Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Center Support Bracket Bolts | 10 N.m | 88 lb in |
| Front Bumper Fascia Lower Center Support Bracket Bolts | 10 N.m | 88 lb in |
| Front Bumper Fascia Side Support to Radiator Support Bolts | 10 N.m | 88 lb in |
| Front Bumper Fascia Side Supports Bolts | 10 N.m | 88 lb in |
| Front Bumper Fascia to Fender Bolts | 10 N.m | 88 lb in |
| Front Bumper Fascia Upper Support at Radiator Support Bolts | 10 N.m | 88 lb in |
| Front Bumper Impact Bar at Frame Bolts | 25 N.m | 18 lb ft |
| Grille Studs Nuts | 5 N.m | 44 lb in |
| Rear Bumper Fascia Outer Retainer Bolt | 10 N.m | 88 lb in |
| Rear Bumper Fascia Outer Retainer in Rear Compartment Bolt | 6 N.m | 53 lb in |
| Rear Bumper Fascia Outer Retainer Nut | 6 N.m | 53 lb in |
| Rear Bumper Fascia Splash Shield to Body Bolts | 2 N.m | 18 lb in |
| Rear Bumper Fascia Splash Shield to Body Nut | 2 N.m | 18 lb in |
| Rear Bumper Impact Bar at Frame Bolts | 25 N.m | 18 lb ft |
| Upper Front Bumper Fascia Support Bolts | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Inspection After Collision
If a severe collision dislodges the bumper from the original position, you may need to replace the following components
- The bumper fascia
- The bumper energy absorber
- The bumper impact bar
Scheme 8
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in General Information. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Front Fascia Replacement Preliminary Procedures Remove the upper and lower fascia grilles. Refer to Fascia Grille Replacement - Front Bumper - Lower . Remove fog lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . Remove turn signal lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . | |
| 1 | Screw, Front Fascia (Qty: 4) Tighten: 2 N.m (18 lb in) |
| 2 | Nut, Front Fascia (Qty: 4) Tighten: 10 N.m (88 lb in) |
| 3 | Retainer, Front Fascia (Qty: 6) |
| 4 | Retainer, Front Fascia (Qty: 2) |
| 5 | Retainer, Front Fascia (Qty: 2) |
| 6 | Retainer, Absorber (Qty: 3) |
| 7 | Fascia, Front Bumper Fascia |
| Front Bumper Absorber Replacement Preliminary Procedures Remove fog lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . Remove turn signal lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . | |
| 1 | Screw, Front Fascia (Qty: 4) Tighten: 2 N.m (18 lb in) |
| 2 | Nut, Front Fascia (Qty: 4) Tighten: 10 N.m (88 lb in) |
| 3 | Retainer, Front Fascia (Qty: 6) |
| 4 | Retainer, Front Fascia (Qty: 2) |
| 5 | Retainer, Front Fascia (Qty: 2) |
| 6 | Retainer, Absorber (Qty: 3) |
| 7 | Fascia, Front Bumper Fascia |
| 8 | Absorber, Front Bumper |
| Front Bumper Impact Bar Replacement Preliminary Procedures Remove fog lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . Remove turn signal lamp. Refer to Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front . | |
| 1 | Screw, Front Fascia (Qty: 4) Tighten: 2 N.m (18 lb in) |
| 2 | Nut, Front Fascia (Qty: 4) Tighten: 10 N.m (88 lb in) |
| 3 | Retainer, Front Fascia (Qty: 6) |
| 4 | Retainer, Front Fascia (Qty: 2) |
| 5 | Retainer, Front Fascia (Qty: 2) |
| 6 | Retainer, Absorber (Qty: 3) |
| 7 | Fascia, Front Bumper Fascia |
| 8 | Absorber, Front Bumper |
| 9 | Bolt, Front Bumper Impact Bar (Qty: 4) Tighten: 25 N.m (18 lb ft) |
| 10 | Bar, Front Bumper |
| NOTE |
|---|
| Refer to Fastener Notice in General Information. |
Fascia, Absorber, Reinforcement Replacement - Front Bumper
Scheme 9
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in General Information. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures: Remove the license lamp. Refer to Tail Lamp, Turn Signal Lamp, High Mount Stop Lamp, License Lamp, Backup Lamp Replacement - Rear in Lighting Systems. | |
| Rear Fascia Replacement | |
| 1 | Retainer, Rear Fascia (Qty: 2) |
| 2 | Retainer, Rear Fascia (Qty: 4) |
| 3 | Nut, Rear Fascia (Qty: 2) Tighten: 6 N.m (53 lb in) |
| 4 | Bolt, Rear Fascia (Qty: 2) Tighten: 10 N.m (88 lb in) |
| 5 | Bolt, Rear Fascia (Qty: 6) Tighten: 10 N.m (88 lb in) |
| 6 | Fascia, Rear Fascia |
| Rear Energy Absorber Replacement | |
| 1 | Retainer, Rear Fascia (Qty: 2) |
| 2 | Retainer, Rear Fascia (Qty: 4) |
| 3 | Nut, Rear Fascia (Qty: 2) Tighten: 6 N.m (53 lb in) |
| 4 | Bolt, Rear Fascia (Qty: 2) Tighten: 10 N.m (88 lb in) |
| 5 | Bolt, Rear Fascia (Qty: 6) Tighten: 10 N.m (88 lb in) |
| 6 | Fascia, Rear Fascia |
| 7 | Retainer, Energy Absorber (Qty: 1) |
| 8 | Absorber, Rear Energy Absorber |
| Rear Impact Bar Replacement | |
| 1 | Retainer, Rear Fascia (Qty: 2) |
| 2 | Retainer, Rear Fascia (Qty: 4) |
| 3 | Nut, Rear Fascia (Qty: 2) Tighten: 6 N.m (53 lb in) |
| 4 | Bolt, Rear Fascia (Qty: 2) Tighten: 10 N.m (88 lb in) |
| 5 | Bolt, Rear Fascia (Qty: 6) Tighten: 10 N.m (88 lb in) |
| 6 | Fascia, Rear Fascia |
| 7 | Retainer, Energy Absorber (Qty: 1) |
| 8 | Absorber, Rear Energy Absorber |
| 9 | Bolts, Rear Impact Bar (Qty: 6) Tighten: 25 N.m (18 lb ft) |
| 10 | Bar, Rear Impact Bar |
| NOTE |
|---|
| Refer to Fastener Notice in General Information. |
Fascia, Bracket, Bar, Absorber Replacement - Rear Bumper
Scheme 10
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in General Information. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures: Raise and support vehicle. Refer to Lifting and Jacking the Vehicle . | |
| 1 | Screw, Air Deflector (Qty: 4) Tighten: 2 N.m (18 lb in) |
| 2 | Screw, Air Deflector (Qty: 4) Tighten: 2 N.m (18 lb in) |
| 3 | Retainer, Air Deflector (Qty: 5) |
| 4 | Bolt, Air Deflector (Qty: 3) Tighten: 10 N.m (89 lb in) |
| 5 | Deflector, Air Deflector |
| NOTE |
|---|
| Refer to Fastener Notice in General Information. |
Air Deflector Replacement - Front Bumper Fascia
Scheme 11
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice in General Information. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Radiator Grille Assembly Replacement Preliminary Procedures: Remove the radiator support sight shield. Refer to Radiator Support Sight Shield Replacement in Body Front End. | |
| 1 | Retainer, Radiator Grille (Qty: 4) |
| 2 | Bumper, Grille Retainer (Qty: 4) |
| 3 | Nut, Grille Assembly (Qty: 2) Tighten: 2 N.m (18 lb in) |
| 4 | Grille Assembly, Radiator |
| 5 | Moulding, Radiator Grille |
| Radiator Lower Grille Assembly Replacement | |
| 6 | Screen Assembly, Radiator Grille |
| NOTE |
|---|
| Refer to Fastener Notice in General Information. |
Fascia Grille Replacement - Front Bumper - Lower
Bumper and Fascia Description
General Motors passenger vehicle bumpers are designed to withstand a collision into a fixed barrier at 5 mph (8 km/h). After absorbing the energy of the collision, the bumper energy absorbers rebound to 80-90 percent of their original position. The bumper energy absorbing capability of the front and the rear bumper systems is achieved through one of the following components in each bumper
- A honeycomb type energy absorbing structure
- A foam type energy absorbing structure
The front and the rear bumper fascias are made of urethane. Urethane withstands minor impact and returns to the original shape.
Refer to General Plastic Repair Instructions in Plastic Panel Information and Repair for repair or refinishing information on the bumper fascia.
Special Tools
Special Tools Illustration Tool Number/Description J 38778 Door Trim Pad and Garnish Clip Remover
Scheme 12
See also:
• Fastener Notice
• Headlamp, Fog Lamp, Turn Signal Lamp, Side Marker Lamp Replacement - Front
• Lifting and Jacking the Vehicle
• Radiator Support Sight Shield Replacement
• General Plastic Repair Instructions
• Fastener Tightening Specifications
• Fascia Grille Replacement - Front Bumper - Lower
