11 00 670 Securing engine in installation position (N54, N54T)
| WARNING | Danger of injury! Observe following instructions relating to special tool |
- Prior to each use, check the special tools for defects, modifications and operational reliability.
- Damaged/modified special tools must not be used!
- No changes or modifications may be made to the special tools!
- Keep special tools dry, clean and free of grease.
Necessary preliminary tasks
- Secure «ENGINE HOOD/BONNET»(ref-381258-S39331041492010122800000)
- Remove rear «AIR DUCT»(ref-381015-S00169098762010122700000)
Assemble transverse member 00 6 000 with special tools 00 6 030.
Scheme 87
Screw in towing hook (1).
Scheme 88
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
The support points on the left side are shown.
| IMPORTANT | Risk of damage! Position transverse member 00 6 030 with a 2nd person help on designated areas (1, 2) of side panel. |
Scheme 89
Secure special tool 11 0 020 to spindle 00 6 002.
Fit suitable chains to special tool 11 0 020 and attach to engine towing hook or lifting eye.
Scheme 90
| WARNING | Danger of injury! Tighten down all adjusting screws and nuts on transverse member 00 6 000. |
Unscrew nuts (1).
Raise engine approx. 10 mm with transverse member.
Installation note
Replace self-locking nuts.
Tightening torque 22 11 2AZ .
11 65 022 Removing and installing/replace exhaust turbocharger for cylinders 1-3 (N54, N54T)
| IMPORTANT | It is not necessary to carry out a chassis/wheel alignment check to release the steering tie rod. |
Necessary preliminary tasks
- Remove both catalytic converters. See «1832050 REMOVING AND INSTALLING/REPLACING CATALYTIC EXHAUST-GAS CONVERTER FOR CYLINDERS 1-3 (N54)»(ref-381017-S18362545612010122700000) or «1832060 REMOVING AND INSTALLING/REPLACING CATALYTIC EXHAUST-GAS CONVERTER FOR CYLINDERS 4-6 (N54)»(ref-381017-S21484823452010122700000)
- Release right «TIE ROD»(ref-381208-S06057946972010122800000) from steering gear
- Drain «COOLANT»(ref-381016-S34662473152010122700000)
- Remove coolant «EXPANSION TANK»(ref-381016-S36533312862010122700000)
- Remove «COOLANT THERMOSTAT»(ref-381014-S31367684012010122700000)
- Remove «COOLANT PUMP»(ref-381014-S04198044612010122700000)
- Remove both vacuum accumulators with bracket
- Remove right «CHARGE-AIR DUCT»(ref-381014-S42154230912010122700000)
- Drain «ENGINE OIL»(ref-381014-S31549461862010122700000) and collect in a clean container, oil is reused
Release screws (1) and remove protective plate (2) above tie rod.
Scheme 91
Release screws (1).
Tightening torque 11 42 7AZ .
Installation note
Replace gasket.
Release screw (2).
Tightening torque 11 42 8AZ .
Remove oil return pipe in direction of arrow.
Installation note
Replace O-ring.
Undo screws (1 and 2)
Tightening torque 11 53 10AZ .
Release coolant feed lines (3 and 4) if necessary with suitable pliers.
| IMPORTANT | Do not place pliers on pipes. Risk of damage! |
Scheme 92
Release screws (1).
Tightening torque 11 53 3AZ .
Remove feed line (2).
Installation note
Replace O-ring.
Scheme 93
Release screw (1).
Tightening torque 11 53 8AZ .
Release coolant return pipe at connection (2) if necessary with suitable pliers.
Release screw (3).
Tightening torque 11 53 9AZ .
Release coolant return pipe at connection (4) if necessary with suitable pliers.
Unfasten coolant return pipe.
Scheme 94
| IMPORTANT | Do not place pliers on pipes. Risk of damage! |
Release screws (1).
Tightening torque 11 65 2AZ .
Remove retaining plate (2).
Release screws (3).
Tightening torque 11 65 2AZ .
Scheme 95
Remove heat shield (1) in direction of arrow.
Note. Carefully swing out heat shield (1) in direction of arrow. Risk of damage! Coolant feed pipe can be removed with heat shield (1).
Scheme 96
Release screws (1).
Tightening torque 11 65 3AZ .
Set holder (2) down on cylinder head cover.
Scheme 97
Release screw (1).
Tightening torque 11 42 4AZ .
Detach oil feed line in direction of arrow.
Installation note
Replace O-ring.
Scheme 98
Release screw (1).
Tightening torque 11 42 5AZ .
Release oil pressure line (2) if necessary with suitable pliers.
| IMPORTANT | Do not place pliers on pipes. Risk of damage! |
Installation note
Replace O-rings.
Scheme 99
Detach vacuum hose from vacuum unit (wastegate valve).
Unscrew nuts (1).
Tightening torque 11 65 1AZ .
Remove turbocharger towards top.
| IMPORTANT | Do not misuse linkage of vacuum unit (wastegate valve) for transportation. Risk of damage! |
Scheme 100
Release screw (2).
Tightening torque 11 42 5AZ .
| IMPORTANT | Where necessary, to release the oil feed line (3), do not place pliers on the pipe. Risk of damage! |
If necessary, release oil feed line (3) with suitable pliers at connection and remove.
Installation note
Replace O-rings.
Installation note
Replace graphite sealing rings (1).
Note. Picture shows turbocharger for cylinders 4 to 6.
Assemble engine.
Delete fault memory in Digital Engine Electronics.
Check air intake system for leaks.
Observe DME instructions.
11 65 024 Removing and installing/replace exhaust turbocharger for cylinders 4-6 (N54, N54T)
Necessary preliminary tasks
- Remove both catalytic converters. See «1832050 REMOVING AND INSTALLING/REPLACING CATALYTIC EXHAUST-GAS CONVERTER FOR CYLINDERS 1-3 (N54)»(ref-381017-S18362545612010122700000) or «1832060 REMOVING AND INSTALLING/REPLACING CATALYTIC EXHAUST-GAS CONVERTER FOR CYLINDERS 4-6 (N54)»(ref-381017-S21484823452010122700000)
- Drain «COOLANT»(ref-381016-S34662473152010122700000)
- Remove coolant «EXPANSION TANK»(ref-381016-S36533312862010122700000)
- Remove both vacuum reservoirs
- Remove right «CHARGE AIR DUCT»(ref-381014-S42154230912010122700000)
- Drain «ENGINE OIL»(ref-381014-S31549461862010122700000) and collect in a clean container, oil is reused
- Remove «RIGHT ENGINE SUPPORT ARM»(ref-381021-S36248333442010122700000)
Release screws (1).
Tightening torque 11 42 7AZ .
Installation note
Replace gasket.
Release screw (2).
Tightening torque 11 42 8AZ .
Remove oil return pipe in direction of arrow.
Installation note
Replace O-ring.
Release screws (1 and 2).
Tightening torque 11 53 10AZ .
Release coolant feed lines (3 and 4) if necessary with suitable pliers.
| IMPORTANT | Do not place pliers on pipes. Risk of damage! |
Installation note
Replace O-rings.
Release screws (1).
Tightening torque 11 53 3AZ .
Remove feed line (2).
Installation note
Replace O-ring.
Release snap ring (1) from linkage of wastegate valve and disengage linkage.
Release screw (5).
Tightening torque 11 53 9AZ .
Release coolant return pipe if necessary with suitable pliers.
Release screw (4).
Tightening torque 11 53 8AZ .
Release coolant feed pipe (2) if necessary with suitable pliers.
Release coolant return pipe (3) if necessary with suitable pliers and remove.
Scheme 101
Installation note
Replace O-rings.
| IMPORTANT | Do not place pliers on pipes. Risk of damage! |
Release screws (1).
Tightening torque 11 65 2AZ .
Remove retaining plate (2).
Unfasten screws (3 and 4).
Tightening torque 11 65 2AZ .
Scheme 102
| IMPORTANT | Carefully swing out heat shields (2 and 3) in direction of arrow. Risk of damage! |
Remove heat shield (3) in direction of arrow.
Remove heat shield (2) in direction of arrow.
Note. Coolant feed pipe (1) can be removed with heat shield (2).
Scheme 103
Release screw (1).
Tightening torque 11 42 4AZ .
Detach oil feed line in direction of arrow.
Installation note
Replace O-ring.
Release screws (1).
Tightening torque 11 65 3AZ .
Set holder (2) down on cylinder head cover.
Picture shows E9x.
Detach vacuum hose from vacuum unit (wastegate valve).
Unscrew nuts (1).
Remove turbocharger towards bottom.
Tightening torque 11 65 1AZ .
| IMPORTANT | Do not misuse linkage of vacuum unit (wastegate valve) for transportation. Risk of damage! |
Picture shows E9x.
Scheme 104
Release screw (2).
Tightening torque 11 42 5AZ .
| IMPORTANT | Where necessary, to release the oil feed line (3), do not place pliers on the pipe. Risk of damage! |
If necessary, release oil feed line (3) with suitable pliers at connection and remove.
Installation note
Replace O-rings.
Installation note
Replace graphite sealing rings (1).
Assemble engine.
Delete fault memory in Digital Engine Electronics.
Check air intake system for leaks.
Observe DME instructions.
