Engine Electrical System - Special Tools (n52)

Engine Electrical System - Special Tools (n52) BMW Z4 E89

Adapter MW

Note. (plug adapter for CNG wiring harness) For reducing the gas pressure in the CNG system

Storage Location

W 2..

SI number

01 14 95 (014)

Scheme 85

Scheme 85: SI number

Note. (Electronic engine power control adapter) For checking of electronic engine power control safety circuit with 20-pin engine connector

Scheme 86

Scheme 86: Adapter MW

Note. (Test adapter, 56-pin) For checking the engine wiring harness on compressed natural gas vehicles

W 2..

01 14 95 (014)

Scheme 87

Scheme 87: SI number

Adapter MP

Note. (Adapter kit) For 134-pin module connector For diagnosis and troubleshooting in Digital Motor Electronics and transmission control unit - from model year 98

02 04 97 (248)

Consisting of

2 = 0491135 Adapter cable

Note. (Adapter cable) 9-pin

2 = 0491136 Measuring module

Note. (Measuring module) 24-pin

2 = 0491137 Measuring module

Note. (Measuring module) 40-pin

Scheme 88

Scheme 88: SI number

2 = 0491138 Measuring module

Note. (Measuring module) 52-pin Delivered from 08/2004 in combination with 12 1 305 (zero-encoded protective cap for new SGM control unit in E6x).

4 = 0495069 Cap

Note. (Zero-encoded protective cap for test box, 52-pin (12 1300/304)) New connector in E61/E61/E63 and E64 on SGM control unit protective cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 protective cap will be supplied with test box.

Adapter cable MW

Note. (Adapter cable, 25-pin) Encoding A

Note. (Adapter cable 25-pin) For checking/encoding B of electronic engine power control safety circuit - model series: E31/engine: M70

Adapter cable Minimum set: Measuring and testing equipment MP

Note. For engines with rod-type ignition coils for measuring secondary voltage

F 104

02 01 01 (671)

Scheme 89

Scheme 89: SI number

Note. (V adapter cable set 58-pin) For diagnosis and troubleshooting at control unit DDE 5.0 04/04 Coding with special pliers (002250) removed - for N46, N52 and S85 engine. Set 12 7 420 consisting of 12 7 421 adapter cable and 12 7 422 cover plate 05/2004 set modification SI 2 03 04 (106)

Q204

Scheme 90

Scheme 90: Storage Location

02 05 01 (479)

Consisting of

1 = 0494963 Adapter cable

Note. (Adapter cable 58-pin)

2 = 0494964 Plate

Note. (Cover plate for test box) For pin allocation on 105-pin test box (61 4 380)

Antistatic mat MW

Note. (Antistatic mat) ESD (Electronic Static Discharge) = electrostatic discharge For protection against ESD during repairs to electronic components. (Replaces the subnumber 12 7 192 from EPROM tool kit 12 7 190)

02 06 04 (128)

Scheme 91

Scheme 91: SI number

Counterholder wrench

In conjunction with: Socket

Note. Alternator N42 engine

Socket

In conjunction with: Counterholder wrench

Note. Hazet 8808 lg10

1 28 03 (051)

Socket wrench insert Minimum set: Mechanical tools MW

Note. (Socket wrench insert WAF 24) For removing and installing the belt pulley on the alternator

A12

01 12 93 (701)

Scheme 92

Scheme 92: SI number

Torque limiter Minimum set: Mechanical tools MW

Note. (torque limiter) 30 Nm For tightening the spark plugs to a limited torque setting

01 05 92 (507)

Scheme 93

Scheme 93: SI number

Zero-coded cover cap for 52-pin test box (12 1300/304)

Note. New plugs in E61/E61/E63 and E64 on SGM control unit Cover cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 cover cap will be supplied with test box.

2 07 04 (138)
