Fuel System- Special Tools BMW X6 M E71

13-0404 Adapter

0495436 130404 Adapter MW

Note. (Adapter 04 (2 pieces)) [Discontinued]

13-8022 Adapter

0491363 138022 Adapter MW

Note. (Adapter hose (2 pieces)) With M6 connecting nipple and quick-release coupling {Discontinued]

Scheme 5

13-8025 Adapter

0491366 138025 Adapter MW

Note. (Adapter hose) With quick-release coupling and ring connection with banjo bolt for testing the output pressure at the metering unit [Discontinued]

13-8010 Adapter

0491360 138010 Adapter MW

Note. For activating the diagnostic functions of the CNG control unit (indicator light in the instrument cluster) and for activating the high-pressure shutoff valve [Discontinued]

Storage Location

W 2..

SI number

01 14 95 (014)

Scheme 6

13-0402 Adapter

0495434 130402 Adapter MW

Note. (Adapter 01 (2 pieces)) [Discontinued]

13-6053 Adapter

0491343 136053 Adapter Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-8023 Adapter

0491364 138023 Adapter MW

Note. (Adapter hose) With counterpiece for quick-release coupling [Discontinued]

13-8024 Adapter

0491365 138024 Adapter MW

Note. (Adapter hoses) With T-piece for intake pressure connection [Discontinued]

13-0405 Adapter

0495437 130405 Adapter MW

Note. (Adapter 26 (2 pieces)) [Discontinued]

13-6050 Adapter

0491340 136050 Adapter Minimum set: Mechanical tools MW

Note. (adapter set for BMW DIS) For measuring oil and fuel pressures [Released]

Storage Location

A3

B3

Scheme 7

SI number

01 12 94 (859)

Consisting of

1. 4 = 0495067 T-piece NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

1. = 0491341 Hose NOTE: (Connecting hose) For connecting reducers 13 6 052, 13 6 053, 13 6 55 and adapters 11 4 050, 11 4 160, 11 4 170, 13 5 131 to BMW DIS [Released]
2. = 0491342 Adapter NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]
3. = 0491343 Adapter NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]
4. = 0491344 Adapter NOTE: (Adapter) [Released]
5. = 0491345 T-piece NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]
6. = 0491346 T-piece NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]
7. = 0491347 T-piece NOTE: Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

13-5255 Adapter

0495579 135255 Adapter Minimum set: Mechanical tools MW

Note. For removing steering shaft on E85. See SI 01 11 06 (265) [Released]

SI number

01 11 06 (265)

Scheme 8

13-0100 Adapter

0491222 130100 Adapter MW

Replaced by: 0491221

Note. Replaced by 13 0 094 (0 491 221) [Replaced]

Storage Location

B15

13-6054 Adapter

0491344 136054 Adapter Minimum set: Mechanical tools MW

Note. (Adapter) [Released]

Storage Location

A3

13-6052 Adapter

0491342 136052 Adapter Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-0162 Adapter

0496480 130162 Adapter Minimum set: Mechanical tools MW

Note. (Adapter SW15) --> only available in set under 13 0 160 (0496371). [Not available separately]

Scheme 9

13-0403 Adapter

0495435 130403 Adapter MW

Note. (Adapter 02 (2 pieces)) [Discontinued]

13-5456 Adapter cable

0494462 135456 Adapter cable MW

Note. (Rail pressure sensor adapter cable (400 mm)) From 09/2011 remaining inventories will be sold off and can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

Scheme 10

0409689 Adapter cable

0409689 Adapter cable MP

Note. (V adapter, 6-pin) For diagnosis and troubleshooting at E-gas actuator, exhaust-gas recirculation valve DISA, HFM and SWIRL flap (only E43) This adapter cable is replaced from February 2011 by cable 13 8 030 (0493837). [Released]

Storage Location

N206

Scheme 11

13-5457 Adapter cable

0494463 135457 Adapter cable MW

Note. (Pressure control valve adapter cable (700 mm)) From 09/2011 remaining inventories will be sold off and can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

2249115 Adapter plate

2249115 Adapter plate MW

In conjunction with: 0 496 885 Tool for injector removal

Note. For removing and installing injectors. (S63TU, N63TU) [released]

Storage Location

B31, C31

SI number

01 19 11 (742)

Scheme 12

13-5451 Basic body

0494457 135451 Basic body MW

Note. (Basic body) With rail pressure sensor and pressure control valve. From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

13-5252 Bush

0493339 135252 Bush Minimum set: Mechanical tools MW

Note. (Threaded bush) [released]

Scheme 13

13-5458 Case

0494491 135458 Case MW

Note. (Case) (not pictured) From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

13-5254 Claw

0493379 135254 Claw Minimum set: Mechanical tools MW

Note. (Clamping claw) For removal of injector nozzles / engine: M57 [discontinued]

13-3068 Connector

0491267 133068 Connector MW

Note. (Connection piece, distributor) All except N73 [released]

Scheme 14

13-3066 Connector

0491265 133066 Connector MW

Note. (Connector for warm-up sensor) All except N73 Only available as part of complete set [Not available separately]

13-3065 Connector

0491264 133065 Connector MW

Note. (Connection piece, distributor) All except N73 [released]

Scheme 15

13-3069 Connector

0491268 133069 Connector MW

Note. For warm-up sensor with hose, all except N73 [released]

13-5450 Device

0494456 135450 Device MW

Note. (Testing device) Checking the high pressure pump ATTENTION - Remaining inventories will be sold off followed by discontinuation from 09/2011 [Released]

SI number

01 09 02 (906)

Consisting of

1. 2 = 0494458 Measuring device NOTE: (rail pressure sensor) Rail pressure sensor contained in 13 5 451. [Discontinued]
2. 3 = 0494459 Valve NOTE: (pressure control valve) Pressure control valve contained in 13 5 451. [Discontinued]
3. 1 = 0494457 Basic body NOTE: (Basic body) With rail pressure sensor and pressure control valve. From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]
4. 4 = 0494460 Line NOTE: (Return line with banjo bolt) Separate components not available, only as part of set 0494456. [Discontinued]
5. 5 = 0494461 Line NOTE: (Fuel line/high pressure pump to testing device (basic body 13 5 451)) From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]
6. 6 = 0494462 Adapter cable NOTE: (Rail pressure sensor adapter cable (400 mm)) From 09/2011 remaining inventories will be sold off and can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]
7. 7 = 0494463 Adapter cable NOTE: (Pressure control valve adapter cable (700 mm)) From 09/2011 remaining inventories will be sold off and can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]
8. 8 = 0494491 Case NOTE: (Case) (not pictured) From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

13-5350 Device

0491321 135350 Device MW

Note. For dynamic setting of diesel fuel injection pump [discontinued]

13-5070 Device

0491288 135070 Device MW

Note. To secure the injection pump control lever - until January 84 [Discontinued]

13-5110 Device

0491295 135110 Device MW

Replaced by: 0491020

Note. (Centring device) For oil pump - Replaced by 11 4 100 (0 491 020) [replaced]

13-5240 Extractor

0491308 135240 Extractor MW

Note. For injection pump sprocket, until January of 84 [discontinued]

13-0293 Fastener

0496826 130293 Fastener Minimum set: Mechanical tools MW

Note. Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]

Scheme 16

13-5162 Fastener

0496568 135162 Fastener Minimum set: Mechanical tools MW

Note. (Cap (2 x)) To close off the fuel lines. Discontinued, only available via complete tool [cannot be ordered separately]

Scheme 17

13-5161 Fastener

0496567 135161 Fastener Minimum set: Mechanical tools MW

Note. (Fastener (2 pieces)) To close off the quick connectors Discontinued, only available via complete tool [cannot be ordered individually]

13-5160 Fastener

0496565 135160 Fastener Minimum set: Mechanical tools MW

Note. (Caps (2x)) To close off the fuel lines when removing and installing the engine. [Released]

Storage Location

A26

SI number

01 22 08 (498)

Consisting of

1. = 0496567 Fastener NOTE: (Fastener (2 pieces)) To close off the quick connectors Discontinued, only available via complete tool [cannot be ordered individually]
2. = 0496568 Fastener NOTE: (Cap (2 x)) To close off the fuel lines. Discontinued, only available via complete tool [cannot be ordered separately]

13-0195 Fitting aid

0495761 130195 Fitting aid Minimum set: Mechanical tools MW

Note. (Installation cone) [Released]

Storage Location

C19

SI number

01 20 06 (299)

Scheme 18

13-0190 Fitting aid

0495756 130190 Fitting aid Minimum set: Mechanical tools MW

Note. (Installation set) For removing and installing the Teflon rings on the injector. [Released]

Storage Location

C19

SI number

01 20 06 (299)

Consisting of

Scheme 19

1. 5 = 0495761 Fitting aid NOTE: (Installation cone) [Released]
2. 4 = 0495760 Holding sleeve NOTE: (Assembly sleeve 3) [Released]
3. 3 = 0495759 Holding sleeve NOTE: (Assembly sleeve 2) [Released]
4. 2 = 0495758 Holding sleeve NOTE: (Assembly sleeve 1) [Released]
5. 1 = 0495757 Pliers NOTE: [Released]

13-5140 Gauge

0491301 135140 Gauge MW

Note. (Plug gauge) For warm-up sensor - Up to January 84 [Discontinued]

13-3000 Gauge

0491255 133000 Gauge MW

Note. (Setting gauge) For pre-tensioning the electric fuel pump with interchangeable diaphragm - Until January 84 [Discontinued]

13-0194 Holding sleeve

0495760 130194 Holding sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve 3) [Released]

Storage Location

C19

SI number

01 20 06 (299)

Scheme 20

13-0193 Holding sleeve

0495759 130193 Holding sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve 2) [Released]

Storage Location

C19

SI number

01 20 06 (299)

Scheme 21

13-0192 Holding sleeve

0495758 130192 Holding sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve 1) [Released]

Storage Location

C19

SI number

01 20 06 (299)

Scheme 22

13-3067 Hose

0491266 133067 Hose MW

Note. (Connecting hose) For checking the fuel delivery rate of the fuel pump All except N73 Only available as part of complete set

13-6051 Hose

0491341 136051 Hose Minimum set: Mechanical tools MW

Note. (Connecting hose) For connecting reducers 13 6 052, 13 6 053, 13 6 55 and adapters 11 4 050, 11 4 160, 11 4 170, 13 5 131 to BMW DIS [Released]

Storage Location

A3

B3

13-5455 Line

0494461 135455 Line MW

Note. (Fuel line/high pressure pump to testing device (basic body 13 5 451)) From 09/2011 can only be ordered as part of the complete special tool 0494456 (13 5 450). [Not available separately]

13-3063 Line

0491262 133063 Line MW

Note. (Connection lines (2 x)) For check of fuel and oil pressure [released]

13-0291 Line

0496824 130291 Line Minimum set: Mechanical tools MW

Note. With connection for 13 3 060 or 11 4 310. Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]

Storage Location

A29, A30, B29

13-5454 Line

0494460 135454 Line MW

Note. (Return line with banjo bolt) Separate components not available, only as part of set 0494456. [Discontinued]

13-0290 Line

0496707 130290 Line Minimum set: Mechanical tools MW

In conjunction with: 13 3 060; 11 4 310

Note. Two fuel lines. Auxiliary lines for 13 3 060. For fuel pressure check in all direct injectors in comb. with IMIB and 100 bar sensor. [Released]

Storage Location

A29

B29

A30

SI number

01 27 09 (598)

Consisting of

1. 3 = 0496826 Fastener NOTE: Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]
2. 2 = 0496825 Line NOTE: Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]
3. 1 = 0496824 Line NOTE: With connection for 13 3 060 or 11 4 310. Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]

13-3064 Line

0491263 133064 Line MW

Note. (Connection line) With T-piece for L-Jetronic, all except N73 [released]

13-0292 Line

0496825 130292 Line Minimum set: Mechanical tools MW

Note. Available as part of complete tool set 13 0 290 (0496707) only. [Not available separately]

Storage Location

B29, C29

13-8020 Measuring device

0491361 138020 Measuring device MW

Note. (Measuring device) With connection parts for checking and adjusting the low pressure regulator [Discontinued]

SI number

01 14 95 (014)

Consisting of

1. = 0491362 Measuring device NOTE: (Measuring device) Without adapter hoses [Discontinued]
2. = 0491363 Adapter NOTE: (Adapter hose (2 pieces)) With M6 connecting nipple and quick-release coupling {Discontinued]
3. = 0491364 Adapter NOTE: (Adapter hose) With counterpiece for quick-release coupling [Discontinued]
4. = 0491365 Adapter NOTE: (Adapter hoses) With T-piece for intake pressure connection [Discontinued]
5. = 0491366 Adapter NOTE: (Adapter hose) With quick-release coupling and ring connection with banjo bolt for testing the output pressure at the metering unit [Discontinued]

13-3060 Measuring device

0491259 133060 Measuring device MW

Note. For checking fuel and oil pressure [released]

Consisting of

1. = 0491260 Pressure gauge NOTE: (Pressure gauge 0...25 bar) [released]
2. = 0491261 Valve NOTE: (Valve) 2-way valve, engine: all, except S50, S54, N73 [released]
3. = 0491262 Line NOTE: (Connection lines (2 x)) For check of fuel and oil pressure [released]
4. = 0491263 Line NOTE: (Connection line) With T-piece for L-Jetronic, all except N73 [released]
5. = 0491264 Connector NOTE: (Connection piece, distributor) All except N73 [released]
6. = 0491265 Connector NOTE: (Connection piece warm-up sensor) All except N73 [Released]
7. = 0491266 Hose NOTE: (Connecting hose) For checking fuel pump fuel delivery rate, all except N73 [Released]
8. = 0491267 Connector NOTE: (Connection piece, distributor) All except N73 [released]
9. = 0491268 Connector NOTE: For warm-up sensor with hose, all except N73 [released]

13-5452 Measuring device

0494458 135452 Measuring device MW

Note. (rail pressure sensor) Rail pressure sensor contained in 13 5 451. [Discontinued]

13-8021 Measuring device

0491362 138021 Measuring device MW

Note. (Measuring device) Without adapter hoses [Discontinued]

13-3020 Measuring glass

0491257 133020 Measuring glass MW

Note. (Measuring glass) For checking of electric fuel pump - fuel delivery rate [discontinued]

Scheme 23

13-5080 Pin

0491289 135080 Pin MW

Note. (Dowel pin) For synchronising the injection pump to the throttle valve - until January 84 [Discontinued]

13-0191 Pliers

0495757 130191 Pliers Minimum set: Mechanical tools MW

Note. [Released]

Storage Location

C19

SI number

01 20 06 (299)

Scheme 24

13-3061 Pressure gauge

0491260 133061 Pressure gauge MW

Note. (Pressure gauge 0...25 bar) [released]

13-5250 Puller

0493321 135250 Puller Minimum set: Mechanical tools MW

Note. For pulling injector nozzles and injectors out of the cylinder head [Released]

Storage Location

A11

B11

SI number

01 06 98 (306)

Consisting of

Scheme 25

1. 4 = 0493379 Claw NOTE: (Clamping claw) For removal of injector nozzles / engine: M57 [discontinued]
2. 1 = 0493338 Rod NOTE: (Guide rod) [Released]
3. 2 = 0493339 Bush NOTE: (Threaded bush) [released]
4. 3 = 0493340 Weight NOTE: (Weight) [released]
5. 5 = 0495579 Adapter NOTE: For removing steering shaft on E85. See SI 01 11 06 (265) [Released]

13-5251 Rod

0493338 135251 Rod Minimum set: Mechanical tools MW

Note. (Guide rod) [Released]

Scheme 26

13-0070 Sensor

0491215 130070 Sensor MW

Replaced by: 0491217

Note. (Exhaust gas probe) For vehicles with catalytic converter - Other: only Japan and USA Replaced by 13 0 090 (0 491 217) [Replaced]

13-0161 Socket wrench

0496479 130161 Socket wrench Minimum set: Mechanical tools MW

Note. (Socket wrench SW14 open) --> only available in set under 13 0 160 (0496371). [Not available separately]

13-0140 Socket wrench

0495280 130140 Socket wrench Minimum set: Mechanical tools MW

Note. For releasing and tightening fuel lines on piezo injector. [Released]

Storage Location

C52

SI number

01 06 05 (181)

Scheme 27

13-0160 Socket wrench with adapter

0496371 130160 Socket wrench with adapter Minimum set: Mechanical tools MW

Note. For releasing and tightening down fuel line screw connection on injector. [Released]

Storage Location

A25

SI number

01 20 08 (490)

Consisting of

1. = 0496479 Socket wrench NOTE: (Socket wrench SW14 open) --> only available in set under 13 0 160 (0496371). [Not available separately]
2. = 0496480 Adapter NOTE: (Adapter SW15) --> only available in set under 13 0 160 (0496371). [Not available separately]

13-0401 Synchrometer

0495433 130401 Synchrometer MW

Note. [Discontinued]

13-0400 Synchrometer

0495432 130400 Synchrometer MW

Note. (Synchrometer) [Discontinued]

Consisting of

1. = 0495433 Synchrometer NOTE: [Discontinued]
2. = 0495434 Adapter NOTE: (Adapter 01 (2 pieces)) [Discontinued]
3. = 0495435 Adapter NOTE: (Adapter 02 (2 pieces)) [Discontinued]
4. = 0495436 Adapter NOTE: (Adapter 04 (2 pieces)) [Discontinued]
5. = 0495437 Adapter NOTE: (Adapter 26 (2 pieces)) [Discontinued]

13-6058 T-piece

0495067 136058 T-piece Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-6055 T-piece

0491345 136055 T-piece Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-6056 T-piece

0491346 136056 T-piece Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-6057 T-piece

0491347 136057 T-piece Minimum set: Mechanical tools MW

Note. Liquidation of existing inventory and then available only as a complete tool set 13 6 050 (83 30 0 491 340) - as of 19.01.12 [Not available separately]

Storage Location

A3

13-4000 Template

0491269 134000 Template MW

Note. (Drilling template) For auxiliary air slide - catalytic converter [Discontinued]

13-3010 Terminal

0491256 133010 Terminal Minimum set: Mechanical tools MW

Note. (Hose clip) For removing a hose during repair work [released]

Storage Location

C4

Scheme 28

13-5150 Tool

0491302 135150 Tool MW

Note. (Tool) For vacuum valves on the injection pump - until January 84 [Discontinued]

13-5453 Valve

0494459 135453 Valve MW

Note. (pressure control valve) Pressure control valve contained in 13 5 451. [Discontinued]

13-3062 Valve

0491261 133062 Valve MW

Note. (Valve) 2-way valve, engine: all, except S50, S54, N73 [released]

13-5253 Weight

0493340 135253 Weight Minimum set: Mechanical tools MW

Note. (Weight) [released]

Scheme 29

13-5020 Wrench

0491277 135020 Wrench Minimum set: Mechanical tools MW

Note. (Wrench) SW17 For releasing and tightening the fuel injection lines [Released]

Storage Location

A9

Scheme 30

13-5310 Wrench

0491317 135310 Wrench MW

Note. For adjusting the fuel injection rate at full load [Discontinued]
