Engine- Special Tools BMW X6 M E71

11-8731 Adapter

0496305 118731 Adapter Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 11 8 73 (83 30 0 496 107) - as of 19.04.12 [Not available separately]

SI number

01 04 07 (352)

Scheme 53

11-4050 Adapter

0491005 114050 Adapter Minimum set: Mechanical tools MW

Note. (Adapter) For connecting pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW diagnosis and information system for checking oil pressure [released]

Storage Location

A4

Scheme 54

11-7470 Adapter

2209377 117470 Adapter MW

In conjunction with: 11 7 430; 13 5 000

Note. To measure the oil pressure. [Released]

Storage Location

C30

SI number

01 07 11 (703)

Scheme 55

11-9894 Adapter

0496382 119894 Adapter MW

Note. (Adapter N63) [released]

Scheme 56

11-8730 Adapter

0496107 118730 Adapter Minimum set: Mechanical tools MW

Note. For compression testing. [Released]

Storage Location

C23

SI number

01 04 07 (352)

Consisting of

Scheme 57

1. 2 = 0496306 Ring NOTE: (Sealing ring) For secure connection of test probe 11 0 222 and adapter 11 8 730/731. [Released]
2. 1 = 0496305 Adapter NOTE: Liquidation of existing inventory and then available only as a complete tool set 11 8 73 (83 30 0 496 107) - as of 19.04.12 [Not available separately]

11-0167 Adapter

0490600 110167 Adapter MW

Replaced by: 0490613

Note. (Test adapter extension) Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

Scheme 58

11-9003 Adapter

0494368 119003 Adapter Minimum set: Mechanical tools MW

Note. (Sliding block) [Released]

Scheme 59

11-0237 Adapter

0494517 110237 Adapter Minimum set: Mechanical tools MW

Note. Measuring "absolute compression" at all cylinders. Engine: W17 [Released]

Scheme 60

11-4060 Adapter

0491006 114060 Adapter MW

Replaced by: 0491003

Note. For pressure gauge for checking the oil pressure - Replaced by 11 4 030 (0 491 003) [Replaced]

Storage Location

B9

11-2118 Adapter

0490834 112118 Adapter MW

Replaced by: 0490504

Note. (Adapter) Replaced by 00 9 120 (0 490 504) [replaced]

Scheme 61

11-0166 Adapter

0490599 110166 Adapter MW

Replaced by: 0490613

Note. (test adapter for petrol engine: M70Discontinued and replaced by 11 0 220 (0 490 613) [replaced]

11-0239 Adapter

0495279 110239 Adapter Minimum set: Mechanical tools MW

Note. Engine M67, M67TU [released]

SI number

01 06 05 (181)

11-0165 Adapter

0490598 110165 Adapter MW

Replaced by: 0490613

Note. (test adapter for petrol engine: all, except M70 Discontinued and replaced by 11 0 220 (0 490 613) [replaced]

11-9895 Adapter

0496383 119895 Adapter MW

Note. (Adapter N74) [released]

SI number

01 31 09 (604)

Scheme 62

11-7430 Adapter

0496820 117430 Adapter MW

In conjunction with: 13 5 000

Note. For oil pressure measurement on oil filter cover. In conjunction with 13 3 060 [Released]

Storage Location

B29

SI number

01 31 09 (604)

Scheme 63

11-5480 Assembly tool

0495372 115480 Assembly tool MW

Note. For installing and removing connecting rods with pistons. [Released]

Storage Location

A20

B20

SI number

01 14 05 (198)

Scheme 64

11-8151 Assembly tool

0494677 118151 Assembly tool MW

Note. Liquidation of existing inventory and then available only as a complete tool set 11 8 150 (83 30 0 493 583) - as of 26.01.12 [Not available separately]

2249164 Assembly tool

2249164 Assembly tool MW

Note. For installing piston with connecting rod in crankcase. (S63TU, N63TU) [released]

Storage Location

B32

SI number

01 19 11 (742)

Scheme 65

11-5440 Assembly tool

0495508 115440 Assembly tool MW

Note. For mounting the pistons with the connecting rod. Engine: N62TU 4.0 litre [Released]

Storage Location

B20

A20

Scheme 66

11-8911 Basic body

0496572 118911 Basic body MW

Note. [Discontinued]

Scheme 67

11-9511 Basic body

0495472 119511 Basic body MW

Note. [Discontinued]

11-9016 Basket

0494380 119016 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine M21, M40 [Released]

Scheme 68

11-8840 Basket

0496143 118840 Basket MW

Note. (Valve spring cage) For removing and fitting the valves. [Released]

SI number

01 05 07 (353)

Scheme 69

11-9017 Basket

0495028 119017 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine N52 [Released]

Scheme 70

11-9015 Basket

0494379 119015 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73 [Released]

Scheme 71

11-9013 Basket

0494377 119013 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine M43, M73 [Released]

11-9012 Basket

0494376 119012 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine M41, M51, S50 [Released]

11-9014 Basket

0494378 119014 Basket Minimum set: Mechanical tools MW

Note. (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62 [Released]

11-2001 Bell housing

0490799 112001 Bell housing Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and after that available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-9892 Bridge

0496380 119892 Bridge MW

Note. [Released]

Scheme 72

11-6380 Bush

0493249 116380 Bush MW

Note. For fitting the valve stem seal [Released]

Storage Location

B15

SI number

01 06 98 (306)

Scheme 73

11-5000 Bush

0491032 115000 Bush MW

Note. For pressing out the water pump shaft [Discontinued]

11-9263 Bush

0494129 119263 Bush Minimum set: Mechanical tools MW

Note. (Bush for counter support) For counter support, for retaining flywheel when gearbox is removed Engine: N62, N73 [Released]

Storage Location

A45

Scheme 74

11-5450 Bush

0495365 115450 Bush MW

Note. (Assembly bush) For installing piston (diameter 87 mm) with connecting rod. Engine: M67TU; N62TUB40; [Released]

SI number

01 14 05 (198)

Scheme 75

11-9265 Bush

0494793 119265 Bush Minimum set: Mechanical tools MW

Note. [Released]

Storage Location

C44

Scheme 76

11-7400 Bush

0494043 117400 Bush Minimum set: Mechanical tools MW

Note. (Slip bush) For installation of the radial shaft seal in the gear case cover, bottom [Released]

Storage Location

B46

SI number

01 10 01 (733)

Scheme 77

11-9266 Bush

0495216 119266 Bush Minimum set: Mechanical tools MW

Note. For counter support, for retaining flywheel when gearbox is removed Engine: M57TU2 [Released]

Storage Location

B44

SI number

01 05 05 (180)

11-0161 Card

0490594 110161 Card MW

Replaced by: 0490613

Note. (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

11-0229 Card

0490622 110229 Card Minimum set: Mechanical tools MW

Note. (Cards) 100 pieces For recording compression tester 11 0 224 [released]

11-0223 Card

0490616 110223 Card Minimum set: Mechanical tools MW

Note. (Cards) 100 pieces For recording compression tester 11 0 221 [released]

11-0231 Case

0493634 110231 Case Minimum set: Mechanical tools MW

Note. With foam insert for recording compression tester [released]

11-0024 Chain

0490571 110024 Chain Minimum set: Mechanical tools MW

Note. (Chain) Version: short As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0023 Chain

0490570 110023 Chain Minimum set: Mechanical tools MW

Note. (Chain) Version: long As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0003 Chain

0490564 110003 Chain Minimum set: Mechanical tools MW

Note. (Chain) Version: short As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0002 Chain

0490563 110002 Chain Minimum set: Mechanical tools MW

Note. (Chain) Version: long As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0022 Chain

0490569 110022 Chain Minimum set: Mechanical tools MW

Note. (Chain) As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0220 Compression tester

0490613 110220 Compression tester Minimum set: Mechanical tools MW

Note. (compression pressure testing set) For all petrol and diesel engines. [Released]

SI number

01 09 92 (558)

Consisting of

1. 2 = 0493634 Case NOTE: With foam insert for recording compression tester [released]
2. 4 = 0490614 Compression tester NOTE: (Compression tester) For diesel engines [released]
3. 4 = 0490615 Sensor NOTE: (Test probe) For recording compression testers 11 0 221 and 11 0 160 / engine: M21, M41, M47, M51, M57, M57T2 [released]
4. 4 = 0490617 Compression tester NOTE: (Compression tester) For petrol engines. [Released]
5. 4 = 0490618 Hose NOTE: (Extension hose) For rubber tapered section with fitting 11 0 228 [discontinued]
6. 4 = 0490619 Sensor NOTE: (Test probe) For recording compression testers 11 0 224 and 11 0 160 / engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62 [released]
7. 4 = 0490621 Tapered section NOTE: (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160. [Released]
8. 4 = 0490625 Valve NOTE: (Non-return valve) [released]
9. 4 = 0490626 Filter NOTE: (Filter) 3 x 3 mm [released]
10. 9 = 0493129 Sensor NOTE: (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85 [released]
11. 2 = 0493387 Sensor NOTE: (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor / engine: M47, M57, M57TU, M57T2 [Released]
12. 4 = 0490620 Sensor NOTE: (Test probe) For recording compression testers 11 0 224 and 11 0 160 / engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129) [replaced]
13. 4 = 0490616 Card NOTE: (Cards) 100 pieces For recording compression tester 11 0 221 [released]
14. 2 = 0494517 Adapter NOTE: Measuring "absolute compression" at all cylinders. Engine: W17 [Released]
15. 4 = 0490622 Card NOTE: (Cards) 100 pieces For recording compression tester 11 0 224 [released]
16. 16 = 0495279 Adapter NOTE: Engine M67, M67TU [released]

11-0224 Compression tester

0490617 110224 Compression tester Minimum set: Mechanical tools MW

Note. (Compression tester) For petrol engines. [Released]

Scheme 78

11-0160 Compression tester

0490593 110160 Compression tester MW

Replaced by: 0490613

Note. (Compression recorder) manufacturer VDO - Replaced by 11 0 220 (0 490 613) [replaced]

Consisting of

1. = 0490594 Card NOTE: (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]
2. = 0490595 Pressure gauge NOTE: Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]
3. = 0490596 Guard NOTE: (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

Replaced by: 0490613

Note. (Compression recorder) manufacturer VDO - Replaced by 11 0 220 (0 490 613) [replaced]

Consisting of

1. = 0490594 Card NOTE: (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]
2. = 0490595 Pressure gauge NOTE: Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]
3. = 0490596 Guard NOTE: (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]
4. = 0490597 Line NOTE: Discontinued and replaced by 11 0 220. (0 490 613) [replaced]
5. = 0490598 Adapter NOTE: (test adapter for petrol engine: all, except M70 Discontinued and replaced by 11 0 220 (0 490 613) [replaced]
6. = 0490599 Adapter NOTE: (test adapter for petrol engine: M70Discontinued and replaced by 11 0 220 (0 490 613) [replaced]
7. = 0490600 Adapter NOTE: (Test adapter extension) Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

11-0221 Compression tester

0490614 110221 Compression tester Minimum set: Mechanical tools MW

Note. (Compression tester) For diesel engines [released]

11-8004 Connection

0491105 118004 Connection MW

Note. For compressed air in the spark plug holes [discontinued]

2249160 Device

2249160 Device MW

Note. For removing and installing torsion spring of intermediate lever. (S63TU) [released]

Storage Location

A32

SI number

01 19 11 (742)

Scheme 79

11-9000 Device

0494362 119000 Device Minimum set: Mechanical tools MW

Note. (Cylinder head clamping device) [Released]

Storage Location

Individual

SI number

01 03 02 (833)

Consisting of

1. = 0494366 Device NOTE: [Released]
2. = 0494367 Rod NOTE: [Released]
3. = 0494368 Adapter NOTE: (Sliding block) [Released]
4. = 0494369 Tab NOTE: [Released]
5. = 0494370 Quick fastener NOTE: [Released]
6. = 0494371 Insert NOTE: (Aluminum strip) [Released]
7. = 0494372 Shaped part NOTE: (Shaped part) [Replaced]
8. = 0494373 Shaped part NOTE: (Shaped part) Shaped part made of plastic [Released]
9. = 0494374 Lever NOTE: [Released]
10. = 0494375 Hook NOTE: [Released]
11. = 0494376 Basket NOTE: (Valve spring cage) Engine M41, M51, S50 [Released]
12. = 0494377 Basket NOTE: (Valve spring cage) Engine M43, M73 [Released]
13. = 0494378 Basket NOTE: (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62 [Released]
14. = 0494379 Basket NOTE: (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73 [Released]
15. = 0494380 Basket NOTE: (Valve spring cage) Engine M21, M40 [Released]

1. 17 = 0495028 Basket NOTE: (Valve spring cage) Engine N52 [Released]

11-9510 Device

0495471 119510 Device MW

Note. For mounting the radial shaft seal of the crankshaft, front. [Discontinued]

Consisting of

1. = 0495472 Basic body NOTE: [Discontinued]
2. = 0495473 Screw NOTE: (Screws (2 pieces)) [Discontinued]
3. = 0495474 Holding sleeve NOTE: (Sliding sleeve) [blocked]
4. = 0495475 Holding sleeve NOTE: (Pressure sleeve) Can no longer be ordered separately. Only available as part of set 11 5 330 = 83 30 0 495 127. [Blocked]
5. = 0495476 nut NOTE: (Nut with bearing) Can no longer be ordered separately. Only available as part of set 31 2 120 = 83 30 0 491 909. [Blocked]

11-8080 Device

0496408 118080 Device MW

Note. (Pressure testing fixture) For leakage test on cylinder head. [Released]

SI number

01 06 08 (437)

Consisting of

Scheme 80

1. = 0496409 Plate NOTE: Liquidation of existing inventory and then available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12 [Not available separately]
2. = 0496410 Valve NOTE: Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12. [Not available separately]
3. = 0496411 Screw NOTE: Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12. [Not available separately]
4. = 0496412 Gasket NOTE: Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12. [Not available separately]

11-7040 Device

0495456 117040 Device MW

Note. (Pressure testing fixture) For sealing coolant openings when pressure-testing cylinder head on watertightness. [Released]

SI number

01 14 05 (198)

Consisting of

Scheme 81

1. = 0495463 Plate NOTE: (Adapter plate (large) with gasket) Discontinued, only available via complete tool [Not available separately]
2. = 0495464 Gasket NOTE: (Gasket for 11 7 041) Discontinued, only available via complete tool [Not available separately]
3. = 0495465 Plate NOTE: (Adapter plate (small) with gasket) Discontinued, only available via complete tool [Not available separately]
4. = 0495466 Gasket NOTE: (Gasket for 11 7 043) Discontinued, only available via complete tool [Not available separately]
5. = 0495467 Screw NOTE: (Set - screws) Discontinued, only available via complete tool [Not available separately]

11-9900 Device

0496360 119900 Device MW

Note. To pretension the timing chain when adjusting the timings. [Released]

Storage Location

B54

C54

SI number

01 06 08 (437)

Consisting of

Scheme 82

1. = 0496384 Shaped part NOTE: Available only as a complete tool set 11 9 900 (83 30 0 496 360) - as of 23.01.12 [Not available separately]
2. = 0496385 Screw NOTE: Available only as a complete tool set 11 9 900 (83 30 0 496 360) - as of 23.01.12 [Not available separately]

2249162 Device

2249162 Device MW

Note. Device for preloading timing chain when adjusting timing. (S63TU) [released]

Storage Location

B31

SI number

01 19 11 (742)

Scheme 83

11-2110 Device

0490826 112110 Device MW

Replaced by: 0490504

Note. For retightening the connecting rod and cylinder head bolts - Replaced by 00 9 120 (0 490 504) [replaced]

Consisting of

1. = 0490827 Extension NOTE: (Extension 1/1") Replaced by 00 9 120 (0 490 504) [replaced]
2. = 0490828 Washer NOTE: (Graduated disc 180°) Replaced by 00 9 120 (0 490 504) [replaced]
3. = 0490829 Holding sleeve NOTE: (Guide sleeve) Replaced by 00 9 120 (0 490 504) [replaced]
4. = 0490830 nut NOTE: (Knurled nut) Replaced by 00 9 120 (0 490 504) [replaced]
5. = 0490831 Socket wrench insert NOTE: (Socket wrench insert WAF 10) Replaced by 00 9 120 (0 490 504) [replaced]
6. = 0490832 Washer NOTE: (Graduated disc up to 270°) Replaced by 00 9 120 (0 490 504) [replaced]
7. = 0490833 Tab NOTE: For counter-holding on the cylinder head Replaced by 00 9 120 (0 490 504) [replaced]
8. = 0490834 Adapter NOTE: (Adapter) Replaced by 00 9 120 (0 490 504) [replaced]

11-8910 Device

0496368 118910 Device MW

Note. (Fixing device) For limiting the tilting motion of the engine when the transmission is removed or installed. [Released]

SI number

01 24 08 (501)

Consisting of

Scheme 84

1. = 0496572 Basic body NOTE: [Discontinued]
2. = 0496573 Upholstery NOTE: [Discontinued]
3. = 0496574 Spindle NOTE: [Discontinued]
4. = 0496575 Screw NOTE: (Screws (2 pieces)) [Discontinued]

11-9001 Device

0494366 119001 Device Minimum set: Mechanical tools MW

Note. [Released]

11-6140 Device

0491071 116140 Device MW

Note. (Testing device) For checking of control valve charging pressure [discontinued]

11-4080 Device

0491008 114080 Device MW

Replaced by: 0491007

Note. For installation of the dipstick guide tube - Replaced by 11 4 070 (0 491 007) [replaced]

11-6251 Dial gauge

0493144 116251 Dial gauge MW

Note. (Dial gauge) With 0.8 mm measuring range in each direction [Released]

Scheme 85

11-2111 Extension

0490827 112111 Extension MW

Replaced by: 0490504

Note. (Extension 1/1") Replaced by 00 9 120 (0 490 504) [replaced]

11-9410 Extractor

0493923 119410 Extractor Minimum set: Mechanical tools MW

Note. For pulling radial seal out of engine block at front [released]

Storage Location

A45

SI number

01 14 01 (766)

Scheme 86

11-2000 Extractor

0490798 112000 Extractor Minimum set: Mechanical tools MW

Note. For crankshaft sprocket [released]

Storage Location

A8

Consisting of

Scheme 87

1. 7 = 0494316 Synchronising key NOTE: Engine: N73 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

1. = 0490799 Bell housing NOTE: Liquidation of existing inventory and after that available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]
2. = 0490800 Plate NOTE: (Plate) Engine: M10, M30, S14, S38, N73 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]
3. = 0490801 Spindle NOTE: Engine: M10, M30, M70, M73, S14, S38, N73 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]
4. = 0490802 Plate NOTE: Engine: M50, M52, M60, M62 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]
5. = 0490803 Spindle NOTE: (Spindle 165 mm) Engine: M50, M52, M60, M62 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]
6. = 0490804 Plate NOTE: (Plate) Engine: M70, M73, N73 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

11-4472 Extractor

0495104 114472 Extractor Minimum set: Mechanical tools MW

Note. (Grindstone) [Released]

Storage Location

B52

Scheme 88

11-0234 Filter

0490626 110234 Filter Minimum set: Mechanical tools MW

Note. (Filter) 3 x 3 mm [released]

11-0331 Fitting aid

0495377 110331 Fitting aid Minimum set: Mechanical tools MW

Note. (Mounting tool) Remaining inventories will be sold off followed by discontinuation - then no longer available individually. Can only be ordered as part of the complete special tool set 83 30 0 495 334 (special tool number 11 0 330). [Not available separately]

Scheme 89

11-0330 Fitting aid

0495334 110330 Fitting aid Minimum set: Mechanical tools MW

Note. (Mounting tool) For installing elasto-belt. [Released]

Storage Location

C53

B53

SI number

01 13 05 (197)

Consisting of

1. = 0495377 Fitting aid NOTE: (Mounting tool) Remaining inventories will be sold off followed by discontinuation - then no longer available individually. Can only be ordered as part of the complete special tool set 83 30 0 495 334 (special tool number 11 0 330). [Not available separately]
2. = 0495378 Ring NOTE: (Adapter ring) Remaining inventories will be sold off followed by discontinuation - then longer available individually. Can only be ordered as part of the complete special tool set 83 30 0 495 334 (special tool number 11 0 330). [Not available separately]

11-8152 Fitting aid

0494678 118152 Fitting aid MW

Note. Liquidation of existing inventory and then available only as a complete tool set 11 8 150 (83 30 0 493 583) - as of 26.01.12 [Not available separately]

Scheme 90

11-8150 Fitting aid

0493583 118150 Fitting aid MW

Note. For removing and installing connecting rods [released]

Storage Location

B2

C2

SI number

01 12 99 (452)

Consisting of

1. = 0494677 Assembly tool NOTE: Liquidation of existing inventory and then available only as a complete tool set 11 8 150 (83 30 0 493 583) - as of 26.01.12 [Not available separately]
2. = 0494678 Fitting aid NOTE: Liquidation of existing inventory and then available only as a complete tool set 11 8 150 (83 30 0 493 583) - as of 26.01.12 [Not available separately]

11-6090 Fixture

0495217 116090 Fixture MW

Note. (Fixture) For supporting the engine on the assembly stand [Released]

SI number

01 05 05 (180)

Scheme 91

11-8930 Fixture

0496370 118930 Fixture MW

Note. (Engine support) For supporting the engine on the engine assembly stand. [Released]

SI number

01 06 08 (437)

Consisting of

Scheme 92

1. = 0496377 Fixture NOTE: (Engine mount) [released]
2. = 0496378 Screw NOTE: (Set of screws) Can only be ordered as part of complete tool 11 9 660 = 0495955 [Released]

11-8931 Fixture

0496377 118931 Fixture MW

Note. Liquidation of existing inventory and then available only as a complete tool set 11 8 930 (83 30 0 496 370) - as of 13.03.12 [Not available separately]

11-6100 Fixture

0495218 116100 Fixture MW

Note. (Fixture) For supporting the engine on the assembly stand [Released]

SI number

01 06 05 (181)

Scheme 93

11-7044 Gasket

0495466 117044 Gasket MW

Note. (Gasket for 11 7 043) Discontinued, only available via complete tool [Not available separately]

SI number

01 14 05 (198)

11-7042 Gasket

0495464 117042 Gasket MW

Note. (Gasket for 11 7 041) Discontinued, only available via complete tool [Not available separately]

SI number

01 14 05 (198)

11-8084 Gasket

0496412 118084 Gasket MW

Note. Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12. [Not available separately]

11-6270 Gauge

0493305 116270 Gauge MW

Note. For securing counterbalance shafts in the working position [Released]

SI number

01 04 98 (304)

Scheme 94

2249144 Gauge

2249144 Gauge MW

Note. Gauge, intake, bank 2. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]

Scheme 95

2249159 Gauge

2249159 Gauge MW

Note. Gauge, exhaust camshaft, bank 2. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]

Scheme 96

11-9893 Gauge

0496381 119893 Gauge MW

Note. (Gauges) [released]

Scheme 97

2249140 Gauge

2249140 Gauge MW

Note. Gauge, exhaust camshaft, bank 1. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]

Scheme 98

11-6300 Gauge

0495219 116300 Gauge Minimum set: Mechanical tools MW

Note. For adjusting distance dimension of U-socket on turbocharger. Application: Engine M57TU 535d (Top) [Released]

Storage Location

C52

SI number

01 05 05 (180)

Scheme 99

2249117 Gauge

2249117 Gauge MW

Note. For securing camshaft at TDC. (S63TU) [released]

Storage Location

B31, C31

SI number

01 19 11 (742)

Consisting of

Scheme 100

1. 4 = 2249159 Gauge NOTE: Gauge, exhaust camshaft, bank 2. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]
2. 3 = 2249144 Gauge NOTE: Gauge, intake, bank 2. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]
3. 2 = 2249140 Gauge NOTE: Gauge, exhaust camshaft, bank 1. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]
4. 1 = 2249137 Gauge NOTE: Gauge, intake, bank 1. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]

11-9890 Gauge

0496359 119890 Gauge MW

Note. For fixing the camshaft in place when adjusting the valve timing. [Released]

Storage Location

C54

C53

SI number

01 06 08 (437)

Consisting of

Scheme 101

1. 5 = 0496383 Adapter NOTE: (Adapter N74) [released]
2. 4 = 0496382 Adapter NOTE: (Adapter N63) [released]
3. 3 = 0496381 Gauge NOTE: (Gauges) [released]
4. 2 = 0496380 Bridge NOTE: [Released]
5. 1 = 0496379 Handle NOTE: (Rotary handle) [released]

2249137 Gauge

2249137 Gauge MW

Note. Gauge, intake, bank 1. Can only be ordered via complete set 83 30 2 249 117. [Not available separately]

Scheme 102

2249171 Gauge

2249171 Gauge MW

Note. For positioning the exhaust turbocharger during installation. (S63TU) [released]

Storage Location

A31, A32

SI number

01 19 11 (742)

Scheme 103

11-0163 Guard

0490596 110163 Guard MW

Replaced by: 0490613

Note. (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

11-9891 Handle

0496379 119891 Handle MW

Note. (Rotary handle) [released]

Scheme 104

11-9261 Holder

0494034 119261 Holder Minimum set: Mechanical tools MW

Note. (Individual counter support) [Released]

11-9450 Holder

0493926 119450 Holder Minimum set: Mechanical tools MW

Note. (Counter support with socket and needle) For counter support of crankshaft when releasing/tightening down central bolt [released]

Storage Location

A45

SI number

01 14 01 (766)

Consisting of

Scheme 105

1. 2 = 0494228 Washer NOTE: Height 22.5 mm with hexagon screw [released]
2. 3 = 0494229 Needle NOTE: [Released]
3. 5 = 0494317 Washer NOTE: Height 10 mm with hexagon screw [released]
4. 1 = 0494227 Lever NOTE: [Released]
5. 4 = 0494230 Socket WAF 46 NOTE: (Socket, AF 27) [released]

11-8920 Holder

0496369 118920 Holder MW

Note. (Counter support) For removal of oil pump flange. [Released]

Storage Location

A54

SI number

01 06 08 (437)

Scheme 106

11-4491 Holder

0495010 114491 Holder MW

Note. (Assembly holder) [Released]

Storage Location

A51

Scheme 107

11-8001 Holder

0491102 118001 Holder MW

Note. (Holder) Discontinuation and replaced by 36 1 030. (0 493 829) [discontinued]

11-8090 Holder

0496365 118090 Holder MW

Note. (Counter support) For releasing central bolt. [Released]

Storage Location

B53

C53

SI number

01 06 08 (437)

Scheme 108

11-9260 Holder

0493938 119260 Holder Minimum set: Mechanical tools MW

Note. (Counter support with screw connection) For holding the flywheel when gearbox is removed [Released]

Storage Location

B43

SI number

01 01 01 (662)

Consisting of

1. = 0494034 Holder NOTE: (Individual counter support) [Released]
2. = 0494035 Screw NOTE: (Screw (M10 thread) with washer) For screwing counter support [Released]
3. = 0494129 Bush NOTE: (Bush for counter support) For counter support, for retaining flywheel when gearbox is removed Engine: N62, N73 [Released]
4. = 0494130 Screw NOTE: (Screw (M12 thread)) For counter support for retaining flywheel when gearbox is removed [Released]
5. = 0494793 Bush NOTE: [Released]
6. = 0495216 Bush NOTE: For counter support, for retaining flywheel when gearbox is removed Engine: M57TU2 [Released]

11-9280 Holder

0493940 119280 Holder Minimum set: Mechanical tools MW

Note. (Counter support) For the crankshaft when releasing/tightening the central bolt [Released]

Storage Location

A43

B43

C43

SI number

01 01 01 (662)

Scheme 109

11-6111 Holder

0495275 116111 Holder MW

Note. (Assembly holder) Not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]

Storage Location

C52

Scheme 110

11-8002 Holder

0491103 118002 Holder MW

Note. (Holder) Discontinuation and replaced by 36 1 030. (0 493 829) [discontinued]

11-2220 Holder

0490853 112220 Holder MW

Replaced by: 0490855

Note. (Counter support) - Nov. 88 Replaced by 11 2 240 (0 490 855) [Replaced]

11-2113 Holding sleeve

0490829 112113 Holding sleeve MW

Replaced by: 83300490504

Note. (Guide sleeve) Replaced by 00 9 120 (0 490 504) [replaced]

11-3370 Holding sleeve

0495310 113370 Holding sleeve MW

Note. (Sleeve) For fitting the valve stem seal [Blocked]

11-1380 Holding sleeve

0490746 111380 Holding sleeve MW

Note. (Assembly sleeve) For fitting the valve stem seal, diameter 7 mm [Released]

Scheme 111

11-6020 Holding sleeve

0491065 116020 Holding sleeve MW

Note. (Centring sleeve) For turbo exhaust manifold - Discontinuation since January 84 [Discontinued]

11-1350 Holding sleeve

0490743 111350 Holding sleeve MW

Replaced by: 0490744

Note. (Assembly sleeves) For fitting the valve stem seal - Replaced by 11 1 360 (0 490 744) [replaced]

11-9514 Holding sleeve

0495475 119514 Holding sleeve MW

Note. (Pressure sleeve) Can no longer be ordered separately. Only available as part of set 11 5 330 = 83 30 0 495 127. [Blocked]

11-9513 Holding sleeve

0495474 119513 Holding sleeve MW

Note. (Sliding sleeve) [blocked]

11-9011 Hook

0494375 119011 Hook Minimum set: Mechanical tools MW

Note. [Released]

11-0225 Hose

0490618 110225 Hose Minimum set: Mechanical tools MW

Note. (Extension hose) For rubber tapered section with fitting 11 0 228 [discontinued]

11-9006 Insert

0494371 119006 Insert Minimum set: Mechanical tools MW

Note. (Aluminum strip) [Released]

11-9009 Lever

0494374 119009 Lever Minimum set: Mechanical tools MW

Note. [Released]

Scheme 112

2249166 Lever

2249166 Lever MW

Note. For positioning the link block during installation. (S63TU, N63TU) [released]

Storage Location

A31

SI number

01 19 11 (742)

Scheme 113

11-9451 Lever

0494227 119451 Lever Minimum set: Mechanical tools MW

Note. [Released]

Storage Location

A45

11-0021 Lifting gear

0490568 110021 Lifting gear Minimum set: Mechanical tools MW

Note. (Cross member) As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0001 Lifting gear

0490562 110001 Lifting gear Minimum set: Mechanical tools MW

Note. (Cross member) As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-0000 Lifting gear

0490561 110000 Lifting gear Minimum set: Mechanical tools MW

Note. (Hoisting gear) For removing and installing engines. As of 08/2011 only available as a complete set. Delivered with TUV inspection certificate and operating instructions. No delivery of separate parts. [Released]

Scheme 114

SI number

01 13 94 (888)

Consisting of

1. = 0490562 Lifting gear NOTE: (Cross member) As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Blocked]
2. = 0490563 Chain NOTE: (Chain) Version: long As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Blocked]
3. = 0490564 Chain NOTE: (Chain) Version: short As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Blocked]
4. = 0490565 Shackle NOTE: (Shackle) 2 pieces As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Blocked]

11-0020 Lifting gear

0490567 110020 Lifting gear Minimum set: Mechanical tools MW

Note. For removing and installing engines. 08/2011 only available as a complete set. Delivered with TUV inspection certificate and operating instructions. No delivery of separate parts. [Released]

Scheme 115

SI number

01 13 94 (888)

Consisting of

1. = 0490568 Lifting gear NOTE: (Cross member) As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Blocked]
2. = 0490569 Chain NOTE: (Chain) As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Blocked]
3. = 0490570 Chain NOTE: (Chain) Version: long As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Blocked]
4. = 0490571 Chain NOTE: (Chain) Version: short As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Blocked]
5. = 0490572 Shackle NOTE: (Shackle) 2 pieces As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Blocked]

11-0164 Line

0490597 110164 Line MW

Replaced by: 0490613

Note. Discontinued and replaced by 11 0 220. (0 490 613) [replaced]

11-1170 Mandrel

0490721 111170 Mandrel MW

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724) [Replaced]

11-1160 Mandrel

0490720 111160 Mandrel MW

Note. (Drift) For separated valve guides - discontinued since April 93 [Discontinued]

11-6113 Mandrel

0495277 116113 Mandrel MW

Note. (Assembly mandrel) Remaining inventories will be sold off, followed by discontinuation and then not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]

Storage Location

C51

11-9190 Mandrel

0493882 119190 Mandrel Minimum set: Mechanical tools MW

Note. (Alignment pin) For securing flywheel in TDC setting [Released]

Storage Location

B43

SI number

01 01 01 (662)

Scheme 116

11-1080 Mandrel

0490709 111080 Mandrel MW

Note. (Mandrel) For valve stem seal [discontinued]

11-1090 Mandrel

0490710 111090 Mandrel MW

Note. (Drift) For valve stem seal with offset valve guides [Discontinued]

11-1120 Mandrel

0490716 111120 Mandrel MW

Note. (Pressing-in mandrel) For non-offset valve guides for pressing in the valve guides on 4- and 6-cylinder engine - Discontinuation since April 93 [Discontinued]

11-1320 Mandrel

0490740 111320 Mandrel MW

Note. (Drift for valve guide) discontined since April 93 [Discontinued]

11-1330 Mandrel

0490741 111330 Mandrel MW

Note. (Drive out mandrel for valve guide) discontinued since April of 93 [discontinued]

11-4494 Mandrel

0495013 114494 Mandrel MW

Note. (Assembly mandrel) [Released]

Storage Location

A51

11-6080 Mandrel

0495215 116080 Mandrel Minimum set: Mechanical tools MW

Note. (Alignment pin) For securing flywheel at TDC setting [released]

Storage Location

C52

SI number

01 05 05 (180)

Scheme 117

11-1190 Mandrel

0490723 111190 Mandrel MW

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724) [Replaced]

11-1140 Mandrel

0490718 111140 Mandrel MW

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724) [Replaced]

11-1100 Mandrel

0490711 111100 Mandrel MW

Note. For press-out of valve guide for 4 and 6-cylinder engines, discontinued since April of 93 [discontinued]

2213485 Measurement aid

2213485 Measurement aid MW

Note. For checking and adjusting the chain play of the oil pump. [Released]

Storage Location

C30

Scheme 118

11-6250 Measuring device

0493143 116250 Measuring device MW

Note. (Measuring device) Sensing arm measuring device With small tripod for measuring tooth flank and side clearance on counterbalance shafts, camshafts and crankshafts. [Released]

SI number

01 04 98 (304)

Consisting of

1. 3 = 0493146 Sensor NOTE: (Sensor) Sensor arm 11.5 mm [Discontinued]
2. 1 = 0493144 Dial gauge NOTE: (Dial gauge) With 0.8 mm measuring range in each direction [Released]
3. 2 = 0493145 Tripod NOTE: (Small hydraulic tripod with magnetic base) [Released]
4. 4 = 0495214 Plate NOTE: (Fixture) Engine: M47T2; M57T2; S85 [Released]
5. 5 = 0495468 Plate NOTE: (Fixture M7) Engine camshaft: M67TU [Released]
6. 6 = 0495470 Plate NOTE: (Fixture M8) Engine crankshaft: M67TU [Released]

11-9453 Needle

0494229 119453 Needle Minimum set: Mechanical tools MW

Note. [Released]

Storage Location

A45

11-9240 Oil filter wrench

0493936 119240 Oil filter wrench Minimum set: Mechanical tools MW

Note. For unfastening and tightening oil filter cover [released]

Storage Location

A43

SI number

01 01 01 (662)

Scheme 119

11-4010 Oil filter wrench

0491001 114010 Oil filter wrench MW

Note. (Oil filter wrench) Discontinued since January of 84 [discontinued]

32-2100 Open-end wrench

0492027 322100 Open-end wrench MW

Note. (Open-end wrench AF 27) For adjusting left track rod on rack [released]

Storage Location

Y4

Scheme 120

11-0050 Open-end wrench

0490575 110050 Open-end wrench MW

Note. For tensioning the V-belt - Only for series H. Laub [Discontinued]

11-7200 Open-end wrench insert

0493434 117200 Open-end wrench insert MW

Note. (Open-end wrench insert) Open-end wrench SW 10 for tightening the VANOS transmission screw connection [released]

Storage Location

C10

SI number

01 23 98 (390)

Scheme 121

11-0390 Pin

0496268 110390 Pin Minimum set: Mechanical tools MW

Note. (roll pin) For securing new tensioning pulley (poly-V belt) [released]

Storage Location

C23

SI number

01 15 07 (390)

Scheme 122

11-3340 Pin

0490973 113340 Pin Minimum set: Mechanical tools MW

Note. (Lock pin (2 pieces)) For retaining the chain tensioner piston (e.g. when removing and installing the cylinder head) and to lock the drive belt tensioner [Discontinued]

Storage Location

B5

C5

SI number

01 09 91 (416)

Scheme 123

11-4120 Pin

0491012 114120 Pin Minimum set: Mechanical tools MW

Note. (Lock pin) For chain tensioners, for retaining the chain tensioner piston (e.g. during cylinder head removal and fitting) [Released]

Storage Location

B5

C5

SI number

01 12 93 (701)

Scheme 124

11-7043 Plate

0495465 117043 Plate MW

Note. (Adapter plate (small) with gasket) Discontinued, only available via complete tool [Not available separately]

SI number

01 14 05 (198)

11-2004 Plate

0490802 112004 Plate Minimum set: Mechanical tools MW

Note. Engine: M50, M52, M60, M62 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-6255 Plate

0495468 116255 Plate MW

Note. (Fixture M7) Engine camshaft: M67TU [Released]

Storage Location

B20

SI number

01 14 05 (198)

11-7041 Plate

0495463 117041 Plate MW

Note. (Adapter plate (large) with gasket) Discontinued, only available via complete tool [Not available separately]

SI number

01 14 05 (198)

11-6254 Plate

0495214 116254 Plate MW

Note. (Fixture) Engine: M47T2; M57T2; S85 [Released]

SI number

01 05 05 (180)

Scheme 125

11-2002 Plate

0490800 112002 Plate Minimum set: Mechanical tools MW

Note. (Plate) Engine: M10, M30, S14, S38, N73 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-6256 Plate

0495470 116256 Plate MW

Note. (Fixture M8) Engine crankshaft: M67TU [Released]

Storage Location

B20

SI number

01 14 05 (198)

11-2006 Plate

0490804 112006 Plate Minimum set: Mechanical tools MW

Note. (Plate) Engine: M70, M73, N73 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-8081 Plate

0496409 118081 Plate MW

Note. Liquidation of existing inventory and then available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12 [Not available separately]

11-5430 Pliers

0495308 115430 Pliers MW

Note. (Piston ring pliers) Diameter 93 mm engine N62TU B48 [Released]

Storage Location

A20

B20

Scheme 126

11-4000 Pliers

0491000 114000 Pliers MW

Note. (Special pliers for oil filter cartridges) Discontinued since January of 84 [discontinued]

11-7280 Pliers

0494310 117280 Pliers MW

Note. (Piston ring pliers) For installing the pistons with connecting rod into crankcase (for 89 mm diameter). [Released]

Storage Location

C42

B42

SI number

01 14 02 (939)

Scheme 127

11-4493 Pliers

0495012 114493 Pliers MW

Note. (Installation pliers) [Released]

Storage Location

A51

11-1250 Pliers

0490728 111250 Pliers MW

Replaced by: 0490796

Note. For removing and installing the valve stem seal. Only free for motorcycle! Replaced by 11 1 480 (0 490 796) [replaced]

11-4492 Pliers

0495011 114492 Pliers MW

Note. (Removal pliers) [Released]

Storage Location

A51

11-2090 Pliers

0490824 112090 Pliers MW

Replaced by: 0490796

Note. For removal of the valve stem seals - Replaced by 11 1 480 (0 490 796) [Replaced]

Scheme 128

11-6112 Pliers

0495276 116112 Pliers MW

Note. (Assembly pliers) Not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]

Storage Location

C51

Scheme 129

11-0162 Pressure gauge

0490595 110162 Pressure gauge MW

Replaced by: 0490613

Note. Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613) [replaced]

11-9005 Quick fastener

0494370 119005 Quick fastener Minimum set: Mechanical tools MW

Note. [Released]

11-8732 Ring

0496306 118732 Ring Minimum set: Mechanical tools MW

Note. (Sealing ring) For secure connection of test probe 11 0 222 and adapter 11 8 730/731. [Released]

SI number

01 16 07 (392)

11-0332 Ring

0495378 110332 Ring Minimum set: Mechanical tools MW

Note. (Adapter ring) Remaining inventories will be sold off followed by discontinuation - then longer available individually. Can only be ordered as part of the complete special tool set 83 30 0 495 334 (special tool number 11 0 330). [Not available separately]

11-6000 Ring spanner

0491063 116000 Ring spanner MW

Note. (Special ring spanner) for exhaust manifold [Discontinued]

11-8600 Ring spanner

0496327 118600 Ring spanner MW

Note. For tightening down exhaust turbocharger screw connection with torque wrench. [Released]

Storage Location

C48

SI number

01 23 07 (412)

Scheme 130

11-0040 Ring spanner

0490574 110040 Ring spanner MW

Note. For tensioning the V-belt - Only for series H. Laub [Discontinued]

11-9002 Rod

0494367 119002 Rod Minimum set: Mechanical tools MW

Note. [Released]

11-8003 Rod

0491104 118003 Rod MW

Note. [Discontinued]

11-4471 Scraper

0495103 114471 Scraper Minimum set: Mechanical tools MW

Note. [Released]

Storage Location

B52

Scheme 131

11-9902 Screw

0496385 119902 Screw MW

Note. Available only as a complete tool set 11 9 900 (83 30 0 496 360) - as of 23.01.12 [Not available separately]

11-8914 Screw

0496575 118914 Screw MW

Note. (Screws (2 pieces)) [Discontinued]

11-9262 Screw

0494035 119262 Screw Minimum set: Mechanical tools MW

Note. (Screw (M10 thread) with washer) For screwing counter support [Released]

11-8932 Screw

0496378 118932 Screw MW

Note. (Set of screws) Can only be ordered as part of complete tool 11 9 660 = 0495955 [Released]

11-8083 Screw

0496411 118083 Screw MW

Note. Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12. [Not available separately]

11-7410 Screw

0494044 117410 Screw MW

Note. For installing the radial shaft seal [released]

Storage Location

C45

SI number

01 10 01 (733)

Scheme 132

11-9264 Screw

0494130 119264 Screw Minimum set: Mechanical tools MW

Note. (Screw (M12 thread)) For counter support for retaining flywheel when gearbox is removed [Released]

Storage Location

A45

11-7045 Screw

0495467 117045 Screw MW

Note. (Set - screws) Discontinued, only available via complete tool [Not available separately]

SI number

01 14 05 (198)

11-9512 Screw

0495473 119512 Screw MW

Note. (Screws (2 pieces)) [Discontinued]

11-0236 Sensor

0493387 110236 Sensor Minimum set: Mechanical tools MW

Note. (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor / engine: M47, M57, M57TU, M57T2 [Released]

Scheme 133

11-0226 Sensor

0490619 110226 Sensor Minimum set: Mechanical tools MW

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160 / engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62 [released]

Scheme 134

11-0235 Sensor

0493129 110235 Sensor Minimum set: Mechanical tools MW

Note. (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85 [released]

Scheme 135

11-0227 Sensor

0490620 110227 Sensor Minimum set: Mechanical tools MW

Replaced by: 0493129

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160 / engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129) [replaced]

11-0222 Sensor

0490615 110222 Sensor Minimum set: Mechanical tools MW

Note. (Test probe) For recording compression testers 11 0 221 and 11 0 160 / engine: M21, M41, M47, M51, M57, M57T2 [released]

Scheme 136

11-6253 Sensor

0493146 116253 Sensor MW

Note. (Sensor) Sensor arm 11.5 mm [Discontinued]

11-0009 Shackle

0490565 110009 Shackle Minimum set: Mechanical tools MW

Note. (Shackle) 2 pieces As of 08/2001, only available as a complete set via 11 0 000 = 0490561. Delivered with TUV inspection certificate and operating instructions. [Blocked]

11-0029 Shackle

0490572 110029 Shackle Minimum set: Mechanical tools MW

Note. (Shackle) 2 pieces As of 08/2011, only available as a complete set via 11 0 020 = 0490567. Delivered with TUV inspection certificate and operating instructions. [Not available separately]

11-9901 Shaped part

0496384 119901 Shaped part MW

Note. Available only as a complete tool set 11 9 900 (83 30 0 496 360) - as of 23.01.12 [Not available separately]

11-9007 Shaped part

0494372 119007 Shaped part Minimum set: Mechanical tools MW

Note. (Shaped part) [Discontinued]

11-9008 Shaped part

0494373 119008 Shaped part Minimum set: Mechanical tools MW

Note. (Shaped part) Shaped part made of plastic [Released]

Scheme 137

11-8720 Socket WAF 46

0496106 118720 Socket WAF 46 Minimum set: Mechanical tools MW

Note. (Long socket SW24) For removal and installation of oil pressure sensor. (Stahlwille or HAZET) [released]

Storage Location

A24

SI number

01 04 07 (352)

Scheme 138

11-9454 Socket WAF 46

0494230 119454 Socket WAF 46 Minimum set: Mechanical tools MW

Note. (Socket, AF 27) [released]

Storage Location

A45

11-2115 Socket wrench insert

0490831 112115 Socket wrench insert MW

Replaced by: 0490504

Note. (Socket wrench insert WAF 10) Replaced by 00 9 120 (0 490 504) [replaced]

11-7020 Socket wrench insert

0491074 117020 Socket wrench insert Minimum set: Mechanical tools MW

Note. (Socket wrench insert WAF 22) For releasing and tightening the oxygen sensor [Released]

Storage Location

A9

Scheme 139

11-2005 Spindle

0490803 112005 Spindle Minimum set: Mechanical tools MW

Note. (Spindle 165 mm) Engine: M50, M52, M60, M62 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-2003 Spindle

0490801 112003 Spindle Minimum set: Mechanical tools MW

Note. Engine: M10, M30, M70, M73, S14, S38, N73 Liquidation of existing inventory and available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-8913 Spindle

0496574 118913 Spindle MW

Note. [Discontinued]

11-2007 Synchronising key

0494316 112007 Synchronising key Minimum set: Mechanical tools MW

Note. Engine: N73 Available only as a complete tool set 11 2 000 = 83 30 0 490 798 - as of 30.11.2011 [not available separately]

Storage Location

A8

11-9004 Tab

0494369 119004 Tab Minimum set: Mechanical tools MW

Note. [Released]

11-2117 Tab

0490833 112117 Tab MW

Replaced by: 0490504

Note. For counter-holding on the cylinder head Replaced by 00 9 120 (0 490 504) [replaced]

11-0228 Tapered section

0490621 110228 Tapered section Minimum set: Mechanical tools MW

Note. (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160. [Released]

11-8000 Tool

0491101 118000 Tool MW

Note. (Device) For changing the valve springs with mounted engine cylinder head M88 [discontinued]

Consisting of

1. = 0491102 Holder NOTE: (Holder) Discontinuation and replaced by 36 1 030. (0 493 829) [discontinued]
2. = 0491103 Holder NOTE: (Holder) Discontinuation and replaced by 36 1 030. (0 493 829) [discontinued]
3. = 0491104 Rod NOTE: [Discontinued]
4. = 0491105 Connection NOTE: For compressed air in the spark plug holes [discontinued]

11-6370 Tool

0493248 116370 Tool MW

Note. (Extractor tool) For pulling off the valve stem seal [released]

Storage Location

B15

SI number

01 06 98 (306)

Scheme 140

11-8570 Tool

0496366 118570 Tool MW

In conjunction with: 11 9 190

Note. (Holding fixture) For holding the engine at TDC. [Released]

Storage Location

A54

SI number

01 06 08 (437)

Scheme 141

11-4470 Tool

0495102 114470 Tool Minimum set: Mechanical tools MW

Note. (cleaning kit) For cleaning sealing surfaces on magnesium crankcase/cylinder head. [Released]

Storage Location

B52

SI number

01 17 04 (130)

Consisting of

Scheme 142

1. = 0495103 Scraper NOTE: [Released]
2. = 0495104 Extractor NOTE: (Grindstone) [Released]

11-9420 Tool

0493924 119420 Tool Minimum set: Mechanical tools MW

Note. (Pulling device) For installing the RWDR in the gear case cover at the bottom [released]

Storage Location

C45

SI number

01 14 01 (766)

Scheme 143

11-6110 Tool set

0495274 116110 Tool set MW

Note. (Tool set) For removal and installation of gudgeon pin circlamps. [Released]

Storage Location

C52

SI number

01 05 05 (180)

Consisting of

1. = 0495275 Holder NOTE: (Assembly holder) Not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]
2. = 0495276 Pliers NOTE: (Assembly pliers) Not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]
3. = 0495277 Mandrel NOTE: (Assembly mandrel) Remaining inventories will be sold off, followed by discontinuation and then not available individually, but as part of set 11 6 110 (0495274) only. [Not available separately]

11-4350 Torque wrench

0495018 114350 Torque wrench Minimum set: Mechanical tools MW

Note. For installing camshaft bearing strips. Adjustment range 2 to 6 Nm. [Enabled]

Storage Location

A51

SI number

01 02 10 (618)

Scheme 144

11-6252 Tripod

0493145 116252 Tripod MW

Note. (Small hydraulic tripod with magnetic base) [Released]

11-8912 Upholstery

0496573 118912 Upholstery MW

Note. [Discontinued]

11-3000 Upholstery

0490899 113000 Upholstery MW

Note. (Support board) For removed camshaft, rocker arm axles, rocker arm, valve spring and valve [discontinued]

11-8082 Valve

0496410 118082 Valve MW

Note. Available only as a complete tool set 11 8 080 (83 30 0 496 408) - as of 31.01.12.[Not available separately]

11-0233 Valve

0490625 110233 Valve Minimum set: Mechanical tools MW

Note. (Non-return valve) [released]

11-2116 Washer

0490832 112116 Washer MW

Replaced by: 0490504

Note. (Graduated disc up to 270°) Replaced by 00 9 120 (0 490 504) [replaced]

11-2112 Washer

0490828 112112 Washer MW

Replaced by: 0490504

Note. (Graduated disc 180°) Replaced by 00 9 120 (0 490 504) [replaced]

11-9452 Washer

0494228 119452 Washer Minimum set: Mechanical tools MW

Note. Height 22.5 mm with hexagon screw [released]

Storage Location

A45

11-3460 Washer

0490996 113460 Washer Minimum set: Mechanical tools MW

Note. (Timing disc) For fitting on counter support 11 2 450 when tightening central bolt using torsion angle adjustment [released]

Storage Location

C1

SI number

01 08 92 (555)

Scheme 145

11-9455 Washer

0494317 119455 Washer Minimum set: Mechanical tools MW

Note. Height 10 mm with hexagon screw [released]

Storage Location

C42

11-2114 nut

0490830 112114 nut MW

Replaced by: 0490504

Note. (Knurled nut) Replaced by 00 9 120 (0 490 504) [replaced]

11-9515 nut

0495476 119515 nut MW

Note. (Nut with bearing) Can no longer be ordered separately. Only available as part of set 31 2 120 = 83 30 0 491 909. [Blocked]

11-4482 oddments tray

0495107 114482 oddments tray MW

Note. (Board, exhaust side) Discontinued, only available as part of complete special tool 11 4 480 = 83 30 0 495 105 [Cannot be ordered individually]

Scheme 146

11-4480 oddments tray

0495105 114480 oddments tray MW

Note. (Boards (2 pieces)) For setting down the individual components of the cylinder head. [Released]

SI number

01 17 04 (130)

Consisting of

1. = 0495106 oddments tray NOTE: (Board, intake side) Discontinued, only available as part of complete special tool 11 4 480 = 83 30 0 495 105 [Cannot be ordered individually]
2. = 0495107 oddments tray NOTE: (Board, exhaust side) Discontinued, only available as part of complete special tool 11 4 480 = 83 30 0 495 105 [Cannot be ordered individually]

11-4481 oddments tray

0495106 114481 oddments tray MW

Note. (Board, intake side) Discontinued, only available as part of complete special tool 11 4 480 = 83 30 0 495 105 [Cannot be ordered individually]
