86 10... Disassembly of Camlock retaining cam
Unscrew bolts (1).
Scheme 128
86 10... Disassembly of base plate
Note. Disassembly of bar refer to 86 10... REPLACING BAR Disassembly of lashing plate refer to 86 10... REPLACING LASHING PLATE AND LASHING EYE Disassembly of 12 volt socket refer to 86 10... REPLACING 12 VOLT SOCKET Remove plastic bush/metal bush refer to 86 10... REMOVING PLASTIC BUSH/METAL BUSH Disassembly of light guard refer to 86 10... REPLACING REAR LIGHT Disassembly of front apron refer to 86 10... DISASSEMBLY OF FRONT APRON Disassembly of left and right aprons refer to 86 10... DISASSEMBLY OF LEFT AND RIGHT APRONS Disassembly of left and right wheel boxes refer to 86 10... DISASSEMBLY OF LEFT AND RIGHT WHEEL BOXES Disassembly of rear apron refer to 86 10... DISASSEMBLY OF REAR APRON Disassembly of left and right lamp housings refer to 86 10... DISASSEMBLY OF LEFT AND RIGHT LAMP HOUSINGS Disassembly of rivet connection, rear support
Unscrew bolts (1).
| CAUTION | Before drilling out rivet heads, drive in rivet pins with a punch. Drill out rivet connections (2). |
86 10... Disassembly of bracket on platform base
Unscrew bolts (1).
Scheme 129
86 10... Disassembly of front apron
Drill out rivets (1) on lower apron edge.
Scheme 130
Remove sealing compound (1).
Drill out rivets (2).
86 10... Disassembly of front protection bar
Release screws (1) on cross-member (2).
86 10... Disassembly of jockey wheel or jockey wheel mount
Turn clamping lever (1) in direction of arrow and release clamping connection. Open clamping bracket (2) and remove jockey wheel (3). Release screws on mount (4) and remove screws.
86 10... Disassembly of left and right aprons
Note. Remove position light, refer to 86 10... REPLACING POSITION LIGHT .
Remove rear light
refer to 86 10... REPLACING REAR LIGHT .
Remove plastic bush/metal bush
refer to 86 10... REMOVING PLASTIC BUSH/METAL BUSH .
Drill out rivets (1) on lower apron edge.
Scheme 131
Remove sealing compound (1).
Drill out all rivets (2) along apron edge.
86 10... Disassembly of left and right lamp housings
Cut through sealing compound (1) and remove.
Drill out rivet connections (2).
86 10... Disassembly of left and right wheel boxes
Remove sealing compound (1).
Drill out rivets (2).
Raise side apron (3). Pull out wheel box (4) towards rear.
86 10... Disassembly of licence plate mounting plate
| CAUTION | Once the connecting screws (1) have been removed, the closing spring of the hinge retracts. Risk of trapping! |
Release screws (1) in loading ramp frame (2) on left and right sides.
86 10... Disassembly of loading ramp frame/disassembly of rail, left/right
Note. Two persons are required to disassemble the loading ramp frame. Disassemble license plate mounting plate Disassemble pull rod. Refer to Removing overrunning equipment/maintaining or replacing guide bush/installing overrunning equipment .
Release screws (1) of loading ramp frame (2) on cross-strut (3).
86 10... Disassembly of rear apron
Note. Remove rear light, refer to 86 10... REPLACING REAR LIGHT . Remove plastic bush/metal bush refer to 86 10... REMOVING PLASTIC BUSH/METAL BUSH .
Cut through sealing compound (1) on left and right and remove.
Drill out rivets (2) on left and right sides on lower apron edge.
