Engine Electrical System - Special Tools (n54)

Engine Electrical System - Special Tools (n54) BMW Z4 E89

Adapter MW

Note. (plug adapter for CNG wiring harness) For reducing the gas pressure in the CNG system

Storage Location

W 2..

SI number

01 14 95 (014)

Scheme 1

Scheme 1: SI number

Note. (Electronic engine power control adapter) For checking of electronic engine power control safety circuit with 20-pin engine connector

Scheme 2

Scheme 2: Adapter MW

Note. (Test adapter, 56-pin) For checking the engine wiring harness on compressed natural gas vehicles

W 2..

01 14 95 (014)

Scheme 3

Scheme 3: SI number

Adapter MP

Note. (Adapter kit) For 134-pin module connector For diagnosis and troubleshooting in Digital Motor Electronics and transmission control unit - from model year 98

02 04 97 (248)

Consisting of

2 = 0491135 Adapter cable

Note. (Adapter cable) 9-pin

2 = 0491136 Measuring module

Note. (Measuring module) 24-pin

Scheme 4

Scheme 4: SI number

2 = 0491137 Measuring module

Note. (Measuring module) 40-pin

2 = 0491138 Measuring module

Note. (Measuring module) 52-pin Delivered from 08/2004 in combination with 12 1 305 (zero-encoded protective cap for new SGM control unit in E6x).

4 = 0495069 Cap

Note. (Zero-encoded protective cap for test box, 52-pin (12 1300/304)) New connector in E61/E61/E63 and E64 on SGM control unit protective cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 protective cap will be supplied with test box.

Adapter cable MW

Note. (Adapter cable, 25-pin) Encoding A

Note. (Adapter cable 25-pin) For checking/encoding B of electronic engine power control safety circuit - model series: E31/engine: M70

Antistatic mat MW

Note. (Antistatic mat) ESD (Electronic Static Discharge) = electrostatic discharge For protection against ESD during repairs to electronic components. (Replaces the subnumber 12 7 192 from Eprom tool kit 12 7 190)

02 06 04 (128)

Scheme 5

Scheme 5: SI number

Counterholder wrench

In conjunction with: Socket

Note. Alternator N42 engine

Fitting aid MW

Note. Fitting aid for spark plug installation. Original BERU ZMH 001 rubber hose 0 890 00 001.

01 04 07 (352)

Scheme 6

Scheme 6: SI number

Socket Minimum set: Mechanical tools MW

Note. For removing and installing the spark plugs (WAF 14 bihexal).

01 04 06 (246)

Scheme 7

Scheme 7: SI number

Socket

In conjunction with: Counterholder wrench

Note. Hazet 8808 lg 10

1 28 03 (051)

Zero-coded cover cap for 52-pin test box (12 1300/304)

Note. New plugs in E61/E61/E63 and E64 on SGM control unit Cover cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 cover cap will be supplied with test box.

2 07 04 (138)
