Contents Wiring diagrams Section: Door Locks & Anti-Theft Systems All sections

Door System, Mirror System & Window System Buick Century VI

Door Locks & Anti-Theft Systems 65 illustrations ~16611 words

Specifications

ApplicationSpecification
MetricEnglish
Armrest Pull Cup Screws2 N.m18 lb in
Armrest Screws4 N.m36 lb in
Body Side Upper and Lower Hinge Bolts33 N.m24 lb ft
Cone Adjuster Body Side Hinge Bolts10 N.m89 lb in
Door Armrest Bracket Screws10 N.m89 lb in
Front Door Lock Screws10 N.m89 lb in
Door Lock Striker Screws25 N.m18 lb ft
Door Side Upper and Lower Hinge Bolts33 N.m24 lb ft
Door Stationary Window Molding Screws2 N.m18 lb in
Door Window Weatherstrip Retainer Screws2 N.m18 lb in
Mirror Motor Screws10 N.m89 lb in
Front Door Lock Actuator Screws2 N.m18 lb in
Inner Trim Panel Screws2 N.m18 lb in
Inside Door Handle Bezel Screw2 N.m18 lb in
Intermediate Door Hinge Bolts33 N.m24 lb ft
Front Door Outer Belt Sealing Strip Screw2 N.m18 lb in
Outer Belt Sealing Strip Self-Tapping Screw2 N.m18 lb in
Outer Energy Absorber Pad Screws2 N.m18 lb in
Front Door Outside Handle Bolts10 N.m89 lb in
Front Door Window Bolts10 N.m89 lb in
Front Door Window Regulator Left Lower Mounting Screw10 N.m89 lb in
Front Door Window Regulator Motor Screws6 N.m53 lb in
Mirror Nuts10 N.m89 lb in
Rear Door Lock Screws10 N.m89 lb in
Rear Door Lock Actuator Screws2 N.m18 lb in
Rear Door Outside Handle Bolts10 N.m89 lb in
Rear Door Outer Belt Sealing Strip Screws2 N.m18 lb in
Rear Door Window Regulator Lower Mounting Screws10 N.m89 lb in
Rear Door Window Regulator motor Screws6 N.m53 lb in
Rear Door Stationary Window Bolt10 N.m89 lb in
Rear Door Stationary Window Screws2 N.m18 lb in
TORX Head Body Side Upper and Lower Hinge Bolt10 N.m89 lb in
Upper Seat Belt Guide Loop Attachment Nut43 N.m31 lb ft
Window Regulator Bolts10 N.m89 lb in
Window to Regulator Bolts10 N.m89 lb in

Fastener Tightening Specifications

Scheme 30

Scheme 30: Power Window Schematics
Scheme 30: Power Window Schematics

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32: Door Lock/Indicator Schematics
Scheme 32: Door Lock/Indicator Schematics

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35: Outside Mirror Schematics
Scheme 35: Outside Mirror Schematics

Scheme 36

Scheme 36: Power Door Systems Component Views
Scheme 36: Power Door Systems Component Views

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42: Power Door Systems Connector End Views
Scheme 42: Power Door Systems Connector End Views

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Diagnostic Starting Point - Doors

For the Outside Automatic Day-Night Mirror system, begin the diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to SYMPTOMS - DOORS in order to identify the correct procedure for diagnosing the system and where the procedure is located.

For the other door systems, begin the system diagnosis with the DIAGNOSTIC SYSTEM CHECK - DOOR SYSTEMS . The Diagnostic System Check will provide the following information

  1. The identification of the control module which commands the system
  2. The ability of the control module to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 2. Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
  2. 5. The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66: Scan Tool Output Controls
Scheme 66: Scan Tool Output Controls

Scheme 67

Scheme 67: Scan Tool Data List
Scheme 67: Scan Tool Data List

Scan Tool Data Definitions

Battery Voltage: The scan tool displays 0-25.5 volts. The state of the battery voltage supplied to the body control module (BCM).

Door Jamb Switch: The scan tool displays Open/Closed. The door jamb switch input to the BCM, where an open passenger door is displayed as Open.

Door Lock Output: The scan tool displays On/Off. The BCM output to the door lock actuators, where Lock is displayed as On.

Door Lock Switch: The scan tool displays Active/Inactive. The driver or passenger door lock switch input to the BCM, where a switch in Lock position is displayed as Active.

Door Unlock Output: The scan tool displays On/Off. The BCM output to the passenger door lock actuators, where Unlock is displayed as On.

Door Unlock Switch: The scan tool displays Active/Inactive. The driver or passenger door lock switch input to the BCM, where a switch in the Unlock position is displayed as Active.

Driver Door Switch: The scan tool displays Open/Closed. The driver door switch input to the BCM, where an open driver door is displayed as Open.

Driver Unlock Output: The scan tool displays On/Off. The BCM output to the driver door lock actuator, where Unlock is displayed as On.

Software Part Number: The scan tool displays the 8 digit part number of the BCM.

Trunk Ajar Switch: The scan tool displays On/Off. The trunk ajar switch input to the BCM, where an open trunk is displayed as On.

Symptoms - Doors

IMPORTANTFor the Outside Automatic Day-Night Mirror system, review the system operation in order to familiarize yourself with the system functions. Refer to OUTSIDE MIRROR DESCRIPTION AND OPERATION .

For the other Door systems, the following steps must be performed before using the symptom tables.

  1. Perform the «DIAGNOSTIC SYSTEM CHECK - DOOR SYSTEMS»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control module can communicate via the serial data link.
  2. Review the system operation in order to familiarize yourself with the system functions: Refer to «POWER WINDOWS DESCRIPTION AND OPERATION»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . Refer to «POWER DOOR LOCKS DESCRIPTION AND OPERATION»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . Refer to «DOOR AJAR INDICATOR DESCRIPTION AND OPERATION»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . Refer to «OUTSIDE MIRROR DESCRIPTION AND OPERATION»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the door systems. Refer to CHECKING AFTERMARKET ACCESSORIES .
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to TESTING FOR INTERMITTENT AND POOR CONNECTIONS in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. Power Windows Inoperative - «All Windows»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  2. Power Windows Inoperative - «Express Down Function»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  3. Power Windows Inoperative - «Lockout Function»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  4. Power Window Inoperative - «Driver Door»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  5. Power Window Inoperative - «Passenger Door»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  6. «Door Ajar Indicator Malfunction»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  7. «Power Door Locks Inoperative»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  8. «Power Mirrors Inoperative»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  9. «Heated Mirrors Inoperative»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)

Scheme 68

Scheme 68: All Windows
Scheme 68: All Windows

Scheme 69

Scheme 69: Express Down Function
Scheme 69: Express Down Function

Scheme 70

Scheme 70: Lockout Function
Scheme 70: Lockout Function

Scheme 71

Scheme 71: Driver Door
Scheme 71: Driver Door

Scheme 72

Scheme 72: Passenger Door
Scheme 72: Passenger Door

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74: Door Ajar Indicator Malfunction
Scheme 74: Door Ajar Indicator Malfunction

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77: Power Door Locks Inoperative
Scheme 77: Power Door Locks Inoperative

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79: Automatic Door Locks Inoperative
Scheme 79: Automatic Door Locks Inoperative

Diagnostic Aids

  1. If the power mirror system fuse is open and a short to ground in the battery positive voltage circuit is not detected, the fault could be a short to ground in one of the power mirror control circuits. This would open the power mirror system fuse when the mirror switch is pressed.
  2. If both power mirrors are inoperative on one or more axis, the most probable cause is a power mirror switch failure. However the fault could be an open circuit on two or more of the power mirror control circuits.
  3. The power mirror assembly is equipped with a pigtail harness and is not serviceable. If an internal open or short is detected in the power mirror assembly, replace the power mirror assembly.

The step numbers below refer to the step numbers on the diagnostic table.

  1. 6. This step tests the integrity of both the mirror control circuits and the power mirror switch. If both power mirrors are inoperative on one or more axis, begin testing by disconnecting one of the power mirrors, if an open circuit is detected and repaired for that power mirror, repeat step 6 for the other power mirror.
  2. 7. This step tests the integrity of the battery positive voltage circuit not the fuse.

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82: Heated Mirrors Inoperative
Scheme 82: Heated Mirrors Inoperative

Power Window Switch Replacement

CAUTIONDisconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.

Note. Apply protective coating/tape at the insertion point of the small flat-bladed tool in order to prevent damage to the inner door trim panel.

IMPORTANTWhen removing a door trim panel or switch plate, the ignition switch must be in the OFF position. This will eliminate the possibility of shorting out the switch if a flat-bladed tool, awl or metal object is used to remove the switch from the harness. Use a flat-bladed tool in order to remove the power window and door lock mounting plate assembly from the trim panel.
  1. Insert the tool at the front of the mounting plate. Press rearward to release the mounting plate retainer and lift up on the front of the plate.
  2. Press down on the rear of the mounting plate to disconnect the tab. Lift out the mounting plate with the switches attached.
  3. Disconnect the electrical connectors.
  4. Remove the switch from the mounting plate.

Installation Procedure

  1. Install the switches into the mounting plate.
  2. Connect the electrical connectors.
  3. Insert the mounting plate tab into the trim panel and press down on the front end to engage the front retainer.

Removal Procedure

IMPORTANTWhen removing a door trim panel or switch plate, the ignition switch must be in the OFF position. This will eliminate the possibility of shorting out the switch if a flat-bladed tool, awl or metal object is used to remove the switch from the harness.

Note. Apply protective coating/tape at the insertion point of the small flat-bladed tool in order to prevent damage to the inner door trim panel.

  1. Insert a plastic, flat-bladed tool at the front edge of the switch mounting plate. Press rearward to release the mounting plate retainer and lift up on the front of the plate.
  2. Lift the mounting plate and switch from the trim panel.
  3. Disconnect the electrical connector from the power window switch.
  4. Remove the switch from the mounting plate.
  1. Install the switch tabs into the mounting plate.
  2. Press down on the tabs in order to secure the switch.
  3. Connect the electrical connector to the window switch.
  4. Align the mounting plate to the door trim panel and press down to secure the retainer.

Scheme 83

Scheme 83: Removal Procedure
Scheme 83: Removal Procedure
  1. Remove the door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or to «HANDLE BEZEL REPLACEMENT - INSIDE - REAR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Press the lock switch retainers outward and remove the switch from the bezel retainers.
  1. Press the door lock switch into the door handle bezel retainers.
  2. Install the door handle bezel. Refer to «HANDLE BEZEL REPLACEMENT - INSIDE - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or to «HANDLE BEZEL REPLACEMENT - INSIDE - REAR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
CAUTIONDisconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.
IMPORTANTWhen removing a door trim panel or switch plate, the ignition switch must be in the OFF position. This will eliminate the possibility of shorting out the switch if a screwdriver, awl or metal object is used to remove the switch from the harness.

Note. Apply protective coating/tape at the insertion point of the small flat-bladed tool in order to prevent damage to the inner door trim panel.

  1. Insert a plastic flat-bladed tool at the front edge of the switch mounting plate. Press the tool rearward to release the mounting plate retainer and lift up on the front of the plate.
  2. Using a small flat-bladed tool, carefully release the window switch retainers and remove the switch.
  3. Disconnect the electrical connector from the switch.
  4. Remove the switch from the door.
  1. Install the power window switch assembly to the mounting plate.
  2. Connect the electrical connectors to the power window switch.
  3. Align the mounting plate into the door trim panel opening and press down to secure the retainer.
IMPORTANTThe bezel on the front inside door handle has an electrical connector for the power door lock system.
  1. Remove the inside door handle bezel screw.
  2. Using a small, flat-bladed tool, remove the inside door handle bezel from the door trim panel.
  3. Remove the inside door lock electrical connector.
  4. Remove the inside door handle bezel from the vehicle.
  1. Connect the door lock electrical connector to the inside door handle bezel.
  2. Press the bezel onto the door trim panel. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the bezel screw to the inside door handle. Tighten Tighten the screw to 2 N.m (18 lb in).
  1. Using a flat-bladed tool, remove the inside door handle bezel from its retainers.
  2. Slide the bezel off the door handle and remove it from the trim panel.
  1. Slide the bezel onto the rear door handle.
  2. Align the connecting clips on the bezel to the rear door trim panel.
  3. Press on the bezel to secure the clips.
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the screws securing the armrest to the trim panel.
  3. Remove the arm rest from the trim panel.
  1. Position the armrest on the door panel. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the armrest screws. Tighten Tighten the armrest screws to 3.5 N.m (31 lb in).
  3. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the armrest bracket screws.
  4. Remove the armrest bracket.
  1. Position the armrest bracket in place. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the armrest bracket screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  3. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Install the trim panel. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Tools Required

J 38778 Door Trim Pad Clip Remover

  1. Remove the power window switch mounting plate. Refer to «POWER WINDOW SWITCH REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-window-switch-replacement) .
  2. Remove the cover in the armrest pull cup.
  3. Remove the armrest pull cup screws.
  4. Remove the screw from the inside door handle bezel.
  5. Insert a flat-bladed tool at the front edge of the bezel. Pry up to remove the bezel from its clips.
  6. Disconnect the electrical connector from the door lock switch.
  7. Disconnect the electrical connector from the reflector/courtesy lamp, if equipped.
  8. Starting at the door bottom, use the J 38778 to disengage the retainers from the door trim panel.
  9. Lift the trim panel up to release the top edge and move it away from the door.
  10. Disconnect the electric connector to the radio speaker.
  11. Remove the door panel.
IMPORTANTBefore installing the door trim panel to the door, discard the old trim panel retainers. Use new trim panel retainers in order to properly secure the trim panel to the door.
  1. Install the new trim panel retainers to the trim panel.
  2. Position the trim panel by the door and connect the electrical connector to the speaker.
  3. Connect the electrical connector to the reflector/courtesy lamp, if equipped.
  4. Position the top of the trim panel at the window opening and press down.
  5. Align the fasteners into the holes in the door metal.
  6. Press on the trim panel in order to secure the fasteners into the door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  7. Install the armrest pull cup screws. Tighten Tighten the armrest pull cup screws to 2 N.m (18 lb in).
  8. Install the cover over the pull cup screws.
  9. Connect the electrical connector to the door lock switch.
  10. Install the door handle bezel.
  11. Install the inside door handle bezel screw. Tighten Tighten the inside door handle bezel screw to 2 N.m (18 lb in).
  12. Install the power window switch. Refer to «POWER WINDOW SWITCH REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__power-window-switch-replacement) .

J 38778 Door Trim Pad Clip Remover

  1. Remove the power window switch (3), if equipped. Refer to «POWER WINDOW SWITCH REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the arm rest pull cup cover (1).
  3. Remove the armrest pull cup screws.
  4. Starting at the door bottom, use the J 38778 to release the door trim panel retainers.
  5. Lift the trim panel up to release the top edge and remove it from the door.
IMPORTANTBefore installing the door trim panel to the door, discard the old trim panel retainers. Use new trim panel retainers in order to properly secure the trim panel to the door.
  1. Install the new trim panel retainers to the trim panel.
  2. Position the top of the trim panel at the window opening and press down.
  3. Align the fasteners into the holes in the door metal.
  4. Firmly press the door panel to seat the fasteners. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the armrest pull cup screws. Tighten Tighten the armrest pull cup screws to 2 N.m (18 lb in).
  6. Install the armrest pull cup cover (1).
  7. Install the power window switch (3). Refer to «POWER WINDOW SWITCH REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
CAUTIONThis vehicle has energy-absorbing foam blocks for side impact protection. To help avoid personal injury in a collision, foam blocks that are damaged, or removed during repairs must be replaced. Failure to replace foam blocks that are removed can violate federal law.
  1. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove energy absorber clip.
  4. Grasp the energy absorber with both hands and remove from the front door.
  1. Remove the protective tape from the adhesive strip on the back side of the absorber pad.
  2. Install the energy absorber pad to the front door, Pressing firmly until the energy absorber pad is fully seated.
  3. Install the energy absorber clip.
  4. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Open the door.
  2. Remove the front door trim. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. From inside the trim panel, press the reflector retaining tabs together and push the reflector out.
  4. Remove the warning reflector from the trim panel.
  1. Press the warning reflector back into the trim panel.
  2. Close the door.
  1. Remove the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. From inside the trim panel, press the reflector retaining tabs in toward the center of the reflector.
  3. Remove the reflector (2) from the door trim.
  1. Press the warning reflector (2) back into place.
  2. Install the door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door radio speaker. Refer to SPEAKER REPLACEMENT - FRONT DOOR .
  3. Disconnect the power mirror electrical connector.
  4. Remove the front door water deflector from the front door.
IMPORTANTA clear waterproof sound deadener deflector seals the door inner panel. Pressure-sensitive adhesive located on the outboard surface of the deflector secures the deflector to the door inner panel. The deflector may be peeled back as needed in order to service the door components.
  1. Position the front door water deflector to the inner door panel.
  2. Install the front door handle through the front door water deflector.
  3. Connect the power mirror electrical connector.
  4. Press the front door water deflector to the front door until fully seated.
  5. Install the front door radio speaker. Refer to SPEAKER REPLACEMENT - FRONT DOOR .
  6. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. remove the rear door water deflector from the rear door inner panel.
IMPORTANTA clear waterproof sound deadener deflector seals the door inner panel. Pressure-sensitive adhesive located on the outboard surface of the deflector secures the deflector to the door inner panel. The deflector may be peeled back as needed in order to service the door components.
  1. Position the rear door water deflector to the rear door inner panel. Align the hook pockets with the trim hook holes in the rear door inner panel.
  2. Press the rear door water deflector to the rear door inner panel until fully seated.
  3. Install the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Up/Down or In/Out Adjustment

IMPORTANTThe door side upper and lower hinge bolts must remain tight enough to retain door adjusted position.
  1. Loosen the 13 mm door side upper and lower hinge bolts. Do not remove the bolts.
  2. Adjust the door up or down by repositioning the door as needed.
  3. Adjust the door in or out by repositioning the door as needed. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  4. Tighten the 13 mm door side hinge bolts. Tighten Tighten the door side upper and lower hinge bolts to 33 N.m (24 lb ft).

Fore/Aft Adjustment

  1. Remove the front fender insulator in order to gain access to the body side hinge bolts. Refer to FENDER SOUND INSULATOR REPLACEMENT - FRONT in Body Front End.
  2. Loosen the 13 mm body side upper and lower hinge bolts (1). Do not remove the bolts (1).
  3. Loosen one 10 mm cone adjuster body side hinge bolt (3). Do not remove the bolt.
  4. Loosen the TORX® body side upper and lower hinge bolts (2). Do not remove the bolt.
  5. Adjust the door fore and aft by repositioning the door as needed. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  6. Tighten the TORX® body side upper and lower hinge bolts. Tighten Tighten the TORX® head body side hinge bolt to 10 N.m (89 lb in).
  7. Tighten the 10 mm cone adjuster body side hinge bolt. Tighten Tighten the cone adjuster body side hinge bolt to 10 N.m (89 lb in).
  8. Tighten the 13 mm body side hinge bolts. Tighten Tighten the body side upper and lower hinge bolts to 33 N.m (24 lb ft).
  9. Install the front fender insulator. Refer to FENDER SOUND INSULATOR REPLACEMENT - FRONT in Body Front End.
  1. Remove the rubber conduit. Refer to «RUBBER CONDUIT REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the door speaker. Refer to SPEAKER REPLACEMENT - FRONT DOOR .
  5. Disconnect the electrical connectors.
  6. Remove the front door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Remove the front door outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Remove the window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Remove the window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  10. Remove the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Remove the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .
  12. Remove the inside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  13. Remove the lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  14. Remove the door side molding. Refer to «GARNISH MOLDING REPLACEMENT - FRONT DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  15. Support the door.
  16. Remove the intermediate door hinge bolts.
  17. Remove the door.

Note. Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.

  1. Install the intermediate door hinge bolts. Tighten Tighten the bolts to 33 N.m (24 lb ft).
  2. Remove the support.
  3. Install the door side moldings. Refer to «GARNISH MOLDING REPLACEMENT - FRONT DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Install the lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the inside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT INSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .
  7. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - FRONT DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Install the window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  10. Install the front door outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system)
  11. Install the front door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  12. Connect the electrical connectors.
  13. Install the door speaker. Refer to SPEAKER REPLACEMENT - FRONT DOOR .
  14. Install the rubber conduit. Refer to «RUBBER CONDUIT REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  15. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  16. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  17. Adjust the door. Refer to «DOOR ADJUSTMENT - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
IMPORTANTThe door side upper and lower hinge bolts must remain tight enough to retain door adjusted position.
  1. Loosen the 13 mm door side upper and lower hinge bolts. Do not remove the bolts.
  2. Adjust the door up or down by repositioning the door as needed.
  3. Adjust the door in or out by repositioning the door as needed. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  4. Tighten the 13 mm door side upper and lower hinge bolts. Tighten Tighten the door side hinge bolts to 33 N.m (24 lb ft).
  1. Loosen the two 13 mm body side upper and lower hinge bolts (1). Do not remove them.
  2. Loosen the 10 mm cone adjuster body side hinge bolt (1).
  3. Adjust the door fore and aft by repositioning the door as needed. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  4. Install the one 10 mm cone adjuster (1) body side hinge bolt. Tighten Tighten the cone adjuster body side hinge bolt to 10 N.m (89 lb in).
  5. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the body side hinge bolts.
  6. Install two 13 mm body side hinge bolts (1). Tighten Tighten the body side hinge bolts to 33 N.m (24 lb ft).
  1. Remove the rubber conduit. Refer to «RUBBER CONDUIT REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the rear door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Remove the rear door outer sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Remove the stationary window molding.
  7. Remove the rear door frame molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Remove the window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Remove the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-rear-outside) .
  10. Remove the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Remove the lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  12. Remove the door window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - REAR DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  13. Remove the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  14. Disconnect the wiring harness.
  15. Support the door.
  16. Remove the intermediate door hinge bolts (1).
  17. Remove the door.
  1. Use the aid of an assistant in order to install the door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the intermediate door hinge bolts (1). Tighten Tighten the bolts to 33 N.m (24 lb ft).
  3. Remove the support.
  4. Connect the wiring harness.
  5. Install the window regulator. Refer to «WINDOW REGULATOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the door window weatherstrip. Refer to «WEATHERSTRIP REPLACEMENT - REAR DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Install the lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the inside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR INSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Install the outside door handle. Refer to «DOOR HANDLE REPLACEMENT - REAR OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-rear-outside) .
  10. Install the window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Install the rear door frame molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  12. Install the stationary window molding.
  13. Install the rear door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  14. Install the rear door outer sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  15. Install the rubber conduit. Refer to «RUBBER CONDUIT REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  16. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  17. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  18. Adjust the door. Refer to «DOOR ADJUSTMENT - REAR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

J 36604 Door Hinge Spring Compressor

  1. Open the door.
  2. Using J 36604, remove the door hinge spring from the door hinge.
  3. Remove the door hinge spring from the vehicle.
  1. Using J 36604, install the door hinge spring to the door hinge.
  2. Close the door.

The hinges are bolted to the door and body. The door side hinges have elongated holes which allow for some up and down, in and out adjustment. The body side hinges have elongated holes which allow for some fore and aft adjustment.

IMPORTANTIn order to minimize door realignment, do not remove both door hinges at the same time. Do each hinge separately and replace any broken hinges first.

Scheme 84

Scheme 84
Scheme 84
  1. Open the door.
  2. Support the door.
  3. Remove the intermediate door hinge bolts.
  4. Remove the hinge spring.
  5. Move the door away from the front pillar as far as the conduit will allow.
  6. Clean the hinge mounting surfaces on the door with a rag and mark the hinge location on the door surface with a grease pencil or other suitable marker.
  7. Remove the bolts from the door side hinge.
  8. Remove the door side hinge. IMPORTANT: The body side door hinge has the following 4 attaching bolts: Two 13 mm One TORX® One 10 mm bolt A cone attached to the back side of the hinge may fall off and end up in the bottom of the front pillar. This cone is used for assembly purposes only and need not be removed in order to adjust or remove the door hinge strap (body side hinge).
  9. Use a rag in order to clean the hinge mounting surface on the body pillar.
  10. Use a grease pencil or other suitable marker in order to mark the hinge location on the body pillar.
  11. Remove the front fender insulator in order to gain access to the body side hinge bolts (1, 2, 3). Refer to FENDER SOUND INSULATOR REPLACEMENT - FRONT in Body Front End. IMPORTANT: Do not loosen the cone adjuster bolt (1) (10 mm hex head). The cone may fall down inside the pillar. This may create a rattle situation.
  12. Remove the two 13 mm body side hinge bolts (2).
  13. Remove the one TORX® head body side hinge bolt.
  14. Remove the body side hinge.

Scheme 85

Scheme 85: Installation Procedure
Scheme 85: Installation Procedure
  1. Align the new door side hinge in position with the old alignment marks. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the door side hinge bolts.
  3. Install the door side hinge bolts. Tighten Tighten the door side hinge bolts to 33 N.m (24 lb ft).
  4. Align the new body side hinge in position with the old alignment marks.
  5. Install two 13 mm body side hinge bolts. Tighten Tighten the body side hinge bolts to 33 N.m (24 lb ft).
  6. Install the TORX® head (1) body side hinge bolt. Tighten Tighten the TORX® head bolt to 10 N.m (89 lb in).
  7. Install the intermediate door hinge bolts. Tighten Tighten the intermediate door hinge bolts to 33 N.m (24 lb ft).
  8. Install the front fender insulator. Refer to FENDER SOUND INSULATOR REPLACEMENT - FRONT in Body Front End.
  9. Remove the door support.
  10. Adjust the door. Refer to «DOOR ADJUSTMENT - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Close the door.
  1. Open the rear door.
  2. Using J 36604, remove the rear door hinge spring from the rear door hinge.
  3. Remove the door hinge spring from the vehicle.
  1. Using J 36604, install the rear door hinge spring to the rear door hinge.
  2. Close the rear door.
IMPORTANTIn order to minimize door realignment, do not remove both door hinges at the same time. Do each hinge separately, and replace any broken hinges first.

Scheme 86

Scheme 86
Scheme 86
  1. Open the door.
  2. Support the door.
  3. Remove the intermediate door hinge bolts.
  4. Remove the hinge spring.
  5. Use a rag in order to clean the hinge mounting surfaces on the door.
  6. Use a grease pencil or other suitable marker in order to mark the hinge location on the door surface.
  7. Remove the door side hinge bolts.
  8. Remove the hinge.
  9. Use a rag in order to clean the hinge mounting surface on the body pillar.
  10. Use a grease pencil or other suitable marker in order to mark the hinge location on the body pillar. IMPORTANT: Do not loosen the cone adjuster bolt (2). The cone may fall down inside the pillar. This may create a rattle situation.
  11. Remove the two 13 mm body side hinge bolts (1).
  12. Remove the body side hinge.
  1. Align the new hinge in position with the old alignment marks. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the door side hinge bolts.
  3. Install the door side hinge bolts. Lightly tighten the bolts.
  4. Align the new body side hinge in position with the old alignment marks.
  5. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the body side hinge bolts.
  6. Install the 13 mm body side hinge bolts (1) Lightly tighten the bolts.
  7. Position the door to install the intermediate bolts.
  8. Install the hinge spring.
  9. Install the intermediate door hinge bolts. Tighten Tighten the intermediate door hinge bolts to 33 N.m (24 lb ft). Tighten Tighten the body side and door side hinge bolts to 33 N.m (24 lb ft).
  10. Remove the door support.
  11. Adjust the door. Refer to «DOOR ADJUSTMENT - REAR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  12. Close the door.

Door Handle Replacement - Front Outside

The outside handles have adjustable outside handle-to-lock rods. This allows for adjustment of the amount of travel needed in order to operate the outside handle.

When servicing a vehicle with adjustable outside handle-to-lock rods, remove all free play between the outside handle and the lock. Also, do not operate the outside handle before these connections are made.

  1. Apply masking tape to the front door outer panel around the front door outside handle.
  2. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Disconnect the front door outside handle rod from the front door lock.
  4. Disconnect the front door outside handle lock rod from the front door lock.
  5. Remove the front door outside handle bolts.
  6. Rotate the front door outside handle to clear the door handle opening.
  7. Remove the front door outside handle from the front door.
  1. Position the front door outside handle to the front door.
  2. Rotate the front door outside handle to install into the front door handle opening. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the front door outside handle bolts. Tighten Tighten the bolts to 10 N.m (89 lb in).
  4. Connect the front door outside handle lock rod from the front door lock.
  5. Connect the front door outside handle rod from the front door lock.
  6. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Remove the masking tape from the front door.

Door Handle Replacement - Rear Outside

The outside handles have adjustable outside handle-to-lock rods. This allows for adjustment of the amount of travel needed in order to operate the outside handle.

When servicing a vehicle with adjustable outside handle-to-lock rods, remove all free play between the outside handle and the lock. Also, do not operate the outside handle before these connections are made.

Scheme 87

Scheme 87: Door Handle Replacement - Rear Outside
Scheme 87: Door Handle Replacement - Rear Outside
  1. Apply masking tape to the rear door outer panel around the rear door outside handle.
  2. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the rear door energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Disconnect the rear door outside handle rod from the rear door lock.
  5. Remove the rear door outside handle bolts (3).
  6. Rotate the rear door outside handle to clear the rear door handle opening.
  7. Remove the rear door outside handle rod (1) from the rear door outside handle (2).
  1. Install the rear door outside handle rod (1) to the rear door outside handle (2).
  2. Position the rear door outside handle (2) and rear door outside handle rod (1) to the rear door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the rear door outside handle bolts (3). Tighten Tighten the bolts to 10 N.m (89 lb in).
  4. Connect the rear door outside handle lock rod to the rear door lock.
  5. Install the rear door energy absorber pad. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Remove the masking tape from the rear door.
  1. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the water deflector as needed. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Use side cutters in order to cut off the outside handle rod-to-lock clip from the lock.
  4. Unscrew the remainder of the clip from the outside handle rod. Discard the clip.
  1. In order to adjust, install a new outside handle rod-to-lock clip onto the door lock lever.
  2. Position the outside door handle rod in the clip in order to eliminate any free play in the outside door handle.
  3. Press the cover closed over the threaded outside door handle rod.
  4. Install the water deflector as needed. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Inspect the door lock system for proper operation.
  1. Remove the front door outside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .
  2. Remove the outside handle rod from door handle.
  1. Install the outside handle rod to the door handle.
  2. Install the front door outside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .
  1. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the water deflector as needed. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Use side cutters in order to cut off the outside handle rod-to-lock clip from the lock.
  4. Unscrew the remainder of the clip from the outside handle rod.
  5. Discard the clip.
  1. In order to adjust, snap a new outside handle rod-to-lock clip onto the door lock lever.
  2. Position the outside door handle rod in the clip in order to eliminate any free play in the outside door handle.
  3. Press the clip cover closed over the threaded outside door handle rod.
  4. Install the water deflector as needed. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Place the window in the full up position.
  2. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . CAUTION: Standard shop practices, particularly eye protection, should be followed during these operations to avoid personal injury. IMPORTANT: Support the back side of the rivet while driving the mandrel out to avoid bending the metal.
  3. Use a center punch to remove the rivet mandrel.
  4. Use a 6.35 mm (1/4 in) drill bit in order to drill out the door handle rivet.
  5. Open the handle clip in order to remove the lock rod from the handle.
  6. Open the handle clip in order to remove the handle rod from the handle.
  7. Remove the inside door handle.
  1. Position the door handle tabs in the door.
  2. Install the handle rod to the handle and press the clip to secure the rod.
  3. Install the lock rod to the handle and press the clip to secure the rod.
  4. Install a new door handle rivet.
  5. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Close the window.
  1. Position the window to the full up position.
  2. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . CAUTION: Standard shop practices, particularly eye protection, should be followed during these operations to avoid personal injury. IMPORTANT: Support the back side of the rivet while driving the mandrel out to avoid bending the metal.
  4. Use a center punch to remove the rivet mandrel (2).
  5. Drill out the rivet using a 6.35 mm (1/4 in) drill bit.
  6. Open the handle clip and remove the lock rod from the handle.
  7. Open the handle clip and remove the handle rod from the handle.
  8. Remove the handle from the inner panel.
  1. Install the handle by inserting the tabs into the inner panel slots.
  2. Install the lock rod to the handle. Press the clip in order to secure the lock rod.
  3. Install the handle rod to the handle. Press the clip in order to secure the handle rod.
  4. Install a new rivet (2).
  5. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the inside handle rod from the lock.
  1. Install the inside handle rod to the lock.
  2. Install the lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the inside handle rod from the lock.
  1. Install the inside handle rod to the lock.
  2. Install the lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Disconnect the front door inside handle rods.
  3. Disconnect the front door inside handle rods from the front door inside rod block.
  4. Disconnect the front door outside handle rods.
  5. Remove the front door lock screws (1,2,3).
  6. Remove the front door lock from inside the front door.
  7. Disconnect the front door lock electrical connectors.
  8. Remove the front door inside handle rods from the front door lock.
  1. Install the front door inside handle rods to the front door lock.
  2. Connect the front door lock electrical connectors.
  3. Position the front door lock into the front door.
  4. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the front door lock screws. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the front door lock screws in the correct fastener tightening sequence (top, bottom, middle, 1,2,3). Tighten Tighten the screws to 10 N.m (89 lb in).
  6. Connect the front door outside handle rods.
  7. Connect the front door inside handle rods.
  8. Connect the front door inside handle rods to the front door inside rod block.
  9. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Disconnect the rear door outside handle rod from the rear door lock.
  3. Disconnect the rear door inside handle rods.
  4. Disconnect the rear door inside handle rods from the rear door inside rod block.
  5. Remove the rear door lock screws (1, 2, 3,).
  6. Remove the rear door lock from the rear door.
  7. Disconnect the rear door lock electrical connectors.
  8. Remove the rear door inside handle rods from the rear door lock.
  1. Install the rear door inside handle rods to the rear door lock.
  2. Connect the rear door lock electrical connectors.
  3. Position the rear door lock into the rear door.
  4. Apply Locktite® Blue GM P/N 12345382, or Canadian P/N 10953489, or equivalent prior to installing the rear door lock screws. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the rear door lock screws in the correct fastener tightening sequence (top, bottom, middle, 1,2,3). Tighten Tighten the screws to 10 N.m (89 lb in).
  6. Connect the rear door inside handle rods.
  7. Connect the rear door inside handle rods to the rear door inside rod block.
  8. Connect the rear door outside handle rod to the rear door lock.
  9. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. This procedure covers the removal and installation of the front and rear door. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or Remove the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the retaining guide block (1). Pull the rod (2) upward until it releases from the retaining guide block.
IMPORTANTLocate the opening in the retaining guide block (1).
  1. Install the inside handle rod to the retaining guide block (1), push inward to secure the rod.
  2. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or Install the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door lock actuator screws.
  3. Remove the front door lock actuator from the front door lock.
  1. Position the front door lock actuator to the front door lock. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the front door lock actuator screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install the front door lock. Refer to «LOCK REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the rear door lock actuator screws.
  3. Remove the rear door lock actuator from the rear door lock.
  1. Position the rear door lock actuator to the rear door lock. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the rear door lock actuator screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Install the rear door lock. Refer to «LOCK REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Lock Cylinder Replacement - Door

The door locks use the fork bolt lock design which includes a safety interlock feature. The door is secured in a closed position when the door lock fork bolt engages the striker. Lock the doors from the inside by sliding the lock knob rearward. The door may also be locked by using the key.

IMPORTANTDo not attempt repairs in order to correct lock discrepancies. Replace the lock.
  1. Remove the outside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .
  2. Remove the lock cylinder retainer clip.
  3. Remove the lock from the handle.
  1. Install the lock to the handle.
  2. Install the lock cylinder retainer clip.
  3. Install the outside handle. Refer to «DOOR HANDLE REPLACEMENT - FRONT OUTSIDE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__door-handle-replacement-front-outside) .

Frozen Lock Cylinder Repair

Tools Required : J 25070 Heat Gun

Repair frozen lock cylinders due to cold weather using the following procedure

IMPORTANTBe careful not to damage painted surfaces while using a heat gun.
  1. Apply heat to the cylinder area with a heat gun J 25070.
  2. Use a paper clip or similar item in order to hold the shutter door open.
  3. Use compressed air and a blow gun attachment in order to force air into the cylinder.
  4. While holding the shutter door open, inject a small amount of multi-purpose lubricant GM P/N 12346241 (Canadian P/N 10953474) or equivalent.
  5. Work the key into the cylinder several times.
  6. Wipe any excess lubrication residue from the key.

Each lock striker is a dual-pin type that attaches to an anchor plate in the body lock pillar. The door is held in the closed position when the lock snaps over and engages the striker.

  1. Mark the position of the striker.
  2. Remove the screws.
  3. Remove the door lock striker.
  4. Remove the spacers as equipped.
  5. Remove the washer.
  1. Install the washer.
  2. Install any spacers that were removed.
  3. Install the striker to the location marked. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  4. Install the door lock striker screws. Tighten Tighten the door lock striker screws to 25 N.m (18 lb ft).
  5. Inspect the striker-to-lock engagement. If the adjustment is needed refer to «LOCK STRIKER ADJUSTMENT - DOOR (WITH MINI WEDGE)»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system__lock-striker-adjustment-door-with) or «LOCK STRIKER ADJUSTMENT - DOOR (W/O MINI WEDGE)»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Lock Striker Adjustment - Door (With Mini Wedge)

Tools Required : J 39346-A Mini-Wedge Door Striker Aligner

IMPORTANTThe door must be properly aligned before adjusting the striker.
  1. Open the door.
  2. Loosen the door striker screws just enough to allow movement of the door striker.
  3. Install the special tool J 39346-A Mini-Wedge Door Striker Aligner. IMPORTANT: Do not slam the door.
  4. Close the door while holding the outside handle in the open position.
  5. Open the door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  6. Tighten the door lock striker screws. Tighten Tighten the door striker screws to 25 N.m (18 lb ft).
  7. Remove the special tool J 39346-A Mini-Wedge Door Striker Aligner.
  8. Close the door.

Striker Adjustment Using Clay or Caulk

IMPORTANTThe door must be properly aligned before adjusting the striker.
  1. Open the door.
  2. Loosen the door striker screws just enough to allow movement of the door striker.
  3. Adjust the door striker up or down and inboard or outboard as required.
  4. Apply modeling clay or body caulking compound to the door lock opening. IMPORTANT: Do not close the door all the way.
  5. Close the door far enough for the striker to make an impression into the modeling clay or body caulking compound.
  6. Open the door and check the door striker impression in the modeling clay or body caulking compound. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  7. Readjust door striker as required. Add or remove spacers as needed. Tighten Tighten the door striker screws to 25 N.m (18 lb ft).
  8. Close the door.

Door Hardware Lubrication

The mechanical components of the door are lubricated during assembly. If additional lubrication is required to any door hardware mechanism, lubricate with the following lubricants. All door lock cylinders should be lubricated with a multi-purpose lubricant, Super-Lube® GM P/N 12346241 (Canadian P/N 10953474) or equivalent. The remainder of all door hardware mechanisms except locks can be lubricated with Lubriplate auto-lube A GM P/N 1052196 or equivalent.

Scheme 88

Scheme 88: Door Hardware Lubrication
Scheme 88: Door Hardware Lubrication

Causes of Slow Moving Glass

CAUTIONDisconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.

Scheme 89

Scheme 89
Scheme 89
  1. Owners may comment that the windows (door glass) operates slowly when going up or down.
  2. Listed below are 4 conditions that may cause slow moving glass. The glass run channel outboard lip at the rearview mirror is rolled over or the glass run channel outboard lip at the door rear, is rolled over (2). The glass run channel is not seated at the door rear. The glass is misaligned in the opening. The regulator is misaligned causing misalignment of the glass.

Scheme 90

Scheme 90: Adjustment Procedure
Scheme 90: Adjustment Procedure
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . Condition 2.1: Using a flat-bladed tool, straighten the run channel lip by pulling it out to its correct position. Condition 2.2: Use a flat-bladed tool to push the run channel rearward to seat it in the door frame. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. Condition 2.3: Loosen the window to regulator bolts. Rotate the cam (5) on the window regulator plate so that the slot (6) is straight up and down. In this position, the back of the glass will tilt forward. Tighten Tighten the 2 window to regulator bolts to 10 N.m (89 lb in). Condition 2.4: Loosen the window to regulator bolts. Loosen the 4 regulator bolts. Now, tighten the window regulator bolts according to the tightening sequence (1, 2, 3, 4). Tighten Tighten the 4 window regulator bolts to 10 N.m (89 lb in). Tighten the 2 window to regulator bolts. Tighten Tighten the 2 window to regulator bolts to 10 N.m (89 lb in).
  3. Connect the power window switch.
  4. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
CAUTIONDisconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.

Scheme 91

Scheme 91
Scheme 91
  1. Owners may comment that the windows (door glass) operates slowly when going up or down.
  2. Listed below are 4 conditions that may cause slow moving glass. The glass run channel outboard lip at the rearview mirror is rolled over or the glass run channel outboard lip at the door rear, is rolled over (2). The glass run channel is not seated at the door rear. The glass is misaligned in the opening. The regulator is misaligned causing misalignment of the glass.

Scheme 92

Scheme 92: Adjustment Procedure
Scheme 92: Adjustment Procedure
  1. Remove the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . Condition 2.1: Using a flat-bladed tool, straighten the run channel lip by pulling it out to its correct position. Condition 2.2: Use a flat-bladed tool to push the run channel rearward to seat it in the door frame. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. Condition 2.3: Loosen the window to regulator bolts. Rotate the cam (5) on the window regulator plate so that the slot (6) is straight up and down. In this position, the back of the glass will tilt forward. Tighten Tighten the 2 window to regulator bolts to 10 N.m (89 lb in). Condition 2.4: Loosen the window to regulator bolts. Loosen the 4 regulator bolts. Now, tighten the window regulator bolts according to the tightening sequence (1, 2, 3, 4). Tighten Tighten the 4 window regulator bolts to 10 N.m (89 lb in). Tighten the 2 window to regulator bolts. Tighten Tighten the 2 window to regulator bolts to 10 N.m (89 lb in).
  3. Connect the power window switch.
  4. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the arm rest bracket. Refer to «ARMREST REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . IMPORTANT: The window regulator screws are seated into key slots in the inner door panel and is unnecessary to remove the screws completely from the window regulator.
  4. Loosen the front door window regulator mounting screws.
  5. Remove the front door window regulator rail left lower mounting screw.
  6. Lower the front door window regulator motor into the front door to gain access to the electrical connector.
  7. Disconnect the front door window regulator motor electrical connector.
  8. Remove the front door window regulator from the front door.
  1. Position the front door window regulator into the front door.
  2. Connect the front door window regulator motor electrical connector.
  3. Position the front door window regulator motor inside the front door and install it into the key slots in the inner door panel.
  4. Position the front door window regulator rail assembly into the key slots in the inner door panel. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the front door window regulator rail left lower mounting screw. Tighten Tighten the screw to 10 N.m (89 lb in). IMPORTANT: In order to ensure proper orientation of the window regulator to the door, tighten the remaining window regulator screws in the specified sequence; lower rear, upper rear, lower front, upper front.
  6. Hand tighten the remaining front door window regulator screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  7. Install the front door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the arm rest bracket. Refer to «ARMREST REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the rear door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the rear door window regulator rail lower mounting screws. IMPORTANT: The window regulator screws are seated into key slots in the inner door panel and is unnecessary to remove the screws completely from the window regulator.
  4. Loosen the rear door window regulator mounting screws.
  5. Lower the rear door window regulator motor into the rear door to gain access to the electrical connector.
  6. Disconnect the rear door window regulator motor electrical connector.
  7. Remove the rear door window regulator from the rear door.
  1. Position the rear door window regulator into the rear door.
  2. Connect the rear door window regulator motor electrical connector.
  3. Position the rear door window regulator motor inside the rear door and install it into the key slots in the inner door panel.
  4. Position the rear door window regulator rail assembly inside the rear door and install it into the key slots in the inner door panel. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the rear door window regulator rail lower mounting screws. Tighten Tighten the screws to 10 N.m (89 lb in). IMPORTANT: In order to ensure proper orientation of the window regulator to the door, tighten the remaining window regulator screws in the specified sequence; lower rear, upper rear, lower front, upper front.
  6. Hand tighten the remaining rear door window regulator screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  7. Install the rear door window. Refer to «WINDOW REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . IMPORTANT: The window regulator screws are seated into key slots in the inner door panel and is unnecessary to remove the screws completely from the window regulator motor.
  2. Loosen the 3 front door window regulator screws.
  3. Position the front door window regulator motor through the access opening in the inner door to gain access to the electrical connector and the front window regulator motor screws.
  4. Disconnect the front door window regulator motor electrical connector.
  5. Remove the front door window regulator motor screws.
  6. Remove the front door window regulator motor and bracket from the front door window regulator.
  1. Position the front door window regulator motor and bracket to the front door window regulator. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the front door window regulator motor screws. Tighten Tighten the screws to 6 N.m (53 lb in).
  3. Connect the front door window regulator motor electrical connector.
  4. Position the front door window regulator motor inside the front door and install it into the key slots in the inner door panel.
  5. Hand tighten the front door window regulator screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  6. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) . IMPORTANT: The window regulator screws are seated into key slots in the inner door panel and is unnecessary to remove the screws completely from the window regulator.
  2. Loosen the 3 rear door window regulator screws.
  3. Position the rear door window regulator motor through the access opening in the inner door to gain access to the electrical connector and the rear window regulator motor screws.
  4. Disconnect the rear door window regulator motor electrical connector.
  5. Remove the rear door window regulator motor screws.
  6. Remove the rear door window regulator motor and bracket from the rear window regulator.
  1. Position the rear door window regulator motor and bracket to the rear door window regulator. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the rear door window regulator motor screws. Tighten Tighten the screws to 6 N.m (53 lb in).
  3. Connect the rear door window regulator motor electrical connector.
  4. Position the rear door window regulator motor inside the rear door and install it into the key slots in the inner door panel.
  5. Hand tighten the rear door window regulator screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  6. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Lower the front door window to the half way position to gain access to the front door window bolts.
  2. Remove the front door water deflector. Refer to «WINDOW ADJUSTMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the front door inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the front door window bolts (2).
  5. Remove the front door window from the front door.
  1. Position the front door window into the front door.
  2. Align the holes in the front door window with the holes in the window regulator. Ensure that both sealing lips on the front door outer belt sealing strip are not rolled over and pointing downward. If this condition is present, the window will not raise correctly. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the front door window bolts (2). Tighten Tighten the bolts to 10 N.m (89 lb in).
  4. Install the front door inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Adjust the front door window as necessary. Refer to «WINDOW ADJUSTMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the inner energy absorber. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Remove the outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Remove the rear door frame molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Remove the window mounting bolts (1, 2).
  8. Remove the window.
  1. Position the window between the inner and the outer panels.
  2. Point the lower front corner of the window down.
  3. Pass the window through the belt opening. Align the edges with the door window weatherstrip.
  4. Turn the window to the horizontal position. Align the holes in the window with the holes in the regulator. Ensure that both sealing lips on the front door outer belt sealing strip are not rolled over and pointing downward. If this condition is present, the window will not raise properly. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  5. Install the window to regulator bolts (1, 2). Tighten the forward bolt first. Tighten Tighten the forward window to regulator bolt to 10 N.m (89 lb in).
  6. Tighten the rearward bolt second. Tighten Tighten the rearward window to regulator bolt to 10 N.m (89 lb in).
  7. Install the rear door frame molding. Refer to «GARNISH MOLDING REPLACEMENT - REAR DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Install the inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  10. Adjust the rear window as necessary. Refer to «WINDOW ADJUSTMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Install the inner energy absorber. Refer to «ENERGY ABSORBER PAD REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  12. Install the water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  13. Install the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Position the window in the full down position.
  2. Remove the trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Remove the outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Lower the rear door window as low as possible in the door opening and remove the two screws attaching it to the regulator.
  7. Slide the window glass down to the bottom of the door while keeping it in the front weatherstrip channel.
  8. Partially remove the rear door window weatherstrip from the channel between the door glass and the stationary window and part way across the top of the window.
  9. Remove the door stationary window screws.
  10. Remove the door stationary window bolt.
  11. Remove the rear door stationary window channel bolt.
  12. Rotate the window foreword and remove it from the rear door.

Scheme 93

Scheme 93: Installation Procedure
Scheme 93: Installation Procedure
  1. Position the rear door stationary window in the rear door. Verify that the rear door window is in the channel of the stationary window and also the front channel. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Loosely install the rear door stationary window channel bolt. Loosely install the two rear door stationary window screws. Tighten Tighten the rear door stationary window bolt to 10 N.m (89 lb in).
  3. Now tighten the door stationary window screws. Tighten Tighten the door stationary window screws to 2 N.m (18 lb in).
  4. Install the rear door window weatherstrip.
  5. Slide the rear door glass up from the bottom of the door, keeping it in the channels and attach it to the regulator.
  6. Check the glass movement by using the regulator motor.
  7. Install the rear door outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT OUTER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  8. Install the rear door inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  9. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  10. Install the rear door inner trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  11. Raise the rear door window to the full up position.
  1. Remove the front door reveal molding. Refer to «GARNISH MOLDING REPLACEMENT - FRONT DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Slide the front door garnish molding upwards.
  3. Remove the front door garnish molding from the front door.
  1. Position the front door garnish molding to the front door.
  2. Slide the front door garnish molding down onto the front door until fully seated.
  3. Install the front door reveal molding. Refer to «GARNISH MOLDING REPLACEMENT - FRONT DOOR FRAME»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the rear door reveal molding. Refer to «REVEAL MOLDING REPLACEMENT - REAR DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Slide the rear door garnish molding upwards.
  3. Remove the rear door garnish molding from the rear door.
  1. Position the rear door garnish molding to the rear door.
  2. Slide the rear door garnish molding down onto the rear door until fully seated.
  3. Install the rear door reveal molding. Refer to «REVEAL MOLDING REPLACEMENT - REAR DOOR WINDOW»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .

Reveal Molding Replacement - Front Door Window

Tools Required : J 38778 Door Trim Pad and Garnish Clip Remover

  1. Remove the front door window belt outside sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Using the J 38778, remove the front door window reveal molding push-in retainer.
  3. Using a small flat-bladed tool, release the retaining clips while pulling front door window reveal molding from the front door.
  4. Remove the front door window reveal molding from the front door.
IMPORTANTEnsure the plastic clip retainers are not damaged prior to reinstallation of the front door window reveal molding. Replace any broken clips.
  1. Position the front door window reveal molding to the front door.
  2. Press the front door window reveal molding plastic retaining clips to the front door until fully seated.
  3. Install the front door window reveal molding push-in retainer.
  4. Install the front door window belt outside sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Pull the reveal molding away from the top of the door using a small flat-bladed tool to release the clips while pulling.
  2. Remove the reveal molding from the door.
  1. Position the window reveal molding on the door.
  2. Install the reveal molding at the top of the door pressing down until the plastic retaining clips are fully seated.
  1. Remove the door rubber conduit (1) from where it attaches at the A-pillar.
  2. Carefully pull the wire harness out from the A-pillar to expose the harness connector.
  3. Disconnect the door wiring harness electrical connector.
  4. Remove the conduit from the door and remove it from the electrical harness.
  1. Thread the door electrical harness through the rubber conduit.
  2. Install the conduit (1) onto the door.
  3. Connect the door wiring harness electrical connector.
  4. Install the conduit to the A-pillar.
  1. Remove the conduit from the center pillar.
  2. Remove the door wiring harness electrical connector.
  3. Remove the conduit from the door.
  1. Install the conduit to the door.
  2. Install the door wiring harness electrical connector.
  3. Install the conduit to the center pillar.
  1. Remove the outside rearview mirror. Refer to «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door window outer belt sealing strip screw.
  3. Remove the front door window outer belt sealing strip.
  1. Position the front door window outer belt sealing strip to the front door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems. IMPORTANT: Align the strip properly to the door inner panel for screw installation.
  2. Install the front door window outer belt sealing strip screw. Tighten Tighten the screw to 2 N.m (18 lb in).
  3. Install the outside rearview mirror. Refer to «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Place the rear door window in the full down position.
  2. Remove the outer belt sealing strip screws.
  3. Remove the rear door window outer belt sealing strip from the rear door flange.
  1. Position the rear door window outer belt sealing strip to the rear door flange. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the rear door window outer belt sealing strip screws. Tighten Tighten the screws to 2 N.m (18 lb in).
  3. Place the rear door window in the full up position.
  1. Lower the front door window.
  2. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Lift the front door window inner belt sealing strip off of the weld flange.
IMPORTANTEnsure the front end of the strip is inserted into the gap formed by the weatherstrip and the door inner panel. Ensure the rear end of the strip is flush to the rear leg of the weatherstrip. Ensure the rear end of the strip does not interfere with the path of the window.
  1. Install the front door window inner belt sealing strip to the weld flange, pressing firmly until fully seated.
  2. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Raise the front door window.
  1. Lower the rear door window.
  2. Remove the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Lift the rear door window inner belt sealing strip off of the weld flange.
IMPORTANTEnsure the rear end of the strip is inserted into the gap formed by the weatherstrip and the door inner panel. Ensure the rear end of the strip is flush to the rear leg of the weatherstrip. Ensure the rear end of the strip does not interfere with the path of the window.
  1. Install the rear door window inner belt sealing strip to the weld flange, pressing firmly until fully seated.
  2. Install the rear door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Raise the rear door window.

J 38778 Door Trim Pad and Garnish Clip Remover

  1. Open the front door.
  2. Using the J 38778, remove the lower half of the front door weatherstrip and retainers from the front door.
  3. Pull the upper half of the front door weatherstrip from the front door weatherstrip track.
  4. Remove the front door weatherstrip from the front door.
  1. Position the front door weatherstrip to the front door.
  2. Press the upper half of the front door weatherstrip into the front door weatherstrip track until fully seated.
  3. Press the lower half of the front door weatherstrip at the retainers into the front door until fully seated.
  4. Close the front door.
  1. Remove the outside mirror. Refer to «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the front door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the front door outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Remove the front door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Remove the front door window weatherstrip from the front door.
  1. Position the front door window weatherstrip to the front door.
  2. Starting in the corner and working out in both directions, press the front door window weatherstrip to the front door until fully seated.
  3. Install the front door window. Refer to «WINDOW REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Install the front door outer belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT OUTER - FRONT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the front door inner sealing strip. Refer to «SEALING STRIP REPLACEMENT - FRONT DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the front door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Install the outside mirror. Refer to «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Place the rear door window in the full down position.
  2. Remove the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the rear door inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the rear door stationary window molding. Refer to «WINDOW REPLACEMENT - REAR DOOR STATIONARY»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Remove the rear door window weatherstrip from the rear door.
  1. Position the rear door window weatherstrip to the rear door window.
  2. Starting in the corner and working outwards, press the rear door window weatherstrip to the rear door until fully seated.
  3. Install the rear door stationary window molding. Refer to «WINDOW REPLACEMENT - REAR DOOR STATIONARY»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Install the rear door inner belt sealing strip. Refer to «SEALING STRIP REPLACEMENT - REAR DOOR WINDOW BELT INNER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the rear door water deflector. Refer to «WATER DEFLECTOR REPLACEMENT - REAR DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Close the rear door window.

J 38778 Door Trim Pad Clip Remover

  1. Open the rear door.
  2. Remove the lower half of the rear door weatherstrip and retainers using J 38778.
  3. Remove the upper half of the rear door weatherstrip pulling the weatherstrip from the track.
  4. Remove the rear door weatherstrip from the rear door.
  1. Install the rear door weatherstrip on the rear door.
  2. Install the upper half of the rear door weatherstrip pushing the weatherstrip into the track.
  3. Install the lower half of the rear door weatherstrip, pressing in on the retainers until each retainer is fully seated.
  4. Close the rear door.
  1. Open the front door.
  2. Remove the carpet retainers. Refer to CARPET RETAINER REPLACEMENT - FRONT in Interior Trim.
  3. Remove the front door weatherstrip by pulling it off the pinch-weld flange.
  1. Install the weatherstrip to the flange on the body.
  2. Install the carpet retainers. Refer to CARPET RETAINER REPLACEMENT - FRONT in Interior Trim.
  3. Close the front door.
  1. Remove the rear carpet retainers. Refer to CARPET RETAINER REPLACEMENT - REAR in Interior Trim.
  2. Pull the lower edges of the weatherstrip and retainers away from the door.
  3. Pull the upper edges of the weatherstrip from the door.
  4. Remove the weatherstrip from the door.
  1. Install the weatherstrip on the door.
  2. Push the upper edges of the weatherstrip onto the door.
  3. Push and seat the lower edges of the weatherstrip and retainers onto the door.
  4. Install the rear carpet retainers. Refer to CARPET RETAINER REPLACEMENT - REAR in Interior Trim.
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Disconnect the mirror remote cable from the front door trim panel.
  3. Remove the mirror reinforcement cover.
  4. Remove the mirror nuts.
  5. Remove the mirror from the front door.
  1. Install the mirror remote cable through the opening in the front door.
  2. Position the mirror to the front door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the mirror nuts. Tighten Tighten the nuts to 10 N.m (89 lb in).
  4. Install the mirror reinforcement cover.
  5. Connect the mirror remote cable to the front door trim panel.
  6. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Disconnect the mirror electrical connectors.
  3. Remove the mirror reinforcement cover.
  4. Remove the mirror nuts.
  5. Remove the mirror from the front door.
  1. Position the mirror to the front door. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  2. Install the mirror nuts. Tighten Tighten the nuts to 10 N.m (89 lb in).
  3. Install the mirror reinforcement cover.
  4. Connect the mirror electrical connectors.
  5. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
CAUTIONApproved safety glasses and gloves should be worn when performing this procedure to reduce the chance of personal injury.
  1. Remove the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  2. Remove the mirror from the front door. Refer to «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  3. Remove the mirror face. Refer to «MIRROR FACE REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  4. Remove the mirror motor screws.
  5. Remove the mirror motor electrical harness through the mirror housing.
  6. Remove the mirror motor from the mirror housing.
  1. Route the mirror motor electrical harness through the mirror housing.
  2. Position the mirror motor to the mirror housing. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  3. Install the mirror motor screws. Tighten Tighten the screws to 10 N.m (89 lb in).
  4. Install the mirror to the front door. Refer to «MIRROR REPLACEMENT - POWER»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «MIRROR REPLACEMENT - REMOTE»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  5. Install the mirror face. Refer to «MIRROR FACE REPLACEMENT»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  6. Install the front door trim panel. Refer to «TRIM PANEL REPLACEMENT - SIDE FRONT DOOR»(/buick/century/vi-1997-2005/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) .
  7. Check the mirror for proper operation.
CAUTIONApproved safety glasses and gloves should be worn when performing this procedure to reduce the chance of personal injury.
IMPORTANTThe outside mirrors are stud mounted to the door metal. The mirror face can be replaced without removing the entire mirror. The left side flat and right side convex mirror faces must be replaced with the same type mirror face when serviced.
  1. Carefully push the outside rearview mirror face on the inner edge (near the front door window glass) to allow finger access.
  2. Grasp the mirror face firmly and pull it from the mirror body.
  3. Remove the outside rearview mirror case from the outside rearview mirror housing and disconnect the heater wire (if equipped).
  4. Remove the 2 jackscrews from back of the mirror case. 4.1. Bend the 2 jackscrews over. 4.2. Press down on the side of the jackscrew popping the screw from the mirror glass case. 4.3. Save the jackscrews for reinstallation to the mirror motor.
IMPORTANTThe jackscrew springs must be positioned on the fingers (opposite the ball end) to compress the fingers.
  1. Push the jackscrews into the mirror motor.
  2. Rotate both jackscrews to position the ball flanges to be inline with the attaching hub. They will then be correctly positioned to the mirror face.
  3. Install the electric heater wire to the mirror, if equipped.
  4. Align the wire stabilizers (if equipped) on the mirror case to the motor. Also align the mirror case to the motor.
  5. With the palm of your gloved hand, press firmly on the center of the glass until the case seats onto the motor.
  6. With the palm of you gloved hand pivot the mirror face to engage the jackscrews. The jackscrews will give a clicking noise when properly seated.
  7. Check the mirror operation and clean the glass face.

Power Window System Components

The power window system consists of the following components

  1. Driver window switch
  2. Front Passenger window switch
  3. Left Rear window switch
  4. Right Rear window switch
  5. Window regulator motors in each of the doors
  6. PWR WINDOWS PWR SUNROOF Circuit Breaker 30A

Power Window System Controls

The power window system can be controlled by a power window up or down switch activation.

Driver Window Operation

When the ignition switch is in the RUN or ACCY position, or Retained Accessory Power (RAP) is enabled and the driver window switch is pressed in the down position, battery positive voltage is applied to the window regulator motor causing the window to open. When the driver window switch is pressed in the up position, voltage is applied to the window regulator motor in the opposite direction and the window closes.

The driver window switch also controls the passenger windows.

Express Down Feature

The driver window will travel to the fully down position when the driver window switch is pressed past the first detent. Pressing the driver window switch to the up position will cancel the express down feature.

Lockout Switch Feature

The driver window switch has a lockout switch which disconnects the battery positive voltage to the passenger window switches, disabling them.

Individual Window Operation

When the ignition switch is in the RUN or ACCY position, or Retained Accessory Power (RAP) is enabled and the lockout switch is disengaged, battery positive voltage will be available at the passenger window switches. When an individual window switch is pressed in the down position, battery positive voltage is applied to the window regulator motor causing that window to open. When the individual window switch is pressed in the up position, voltage is applied to the window regulator motor in the opposite direction causing that window to close. The return path to ground is supplied through the inactive control circuit being normally grounded through the driver window switch.

Door Lock System Components

The power door lock system consists of the following components

  1. Body Control Module (BCM)
  2. Driver door lock switch
  3. Front passenger door lock switch
  4. Door lock actuators in each of the doors
  5. DOOR LOCKS 20A fuse

Door Lock System Controls

The power door lock system is controlled by the BCM and can be activated by any one of the following

  1. A door lock switch Lock or Unlock actuation
  2. A keyless entry transmitter actuation
  3. An automatic door lock actuation, see VEHICLE PERSONALIZATION in Personalization
  4. An automatic door unlock actuation, see VEHICLE PERSONALIZATION in Personalization
  5. A last door closed locking (LDCL) actuation, see VEHICLE PERSONALIZATION in Personalization

Door Lock Operation

When the BCM detects a transition of either of the door lock switches to the Lock position, it switches the door lock actuator lock control circuit to voltage. Since the lock actuator unlock control circuits are at ground potential within the BCM, the door lock actuator motors transition to the Lock position.

Driver Door Unlock Operation

When the BCM detects a transition of either of the door lock switches to the Unlock position, it switches the driver door lock actuator unlock control circuit to voltage. Since the door lock actuator lock control circuit is at ground potential within the BCM, the driver door lock actuator transitions to the Unlock position.

The driver door lock actuator unlock control circuit is a dedicated control circuit used only for the driver door lock actuator. This is done so that the driver door may be unlocked by itself using a keyless entry transmitter or an automatic door unlock function, if programmed.

Passenger Door Unlock Operation

When the BCM detects a transition of either of the door lock switches to the Unlock position, it switches the door lock actuator unlock control circuits to voltage. Since the door lock actuator lock control circuit is at ground potential within the BCM, the passenger door lock actuators transition to the Unlock position.

The door lock actuator unlock control circuits are dedicated control circuits used only for the passenger door lock actuators. This is done so that the driver door may be unlocked by itself using a keyless entry transmitter or an automatic door unlock function, if programmed.

Lockout Prevention

This function is intended to prevent the vehicle operator from locking the doors if the key is left in the ignition and any vehicle door is open. The lockout prevention function can be overridden by the BCM if the BCM receives a door Lock input for longer than 3 seconds.

Automatic Door Lock/Unlock

The automatic door lock/unlock function is a Vehicle Personalization feature with the following four programmable modes of operation

  1. The automatic door lock feature is disabled.
  2. All of the doors lock when the vehicle is shifted out of Park with the ignition ON.
  3. All of the doors lock when the vehicle is shifted out of Park with the ignition ON, and all of the doors Unlock when the vehicle is shifted into Park.
  4. All of the doors lock when the vehicle is shifted out of Park with the ignition ON, and only the driver door Unlocks when the vehicle is shifted into Park.

The automatic door lock function can only be enabled by the BCM if the driver door switch is in the Inactive state - door closed. For information on programming the automatic door locks, refer to VEHICLE PERSONALIZATION in Personalization.

Automatic Door Re-Lock

The automatic door re-lock function is a Vehicle Personalization feature that comes from the factory enabled. After an automatic door lock function has occurred, the BCM will re-lock an opened vehicle door only if the vehicle is in gear and the brake is On.

Last Door Closed Locking (LDCL)

The last door closed locking (LDCL) function is a Vehicle Personalization feature that is intended to allow the doors to be locked while passengers are exiting the vehicle. When LDCL is in Active Mode, the BCM will delay locking of the vehicle doors for 5 seconds after all of the doors have been closed. The LDCL function will be overridden if the BCM receives a door Unlock input or a key in ignition input.

Door/Trunk Ajar Indicator

The IPC illuminates the DOOR/TRUNK indicator in the message center when the body control module (BCM) detects that any of the four doors or the trunk is open. The IPC receives a class 2 message from the BCM requesting illumination. If the vehicle is shifted out of park with a door or the trunk open, the BCM sends a class 2 message to the radio in order to activate an audible warning.

Power Mirror System Components

The power mirror system consists of the following components

  1. Outside rearview mirror switch
  2. Mirror selector switch
  3. Driver outside rearview mirror
  4. Passenger outside rearview mirror
  5. POWER MIRRORS Fuse 2A

Each of the outside rearview mirrors contains 2 motors. The vertical motor operates the mirror in the up and down directions, and the horizontal motor operates the mirror in the left and right directions. Each of the outside rearview mirror motors are circuit breaker protected.

Power Mirror System Controls

The outside rearview mirror switch is a 4 position directional switch: Up, Down, Left and Right.

The mirror select switch is a 3 position switch: L, Off and R.

Power Mirror System Operation

The outside rearview mirror switch receives power through the battery positive voltage circuit from the POWER MIRROR 2A Fuse. The power mirror switch also receives a constant ground.

The 4 positions of the direction switch have dual switch contacts. Each of the contacts are connected to opposing sides of the appropriate power mirror motors through the selector switch. The selector switch completes these circuits depending on the position of the selector switch, L or R.

If the selector switch is placed in the L position and the up switch is depressed, battery positive voltage will be supplied to the left outside rearview mirror vertical motor through the left mirror motor down control circuit and ground through the left mirror motor left control circuit. If the down switch is depressed, battery positive voltage will be supplied to the left outside rearview mirror vertical motor through the left mirror motor left control circuit and ground through the left mirror motor down control circuit.

The remainder of the mirror functions operate in the same manner as described above. Placing the power mirror switch in opposing positions, left/right or up/down, will reverse the polarity to the mirror motor.

Heated Mirrors

Battery positive voltage is supplied through the REAR DEFOG circuit breaker in the fuse block to the rear window defogger relay. With the ignition in the ON position, ignition 3 voltage is supplied through the HVAC fuse in the fuse block to the rear window defogger relay coil. When you depress the rear window defogger switch, the rear window defogger indicator illuminates and grounds the control circuit of the rear window defogger relay. This energizes the rear window defogger relay and allows battery positive voltage to the HEATED MIRROR fuse 10A. The HEATED MIRROR fuse provides battery positive voltage to the heated mirrors.

Scheme 94

Scheme 94: Special Tools and Equipment
Scheme 94: Special Tools and Equipment

More articles — Accessories & Equipment
