17 00 009 Checking cooling system for leaks (N54, N52K)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Protective measures/rules of conduct
- Wear protective goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00 2 030 (universal hydraulic lifter).
Recycling
Observe country-specific waste-disposal regulations.
Scheme 66
Checking pressure drop in cooling system
Open cap on coolant expansion tank. Fit special tools (1) 17 0 101 and (2) 17 0 113.
Build up GAUGE PRESSURE and wait approx. 2 minutes.
Cooling system is impervious to leaks if pressure drop is max. 0.1 bar.
Scheme 67
Checking pressure relief valve in cap
Note. While the vehicle is driven at high outside temperatures, the design may cause the pressure relief valve in the cap to open slightly and air together with dissolved coolant to escape. This coolant vapor condenses on the surface of the expansion tank and leaves traces when the vehicle has cooled down. These traces do not indicate whether the cap is defective or not. When the vehicle has been parked up for an extended period of time, the residual escaping coolant can cause the pressure relief valve in the cap to stick; therefore check the cap again 2 to 3 times.
Replace the cap only after you have checked three times and there is an incorrect opening pressure.
Screw cap (1) onto special tool 17 0 114.
Build up pressure with special tool (hand pump) 17 0 101; observe pressure gauge to ascertain when opening pressure is achieved.
Compare OPENING PRESSURE of pressure relief valve.
Scheme 68
17 00 515 Checking function of radiator and heating system
| WARNING | Danger of scalding! Only carry out work on cooling system after engine has cooled down. |
Necessary preliminary tasks
- Switch off ignition.
- Remove air duct.
- Remove fan cowl with electronic fan.
Check production date.
Scheme 69
Clamp off low-temperature feed lines with special tool 13 3 010.
Function test
Observe diagnosis instructions.
Scheme 70
Check function of radiator.
Clamp off low-temperature feed line (1) at coolant pump outlet or radiator inlet with special tool 13 3 010 (see arrows).
Scheme 71
Automatic transmission only
Check function of heat exchanger.
Clamp off low-temperature feed line (1) at coolant pump outlet with special tool 13 3 010.
Clamp off low-temperature feed line (2) at oil-coolant heat exchanger with special tool 13 3 010.
Scheme 72
Check heating and cooling circuits in accordance with diagnosis instruction.
17 00 008 Draining and adding coolant (N52K)
| WARNING | Danger of scalding! These tasks on the cooling system should only be carried out on an engine that has cooled down! |
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. |
In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant.
Installation
Use only recommended coolant.See COOLING SYSTEM - OPERATING FLUIDS .
Observe mixture ratio.
Protective measures/rules of conduct
- Wear safety goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | For dirt contamination of the cooling system (e.g. by engine oil), the cooling system must be rinsed with water until all dirt contamination is removed! |
| IMPORTANT | Risk of slipping due to coolant on the floor. Risk of injury! |
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00 2 030 (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste-disposal regulations.
Necessary preliminary tasks
- Remove front «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#front-axle-repair__51-47-490-removing-and-installingreplacing)
Draining coolant
Open cap (1) on coolant expansion tank.
Installation
Close cap (1) until the arrow marks line up.
Scheme 73
Unfasten and detach right coolant hose (1) from radiator.
Drain, catch and dispose of coolant.
Scheme 74
Adding coolant
Use recommended coolant COOLING SYSTEM - OPERATING FLUIDS .
Observe mixture ratio.
Observe FILLING CAPACITIES .
Fill and vent COOLING SYSTEM .
Observe venting instructions without fail.
Assemble engine.
Check COOLANT SYSTEM for leaks.
17 00... Instructions for working on cooling system
| WARNING | Danger of scalding! Work on the cooling system should only be carried out when the engine has cooled down. |
| IMPORTANT | Wear protective gloves and safety goggles. |
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant. When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. |
In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant.
| IMPORTANT | Open cooling system only when it has cooled down. Opening the cooling system while hot can result in air entering the system. This can cause overheating with permanent damage to the engine. |
| IMPORTANT | You must protect the alternator against contamination before carrying out any work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
| IMPORTANT | Do not fill coolant expansion tank over MAX level as overfilling will cause the coolant to overflow. This may give rise to traces of residual coolant on the expansion tank or in the engine compartment and wrongly suggest possible leakages. |
Recycling
Catch and dispose of drained coolant.
Observe country-specific waste-disposal regulations.
Note. To disconnect coolant hoses, use commercially available disconnect tools such as HAZET brand tools (see table).
| HAZET no. | Description |
|---|---|
| 4590-1 | Disconnect tool, length (mm): 150 |
| 4590-2 | Disconnect tool, length (mm): 180 |
| 4590-3 | Disconnect tool, length (mm): 253 |
| 4590/2 | Disconnect/plier set |
| 4590/3 | Disconnect/plier set |
COMMERCIALLY AVAILABLE DISCONNECT TOOL
Scheme 75
Note. Tightening torque, hose clamps 17 00 1AZ .
Scheme 76
Instructions for disassembly/assembly of coolant hose quick-connect couplings
Disassembly of quick-connect coupling
Pull out lock (1) and (2). Pull off hose.
Scheme 77
Installation
Check O-rings (1).
Do not coat O-rings (1) with antiseize agent.
Scheme 78
Assembly of quick-connect coupling
Press in lock (1) before installing fast-release coupling.
Push on hose.
Quick-connect coupling must clearly snap audibly into place.
Scheme 79
00 Safety information for working on vehicles with automatic engine start-stop function (MSA)
| WARNING | If the engine hood/bonnet contact is pulled upwards (workshop mode), the information "switch closed" is output. The automatic engine start-stop function is active. An automatic engine start is possible. |
Observe safety precautions when working on MSA vehicles
Before carrying out practical work on the engine, always ensure that the MSA functionality is deactivated so as to prevent automatic engine starting while work is being carried out in the engine compartment.
MSA function is deactivated by
- Deactivate MSA by means of button (1) in passenger compartment
- Open seat belt buckle and driver's door
Scheme 80
- Open engine bonnet/hood and ensure that engine hood/bonnet contact is not in workshop mode
- Workshop mode A = 10 mm
- Basic setting (engine hood/bonnet open) B = 7 mm
To make sure that the engine hood/bonnet contact is at the basic setting, if necessary press the hood/bonnet contact up to the limit position before starting work and slowly release.
Scheme 81
When working with diagnosis tools
- Observe instructions in diagnosis tool
17 00 039 Venting and filling cooling system with vacuum filling unit (Version 1)
| Type | Engine | Adapter Y from 17 0 100 |
|---|---|---|
| E60/E61/E63/E64 | All | 17 0 113 |
| E65/E66 | M54/N52/N62/N62T/N73 | 17 0 105 |
| E65/E66 | M57S/M57T/M67/M67T | 17 0 113 |
| E70/E71/E72 | All | 17 0 113 |
| E81/E82/E84/E87/E88/E89 | All | 17 0 113 |
| E83 | M54/N46/N52K | 17 0 105 |
| E83 | M47S/M57S/M57T/M57Y/N47 | 17 0 113 |
| E85/E86 | All | 17 0 105 |
| E90/E91/E92/E93 | All | 17 0 113 |
| F01/F02/F03/F04/F07/F10 | All | 17 0 113 |
| R50/R52 | W10 | 17 0 107 and 17 0 102 |
| R50 | W17 | 17 0 109 |
| R52/R53 | W11 | 17 0 109 |
| R55/R56/R57/R60 | All | 17 0 109 |
| F25 | All | 17 0 113 |
SPECIAL TOOLS REFERENCE CHART
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of part quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | You must protect the alternator against contamination by coolant when carrying out repair work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Note on ordering
- Workshop equipment
- Workshop equipment catalogue
- Filler unit no. 81 39 2 152 473
- Collecting vessel no. 81 49 2 152 347
- Adapter: 17 0 100
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of emerging coolant in drip tray (1) and if necessary special tool 00 2 030 (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste disposal regulations.
| IMPORTANT | Check all the coolant hoses before filling the cooling system with the vacuum filling unit. If necessary, replace damaged and porous coolant hoses. |
Scheme 82
- 1) Filling unit with vacuum meter and shut-off valves
- 2) Filler hose
- 3) Coolant container
- 4) Venturi nozzle
- 5) Compressed air connection (max. 6 bar)
- 6) Outgoing-air hose (lead outgoing-air hose into a collecting container)
Requirements
- Cooling system expansion tank must be empty.
- There must be sufficiently premixed coolant in the filling unit container, 1 - 2 liters more than the vehicle filling capacity. Use only recommended coolant «COOLING SYSTEM - OPERATING FLUIDS»(ref-265751) . Observe mixture ratio. Observe capacities.
- Position the filling unit container at the same height as the coolant expansion tank.
- Compressed-air connection with 6 bar pressure present.
- Set vehicle heater to maximum temperature.
Select adapter (Y) according to table and connect to coolant expansion tank.
Connect filler unit to adapter connection (X).
Scheme 83
Shut-off valves (A) and (B) of the filling unit (1) must be closed.
X) Expansion tank connection
Scheme 84
Connect venturi nozzle (1) to filling unit (2).
X) Expansion tank connection
Scheme 85
Connect compressed air (1).
X) Expansion tank connection
Scheme 86
Open shut-off valve (B).
The venturi nozzle produces a flow noise.
Scheme 87
Then open shut-off valve (A) until the filling hose (1) is free of bubbles.
Close shut-off valve (A) again. The filling hose (1) is vented in this way.
Scheme 88
Shut-off valve (B) remains open. Generate vacuum in coolant system for approx. 2 minutes. The final vacuum is reached at a vacuum of -0.7 to -0.95 bar. Green scale on the vacuum meter.
Note. The coolant hoses contract during vacuum build-up.
Then close shut-off valve (B) again.
Scheme 89
Both shut-off valves (A) and (B) must be closed. Then seal Venturi nozzle (1).
Scheme 90
The cooling system must hold the vacuum for 30 seconds. If the needle in the vacuum meter falls, this indicates a leak in the cooling system.
If the vacuum remains constant, proceed with filling.
In event of leaks, check cooling system for leaks.
Scheme 91
| IMPORTANT | There must be sufficiently premixed coolant in the filling unit container, 1 - -2 liters more than the vehicle filling capacity. |
Position the filling unit container at the same height as the coolant expansion tank.
Shut-off valve (B) remains closed during the filling process.
To fill the cooling system, open shut-off valve (A) to filling unit container.
Scheme 92
Coolant is now added.
The filling process is finished when the needle in the vacuum meter is at 0 bar or no longer falls.
If necessary, reduce remaining vacuum. Open shut-off valve (B) to do so.
Scheme 93
Remove filling unit with adapter from expansion tank.
Adjust coolant level to max.
Close coolant expansion tank.
Scheme 94
Check function of cooling system.
Check cooling system for leaks.
17 00 039 Venting and filling cooling system with vacuum filling unit (Version 2)
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | You must protect the alternator against contamination by coolant before carrying out any work on the coolant circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Note on ordering
- Workshop equipment
- Workshop equipment catalogue
- No.- 81 93 2 152 473
| IMPORTANT | Risk of slipping due to coolant on the floor. Risk of injury! |
Catch and dispose of emerging coolant in drip tray (1) and if necessary special tool 00 2 030 (universal hydraulic lifter).
Recycling
Observe country-specific waste-disposal regulations.
| IMPORTANT | Check all the coolant hoses before filling the cooling system with the vacuum filling unit. If necessary, replace damaged and porous coolant hoses. |
Note. Following graphics shows F01, procedure for other model series is identical.
Vacuum filling unit consists of
- 1) Filling unit with vacuum meter and shut-off valves
- 2) Filler hose
- 3) Coolant container
- 4) Venturi nozzle
- 5) Compressed-air connection (max. 6 bar)
- 6) Outgoing-air hose (lead outgoing-air hose into a collecting container)
Scheme 95
Preconditions
- Cooling system expansion tank must be empty.
- There must be sufficiently premixed coolant in the filling unit container, 1 - 2 liters more than the vehicle filling capacity. Use only recommended coolant «COOLING SYSTEM - OPERATING FLUIDS»(ref-265751) . Observe mixture ratio. Observe «FILLING CAPACITIES»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-technical-data-n52) .
- Position the filling unit container at the same height as the coolant expansion tank.
- Compressed-air connection with 6 bar pressure present.
- Set heating to maximum temperature.
Application
Connect filling unit (1) with adapter (2) 17 0 113 to coolant expansion tank.
Shut-off valves (A) and (B) must be closed.
Scheme 96
Connect venturi nozzle (1) to filling unit (2).
Scheme 97
Connect compressed air (1) and open shut-off valve (B).
The venturi nozzle produces a flow noise.
Scheme 98
Then open shut-off valve (A) until filler hose (1) is filled without bubbles. Close shut-off valve (A) again. This vents the filler hose (1).
Scheme 99
Shut-off valve (B) remains open. Approx. 1 minute. Generate vacuum in cooling circuit. The end vacuum is reached at a vacuum of -0.7 to -0.95 bar. Green scale in vacuum meter.
Note. The coolant hoses contract during vacuum build-up.
Then close shut-off valve (B) again.
Scheme 100
Both shut-off valves (A) and (B) must be closed. Then seal venturi nozzle (1).
The cooling system must maintain the vacuum for 30 seconds. If the needle in the vacuum meter falls, this indicates a leak in the cooling system.
If the vacuum remains constant, proceed with filling.
In event of leaks, check COOLING SYSTEM FOR LEAKS .
Scheme 101
| IMPORTANT | There must be sufficiently PREMIXED COOLANT in the filling unit container, 1 - 2 liters more than the vehicle filling capacity. Position the filling unit container at the same height as the coolant expansion tank. |
Shut-off valve (B) remains closed during the filling process.
To fill the cooling system, open shut-off valve (A) to filling unit container.
Coolant is now added.
The filling process is finished when the needle in the vacuum meter is at 0 bar or no longer falls.
Scheme 102
If necessary, release remaining vacuum. To do so, open shut-off valve (B).
Remove filling unit with adapter from expansion tank.
Adjust coolant level to max.
Scheme 103
Close coolant expansion tank.
Installation
Close cap (1) until the arrow marks line up.
Scheme 104
Check function of cooling system.
Check COOLING SYSTEM FOR LEAKS .
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Protective measures/rules of conduct
- Wear protective goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00 2 030 (universal hydraulic lifter).
Recycling
Observe country-specific waste-disposal regulations.
Checking pressure drop in cooling system
Open cap on coolant expansion tank. Fit special tools (1) 17 0 101 and (2) 17 0 113.
Build up GAUGE PRESSURE and wait approx. 2 minutes.
Cooling system is impervious to leaks if pressure drop is max. 0.1 bar.
Checking pressure relief valve in cap
Note. While the vehicle is driven at high outside temperatures, the design may cause the pressure relief valve in the cap to open slightly and air together with dissolved coolant to escape. This coolant vapor condenses on the surface of the expansion tank and leaves traces when the vehicle has cooled down. These traces do not indicate whether the cap is defective or not. When the vehicle has been parked up for an extended period of time, the residual escaping coolant can cause the pressure relief valve in the cap to stick; therefore check the cap again 2 to 3 times.
Replace the cap only after you have checked three times and there is an incorrect opening pressure.
Checking pressure relief valve in cap
Screw cap (1) onto special tool 17 0 114.
Build up pressure with special tool (hand pump) 17 0 101; observe pressure gauge to ascertain when opening pressure is achieved.
Compare OPENING PRESSURE of pressure relief valve.
17 11 052 Removing and installing left module carrier (N52K, N54)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Necessary preliminary tasks
- Remove «FAN COWL»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-11-035-removing-and-installingreplacing)
- N54/N54T only: Remove intercooler
Release bolts (1) on radiator on left and right.
Tightening torque 17 10 2AZ .
Do not unfasten or detach coolant hose (2).
Do not drain coolant.
Scheme 105
Slide radiator and condenser slightly towards rear.
Feed out left module carrier (1) and remove towards top.
Scheme 106
Installation
When reinstalling module carrier (1), ensure without fail that the radiator is correctly seated in mounting (2).
Scheme 107
Add final details to vehicle.
17 11 000 Removing and installing radiator (N52K, N54)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | Wear protective goggles and gloves. |
Necessary preliminary tasks
- Remove «FAN COWL»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-11-035-removing-and-installingreplacing)
- Draining «COOLANT»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-00-008-draining-and-adding)
- Unlock coolant hoses and detach
- N54/N54T only: Remove intercooler
Only automatic transmission or twin-clutch gearbox: Release bolt and detach hose (1).
Scheme 108
Only automatic transmission or twin-clutch gearbox: Release bolt (1) and detach hose (2).
Scheme 109
Release bolts (1) on radiator on left and right.
Tightening torque 17 10 2AZ .
Unlock and detach coolant hose (2).
Lift out module carrier (1) on left.
Feed out radiator (2) and remove towards top.
Scheme 110
Installation
When reinstalling the radiator and module carrier (1), ensure without fail that the radiator is correctly seated in mounting (2).
Add final details to vehicle.
Check COOLING SYSTEM for leaks.
17 11 054 Removing and installing right module carrier (N52K, N54)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| WARNING | Risk of injury! Refrigerant circuit is under high pressure! Follow safety instructions for handling refrigerant See 6450... INSTRUCTIONS FOR HANDLING REFRIGERANT R 134A or 6450... SAFETY INSTRUCTIONS FOR HANDLING REFRIGERANT R134A . Avoid contact with refrigerant and refrigerant oil Follow safety instructions for HANDLING REFRIGERANT OIL . |
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. Follow INSTRUCTIONS for opening and replacing parts in refrigerant circuit. |
If A/C system is opened for more than 24 hours: Replace DESICCANT INSERT for A/C system.
Necessary preliminary tasks
- Remove left «MODULE CARRIER»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-11-052-removing-and-installing)
- Drain off «AIR CONDITIONING SYSTEM»(/bmw/z4/e89-2009-2013/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-50-010-drawing-off-evacuating)
Release screws (1).
Tightening torque 64 53 6AZ .
Detach A/C lines (2) from A/C condenser.
Installation
Replace all sealing rings and moisten with refrigerant oil.
Scheme 111
Lift out right module carrier (1) together with A/C condenser (2).
Scheme 112
Release A/C condenser from module carrier. In so doing, release lock (1) on side of module carrier in direction of arrow.
Scheme 113
Installation
When reinstalling the radiator and module carrier (1), ensure without fail that the radiator is correctly seated in mounting (2).
Add final details to vehicle.
Evacuate and fill A/C SYSTEM .
17 11 100 Removing and installing/replacing coolant expansion tank (N54, N52K)
Necessary preliminary tasks
- Drain «COOLANT»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-00-008-draining-and-adding) .
N54 only: Release vacuum line at retainers (1) from expansion tank.
Unfasten screws (2).
Tightening torque 17 10 4AZ .
Release and disconnect coolant hoses (3).
Raise expansion tank (4)
Scheme 114
Unlock plug (1) on coolant level switch and disconnect.
Remove expansion tank (2).
Installation
Make sure locating pin (3) is correctly seated in rubber mount (4).
Scheme 115
Assemble engine.
Top up COOLANT .
Check cooling system for LEAKS .
17 11 035 Removing and installing/replacing fan cowl with electric fan (N52K, N54)
Necessary preliminary tasks
- Read out fault memory of DME control unit
- Turn off ignition
- Remove «CROSS-MEMBER»(ref-381258-S12487345552010122800000)
- Only automatic transmission and twin-clutch gearbox
RELEASE TRANSMISSION FLUID COOLER from the fan cowl do not remove
Unclip coolant line (1) from fan cowl.
Unlock and disconnect plug (2) on fan cowl on right.
Scheme 116
Release screw (1) on fan cowl.
Tightening torque 17 10 1AZ .
Release lock (2) and remove fan cowl (3) towards top.
Scheme 117
Installation
Insert retaining tabs (1) at bottom on radiator/intercooler.
Scheme 118
Note. Check stored fault message. Reassemble the vehicle. clear fault memory.
17 12 010 Removing and installing/replacing coolant pipe on front axle (N52K)
Necessary preliminary tasks: Remove intake filter housing. See 13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K) . Drain coolant .
Release screws (1). Tightening torque 17 10 5AZ. Unfasten and detach coolant pipe from expansion tank (2). Unfasten and detach coolant pipe from coolant thermostat (3). Unfasten and detach coolant pipe from coolant hose (4). Feed out coolant pipe and remove.
Scheme 119
Assemble engine. Top up coolant . Check cooling system for leaks .
17 21 500 Flushing transmission oil cooler with lines (automatic transmission)
Note. Carry out the work steps listed when: Installing a new or replacement transmission. Flushing can only be carried out with the automatic transmission removed.
Procedure
Automatic transmission removed.
Connect appropriate adapters (see description below) to oil lines exiting from automatic transmission.
Connect connecting line 17 2 019 from the oil collection unit with the quick-release coupling.
Connect drain line 17 2 018 using quick-release coupling.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid.
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Arrangement, flushing apparatus for transmissions A5S 310Z, A5S 560Z, A5S 360R/390R, A4S 200R, A5S 325Z
Scheme 120
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 011 Adapter for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2) 17 2 021 Mounting plate for adapter 17 2 011 for transmissions A5S 325Z, GA6HP26Z
Arrangement of flushing apparatus for transmission A4S 310R
Scheme 121
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
Arrangement of flushing apparatus for transmission A4S 300J
Scheme 122
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 014 Banjo bolt for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
Arrangement of flushing apparatus for transmission A5S 440Z
Scheme 123
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 013 Banjo bolt for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
17 21 500 Flushing transmission oil cooler with lines (automatic transmission) (GA6HP19Z, GAHP26Z, GA6HP32Z)
Note. Carry out the work steps listed when: Installing a new or replacement transmission.
Procedure
Automatic transmission removed.
Connect appropriate adapters (see description below) to oil lines exiting from automatic transmission.
Connect connecting line 17 2 019 from the oil collection unit with the quick-release coupling.
Connect drain line 17 2 018 using quick-release coupling.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid) through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid.
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Press hydraulic lines (1) into adapters (2).
Slide clamping bar (3) into guides and secure with screw (4).
Scheme 124
Arrangement of flushing apparatus for transmissions GA6HP19Z, GA6HP26Z, GA6HP32Z
Scheme 125
- Transmission-oil cooler with lines
- Oil collection unit 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 019 Hose to oil collection unit (2)
- Oil drip tray 17 2 018 Hose to oil drip tray (3)
- Adapter with clamping bar 17 2 060 Adapter with clamping bar for aluminum lines and steel lines with aluminum connection (line diameter 12 mm) GA6HP19Z 17 2 070 Adapter with clamping bar (line diameter 15 mm) GA6HP26Z, GA6HP32Z, TCT for N54 engine 17 2 080 Adapter with clamping bar for fuel lines GA6HP26Z
Note. Carry out the work steps listed when: Installing a new or replacement transmission. Flushing can only be carried out with the automatic transmission removed.
Procedure
Automatic transmission removed.
Connect appropriate adapters (see description below) to oil lines exiting from automatic transmission.
Connect connecting line 17 2 019 from the oil collection unit with the quick-release coupling.
Connect drain line 17 2 018 using quick-release coupling.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid (refer to BMW Service Operating Fluids) through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid (refer to BMW Service Operating Fluids).
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Arrangement, flushing apparatus for transmissions A5S 310Z, A5S 560Z, A5S 360R/390R, A4S 200R, A5S 325Z
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 011 Adapter for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2) 17 2 021 Mounting plate for adapter 17 2 011 for transmissions A5S 325Z, GA6HP26Z
Arrangement of flushing apparatus for transmission A4S 310R
Scheme 126
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
Arrangement of flushing apparatus for transmission A4S 300J
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 014 Banjo bolt for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
Arrangement of flushing apparatus for transmission A5S 440Z
Scheme 127
- Transmission oil cooler with lines
- Oil collection unit
- Oil drip tray 17 2 012 Adapters (2 x) for connecting transmission-side oil cooler lines (1) 17 2 013 Banjo bolt for connecting transmission-side oil cooler lines (1) 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 018 Hose to oil drip tray (3) 17 2 019 Hose to oil collection unit (2)
Note. Carry out the work steps listed when: Installing a new or replacement transmission.
Procedure
Automatic transmission removed.
Connect appropriate adapters (see description below) to oil lines exiting from automatic transmission.
Connect connecting line 17 2 019 from the oil collection unit with the quick-release coupling.
Connect drain line 17 2 018 using quick-release coupling.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid (refer AUTOMATIC TRANSMISSION - OPERATING FLUIDS ) through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid.
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Press hydraulic lines (1) into adapters (2).
Slide clamping bar (3) into guides and secure with screw (4).
Arrangement of flushing apparatus for transmissions GA6HP19Z, GA6HP26Z, GA6HP32Z
- Transmission-oil cooler with lines
- Oil collection unit 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 019 Hose to oil collection unit (2)
- Oil drip tray 17 2 018 Hose to oil drip tray (3)
- Adapter with clamping bar 17 2 060 Adapter with clamping bar for aluminum lines and steel lines with aluminum connection (line diameter 12 mm) GA6HP19Z 17 2 070 Adapter with clamping bar (line diameter 15 mm) GA6HP26Z, GA6HP32Z, TCT for N54 engine 17 2 080 Adapter with clamping bar for fuel lines GA6HP26Z
17 22 010 Removing and installing/replacing heat exchanger for automatic transmission (N52K)
| IMPORTANT | Danger of scalding! Only perform this work after engine has cooled down. |
Necessary preliminary tasks
- Drain «COOLANT»(/bmw/z4/e89-2009-2013/remont/cooling-system-mechanical/#cooling-system-repair-n52__17-00-008-draining-and-adding) .
- Remove «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#front-axle-repair__51-47-490-removing-and-installingreplacing) .
Recycling
Catch and dispose of drained coolant in a suitable container.
Transmission fluid emerges when oil lines are detached from heat exchanger.
Catch and dispose of escaping transmission fluid in a suitable container.
Observe country-specific waste-disposal regulations.
Release and disconnect coolant hoses (1).
Unlock transmission fluid lines (2) and detach.
Scheme 128
Lay the coolant hose (1) to the side if necessary.
Release screw.
Tightening torque 17 10 6AZ .
Remove transmission oil cooler.
Scheme 129
Note. Assemble engine. Check FLUID LEVEL in automatic transmission. If necessary, top up transmission fluid.
See also:
• GAUGE PRESSURE
• UNDERBODY PROTECTION
• 17 00 1AZ
• 6450... INSTRUCTIONS FOR HANDLING REFRIGERANT R 134A
• 6450... SAFETY INSTRUCTIONS FOR HANDLING REFRIGERANT R134A
• INSTRUCTIONS
• DESICCANT INSERT
• AIR CONDITIONING SYSTEM
• 64 53 6AZ
• 13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K)
• FLUID LEVEL
• COOLING SYSTEM
• COOLANT SYSTEM
• FAN COWL
• COOLANT
• MODULE CARRIER
• RELEASE TRANSMISSION FLUID COOLER
