Wiring Systems and Power Management - Master Electrical Schematic Icons Buick Encore I

Master Electrical Schematic Icons Icon Icon Definition WARNING: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs. WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. WARNING: To help avoid personal injury, always treat the accessory power receptacle, accessory DC/AC power inverter module, AC circuit wires, and connectors as if AC high-voltage is present. NOTE: Always perform the High Voltage Disabling procedure prior to servicing any High Voltage component or connection. Personal Protection Equipment (PPE) and proper procedures must be followed. The High Voltage Disabling procedure will perform the following tasks: Identify how to disable high voltage. Identify how to test for the presence of high voltage. Identify condition under which high voltage is always present and personal protection equipment (PPE) and proper procedures must be followed. Before working on any high voltage system, be sure to wear the following Personal Protection Equipment: Safety glasses with appropriate side shields when within 15 meters (50 feet) of the vehicle, either indoors or outdoors. Certified and up-to-date Class "0" Insulation gloves rated at 1000V with leather protectors. - Visually and functionally inspect the gloves before use. - Wear the Insulation gloves with leather protectors at all times when working with the high voltage battery assembly, whether the system is energized or not. Failure to follow the procedures exactly as written may result in serious injury or death. NOTE: Always perform the High Voltage Disabling procedure prior to servicing any High Voltage component or connection. Personal Protection Equipment (PPE) and proper procedures must be followed. Failure to follow the procedure exactly as written may result in serious injury or death. NOTE: Twisted wires provide an effective shield that helps protect sensitive electronic components from electrical interference. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted wires shown : The wires must be twisted a minimum of 16 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.25 in). NOTE: The following components have wire colors that are known to have been changed during production by the wiring harness supplier. Not all possible wire color combinations are known at this time. K47 Rear Differential Clutch Control Module X2 (M32 Differential Clutch Pump) The following lists some of the colors known to have been used in these cavities: RD wires in both cavity A and B, BK wires in both cavity A and B, BK in cavity A, RD in cavity B, and WH in cavity C. Q49 Rear Differential Clutch Solenoid Valve The following lists some of the colors known to have been used in these cavities: RD wires in both cavities, BK wires in both cavities, and BK in cavity 1, RD in cavity 2

Scheme 233

Scheme 234

Scheme 235

Scheme 236
