Starters: Wiring BMW Z3 E36 facelift

Starter 3 illustrations

WIRING DIAGRAMS

Note. Wiring diagrams not shown here may be available in appropriate STARTING/CHARGING article under SYSTEM WIRING DIAGRAMS in ELECTRICAL.

Starting System Wiring Diagram (1999 318ti). Scheme 3

Scheme 3: Starting System Wiring Diagram (1999 318ti)
Scheme 3: Starting System Wiring Diagram (1999 318ti)

Starting System Wiring Diagram (1999-2000 323i Convertible, 323is, 1999 328i Convertible, 328is & 1999 M3). Scheme 4

Scheme 4: Starting System Wiring Diagram (1999-2000 323i Convertible, 323is, 1999 328i Convertible, 328is & 1999 M3)
Scheme 4: Starting System Wiring Diagram (1999-2000 323i Convertible, 323is, 1999 328i Convertible, 328is & 1999 M3)

Starting System Wiring Diagram (1999-2000 M Coupe, M Roadster & Z3). Scheme 5

Scheme 5: Starting System Wiring Diagram (1999-2000 M Coupe, M Roadster & Z3)
Scheme 5: Starting System Wiring Diagram (1999-2000 M Coupe, M Roadster & Z3)
