Supplemental Inflatable Restraint System Deactivation Procedures Buick Century VI

SPECIAL CARE DURING MECHANICAL REPAIRS

In some instances, it may be necessary to remove the steering column or instrument panel to access electrical components. Observe specific manufacturer SERVICE PRECAUTIONS when working on a vehicle with an air bag system.

Electrical power sources should NEVER be allowed to contact the inflator on the back of the air bag module. NEVER probe air bag system electrical wires with an analog volt-ohmmeter or test light. Always disable air bag system before servicing vehicle. See appropriate DISABLING & ACTIVATING AIR BAG SYSTEM procedure. Failure to disable system properly may result in accidental air bag deployment and possible personal injury.

If air bag system is not fully functional for any reason, DO NOT drive vehicle until system is repaired and functions properly. DO NOT remove bulbs, modules, sensors, or other air bag components which will prevent air bag system from operating as designed. If air bag system is not functional, park vehicle until system is repaired and functions properly.

CHRYSLER

All Chrysler vehicles are equipped with driver and passenger side air bags. In addition, some models may be equipped with front seat belt tensioners, left and right front seat side air bags and/or left and right curtain air bags. Unless specific models are mentioned, the following procedures apply to all models with an air bag system.

Except Sebring Coupe & Stratus Coupe

1. Connect DRB-III scan tool, or equivalent, to Data Link Connector (DLC). DLC is located on the driver side lower edge of the instrument panel near steering column. Ensure latest version of DRB-III scan tool software cartridge is being used.
2. Turn ignition switch to ON position, with engine off. Exit vehicle with DRB-III scan tool. Ensure no one is inside vehicle, then reconnect negative battery cable.
3. Using DRB-III scan tool, read and record any active (current) or stored (historical) Diagnostic Trouble Codes (DTCs). Using DRB-III, erase all stored DTCs. If an problems exists, DTCs will not erase. If DTCs are found, perform diagnosis and repairs as necessary. If all DTCs are erased, go to next step.
4. From outside of the vehicle, and away from air bags, turn ignition off for about 15 seconds, then back to ON position. Observe AIR BAG warning light.
5. AIR BAG warning light should come on for about 6-8 seconds, then go out, indicating system is functioning properly. If AIR BAG warning light either fails to come on, blinks on and off, or comes on and stays on, a system malfunction exists. Diagnosis and repair air bag system as necessary.

Sebring Coupe/Stratus Coupe

1. SRS-ECU monitors SRS system and stores data concerning any detected faults in the system. When the ignition switch is turned to ON or START position, SRS warning light will illuminate for about 7 seconds and then turn OFF. This indicates that the SRS system is in operational order.
2. If the SRS warning light does not illuminate, stays on for more than 7 seconds or illuminates while driving, there is a malfunction. Perform diagnosis and repairs as necessary.

SERVICE PRECAUTIONS

This air bag system is a sensitive, complex electronic unit. Before attempting to diagnose or service any air bag system or related steering wheel, steering column or instrument panel components, the following precautions should be observed

1. Disable air bag system before servicing any air bag system or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-activating-air-bag-system) .
2. Wait at least 2 minutes after disconnecting and isolating negative battery cable before servicing air bag system. Servicing air bag system before 2-minute period may cause accidental air bag deployment and possible personal injury.
3. ALWAYS maintain a safe distance from all air bags when activating air bag system.
4. DO NOT turn passenger side air bag ON/OFF switch while ignition is in RUN position. This action will set active and stored DTCs.
5. When reconnecting air bag system components, ensure ignition is in OFF or LOCK position and negative battery cable is disconnected and isolated.
6. DO NOT use any electrical test equipment on or near SRS components unless specified to do so. DO NOT use an analog ohmmeter. Use a DVOM with a maximum test current of 2 milliamps or less, at minimum resistance measurement range.
7. After deployment, air bag surface may contain sodium hydroxide deposits, which may irritate skin. Sodium hydroxide is a product of gas generant combustion. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water.
8. Because of critical system operating requirements, DO NOT try to service any air bag components. Manufacturer recommends that defective components should only be replaced with NEW, original equipment parts. DO NOT use salvaged air bag components or other parts. Substitute parts may appear interchangeable, but internal differences may result in inferior occupant protection.
9. Factory installed fasteners have a special coating and are specifically designed for air bag components. Manufacturer recommends using NEW, original equipment replacement fasteners. DO NOT use substitutes or salvaged parts.
10. Clockspring must be replaced if driver's air bag is deployed.
11. Each time a connector is disconnected, ensure it is clean and not damaged. Always pay particular attention to circuit being tested. Dirt, water and corrosion are the most common problems in connectors, causing voltage drop, open circuits and other improper operations.
12. When performing electrical tests, prevent accidental shorting of terminals. Such shorts can damage fuses or components and may cause a second fault code to set, making diagnosis of original problem more difficult.
13. After repairs are complete and ignition is turned to RUN or ON position, stay clear of air bag(s) to avoid injury in case of accidental air bag deployment.
14. Wear safety glasses, rubber gloves, and long sleeved clothing when cleaning powder residue from the vehicle after an air bag deployment. Sodium hydroxide powder residue emitted from a deployed air bag can cause skin irritation. Flush affected area with cool water if irritation is experienced. If nasal or throat irritation is experienced, exit the vehicle for fresh air until the irritation ceases. If irritation continues, see a physician.
15. Some models use 2 stage deployment inflators on driver and passenger air bag modules. If stage one was used to deploy a dual stage inflator module, stage 2 may still be active. Therefore, a deployed 2 stage air bag inflator module must be treated as an active module. When deactivating an air bag system with deployed air bags, a deployed 2 stage air bag may still be active. If disposal of a deployed or undeployed dual stage module is required, both deployment loops must be energized to deploy the air bag.
16. Deployed front air bags may or may not have live pyrotechnic material within the air bag inflator. DO NOT dispose of air bags unless complete deployment has occurred. Dispose of air bags (deployed and undeployed) in a manner consistent with state, provincial, local and federal regulations.
17. Ensure air bag warning light is operating properly and system faults are not indicated. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__system-operation-check) .
18. When placing a undeployed (live) air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed.
19. When carrying a undeployed (live) air bag module, point trim cover away from your body to minimize injury in case of accidental deployment.
20. DO NOT use a replacement air bag module that is not in the original packaging, improper deployment and personal injury can result. Air bag module must be stored in its original special container until used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks and electrical energy.
21. The Air Bag Control Module (ACM)/Occupant Restraint Controller (ORC) contains an air bag sensor which enables SRS to deploy air bags. If air bag control module is dropped, struck or kicked, it can damage air bag sensor or affect its calibration. If air bag control module is dropped, it must be replaced with a NEW unit.
22. DO NOT connect ACM/ORC connector while battery is connected. Ensure ACM/ORC and mounting bracket are securely installed to vehicle before connecting electrical connector.
23. On vehicles with side air bags, use caution when working around "B" pillar or side air bags.
24. Electrical sources should never be allowed near air bag module connector.
25. On Dakota, Durango, Neon, Ram Truck and Ram Van, passenger air bag module contains an Argon gas canister. Canister is pressurized to more than 2500 psi. DO NOT puncture, incinerate, or bring into contact with electricity. DO NOT store at temperatures above 200°F (93°C).
26. On Caravan, Neon, Town & Country and Voyager, passenger air bag and seat air bag modules each contain an Argon gas canister. Canister is pressurized to more than 2500 psi. DO NOT puncture, incinerate, or bring into contact with electricity. DO NOT store at temperatures above 200°F (93°C).
27. On Sebring Sedan, Sebring Convertible and Stratus Sedan, the driver air bag, passenger air bag, seat air bag modules and curtain air bag modules (if equipped) each contain an Argon gas canister. Argon gas canisters are pressurized to more than 2500 psi. DO NOT puncture, incinerate, or bring into contact with electricity. DO NOT store at temperatures above 200°F (93°C).
28. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and functions properly. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally.

DISABLING & ACTIVATING AIR BAG SYSTEM

Disabling System (Except Sebring Coupe & Stratus Coupe)

1. Ensure ignition switch is in OFF or LOCK position. Disconnect and shield negative battery cable at battery. Tape the battery cable terminal to prevent accidental connection and air bag deployment.
2. After disconnecting negative battery cable, WAIT at least 2 minutes for reserve capacitor to discharge before servicing air bag system.

Activating System (Except Sebring Coupe & Stratus Coupe)

1. Connect DRB-III scan tool, or equivalent, to Data Link Connector (DLC). DLC is located on the driver side lower edge of the instrument panel, near steering column. Ensure latest version of DRB-III scan tool software cartridge is being used.
2. Turn ignition switch to ON position, with engine off. Exit vehicle with DRB-III scan tool. Ensure no one is inside vehicle, then reconnect negative battery cable.
3. Using DRB-III scan tool, read and record any active (current) or stored (historical) Diagnostic Trouble Codes (DTCs). Using DRB-III, erase all stored DTCs. If an problems exists, DTCs will not erase. If DTCs are found, perform diagnosis and repairs as necessary. If all DTCs are erased, go to next step.
4. From outside of the vehicle, and away from air bags, turn ignition off for about 15 seconds, then back to ON position. Observe AIR BAG warning light.
5. AIR BAG warning light should come on for about 6-8 seconds, then go out, indicating system is functioning properly. If AIR BAG warning light either fails to come on, blinks on and off, or comes on and stays on, a system malfunction exists. Diagnosis and repair air bag system as necessary.

Disabling System (Sebring Coupe & Stratus Coupe)

Turn ignition switch to OFF or LOCK position. Disconnect and shield negative battery cable at battery. WAIT at least 60 seconds for reserve capacitor to discharge before servicing air bag system. After disconnecting negative battery cable, tape the terminal to prevent accidental connection and air bag deployment.

Activating System (Sebring Coupe & Stratus Coupe)

1. Ensure ignition switch is in OFF or LOCK position. Reconnect negative battery cable. Turn ignition switch to ON position. SRS warning light should illuminate for 7 seconds and then go out, indicating system is functioning properly.
2. If AIR BAG warning light either fails to come on, blinks on and off, or comes on and stays on, a system malfunction exists. Diagnosis and repair air bag system as necessary.

SYSTEM OPERATION CHECK

1. When checking air bag system operation (also known as prove out system), and upon completion of each diagnostic test, check for faults in air bag system. To check system, turn ignition switch from OFF to RUN position. If AIR BAG warning light illuminates for approximately 6 seconds and then goes out, air bag system is functioning properly and no fault codes exist. NOTE: On regular cab and extra cab pickups, passenger air bag deactivation switch light must turn on and off in same manner as instrument cluster warning light during system operation check.
2. If a fault is detected in air bag system during initial system check, AIR BAG warning light will either fail to light, stay on continuously, or flash. Flashing may not begin for up to 30 seconds after initial bulb check (ignition turned from OFF to RUN). If AIR BAG warning light flashes, indicating a fault in system, diagnose and repair air bag system as necessary.
3. If a system fault exists and AIR BAG warning light fails to light, an audible tone will be heard, indicating AIR BAG warning light is out and service is required. The tone is a chime which sounds 5 sets of 5 beeps.

These precautions should be observed when working with SRS

1. Disable SRS before servicing any SRS or steering column components. Failure to do so may result in accidental air bag deployment and personal injury. See procedures under «DISABLING & ACTIVATING AIR BAG SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
2. To deplete backup power supply energy, disconnect and isolate negative battery cable. WAIT at least one minute. Ensure that auxiliary batteries and other power supplies (if equipped) are disconnected.
3. On vehicles equipped with side air bags and seat belt pretensioners, manufacturer recommends removing front seats from vehicle before performing any diagnostics or repairs to seat air bag or seat belt pretensioner system. For diagnostics on systems other than side air bags or seat belt pretensioners, seats may be left in vehicle as long as simulator tool is installed in place of side air bag and seat belt pretensioner harness.
4. On all models, wait one minute after disconnecting negative battery cable before working on vehicle. Backup power supply holds a deployment charge for approximately one minute after negative battery cable is disconnected. Servicing SRS before one minute may cause accidental air bag deployment and possible personal injury.
5. To avoid accidental deployment and possible personal injury, the backup power supply must be depleted before repairing or replacing any front or side air bag Supplemental Restraint System (SRS) components and before servicing, replacing, adjusting or striking components near the front or side air bag sensors, such as doors, instrument panel, console, door latches, strikers, seats and hood latches.
6. Vehicle sensor orientation is critical for proper system operation. If a vehicle is involved in a collision, inspect sensor mounting bracket and wiring pigtail for deformation. If damaged, replace sensor.
7. After diagnosing or repairing a seat system or SRS, the air bag simulators must be removed before operating the vehicle over the road.
8. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.
9. Because of critical system operating requirements, DO NOT service air bag sensors, clockspring, diagnostic monitor or air bag module. Repairs are made by replacement only.
10. If replacing deployed air bag module, always install a NEW air bag Electronic Crash Sensor (ECS) module.
11. On vehicles with side air bags, use caution when working around "A", "B" and "C" pillars. Side air bag sensors are located at or near the base of the pillars.
12. Always wear safety glasses whenever servicing an air bag equipped vehicle or handling an air bag.
13. When carrying a live air bag module, ensure air bag module and trim cover are pointed away from your body. This minimizes chance of injury in event of an accidental deployment.
14. When placing a live air bag module on a bench or other surface, always face air bag module and trim cover facing up and away from surface. This will reduce motion of module if it is accidentally deployed.
15. After deployment, air bag surface may contain deposits of sodium hydroxide, which may irritate skin. Sodium hydroxide is a product of gas generant combustion. Always wear gloves and safety glasses when handling a deployed air bag. Wash your hands using mild soap and water. Follow correct disposal procedures.
16. Some models use 2 stage deployment inflators on driver and passenger air bag modules. If stage one was used to deploy a dual stage inflator module, stage 2 may still be active. Therefore, a deployed 2 stage air bag inflator module must be treated as an active module. When deactivating an air bag system with deployed air bags, a deployed 2 stage air bag may still be active. If disposal of a deployed or undeployed dual stage module is required, both deployment loops must be energized to deploy the air bag.
17. If scrapping a vehicle with an undeployed air bag module, air bag must be deployed.
18. If a part is replaced and new part does not correct condition, reinstall original part and perform diagnostic procedure again.
19. Never probe connectors on air bag module. Doing so may cause air bag deployment and/or personal injury.
20. Instruction to disconnect always refers to connector. DO NOT remove component from vehicle if instructed to disconnect.
21. After any servicing, ensure AIR BAG warning light does not indicate any fault codes. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
22. Replace air bag module if trim cover (deployment doors) is marred or damaged. DO NOT repaint trim cover. Paint may degrade cover material. Replace air bag module as necessary. Ensure damaged air bag is deployed.
23. Clockspring electrical connectors are unique and cannot be reversed when connected to the driver air bag module. Match the electrical connector key to the keyway in the driver air bag module. DO NOT force electrical connectors into the driver air bag module.
24. Any time side safety curtain has deployed, the headliner, and all "A", "B" and "C" pillar trim panels and attaching hardware must be replaced along with any other damaged components and hardware. Failure to do so may result in personal injury in the event of a safety canopy deployment.

Disabling System (Aviator)

1. Disconnect the battery ground cable and wait for one minute. Remove the driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect 2 air bag simulators (418-F395) to the clockspring side of the driver air bag module electrical connectors. (Scheme 1) See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
2. Open the glove compartment to its fullest extent by pushing in on the tabs and releasing the glove compartment. Disconnect the passenger air bag module electrical connector. Connect air bag simulator (418-F403) to the harness side of the passenger air bag module electrical connector. (Scheme 2) See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Separate the passenger side "C" pillar trim panel. Disconnect the passenger side safety canopy module electrical connector, located on the "C" pillar behind the second row safety belt shoulder height adjuster. Connect air bag simulator (418-F088/105-R0012) to the vehicle harness side of the passenger side safety canopy module electrical connector. (Scheme 3) See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. From under the passenger front seat, disconnect the passenger seat 11-pin electrical connector C315. Connect front seat air bag simulator (501-095) to the passenger seat body wiring harness electrical connector C315.
5. Separate the driver side "C" pillar trim panel. Disconnect the driver side safety canopy module electrical connector, located on the "C" pillar behind the second row safety belt shoulder height adjuster. Connect air bag simulator (418-F088/105-R0012) to the vehicle harness side of the driver side safety canopy module electrical connector.
6. From under the driver front seat, disconnect the driver seat 11-pin electrical connector C327. Connect front seat air bag simulator (501-095) to the driver seat body wiring harness electrical connector C327. Reconnect the battery ground cable.

Scheme 1

Scheme 2

Scheme 3

Activating System (Aviator)

1. Disconnect and isolate negative battery cable and wait one minute. From under the driver front seat, disconnect the front seat air bag simulator and connect the driver seat 11-pin electrical connector C327.
2. Remove the air bag simulator from the driver side safety canopy module electrical connector. Connect the driver side safety canopy module electrical connector. Install the driver side "C" pillar trim panel.
3. From under the passenger front seat, disconnect the front seat air bag simulator and connect the passenger seat 11-pin electrical connector C315. Remove the air bag simulator from the passenger side safety canopy module electrical connector.
4. Connect the passenger side safety canopy module electrical connector. Install the passenger side "C" pillar trim panel. Remove the air bag simulator from the passenger air bag module electrical connector. Connect the passenger air bag module electrical connector.
5. Remove the air bag simulators from the driver air bag module electrical connectors. Install the driver air bag module. Reconnect the battery ground cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .

Disabling System (Blackwood)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt front seats to their highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Pull out retaining clips at all 4 corners of upper steering column cover and remove cover. Remove central junction box cover. Remove 2 bolts and disconnect parking brake release lever. Remove 2 retaining bolts and disconnect hood release lever. Remove lower instrument panel steering column cover.
3. Disconnect clockspring electrical connector at the base of steering column. (Scheme 4) Connect appropriate air bag simulator to lower clockspring connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. Remove oval-shaped relay cover from passenger side of instrument panel. (Scheme 6) Disconnect passenger side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
5. Disconnect passenger seat side air bag connector located under passenger seat. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side.
6. Remove passenger side "B" pillar assist handle and trim panel. Disconnect passenger side safety belt retractor pretensioner connector. Connect appropriate simulator to vehicle harness (in place of safety belt retractor pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side safety belt retractor pretensioner. Connect negative battery cable.

Scheme 4

Activating System (Blackwood)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column.
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module harness connector. Install relay cover on instrument panel. Remove simulator from passenger seat side air bag vehicle harness connector. Connect passenger seat side air bag connector. Repeat procedure for driver side.
3. Remove simulator from vehicle harness and connect passenger side safety belt retractor pretensioner. Install trim panel as necessary. Repeat procedure for driver side safety belt retractor pretensioner.
4. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Crown Victoria, Grand Marquis & Marauder)

1. Record preset radio frequencies for reprogramming (if equipped). Move and tilt seats to the highest and rearmost positions. Disconnect negative battery cable. Also disconnect any auxiliary batteries and power supplies (if equipped). Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulators to clockspring connectors at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulators to passenger air bag vehicle harness connectors (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. Disconnect passenger seat side air bag module electrical connector, located under front seat. Connect appropriate front seat side air bag simulator to vehicle harness side connector (in place of passenger seat side air bag module). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat for driver front seat side air bag module.
5. Disconnect driver seat belt pretensioner, located behind "B" pillar. Connect appropriate simulator to connector (in place of seat belt pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger's side. Connect negative battery cable.

Activating System (Crown Victoria, Grand Marquis & Marauder)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect module to vehicle harness. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Remove simulators from front seat side air bag modules and seat belt pretensioner connectors. Reconnect front seat side air bag modules and seat belt pretensioners to vehicle harness.
3. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-excursion-f250-550-super) . Reprogram preset radio frequencies and set clock.

Disabling System (Econoline)

1. Record radio preset frequencies for reprogramming (if equipped). On gasoline engines with single battery, disconnect negative battery cable. On gasoline engines with dual batteries, also disconnect auxiliary negative battery cable (on right frame rail). On diesel engines, disconnect primary negative battery cable. Disconnect and INSULATE primary battery positive cable.
2. On all models, wait at least one minute for backup power supply to deplete stored energy. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Release retaining clips and remove right lower instrument panel finish panel. Remove bolts and remove right lower instrument panel finish panel reinforcement and reinforcement mounting bracket. Locate and disconnect the passenger air bag module electrical connector between interior engine cover and passenger air bag module. (Scheme 5)
4. Attach air bag simulator to harness side of the passenger air bag module electrical connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
5. Disconnect both seat belt buckle pretensioner electrical connectors. Attach air bag simulator to harness side of each seat belt pretensioner electrical connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Reconnect all battery cables.

Scheme 5

Activating System (Econoline)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger side air bag module harness connector. Install passenger air bag module and finish panels. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) .
3. Remove air bag simulator tool from each seat belt pretensioner harness. Reconnect both seat belt pretensioner connectors. Reconnect all battery cables. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Escape)

1. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove access panel on bottom of steering wheel. Disconnect air bag module connector. Connect appropriate air bag simulator to clockspring connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Open glove box. Press in on sides to release stops and lower glove box. Disconnect passenger air bag module electrical connector. Connect appropriate air bag simulator to passenger air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. If vehicle is not equipped with side air bags, go to next step. Disconnect side air bag module connector under driver seat. Connect appropriate air bag simulator to vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side.
5. Disconnect passenger seat belt pretensioner, located behind "B" pillar. Connect appropriate seat belt pretensioner simulator to vehicle harness connector (in place of seat belt pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side. Connect negative battery cable.

Activating System (Escape)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector. Reconnect air bag module connector. Install steering wheel access panel.
2. Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect air bag module connector. Restore glove box to original position.
3. Disconnect side air bag simulators. Reconnect side air bag module connectors. Disconnect seat belt pretensioner simulators. Reconnect seat belt pretensioner connectors. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram preset radio frequencies and set clock.

Disabling System (Excursion & F250-550 Super Duty)

1. Record preset radio frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Open glove box. Push in on 2 side tabs and rotate glove box down. Disconnect passenger air bag module connector. Connect appropriate air bag simulator to passenger air bag vehicle harness connector (in place of air bag).
4. On all models except F250-550 Super Duty SuperCab, remove passenger side "B" pillar trim panel and disconnect safety belt retractor pretensioner electrical connector. Connect appropriate air bag simulator to vehicle harness connector (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side.
5. On F250-550 Super Duty SuperCab models with safety belt retractor pretensioners, remove passenger door scuff plate. Remove bolt and separate passenger safety belt retractor pretensioner from floor. Disconnect passenger safety retractor pretensioner connector. Connect appropriate air bag simulator to vehicle harness connector (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Install passenger safety belt retractor pretensioner and temporarily install bolt. Repeat procedure for driver side.
6. On F250-550 Super Duty SuperCab models with safety belt buckle pretensioners, disconnect passenger side safety belt buckle pretensioner connector from under passenger seat. Connect appropriate air bag simulator to vehicle harness connector (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side. On all models, connect negative battery cable.

Activating System (Excursion & F250-550 Super Duty)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect passenger air bag module connector.
2. On all models except F250-550 Super Duty SuperCab, remove simulator from passenger side safety belt retractor pretensioner electrical connector. Connect passenger side safety belt retractor pretensioner. Install "B" pillar trim panel. Repeat procedure for driver side.
3. On F250-550 Super Duty SuperCab models with safety belt retractor pretensioners, remove bolt and separate passenger safety belt retractor pretensioner from floor. Remove simulator from passenger safety belt retractor pretensioner connector. Connect passenger safety belt retractor pretensioner. Install passenger side safety belt retractor pretensioner and tighten bolt to 30 ft. lbs. (40 N.m). Install passenger side scuff plate. Repeat procedure for driver side.
4. On F250-550 Super Duty SuperCab models with safety belt buckle pretensioners, remove simulator from passenger side safety belt buckle pretensioner connector. Connect passenger side safety belt buckle pretensioner connector. Repeat procedure for driver side.
5. On all models, reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram preset radio frequencies and set clock.

Disabling System (Expedition & Navigator)

1. Record preset radio frequencies for reprogramming (if equipped). Move and tilt front seats to their highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). (Scheme 1) See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Push in on glove box tabs, release glove box and fully open glove compartment. Disconnect passenger air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. The safety canopy bridge resistor is located on the right side of the vehicle, above the headliner. DO NOT disconnect the safety canopy bridge resistor.
5. Remove passenger side "B" pillar lower trim panel. Disconnect passenger side seat belt retractor pretensioner connector. Connect appropriate simulator to vehicle harness connector (in place of seat belt pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side seat belt retractor pretensioner. Connect negative battery cable.
6. If vehicle is equipped with safety canopies, separate passenger side "C" pillar trim panel. Disconnect passenger side safety canopy electrical connector, located on "C" pillar, behind the second row safety belt shoulder height adjuster. Connect appropriate simulator to vehicle harness connector (in place of passenger side safety canopy). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side safety canopy.
7. From under the passenger front seat, disconnect the seat belt buckle pretensioner electrical connector. Connect appropriate simulator to vehicle harness connector (in place of passenger side seat belt buckle pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side seat belt buckle pretensioner electrical connector. Connect negative battery cable.

Scheme 6

Activating System (Expedition & Navigator)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module connector.
2. If vehicle is equipped with safety canopies, remove air bag simulators from passenger side safety canopy electrical connector, located on "C" pillar, behind the second row safety belt shoulder height adjuster. Connect passenger side safety canopy vehicle harness connectors. Repeat procedure for driver side safety canopy. Remove simulator from passenger side safety belt retractor pretensioner vehicle harness connector. Connect passenger side safety belt retractor pretensioner connector. Repeat procedure for driver side safety belt retractor pretensioner.
3. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram preset radio frequencies and set clock.

Disabling System (Explorer & Mountaineer)

1. Record preset radio frequencies for reprogramming (if equipped). Move and tilt the front seats to their highest and most forward position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect appropriate air bag simulator to clockspring connectors at top of steering column (in place of air bag). (Scheme 1) See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Remove glove box. Disconnect passenger air bag connector. Connect appropriate air bag simulator to passenger's air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). For models equipped with safety canopies, go to next step. If vehicle is not equipped with safety canopies, connect negative battery cable.
4. The safety canopy bridge resistor is located on the right side of the vehicle, above the headliner. DO NOT disconnect the safety canopy bridge resistor.
5. Separate passenger side "C" pillar trim panel. Disconnect passenger side air bag connector, located on "C" pillar behind second row safety belt shoulder height adjuster. Connect appropriate side air bag simulator (in place of air bag). Repeat procedure for driver side air bag. Connect negative battery cable.
6. From under front seat, push in to release tab and disconnect seat belt buckle pretensioner electrical connector. Connect appropriate air bag simulator (in place of seat belt pretensioner) to seat belt buckle pretensioner floor electrical connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Connect the battery ground cable.

Activating System (Explorer & Mountaineer)

1. Move and tilt the front seats to their highest and most forward position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module harness connector. Install glove box.
3. On models with safety canopies, remove air bag simulator from safety canopies vehicle harness connector. Connect safety canopies to vehicle harness connector. Install "C" pillar trim panel. Repeat procedure for driver side air bag.
4. From under front seat, push in to release tab and disconnect air bag simulator from seat belt buckle pretensioner electrical connector. Connect seat belt buckle pretensioner electrical connector to pretensioner floor electrical connector.
5. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Explorer Sport)

1. Record preset radio frequencies for reprogramming (if equipped). Move and tilt seats to their highest and most forward position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulator to passenger's air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. Remove rear quarter trim panels. Disconnect passenger side seat belt retractor pretensioner electrical connector. Connect appropriate air bag simulator to seat belt retractor pretensioner vehicle harness connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side seat belt retractor pretensioner electrical connector. Connect negative battery cable.

Activating System (Explorer Sport)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module harness connector. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) .
3. On models with side air bags, remove air bag simulator from passenger side air bag vehicle harness connector. Connect side air bag to vehicle harness connector. Repeat procedure for driver side air bag.
4. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Explorer Sport Trac)

1. Record preset radio frequencies for reprogramming (if equipped). Move and tilt seats to their highest and most forward position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulator to passenger's air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. For vehicles not equipped with safety canopies, DO NOT disconnect safety canopy bridge resistor. If vehicle is equipped with safety canopies, go to next step.
5. If vehicle is equipped with safety canopies, remove passenger side "C" pillar trim panels. Disconnect passenger side safety canopy electrical connector. Connect appropriate air bag simulator to safety canopy vehicle harness connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side safety canopy electrical connector.
6. Remove passenger side "B" pillar trim panel. Disconnect passenger side seat belt retractor pretensioner electrical connector. Connect appropriate air bag simulator to safety canopy vehicle harness connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for driver side seat belt retractor pretensioner electrical connector. Connect negative battery cable.

Activating System (Explorer Sport Trac)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module harness connector. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) .
3. Remove air bag simulator from passenger side seat belt retractor pretensioner electrical connector. Connect seat belt retractor pretensioner to vehicle harness connector. Repeat procedure for driver side.
4. If vehicle is equipped with safety canopies, remove air bag simulator from passenger side safety canopy electrical connector. Connect safety canopy electrical connector. Repeat procedure for driver side.
5. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Focus)

1. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connectors at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove glove box. Disconnect passenger side air bag module electrical connectors. Connect appropriate air bag simulators to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. Working beneath driver's seat, disconnect driver side air bag module connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side air bag module.
5. Disconnect driver side pretensioner electrical connector. Connector is located under driver's seat. Connect a seat belt pretensioner simulator to vehicle harness (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side seat belt pretensioner. Connect negative battery cable.

Activating System (Focus)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove the seat belt pretensioner simulators from the vehicle harness. Connect seat belt pretensioner connectors to vehicle harness.
2. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect passenger air bag module connector. Install glove box.
3. Remove air bag simulator from driver side air bag vehicle harness. Reconnect driver side air bag module connector. Repeat procedure for passenger side air bag connector.
4. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (F150)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt front seats to their highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Remove oval-shaped relay cover from passenger side of instrument panel. (Scheme 6) Disconnect passenger side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. Vehicles equipped with Seat Integrated Restraints (SIR), disconnect passenger seat safety belt buckle connector located under the seat. Connect appropriate simulator to vehicle harness (in place of safety belt buckle). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side.
5. Regular cabs with safety belt retractor pretensioners, access the passenger safety belt retractor and pretensioner located behind the passenger side rear corner trim panels. SuperCabs with safety belt retractor pretensioners, access the passenger safety belt retractor and pretensioner located under passenger side safety belt retractor trim cover. SuperCrews with safety belt retractor pretensioners, access the passenger safety belt retractor and pretensioner located behind the passenger side "B" pillar trim panels.
6. On vehicles equipped with safety belt retractor pretensioners, disconnect the passenger safety belt retractor and pretensioner electrical connector. Connect appropriate simulator to vehicle harness (in place of safety belt buckle). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side. Connect negative battery cable.

Activating System (F150)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver's air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger air bag module harness connector. Install relay cover on instrument panel. If vehicle is equipped with seat integrated restraints, remove simulator from vehicle harness and connect passenger side safety belt buckle. Repeat procedure for driver side.
3. If vehicle is equipped with safety belt retractor pretensioners, remove simulator from vehicle harness and connect passenger side safety belt retractor pretensioner. Install trim panel as necessary. Repeat procedure for driver side safety belt retractor pretensioner.
4. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (LS)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt front seats to the highest and most forward position. Disconnect negative battery cable. WAIT at least one minute for backup power supply to deplete stored energy. Be sure to disconnect auxiliary batteries and power supplies (if equipped).
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module). Connect appropriate air bag simulators to clockspring connectors at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. If vehicle is equipped with side air curtain modules, remove "A" pillar trim panel. Disconnect driver's side air curtain module electrical connector. (Scheme 7) Connect appropriate air bag simulator to vehicle harness of the driver's side air curtain module electrical connector. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for passenger's side air curtain module.
4. Remove glove box. (Scheme 8) The passenger air bag module electrical connector is located in front of the cross-car beam attached by a pin-type retainer to a bracket on the back of the passenger air bag module. (Scheme 9) Disconnect passenger side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
5. Connect negative battery cable. Move and tilt the front seats to their highest and most forward position. Disconnect the battery ground cable and WAIT at least one minute. Be sure to disconnect auxiliary batteries and power supplies (if equipped).
6. From under the passenger seat, release the tab and disconnect the passenger seat side air bag (without side air curtain) or passenger seat side thorax air bag (with side air curtain) electrical connector. Connect appropriate air bag simulator to vehicle harness. See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side.
7. Remove passenger side "B" pillar weather-stripping. Position passenger side safety belt shoulder height adjuster to its highest point. Detach passenger side "B" pillar trim panel. Remove passenger side front and rear door scuff plates. Remove the passenger side "B" pillar lower trim panel.
8. Disconnect passenger side safety belt retractor pretensioner electrical connector. Located at base of "B" pillar. Connect a seat belt pretensioner simulator to vehicle harness (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side seat belt pretensioner. Connect negative battery cable.

Scheme 7

Scheme 8

Scheme 9

Activating System (LS)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove the pretensioner simulators from the vehicle harness at the seat belt retractor pretensioner. Connect seat belt pretensioner connectors to vehicle harness.
2. Remove air bag simulators from side air curtain modules. Connect side air curtain module connectors to vehicle harness.
3. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect passenger air bag module connector.
4. Remove air bag simulator from driver side air bag vehicle harness. Reconnect driver side air bag module connector. Repeat procedure for passenger side air bag connector.
5. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Mustang)

1. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. WAIT at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Open glove box. Press sides inward and lower glove box to floor. Remove passenger air duct (if necessary). Disconnect passenger side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Connect negative battery cable.

Activating System (Mustang)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Connect passenger side air bag module harness connector. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Ranger)

1. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Connect negative battery cable.

Activating System (Ranger)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock. Using scan tool, clear DTCs.

Disabling System (Sable & Taurus)

1. Record radio preset frequencies for reprogramming (if equipped). Move seats to highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove lower steering column cover. Disconnect 4-pin driver air bag connector at base of steering column. (Scheme 10) Connect appropriate air bag simulator (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Remove passenger air bag. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module). Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. Disconnect passenger side air bag electrical connector under passenger seat. Connect air bag simulator to vehicle connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side air bag module.
5. Release the hook and loop strip and pull the seat cushion trim cover away enough to expose the safety belt buckle pretensioner connector. Disconnect driver side safety belt buckle pretensioner connector. Connect appropriate seat belt pretensioner simulator to vehicle harness (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for passenger side safety belt buckle pretensioner. Connect negative battery cable.

Scheme 10

Activating System (Sable & Taurus)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove the pretensioner simulators from the vehicle harness at the safety belt buckle pretensioners. Connect seat belt pretensioner connectors to vehicle harness.
2. Remove air bag simulator from driver side air bag vehicle harness. Reconnect driver side air bag module connector to vehicle harness. Repeat procedure for passenger side air bag connector.
3. Remove air bag simulator from driver air bag harness connector. Connect driver air bag module to vehicle harness. Install lower steering column cover. Remove air bag simulator from passenger air bag vehicle harness connector. Install passenger air bag module and reconnect air bag module connector to vehicle harness. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) .
4. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Thunderbird)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt front seats to the highest and most forward position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove glove box. Disconnect passenger side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. Working beneath driver's seat, disconnect driver side air bag module connector. Connect appropriate air bag simulator to vehicle harness (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side air bag module.
5. Access driver side seat belt retractor pretensioner connector behind trim panel. Disconnect driver side pretensioner electrical connector. Connect a seat belt pretensioner simulator to vehicle harness (in place of pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side seat belt pretensioner. Connect negative battery cable.

Activating System (Thunderbird)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove the pretensioner simulators from the vehicle harness at the seat belt retractor pretensioner. Connect seat belt pretensioner connectors to vehicle harness.
2. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect passenger air bag module connector.
3. Remove air bag simulator from driver side air bag vehicle harness. Reconnect driver side air bag module connector. Repeat procedure for passenger side air bag connector.
4. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Town Car)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt front seats to the highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulators to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulator to vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
4. Working under driver's seat, disconnect side air bag module electrical connector. Connect appropriate air bag simulator to vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger side air bag module.
5. Disconnect driver side seat belt pretensioner connector. Connector is located behind driver side "B" pillar. Connect appropriate simulator to vehicle harness connector (in place of seat belt pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Repeat procedure for passenger seat belt pretensioner. Connect negative battery cable.

Activating System (Town Car)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) .
3. Remove air bag simulator from passenger side air bag vehicle harness. Connect passenger side air bag module connector to vehicle harness. Repeat procedure for driver side air bag module.
4. Remove simulator from passenger seat belt pretensioner vehicle harness. Connect passenger seat belt pretensioner connector to vehicle harness. Repeat procedure for driver seat belt pretensioner.
5. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Disabling System (Windstar)

1. Record radio preset frequencies for reprogramming (if equipped). Move and tilt the front seats to their highest and rearmost position. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove access panel on rear of steering wheel. (Scheme 11) Disconnect air bag module connector. Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
3. Open glove box. Press in on sides to release stops and lower glove box. Disconnect passenger air bag module electrical connector. Connect appropriate air bag simulator to passenger air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator).
4. Disconnect side air bag module connector under driver seat. Connect appropriate air bag simulator to vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for passenger side.
5. Disconnect passenger seat belt pretensioner, located behind "B" pillar. Connect appropriate seat belt pretensioner simulator to vehicle harness connector (in place of seat belt pretensioner). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator). Repeat procedure for driver side. Connect negative battery cable.

Scheme 11

Activating System (Windstar)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Reconnect air bag module connector. Install steering wheel access panel.
2. Remove air bag simulator from passenger air bag vehicle harness connector. Reconnect air bag module connector. Restore glove box to original position.
3. Disconnect side air bag simulators. Reconnect side air bag module connectors. Disconnect seat belt pretensioner simulators. Reconnect seat belt pretensioner connectors. Reconnect negative battery cable. Recheck system operation. Perform «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram USER 1 and USER 2 preset radio frequencies and set clock.

Disabling System (ZX2)

1. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy.
2. Remove driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) . Connect appropriate air bag simulator to clockspring connector at top of steering column (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) .
3. Remove passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Connect appropriate air bag simulator to passenger air bag vehicle harness connector (in place of air bag). See «AIR BAG SIMULATOR»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__air-bag-simulator) . Connect negative battery cable.

Activating System (ZX2)

1. Disconnect negative battery cable. Wait at least one minute for backup power supply to deplete stored energy. Remove air bag simulator from clockspring connector at top of steering column. Install driver air bag module. See «DRIVER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__driver-air-bag-module) .
2. Remove air bag simulator from passenger air bag vehicle harness connector. Install passenger air bag module. See «PASSENGER AIR BAG MODULE»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__passenger-air-bag-module) . Reconnect passenger air bag module connector. Reconnect negative battery cable. Recheck system operation. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

AIR BAG SIMULATOR

An air bag simulator tool is needed when deactivating the air bag system. The air bag simulator contains a calibrated 2-ohm resistor which simulates the air bag module connections to the system. DO NOT short circuit air bag module connections with a zero-ohm jumper wire. For specific simulator applications, see AIR BAG SIMULATOR APPLICATION table.

AIR BAG SIMULATOR APPLICATION

Scheme 12

Scheme 13

DRIVER AIR BAG MODULE

Removal & Installation (Aviator, Econoline, Excursion, Expedition, Explorer, Explorer Sport, Explorer Sport Trac, F150, F250-550 Super Duty, Mountaineer & Navigator)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute to deplete backup power supply energy.
2. Remove 2 back cover plugs from rear of steering wheel. Remove bolts retaining air bag module to steering wheel. (Scheme 14) Disconnect electrical connector(s) from air bag module. Remove air bag module from steering wheel.
3. To install, reverse removal procedure. Tighten air bag module bolts to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications). Connect negative battery cable. Ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Reprogram radio preset frequencies and set clock.

Removal & Installation (Crown Victoria, Grand Marquis & Marauder)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Record USER 1 and USER 2 preset radio frequencies for reprogramming. Disconnect negative battery cable.
2. Remove 2 back cover plugs from rear of steering wheel. Remove bolts from side of steering wheel (one on each side of steering wheel hub). Disconnect air bag module and horn wiring connectors from clockspring connector, and remove driver air bag module.
3. To install, connect air bag module wiring connector to clockspring connector. Position air bag module on steering wheel and install bolts. Tighten fasteners to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Connect negative battery cable. Ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-excursion-f250-550-super) . Reprogram USER 1 and USER 2 preset radio frequencies and set clock.

Removal & Installation (Focus, LS, Mustang, Ranger, Thunderbird, Town Car & ZX2)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute to deplete backup power supply energy.
2. Remove module retaining screw trim plugs, (if equipped), from back of steering wheel. Remove driver air bag retaining screws or Torx screws. (Scheme 14) Disconnect air bag module wiring connector from clockspring connector. Disconnect horn switch connector, if necessary. Remove air bag module.
3. To install, reverse removal procedure. Tighten air bag module bolts to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications). Connect negative battery cable. Ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Reprogram radio preset frequencies and set clock.

Scheme 14

PASSENGER AIR BAG MODULE

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . The passenger air bag module is mounted in right side of instrument panel, above glove box. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute.
2. Remove trim panel above glove compartment by pulling straight out to release retaining clips. Disconnect 3 electrical connectors and remove trim panel. Open glove box. Push in on glove box door tabs and position glove box door downward. Through glove box opening, remove 2 lower passenger air bag module retaining bolts. Remove 2 upper passenger air bag module retaining bolts.
3. Remove passenger air bag module by placing one hand in from the glove box opening, and pushing air bag module from instrument panel. Disconnect passenger air bag module electrical connector and remove module from vehicle. To install, reverse removal procedure. Tighten passenger air bag module retaining bolts to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Removal & Installation (Explorer Sport, Explorer Sport Trac & Ranger)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . The passenger air bag module is mounted in right side of instrument panel, above glove box. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute.
2. Open glove box. Push in on glove box door tabs and position glove box door downward. Remove 2 passenger air bag module retaining bolts. Remove passenger air bag module by placing one hand in from the glove box opening, and pushing air bag module from instrument panel. Disconnect passenger air bag module electrical connector and remove module from vehicle.
3. To install, reverse removal procedure. Tighten passenger air bag module bolts to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

Removal & Installation (Sable & Taurus)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . The passenger air bag module is mounted in right side of instrument panel, above glove box. Disable air bag system. See «DISABLING SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-sable-taurus) . Leave negative battery cable disconnected.
2. Open glove box. Push in on tabs, and rotate glove box downward. Through glove box opening, remove 2 passenger air bag Torx bolts.
3. On passenger side of instrument panel, pull lower left corner of top trim panel away from instrument panel. Working from left to right, slide across seam between trim cover and instrument panel, releasing trim cover retaining clips. Disconnect passenger air bag module electrical connector and remove module.
4. To install, reverse removal procedure. Top trim cover is correctly aligned when there is an even gap around outside edge of cover. Tighten passenger air bag module fasteners to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-excursion-f250-550-super) .
5. Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio presets and reset clock. Repeat SYSTEM OPERATION CHECK.

Removal & Installation (Thunderbird)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). The passenger air bag module is mounted in right side of instrument panel, above glove box. Record radio preset frequencies for reprogramming (if equipped). Deactivate the air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures).
2. Position the seats as needed to remove the console. Disconnect the battery. Apply parking brake and place the transmission selector lever in NEUTRAL. Pull upward from front of the trim panel to release the retainers and remove console finish panel. Disconnect electrical connectors and lower instrument panel finish panel. Remove parking brake boot. Remove floor console assembly rear nut, and front and rear screws. Remove floor console assembly rear bolts and floor console assembly.
3. Remove the left and right "A" pillar lower trim panels. Remove left and right windshield side garnish moldings. Remove instrument panel components in the order indicated. (Scheme 15), (Scheme 16) and (Scheme 17). Ensure air bag simulator is installed in place of passenger air bag module. With help from an assistant, remove instrument panel.
4. Position instrument panel on a clean, padded work bench with back facing up. Remove instrument panel components and passenger air bag module in order indicated. (Scheme 18)and (Scheme 19).
5. To install, reverse removal procedure. Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Reprogram radio preset frequencies and set clock.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Removal & Installation (Town Car)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . The passenger air bag module is mounted in right side of instrument panel, above glove box. Disable air bag system. See «DISABLING SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-town-car) . Leave negative battery cable disconnected.
2. Remove audio unit. Remove instrument cluster finish panel. Open glove box. Disconnect glove compartment isolator. Push in on tabs, and rotate glove box downward. Through glove box opening, separate air bag module wiring harness retainers from instrument panel. Remove 2 passenger air bag module bolts through glove box opening.
3. Remove passenger air bag module by placing one hand in from the glove box opening, and pushing air bag module from instrument panel. Disconnect passenger air bag module electrical connector and remove module from vehicle.
4. To install, reverse removal procedure. Tighten passenger air bag module fasteners to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__disabling-system-excursion-f250-550-super) .
5. Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio presets and reset clock. Repeat SYSTEM OPERATION CHECK.

Removal & Installation (ZX2)

1. Before proceeding, see «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . The passenger air bag module is mounted in right side of instrument panel, above glove box. Record radio preset frequencies for reprogramming (if equipped). Disconnect negative battery cable. Wait at least one minute.
2. Open glove box. Push in on glove box door tabs and position glove box door downward. Remove 4 passenger air bag module retaining bolts. Pull module from instrument panel. Disconnect passenger air bag module electrical connector and remove module from vehicle.
3. To install, reverse removal procedure. Tighten passenger air bag module bolts to specification. See «AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures__torque-specifications) . Check AIR BAG warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) . Reprogram radio preset frequencies and set clock.

TORQUE SPECIFICATIONS

AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)

GENERAL MOTORS

Pickups With Passenger Air Bag

Turn ignition switch from OFF to ON position. Turn passenger air bag switch to OFF position, then back to ON position. With ON/OFF switch in ON position, AIR BAG warning light should flash 7 times, then turn off.

The following AIR BAG warning light conditions indicate possible SIR system faults.

1. Light does not illuminate at all.
2. Light remains illuminated when ignition is turned on.
3. Light illuminates while vehicle is driven.

All Models Except Pickups With Passenger Air Bag

Turn ignition switch from OFF to ON or RUN position. AIR BAG warning light should flash 7 times (6-10 times on DeVille) and then turn off.

The following AIR BAG warning light conditions indicate possible SIR system faults.

1. Light does not illuminate at all.
2. Light remains illuminated when ignition is turned on.
3. Light illuminates while vehicle is driven.

SIR system faults are usually due to a disconnected/loose electrical connector caused by previous service on vehicle. Always check all Yellow SIR connectors for loose connections or damage.

If all connectors are okay, and AIR BAG warning light is still not operating properly, diagnose SIR system. Repair air bag system as necessary.

Vehicles With Passenger Presence System (PPS)

PASSENGER AIR BAG ON/OFF indicators located on the rear view mirror are used to notify the driver when the Passenger Presence System (PPS) has enabled or disabled the instrument panel inflator module. The PPS air bag indicators will also inform the driver of any PPS malfunctions. When the ignition is turned on, the PPS module is supplied with ignition 1 voltage and commands both PASSENGER AIR BAG ON/OFF indicators ON for 5 seconds. The PPS module conducts tests on the PPS components and circuits while both ON/OFF indicators are ON. If no malfunctions are detected, the PPS module will turn the PASSENGER AIR BAG indicator ON or OFF depending on the status of the PPS. If a malfunction is detected, the PPS module will store a Diagnostic Trouble Code (DTC), default the PPS to the OFF state and communicate with the SDM that a DTC has been set. When the SDM detects that the PPS has set a DTC, the SDM will set either DTC B0092 or B0098 and request the Instrument Panel Cluster (IPC) to turn the AIR BAG indicator located on the IPC ON. This is done to notify the driver of any PPS malfunctions. The presence of a SIR system malfunction could result in non-deployment of the air bags. The AIR BAG indicator will remain ON until the malfunction has been repaired.

Observe the following service precautions when working with air bag systems

1. Disable appropriate air bag system zone or zones before servicing any air bag system or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
2. Sensing and Diagnostic Module (SDM) maintains a reserve energy supply. Deployment power is available for as long as one minute after disconnecting battery power. Servicing vehicle before this time limit is reached may cause accidental air bag deployment and possible personal injury.
3. After repairs, stay well away from air bag inflator module(s), and turn ignition switch to ON position. Ensure AIR BAG warning light is working properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
4. Use only new, original equipment replacement parts. DO NOT use salvaged parts for SIR system repairs.
5. DO NOT expose air bag inflator modules to temperatures above 150°F (65°C).
6. Always wear safety glasses when servicing or handling an air bag.
7. Air bag module must be stored in its original special container until it is ready to be used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks or high electrical energy.
8. When placing a live air bag module on a bench or other surface, always face air bag and trim cover upward, away from surface. This will reduce motion of module if it is accidentally deployed.
9. After deployment, air bag surface may contain deposits of sodium hydroxide which can irritate skin. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
10. When carrying a live air bag module, point trim cover away from your body to minimize injury in case of accidental deployment. DO NOT carry live air bag module by wiring harness or connector.
11. DO NOT carry seat belt pretensioner by wiring harness or connector. Seat belt pretensioner can be carried by piston tube. When handling a live seat belt pretensioner, DO NOT touch seat belt pretensioner in cable area between buckle and mounting bolt hole. DO NOT cover pretensioner piston tube opening with hands or point open end at yourself or others.
12. Coil assembly must be replaced whenever air bag is deployed. Replace Sensing and Diagnostic Module (SDM), driver air bag module, passenger air bag module, side air bag module, side air bag sensor or front air bag sensor if any component has been dropped from a height of 3 feet or more.
13. DO NOT attempt to repair Sensing and Diagnostic Module (SDM), air bag inflator modules, air bag sensors or steering wheel coil assembly. Service all components by replacement only.
14. Electrical sources should never be allowed near inflator on back of air bag module.
15. Avoid touching Sensing and Diagnostic Module (SDM) terminals to prevent electrostatic discharge damage.
16. If water enters the vehicle's interior and soaks the carpet up to level of Sensing and Diagnostic Module (SDM), inspect the affected area and remove all evidence of water. Repair water damage, replace SDM, and replace harness connector. Failure to do this may result in accidental air bag deployment and possible personal injury.
17. If air bag system is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If air bag system is not functional, park vehicle until repairs can be made.

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

Supplemental Inflatable Restraint (SIR) Disabling & Enabling Zones

Note. Not all zones are used by all vehicles.

The Supplemental Inflatable Restraint (SIR) system has been divided into disabling and enabling zones. When performing service on or near SIR components or SIR wiring, it may be necessary to disable the SIR components in that zone. It may be necessary to disable more than one zone depending on the location of other SIR components and the area being serviced. (Scheme 20) Identify the specific zone or zones in which service will be performed and disable and enable selected zone or zones.

Scheme 20

Disabling System (Alero, Grand Am & Malibu)

Note. When AIR BAG fuse is removed and the ignition is in ON position, the AIR BAG warning lamp will illuminate. This is a normal operation and does not indicate an SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove AIR BAG fuse from junction block/fuse panel at far left end of instrument panel. (Scheme 21) Wait one minute.
3. Zone 3 To disable driver side air bag module and coil located in SIR Zone 3, remove Connector Position Assurance (CPA) clip. (Scheme 20) Disconnect driver 2-pin Yellow SIR connector located above fuse block. (Scheme 21)
4. Zone 5 To disable passenger side air bag module located in SIR Zone 5, remove access panel from junction block/fuse panel at far right end of instrument panel. (Scheme 20) Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located above fuse block. (Scheme 22)
5. Zone 9 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, remove CPA clip. (Scheme 20) Disconnect driver side 2-pin Yellow SIR connector located above fuse block. (Scheme 21)and (Scheme 22). Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located above fuse block.

Scheme 21

Scheme 22

Activating System (Alero, Grand Am & Malibu)

1. Ensure key is out of ignition switch and AIR BAG fuse is still removed. Connect Yellow SIR connectors previously disconnected to vehicle harness and install CPA clips. Install AIR BAG fuse. Install access panels.
2. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.

Disabling System (Astro & Safari)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is under lower left side of instrument panel, on firewall. Wait at least one minute.
3. Zone 1 To disable inflatable restraint front end discriminating sensor located in SIR Zone 1, raise and support the vehicle. (Scheme 20) Remove Connector Position Assurance (CPA) clip from inflatable restraint front end discriminating sensor connector located on the frame crossmember. Disconnect inflatable restraint front end discriminating sensor connector.
4. Zone 3 To disable driver side air bag module and coil located in SIR Zone 3, remove sound insulator and knee bolster from lower left side of instrument panel. (Scheme 20) Remove CPA clip from driver 2-pin Yellow SIR connector located left of the steering column near the knee bolster. Disconnect driver 2-pin Yellow SIR connector located near the knee bolster. (Scheme 23)
5. Zone 5 To disable passenger side air bag module located in SIR Zone 5, remove passenger knee bolster from right side of instrument panel. (Scheme 20) Remove the CPA clip from the passenger side air bag module 2-pin Yellow SIR connector located behind instrument panel support. Disconnect passenger side air bag module 2-pin Yellow connector. (Scheme 24)
6. Zone 7 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 7, remove sound insulator and knee bolster from lower left side of instrument panel. (Scheme 20) Remove CPA clip from driver 2-pin Yellow SIR connector located left of the steering column near the knee bolster. Disconnect driver 2-pin Yellow SIR connector located near the knee bolster. (Scheme 23) Remove passenger knee bolster from right side of instrument panel. Remove passenger air bag CPA clip and disconnect 2-pin Yellow SIR connector located behind instrument panel support. (Scheme 24)

Activating System (Astro & Safari)

1. Remove key from ignition switch. Ensure AIR BAG fuse is still removed from fuse block. Connect passenger air bag Yellow 2-pin connector. Install CPA clip. Connect driver air bag Yellow 2-pin connector. Install CPA clip. To complete installation, reverse removal procedure.
2. Install AIR BAG fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off.

Scheme 23

Scheme 24

Disabling System (Aurora, Bonneville, LeSabre & Park Avenue)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position. Remove key from ignition switch.
2. Remove SIR fuse from fuse block. On Aurora, Bonneville and LeSabre, fuse is in rear fuse block beneath rear seat cushion, on driver's side. On Park Avenue, fuse is in underhood fuse block. Wait one minute.
3. Zone 1 On Aurora, Bonneville and LeSabre, to disable inflatable restraint front end discriminating sensor located in SIR Zone 1, open front hood. Locate front end sensor sometimes referred to as Electronic Frontal Sensor (EFS). Remove Connector Position Assurance (CPA) clip from EFS. Remove EFS connector from the EFS.
4. Zones 2 & 6 To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove appropriate center pillar trim panel. Remove front and rear carpet retainers and then center pillar trim panel. Remove inflatable restraint SIS CPA clip from the SIS and then remove SIS Yellow connector. (Scheme 25)
5. Zone 3 To disable inflatable restraint steering wheel module and coil located in SIR Zone 3, remove sound insulator panel from under left side of instrument panel. Remove CPA clip, and disconnect driver 2-pin Yellow SIR connector at base of steering column. (Scheme 26)
6. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove right insulator panel from under right side of instrument panel. Remove passenger air bag CPA clip from the vehicle harness Yellow connector located under instrument panel and disconnect 2-pin Yellow SIR connector from vehicle harness. (Scheme 27)
7. Zone 7 To disable driver's seat side air bag module located in SIR Zone 7, remove CPA clip from driver's seat side air bag module Yellow 2-pin connector located under driver's seat. (Scheme 28) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector.
8. Zone 8 On Aurora, Bonneville and LeSabre, to disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable SIR Zones 1, 2, 3 5, 6, 7 and 9. Remove CPA clip from Yellow connectors and disconnect vehicle harness SIR Yellow connectors.
9. Zone 9 (Except Park Avenue) On Aurora, Bonneville and LeSabre, to disable passenger's seat side air bag module located in SIR Zone 9, remove CPA clip from passenger's seat side air bag module Yellow 2-pin connector located under passenger's seat. (Scheme 28) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector.
10. Zone 9 (Park Avenue) On Park Avenue, inflatable restraint Sensing and Diagnostic Module (SDM) and passenger's seat side air bag module are located in SIR Zone 9. To disable passenger's seat side air bag module, remove CPA clip from passenger's seat side air bag module Yellow 2-pin connector located under passenger's seat. (Scheme 28) Disconnect vehicle harness Yellow connector from side air bag module Yellow connector. To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable passenger's seat side air bag module and SIR Zones 2, 3, 5, 6 and 7. Remove CPA clip from Yellow connectors and disconnect vehicle harness SIR Yellow connectors.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Activating System (Aurora, Bonneville, LeSabre & Park Avenue)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Avalanche, Escalade, Escalade ESV, Escalade EXT, Sierra, Silverado, Suburban, Tahoe, Yukon & Yukon XL)

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is located at far left end of instrument panel. Wait one minute.
2. Zone 1 To disable, inflatable restraint front end sensors located in SIR Zone 1, raise and support vehicle. Remove Connector Position Assurance (CPA) clip from both front end sensor connectors located on the frame crossmember. Disconnect both front end sensor connectors.
3. Zones 2 & 6 To disable left or right front door inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove the front door handle bezel. Remove the window handle, if equipped. Release the upper extension by pulling outward in order to release upper retainer clip. Remove upper extension from door trim panel by lifting up and out. Remove the manual lock lever from the trim panel using a flat-bladed tool. Remove the trim panel screws. Disconnect the electrical connectors and remove trim panel from door. Carefully slide door trim panel up in order to release retainers from the door. Remove CPA clip from side air bag sensor Yellow 2-pin connector located near bottom of door. (Scheme 29) Disconnect side air bag sensor Yellow 2-pin connector.
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from steering wheel module Yellow 4-pin connector located left of steering column near knee bolster. (Scheme 30) Disconnect steering wheel module Yellow 4-pin connector.
5. Zone 5 To disable passenger air bag module located in SIR Zone 5, open glove box. Push in on glove box sides to fully open glove box. Remove CPA clip. Disconnect passenger air bag 4-pin Yellow SIR connector located behind glove box attached to main instrument panel support. (Scheme 31)
6. Zone 7 To disable inflatable restraint Sensing and Diagnostic Module (SDM), inflatable restraint side air bag module, and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 7, remove CPA clip from driver air bag module Yellow 4-pin connector. Disconnect driver air bag module Yellow 4-pin connector. Remove CPA clip from passenger air bag module Yellow 4-pin connector. Disconnect passenger air bag module Yellow 4-pin connector. Remove CPA clip from the right front side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right front side air bag module Yellow 2-pin connector. Remove CPA clip from left front side air bag module Yellow 2-pin connector located under driver seat. Disconnect left front side air bag module Yellow 2-pin connector.
7. Zone 9 To disable inflatable restraint Passenger Presence System (PPS), inflatable restraint side air bag module, inflatable restraint Seat Position Switch (SPS), and inflatable restraint seat belt tension retractor sensor located in SIR Zone 9, remove CPA clip from right side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right side air bag module Yellow 2-pin connector.

Scheme 29

Scheme 30

Scheme 31

Activating System (Avalanche, Escalade, Escalade ESV, Escalade EXT, Sierra, Silverado, Suburban, Tahoe, Yukon & Yukon XL)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Aztek & Rendezvous)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove console accessory wiring junction block access hole cover. Remove SIR (10-amp) fuse from fuse block. Fuse block is behind access cover on right side of center console. Wait one minute.
2. Zone 1 To disable restraint Electronic Front End Sensor (EFS) located in SIR Zone 1, remove grille. Remove retainers that hold upper front bumper fascia to radiator support. Pull fascia from radiator support to gain access to sensor. Remove Orange CPA clip from Yellow sensor harness connector. Disconnect harness connector from sensor.
3. Zones 2 Or 6 To disable driver/left Side Impact Sensor (SIS) located in SIR Zone 2 or passenger/right Side Impact Sensor (SIS) located in SIR Zone 6, remove front and rear door sill plates from appropriate zone. Remove center pillar lower trim. Remove CPA clip from Yellow 2-pin harness connector on inflatable restraint side air bag sensor. (Scheme 32) Disconnect wiring harness connector from side air bag sensor.
4. Zone 3 To disable driver side air bag module and coil located in SIR Zone 3, remove sound insulator panel from under left side of dash. Remove CPA clip. Disconnect driver air bag 2-pin Yellow SIR connector at base of steering column. (Scheme 33)
5. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove sound insulator panel from under right side of dash. Remove CPA clip from passenger air bag module connector located behind right side insulator panel. Disconnect passenger air bag 2-pin Yellow SIR connector. (Scheme 58)
6. Zone 7 Or 9 To disable driver seat side air bag module located in SIR Zone 7 or passenger seat side air bag module located in SIR Zone 9, remove CPA clip from driver side or passenger side air bag 2-pin Yellow SIR connector. Disconnect Yellow SIR connector from vehicle harness located under driver seat or passenger seat. (Scheme 34)
7. Zone 9 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5, 7 and passenger seat side air bag module located in SIR Zone 9. Disconnect Yellow component connectors.

Activating System (Aztek & Rendezvous)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Scheme 32

Scheme 33

Scheme 34

Disabling System (Blazer, Jimmy, S10 Pickup & Sonoma)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove SIR fuse from instrument panel fuse block. Fuse block is located behind access cover on far left end of instrument panel. Wait one minute.
2. Zone 1 To disable inflatable restraint front end discriminating sensors located in SIR Zone 1, raise and support the vehicle. Remove Connector Position Assurance (CPA) clip from both inflatable restraint front end discriminating sensor connectors located on frame crossmember. Disconnect inflatable restraint front end discriminating sensor connectors.
3. Zone 3 To disable driver side air bag module and coil located in SIR Zone 3, remove left side knee bolster. Remove CPA clip and disconnect driver air bag 2-pin Yellow SIR connector at base of steering column. (Scheme 35)
4. Zone 5 To disable passenger side air bag module located in SIR Zone 5, open glove box, lift stop, and allow door to fully open. Remove CPA clip and disconnect passenger air bag 2-pin Yellow SIR connector. Connector is located behind instrument panel support, in left side of glove box opening.
5. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 1, 3 & 5. Disconnect Yellow component connectors.

Activating System (Blazer, Jimmy, S10 Pickup & Sonoma)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Scheme 35

Disabling System (Bravada, Envoy, Envoy XL, TrailBlazer & TrailBlazer EXT)

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove SIR fuse from underhood fuse block. Fuse block is located in the underhood fuse block. Wait one minute.
2. Zone 1 To disable inflatable restraint Electronic Front Sensors (EFS) located in SIR Zone 1, remove the grille. Remove headlamp wire harness from the retaining clip and raise wire harness to gain access to the front end sensor. Loosen sensor retaining bolts and remove sensor assembly from the frame. (Scheme 36) Position sensor assembly above the front bumper. Remove sensor retaining bolts and protective cover. Remove Connector Position Assurance (CPA) clip from the sensor electrical connector and disconnect sensor electrical connector.
3. Zones 2 & 6 To disable left or right front door inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove accessory switch panel. Remove 2 trim panel retaining bolts. Release 9 trim panel fasteners from door and remove trim panel from the door. Remove CPA clip from side air bag sensor Yellow 2-pin connector located near the bottom of door. (Scheme 29) Disconnect side air bag sensor Yellow 2-pin connector located near the bottom of door.
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove left instrument panel closeout/insulator panel. Remove 4 trim panel retaining screws, release trim panel retaining clips and remove trim panel. Remove CPA clip from driver air bag module Yellow 4-pin connector located left of steering column, near knee bolster. (Scheme 37) Disconnect driver air bag module Yellow 4-pin connector.
5. Zone 5 To disable passenger air bag module located in SIR Zone 5, access passenger air bag module Yellow 4-pin connector through glove box. Remove CPA clip from instrument panel module Yellow 4-pin connector located behind instrument panel support. Disconnect instrument panel module Yellow 4-pin connector located behind instrument panel support.
6. Zone 7 To disable inflatable restraint side air bag module located in SIR Zone 7, remove CPA clip from left side air bag module Yellow 2-pin connector located under driver seat. Disconnect left side air bag module Yellow 2-pin connector located under driver seat.
7. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3, 5, 7 and 9. Disconnect Yellow component connectors.
8. Zone 9 To disable inflatable restraint side air bag module located in SIR Zone 9, remove CPA clip from right side air bag module Yellow 2-pin connector located under passenger seat. Disconnect right side air bag module Yellow 2-pin connector located under passenger seat.

Scheme 36

Scheme 37

Activating System (Bravada, Envoy, Envoy XL, TrailBlazer & TrailBlazer EXT)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Cavalier & Sunfire)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK or OFF position and remove key. Remove AIR BAG fuse from fuse block. Fuse block is located behind cover on far left end of instrument panel. Wait at least one minute.
2. Zones 2 Or 6 (Coupe) To disable Side Impact Sensor (SIS) located in SIR Zone 2 (left) or 6 (right), remove door trim panel of suspect sensor. Remove enough water deflector to access the side air bag sensor. Remove side air bag sensor from door. (Scheme 38) Remove Connector Position Assurance (CPA) clip from SIS connector and disconnect SIS connector.
3. Zones 2 Or 6 (Sedan) To disable Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove center pillar upper trim. Remove inflatable restraint side air bag sensor from center pillar. (Scheme 39) Remove CPA clip from SIS connector and disconnect SIS connector.
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from driver air bag module in-line Yellow 2-pin connector. Connector is located under the instrument panel, left of the steering column. (Scheme 40) Disconnect driver air bag module Yellow 2-pin connector.
5. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove CPA clip from the passenger air bag module in-line Yellow 2-pin connector located under the instrument panel, left of the steering column. (Scheme 40) Disconnect the inflatable restraint instrument panel module in-line connector.
6. Zone 7 Or 9 To disable driver seat with left side air bag module located in SIR Zone 7 or passenger seat with right side air bag module located in SIR Zone 9, remove CPA clip from inflatable restraint side air bag module connector located under seat. (Scheme 41) Disconnect side air bag module connector.
7. Zone 9 To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5, 7 and 9. Disconnect Yellow component connectors.

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Activating System (Cavalier & Sunfire)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Century, Grand Prix & Regal)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position and remove key. Remove fuse block access door on far right end of instrument panel. Remove AIR BAG (or SIR) fuse. Wait one minute.
2. Zone 2 (Century & Regal Only) To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2, remove front and rear door jam carpet retainer. Remove door jam weatherstrip from center pillar pinch weld flange to expose the lower trim panel. Starting at the base, grasp trim panel firmly with both hands and pull panel away from center pillar. Remove seat belt from the slot in the lower trim panel. Remove the center pillar lower trim. Loosen 2 SIS mounting screws and remove SIS from center pillar. Remove Connector Position Assurance (CPA) clip from SIS connector. Disconnect SIS connector.
3. Zone 3 To disable, driver air bag module and coil located in SIR Zone 3, remove sound insulator panel from under lower left side of instrument panel. Remove CPA clip, and disconnect driver air bag module Yellow 2-pin connector at base of steering column. (Scheme 42) Disconnect steering wheel module coil connector.
4. Zone 5 To disable passenger side air bag module, located in SIR Zone 5, remove left insulator panel. Remove CPA clip from passenger 2-pin Yellow connector. Disconnect passenger 2-pin Yellow SIR connector located to right of steering column. (Scheme 43)
5. Zone 7 (Century & Regal Only) To disable driver seat side air bag, located in SIR Zone 7, remove CPA clip from driver side air bag module 2-pin Yellow connector located under driver seat. Disconnect side air bag module 2-pin Yellow connector.
6. Zone 9 (Century & Regal Only) To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 2, 3 and 5. Disconnect Yellow component connectors.
7. Zone 9 (Grand Prix Only) To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3 and 5. Remove CPA clip from SDM wiring harness connector. Disconnect SDM wiring harness connector from SDM.

Scheme 42

Scheme 43

Activating System (Century, Grand Prix & Regal)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Chevy Express & Savana)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove AIR BAG fuse from instrument panel fuse block. Fuse block is located on lower left side of instrument panel, above hood release. Wait one minute.
2. Zone 1 To disable inflatable restraint front end sensor located in SIR Zone 1, raise and support vehicle. Remove Connector Position Assurance (CPA) clip from front end sensor connector located on frame crossmember. Disconnect the front end sensor connector.
3. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from driver air bag module 4-pin Yellow connector. (Scheme 44) Disconnect driver air bag module 4-pin Yellow connector located left of steering column, near knee bolster.
4. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove passenger-side lower trim panel and knee bolster. Remove CPA clip, and disconnect passenger air bag 4-pin Yellow SIR connector located behind instrument panel support. (Scheme 45)
5. Zone 7 To disable inflatable restraint Sensing and Diagnostic Module (SDM), inflatable restraint seat belt pretensioner and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 7, disable Zones 3 and 5. Remove CPA clip from right seat belt pretensioner Yellow 2-pin connector located under passenger seat. (Scheme 46) Disconnect right seat belt pretensioner Yellow 2-pin connector. Remove CPA clip from left seat belt pretensioner Yellow 2-pin connector located under driver seat. Disconnect left seat belt pretensioner Yellow 2-pin connector.
6. Zone 9 To disable inflatable restraint seat belt pretensioner and inflatable restraint Seat Position Switch (SPS) located in SIR Zone 9, remove CPA clip from right seat belt pretensioner Yellow 2-pin connector located under passenger seat. Disconnect right seat belt pretensioner Yellow 2-pin connector.

Activating System (Chevy Express & Savana)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Scheme 44

Scheme 45

Scheme 46

Disabling System (Corvette)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key. Remove SDM fuse (No. 16) from interior fuse block under front floor kick-up panel (passenger side). Wait one minute.
2. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, carefully pry instrument panel courtesy light from left lower closeout panel. Remove push-on retaining nut from steering column bracket stud. Release left lower closeout panel push-in retainers from instrument panel lower support beam. Insert courtesy light up through closeout panel opening. Lower and remove closeout panel. Release notch in right forward edge of closeout panel from tab on accelerator pedal bracket. Remove left sound insulator. Remove CPA clip from driver air bag module coil connector located at base of steering column. (Scheme 47) Disconnect steering wheel module coil connector located at base of steering column.
3. Zone 4 To disable Sensing and Diagnostic Module (SDM) located in SIR Zone 4, remove left sound insulator. Remove CPA clip from inflatable restraint steering wheel module coil connector located at base of steering column. Disconnect driver air bag module coil connector located at base of steering column. Remove CPA clip from passenger air bag module connector located near base of the steering column. Disconnect passenger air bag module connector.
4. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove left sound insulator. Remove CPA clip from passenger air bag module connector located at base of steering column. (Scheme 43) Disconnect passenger air bag module connector located at the base of the steering column.

Scheme 47

Activating System (Corvette)

Remove key from ignition switch. Ensure SDM fuse (No. 16) is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (DeVille)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove rear seat cushion. Locate rear fuse block under rear seat cushion. Remove SIR fuse from rear fuse block. Wait one minute.
2. Zone 1 To disable inflatable restraint front end sensor located in SIR Zone 1, open front hood. Locate front end sensor sometimes referred to as Electronic Frontal Sensor (EFS). (Scheme 48) Remove Connector Position Assurance (CPA) clip from the EFS connector. Remove EFS connector from EFS.
3. Zones 2 Or 6 To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove appropriate center pillar trim panel. Pull out on center pillar garnish molding to disengage retainer clips. Remove front and rear carpet retainer. Remove center pillar garnish molding. Remove appropriate side air bag sensor CPA clip from SIS. (Scheme 49) Remove SIS connector from SIS.
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove driver side sound insulator. Remove CPA clip and disconnect Yellow 2-pin SIR connector at base of steering column. (Scheme 50)
5. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove right sound insulator from bottom of instrument panel. Remove CPA clip from passenger air bag module Yellow connector located below instrument panel. see scheme 51 Disconnect passenger air bag module Yellow connector from vehicle harness Yellow connector.
6. Zones 7 Or 9 To disable seat side air bag module and seat belt pretensioner located in SIR Zone 7 (left) or Zone 9 (right), move front seats fully forward. Remove both CPA clips from appropriate side air bag module and pretensioner Yellow connector located under driver or passenger seat. (Scheme 51) Disconnect Yellow connector from appropriate side air bag module and pretensioner Yellow harness connector.
7. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3, 5, 7 and 9. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.
8. Zones 10 Or 12 To disable rear inflatable restraint side air bag module located in SIR Zone 10 (left) or Zone 12 (right), remove rear seat back. Remove CPA clip from rear side air bag module Yellow connector. Disconnect side air bag module Yellow connector from vehicle harness Yellow connector. (Scheme 52)

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Activating System (DeVille)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 6-10 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Impala & Monte Carlo)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to OFF position and remove key from ignition switch. Remove SDM fuse from fuse block at far left end of instrument panel. Fuse block is under access cover. Wait one minute.
2. Zone 1 To disable inflatable restraint Electronic Front End Sensor (EFS) located in SIR Zone 1, remove radiator upper air baffle and deflector. Remove Orange CPA clip from Yellow sensor harness connector. Disconnect sensor harness connector from sensor. (Scheme 53)
3. Zone 2 (Impala) To disable Side Impact Sensor (SIS) located in SIR Zone 2, remove front carpet retainer. Pull up carpet retaining leg of quarter lower trim panel. Pull center pillar lower trim panel out to disengage push-in retaining clips. Slide panel down, then out from under the upper trim panel. Remove seat belt from slot in center lower trim panel. Remove center lower trim panel from center pillar. Remove left SIS from center pillar. (Scheme 54) Remove CPA clip from SIS connector. Disconnect SIS connector from SIS.
4. Zone 2 (Monte Carlo) To disable left Side Impact Sensor (SIS) located in SIR Zone 2, remove left door trim panel. Remove water deflector as required. Remove inner energy absorber pad. Loosen the top clip from the outer energy absorber pad and pull the pad away from outer door panel. Remove sensor fasteners. Remove left side air bag sensor from mounting bracket on door air bag beam. (Scheme 55) Remove CPA clip from SIS connector. Disconnect SIS connector from SIS.
5. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove left insulator panel. Remove CPA clip from driver air bag Yellow connector located at base of steering column. (Scheme 42) Disconnect driver air bag Yellow air bag connector.
6. Zone 5 To disable passenger air bag module, located in SIR Zone 5, remove access hole cover from far right end of instrument panel. Unclip passenger air bag Yellow connector from metal rail. Remove Connector Position Assurance (CPA) clip and disconnect passenger air bag Yellow air bag connector.
7. Zone 7 To disable driver seat left side air bag module located in SIR Zone 7, move driver seat as far forward as possible. Remove CPA clip from side air bag module connector located under the driver seat. Disconnect side air bag module connector.
8. Zone 9 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 3, 5 and 7. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 53

Scheme 54

Scheme 55

Activating System (Impala & Monte Carlo)

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Montana, Silhouette & Venture)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn steering wheel to place wheels in straight-ahead position. Remove key from ignition switch. Remove SDM (air bag) fuse from instrument panel fuse block. Fuse block is at far right end of instrument panel. Wait at least one minute.
2. Zone 1 To disable Electronic Front End Sensors (EFS) located in SIR Zone 1, remove CPA clips from both electronic front end sensor connectors. Disconnect both EFS connectors from EFS. (Scheme 36)
3. Zones 2 Or 6 To disable Side Impact Sensors (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove seat belt retractor and center pillar trim cover. Loosen side air bag sensor fasteners. (Scheme 56) Remove side air bag sensor from center pillar. Remove CPA clip from side air bag sensor Yellow 2-pin harness connector. Disconnect side air bag sensor wiring harness connector.
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove left side sound insulator from under steering column. Remove CPA clip from driver air bag module Yellow 2-pin connector. Disconnect Yellow 2-pin connector located at base of steering column. (Scheme 57)
5. Zone 5 To disable passenger air bag Module located in SIR Zone 5, remove sound insulator panel from under right side of dash. Remove CPA clip from passenger air bag module connector located behind right side insulator panel. Disconnect passenger air bag 2-pin Yellow SIR connector. (Scheme 58)
6. Zone 7 To disable inflatable restraint side air bag module and seat belt pretensioner located in SIR Zone 7, move driver seat fully forward. Locate driver seat side air bag and seat belt pretensioner Yellow 2-pin connectors, located under driver's seat. Remove CPA clip and disconnect both connectors. (Scheme 59)
7. Zone 9 To disable inflatable restraint side air bag module, seat belt pretensioner, and Sensing and Diagnostic Module (SDM) located in SIR Zone 9, remove left insulator panel. Remove CPA clips from driver air bag module coil connector located at the base of steering column. Disconnect driver air bag module coil connector. Remove right insulator panel. Remove CPA clips from passenger air bag module connector located behind right insulator panel. Disconnect passenger air bag module connector. Remove CPA clips from left and right side air bag modules located under driver and passenger seats. Disconnect side air bag module connectors. Remove CPA clips from left and right seat belt pretensioner connectors located under driver and passenger seats. Disconnect seat belt pretensioner connectors.

Scheme 56

Identifying Driver Air Bag Yellow 2-Pin Connector (Montana, Silhouette & Venture). Scheme 57

Identifying Passenger Air Bag Yellow 2-Pin Connector (Aztek, Montana, Rendezvous, Silhouette & Venture). Scheme 58

Locating Side Impact & Seat Belt Pretensioner Yellow 2-Pin Connectors (Montana, Silhouette & Venture). Scheme 59

Activating System (Montana, Silhouette & Venture)

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Saturn, ION)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition off and remove key. Locate and remove AIR BAG fuse from Body Control Module (BCM) fuse center located under center of instrument panel. Wait one minute.
2. Zone 2 Or 6 (Coupe) To disable inflatable restraint roof rail module and seat belt pretensioner located in Zone 2 (left) or Zone 6 (right), using a small, flat-bladed tool, pry off upper lock pillar garnish molding screw covers. Remove screws from upper lock pillar garnish molding. Remove rear defroster harness to prevent damage. Pull at clip locations to disengage garnish molding and remove upper garnish molding. Carefully disengage lower tabs from lower garnish molding on lock pillar and remove garnish molding from upper lock pillar. Remove Connector Position Assurance (CPA) clip from roof rail module connector and disconnect module connector from vehicle harness connector. (Scheme 60) Lower headliner to access left front seat belt pretensioner connector. Remove CPA clip from seat belt pretensioner connector and disconnect pretensioner connector. (Scheme 61)
3. Zone 2 Or 6 (Sedan) To disable inflatable restraint roof rail module and seat belt pretensioner located in Zone 2 (left) or Zone 6 (right), remove lower center pillar trim. Remove CPA clip from front seat belt pretensioner connector and disconnect seat belt pretensioner connector from vehicle harness connector. (Scheme 62) Remove garnish molding from upper lock pillar. Remove CPA clip from roof rail module connector and disconnect roof rail module connector from vehicle harness connector. (Scheme 60)
4. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove driver side outer trim cover from instrument panel. (Scheme 63) Remove CPA clip from driver air bag module coil connector and disconnect module connector from vehicle harness connector.
5. Zone 5 To disable passenger air bag module SIR Zone 5, remove passenger side outer trim cover from instrument panel. Remove CPA clip from passenger air bag module connector and disconnect module connector from vehicle harness connector. (Scheme 64)
6. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 2, 3, 5 and 6. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Activating System (Saturn, ION)

Remove key from ignition switch. Ensure AIR BAG fuse is still removed from Body Control Module (BCM) fuse center. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install AIR BAG fuse in Body Control Module (BCM) fuse center. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times when ignition is turned on. To complete installation, reverse removal procedures.

Disabling System (Saturn, L Series)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition off and remove key. Remove AIR BAG fuse from Body Control Module (BCM) fuse center located under right side of instrument panel, attached to BCM. Wait one minute.
2. Zone 2 Or 6 To disable inflatable restraint roof rail module located in SIR Zone 2 (left) or Zone 6 (right), using a small, flat-bladed tool, pry off upper lock pillar garnish molding screw covers. Remove garnish molding from upper lock pillar. (Scheme 65) Remove fastener and shoulder belt. Fold down rear seat back. Remove CPA clip from roof rail module connector and disconnect module connector from vehicle harness connector. (Scheme 60)
3. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove lower left instrument panel closeout panel. Push out clips that secure Yellow 2-pin air bag connectors to instrument panel brace. (Scheme 66) Remove Connector Position Assurance (CPA) clips. Disconnect both Yellow 2-pin connectors.
4. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove lower left instrument panel closeout panel. Push out clips that secure Yellow 2-pin air bag connectors to instrument panel brace. (Scheme 66) Remove Connector Position Assurance (CPA) clips. Disconnect both Yellow 2-pin connectors.
5. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 2, 3, 5 and 6. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 65

Scheme 66

Activating System (Saturn, L Series)

1. Ensure wheels are in straight ahead position. Turn ignition off and remove key. Ensure AIR BAG fuse is still removed from Body Control Module (BCM) fuse center.
2. Connect left and right side curtain air bag Yellow 2-pin air bag connectors. Install CPA clips. Install "C" pillar trim panels. Coat "C" pillar shoulder belt fastener with Loctite 242 or equivalent. Tighten shoulder belt fastener to 26 ft. lbs. (35 N.m).
3. Remove key from ignition switch. Ensure AIR BAG fuse is still removed from Body Control Module (BCM) fuse center. Install AIR BAG fuse in BCM fuse center. Staying well away from both front air bag inflator modules, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Saturn VUE)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition off and remove key. Locate and remove the AIR BAG fuse from the Body Control Module (BCM) fuse center located under center of instrument panel. Wait one minute.
2. Zones 2 Or 6 To disable inflatable restraint roof rail module located in SIR Zone 2 (left) or Zone 6 (right), remove "D" pillar upper trim panel rear window molding. (Scheme 67) Remove both the left and right rear corner garnish moldings. (Scheme 68) Remove the rear headliner push-in retainers. Using a small flat-bladed tool, partially remove right and left coat hook center retainers, then pull on coat hooks to remove them from headliner. (Scheme 69) Carefully pull back on headliner to gain access to right and left roof rail side air bag module Yellow 2-pin connectors. Remove CPA clips from both connectors. Disconnect left and right side air bag curtain Yellow 2-pin connectors. (Scheme 70)
3. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove CPA clip from driver air bag Yellow 2-pin connector. Connector is clipped to steering column brace. (Scheme 71) Disconnect Yellow 2-pin connector.
4. Zone 5 To disable passenger air bag module located in SIR Zone 5, detach clip holding passenger air bag Yellow 2-pin connector to metal brace. Brace is near blower motor housing. (Scheme 72) Remove CPA clip and disconnect passenger air bag Yellow 2-pin connector.
5. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zone 2, 3, 5 and 6. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Activating System (Saturn VUE)

Remove key from ignition switch. Ensure AIR BAG fuse is still removed from Body Control Module (BCM) fuse center. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install AIR BAG fuse in Body Control Module (BCM) fuse center. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times when ignition is turned on. To complete installation, reverse removal procedures.

Disabling System (Seville)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position and remove key from ignition switch. Remove rear seat cushion. Locate rear fuse block under rear seat cushion. Remove SIR fuse from rear fuse block. Wait one minute.
2. Zones 2 Or 6 To disable inflatable restraint Side Impact Sensor (SIS) located in SIR Zone 2 (left) or Zone 6 (right), remove appropriate center pillar trim panel. Pull out on center pillar garnish molding to disengage retainer clips. Remove front and rear carpet retainer. Remove center pillar garnish molding. Remove appropriate side air bag sensor CPA clip from SIS. (Scheme 49) Remove SIS connector from SIS.
3. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove driver side sound insulator. Remove CPA clip and disconnect Yellow 2-pin SIR connector at base of steering column. (Scheme 50)
4. Zone 5 To disable passenger air bag module located in SIR Zone 5, remove right sound insulator from bottom of instrument panel. Remove CPA clip from passenger air bag module Yellow connector located below instrument panel. see scheme 51 Disconnect passenger air bag module Yellow connector from vehicle harness Yellow connector.
5. Zone 7 To disable seat side air bag module and seat belt pretensioner located in SIR Zone 7, move driver seat fully forward. Working under driver seat, remove both CPA clips from driver side air bag module and pretensioner Yellow connector. (Scheme 51) Disconnect Yellow connector from driver side air bag module and pretensioner Yellow connector. Disconnect Yellow connector from vehicle harness.
6. Zone 9 To disable passenger side air bag module and pretensioner located in SIR Zone 9, move passenger seat fully forward. Working under passenger seat, remove both CPA clips from passenger side air bag module and pretensioner Yellow connector. (Scheme 51) Disconnect Yellow connector from passenger side air bag module and pretensioner Yellow connector. Disconnect Yellow connector from vehicle harness.
7. Zone 9 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 9, disable Zones 2, 3, 5, 6, 7 and passenger side air bag module and pretensioner located in SIR Zone 9. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Activating System (Seville)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 6-10 times, and then turns off. To complete installation, reverse removal procedures.

Disabling System (Tracker)

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures). Ensure front wheels are in straight-ahead position. Remove key. Remove AIR BAG fuse from in-line fuse holder located near base of steering column. (Scheme 73)
2. Zone 3 To disable driver air bag module and coil located in SIR Zone 3, remove steering column opening trim plate. Remove Connector Position Assurance (CPA) clip, release lock tab, and disconnect driver air bag Yellow 2-pin connector. (Scheme 73)
3. Zone 5 To disable passenger air bag module located in SIR Zone 5, open glove box. Push inward on left and right-side stoppers and rotate glove box downward. Remove CPA clip, and disconnect Yellow 2-pin passenger-side air bag connector. (Scheme 74)
4. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3 and 5. Remove CPA clip from components Yellow connector. Disconnect components Yellow connector from vehicle harness Yellow connectors.

Scheme 73

Scheme 74

Activating System (Tracker)

Remove key from ignition switch. Ensure SDM fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. To complete installation, reverse removal procedures.

Grand Cherokee, Liberty & Wrangler

1. Connect DRB-III scan tool, or equivalent, to Data Link Connector (DLC). DLC is located under left side of instrument panel, near steering column. Use latest version of DRB-III scan tool cartridge.
2. Turn ignition switch to RUN or ON position, with engine off. Exit vehicle with DRB-III scan tool. Ensure no one is inside vehicle.
3. Using DRB-III scan tool, read and record any active or stored Diagnostic Trouble Codes (DTCs). If DTCs are not active, erase all stored DTCs. If an active SRS problem exists, DTCs will not erase.
4. With ignition still on, check that nobody is in the vehicle. From outside of the vehicle, and away from air bags, turn ignition off for about 15 seconds, then back to the RUN or ON position.
5. Observe AIR BAG warning light. AIR BAG warning light should come on for about 6-8 seconds, then go out, indicating system is functioning properly. If AIR BAG warning light either fails to come on, blinks on and off, or comes on and stays on, a system malfunction exists. Diagnose and repair air bag system as necessary.

The following precautions should be observed when working with air bag systems

1. Disable air bag system before servicing any air bag system or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
2. Wait at least 2 minutes after disconnecting negative battery cable before servicing air bag system. Servicing air bag system before 2-minute period may cause accidental air bag deployment and possible personal injury.
3. DO NOT use any electrical test equipment on or near SRS components unless specified to do so. DO NOT use an analog ohmmeter. Use a DVOM with a maximum test current of 2 milliamps or less, at minimum resistance measurement range.
4. After deployment, air bag surface may contain sodium hydroxide deposits, which may irritate skin. Sodium hydroxide is a product of gas generant combustion. Always wear safety glasses, rubber gloves and a long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
5. Because of critical system operating requirements, DO NOT try to service any air bag components. Manufacturer recommends that defective components should always be replaced with only original equipment parts.
6. Deployed front air bags have 2 initiators (squibs) in the air bag inflator and may or may not have live pyrotechnic material within the inflator. DO NOT dispose of these air bags unless you are sure of complete deployment.
7. Factory installed fasteners have a special coating and are specifically designed for air bag components. Manufacturer recommends using original equipment replacement fasteners. DO NOT use substitutes.
8. Clockspring must be replaced if driver's air bag is deployed.
9. Each time a connector is disconnected, ensure it is clean and not damaged. Always pay particular attention to circuit being tested. Dirt, water and corrosion are the most common problems in connectors, causing voltage drop, open circuits and other improper operations.
10. When performing electrical tests, prevent accidental shorting of terminals. Such shorts can damage fuses or components and may cause a second fault code to set, making diagnosis of original problem more difficult.
11. After repairs are complete and ignition is turned to RUN or ON position, stay clear of air bag(s) to avoid injury in case of accidental air bag deployment.
12. When handling a seat belt tensioner retractor, proper care should be exercised to keep fingers out from under the retractor cover and away from seat belt webbing where it exits from the retractor cover.
13. Ensure air bag warning light is operating properly and system faults are not indicated. See «SYSTEM OPERATION CHECK»(/buick/century/vi-1997-2005/remont/airbag/#supplemental-inflatable-restraint-system-deactivation-procedures) .
14. When placing a undeployed (live) air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed.
15. When carrying a undeployed (live) air bag module, point trim cover away from your body to minimize injury in case of accidental deployment.
16. Air bag module must be stored in its original special container until used for service. It must be stored in a clean, dry place, away from sources of extreme heat, sparks and electrical energy.
17. The Air Bag Control Module (ACM) contains an air bag sensor which enables SRS to deploy air bags. DO NOT connect ACM connector while battery is connected. Ensure ACM and mounting bracket are securely installed to vehicle before connecting electrical connector.
18. On vehicles equipped with side air bags or side curtain air bags, use caution when working around "B" pillar and/or side air bags.
19. Use extreme care to prevent any foreign material from entering air bag, or becoming entrapped between air bag cushion and air bag trim cover.
20. Never paint air bag trim covers or use a replacement trim cover not recommended by the manufacturer. Paint may change the way trim covers respond to an air bag deployment.
21. Electrical sources should never be allowed near connector on back of air bag module.
22. Passenger air bag module contains an Argon gas canister. Canister is pressurized to more than 2500 psi. DO NOT puncture, incinerate, or bring into contact with electricity. DO NOT store at temperatures above 200°F (93°C).
23. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and functions properly. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally.

Disabling System

Ensure ignition switch is in OFF or LOCK position. Disconnect and shield negative battery cable at battery. After disconnecting negative battery cable, wait at least 2 minutes for reserve capacitor to discharge before servicing air bag system.

Activating System

Ensure ignition switch is in OFF or LOCK position. Connect negative battery cable. From a position clear of air bag(s), turn ignition switch to RUN or ON position. Observe SRS/AIR BAG warning light. Warning light should come on for 6-8 seconds and then go out, indicating system is functioning properly. If warning light fails to illuminate, or illuminates and stays on, a system malfunction exists. See SYSTEM OPERATION CHECK .

See also:
• DISABLING & ACTIVATING AIR BAG SYSTEM
• SYSTEM OPERATION CHECK
• DISABLING & ACTIVATING AIR BAG SYSTEM
• DRIVER AIR BAG MODULE
• AIR BAG SIMULATOR
• PASSENGER AIR BAG MODULE
• SYSTEM OPERATION CHECK
• AIR BAG MODULE TORQUE SPECIFICATIONS (FORD)
• DISABLING SYSTEM
• DISABLING SYSTEM
