Power and Grounding Connector End Views
Ignition Switch Connector Part Information OEM: IL-AG5-7P-s3T2 (Molex) Service: See Catalog 7-Way F (GN) Pin Wire Color Circuit No. Function 1 L-GN 80 Key In Ignition Switch Signal 2 BK/WH 1551 Ground 3 BN 1141 Ignition 3 Voltage 4 WH/BK 644 12-Volt Reference 5 YE 5 Crank Voltage 6 WH/BK 644 12-Volt Reference 7 PK 1239 Ignition 1 Voltage
Inline Harness Connector End Views
C100 Engine Wiring Harness to Transmission Wiring Harness (L26) Connector Part Information OEM: 15444376 Service: See Catalog 20-Way F Micro-Pack 100W Series Sealed (BK) Connector Part Information OEM: 15409446 Service: See Catalog 20-Way M Micro-Pack 100W Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-GN 1222 1-2 SS Valve Control A L-GN 1222 1-2 SS Valve Control B YE/BK 1223 2-3 SS Valve Control B YE 1223 2-3 SS Valve Control C RD/BK 1228 PC Solenoid Valve High Control C PU 1228 PC Solenoid Valve High Control D L-BU/WH 1229 PC Solenoid Valve Low Control D L-BU 1229 PC Solenoid Valve Low Control E PK 1339 Ignition 1 Voltage E RD 839 Ignition 1 Voltage F BK/WH 771 Transmission Range Signal A F RD/BK 771 Transmission Range Signal A G YE 772 Transmission Range Signal B G D-GN/WH 772 Transmission Range Signal B H GY 773 Transmission Range Signal C H YE/BK 773 Transmission Range Signal C J WH 776 Transmission Range Signal P J GY/WH 776 Transmission Range Signal P K BK/WH 451 Ground K BK/WH 1050 Ground L YE/BK 1227 TFT Sensor Signal L BN 1227 TFT Sensor Signal M BK 452 Low Reference M GY 452 Low Reference N-R - - Not Available N-R - - Not Used S RD/BK 1230 A/T ISS High Signal S BK 1230 A/T ISS High Signal T TN/BK 422 TCC Solenoid Valve Control T TN 418 TCC Solenoid Valve Control U WH 1804 TCC Release Switch Signal U WH 1804 TCC Release Switch Signal V D-BU/WH 1231 A/T ISS Low Signal V D-GN 1231 A/T ISS Low Signal W - - Not Available W - - Not Available
Scheme 71
Scheme 72
C100 Off-Engine Wiring Harness to Transmission Wiring Harness (LY7) Connector Part Information OEM: 15480685 Service: See Catalog 20-Way F Micro-Pack 100W Series Sealed (BK) Connector Part Information OEM: 15409446 Service: See Catalog 20-Way M Micro-Pack 100W Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-GN 1222 1-2 SS Valve Control A L-GN 1222 1-2 SS Valve Control B YE/BK 1223 2-3 SS Valve Control B YE 1223 2-3 SS Valve Control C RD/BK 1228 PC Solenoid Valve High Control C PU 1228 PC Solenoid Valve High Control D L-BU/WH 1229 PC Solenoid Valve Low Control D L-BU 1229 PC Solenoid Valve Low Control E PK 1339 Ignition 1 Voltage E RD 839 Ignition 1 Voltage F BK/WH 771 Transmission Range Signal A F RD/BK 771 Transmission Range Signal A G YE 772 Transmission Range Signal B G D-GN/WH 772 Transmission Range Signal B H GY 773 Transmission Range Signal C H YE/BK 773 Transmission Range Signal C J WH 776 Transmission Range Signal P J GY/WH 776 Transmission Range Signal P K BK/WH 1451 Ground K BK/WH 1050 Ground L YE/BK 1227 TFT Sensor Signal L BN 1227 TFT Sensor Signal M BK 2762 Low Reference M GY 452 Low Reference N-R - - Not Used N-R - - Not Used S RD/BK 1230 A/T ISS High Signal S BK 1230 A/T ISS High Signal T BN 418 TCC Solenoid Valve Control T TN 418 TCC Solenoid Valve Control U WH 1804 TCC Release Switch Signal U WH 1804 TCC Release Switch Signal V D-BU/WH 1231 A/T ISS Low Signal V D-GN 1231 A/T ISS Low Signal W OG/BK 1786 Park/Neutral Signal W OG 1786 Park/Neutral Signal
C101 Engine Harness to I/P Harness (L26) Connector Part Information OEM: 12191511 Service: See Catalog 20-Way F Micro-Pack 100W Series Sealed (GY) Connector Part Information OEM: Assembly 15449357 Connector 12160542 Clip 12059415 Service: See Catalog 20-Way M Micro-Pack 100W Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN/WH 419 MIL Control A BN/WH 419 MIL Control B D-GN 1049 Class 2 Serial Data B D-GN 1049 Class 2 Serial Data C RD 885 Left Rear Wheel Speed Sensor Low Reference (JL9) C RD 885 Left Rear Wheel Speed Sensor Low Reference (JL9) D BK 884 Left Rear Wheel Speed Sensor Signal (JL9) D BK 884 Left Rear Wheel Speed Sensor Signal (JL9) E WH 883 Right Rear Wheel Speed Sensor Low Reference (JL9) E WH 883 Right Rear Wheel Speed Sensor Low Reference (JL9) F-K - - Not Used F-K - - Not Used L BN 882 Right Rear Wheel Speed Sensor Signal (JL9) L BN 882 Right Rear Wheel Speed Sensor Signal (JL9) M PU 1272 Low Reference M PU 1272 Low Reference N TN 1274 5-Volt Reference N TN 1274 5-Volt Reference P L-BU 1162 APP Sensor 2 Signal P L-BU 1162 APP Sensor 2 Signal R BN 1271 Low Reference R BN 1271 Low Reference S WH/BK 1164 5-Volt Reference S WH/BK 1164 5-Volt Reference T D-BU 1161 APP Sensor 1 Signal T D-BU 1161 APP Sensor 1 Signal U L-BU 1122 Class 2 Serial Data (JL9) U L-BU 1122 Class 2 Serial Data (JL9) V-W - - Not Used V-W - - Not Used
C101 Off-Engine Harness to I/P Harness (LY7) Connector Part Information OEM: 12193583 Service: See Catalog 20-Way F Micro-Pack 100W Series Sealed (GY) Connector Part Information OEM: Assembly 15449357 Connector 12160542 Clip 12059415 Service: See Catalog 20-Way M Micro-Pack 100W Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN/WH 419 MIL Control A BN/WH 419 MIL Control B D-GN 1049 Class 2 Serial Data B D-GN 1049 Class 2 Serial Data C RD 885 Left Rear Wheel Speed Sensor Low Reference C RD 885 Left Rear Wheel Speed Sensor Low Reference D BK 884 Left Rear Wheel Speed Sensor Signal D BK 884 Left Rear Wheel Speed Sensor Signal E WH 883 Right Rear Wheel Speed Sensor Low Reference E WH 883 Right Rear Wheel Speed Sensor Low Reference F TN/WH 2500 High Speed GMLAN Serial Data Bus+ (JL4/JL9) F TN/WH 2500 High Speed GMLAN Serial Data Bus+ (JL4/JL9) G TN 2501 High Speed GMLAN Serial Data Bus- (JL4/JL9) G TN 2501 High Speed GMLAN Serial Data Bus- (JL4/JL9) H GY/BK 1798 Ground (JL4/JL9) H GY/BK 1798 Ground (JL4/JL9) J D-BU 716 Yaw Rate Sensor Signal (JL4/JL9) J D-BU 716 Yaw Rate Sensor Signal (JL4/JL9) K GY 930 5-Volt Reference (JL4/JL9) K GY 930 5-Volt Reference (JL4/JL9) L BN 882 Right Rear Wheel Speed Sensor Signal L BN 882 Right Rear Wheel Speed Sensor Signal M PU 1272 Low Reference M PU 1272 Low Reference N TN 1274 5-Volt Reference N TN 1274 5-Volt Reference P L-BU 1162 APP Sensor 2 Signal P L-BU 1162 APP Sensor 2 Signal R BN 1271 Low Reference R BN 1271 Low Reference S WH/BK 1164 5-Volt Reference S WH/BK 1164 5-Volt Reference T D-BU 1161 APP Sensor 1 Signal T D-BU 1161 APP Sensor 1 Signal U L-BU 1122 Class 2 Serial Data U L-BU 1122 Class 2 Serial Data V BN/WH 2086 Yaw Rate Sensor Test Control (JL4/JL9) V BN/WH 2086 Yaw Rate Sensor Test Control (JL4/JL9) W L-BU 715 Lateral Accelerometer Signal (JL4/JL9) W L-BU 715 Lateral Accelerometer Signal (JL4/JL9)
C102 Off-Engine Harness to I/P Harness (LY7) Connector Part Information OEM: 12162144 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: 12162102 Service: See Catalog 4-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A - - Not Used A - - Not Used B YE 2361 SAE J1939 Serial Data Bus + B YE 2361 SAE J1939 Serial Data Bus + C D-GN 2362 SAE J1939 Serial Data Bus - C D-GN 2362 SAE J1939 Serial Data Bus - D - - Not Used D - - Not Used
C104 I/P Harness to Engine Harness Connector Part Information OEM: 12052613 Service: See Catalog 2-Way F 480 Metri-Pack Series Sealed (BK) Connector Part Information OEM: 12065863 Service: See Catalog 2-Way M 480 Metri-Pack Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A RD 1442 Battery Positive Voltage A RD 1442 Battery Positive Voltage B OG 1540 Battery Positive Voltage B OG 1540 Battery Positive Voltage
C107 Off-Engine Harness to On-Engine Harness (LY7) Connector Part Information OEM: 12059472 Service: See Catalog 7-Way F Metri-Pack 150, 280 Mixed Series Sealed (BK) Connector Part Information OEM: 12052200 Service: See Catalog 7-Way M Metri-Pack 150, 480 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK 639 Ignition 1 Voltage A PK/BK 5291 Ignition 1 Voltage B - - Not Used B - - Not Used C D-GN 59 A/C Compressor Clutch Supply Voltage C D-GN 59 A/C Compressor Clutch Supply Voltage D PK 239 Ignition 1 Voltage D PK/BK 5292 Ignition 1 Voltage E PU 6 Starter Solenoid Crank Voltage E PU 6 Starter Solenoid Crank Voltage F PK 839 Ignition 1 Voltage F PK/BK 5293 Ignition 1 Voltage G BK/WH 1451 Ground G BK/WH 1451 Ground
Scheme 73
C108 Battery Cable Harness to I/P Harness Connector Part Information OEM: 12065172 Service: See Catalog 1-Way F 280 Metri-Pack Series Sealed (BK) Connector Part Information OEM: 12065171 Service: See Catalog 1-Way M Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK/WH 151 Ground A BK/WH 151 Ground
C109 On-Engine Harness to Fuel Injector Harness (LY7) Connector Part Information OEM: 1-963214-1 (AMP) Service: See Catalog 10-Way F (BK) Connector Part Information OEM: 1-962352-1 (AMP) Service: See Catalog 10-Way M 2.8 mm (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 PK/BK 5291 Ignition 1 Voltage 1 WH 5291 Ignition 1 Voltage 2 PK/BK 5292 Ignition 1 Voltage 2 WH 5292 Ignition 1 Voltage 3 TN 1744 Fuel Injector 1 Control 3 TN 1744 Fuel Injector 1 Control 4 PK/BK 1746 Fuel Injector 3 Control 4 PK/BK 1746 Fuel Injector 3 Control 5 TN/WH 845 Fuel Injector 5 Control 5 TN/WH 845 Fuel Injector 5 Control 6 L-GN/BK 1745 Fuel Injector 2 Control 6 L-GN/BK 1745 Fuel Injector 2 Control 7 L-BU/BK 844 Fuel Injector 4 Control 7 L-BU/BK 844 Fuel Injector 4 Control 8 YE/BK 846 Fuel Injector 6 Control 8 YE/BK 846 Fuel Injector 6 Control 9-10 - - Not Used 9-10 - - Not Used
Scheme 74
C110 Engine Harness to Ignition Control Module (ICM) Wiring Harness (L26) Connector Part Information OEM: 12047937 Service: See Catalog 8-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: 12047931 Service: See Catalog 8-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WH 423 IC Timing Control A WH 423 IC Timing Control B TN/BK 424 IC Timing Signal B TN/BK 424 IC Timing Signal C L-BU/BK 647 Medium Resolution Engine Speed Signal C L-BU/BK 647 Medium Resolution Engine Speed Signal D PU/WH 430 Low Resolution Engine Speed Signal D PU/WH 430 Low Resolution Engine Speed Signal E - - Not Used E WH 121 Engine Speed Signal F BK 630 Camshaft Position Signal F BK 630 Camshaft Position Signal G RD/BK 453 Low Reference G RD/BK 453 Low Reference H PK 239 Ignition 1 Voltage H PK 239 Ignition 1 Voltage
C120 Forward Lamp Harness to I/P Harness Connector Part Information OEM: 15326829 Service: See Catalog 6-Way F GT 150 Series Sealed (BK) Connector Part Information OEM: 15326833 Service: See Catalog 6-Way M GT 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-GN/BK 735 Ambient Air Temperature Sensor Signal A L-GN/BK 735 Ambient Air Temperature Sensor Signal (CJ2) B YE 61 Low Reference B YE 61 Low Reference (CJ2) C PU 2612 Low Reference C PU 2612 Low Reference D WH/BK 2611 Front End Sensor Signal - Right Front D WH/BK 2611 Front End Sensor Signal - Right Front E GY 2260 Low Reference E GY 2260 Low Reference (AK5) F YE 2160 Front End Discriminating Sensor Signal F YE 2160 Front End Discriminating Sensor Signal (AK5)
C125 Engine Harness to Knock Sensor Jumper Harness (L26) Connector Part Information OEM: 12065172 Service: See Catalog 1-Way F Metri-Pack 280 Series Sealed (BK) Connector Part Information OEM: 12065171 Service: See Catalog 1-Way M Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-BU 1876 Knock Sensor 2 Signal A D-BU 1876 Knock Sensor 2 Signal
C126 Engine Coolant Temperature (ECT) Sensor Jumper Harness to Engine Harness (L26) Connector Part Information OEM: 12052644 Service: See Catalog 2-Way F Metri-Pack 150 Series Sealed (GY) Connector Part Information OEM: 12162343 Service: See Catalog 2-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 410 ECT Sensor Signal A YE 410 ECT Sensor Signal B YE 2761 Low Reference B BK 2761 Low Reference
C141 Forward Lamp Harness to Left Front Headlamp Harness Connector Part Information OEM: 15342659 (Delphi) Service: See Catalog 6-Way F YES C/US CAR Class 3 Sealed (GY) Connector Part Information OEM: 7282-5577-10 (AFL) Service: See Catalog 6-Way M YES C/US CAR Class 3 Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 - - Not Used 1 - - Not Used 2 BK 1350 Ground 2 BK 1350 Ground 3 - - Not Used 3 - - Not Used 4 D-GN/WH 711 Left Headlamp High Beam Supply Voltage 4 D-GN/BK 711 Left Headlamp High Beam Supply Voltage 5 YE 712 Left Headlamp Low Beam Supply Voltage 5 TN/WH 712 Left Headlamp Low Beam Supply Voltage 6 - - Not Used 6 - - Not Used
Scheme 75
Scheme 76
C142 Forward Lamp Harness to Right Front Headlamp Harness Connector Part Information OEM: 15342659 (Delphi) Service: See Catalog 6-Way F YES C/US CAR Class 3 Sealed (GY) Connector Part Information OEM: 7282-5577-10 (AFL) Service: See Catalog 6-Way M YES C/US CAR Class 3 Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 - - Not Used 1 - - Not Used 2 BK 1250 Ground 2 BK 150 Ground 3 - - Not Used 3 - - Not Used 4 L-GN/BK 311 Right Headlamp High Beam Supply Voltage 4 D-GN/BK 311 Right Headlamp High Beam Supply Voltage 5 TN/WH 312 Right Headlamp Low Beam Supply Voltage 5 TN/WH 312 Right Headlamp Low Beam Supply Voltage 6 - - Not Used 6 - - Not Used
C143 Forward Lamp Harness to Left Forward Lamp Jumper Harness Connector Part Information OEM: 12186568 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: Assembly 15423441 Connector 12186271 Clip 12040678 Service: See Catalog 4-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 34 Fog Lamp Supply Voltage (T96) A PU 34 Fog Lamp Supply Voltage (T96) B BK 1350 Ground B BK 1350 Ground C L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage C L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage D BN 9 Park Lamp Supply Voltage D BN 9 Park Lamp Supply Voltage
C144 Forward Lamp Harness to Right Forward Lamp Jumper Harness Connector Part Information OEM: 12186568 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: 15423441 Connector 12186271 Clip 12040678 Service: See Catalog 4-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PU 34 Fog Lamp Supply Voltage (T96) A PU 34 Fog Lamp Supply Voltage (T96) B BK 1250 Ground B BK 1250 Ground C D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage C L-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage D BN 9 Park Lamp Supply Voltage D BN 9 Park Lamp Supply Voltage
C145 Forward Lamp Harness to LH Sidemarker Lamp Harness Connector Part Information OEM: 15300027 Service: See Catalog 2-Way F Metri-Pack 280 Series, Sealed (BK) Connector Part Information OEM: 16530707 Service: See Catalog 2-Way M Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage A BN 9 Park Lamp Supply Voltage B BK 1350 Ground B BK 1350 Ground
C146 Forward Lamp Harness to RH Sidemarker Lamp Harness Connector Part Information OEM: 15300027 Service: See Catalog 2-Way F Metri-Pack 280 Series, Sealed (BK) Connector Part Information OEM: 16530707 Service: See Catalog 2-Way M Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage A BN 9 Park Lamp Supply Voltage B BK 1250 Ground B BK 1250 Ground
C200 Body Harness to I/P Harness Connector Part Information OEM: 15368704 (Delphi) 174952-1 (AMP) Service: See Catalog 20-Way F Multilock 070 Series (WH) Connector Part Information OEM: 15364296 (Delphi) 174936-1 (AMP) Service: See Catalog 20-Way M Multilock 070 Series (WH) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BN 882 Right Rear Wheel Speed Sensor Signal 1 BN 882 Right Rear Wheel Speed Sensor Signal 2 BK 884 Left Rear Wheel Speed Sensor Signal 2 BK 884 Left Rear Wheel Speed Sensor Signal 3 - - Not Used 3 BK 1576 Rear Compartment Lid Release Switch 4 PU 2612 Low Reference 4 PU 2612 Low Reference 5 WH/BK 2611 Front End Sensor Signal - Right Front 5 WH/BK 2611 Front End Sensor Signal - Right Front 6 GY 655 Cellular Microphone Signal (UE1) 6 GY 655 Cellular Microphone Signal (UE1) 7 BARE 1705 Shielded Ground (UE1) 7 BARE 1705 Shielded Ground (UE1) 8 - - Not Used 8 - - Not Used 9 RD 885 Left Rear Wheel Speed Sensor Low Reference 9 RD 885 Left Rear Wheel Speed Sensor Low Reference 10 WH 883 Right Rear Wheel Speed Sensor Low Reference 10 WH 883 Right Rear Wheel Speed Sensor Low Reference 11 D-GN/WH 2514 Keypad Signal (UE1) 11 D-GN/WH 2514 Keypad Signal (UE1) 12 L-GN/BK 2515 Keypad Supply Voltage (UE1) 12 L-GN/BK 2515 Keypad Supply Voltage (UE1) 13 YE/BK 2516 Keypad Green LED Signal (UE1) 13 YE/BK 2516 Keypad Green LED Signal (UE1) 14 BN/WH 2517 Keypad Red LED Signal (UE1) 14 BN/WH 2517 Keypad Red LED Signal (UE1) 15 YE 2160 Front End Discriminating Sensor Signal (AK5) 15 YE 2160 Front End Discriminating Sensor Signal (AK5) 16 GY 2260 Low Reference (AK5) 16 GY 2260 Low Reference (AK5) 17 - - Not Used 17 - - Not Used 18 BK/WH 1455 Keyless Entry Program Enable Signal 18 BK/WH 1455 Keyless Entry Program Enable Signal 19 PU/WH 1630 Steering Column Key Cylinder Lock Solenoid Control 19 PU/WH 1630 Steering Column Key Cylinder Lock Solenoid Control 20 WH 5075 Current Sensor Signal 20 WH 5075 Current Sensor Signal
C201 Steering Column Harness to I/P Harness Connector Part Information OEM: 15359287 Service: See Catalog 40-Way F GT Mixed Series (BK) Connector Part Information OEM: 15359284 Service: See Catalog 40-Way M GR 150, 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1-A5 - - Not Used A1-A5 - - Not Used A6 BK/WH 1551 Ground A6 BK/WH 1551 Ground A7 PK 1539 Ignition 1 Voltage A7 PK 1539 Ignition 1 Voltage A8 GY 1884 Cruise Control Switch Signal (K34) A8 GY 1884 Cruise Control Switch Signal (K34) B1 - - Not Used B1 - - Not Used B2 BK 28 Horn Relay Control B2 BK 28 Horn Relay Control B3 PU 1375 Remote Radio Control Supply Voltage (UK3) B3 PU 1375 Remote Radio Control Supply Voltage (UK3) B4 GY/BK 1458 Instrument Panel Lamp Supply Voltage - 4 B4 GY/BK 1458 Instrument Panel Lamp Supply Voltage - 4 B5 D-BU 1796 Steering Wheel Controls Signal (UK3) B5 D-BU 1796 Steering Wheel Controls Signal (UK3) B6 BK 1550 Ground B6 BK 1550 Ground B7 WH 103 Headlamp Switch Headlamps On Signal B7 WH 103 Headlamp Switch Headlamps On Signal B8 D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage (w/o D55) B8 D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage B9 BN 1141 Ignition 3 Voltage B9 BN 1141 Ignition 3 Voltage B10 PK 1239 Ignition 1 Voltage B10 PK 1239 Ignition 1 Voltage B11 WH 1459 Security System Sensor Supply Voltage B11 WH 1459 Security System Sensor Supply Voltage B12 PU/WH 1630 Steering Column Key Cylinder Lock Solenoid Control (Console Shift) B12 PU/WH 1630 Steering Column Key Cylinder Lock Solenoid Control C1 TN 1835 Security System Sensor Low Reference C1 BK 1835 Security System Sensor Low Reference C2 L-BU 1872 Exterior Lamps Off Input C2 L-BU 1872 Exterior Lamps Off Input C3 OG 192 Front Fog Lamp Switch Signal (T96) C3 OG 192 Front Fog Lamp Switch Signal (T96) C4 TN 2144 Hazard Switch Signal C4 TN 2144 Hazard Switch Signal C5 BN/WH 301 Park Lamp Switch On Signal C5 BN/WH 301 Park Lamp Switch On Signal C6 YE 5 Crank Voltage C6 YE 5 Crank Voltage C7-C8 - - Not Used C7-C8 - - Not Used C9 WH/BK 644 12-Volt Reference C9 WH/BK 644 12-Volt Reference C10 L-GN 80 Key In Ignition Switch Signal C10 L-GN 80 Key In Ignition Switch Signal C11-C12 - - Not Used C11-C12 - - Not Used D1-D8 - - Not Used D1-D8 - - Not Used
Scheme 77
C208 I/P Harness to Body Harness (JL4) Connector Part Information OEM: 15332153 (Delphi) Service: See Catalog 10-Way F GT 150 Series (BK) Connector Part Information OEM: 15332158 (Delphi) Service: See Catalog 10-Way M GT 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BARE 814 Drain Wire (U2K) A BARE 814 Drain Wire (U2K) B BN/WH 367 Remote Radio Left Audio Signal (U2K) B BN/WH 367 Remote Radio Left Audio Signal (U2K) C D-GN/WH 368 Remote Radio Right Audio Signal (U2K) C D-GN/WH 368 Remote Radio Right Audio Signal (U2K) D BK/WH 372 Remote Radio Audio Output (-) (U2K) D BK/WH 372 Remote Radio Audio Output (-) (U2K) E PK 1039 Ignition 1 Voltage E PK 1039 Ignition 1 Voltage F GY/BK 1798 Ground F GY/BK 1798 Ground G D-BU 716 Yaw Rate Sensor Signal (JL4) G D-BU 716 Yaw Rate Sensor Signal (JL4) H GY 930 5-Volt Reference H GY 930 5-Volt Reference J BN/WH 2086 Yaw Rate Sensor Test Control (JL4) J BN/WH 2086 Yaw Rate Sensor Test Control (JL4) K L-BU 715 Lateral Accelerometer Signal (JL4) K L-BU 715 Lateral Accelerometer Signal (JL4)
C209 Inflatable Restraint Driver Harness to I/P Harness Connector Part Information OEM: 15336479 (Delphi) Service: See Catalog 4-Way F Metri-Pack 280 Series (YE) Connector Part Information OEM: 15336467 (Delphi) Service: See Catalog 4-Way M Metri-Pack 280 Series (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 TN 3021 Steering Wheel Module - Stage1 - High Control A1 TN 3021 Steering Wheel Module - Stage1 - High Control A2 BN 3020 Steering Wheel Module - Stage1 - Low Control A2 BN 3020 Steering Wheel Module - Stage1 - Low Control B1 WH 3023 Steering Wheel Module - Stage2 - High Control B1 WH 3023 Steering Wheel Module - Stage2 - High Control B2 PK 3022 Steering Wheel Module - Stage2 - Low Control B2 PK 3022 Steering Wheel Module - Stage2 - Low Control
Scheme 78
C210 HVAC Harness to I/P Harness (C67) Connector Part Information OEM: 15326110 Service: See Catalog 12-Way F GT 280 Series (BK) Connector Part Information OEM: 15326942 Service: See Catalog 12-Way M GT 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK/WH 1551 Ground A BK/WH 1551 Ground B BK 1450 Ground B BK 1450 Ground C PK 739 Ignition 1 Voltage C PK 739 Ignition 1 Voltage D BK 1450 Ground D BK 1450 Ground E - - Not Used E - - Not Used F OG 1040 Battery Positive Voltage F OG 1040 Battery Positive Voltage G GY 8 Instrument Panel Lamp Supply Voltage G GY 8 Instrument Panel Lamp Supply Voltage H RD 442 Battery Positive Voltage H RD 442 Battery Positive Voltage J - - Not Used J - - Not Used K WH 1038 HVAC Class 2 Serial Data K WH 1038 HVAC Class 2 Serial Data L-M - - Not Used L-M - - Not Used
Scheme 79
C210 HVAC Harness to I/P Harness (CJ2) Connector Part Information OEM: 12064749 Service: See Catalog 2-Way F 480 Series (BK) Connector Part Information OEM: 12066387 Service: See Catalog 2-Way M 480 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 1450 Ground A BK 1450 Ground B RD 442 Battery Positive Voltage B RD 442 Battery Positive Voltage
C240 Body Harness to Console Harness (D55) Connector Part Information OEM: 12129081 Service: See Catalog 2-Way F Metri-Pack 280 Series (BK) Connector Part Information OEM: Assembly 15373541 Connector 12129155 Connector Clip 06288295 Service: See Catalog 2-Way M Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 2540 Battery Positive Voltage A OG 2540 Battery Positive Voltage B BK 750 Ground B BK 550 Ground
C241 Body Harness to PRNDL Harness Connector Part Information OEM: 12047886 Service: See Catalog 8-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12045688 Service: See Catalog 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 743 Accessory Voltage A WH 743 Accessory Voltage B PU 1630 Steering Column Key Cylinder Lock Solenoid Control B WH 1630 Steering Column Key Cylinder Lock Solenoid Control C GY 8 Instrument Panel Lamps Dimmer Switch Signal C BU 8 Instrument Panel Lamps Dimmer Switch Signal D BK 550 Ground D BU 550 Ground E D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage E BK 1135 A/T Shift Lock Control Solenoid Supply Voltage F BK 550 Ground F BK 550 Ground G-H - - Not Used G-H - - Not Used
C250 I/P Harness to Body Harness Connector Part Information OEM: 15336479 (Delphi) Service: See Catalog 4-Way F Metri-Pack 280 Series (YE) Connector Part Information OEM: 15336467 (Delphi) Service: See Catalog 4-Way F Metri-Pack 280 Series (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 TN 3021 Steering Wheel Module - Stage1 - High Control A1 TN 3021 Steering Wheel Module - Stage1 - High Control A2 BN 3020 Steering Wheel Module - Stage1 - Low Control A2 BN 3020 Steering Wheel Module - Stage1 - Low Control B1 WH 3023 Steering Wheel Module - Stage2 - High Control B1 WH 3023 Steering Wheel Module - Stage2 - High Control B2 PK 3022 Steering Wheel Module - Stage2 - Low Control B2 PK 3022 Steering Wheel Module - Stage2 - Low Control
C260 Body Harness to Left Front Door Harness Connector Part Information OEM: 15401211 Service: See Catalog 40-Way F GT Mixed Series (GY) Connector Part Information OEM: 15401208 Service: See Catalog 40-Way M GT 150, 280 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 GY 295 Door Lock Actuator Lock Control A1 GY 295 Door Lock Actuator Lock Control A2 YE 143 Accessory Voltage A2 YE 143 Accessory Voltage A3 L-BU 166 Power Window Master Switch Right Front Up Signal A3 L-BU 166 Power Window Master Switch Right Front Up Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A5 L-GN 170 Power Window Master Switch Right Rear Up Signal A5 L-GN 170 Power Window Master Switch Right Rear Up Signal A6 PU 171 Power Window Master Switch Right Rear Down Signal A6 PU 171 Power Window Master Switch Right Rear Down Signal A7 D-GN 168 Power Window Master Switch Left Rear Up Signal A7 D-GN 168 Power Window Master Switch Left Rear Up Signal A8 TN 694 Driver Door Lock Actuator Unlock Control A8 TN 694 Driver Door Lock Actuator Unlock Control B1-B2 - - Not Used B1-B2 - - Not Used B3 GY 118 Left Front Speaker Output (-) B3 GY 118 Left Front Speaker Output (-) B4 TN 201 Left Front Speaker Output (+) B4 TN 201 Left Front Speaker Output (+) B5 BN/WH 1498 Passenger Mirror Motor Down Control B5 BN/WH 1498 Passenger Mirror Motor Down Control B6 L-BU/WH 1497 Passenger Mirror Motor Left/Up Control B6 L-BU/WH 1497 Passenger Mirror Motor Left/Up Control B7 RD/WH 881 Passenger Mirror Motor Right Control B7 RD/WH 881 Passenger Mirror Motor Right Control B8 OG/BK 781 Driver Door Lock Switch UnLock Signal B8 OG/BK 781 Driver Door Lock Switch UnLock Signal B9 RD/BK 780 Driver Door Lock Switch Lock Signal B9 RD/BK 780 Driver Door Lock Switch Lock Signal B10 GY 8 Instrument Panel Lamps Dimmer Switch Signal B10 GY 8 Instrument Panel Lamps Dimmer Switch Signal B11 GY/BK 745 Left Front Door Ajar Switch Signal B11 GY/BK 745 Left Front Door Ajar Switch Signal B12 TN 126 Left Front Door Open Switch Signal B12 TN 126 Left Front Door Open Switch Signal C1 L-GN 1123 Door Lock Key Switch Lock Signal C1 L-GN 1123 Door Lock Key Switch Lock Signal C2 PU 1124 Door Lock Key Switch Unlock Signal C2 PU 1124 Door Lock Key Switch Unlock Signal C3 OG 840 Battery Positive Voltage C3 OG 840 Battery Positive Voltage C4 WH 2132 Side Impact Sensing Module - Left - Signal (AY1) C4 WH 2132 Side Impact Sensing Module - Left - Signal (AY1) C5 YE 2131 Side Impact Sensing Module - Left - Voltage (AY1) C5 YE 2131 Side Impact Sensing Module - Left - Voltage (AY1) C6-C7 - - Not Used C6-C7 - - Not Used C8 OG 267 Heated Mirror Element Supply Voltage (DK2) C8 OG 267 Heated Mirror Element Supply Voltage (DK2) C9-C12 - - Not Used C9-C12 - - Not Used D1 - - Not Used D1 - - Not Used D2 PU 169 Power Window Master Switch Left Rear Down Signal D2 PU 169 Power Window Master Switch Left Rear Down Signal D3 D-BU 1307 Power Window Master Switch Lockout Control D3 D-BU 1307 Power Window Master Switch Lockout Control D4 BK 550 Ground D4 BK 550 Ground D5-D8 - - Not Used D5-D8 - - Not Used
Scheme 80
C261 I/P Harness to Right Front Door Harness Connector Part Information OEM: 15401211 Service: See Catalog 40-Way F GT Mixed Series (GY) Connector Part Information OEM: 15401208 Service: See Catalog 40-Way M GT 150, 280 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 GY 295 Door Lock Actuator Lock Control A1 GY 295 Door Lock Actuator Lock Control A2 YE 143 Accessory Voltage A2 YE 143 Accessory Voltage A3 L-BU 166 Power Window Master Switch Right Front Up Signal A3 L-BU 166 Power Window Master Switch Right Front Up Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A5-A7 - - Not Used A5-A7 - - Not Used A8 TN 294 Door Lock Actuator Unlock Control A8 TN 294 Door Lock Actuator Unlock Control B1 BN/WH 1498 Passenger Mirror Motor Left/Up Control B1 BN/WH 1498 Passenger Mirror Motor Left/Up Control B2 BK 750 Ground B2 BK 750 Ground B3 RD/WH 881 Passenger Mirror Motor Right Control B3 RD/WH 881 Passenger Mirror Motor Right Control B4 L-BU/WH 1497 Passenger Mirror Motor Left/Up Control B4 L-BU/WH 1497 Passenger Mirror Motor Left/Up Control B5-B6 - - Not Used B5-B6 - - Not Used B7 D-GN 117 Right Front Speaker Output (-) B7 D-GN 117 Right Front Speaker Output (-) B8 L-GN 200 Right Front Speaker Output (+) B8 L-GN 200 Right Front Speaker Output (+) B9 L-GN 1177 Right Front Door Open Switch Signal B9 L-GN 1177 Right Front Door Open Switch Signal B10-B11 - - Not Used B10-B11 - - Not Used B12 L-BU 244 Passenger Door Lock Switch Lock Signal B12 L-BU 244 Passenger Door Lock Switch Lock Signal C1 D-BU 245 Passenger Door Lock Switch Unlock Signal C1 D-BU 245 Passenger Door Lock Switch Unlock Signal C2 GY 8 Instrument Panel Lamp Supply Voltage C2 GY 8 Instrument Panel Lamp Supply Voltage C3 BK/WH 746 Right Front Door Ajar Switch Signal C3 BK/WH 746 Right Front Door Ajar Switch Signal C4 D-GN 2134 Side Impact Sensing Module - Right - Signal (AY1) C4 D-GN 2134 Side Impact Sensing Module - Right - Signal (AY1) C5 TN 2133 Side Impact Sensing Module - Right - Voltage (AY1) C5 TN 2133 Side Impact Sensing Module - Right - Voltage (AY1) C6-C7 - - Not Used C6-C7 - - Not Used C8 OG 267 Heated Mirror Element Supply Voltage (DK2) C8 OG 267 Heated Mirror Element Supply Voltage (DK2) C9-C12 - - Not Used C9-C12 - - Not Used D1-D8 - - Not Used D1-D8 - - Not Used
C275 Inflatable Restraint Coil Harness to Steering Column Harness Connector Part Information OEM: 12047886 Service: See Catalog 8-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12045688 Service: See Catalog 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GY 1884 Cruise Control Switch Signal A GY 1884 Cruise Control Switch Signal B D-BU 28 Horn Relay Control B BK 28 Horn Relay Control C D-GN 8 Instrument Panel Lamps Dimmer Switch Signal C BK 8 Instrument Panel Lamps Dimmer Switch Signal D BK 1539 Ignition 1 Voltage D PK 1539 Ignition 1 Voltage E GY 1375 Remote Radio Control Supply Voltage (UK3) E PU 1375 Remote Radio Control Supply Voltage (UK3) F BN 1458 Instrument Panel Lamp Supply Voltage - 4 F GY/BK 1458 Instrument Panel Lamp Supply Voltage - 4 G YE 1796 Steering Wheel Controls Signal (UK3) G D-BU 1796 Steering Wheel Controls Signal H YE/BK 658 Cellular Telephone Voice Signal H D-BU 658 Cellular Telephone Voice Signal
C277 Inflatable Restraint Coil Harness to Steering Wheel Harness (UK3) Connector Part Information OEM: 12047886 Service: See Catalog 8-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12045688 Service: See Catalog 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A GY 1884 Cruise Control Switch Signal A GY 1884 Cruise Control Switch Signal B D-BU 28 Horn Relay Control B BK 28 Horn Relay Control C D-GN 8 Instrument Panel Lamps Dimmer Switch Signal C BK 8 Instrument Panel Lamps Dimmer Switch Signal D BK 1539 Ignition 1 Voltage D PK 1539 Ignition 1 Voltage E PU 1375 Remote Radio Control Supply Voltage E PU 1375 Remote Radio Control Supply Voltage F BN 1458 Instrument Panel Lamp Supply Voltage - 4 F GY/BK 1458 Instrument Panel Lamp Supply Voltage - 4 G PK 1539 Steering Wheel Controls Signal G D-BU 1539 Steering Wheel Controls Signal D-BU 1539 Steering Wheel Controls Signal H D-BU 658 Cellular Telephone Voice Signal H D-BU 658 Cellular Telephone Voice Signal
C278 PSIR Jumper Harness to Body Harness Connector Part Information OEM: 15336479 (Delphi) Service: See Catalog 4-Way F Metri-Pack 280 Series (YE) Connector Part Information OEM: 15476173 (Delphi) Service: See Catalog 4-Way M Metri-Pack 280 Series (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 YE 3025 I/P Module - Stage1 - High Control A1 YE 3025 I/P Module - Stage1 - High Control A2 OG 3024 I/P Module - Stage1 - Low Control A2 OG 3024 I/P Module - Stage1 - Low Control B1 GY 3027 I/P Module - Stage2 - High Control B1 GY 3027 I/P Module - Stage2 - High Control B2 PU 3026 I/P Module - Stage2 - Low Control B2 PU 3026 I/P Module - Stage2 - Low Control
C311 Body Harness to Left Front Seat Harness Connector Part Information OEM: 15336205 Service: See Catalog 12-Way F GT 150, 280 Mixed Series (BK) Connector Part Information OEM: 15336209 Service: See Catalog 12-Way M GT 150, 280 Mixed Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 1140 Battery Positive Voltage A OG 1140 Battery Positive Voltage B - - Not Used B - - Not Used C OG 1440 Battery Positive Voltage (KA1) C OG 1440 Battery Positive Voltage (KA1) D PU 2477 Driver Heated Seat Back Only Mode Signal (KA1) D PU 2477 Driver Heated Seat Back Only Mode Signal (KA1) E YE/BK 2079 Heated Seat Cushion Temperature Sensor Signal (KA1) E YE/BK 2079 Heated Seat Cushion Temperature Sensor Signal (KA1) F BK/WH 238 Seat Belt Switch - Left F BK/WH 238 Seat Belt Switch - Left G - - Not Used G - - Not Used H YE 2080 Driver Heated Seat Cushion Temperature Sensor Low Reference (KA1) H YE 2080 Driver Heated Seat Cushion Temperature Sensor Low Reference (KA1) J-L - - Not Used J-L - - Not Used M BK 650 Ground M BK 650 Ground
Scheme 81
C312 Left Front Seat Harness to Left Front Seat Back Harness (AL9) Connector Part Information OEM: 12129136 Service: See Catalog 4-Way F Metri-Pack 280 Series (BK) Connector Part Information OEM: 12129135 Service: See Catalog 4-Way M Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-BU/WH 611 Driver Seat Lumbar Motor Forward Control A D-BU 611 Driver Seat Lumbar Motor Forward Control B PK/BK 610 Driver Seat Lumbar Motor Rearward Control B PK 610 Driver Seat Lumbar Motor Rearward Control C-D - - Not Used C-D - - Not Used
C313 Body Harness to Right Front Seat Harness Connector Part Information OEM: 15336219 Service: See Catalog 16-Way F GT 150, 280 Series Sealed (BK) Connector Part Information OEM: 15336224 Service: See Catalog 16-Way M GT 150, 280 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 850 Ground A BK 850 Ground B - - Not Used B - - Not Used C GY 2434 Passenger Heated Seat Cushion Temperature Sensor Signal (KA1) C GY 2434 Passenger Heated Seat Cushion Temperature Sensor Signal (KA1) D TN/WH 2430 Passenger Heated Seat Back Only Mode Signal (KA1) D TN/WH 2430 Passenger Heated Seat Back Only Mode Signal (KA1) E RD 1362 Seat Belt Switch - Right - Signal E RD 1362 Seat Belt Switch - Right - Signal F PK 2435 Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1) F PK 2435 Passenger Heated Seat Cushion Temperature Sensor Low Reference (KA1) G-H - - Not Used G-H - - Not Used J OR 1140 Battery Positive Voltage J OR 1140 Battery Positive Voltage K OR 1440 Battery Positive Voltage K OR 1440 Battery Positive Voltage L BK/WH 1751 Ground L BK/WH 1751 Ground M PK 2306 Occupant Sensor Serial Data Link M PK 2306 Occupant Sensor Serial Data Link N D-BU 2307 Passenger Air Bag On Indicator Control N D-BU 2307 Passenger Air Bag On Indicator Control P D-GN 2308 Passenger Air Bag Off Indicator Control P D-GN 2308 Passenger Air Bag Off Indicator Control R OR 640 Battery Positive Voltage R OR 640 Battery Positive Voltage S YE 1139 Ignition 1 Voltage S YE 1139 Ignition 1 Voltage
C315 Right Front Seat Safety Harness to Body Harness Connector Part Information OEM: 12077921 Service: See Catalog 2-Way F Metri-Pack 280 Series (YE) Connector Part Information OEM: 12186799 Service: See Catalog 2-Way M Metri-Pack 280 Series P2S (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A L-GN 2116 Seat Belt Pretensioner - Right - High Control A L-GN 2116 Seat Belt Pretensioner - Right - High Control B OG 2117 Seat Belt Pretensioner - Right - Low Control B OG 2117 Seat Belt Pretensioner - Right - Low Control
C316 Left Front Seat Safety Harness to Body Harness Connector Part Information OEM: 12077921 Service: See Catalog 2-Way F Metri-Pack 280 Series (YE) Connector Part Information OEM: 12186799 Service: See Catalog 2-Way M Metri-Pack 280 Series P2S (YE) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK/WH 2118 Seat Belt Pretensioner - Left - High Control A BK/WH 2118 Seat Belt Pretensioner - Left - High Control B OG/BK 2119 Seat Belt Pretensioner - Left - Low Control B OG/BK 2119 Seat Belt Pretensioner - Left - Low Control
C317 Headliner Harness to Roof Harness Connector Part Information OEM: 12047662 Service: See Catalog 2-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12047663 Service: See Catalog 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Courtesy Lamp A OG 1732 Inadvertent Power Courtesy Lamp B BK 750 Ground B BK 750 Ground
C318 Headliner Harness to Roof Harness Connector Part Information OEM: 12047662 Service: See Catalog 2-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 12047663 Service: See Catalog 2-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Power Courtesy Lamp A OG 1732 Inadvertent Power Courtesy Lamp B BK 750 Ground B BK 750 Ground
C355 Body Harness to Left Rear Door Harness Connector Part Information OEM: 15441216 Service: See Catalog 9-Way F GT 150, 280 Series Sealed (BK) Connector Part Information OEM: 15486551 Service: See Catalog 9-Way M GT 150, 280 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 550 Ground A BK 550 Ground B TN 294 Door Lock Actuator Unlock Control B TN 294 Door Lock Actuator Unlock Control C D-BU 1307 Power Window Master Switch Lockout Control C D-BU 1307 Power Window Master Switch Lockout Control D D-BU/WH 1179 Left Rear Door Open Switch Signal D D-BU/WH 1179 Left Rear Door Open Switch Signal E GY 295 Door Lock Actuator Lock Control E GY 295 Door Lock Actuator Lock Control F L-BU/BK 747 Left Rear Door Ajar Switch Signal F L-BU/BK 747 Left Rear Door Ajar Switch Signal G D-GN 168 Power Window Master Switch Left Rear Up Signal G D-GN 168 Power Window Master Switch Left Rear Up Signal H PU 169 Power Window Master Switch Left Rear Down Signal H PU 169 Power Window Master Switch Left Rear Down Signal J - - Not Used J - - Not Used
Scheme 82
C356 Body Harness to Right Rear Door Harness Connector Part Information OEM: 15441216 Service: See Catalog 9-Way F GT 150, 280 Series Sealed (BK) Connector Part Information OEM: 15486551 Service: See Catalog 9-Way M GT 150, 280 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 750 Ground A BK 750 Ground B TN 294 Door Lock Actuator Unlock Control B TN 294 Door Lock Actuator Unlock Control C D-BU 1307 Power Window Master Switch Lockout Control C D-BU 1307 Power Window Master Switch Lockout Control D YE/BK 1181 Right Rear Door Open Switch Signal D YE/BK 1181 Right Rear Door Open Switch Signal E GY 295 Door Lock Actuator Lock Control E GY 295 Door Lock Actuator Lock Control F L-GN/BK 748 Right Rear Door Ajar Switch Signal F L-GN/BK 748 Right Rear Door Ajar Switch Signal G L-GN 170 Power Window Master Switch Right Rear Up Signal G L-GN 170 Power Window Master Switch Right Rear Up Signal H PU 171 Power Window Master Switch Right Rear Down Signal H PU 171 Power Window Master Switch Right Rear Down Signal J - - Not Used J - - Not Used
C390 Headliner Harness to Body harness Connector Part Information OEM: 15332177 Service: See Catalog 16-Way F GT 150 Series (BK) Connector Part Information OEM: 15332182 Service: See Catalog 16-Way M GT 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 750 Ground A BK 750 Ground B GY/BK 690 Courtesy Lamp Supply Voltage B GY/BK 690 Courtesy Lamp Supply Voltage C OG 1732 Courtesy Lamps Supply Voltage C OG 1732 Courtesy Lamps Supply Voltage D YE 643 Accessory Voltage (D88) D YE 643 Accessory Voltage (D88) E L-GN 24 Backup Lamp Supply Voltage E L-GN 24 Backup Lamp Supply Voltage F GY 655 Cellular Microphone Signal (UE1) F GY 655 Cellular Microphone Signal (UE1) G BARE 1705 Shielded Ground (UE1/UG) G BARE 1705 Shielded Ground (UE1/UG) H - - Not Used H - - Not Used J WH 2370 Telltale Assembly Supply Voltage (UD7) J WH 2370 Telltale Assembly Supply Voltage (UD7) K OG 2371 Left Amber Indicator Control (UD7) K OG 2371 Left Amber Indicator Control (UD7) L D-BU 2372 Center Amber Indicator Control (UD7) L D-BU 2372 Center Amber Indicator Control (UD7) M GY 2373 Red Indicator Control (UD7) M GY 2373 Red Indicator Control (UD7) N D-GN/WH 2514 Keypad Signal (UE1) N D-GN/WH 2514 Keypad Signal (UE1) P L-GN/BK 2515 Keypad Supply Voltage (UE1) P L-GN/BK 2515 Keypad Supply Voltage (UE1) R YE/BK 2516 Keypad Green LED Signal (UE1) R YE/BK 2516 Keypad Green LED Signal (UE1) S BN/WH 2517 Keypad Red LED Signal (UE1) S BN/WH 2517 Keypad Red LED Signal (UE1)
Scheme 83
C398 Roof Harness to Sunroof Harness (CF5) Connector Part Information OEM: 174923-2 (AMP) Service: See Catalog 6-Way F Amp Multi-Lock 070 Series (BK) Connector Part Information OEM: 15448099 Service: See Catalog 6-Way M Amp Multi-Lock 070 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BN 100 Sunroof Switch Open Signal 1 BN 100 Sunroof Switch Open Signal 2 OG 110 Sunroof Switch Close Signal 2 OG 110 Sunroof Switch Close Signal 3 D-BU 128 Sunroof Switch Low Reference 3 D-BU 128 Sunroof Switch Low Reference 4 BK 750 Ground 4 BK 750 Ground 5 YE 643 Accessory Voltage 5 YE 643 Accessory Voltage 6 - - Not Used 6 - - Not Used
C400 Rear Deck Lid Harness to Body Harness Connector Part Information OEM: 12047886 Service: See Catalog 8-Way F Metri-Pack 150 Series (BK) Connector Part Information OEM: 15422329 Service: See Catalog 8-Way M Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A-C - - Not Used A-C - - Not Used D OG/BK 737 Rear Compartment Lamp Control D OG/BK 737 Rear Compartment Lamp Control E BK 750 Ground E BK 750 Ground F L-BU 1344 Trunk Release Relay Control F L-BU 1344 Trunk Release Relay Control G - - Not Used G - - Not Used H RD/BK 744 Rear Compartment Lid Ajar Switch H RD/BK 744 Rear Compartment Lid Ajar Switch
C401 Body Harness to Left Rear Lamp Harness Connector Part Information OEM: 12162144 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: 12162102 Service: See Catalog 4-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 18 Left Rear Stop/Turn Lamp Supply Voltage A YE 18 Left Rear Stop/Turn Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage C L-GN 24 Backup Lamp Supply Voltage C D-GN 24 Backup Lamp Supply Voltage D BK 550 Ground D BK 150 Ground
C402 Body Harness to Right Rear Lamp Harness Connector Part Information OEM: 12162144 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (BK) Connector Part Information OEM: 12162102 Service: See Catalog 4-Way M Metri-Pack 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage A YE 18 Right Rear Stop/Turn Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage C L-GN 24 Backup Lamp Supply Voltage C D-GN 24 Backup Lamp Supply Voltage D BK 750 Ground D BK 150 Ground
C405 Fuel Tank Harness to Body Harness Connector Part Information OEM: 12146439 Service: See Catalog 4-Way F Metri-Pack 150 Series Sealed (GY) OEM: 12176335 Service: See Catalog 8-Way F Metri-Pack 280 Series Sealed (GY) Connector Part Information OEM: 15326714 Service: See Catalog 12-Way M Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN 882 Right Rear Wheel Speed Sensor Signal 1A BN 882 Right Rear Wheel Speed Sensor Signal B WH 883 Right Rear Wheel Speed Sensor Low Reference 1B WH 883 Right Rear Wheel Speed Sensor Low Reference C BK 884 Left Rear Wheel Speed Sensor Signal 1C BK 884 Left Rear Wheel Speed Sensor Signal D RD 885 Left Rear Wheel Speed Sensor Low Reference 1D RD 885 Left Rear Wheel Speed Sensor Low Reference A BK 150 Ground 3A BK 1850 Ground B BK/WH 651 Low Reference 3B BK 2759 Low Reference C GY 120 Fuel Pump Supply Voltage 3C GY 120 Fuel Pump Supply Voltage D PU 30 Fuel Level Sensor Signal 3D PU 1589 Fuel Level Sensor Signal E - - Not Used 3E - - Not Used F GY/BK 416 5-Volt Reference 3F GY 2700 5-Volt Reference G D-GN 890 Fuel Tank Pressure Sensor Signal 3G D-GN 890 Fuel Tank Pressure Sensor Signal H OG/BK 469 Low Reference 3H BK 2759 Low Reference BK 2759 Low Reference
Scheme 84
Scheme 85
C406 Body Harness to License Lamp Harness Connector Part Information OEM: 15326801 Service: See Catalog 2-Way F Global Terminal 150 Series Sealed (BK) Connector Part Information OEM: 15324570 Service: See Catalog 2-Way M Global Terminal 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage A BN 9 Park Lamp Supply Voltage B BK 550 Ground B BK 550 Ground
C450 Body Harness to Rear Park Assist Harness (UD7) Connector Part Information OEM: 15465945 Service: See Catalog 8-Way F Global Terminal 150 Series Sealed (BK) Connector Part Information OEM: 15476174 Service: See Catalog 8-Way M Global Terminal 150 Series Sealed (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YE 2375 LR Corner Object Sensor Signal A YE 2375 LR Corner Object Sensor Signal B OG 2376 LR Middle Object Sensor Signal B OG 2376 LR Middle Object Sensor Signal C D-GN 2377 RR Middle Object Sensor Signal C D-GN 2377 RR Middle Object Sensor Signal D RD 2378 RR Corner Object Sensor Signal D RD 2378 RR Corner Object Sensor Signal E D-BU 2374 Object Sensor Supply Voltage E D-BU 2374 Object Sensor Supply Voltage F GY 2379 Object Sensor Low Reference F GY 2379 Object Sensor Low Reference G-H - - Not Used G-H - - Not Used
C501 Left Front Door Harness to Left Front Door Trim Harness Connector Part Information OEM: 15401211 Service: See Catalog 40-Way F GT 150 280 Series (GY) Connector Part Information OEM: 15463191 Service: See Catalog 40-Way M GT 150 280 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 - - Not Used A1 - - Not Used A2 YE 143 Accessory Voltage A2 YE 143 Accessory Voltage A3 L-BU 166 Power Window Master Switch Right Front Up Signal A3 L-BU 166 Power Window Master Switch Right Front Up Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A5 L-GN 170 Power Window Master Switch Right Rear Up Signal A5 L-GN 170 Power Window Master Switch Right Rear Up Signal A6 PU 171 Power Window Master Switch Right Rear Down Signal A6 PU 171 Power Window Master Switch Right Rear Down Signal A7 D-GN 168 Power Window Master Switch Left Rear Up Signal A7 D-GN 168 Power Window Master Switch Left Rear Up Signal A8 - - Not Used A8 - - Not Used B1-B4 - - Not Used B1-B4 - - Not Used B5 BN/WH 1498 Passenger Mirror Motor Up Control B5 BN/WH 1498 Passenger Mirror Motor Up Control B6 L-BU/WH 1497 Passenger Mirror Motor Left/Down Control B6 L-BU/WH 1497 Passenger Mirror Motor Left/Down Control B7 RD/WH 881 Passenger Mirror Motor Right Control B7 RD/WH 881 Passenger Mirror Motor Right Control B8 OG/BK 781 Driver Door Lock Switch Unlock Signal B8 OG/BK 781 Driver Door Lock Switch Unlock Signal B9 RD/BK 780 Driver Door Lock Switch Lock Signal B9 RD/BK 780 Driver Door Lock Switch Lock Signal B10 GY 8 Instrument Panel Lamp Supply Voltage B10 GY 8 Instrument Panel Lamp Supply Voltage B11-B12 - - Not Used B11-B12 - - Not Used C1 WH 81 Driver Mirror Motor Right Control C1 WH 81 Driver Mirror Motor Right Control C2 YE 88 Driver Mirror Motor Up Control C2 YE 88 Driver Mirror Motor Up Control C3 OG 840 Battery Positive Voltage C3 OG 840 Battery Positive Voltage C4 L-GN 1499 Driver Mirror Motor Left/Down Control C4 L-GN 1499 Driver Mirror Motor Left/Down Control C5-C12 - - Not Used C5-C12 - - Not Used D1 - - Not Used D1 - - Not Used D2 PU 169 Power Window Master Switch Left Rear Down Signal D2 PU 169 Power Window Master Switch Left Rear Down Signal D3 D-BU 1307 Power Window Master Switch Lockout Signal D3 D-BU 1307 Power Window Master Switch Lockout Signal D4 BK 550 Ground D4 BK 550 Ground D5 BN 165 Power Window Motor Left Front Down Control D5 BN 165 Power Window Motor Left Front Down Control D6 D-BU 164 Power Window Motor Left Front Up Control D6 D-BU 164 Power Window Motor Left Front Up Control D7-D8 - - Not Used D7-D8 - - Not Used
C601 Right Front Door Harness to Right Front Door Trim Harness Connector Part Information OEM: 15401211 Service: See Catalog 40-Way F GT 150 280 Series (GY) Connector Part Information OEM: 15463191 Service: See Catalog 40-Way M GT 150 280 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 - - Not Used A1 - - Not Used A2 YE 143 Accessory Voltage A2 YE 143 Accessory Voltage A3 L-BU 166 Power Window Master Switch Right Front Up Signal A3 L-BU 166 Power Window Master Switch Right Front Up Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A4 TN 167 Power Window Master Switch Right Front Down Signal A5 D-BU 666 Power Window Motor Right Front Up Control A5 D-BU 666 Power Window Motor Right Front Up Control A6 BN 667 Power Window Motor Right Front Down Control A6 BN 667 Power Window Motor Right Front Down Control A7-A8 - - Not Used A7-A8 - - Not Used B1 - - Not Used B1 - - Not Used B2 BK 750 Ground B2 BK 750 Ground B3-B11 - - Not Used B3-B11 - - Not Used B12 L-BU 244 Passenger Door Lock Switch Lock Signal B12 L-BU 244 Passenger Door Lock Switch Lock Signal C1 D-BU 245 Passenger Door Lock Switch Unlock C1 D-BU 245 Passenger Door Lock Switch Unlock C2 GY 8 Instrument Panel Lamp Supply Voltage C2 GY 8 Instrument Panel Lamp Supply Voltage C3-C12 - - Not Used C3-C12 - - Not Used D1-D8 - - Not Used D1-D8 - - Not Used
Splice Pack SP205 Connector Part Information OEM: 15450641 Service: See Catalog 12-Way F GT 150 Series (GY) Pin Wire Color Circuit No. Function A PU 1132 DLC Class 2 Serial Data B D-GN 1049 ECM/PCM Class 2 Serial Data C - - Not Used D OG 1044 Radio Class 2 Serial Data E L-BU 1122 ABS/TCS Class 2 Serial Data F D-BU 1128 SDM Class 2 Serial Data G GY 1036 IPC Class 2 Serial Data H - - Not Used J L-GN 2271 ADG Class 2 Serial Data (UE1) K - - Not Used L WH 1038 HVAC Class 2 Serial Data M L-GN 1037 BCM Class 2 Serial Data
