Accessory Power Socket Buick LaCrosse I

Body Electrical 3 illustrations ~289 words

Scheme 68

Scheme 68: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 68: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 69

Scheme 69: Power Outlet Component Views
Scheme 69: Power Outlet Component Views
CalloutComponent Name
1Lamp Switch Assembly - Fog Lamp
2Instrument Panel Cluster (IPC)
3Ignition Switch
4Air Temperature Sensor - Inside
5Sunload Sensor Assembly (CJ2) or Ambient Light Sensor (C67)
6Theft LED
7Driver Information Center (DIC)
8Radio
9HVAC Control Module
10Heated Seat Switch - Front Passenger
11Cigar Lighter
12Heated Seat Switch - Driver
13Steering Wheel Controls - Right
14Cruise Control Switch
15Voice Recorder/Cruise Switch Assembly
16Steering Wheel Controls - Left
17Turn Signal/Multifunction Switch
18I/P Dimmer Switch
19Lamp Switch Assembly - Interior Lamps

Scheme 70

Scheme 70
Scheme 70
CalloutComponent Name
1Auxiliary Power Outlet
2C240

Power Outlet Connector End Views

Auxiliary Power Outlet Connector Part Information OEM: 12176836 Service: 15305923 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A OG 2540 Battery Positive Voltage B - - Not Used C BK 550 Ground

Cigar Lighter Connector Part Information OEM: 12176836 Service: 15305923 3-Way F Metri-Pack 280 Series (GY) Pin Wire Color Circuit No. Function A OG 2540 Battery Positive Voltage B - - Not Used C BK 1450 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Removal Procedure

  1. Remove the 12-volt power supply or cigar lighter fuse.
  2. Remove the socket by placing one side of the "T" portion of the tool J 42059 into the socket and into the square window tab. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/body-electrical/#accessory-power-socket__special-tools) .
  3. Position the opposite "T" portion of the tool into the opposing square window tab.
  4. Pull the socket straight out of the retaining ring.
  5. Remove the tool from the socket.
  6. Disconnect the electrical connector from the socket.
  7. Using your finger, remove the socket retaining ring by pulling the retaining ring out of the mounting hole.

Installation Procedure

  1. Position the retaining ring to the mounting hole.
  2. Index the key to the retaining ring to the slot in the mounting hole.
  3. Install the retaining ring by pressing the retaining ring into the mounting hole until fully seated.
  4. Connect the electrical connector to the socket.
  5. Position the socket to the retaining ring.
  6. Install the socket into the retaining ring by pressing in the socket until fully seated.
  7. Install the 12-volt power supply or cigar lighter fuse.

Special Tools

Special Tools Illustration Tool Number/Description J 42059 Cigar Lighter Socket Remover
