peel the auxiliary weatherstrip away from the door header.

1. Align the rear hole (1) in the weatherstrip to the plastic nut in the door header. see scheme 208
2. Seat the top of the seal lip over the flange.
3. Starting at the rear, roll the weatherstrip over the flange on the door header while holding the weatherstrip lip in order to prevent tucking under against the door.
4. Install the rear screw (1). CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
5. Install the remaining screws. Tighten the screw (1) to 2 N.m (18 in lbs). Tighten the screws (2-7) to 2 N.m (18 in lbs).
6. Install the window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
7. Install the outside rearview mirror. Refer to «MIRROR REPLACEMENT - POWER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__mirror-replacement-power).
8. Install the upper door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front).

1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear) .
2. Remove the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
4. Remove the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
5. Remove the window inner belt seal. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
6. Remove the window outer belt seal. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
7. Remove the door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door) .
8. Remove the rear door stationary window. Refer to «WINDOW/DIVISION CHANNEL - REAR DOOR STATIONARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
9. Remove the rear door upper auxiliary weatherstrip fasteners (1-7).
10. Carefully peel the auxiliary weatherstrip away from the door header.

1. Seat the top of the seal lip over the door header flange.
2. Align the front hole in the weatherstrip to the plastic nut in the door header.
3. Starting at the front, roll the weatherstrip over the flange on the door header while holding the weatherstrip lip in order to prevent the weatherstrip from tucking under against the door.
4. Install the door to door seal on to the forward flange of the door header starting at the top and working towards the bottom.
5. Ensure that the front fastener (1) hole is aligned with the plastic nut in the door header. see scheme 209 CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
6. Install the auxiliary weatherstrip fasteners. Tighten the fasteners, starting with the front fastener (1) to 2 N.m (18 in lbs).
7. Install the rear door stationary window. Refer to «WINDOW/DIVISION CHANNEL - REAR DOOR STATIONARY»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
8. Install the door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__window-replacement-rear-door).
9. Install the window outer belt seal. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
10. Install the window inner belt seal. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
11. Install the energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
12. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
13. Install the door module. Refer to «DOOR CONTROL MODULE REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system).
14. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-rear).

1. Remove the sill plate. Refer to «CARPET RETAINER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Start at the rear upper corner of the door opening and pull the weatherstrip away from the door opening flange.
3. Work around the door opening and remove the weatherstrip.

Scheme 127

1. Position the paint dot in the upper corner of the center pillar. NOTE: One paint dot on the weatherstrip indicates the RH weatherstrip starting point. Two paint dots on the weatherstrip indicates the LH weatherstrip starting point. NOTE: The rubber side of the weatherstrip should be outboard of the car.
2. Working downward along the rear edge, install the weatherstrip on the door opening flange ensuring that the carrier is fully seated in the corners.
3. From the center pillar working forward, install the weatherstrip along the roof rail and the window-pillar flange ensuring that the carrier is fully seated in the corners.
4. Using the palm of your hand or a rubber mallet, ensure that the weatherstrip is seated on the entire door opening flange.
5. Using a plastic trim stick or an equivalent, position the close-out lip over the interior trim around the door opening, or use the ripcord, on new weatherstrip, under the close-out lip, in order to reposition the lip over the interior trim.
6. Install the sill plate. Refer to «CARPET RETAINER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

1. Remove the sill plate. Refer to «CARPET RETAINER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Start at the rear upper corner of the door opening and pull the weatherstrip away from the door opening flange.
3. Work around the door opening and remove the weatherstrip.

Scheme 128

1. Position the paint dot in the upper corner of the center pillar. NOTE: One paint dot on the weatherstrip indicates the RH weatherstrip starting point. Two paint dots on the weatherstrip indicates the LH weatherstrip starting point. NOTE: The rubber side of the weatherstrip should be outboard of the car.
2. Working downward along the front edge, install the weatherstrip on the door opening flange ensuring that the carrier is fully seated in the corners.
3. From the center pillar corner working rearward, install the weatherstrip along the roof rail and the rear of the door opening.
4. Using the palm of your hand or a rubber mallet, ensure that the weatherstrip is seated on the entire door opening flange.
5. Using a plastic trim stick or an equivalent, position the close-out lip over the interior trim around the door opening, or use the pull-string, on new weatherstrip, under the close-out lip, in order to reposition the lip over the interior trim.
6. Install the sill plate. Refer to «CARPET RETAINER REPLACEMENT»(/buick/lesabre/viii-2000-2005/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

MIRROR REPLACEMENT - POWER

Note. Tools Required: Door Trim Pad Clip Remover (J 38778).

Scheme 129

1. Remove the upper door trim panel (1). Use the J 38778 in order to pry out the retainer at the top of the upper door trim panel. Lift the upper door trim panel up in order to remove. Disconnect the wire harness from the tweeter.
2. Remove the insulator (4).
3. Remove the door trim panel in order to gain access to the power mirror wire harness connector (2). Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front) .
4. Disconnect the power mirror wire harness electrical connector (2).
5. Disconnect the wire harness from the retainer clips.
6. Remove the mirror fasteners.
7. Remove the mirror (1) from the door.
8. Pull the wiring harness through the hole (3) in the mirror patch.

1. Route the mirror wiring harness (2) through the hole (3) in the mirror patch. see scheme 213
2. Install the mirror (1) into the door frame. CAUTION: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the mirror fasteners in the following sequence: Tighten the top mirror fastener to 9 N.m (80 in lbs). Tighten the forward mirror fastener to 9 N.m (80 in lbs). Tighten the rear mirror fastener to 9 N.m (80 in lbs).
4. Install the insulator (4).
5. Install the mirror wire harness into the retainer clip (1).
6. Attach the wire clip (1) to the door module (3).
7. Connect the power mirror electrical connector (2) to the door module.
8. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__trim-panel-replacement-side-front). NOTE: Use a new push in fastener when reinstalling the upper door trim panel. This will prevent the upper door trim panel from rattling against the door frame.
9. Install the upper door trim panel (1). see scheme 212 Connect the wire harness to the tweeter. Insert the tabs at the bottom of the upper door trim panel into the slots on the door trim panel. Insert the push in retainer into the door.

1. Remove the mirror and the plastic backing plate assembly (2). Manually tilt the mirror glass (2) inboard towards the vehicle. Insert fingers behind the mirror glass assembly (2). Gently pull the mirror glass assembly (2) from the housing (1).
2. Disconnect the electrical connectors.
3. Remove the actuators (2) that may have remained attached to the mirror face backing (1). Push the actuator in the direction of one of the two slots of the molded ring where the actuator ball attaches in order to disengage it from the mirror glass assembly (1).

Scheme 130

1. Ensure that the actuator springs (7) are not pushed down on the actuator shafts, but are seated in the groove provided. see scheme 215
2. Install the actuator shafts (2) on to the power drive unit (4) by pressing and rotating the actuator on to the power drive unit.
3. Connect the electrical connectors to the mirror glass assembly.
4. Align the mirror face assembly pivot points (3) to the actuator shafts (5) and the memory pins (4). see scheme 215
5. Install the mirror glass assembly. Use a 5 cm by 10 cm (2 in by 4 in) sanding block and firmly press the mirror glass assembly with enough force in order to engage the center pivot point on to the power drive unit. Apply pressure to the top of the mirror glass assembly with the sanding block until an audible snap is heard. Manually tilt the mirror glass assembly outboard away from the vehicle. Apply pressure to the outboard portion of the mirror glass assembly with the sanding block until an audible snap is heard.
6. Ensure proper operation of the outside rear view mirror by operating in all directions.

Scheme 131

1. Remove the mirror and plastic backing plate assembly from the mirror housing (1). Manually tilt the mirror glass inboard towards the vehicle. Insert fingers behind the mirror glass assembly. Gently pull the assembly from the housing.
2. Disconnect the electrical connectors.
3. If one or both of the actuator shaft(s) (2) come off with the mirror glass assembly, push the actuator in the direction of one of the two slots of the molded ring where the actuator ball attaches to and disengage it from the mirror glass assembly.
4. Verify that the springs (7) on the actuator shafts (8) are not pushed down on the shafts. see scheme 219
5. Ensure that the springs (5) are seated in the grooves.

1. Snap the actuator shafts into the power drive unit (8).
2. Connect the electrical connectors.
3. Rotate the actuator shafts in order to align the ears with the corresponding slots in the back side of the mirror face (7).
4. Align the swivel (3) on the power drive unit (8) to the pivot points on the mirror backing plate. NOTE: To avoid damaging electrochromatic mirrors, yellowing and/or silver delamination, pressure must not be applied to the center of the mirror. Place a 6 x 9 cm (2 x 3 in) block of wood in the indicated target area. This will distribute pressure evenly.
5. Hold a block against the mirror face while you perform the following procedure: Push in on the block (6) until you hear a snap. Tilt the mirror (7) toward the upper actuator shaft (2). Apply pressure on the block until the ratchet sound stops. Tilt the mirror (7) toward the outside actuator shaft (4). Apply pressure on the block until the ratchet sound stops.
6. Inspect the mirror for proper operation. If the mirror is not operating properly, inspect the actuator shaft alignments again.

Power Windows System Components

The following components are used to control the power windows

1. Driver Door Module (DDM).
2. Passenger Front Door Module (PDM).
3. LH Rear Door Module (LRDM).
4. RH Rear Door Module (RRDM).
5. Driver Door Switch Assembly (DDSA).
6. RH Front Power Window Switch.
7. LH Rear Power Window Switch.
8. RH Rear Power Window Switch.
9. LH Front Power Window Motor.
10. RH Front Power Window Motor.
11. LH Rear Power Window Motor.
12. RH Rear Power Window Motor.
13. PWR WDO 30 Amp Circuit Breaker.

Power Windows Operation

The vehicle is equipped with power windows controlled by the door modules. Each passenger door power window can be operated, either from a switch built into the Driver Door Switch Assembly (DDSA), or from a switch mounted locally on its associated door.

The driver door power window can only be operated from the driver door window switch built into the Driver Door Switch Assembly (DDSA).

When the Driver Door Module (DDM) receives a window switch request from the DDSA, the DDM checks the Class 2 serial data to see if the status information is correct (i.e. ignition switch position) to permit window operation to occur. If the status information is correct, the DDM, either supplies power and ground to its associated window motor, or, if the request is for one of the passenger windows, sends a command via the power door serial data circuit to the Passenger Door Module (PDM, LRDM, or RRDM) controlling the window. The Passenger Door Module (PDM, LRDM, or RRDM) controlling the window then supplies power and ground to its associated window motor to move the window as requested.

When one of the local window switches mounted on one of the passenger doors is operated, the associated door module examines the request and checks to see if there are any messages from the DDM prohibiting the movement. If conditions are correct, and no prohibitive messages have been received from the DDM, the associated door module then supplies power and ground to its associated window motor to move the window as requested.

Windows Power & Ground

Each door module has its own battery positive voltage supply circuit to use for power window operation, but they are all fed by the same 30 amp power window circuit breaker located in the rear fuse block. Each door module also has a separate ground circuit to use for power window operation. These circuits are in the same dedicated connector as the window motor drive circuits of each door module.

Window Motors

Each door module supplies battery positive voltage and ground, through the window motor drive circuits, to its associated window motor. The window motors are reversible. The direction the window moves depends on which motor drive circuit the battery positive voltage is applied to, and which motor drive circuit the ground is applied to. To move the window in the Up direction, the module applies battery positive voltage to the window motor Up drive circuit, and ground to the window motor Down drive circuit. When a window movement in the opposite direction is needed, the module reverses the polarity and supplies power and ground to the opposite circuits to move the window in the reverse direction.

Windows Express Down Feature

The front door windows have the Express Down feature. This allows the front windows to be fully opened by momentarily pressing the appropriate window switch to the second detente of the Down position.

Window Lockout Feature

The window lockout switch is built into the Driver Door Switch Assembly (DDSA). The lockout function can be programmed to prevent both rear windows from being operated from their locally mounted switches, or, to prevent all of the passenger windows from being operated from their locally mounted switches. When the lockout switch is pressed momentarily, the LED indicator is illuminated, and the DDSA receives the switch signal. The DDSA sends a message over the power door serial data line to the Driver Door Module (DDM) indicating that the switch is active. The DDM then sends a message over the power door serial data line to both rear door modules to prohibit the rear windows from being operated from the rear door window switches, or, sends the message to all of the passenger doors to prohibit all passenger windows from being operated from their respective switches. When the lockout function has been activated, the windows can still be operated from the driver door by using the window switches built into the DDSA.

Power Door Lock Components

The power door lock system consists of the following components

1. Driver door lock switch.
2. Passenger door lock switch.
3. Driver Door Switch Assembly (DDSA).
4. Driver Door Module (DDM).
5. Passenger Door Module (PDM).
6. Left Rear Door Module (LRDM).
7. Right Rear Door Module (RRDM).
8. Driver door lock actuator.
9. Passenger door lock actuator.
10. Left rear door lock actuator.
11. Right rear door lock actuator.
12. Driver door cylinder unlock switch.
13. Passenger door cylinder unlock switch.
14. DRVMDL Fuse (10 amp).
15. PASS MDL Fuse (10 amp).
16. RRDR MDL Fuse (10 amp).

Door Lock System Controls

The power door lock system can be controlled by any of the following

1. A power door lock switch activation.
2. A keyless entry transmission.
3. A driver door key cylinder unlock switch activation.
4. A passenger door key cylinder unlock switch activation.
5. An automatic door lock function.

Power Door Lock Operation

The vehicle is equipped with power door locks. Each lock actuator is powered and controlled by the door module mounted in the individual door. The Driver Door Module (DDM) is the master control for the door lock system but the Rear Integration Module (RIM) determines when the lock functions are permitted.

The passenger front door interior lock switch is wired to the Passenger Front Door Module (PDM). The driver door interior lock switch is wired to the Driver Door Switch Assembly (DDSA). Interior lock switches are not provided for the rear doors. The DDSA and the PDM send the lock switch requests to the Driver Door Module (DDM) over the power door serial data circuit. The DDM then sends the lock requests to the RIM over the Class 2 serial data circuits.

The door lock operation modes are controlled by the RIM. The RIM examines the requested function from the DDM, or the Remote Function Actuator (RFA), as well as the transmission shift selector position and the ignition switch position information available over the Class 2 serial data circuits. If the RIM determines that a lock or unlock function is permitted, it sends a class 2 message back to the DDM commanding the DDM to perform that function. The DDM then sends commands to the rest of the door modules via the power door serial data circuit to implement the selected locking function.

Power Door Lock Motors

Each door module supplies battery positive voltage and ground, through the door lock actuator motor drive circuits to its associated door lock actuator motor. The power door lock motors are reversible. The function performed by the lock motor (Lock or Unlock), depends on which motor drive circuit the battery positive voltage is applied to, and which motor drive circuit the ground is applied to. To perform a lock function, the module applies battery positive voltage to the door lock motor Lock circuit, and ground to the door lock motor Unlock circuit. To perform a Unlock function, the module reverses the polarity and applies battery positive voltage to the door lock motor Unlock circuit, and ground to the door lock motor Lock circuit.

Front Passenger Door Power Lock Switch

In order to receive a signal from its associated door lock switch, the front passenger door module supplies battery positive voltage and ground to the switch. Their are two circuits for battery positive voltage, one for a lock signal, and one for an unlock signal. The module supplies ground to the switch via a third circuit. When the switch is activated for a lock or unlock function, voltage flows through the switch, providing the module with the necessary signal input.

Driver Door Power Lock Switch

The driver door lock switch is the same as the passenger door lock switch, but it is wired to the Driver Door Switch Assembly (DDSA), and, for a ground circuit, to the driver door module. It also works the same way as the passenger lock switch works, but the switch signal input information is detected and processed by the DDSA. The DDSA has two circuits that supply 5 volts to the driver door lock switch, one for a lock signal, and one for an unlock signal. The driver door lock switch ground circuit is provided by the driver door module. When the door lock switch is activated, the voltage that flows through it is detected by the DDSA. The DDSA then relays the switch information to the driver door module via the power door serial data circuit.

Automatic Door Locks

The automatic door lock system provides for locking or unlocking all or one of the doors when shifting the transmission in and out of PARK, or, when turning the ignition key to the OFF position. This system is commanded according to the information stored in the RIM. The RIM receives the features selected by the driver from the Driver Information Center (DIC). The RIM commands the Driver Door Module (DDM) which in turn commands the individual passenger door modules. For customized selections available and programming instructions, refer to PERSONALIZATION DESCRIPTION & OPERATION in Personalization.

Anti-Lockout feature

Leaving the key in the ignition with any door open will disable the use of the power door locks and the Remote Keyless Entry (RKE) lock function.

The anti-lockout feature can be overridden by holding the lock switch in the LOCK position for more than 3 seconds.

Central Door Unlock

The central door unlock feature is activated when the driver door key is inserted into, either the driver door lock cylinder, or, the front passenger door lock cylinder, and turned to the Unlock position. The doors will unlock when either of the following happens

1. The DDM sees that its door cylinder switch is continuously closed for longer than 3 seconds.
2. The DDM sees that its door cylinder switch is closed twice in 3 seconds.
3. The PDM sends a message over the power door serial data circuit to the DDM indicating that the passenger door cylinder switch is continuously closed for longer than 3 seconds.
4. The PDM sends a message over the power door serial data circuit to the DDM indicating that the passenger door cylinder switch has been closed twice in 3 seconds.

The DDM sends a Class 2 message to the RIM indicating the above. The RIM sends a Class 2 message to the DDM to unlock all doors. The DDM sends a power door serial data message to the other door modules to unlock all doors.

The door cylinder switches are a built in part of each doors actuator assembly and are wired to either, the Driver Door Module (DDM) or the front Passenger Door Module (PDM). Each door cylinder switch is connected to its exterior door key cylinder by means of a mechanical rod. Each door module supplies battery positive voltage through the door key switch signal circuit, and ground via a ground circuit to the normally open contacts of its respective switch. When the switch is closed, voltage flows through the switch, providing the door module with the necessary signal input.

Delayed Locking feature

This personalization feature permits the delay of all door locking until 5 seconds after the last door is closed. This feature is controlled by the RIM which operates based on data received over the Class 2 serial data circuits.

1. When the lock function is requested (either by the Remote Function Actuator (RFA) or the DDM) while the drivers door is open and the ignition key is removed from the ignition, the RIM commands the radio, via the Class 2 serial data circuit, to sound the chime 3 times to signal that the delayed locking is active.
2. When the DDM detects that the driver door is closed, and receives the message from the other door modules that their respective doors are also closed, it sends a Class 2 message to the RIM.
3. The RIM waits for 5 seconds, then sends the Class 2 message to the DDM to lock doors. The DDM sends the power door serial data message to the rest of the door modules to lock the doors. If a door is opened during the 5 second delay period, the RIM resets the timer and waits until it again receives the doors closed message from the DDM to restart the delay period. Pressing a power lock switch on a door or on the remote transmitter for the RFA causes the RIM to override this feature and lock all doors immediately. To program the delayed locking feature, refer to «PERSONALIZATION DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__personalization-description-operation) in Personalization.

PERSONALIZATION DESCRIPTION & OPERATION

Personalization features may be set for the vehicle or the driver. Vehicle features do not change with each driver. Specific drivers are recognized by the vehicle through the keyless entry transmitters, the memory buttons, or the Driver Information Center (DIC), and the personalization settings for that driver are recalled.

For more information on vehicle personalization features for this vehicle, refer to Vehicle Personalization .

For more information on driver personalization features for this vehicle, refer to Driver Personalization .

Vehicle Personalization

Chime Level Adjustment In order to adjust the chime level, perform the following steps

1. Turn the ignition ON.
2. Turn the radio OFF.
3. Press and hold the radio push-button 6 until either LOD or SF appears on the radio display.
4. To toggle the setting, press and hold the radio push-button 6 again.

Refer to AUDIBLE WARNINGS DESCRIPTION & OPERATION in Instrument Panel, Gages, & Console for more information about the chime.

Level 1 (Custom Only)

The following features may be personalized as part of level 1 personalization

1. Automatic door locks.
2. Delayed locking.
3. Perimeter lighting.
4. Remote Activation Verification (RAV).

Level 2 (Custom & LTD)

The following features may be personalized as part of level 2 personalization

1. Automatic door locks.
2. Delayed locking.
3. Driver ID greeting.
4. Perimeter lighting.
5. Perimeter lighting timer.
6. Remote Activation Verification (RAV).
7. Window lock-out.

Level 3 (LTD Only)

The following features may be personalized as part of level 3 personalization

1. Automatic door locks.
2. Delayed locking.
3. Driver ID greeting.
4. Memory seat options.
5. Parallel park assist.
6. Perimeter lighting.
7. Perimeter lighting timer.
8. Remote Activation Verification (RAV).
9. Window lock-out.

The following are the modes of operation for the automatic door locks feature

1. Mode 0 The automatic door locks feature is disabled.
2. Mode 1 All of the doors lock when the vehicle is shifted out of PARK with the ignition ON.
3. Mode 2 All of the doors lock when the vehicle is shifted out of PARK with the ignition ON. Only the driver door unlocks when the vehicle is shifted into PARK.
4. Mode 3 (Default) All of the doors lock when the vehicle is shifted out of PARK with the ignition ON. All of the doors unlock when the vehicle is shifted into PARK.

Delayed Locking

The following are the modes of operation for the delayed locking feature

1. On All of the doors lock 5 seconds after the last door is closed when the lock switch is activated.
2. Off (Default) The delayed locking feature is disabled.

Perimeter Lighting

The following are the modes of operation for the perimeter lighting feature

1. On (Default) The perimeter lights illuminate with a keyless entry transmitter signal.
2. Off The perimeter lights do not illuminate with a keyless entry transmitter signal.

Remote Activation Verification

The following are the modes of operation for the remote activation verification feature

1. Mode 1 (Default) The remote activation verification feature is disabled.
2. Mode 2 Only the exterior lamps flash.
3. Mode 3 Only the horn chirps.
4. Mode 4 The exterior lamps flash, and the horn chirps.

Passenger Window Lockout

The following are the modes of operation for the passenger window lockout feature

1. Mode 0 Lock out rear windows only.
2. Mode 1 (Default) Lock out all of the passenger windows.

Memory Seats Programming

Perform the following actions in order to program the memory seats

1. Move the seat to the desired position.
2. Press and hold the correct memory seat button for the driver until you hear two beeps.
3. Move the seat to the desired EXIT position.
4. Press and hold the EXIT button until you hear two beeps.
5. Repeat steps 1 - 4 for the other driver.

Programming Features On Vehicles Without DIC

Note. Transmitter 1 and transmitter 2 may be programmed separately for two different drivers. When programming the personalization features using the keyless entry transmitters, be sure to use the correct transmitter for the driver whose features are currently being programmed.

Enter Programming

Perform the following actions in order to enter programming

1. Turn the ignition to RUN.
2. Place the vehicle in PARK.
3. Close all of the doors.
4. Depress and hold the driver side power door lock switch during the entire personalization programming session. The doors will lock to confirm program mode.

Continue with the following steps in order to personalize the automatic door locks

1. Press the LOCK button on the correct keyless entry transmitter. The vehicle will remain in the current mode and will react according to the current mode settings. See «Automatic Door Locks»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) modes above.
2. Press the LOCK button on the keyless entry transmitter again in order to advance to the next mode. Again the vehicle will react according to the mode settings.
3. Continue to press the LOCK button on the keyless entry transmitter until the desired mode is reached.

Continue with the following steps in order to personalize the delayed locking feature

1. Press the UNLOCK button on the correct keyless entry transmitter.
2. The door locks signal the current mode. If the delayed locking feature is ON, the doors lock. If the delayed locking feature is OFF, the doors unlock.
3. Press the UNLOCK button on the keyless entry transmitter again in order to advance to the next mode. The door locks lock or unlock to signal the mode change.

Continue with the following steps in order to personalize the remote activation verification feature

1. Press the rear compartment release button on the correct keyless entry transmitter. The vehicle will remain in the current mode, and the horn will chirp once.
2. Press the rear compartment release button on the keyless entry transmitter again to advance to the next mode. See «Remote Activation Verification»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__remote-activation-verification) modes above for mode descriptions. The horn will chirp once.
3. Continue to press the rear compartment release button until the desired mode is reached.

Continue with the following steps in order to personalize the perimeter lighting

1. Press the panic button on the correct keyless entry transmitter.
2. The horn signals the current mode. If the perimeter lighting feature is ON, the horn will chirp twice. If the perimeter lighting feature is OFF, the horn will chirp once.
3. Press the panic button on the keyless entry transmitter again in order to advance to the next mode. The horn will chirp to signal the mode change.

Exit Programming

Any of the following events will cause the programming sequence to be terminated

1. The ignition is moved from the RUN position.
2. The key is used to manually unlock the door, and the door is opened.
3. The driver side power door lock switch is released.
4. The programming time of 2 minutes expires.

To enter programming with the DIC, perform the following actions

1. Turn the ignition to RUN.
2. Place the vehicle in PARK.
3. Press the ENG/MET button for 5 seconds.
4. The DIC displays WELCOME TO BUICK OPTION FEATURE then PRESS ENG/MET TO SELECT OPTIONS then PRESS RESET TO GO TO NEXT CHOICE.
5. The DIC then displays DRIVER #: 1 2. An arrow is shown next to the current driver.
6. Press the ENG/MET button in order to change the driver # for this programming session.
7. Press the RESET button in order to advance to the next option.

Continue with the following steps in order to personalize the automatic door locks

1. The DIC displays AUTO DOOR LOCKS: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.
4. If the previous choice was AUTO DOOR LOCKS ON, the DIC displays UNLOCK: OFF/ON.
5. Press the ENG/MET button in order to place the arrow before the desired choice.
6. Press the RESET button in order to advance to the next option.
7. If the previous choice was UNLOCK ON, the DIC displays UNLOCK: KEY OFF/PARK.
8. Press the ENG/MET button in order to place the arrow before the desired choice.
9. Press the RESET button in order to advance to the next option.
10. The DIC displays DOOR TO UNLOCK: DRIVER/ALL.
11. Press the ENG/MET button in order to place the arrow before the desired choice.
12. Press the RESET button in order to advance to the next option.

Passenger Window Lock-Out

Continue with the following steps in order to personalize the passenger window lock-out feature

1. The DIC displays WINDOW LOCKOUT: REAR/R+PASS.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.

Continue with the following steps in order to personalize the remote activation verification feature

1. The DIC displays KEYLESS FEEDBACK: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.
4. If the previous choice was KEYLESS FEEDBACK ON, the DIC displays LIGHTS FEEDBACK: OFF/ON.
5. Press the ENG/MET button in order to place the arrow before the desired choice.
6. Press the RESET button in order to advance to the next option.
7. The DIC displays HORN FEEDBACK: OFF/ON.
8. Press the ENG/MET button in order to place the arrow before the desired choice.
9. Press the RESET button in order to advance to the next option.

Continue with the following steps in order to personalize the delayed locking feature

1. The DIC displays DELAYED LOCKING: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.

Continue with the following steps in order to personalize the perimeter lighting

1. The DIC displays PERIMETER LIGHTS: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.
4. If the previous choice was PERIMETER LIGHTS ON, the DIC displays EXTERIOR LIGHTS TIME-OUT 5/10/15/20/25/30.
5. Press the ENG/MET button in order to place the arrow before the desired choice.
6. Press the RESET button in order to advance to the next option.

Memory Seats

Continue with the following steps in order to personalize the memory seat recall

1. The DIC displays SEAT RECALL: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.
4. If the last choice was SEAT RECALL ON, the DIC displays RECALL MEMORY POSITION: MEMORY/EXIT.
5. Press the ENG/MET button in order to place the arrow before the desired choice.
6. Press the RESET button in order to advance to the next option.

Parallel Park Assist

Continue with the following steps in order to personalize the parallel park assist feature

1. The DIC displays TILT MIRRORS: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.

Driver ID

Continue with the following steps in order to personalize the driver ID

1. The DIC displays DRIVER ID: OFF/ON.
2. Press the ENG/MET button in order to place the arrow before the desired choice.
3. Press the RESET button in order to advance to the next option.

When the programming is complete, OPTION FEATURE SELECTION DONE appears on the display. To exit programming before the list is complete, perform any of the following actions

1. Press any of the following DIC buttons: ODO/TRIP FUEL INFO GAGE INFO
2. Turn the key from the RUN position.

Programming Features With The Tech 2

To enter programming with the Tech 2, perform the following actions

1. Install the scan tool.
2. Turn ON the ignition with the engine OFF.
3. Select the correct vehicle and model year.
4. Select Body.
5. Select Personalization.

Continue with the following steps in order to enter a new driver ID

1. Select Driver Information Center.
2. Select Driver #1 or Driver #2.
3. Select Driver #1 Name or Driver #2 Name (depending on your previous choice).
4. Spell the ID with the Tech 2 keys.
5. Select Save Options.
6. Exit the menu.

Continue with the following steps in order to turn the driver ID on or off.

1. Select Set Options.
2. Select Driver #1 ID Displayed or Driver #2 ID Displayed.
3. Highlight Driver #1 ID Display or Driver #2 ID Display (depending on your previous choice) and press the ENTER button to turn the selection ON or OFF. An asterisk appears when the feature is turned ON.
4. Select Save Options.
5. Exit the menu.

Continue with the following steps in order to program the delayed locking feature

1. Select Set Options.
2. Select Driver #1 Delayed Locking or Driver #2 Delayed Locking.
3. Highlight Delay Locking and press the ENTER button to turn the selection ON or OFF. An asterisk appears when the feature is ON.
4. Select Save Options.
5. Exit the menu.

Continue with the following steps in order to program the remote activation verification feature

1. Select Set Options.
2. Select Driver #1 Activation Verification or Driver #2 Activation Verification.
3. Highlight the desired mode from the following choices: See «Remote Activation Verification»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__remote-activation-verification) modes above for mode descriptions. Mode 1 Mode 2 Mode 3 Mode 4
4. Press the ENTER button to turn the mode ON or OFF. (You must turn the current mode OFF before you can turn another one ON.)
5. Select Save Options.
6. Exit the menu.

Continue with the following steps in order to program the perimeter lighting feature

1. Select Set Options.
2. Select Driver #1 Perimeter Lighting or Driver #2 Perimeter Lighting.
3. Highlight Perimeter Lighting and press the ENTER button to turn it ON or OFF. An asterisk appears when it is ON.
4. Select Save Options.
5. Exit the menu.
6. If the previous choice was perimeter lighting feature ON, select Driver #1 Perimeter Light Timer or Driver #2 Perimeter Light Timer.
7. Choose the desired time from the following selections: Delay 5 Seconds. Delay 10 Seconds. Delay 15 Seconds. Delay 20 Seconds. Delay 25 Seconds. Delay 30 Seconds.
8. Select Save Options.
9. Exit the menu.

Continue with the following steps in order to program the passenger window lock-out feature

1. Select Set Options.
2. Select Driver #1 Pass. Window Lock-out or Driver #2 Pass. Window Lock-out.
3. Highlight Include Front Pass. Window Lockout and press the ENTER button to turn the selection ON or OFF. An asterisk appears when the feature is ON.
4. Select Save Options.
5. Exit the menu.

Continue with the following steps in order to program the automatic door locks feature

1. Select Set Options.
2. Select Driver #1 Automatic Door Lock Mode or Driver #2 Automatic Door Lock Mode.
3. Highlight the desired mode from the following choices: See «Automatic Door Locks»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) modes above for mode descriptions. Mode 0. Mode 1. Mode 2. Mode 3. Mode 4. Mode 5.
4. Press the ENTER button to turn the mode ON or OFF. (You must turn the current mode OFF before you can turn another one ON.)
5. Select Save Options.
6. Exit the menu.

Continue with the following steps in order to program the memory seat recall

1. Select Set Options.
2. Select Driver #1 Memory Recall or Driver #2 Memory Recall.
3. Highlight the desired setting from the following choices: Remote Entry Recall Driver Seat. Recall Exit on RKE Unlock.
4. Press the ENTER button to turn the setting ON or OFF. An asterisk appears when the feature is turned ON.
5. Select Save Options.
6. Exit the menu.

Continue with the following steps in order to program the parallel park assist feature

1. Select Set Options.
2. Select Driver #1 Curb View or Driver #2 Curb View.
3. Highlight Parallel Park Assist and press the ENTER button to turn the selection ON or OFF. An asterisk appears when the feature is ON.
4. Select Save Options.
5. Exit the menu.

Additional Information

For more information on the personalization features, refer to one of the following description and operations

1. Refer to «POWER DOOR LOCKS DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) for more information about the following features: Automatic door locks. Delayed locking.
2. Refer to «DRIVER INFORMATION CENTER (DIC) DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/gauges-instrument-panels/#instrument-panel-gauges-console) in Instrument Cluster, Gauges, and Console for more information about the driver ID.
3. Refer to «MEMORY SEATS DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/seats/#power-seat-system__memory-seats-description-operation) in Seats for more information about the memory seats options.
4. Refer to «OUTSIDE MIRROR DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) for more information about the parallel park assist feature.
5. Refer to «POWER WINDOWS DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) for more information about the passenger window lock-out feature.
6. Refer to «KEYLESS ENTRY SYSTEM DESCRIPTION & OPERATION»(/buick/lesabre/viii-2000-2005/remont/door-locks-anti-theft-systems/#keyless-entry-system) in Keyless Entry for more information about the remote activation verification feature.

Door Ajar Indicator System Components

The door ajar indicator system consists of the following components

1. Driver Door Module (DDM).
2. Passenger Door Module (PDM).
3. Left Rear Door Module (LRDM).
4. Right Rear Door Module (RRDM).
5. Instrument Panel Cluster (IPC).
6. LH Front Door Ajar Switch.
7. RH Front Door Ajar Switch.
8. LH Rear Door Ajar Switch.
9. RH Rear Door Ajar Switch.

The following are the Driver Information Center (DIC) messages associated with the power door system.

Driver Door Ajar (140)

The Driver Door Module (DDM) receives a discrete input from the driver ajar switch. The IPC receives the status of the driver door from the Driver Door Module (DDM) via class 2 serial data message. When the driver door is open and the vehicle is out of the PARK gear, the IPC displays the message. Also, if the vehicle speed is greater than 4.8 km/h (3 mph), the IPC displays the message and sends a class 2 serial data message requesting 5 chimes to sound.

Passenger Door Ajar (141)

The Passenger Door Module (PDM) receives a discrete input from the passenger ajar switch and sends the status to the Driver Door Module (DDM) via the power door serial data circuit. The IPC receives the status of the passenger door from the Driver Door Module (DDM) via class 2 serial data message. When the passenger door is open and the vehicle is out of the PARK gear, the IPC displays the message. Also, if the vehicle speed is greater than 4.8 km/h (3 mph), the IPC displays the message and sends a class 2 serial data message requesting 5 chimes to sound.

Left Rear Door Ajar (142)

The LH Rear Door Module (LRDM) receives a discrete input from the LH rear ajar switch and sends the status to the Driver Door Module (DDM) via the power door serial data circuit. The IPC receives the status of the LH rear door from the Driver Door Module (DDM) via class 2 serial data message. When the LH rear door is open and the vehicle is out of the PARK gear, the IPC displays the message. Also, if the vehicle speed is greater than 4.8 km/h (3 mph), the IPC displays the message and sends a class 2 serial data message requesting 5 chimes to sound.

Right Rear Door Ajar (143)

The RH Rear Door Module (RRDM) receives a discrete input from the RH rear ajar switch and sends the status to the Driver Door Module (DDM) via the power door serial data circuit. The IPC receives the status of the RH rear door from the Driver Door Module (DDM) via class 2 serial data message. When the RH rear door is open and the vehicle is out of the PARK gear, the IPC displays the message. Also, if the vehicle speed is greater than 4.8 km/h (3 mph), the IPC displays the message and sends a class 2 serial data message requesting 5 chimes to sound.

Outside Mirror System Components

The power outside mirror system consists of the following components

1. Driver Door Switch Assembly (DDSA).
2. Driver Door Module (DDM).
3. Passenger Door Module (PDM).
4. Driver outside mirror.
5. Passenger outside mirror.
6. Power door serial data circuit.
7. DRV MDL 10A fuse, door module logic and internal driver operation.
8. PASS MDL 10A fuse, door module logic and internal driver operation.

Driver & Passenger Outside Mirror Operation

In order to control outside rear view mirror adjustments, two switches are contained within the Driver Door Switch Assembly (DDSA). The DDSA contains a built in mirror select switch and a built in mirror position switch. The DDSA reports the switch activity to the Driver Door Module (DDM) via the power door serial data circuit.

The mirror select switch is used to select which mirror, left or right, is to be moved.

The mirror position switch is used to move the mirror that has been selected to the desired position.

When the mirror position switch is activated in a Up, Down, Left, or Right direction, the DDSA recognizes the input and sends this data on to the DDM.

Depending on which mirror has been selected for adjustment, the DDM either moves the driver door mirror to the requested position, or sends a power door serial data message to the Passenger Door Module (PDM) indicating that the passenger door mirror needs to be moved. The PDM then moves the passenger door mirror to the requested position.

Each mirror has two reversible motors for position adjustment. The door modules control the reversible motors by supplying battery positive voltage (B+) and ground to these motors.

LH Mirror

For a LH mirror left movement, the driver door module supplies battery positive voltage (B+) via the left mirror motor left circuit, and ground via the left mirror motor right circuit to the LH mirror horizontal motor. For a LH mirror right movement, the driver door module reverses the polarity and supplies battery positive voltage (B+) via the left mirror motor right circuit, and ground via the left mirror motor left circuit to the LH mirror horizontal motor. For a LH mirror up movement, the driver door module supplies battery positive voltage (B+) via the left mirror motor up circuit, and ground via the left mirror motor down circuit to the LH mirror vertical motor. For a LH mirror down movement, the driver door module reverses the polarity and supplies battery positive voltage (B+) via the left mirror motor down circuit, and ground via the left mirror motor up circuit to the LH mirror vertical motor.

RH Mirror

For a RH mirror left movement, the passenger door module supplies battery positive voltage (B+) via the right mirror motor left circuit, and ground via the right mirror motor right circuit to the RH mirror horizontal motor. For a RH mirror right movement, the passenger door module reverses the polarity and supplies battery positive voltage (B+) via the right mirror motor right circuit, and ground via the right mirror motor left circuit. For a RH mirror up movement, the passenger door module supplies battery positive voltage (B+) via the right mirror motor up circuit, and ground via the right mirror motor down circuit to the RH mirror vertical motor. For a RH mirror down movement, the passenger door module reverses the polarity and supplies battery positive voltage (B+) via the right mirror motor down circuit and ground via the right mirror motor up circuit.

Memory Mirrors (A45) Personalization Option

The vehicle may be equipped with the "personalization package" containing memory seats and memory mirrors. However, the front door modules cannot perform memory mirror functions unless the Personalization Option is activated. The Dash Integration Module (DIM) stores the vehicles Personalization Option setting provided at the assembly plant. The DIM reports this Personalization Option setting to both front door modules, as well as other receiving modules, each time the ignition switch is cycled to RUN. The front door modules then store the Personalization Option setting and examine it before making a memory mirrors adjustment.

The Personalization Option setting stored within the front door modules will not change until the Personalization Option setting within the DIM is changed and the ignition switch then cycled to RUN

If the Personalization Option is activated on a vehicle that is not equipped with A45, the door modules will erroneously set DTCs B1583, B1593, B1613, and B1623.

Memory Mirrors (A45) Operation

The vehicle may be equipped with the "personalization package" containing memory seats and memory mirrors. The memory mirrors are controlled by the Driver Door Switch Assembly (DDSA), the Driver Door Module (DDM), and the Passenger Door Module (PDM). The DDSA is used in decoding memory switch activations and the door modules are used to store mirror position information and move the mirrors.

When a mirror position is programmed into the personalization package, the door modules store the position information and assign it to the personalization code. During a memory recall, that personalization code is retrieved by the modules. The modules then check the current position of the mirrors and move them to the position matching the retrieved code.

Each mirror is equipped with 2 potentiometer type position sensors and circuits that provide constant information, in the form of feedback voltage, to each door module indicating the position of the mirrors on their horizontal and vertical axis. The mirror position sensors are attached to each mirror motor's transmission cable. When the cable rotates, the resistance of the sensors vary and the feedback voltage is monitored by the appropriate door module to determine the mirrors position. The sensor feedback voltage varies from 0.25 volts to 4.75 volts. Each door module also supplies reference voltage through a 5-volt reference circuit, and ground through a memory seat/mirror sensor low reference circuit to their respective mirror position sensors.

The driver door module receives feedback voltage from the LH mirror horizontal position sensor through the left mirror horizontal position sensor signal circuit and feedback voltage from the LH mirror vertical position sensor through the left mirror vertical position sensor signal circuit.

The passenger door module receives feedback voltage from the RH mirror horizontal position sensor through the right mirror horizontal position sensor signal circuit and feedback voltage from the RH mirror vertical position sensor through the right mirror vertical position sensor signal circuit.

When a memory Set command is received, each door module records the motor positions by storing the feedback voltage of their respective position sensors. When a memory Recall command is received. Each door module moves the motors until the position sensor feedback voltages equal the feedback voltages stored in memory.

Memory Mirrors (A45) Parallel Parking Mode

If the vehicle is equipped with memory mirrors, it is equipped with the parallel parking mode feature. For this feature, the driver door module communicates with the Powertrain Control Module (PCM) over the class 2 data link. When the gear selector is shifted to reverse, the PCM transmits this status via a class 2 message to the driver door module. The driver door module sends this message on to the passenger door module over the power door serial data circuit. The Passenger Front Door Module (PDM) then supplies battery positive voltage and ground to the vertical motor of the RH outside rear view mirror to tilt the mirror down 7 degrees. This allows the driver to see the curb while parallel parking.

Heated Mirrors

The mirrors heat during the defrost/defog cycles for the rear window. The heated mirrors are connected to the Driver Door Module (DDM) and the Passenger Front Door Module (PDM). The DDM receives a class 2 message from the Instrument Panel Cluster (IPC) via the Rear Integration Module (RIM) commanding the heated mirrors ON. The DDM also examines information from the Dash Integration Module (DIM) to determine if vehicle conditions are correct for the heated mirrors function to occur. If conditions are correct, the DDM then commands the driver side mirror heater ON, and sends a power door serial data message to the Passenger Front Door Module (PDM) to command the passenger side mirror heater ON.

The DDM supplies battery positive voltage to the LH outside rearview mirror heating element via the feed circuit, and ground via the return circuit.

The PDM supplies battery positive voltage to the RH outside rearview mirror heating element via the feed circuit, and ground via the return circuit.

Automatic Day/Night Feature Operation

The automatic day/night feature of the driver outside rearview mirror is controlled by the inside rearview mirror. The inside rearview mirror supplies a signal and a low reference to the driver outside rearview mirror. The voltage on the signal circuit of the driver outside rearview mirror varies between 0.5-1.5 volts depending on light conditions present at the inside rearview mirror. At night, with the automatic day-night feature enabled, the driver outside rearview mirror will automatically darken with the inside rearview mirror to reduce the glare from the headlamps from behind. The voltage on the signal circuit of the driver outside rearview mirror will be near 1.5 volts. In the daytime, the mirrors are in a normal state. The voltage on the signal circuit of the driver outside rearview mirror may be less than or near 0.5 volts. Refer to INSIDE REARVIEW MIRROR DESCRIPTION & OPERATION in Stationary Windows for further description and operation of the inside rearview mirror.

Scheme 132

Scheme 133

See also:
• BODY CONTROL MODULE (BCM) PROGRAMMING/RPO CONFIGURATION (DIM)
• TESTING FOR INTERMITTENT & POOR CONNECTIONS
• GARNISH MOLDING REPLACEMENT - CENTER PILLAR
• SEAT BACK REPLACEMENT - REAR
• CARPET RETAINER REPLACEMENT
• AUDIBLE WARNINGS DESCRIPTION & OPERATION
• DRIVER INFORMATION CENTER (DIC) DESCRIPTION & OPERATION
• MEMORY SEATS DESCRIPTION & OPERATION
• KEYLESS ENTRY SYSTEM DESCRIPTION & OPERATION
• INSIDE REARVIEW MIRROR DESCRIPTION & OPERATION
• DIAGNOSTIC SYSTEM CHECK - DOOR SYSTEMS
• CHECKING AFTERMARKET ACCESSORIES
• TRIM PANEL REPLACEMENT - SIDE FRONT DOOR
• TRIM PANEL REPLACEMENT - SIDE REAR DOOR
• LOCK STRIKER ADJUSTMENT - DOOR
• MIRROR REPLACEMENT - POWER
• WINDOW REPLACEMENT - FRONT DOOR
• DOOR ADJUSTMENT
• WINDOW REPLACEMENT - REAR DOOR
• PERSONALIZATION DESCRIPTION & OPERATION
• Remote Activation Verification
