61 0 021 Fuse link FF 3.15 A / 500 V
Note: For analog/digital multimeter M 2005, M 2007, M2008
Storage location: H 107
Order number: 61 0 021
Fuse link FF 3.15 A / 500 V
61 0 060 Sealing cap for fiber-optic cable
Minimum set: Mechanical tools
Note: Sealing cap for sealing fiber-optic cable during repair work, e.g. body or painting work (10 x per bag)
Series: E60, E65, E66, E67, E85
SI number: 1 10 03 (995)
Order number: 61 0 060 Sealing cap for fiber-optic cable
Scheme 183
61 1 150 Releasing tool kit
Minimum set: Mechanical tools
Note: For circular connector / ejector tool - Contains the kits 61 1 130, 61 1 140 and 61 1 180
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E66, E83, E85, R50, R53, RR1
Storage location: K 106
Order number: 61 1 150 Releasing tool kit
Scheme 184
Consisting of
61 1 151 Pressing-out tool
Note: For Power-Timer contacts / AMP and Bosch
61 1 152 Pressing-out tool
Note: For Micro-Timer contacts
61 1 153 Release tool
Note: For retaining tabs of relay holder
61 1 154 Replacement sleeve dia. 1.5 mm for 61 1 139
Note: Order number was reserved in 8/95 on delivery of case temporarily for case insert
61 1 155 Replacement sleeve dia. 3.5 mm for 61 1 133
61 1 156 Replacement sleeve dia. 2.5 mm for 61 1 132
61 1 157 Replacement sleeve dia. 1.5 mm for 61 1 131
61 1 158 Case with insert
61 1 159 Operating instructions
61 1 131 Pressing-out tool
Note: For 1.5 mm round contacts
61 1 132 Pressing-out tool
Note: For 2.5 mm round contacts
61 1 133 Pressing-out tool
Note: For 3.5 mm round contacts
61 1 134 Pressing-out tool
Note: For mini flat spring contacts
61 1 135 Pressing-out tool
Note: For standard flat spring contacts
61 1 136 Pressing-out tool
Note: For Power-Timer contacts (G & H)
61 1 137 Pressing-out tool
Note: For Timer contacts
61 1 138 Socket wrench
Note: For telltale lamps (instrumentcluster)
61 1 139 Pressing-out tool
Note: Slotted sleeve for 1.5 mm dia.
Kostal round contacts
61 1 141 Release tool
Note: For D 2.5 / ELA, 4-pin, round
61 1 142 Release tool
Note: For D 2.5 / ELA, 7-pin, round
61 1 143 Release tool
Note: For D 2.5 / ELA, 12-pin, round
61 1 144 Release tool
Note: For D 2.5 / ELA, 25-pin, round
61 1 145 Release tool
Note: For D 1 5 / ELA 10-pin round
61 1 149 Replacement blades
Note: For pressing-out tool 61 1 148
61 1 148 Pressing-out tool for SLC
Note: SLK = Sensor Laminated Contacts
61 1 180 Pressing-out tool
Note: For load current contacts This individual tool belongs to 61 1 150
61 1 180 Removal tool
Minimum set: Mechanical tools
Note: For load current contacts
Series: All models
SI number: 20600(636)
Order number: 61 1 180 Removal tool
Scheme 185
61 1 350 Set of assembly tools
Note: For removing and installing socket in transmission connector on automatic transmission
Transmission: 4 HP 22, 4 HP 24
Storage location: I 103
Order number: 61 1 350 Set of assembly tools
Scheme 186
Consisting of
1 = 61 1 351 Removal tool
2 = 61 1 352 Fitting drift
61 2 070 Cable set
Minimum set: Measuring and testing equipment
Note: For performing installation and adjustment work with front seat with electric seat adjustment removed 61 2 071 for activating removed convertible top E85 and R52
Series: E31, E36, E38, E46, E52, E60, E61, E65, E66, E85, R52, RR1
Storage location: R 204, R 205, R 206, R 207
SI number: 2 12 91(450)
Order number: 61 2 070
Cable set
Consisting of
Scheme 187
1 = 61 2 071 Power supply cable
Note: Connection between a battery and different adapter cables
2 = 61 2 072 Adapter cable
Note: Model series: E36
3 = 61 2 073 Adapter lead
Note: Model series: E38
In conjunction with: 61 2 071
4 = 61 2 074 Adapter lead
Note: Model series: E46, E52
In conjunction with: 61 2 071
61 2 080 Adapter lead
Minimum set: Measuring and testing equipment
In conjunction with: 612071
Note: Activation of E85 convertible top hydraulics with convertible top removed
Series: E85
SI number: 01 10 02 (907)
Order number: 61 2 080 Adapter lead
Scheme 188
61 2 090 Adapter lead
Minimum set: Measuring and testing equipment
In conjunction with: With removed convertible top with cable 61 2 071
Note: For external connection of a servomotor during seat removal (faulty motor on seat) For E85: For activating convertible top lock with removed convertible top For R52 (MINI Convertible): for activating convertible top lock (with removed convertible top)
Series: E52, E85, R52
Storage location: R 212
SI number: 2 05 00(624)
Order number: 61 2 090 Adapter lead
Scheme 189
61 2 310 Adapter for measuring closed-circuit current
In conjunction with: MoDiC / DIS
Note: Modified measurement method, also suitable for voltage measurement
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E85, R50, R53
Storage location: I 108
SI number: 2 05 99(511)
Order number: 61 2 310 Adapter for measuring closed-circuit current
Scheme 190
61 2 410 Battery trickle charger
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1
Storage location: Single
SI number: 2 02 00(545)
Order number: 61 2 410 Battery trickle charger
Scheme 191
Consisting of
1 = 61 2 411 Trickle charger
Note: With connecting cable (flat cable) for cigarette lighter socket
2 = 61 2 412 Power supply cable
Note: Country-specific equipment
3 = 61 2 413 Adapter cable
Note: For direct connection to battery or terminal
9 = 61 2 419 Operating instructions
61 3 300 Removal tool
Minimum set: Mechanical tools
Note: For removing ring antenna at ignition lock
Series: E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/C, E38, E38/3, E39, E39tou, E46, E52, E53, E60, E61, E63, E64, E83, E85, R50, R52, R53
SI number: 1 17 97 (228)
Order number: 61 3 300 Removal tool
Scheme 192
61 4 300 Adapter lead for OBD socket
Note: For connecting diagnosis system to OBD socket from 06/2000.
Storage location: Single
SI number: 2 04 00 (561)
Order number: 61 4 300 Adapter lead for OBD socket
Scheme 193
61 4 320 Crimping set with pliers
Minimum set: Measuring and testing equipment
Note: For optical fibres and cable repair
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E65, E66, E67, E85, R50, R53, RR1
SI number: 1 14 01(766)
Order number: 61 4 320 Crimping set with pliers
Scheme 194
Consisting of
1 = 61 4 321 Pliers without crimping head
2 = 61 4 322 Crimping head
Note: For stripping insulation and cutting fiber optic cable to length
3 = 61 4 323 Crimping head
Note: For crimping fiber optic cable contacts
4 = 61 4 324 Crimping head
Note: For crimping MQS contacts
5 = 61 4 325 Crimping head
Note: For crimping MPQ contacts
6 = 61 4 326 Substitute blade
Note: For face-cutting fiber optic cables
7 = 61 4 327 Substitute blade
Note: With tool for replacing blade in cable stripping unit
61 4 370 V-adapter lead (2-pin), zero-coded
Minimum set: Measuring and testing equipment
Note: Can be used on different plug housings in engine wiring harness (e.g. from Kostal - "SLK 2.8", Tyco - "Junior-Power-Timer"or Bosch) with different codings.
Series: E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
SI number: 02 01 05 186
Order number: 61 4 370 V-adapter lead (2-pin), zero-coded
Scheme 195
61 4 380 Measuring box, 105-pin, complete
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 61-pin to 105-pin plug connections
Series: E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
Storage location: G 110, S 205, U 202, U 205
SI number: 2 04 01(710)
Order number: 61 4 380 Measuring box, 105-pin, complete
Scheme 196
Consisting of
1 = 61 4 381 Measuring box, 105-pin
Note: Without accessories
2 = 61 4 382 Test lead, black
Note: 2 mm system, lead length: 750 mm
3 = 61 4 383 Test lead, red
Note: 2 mm system, lead length: 750 mm
4 = 61 4 384 Test lead set
Note: 2/4 mm system, lead length: 200 mm
5 = 61 4 385 Earth/ground cable
Note: For shield pick-off, lead length: 1.5 m
61 4 390 Measuring box, 60-pin
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 27-pin to 60- pin plug connections
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
Storage location: T 210
SI number: 2 02 98(308)
Order number: 61 4 390 Measuring box, 60-pin
Scheme 197
61 6 060 Universal wiper arm puller
Minimum set: Mechanical tools
Note: For removing windscreen wiper arm from drive shaft
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, RR1
Storage location: B40
SI number: 1 10 99 (433)
Order number: 61 6 060 Universal wiper arm puller
Scheme 198
Consisting of
1 = 61 6 061 Basic body
2 = 61 6 062 Claw, left/right
3 = 61 6 063 Spindle
4 = 61 6 064 Thrust piece
61 6 210 Wiper arm puller
Minimum set: Mechanical tools
Series: E52, E53, E60, E61, E63, E64, E83, E85, E87, E90, E91, R50, R52, R53
SI number: 1 01 05 (172)
Order number: 61 6 210 Wiper arm puller
Scheme 199
61 9 040 Set of tools for repair kit IV
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E85, R50, R53
Storage location: K 108
SI number: 2 02 92(505)
Order number: 61 9 040 Set of tools for repair kit IV
Scheme 200
Consisting of
1 = 61 9 041 Hand pliers without crimper
2 = 61 9 042 Crimper
Note: For crimping butt connectors and contact sleeves for strip connectors
3 = 61 9 043 Cable stripper with wire cutter
4 = 61 9 044 Crimper
Note: For crimping antenna connector (antenna cable/radio plug connection)
61 9 045 Female die
In conjunction with: 61 9 041 Crimping tool
Note: For crimping 2.5 mm (dia.) sleeves
Order number: 61 9 045
Female die
