Lights - Repair BMW Z4 E85/E86

Exterior Lights 52 illustrations ~2290 words

63 10... Test requirements for headlight vertical aim adjustment

  1. Car parked on level ground.
  2. Replace faulty glass and mirrors and defective light bulbs.
  3. Check tire pressure and correct if necessary.
  4. Apply load equivalent to one person on driver's seat (approx. 75 kg).
  5. Vehicle with full fuel tank or appropriate additional weight in luggage compartment.
  6. Correct adjustment of headlights in relation to engine hood (gap dimensions).
  7. Manual headlight vertical aim control: Turn handwheel to 0 position.
  8. Automatic headlight vertical aim control: Wait approx. 30 seconds after switching on lights.
  9. Version with xenon headlights: Wait 80 seconds after switching on lights. During this time, do not move the vehicle and avoid vibrations.
  10. Align headlight aimer with vehicle longitudinal axis and parallel to parking surface. Set marking line (M) on aimer to distance (e). Scale graduations on aimer are equal to a gradient in cm at a distance of 10 meters.

Scheme 1

Scheme 1

Light/Dark Limit Of Headlights In Headlight Aimer

e Adjustment dimension, headlights

  1. as per type plate on headlight housing in % (e.g.: 1.0 % = 10 cm / 10 m = 10 on headlight aimer).

Adjustment dimension, fog lights

  1. all vehicles 2.0 % = 20 cm / 10 m = 20 on headlight aimer.

H Height of center of headlight above parking surface.

h H - e = height of marking line above parking surface

+ Central mark = center point of high-beam headlight.

M Marking line of headlamp aimer

S Parking surface of vehicle and headlight aimer

Adjustment dimension (e) is only valid for EUR. Observe differing national regulations.

63 10 004 Adjusting headlights

Note. Engine hood is open.

Adjust headlights at adjusting screws (1) and (2).

A definite allocation of adjusting screws is not possible.

Scheme 2

Scheme 2: 63 10 004 Adjusting headlights
  1. Adjustment screw primarily for vertical adjustment
  2. Adjustment screw primarily for lateral adjustment

63 10 014 Adjusting fog lamps

Adjust fog lamp (1) at adjusting screw (2).

Scheme 3

Scheme 3: 63 10 014 Adjusting fog lamps

Scheme 4

Scheme 4: 63 12.. Overview of headlight

63 12 001 Removing and installing/replacing left headlight

Necessary preliminary tasks

  1. Remove front bumper trim. See «51 11... OVERVIEW OF FRONT BUMPER»(/bmw/z4/e85e86-2002-2005/remont/door-locks-anti-theft-systems/#body-equipment-repair) .

Release screws (1).

Pull out headlight (2) in direction of arrow slightly, unlock and disconnect all plug connections.

Remove headlight (2).

Installation

Adjust headlight to fit. See 63 10 004 Adjusting Headlights .

Scheme 5

Scheme 5
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Replacement

If necessary, remove Bulbs .

Installation

Adjust headlights . See 63 10 004 Adjusting Headlights .

63 12 010 Removing and installing/replacing left headlight (xenon headlight)

WARNINGXenon headlights: Danger to life due to high voltage! Therefore disconnect xenon headlights from the power supply. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

The subsequent procedure is described in

"Removing Left Headlight ".

Replacement

  1. Remove control unit for xenon headlight. See «63 12 860 Replacing Control Unit For Left Xenon Headlight»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-12-860-replacing-control-unit) .
  2. Remove ignition unit for xenon headlight. See «63 12 870 Replacing Ignition Unit For Left Xenon Headlight»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-12-870-replacing-ignition-unit) .
  3. Remove «Bulb»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-99-076-replacing-lamp-for) for xenon light.
  4. If necessary, remove «Bulbs»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-99-273-replacing-bulb-for) .

63 12 860 Replacing control unit for left xenon headlight

WARNINGVersion with xenon headlights: Danger to life due to high voltage! Therefore disconnect all components from voltage supply before removal. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Necessary preliminary tasks

  1. Remove left «Headlight»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-12-010-removing-and-installingreplacing) (xenon headlight).

Release screws (1).

Remove control unit for xenon headlight (2) upwards from headlight (3).

Scheme 6

Scheme 6

Installation

When installing control unit for xenon headlight (1), make sure sealing sleeve (2) is correctly seated.

Scheme 7

Scheme 7

63 12 870 Replacing ignition unit for left xenon headlight

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 8

Scheme 8: 63 12 870 Replacing ignition unit for left xenon headlight
WARNINGVersion with xenon headlights: Danger to life due to high voltage! Therefore disconnect all components from voltage supply before removal. Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.

Lift locking bracket (1) out of mounts (2) and fold down as illustrated.

Feed out cover (3) in direction of arrow and remove.

Scheme 9

Scheme 9

Unfasten plug connection (1) and disconnect.

Turn ignition unit for xenon headlight (2) approx. 30° in counterclockwise direction, detach from headlight (3) and remove.

Installation

Make sure inner ring is correctly positioned in ignition unit for xenon headlight.

Scheme 10

Scheme 10

63 13 200 Removing and installing/replacing front left or right auxiliary turn signal lamp

Turn front auxiliary turn signal lamp (1) approx. 45° counterclockwise and pull out of trim (2).

Unlock plug connection behind and disconnect.

Remove front auxiliary turn signal lamp (2).

Scheme 11

Scheme 11: 63 13 200 Removing and installing/replacing front left or right auxiliary turn signal lamp

Replacement

WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

If necessary, remove Bulb .

63 14 015 Removing and installing/replacing rear left or right side marker lamps

Loosen screws (1).

Unlock retaining hook (2) and remove side marker lamp (3) towards rear.

Scheme 12

Scheme 12: 63 14 015 Removing and installing/replacing rear left or right side marker lamps

63 17 060 Removing and installing (replacing) left or right front fog lamp

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 13

Scheme 13: 63 17 060 Removing and installing (replacing) left or right front fog lamp

Unlock plug connection (1) and disconnect.

Release screw (2) and remove front fog lamp (3).

Scheme 14

Scheme 14

Replacement

WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

If necessary, remove Bulb .

Installation

Adjust Front Fog Lamps .

Scheme 15

Scheme 15: 63 21.. Overview of rear light

63 21 055 Replacing a socket housing for left or right tail light

Turn turn-lock fastener (1) in direction of arrow and remove trim (2).

WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Scheme 16

Scheme 16

Turn socket housing for rear light to be replaced counterclockwise and remove.

Convert Bulb , replace if necessary.

Note. EUR driver's side only: Socket housing for fog warning lamp All others: Socket housing for reversing light Socket housing for combined brake/rear light Socket housing for turn signal light Socket housing for combined brake/rear light

Scheme 17

Scheme 17

63 21 101 Replacing sealing frame for left or right rear light

Necessary preliminary tasks

  1. Remove «Rear Light»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-21-170-removing-and-installingreplacing)

Detach sealing frame for rear light (1) from rear light (2).

Installation

Sealing frame for rear light (1) is centered via openings for threaded pins (3).

Make sure sealing frame for rear light (1) is correctly bonded all round on rear light (2).

Scheme 18

Scheme 18

63 21 170 Removing and installing/replacing left or right rear light

Turn turn-lock fastener (1) in direction of arrow and remove trim (2).

Scheme 19

Scheme 19: 63 21 170 Removing and installing/replacing left or right rear light

Disconnect plug connection (1).

Note. Secure rear light (3) against falling out.

Release nuts (2) and remove exterior rear light (3).

Scheme 20

Scheme 20

Installation

  1. Make sure sealing frame for rear light (2) is correctly seated, replace if necessary.
  2. Make sure guides (1) of rear light (3) are correctly seated in associated mountings.
  3. Make sure (outer) gap of rear light (3) is uniform all round.

Replacement

Remove trim on rear light.

If necessary, remove all socket housings for rear light.

Scheme 21

Scheme 21

63 25 000 Removing and installing/replacing additional stop light

Open trunk lid.

Loosen screws (1).

Feed out cover (2) in direction of arrow, unlock plug connection of auxiliary brake light behind it and disconnect.

Pay attention to springs underneath when releasing nuts (3).

Scheme 22

Scheme 22: 63 25 000 Removing and installing/replacing additional stop light

Installation

Tightening sequence of screws

  1. Middle
  2. Outer

Tightening torque is 2-3 N.m.

Pull auxiliary brake light (1) in direction of arrow out of rear lid (2) and remove.

Installation

Make sure auxiliary brake light seal is correctly seated. If necessary, replace auxiliary brake light seal.

Scheme 23

Scheme 23

63 26 000 Removing and installing/replacing left or right license plate light

Special tools required

  1. 64 1 020

Lever out license plate light (1) with special tool 64 1 020 as illustrated.

Disconnect associated plug connection and remove license plate light (1).

Scheme 24

Scheme 24
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Replacement

If necessary, remove bulb.

Scheme 25

Scheme 25: 63 31.. Overview of interior lights

63 31 000 Removing and installing/replacing complete ceiling light

Note. Secure complete ceiling light against falling out.

Unclip complete ceiling light (1) in direction of arrow from cowl panel insert (2).

Disconnect associated plug connections and remove complete ceiling light (1).

Scheme 26

Scheme 26: 63 31 000 Removing and installing/replacing complete ceiling light
IMPORTANTFollow instructions for handling light bulbs (interior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Replacement

If necessary, remove bulbs.

63 31 020 Removing and installing/replacing footwell light

Driver's side

Unclip footwell light (1) in direction of arrow from panel for pedals (2), disconnect associated plug connection and remove footwell light (1).

Scheme 27

Scheme 27: 63 31 020 Removing and installing/replacing footwell light

Passenger side

Unclip footwell light (1) in direction of arrow from bottom right instrument panel trim (2), disconnect associated plug connection and remove footwell light (1).

Scheme 28

Scheme 28
IMPORTANTFollow instructions for handling light bulbs (interior lights). See 63 99... Instructions for handling light bulbs (exterior lights) .

Replacement

If necessary, remove bulb.

63 31 070 Removing and installing/replacing storage box light

Special tools required

  1. 00 9 322

Note. Open lid on storage box.

Lever out storage box light (2) in direction of arrow through opening (1) with special tool 00 9 322.

Disconnect associated plug connection and remove storage box light (2).

Scheme 29

Scheme 29
IMPORTANTFollow instructions for handling light bulbs (interior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Replacement

If necessary, remove bulb.

63 31 080 Removing and installing/replacing luggage compartment light

Lever out luggage compartment light (1) in direction of arrow.

Disconnect associated plug connection and remove luggage compartment light (1).

Scheme 30

Scheme 30: 63 31 080 Removing and installing/replacing luggage compartment light
IMPORTANTFollow instructions for handling light bulbs (interior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Replacement

If necessary, remove bulb.

Scheme 31

Scheme 31: 63 99.. Overview of bulbs

63 99... Instructions for handling light bulbs (exterior lights)

WARNINGXenon headlights: Danger to life due to high voltage! Work on the entire xenon lighting system (ignition unit, control unit and lamp) may only be carried out by specialist personnel.
WARNINGHalogen lamps are under pressure: To avoid injury, wear protective goggles and gloves.
IMPORTANTTo prevent short-circuiting, disconnect light bulbs from voltage supply prior to replacement.

Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.

Only touch light bulbs with clean gloves or a clean cloth.

Do not expose light bulbs to mechanical vibrations.

Use only recommended light bulbs.

Follow the light bulb manufacturer's instructions without fail.

63 99... Instructions for replacing light bulbs (interior lights)

CAUTIONTo prevent short-circuiting, disconnect light bulbs from voltage supply prior to replacement.

Do not touch the glass bulbs in new lights bulbs as even the slightest contamination will burn in and reduce bulb service life.

Only touch light bulbs with clean gloves or a clean cloth.

Do not expose light bulbs to mechanical vibrations.

Use only recommended light bulbs.

Follow the light bulb manufacturer's instructions without fail.

63 99 002 Replacing halogen bulb for high-beam headlight on left

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 32

Scheme 32: 63 99 002 Replacing halogen bulb for high-beam headlight on left
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Lift locking bracket (1) out of mounts (2) and fold down as illustrated.

Feed out cover (3) in direction of arrow and remove.

Scheme 33

Scheme 33

Turn bulb holder (1) in direction of arrow and pull back towards rear.

Remove bulb from bulb holder (1).

Installation

Note Type Of Bulb .

Scheme 34

Scheme 34

63 99 076 Replacing lamp for left xenon headlight

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 35

Scheme 35: 63 99 076 Replacing lamp for left xenon headlight
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Lift locking bracket (1) out of mounts (2) and fold down as illustrated.

Feed out cover (3) in direction of arrow and remove.

Scheme 36

Scheme 36

Unfasten plug connection (1) and disconnect.

Turn ignition unit for xenon headlight (2) approx. 30° in counterclockwise direction, detach from headlight (3) and remove.

Installation

Make sure inner ring is correctly positioned in ignition unit for xenon headlight (2).

Scheme 37

Scheme 37

Unlock retainer (1) as illustrated on both sides.

Remove lamp for xenon headlight (2) from headlight (3).

Installation

Make sure lamp for xenon headlight (2) is correctly seated in headlight (3).

Scheme 38

Scheme 38

63 99 132 Replacing bulb for side marker lamp, front left

US only: This job is described under

EUR only

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 39

Scheme 39: 63 99 132 Replacing bulb for side marker lamp, front left
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Lift locking bracket (1) out of mounts (2) and fold down as illustrated.

Feed out cover (3) in direction of arrow and remove.

Scheme 40

Scheme 40

Feed out bulb holder (1) in direction of arrow and remove.

Scheme 41

Scheme 41

Take bulb (1) out of bulb holder.

Installation

Note type of bulb .

Scheme 42

Scheme 42

63 99 201 Replacing halogen bulb for left or right front fog lamp

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 43

Scheme 43: 63 99 201 Replacing halogen bulb for left or right front fog lamp
IMPORTANTFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Turn retaining ring (1) in direction of arrow and remove bulb holder (3) from front fog lamp (2).

Note. Press bulb holder (3) forwards if retaining ring (1) is tightly seated.

Scheme 44

Scheme 44

Remove bulb (2) from bulb holder (1) in direction of arrow.

Installation

Note type of bulb .

Scheme 45

Scheme 45

63 99 273 Replacing bulb for turn indicator, front left

Note. Front wheel removed for purposes of clarity.

Unlock fasteners (1) by turning counterclockwise through 180° and fold up cover (2) in direction of arrow.

Scheme 46

Scheme 46: 63 99 273 Replacing bulb for turn indicator, front left
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Lift locking bracket (1) out of mounts (2) and fold down as illustrated.

Feed out cover (3) in direction of arrow and remove.

Scheme 47

Scheme 47

Note. The front turn signal lamps has 2 bulbs. Bulb holder (1): outer side of vehicle Bulb holder (2): inner side of vehicle

Unlock bulb holder (1) or (2) with a Phillips screwdriver approx. 30° counterclockwise and feed out with a suitable tool (e.g. long-nose pliers).

Scheme 48

Scheme 48

Press bulb (1) and feed out of bulb holder in direction of arrow.

Installation

Note Type Of Bulb .

Scheme 49

Scheme 49

63 99 295 Replacing bulb for auxiliary turn signal light, front left or right

Necessary preliminary tasks

  1. Remove «front Auxiliary Turn Signal Light»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-13-200-removing-and-installingreplacing)
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions for handling light bulbs (exterior lights) .

Turn bulb holder (1) in direction of arrow and remove from front auxiliary turn signal lamp (2).

Scheme 50

Scheme 50

Remove bulb (1) from bulb holder (2) in direction of arrow.

Installation

Note Type Of Bulb .

Scheme 51

Scheme 51

63 99 315 Replacing light bulb(s) for left or right rear light

Necessary preliminary tasks

  1. Remove «Socket Housing For Rear Light»(/bmw/z4/e85e86-2002-2005/remont/exterior-lights/#lights-repair__63-21-055-replacing-a-socket)
WARNINGFollow instructions for handling light bulbs (exterior lights). See 63 99... Instructions For Handling Light Bulbs (Exterior Lights) .

Remove faulty bulb (1) in direction of arrow from socket housing (2).

Installation

Note Type Of Bulb .

Scheme 52

Scheme 52
