INTRODUCTION
Mode 6 is designed to allow access to the results of onboard diagnostic monitoring tests of specific components/systems that are not continuously monitored. These systems include the catalytic converter, EVAP system, oxygen sensor, oxygen sensor heater, EGR system, secondary AIR system, and sometimes misfire.
Mode 6 data is output from the PCM/ECM in hexadecimal form. The $ sign indicates a hexadecimal number. Depending on the software in the scanner, the output could be displayed in hexadecimal numbers (no conversion), raw data (conversion to decimal numbers), or measurable values (applying conversion factor to raw data).
Before reading mode 6 information, ensure that the monitor for the information you are accessing has run to completion. If the monitor is not complete, the mode 6 data will not be accurate.
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
2004 3.6L
| OBD Monitor ID (OBDIMID) | Test ID (TID) | Units and Scaling ID (UASID) | Description | Range For Information ONLY. Source information is ISO-15031-5 document | Resolution For Information ONLY. Source information is ISO-15031-5 document |
|---|---|---|---|---|---|
| Oxygen Sensor Monitor Bank 1 Sensor 1 | |||||
| 01 | 81 | 1E | Equivalence Ratio (Lambda) - Measured Actual | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 01 | 82 | 1E | Equivalence Ratio (Lambda) - Commanded Set Point | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 01 | 83 | 2F | Dynamic Response Performance (Normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| 01 | 84 | 85 | Secondary Sensor Trim Correction of Primary Sensor | 0.999 to 0.999 counts | 0.0000305 counts/bit |
| Oxygen Sensor Monitor Bank 1 Sensor 2 | |||||
| 02 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 1 | |||||
| 05 | 81 | 1E | Equivalence Ratio (Lambda) - Measured Actual | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 05 | 82 | 1E | Equivalence Ratio (Lambda) - Commanded Set Point | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 05 | 83 | 2F | Dynamic Response Performance (Normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| 05 | 84 | 85 | Secondary Sensor Trim Correction of Primary Sensor | 0.999 to 0.999 counts | 0.0000305 counts/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 2 | |||||
| 06 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| Catalyst Monitor | |||||
| 21 | 84 | 06 | Catalyst Test Bank 1 | 0.000 to 19.988 counts | 0.000305 counts/bit |
| 22 | 84 | 06 | Catalyst Test bank 2 | 0.000 to 19.988 counts | 0.000305 counts/bit |
| EVAP Monitor (Cap Off) | |||||
| 39 | 80 | 81 | EVPD Weak Vacuum Test - Gross Leak | 32768 to +32767 counts | 1 count/bit |
| EVAP Monitor 0.020" | EWMA = Exponentially Weighted Moving Average EONV = Engine Off Natural Vacuum | ||||
| 3C | 80 | 05 | EONV NV 0.020 Test - EWMA | 0.000 to 1.999 counts | 0.0000305 counts/bit |
| Purge Flow Monitor | |||||
| 3D | 88 | 84 | Purge Valve Flow Test - Stuck Open/Leak | 32.768 to +32.767 counts | 0.001 count/bit |
| 3D | 8C | 81 | Canister Vent Valve Test - Stuck Closed/Restricted | 32768 to +32767 counts | 1 count/bit |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 1 | |||||
| 41 | 82 | 2F | Heater Power (normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 2 | |||||
| 42 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohms/bit |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 1 | |||||
| 45 | 82 | 2F | Heater Power (normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 2 | |||||
| 46 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohms/bit |
| Fuel System Monitor Bank 1 | |||||
| 81 | 80 | AF | Additive Fuel (Offset) Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 81 | 82 | 05 | Multiplicative Fuel (Slope) Correction | 0.000 to 1.999 counts | 0.0000305 counts/bit |
| Fuel System Monitor Bank 2 | |||||
| 82 | 80 | AF | Additive Fuel Offset Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 82 | 82 | 05 | Multiplicative Fuel Slope Correction | 0.000 to 1.999 counts | 0.0000305 counts/bit |
Mode $06 Data Definitions For 2004 Buick (3.6L)
2005 3.6L
| OBD Monitor ID (OBDMID) | Test ID (TID) | Units and Scaling ID (UASID) | Description | Range For Information ONLY. Source information is ISO-15031-5 document | Resolution For Information ONLY. Source information is ISO-15031-5 document |
|---|---|---|---|---|---|
| Oxygen Sensor Monitor Bank 1 Sensor 1 | |||||
| 01 | 81 | 1E | Equivalence Ratio (Lambda) - Measured Actual | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 01 | 82 | 1E | Equivalence Ratio (Lambda) - Commanded Set Point | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 01 | 83 | 2F | Dynamic Response Performance (Normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| 01 | 84 | 85 | Secondary Sensor Lambda Trim Correction of Primary Sensor | 0.999 to | 0.999 0.0000305/bit |
| Oxygen Sensor Monitor Bank 1 Sensor 2 | |||||
| 02 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 02 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 1 | |||||
| 05 | 81 | 1E | Equivalence Ratio (Lambda) - Measured Actual | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 05 | 82 | 1E | Equivalence Ratio (Lambda) - Commanded Set Point | 0.000 to 1.999 lambda | 0.0000305 lambda/bit |
| 05 | 83 | 2F | Dynamic Response Performance (Normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| 05 | 84 | 85 | Secondary Sensor Lambda Trim Correction of Primary Sensor | 0.999 to | 0.999 0.0000305/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 2 | |||||
| 06 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| 06 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0000 to 7.9900 V | 0.122 mv/bit |
| Catalyst Monitor | |||||
| 21 | 84 | 06 | Catalyst Test Bank 1 (normalized) | 0.000 to | 19.988 0.000305/bit |
| 22 | 84 | 06 | Catalyst Test bank 2 (normalized) | 0.000 to | 19.988 0.000305/bit |
| EVAP Monitor (Cap Off) | |||||
| 39 | 80 | 81 | EVPD Weak Vacuum Test - Gross Leak | 32768 to +32767 | 1 count/bit |
| EVAP Monitor 0.020" | EWMA = Exponentially Weighted Moving Average EONV = Engine Off Natural Vacuum | ||||
| 3C | 80 | 05 | EONV NV 0.020 Test - EWMA | 0.000 to 1.999 | 0.0000305/bit |
| Purge Flow Monitor | |||||
| 3D | 88 | 84 | Purge Valve Flow Test - Stuck Open/Leak | 32.768 to +32.767 | 0.001 count/bit |
| 3D | 8C | 81 | Canister Vent Valve Test - Stuck Closed/Restricted | 32768 to +32767 | 1 count/bit |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 1 | |||||
| 41 | 82 | 2F | Heater Power (normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 2 | |||||
| 42 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohm/bit |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 1 | |||||
| 45 | 82 | 2F | Heater Power (normalized) | 0.00 to 655.35 % | 0.01 %/bit |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 2 | |||||
| 46 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohm/bit |
| Fuel System Monitor Bank 1 | |||||
| 81 | 80 | AF | Additive Fuel (Offset) Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 81 | 82 | 05 | Multiplicative Fuel (Slope) Correction | 0.000 to | 1.999 0.0000305/bit |
| Fuel System Monitor Bank 2 | |||||
| 82 | 80 | AF | Additive Fuel Offset Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 82 | 82 | 05 | Multiplicative Fuel Slope Correction | 0.000 to | 1.999 0.0000305/bit |
| Misfire Cylinder 1 data | |||||
| A2 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A2 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 2 data | |||||
| A3 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A3 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 3 data | |||||
| A4 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A4 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 4 data | |||||
| A5 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A5 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 5 data | |||||
| A6 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
Mode $06 Data Definitions For 2005 Buick (3.6L)
2006 3.6L
| OBD Monitor ID (OBDMID) | Test ID (TID) | Units and Scaling ID (UASID) | Description | Range For Information ONLY. Source information is ISO-15031-5 document | Resolution For Information ONLY. Source information is ISO-15031-5 document |
|---|---|---|---|---|---|
| Oxygen Sensor Monitor Bank 1 Sensor 1 | |||||
| 01 | 83 | 05 | Dynamic Response Performance (Normalized) | 0.0 to 1.999 | 0.0000305/bit |
| 01 | 84 | 85 | Secondary Sensor Lambda Trim Correction of Primary Sensor | 0.999 to 0.999 | 0.0000305/bit |
| Oxygen Sensor Monitor Bank 1 Sensor 2 | |||||
| 02 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 81 | 0A | Equivalence Ratio (Lambda) - Measured Actual | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 82 | 0A | Equivalence Ratio (Lambda) - Commanded Set Point | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 83 | 0A | Dynamic Response Performance (Normalized) | 0.0 to 7.99 V | 0.122 mv/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 1 | |||||
| 05 | 83 | 05 | Dynamic Response Performance (Normalized) | 0.0 to 1.999 | 0.0000305/bit |
| 05 | 84 | 85 | Secondary Sensor Lambda Trim Correction of Primary Sensor | 0.999 to 0.999 | 0.0000305/bit |
| Oxygen Sensor Monitor Bank 2 Sensor 2 | |||||
| 06 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit |
| 06 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit |
| 06 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit |
| 06 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 81 | 0A | Equivalence Ratio (Lambda) - Measured Actual | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 82 | 0A | Equivalence Ratio (Lambda) - Commanded Set Point | 0.0 to 7.99 V | 0.122 mv/bit |
| 02 | 83 | 0A | Dynamic Response Performance (Normalized) | 0.0 to 7.99 V | 0.122 mv/bit |
| Catalyst Monitor | |||||
| 21 | 84 | 06 | Catalyst Test Bank 1 (normalized) | 0.0 to 19.988 | 0.000305/bit |
| 22 | 84 | 06 | Catalyst Test bank 2 (normalized) | 0.0 to 19.988 | 0.000305/bit |
| EVAP Monitor (Cap Off) | |||||
| 39 | 80 | 81 | EVPD Weak Vacuum Test - Gross Leak | 32768 to +32767 | 1.0/bit |
| EVAP Monitor 0.020" | EWMA = Exponentially Weighted Moving Average EONV = Engine Off Natural Vacuum | ||||
| 3C | 80 | 05 | EONV NV 0.020 Test - EWMA | 0.0 to 1.999 | 0.0000305/bit |
| Purge Flow Monitor | |||||
| 3D | 88 | 81 | Purge Valve Flow Test - Stuck Open/Leak | 32768 to +32767 | 1.0/bit |
| 3D | 8C | 81 | Canister Vent Valve Test - Stuck Closed/Restricted | 32768 to +32767 | 1.0/bit |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 1 | |||||
| 41 | 85 | 16 | Heater Temperature | 40 to 6513.5 °C | 0.1 °C per bit - 40°C |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 2 | |||||
| 42 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohm/bit |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 1 | |||||
| 45 | 85 | 16 | Heater Temperature | 40 to 6513.5 °C | 0.1 °C per bit - 40°C |
| Oxygen Sensor Heater Monitor Bank 2 Sensor 2 | |||||
| 46 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohm/bit |
| Fuel System Monitor Bank 1 | |||||
| 81 | 80 | AF | Additive Fuel (Offset) Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 81 | 82 | 05 | Multiplicative Fuel (Slope) Correction | 0.0 to 1.999 | 0.0000305/bit |
| Fuel System Monitor Bank 2 | |||||
| 82 | 80 | AF | Additive Fuel Offset Correction | 327.68 to +327.67 % | 0.01 %/bit |
| 82 | 82 | 05 | Multiplicative Fuel Slope Correction | 0.0 to 1.999 | 0.0000305/bit |
| Misfire Cylinder 1 data | |||||
| A2 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles 0 to 65535 | Counts | 1 count/bit |
| A2 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 2 data | |||||
| A3 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A3 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 3 data | |||||
| A4 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A4 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 4 data | |||||
| A5 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A5 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 5 data | |||||
| A6 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A6 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
| Misfire Cylinder 6 data | |||||
| A7 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit |
| A7 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit |
Mode $06 Data Definitions For 2006 Buick (3.6L)
2007-08 3.6L
| OBD Monitor ID (OBDMID) | Test ID (TID) | Units and Scaling ID (UASID) | Description | Range For Information ONLY. Source information is ISO-15031-5 document | Resolution For Information ONLY. Source information is ISO-15031-5 document | Associated DTC |
|---|---|---|---|---|---|---|
| Oxygen Sensor Monitor Bank 1 Sensor 1 | ||||||
| 01 | 83 | 05 | Dynamic Response Performance (Normalized) | 0.0 to 1.999 | 0.0000305/bit | P0133 |
| Oxygen Sensor Monitor Bank 1 Sensor 2 | ||||||
| 02 | 01 | 0A | Rich to Lean Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit | |
| 02 | 02 | 0A | Lean to Rich Sensor Threshold Voltage | 0.0 to 7.99 V | 0.122 mv/bit | |
| 02 | 05 | 10 | Rich to Lean Sensor Transient (Gradient) Time | 0 to 65535 ms | 1.0 ms/bit | P013A |
| 02 | 07 | 0A | Minimum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit | P0137 |
| 02 | 08 | 0A | Maximum Sensor Voltage Achieved | 0.0 to 7.99 V | 0.122 mv/bit | P0138 |
| 02 | 81 | 0A | Maximum Sensor Voltage for Functional Check | 0.0 to 7.99 V | 0.122 mv/bit | P2270 |
| 02 | 82 | 0A | Minimum Sensor Voltage for Functional Check | 0.0 to 7.99 V | 0.122 mv/bit | P2271 |
| 02 | 83 | 0A | Dynamic Response Performance - Decel Fuel Cut-Off | 0.0 to 7.99 V | 0.122 mv/bit | P2271 |
| 02 | 86 | 16 | Rich to Lean Sensor Delay (Response) Time | 0 to 655350 ms | 10.0 ms/bit | P013E |
| Catalyst Monitor | EWMA = Exponentially Weighted Moving Average | |||||
| 21 | 84 | 05 | Catalyst Test Bank 1 (normalized) - EWMA | 0.0 to 1.999 | 0.0000305/bit | P0420 |
| EVAP Monitor (Cap Off) | ||||||
| 39 | 80 | 81 | EVAP Tank Gross Leak | 32768 to +32767 | 1.0/bit | P0455 |
| EVAP Monitor 0.020" | EONV = Engine Off Natural Vacuum EWMA = Exponentially Weighted Moving Average | |||||
| 3C | 80 | 05 | EONV NV 0.020 Test - EWMA | 0.0 to 1.999 | 0.0000305/bit | P0442 |
| Purge Flow Monitor | ||||||
| 3D | 88 | 81 | Purge Valve Flow Test - Stuck Open/Leak | 32768 to +32767 | 1.0/bit | P0496 |
| 3D | 8C | 81 | Canister Vent Valve Test - Stuck Closed/Restricted | 32768 to +32767 | 1.0/bit | P0446 |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 1 | ||||||
| 41 | 85 | 16 | Heater Temperature | 40 to 6513.5 °C | 0.1 °C per bit - 40°C | P0135 |
| Oxygen Sensor Heater Monitor Bank 1 Sensor 2 | ||||||
| 42 | 81 | 14 | Sensor Element Impedance | 0 to 65535 Ohms | 1 Ohm/bit | P0141 |
| Fuel System Monitor Bank 1 | ||||||
| 81 | 80 | AF | Additive Fuel (Offset) Correction | 327.68 to +327.67 % | 0.01 %/bit | P2187, P2188 |
| 81 | 82 | 05 | Multiplicative Fuel (Slope) Correction | 0.0 to 1.999 | 0.0000305/bit | P2177, P2178 |
| Misfire Cylinder 1 data | ||||||
| A2 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit | P0301 |
| A2 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit | P0301 |
| Misfire Cylinder 2 data | ||||||
| A3 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit | P0302 |
| A3 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit | P0302 |
| Misfire Cylinder 3 data | ||||||
| A4 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit | P0303 |
| A4 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit | P0303 |
| Misfire Cylinder 4 data | ||||||
| A5 | 0B | 24 | EWMA (Exponentially Weighted Moving Average) misfire counts for the last 10 driving cycles | 0 to 65535 counts | 1 count/bit | P0304 |
| A5 | 0C | 24 | Misfire counts for the last/current driving cycles | 0 to 65535 counts | 1 count/bit | P0304 |
Mode $06 Data Definitions For 2007-08 Buick (3.6L)
