Maintenance and General Information - Repair Instructions BMW X5 E70

00 Danger of Poisoning If Oil Is Ingested/Absorbed Through The Skin

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are

1. Headaches
2. Dizziness
3. Stomach aches
4. Vomiting
5. Diarrhoea
6. Cramps/fits
7. Unconsciousness

Protective measures/rules of conduct

1. Pour oil only into appropriately marked containers
2. Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
3. Observe country-specific safety regulations

First aid measures

1. Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.

00 Risk of Injury If Oil Comes Into Contact With Eyes And Skin

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are

1. Impaired sight
2. Irritation of the eyes
3. Reddening of the skin
4. Rough and cracked skin

Protective measures/rules of conduct

1. Wear protective goggles
2. Wear oil-resistant protective gloves
3. Observe country-specific safety regulations

First aid measures

1. Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
2. Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.

00 Safety Instructions For Handling Oil

Recycling

Observe country-specific waste-disposal regulations.

Measures if oil is unintentionally released

1. Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
2. Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
3. Limiting spread: Use oil blocks to prevent the surface spread of oil.
4. Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.

Scheme 31

Scheme 32

00 ... ... Lifting Vehicle With A Lifting Platform

Note. The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions.

Necessary preliminary tasks

1. If necessary, remove jacking points from equipment pack and insert from below into openings in front and rear sill areas

Scheme 33

00 ... ... Notes on Using Repair Instructions, Technical Data, Tightening Torques

These repair instructions are intended to help expertly carry out maintenance and repair work.

They thus supplement the practical and theoretical training of master mechanics and fitters in BMW's Service Training Centers.

The Repair Instructions describes the removal, installation and replacement of subassemblies in the vehicle.

The Repair Instructions describe tasks which can be carried out on series-production BMW Group vehicles and vehicles which have not been subsequently converted.

Cross-references to "TECHNICAL DATA" and "TIGHTENING TORQUES" must be complied with.

If there are no cross-references to tightening torques in the repair instructions, the excerpts from the company standard BMW N 600 02.0 must be observed. See 00 MAINTENANCE AND GENERAL INFORMATION .

Cross-references to other flat rate units are intended as an aid and can refer to a complete work operation or merely to individual work steps contained therein.

Cross-references to other flat rate units must not be considered as an extension of the labor performance standard.

The structure of the Repair Instructions corresponds to the numbering system of the flat rate manuals (flat rate units).

Note. With the exception of inspection operations, no flat rates are published for the E52 (Z8) model series. However, the numbering system (flat rate units) is retained.

Furthermore, the corresponding microfiches of the repair instructions are valid for the E12, E21, E24, E28, E30, E31 and E34 model series.

The microfiche is also valid for the E32 model series with the following exception: For the 750i, 750Li models and the job description 31 31 000 Replacing front left or right spring strut, the TIS CD must be used!

In general, the individual work steps of the Repair Instructions describe only the removal of subassemblies. All removed subassemblies are reinstalled in reverse sequence. If particular features need to be observed during installation, they are identified as notes on installation. In contrast, complicated removal and installation procedures are described separately.

Further information on repair operations can be found on the "Commercial Service Data CD (KSD CD)". For the E39, E46 and E53 model series and the following model series, it is possible after selecting the FRU items to activate the corresponding information via the Text and Inclusive Items buttons.

Improvements and modifications are published regularly in service information bulletins.

Scheme 34

Scheme 35

00 .. ... Symbols Used And Information In Repair Instructions

Example

Note. Particular information on improved procedures for operation, testing, adjustment and upkeep. Also indicates the end of a repair article.

Recycling

Observe country-specific waste-disposal regulations

General information

Refers to other instructions: such as e.g.

Necessary preliminary tasks

Further instructions: refer to operating instructions for balancing machine.

Replacement

Carry out programming/coding.

Note. Many electronic control units must be programmed/coded (e.g. when replaced).

Note. Connect BMW diagnosis system

Note. Electronic control units and other electronic components - if handled incorrectly - can be damaged or destroyed by electrostatic discharge.

00 00 ... Battery: Checking Display. If Necessary, Recharge Battery.

Vehicles with low-maintenance battery

Check acid level, top up with distilled water if necessary

If level drops below Max. marking, top up distilled water to Max. marking.

Vehicles with maintenance-free battery

Check charge start by way of magic eye.

00 00 ... Body and Underbody: Checking For Corrosion And Damage

Inspect chassis, underbody and wheel arches and check for corrosion and damage.

Note. It is absolutely essential to rectify any identified faults after consulting the customer and to issue a separate invoice.

00 00 ... Body: Check For Corrosion (Except Cavities)

Visually inspect the underbody, wheel arches and frame members for rust and damage.

00 00 ... Brake Lines And Connections: Visual Inspection For Leaks, Damage And Correct Position

Check brake lines and connections

1. Visual inspection in visible area for: Check brake fluid level in expansion tank leaks traces of fluid damage crushing/flattening correct routing of brake lines correct seating of brake lines in holders

Note. Detected faults must urgently be repaired after consultation with the customer!

00 00 ... Check Windscreen Wash/Wipe System

1. Check wipe pattern for smearing; if necessary, replace wiper blades after consulting with customer. See «61 61 01. ADJUSTING LEFT OR RIGHT WINDSCREEN WIPER»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-61-01-adjusting-left-or) , «61 61 010 CHECKING/ADJUSTING CONTACT ANGLE OF WINDSCREEN WIPER ARMS ON WINDSCREEN»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-61-010-checkingadjusting-contact-angle) , «61 61 041 REPLACING BOTH WINDSCREEN WIPER BLADES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-61-041-replacing-both-windscreen)
2. The spray jet must emerge uniformly from the spray nozzle, replace nozzle if necessary and issue a separate invoice. See «61 71 015 REMOVING AND INSTALLING/REPLACING A SPRAY NOZZLE IN WINDSCREEN WASHER SYSTEM»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-71-015-removing-and-installingreplacing)

00 00 ... Checking Coolant Level And Concentration, Correcting If Necessary

1. Check connections, hose clamps and hoses for coolant residues and damage such as e.g. cracks.
2. Check coolant level in expansion tank. Coolant level must be between Min. and Max. markings. If necessary, top up coolant to max. fill level.
3. In event of topping up: Check concentration with antifreeze tester (special tool) in coolant expansion tank. If necessary, drain off the difference quantity at the coolant drain plug and top up with recommended coolant (issue a separate invoice).

Horn

Check function.

Note. In the case of twin-tone fanfares, make sure that both fanfares are working properly.

Headlight flasher

Activate headlight flashers, check high-beam headlights and blue indicator lamp in instrument cluster for correct operation.

Hazard warning system

Check function.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

Instrument lighting

Check function of instrument and indicator/warning lamps.

Indication field lighting

Check function of light switches; dimmer; controls; heater/air conditioning; rear window demister; radio; (depending on equipment) on-board computer; power windows; electric sunroof; fog lamp.

Heater

Check function of all blower stages, air distribution and air outlet.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

00 00 ... Checking Lighting System

1. Check lighting system for correct operation: Check headlights, rear lights and associated telltale/indicator lamps Check sidelamps, parking lights, dipped-beam and main-beam headlights for correct operation Check headlight flasher for correct operation Check signal horn Check left/right direction indicators and hazard warning system for correct operation Check brake lights for correct operation Check reversing lights and license plate lights for correct operation Check front and rear fog lights for correct operation Check interior lights (assembly: interior lights, footwell lights, luggage compartment lights, glovebox light) for correct operation Check instrument and indication field lighting

00 00 ... Checking Roadworthiness (Test Drive)

1. Checking roadworthiness Take vehicle for a test drive, checking service and parking brakes in the process For vehicles with rear disc brakes, brake in parking brake as instructed. See «34 41 006 ADJUSTING PARKING BRAKE»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-41-006-adjusting-parking-brake) . Check function of parking brake. See «34 00 012 PARKING BRAKE FUNCTION CHECK»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-00-012-parking-brake-function) . Check steering for play, ease of movement and directional stability Check clutch for problem-free disengagement and non-spasmodic driving off at normal operating temperature Check function of all drive positions and driving programs in cars with automatic transmissions Visually inspect shock absorbers for leaks Check indicator/warning lamps and Check Control system for correct operation Check due date for statutory roadworthiness and exhaust emission tests and advise customer of test dates

00 00 ... Diagnostic Brief Test

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field. Check identified faults and if necessary rectify these faults after consulting with customer.

Scheme 36

INFORMATION WARNING LABELS REFERENCE

Key

US = United States

CDN = Canada

CCC = Car Communication Computer

OBD = On-Board Diagnosis

00 00 ... Microencapsulated Screws

Screw locking is a means to preventing a screwed connection from being loosened by external influences.

After the screw has been coated with the adhesive, the adhesive remains inactive until it is activated by capsule breakage when the screw is inserted and then cures at room temperature.

Installation

1. Microencapsulated screws (Loctite) must be replaced and may not be reused
2. Screw connection must be completed within 20 mins. (start of curing)
3. Microencapsulated screws must not be retightened
4. Thread of nut must be cleaned beforehand in event of repeated use

00 00 ... Normalization of Electric Steering Column Adjustment

Note. Normalization must be carried out after the following work

1. Removal or replacement of control panel in heater-A/C system or of steering column
2. Repair work to electric steering column adjustment
3. Coding/programming of IHKA control unit

Normalization of electric steering column adjustment is possible via the diagnosis system under the following path

1. Diagnosis
2. Function selection
3. Service functions
4. Chassis
5. Electric steering column adjustment

00 00 ... Notes on Maneuvering In Event Of Power Failure

Note. In the event of a power failure or electrical fault, the electromechanical parking brake and the transmission interlock can be manually released.

Observe following sequence

1. Secure vehicle against rolling, e.g. with chocks.
2. Manually release electromechanical parking brake. See «34 41 ... OVERVIEW OF PARKING BRAKE»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair) .
3. Then manually release interlock of automatic transmission. See «24 34 ... MANUAL EMERGENCY RELEASE OF TRANSMISSION LOCK»(/bmw/x5/e70-2006-2010/remont/automatic-trans/#automatic-transmission-repair) .

00 00 ... Raising BMW Multi-Trailer

The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions. It is essential to follow the lifting platform operating instructions, in particular the safety instructions and carrying capacity!

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Before raising the BMW multi-trailer, please observe the following points

1. Raise the trailer only when it is unloaded
2. Remove a supplied loading ramp from the loading ramp frame so that all chassis areas of the BMW multi-trailer are freely accessible
3. There must be sufficient clearance between the carrier arms/flat girder bridges and the GFK aprons or the front guard of the BMW multi-trailer
4. The BMW multi-trailer must always be positioned in the middle of the lifting platform.

The areas (2) on the longitudinal members (1) marked in the adjacent diagram are the best areas for attaching the additional supports.

Scheme 37

General notes on using twin-pillar lifting platforms

For the twin-pillar lifting platforms described, the BMW multi - trailer is positioned in the direction of travel on the platform. For lifting platforms which do not create sufficient clearance between disk wheel and carrier arms, move the BMW multi - trailer against the direction of travel onto the platform.

Becker & Sohne twin-strut underfloor platform

The BMW multi-trailer can only be raised if it is supported at right angles to the direction of travel. For raising, use the high additional supports (1) of Becker & Sohne.

Scheme 38

MAHA twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the support plate attachment sleeves for transporters (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 39

Romaico-Lift twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the 146 mm high attachments (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 40

Working pit

The BMW multi-trailer can be serviced or repaired in conjunction with a working pit if the following measures are taken into consideration. The BMW multi-trailer must be secured against slipping/tilting sideways. The drawbar jockey wheel must be firmly secured against rolling.

Belt Strap, Retractor Mechanism, Belt Interlock

Pull out strap and make sure it emerges without jerking.

Check belt strap for

1. folding
2. unravelling
3. pinches
4. cracks and tears
5. traces of melting

Retract belt strap; here the inertia reel mechanism must retract the strap automatically and without squeaking noises, the last section of the strap may have to be fed in.

Pull out belt strap in short tugs - locking reel must lock.

Belt Buckle

The tongue on the belt strap must easily snap into place with an audible click.

When the "Press" button is pressed, the tongue must be ejected from the buckle under spring pressure.

Note. If the seat belt is damaged, you must replace the seat belt completely after consulting the customer; issue a separate invoice for this work. Instructions on how to proceed, refer to Checking automatic seat belt 72 11 ... CHECKING AUTOMATIC SAFETY BELT .

Checking play

1. For hydraulically assisted steering systems, the engine must be running
2. For electrically assisted steering systems, the ignition must be on
3. Steering wheel: Move steering wheel back and forth and check for play
4. Tie rod joint: There must no clearance between tie rod arm (2) and tie rod joint (1).

Checking for leaks

The following illustration shows the arrangement of the power steering components and lines.

Scheme 41

Scheme 42

Check all visible connections, hoses, lines and steering gear for traces of fluid.

Checking for damage and wear

Check gaiters, flexible disc and axle and tie rod sleeves for damage (e.g. cracks, holes), for leaks or missing clamping bands on gaiters.

00 00 ... Steering Fluid Reservoir: Check Oil Level.

Visual inspection and leak test

Check connections, hoses and steering gear for traces of fluid.

Checking fluid level

Check fluid level with engine switched off at expansion tank of power steering/ride-height control system. The fluid temperature should be approx. 20°C here.

Ensure that the cap is fully screwed in prior to the fill level check.

If necessary, add hydraulic fluid (refer to Service Information Operating Fluids) up to Max. marking (1).

Scheme 43

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

Scheme 44

00 00 ... Tires: Checking Inflation Pressure, Correcting If Necessary (Incl. Spare Wheel), Checking External Condition, Tread Depth, Pattern

1. Checking tire inflation pressure: Check tire inflation pressure in accordance with information plate on B-pillar The inflation pressure in the spare wheel must be 0.5 bar higher than the maximum specified value on the information plate Initialize Run Flat Indicator. See «36 11 500 INITIALIZING RUN FLAT INDICATOR (RPA)»(/bmw/x5/e70-2006-2010/remont/wheel-tire-system/#wheel-and-tires-repair__36-11-500-initializing-run-flat) .
2. Checking tire condition: Check tread depth of all types with tire tread gauge Check tire tread surfaces and side walls for incisions and foreign particles such as nails or screws Check tire tread pattern for localized flattening and wear on one side; if necessary, carry out wheel/chassis alignment after consulting with customer and issue a separate invoice for this work

Note. For details of approved wheel-tire combinations, refer to KSD CD. For reasons of driving safety, only use tires of the same type and tread pattern on a single vehicle Inform customer of any incorrect or worn tires

00 00 ... Underbody incl. All Visible Components: Checking For Damage, Leaks, Corrosion

1. Visually inspect underbody: For leaks (transmission, brake components, steering) Damage to underbody Corrosion on underbody

00 00 ... Upkeep Measures For Stored Vehicles (New And Used Cars) And Vehicles To Be Laid Up At Customer's Premises

STORED VEHICLE MEASURE REFERENCE CHART

00 00 ... Windscreen Washer System: Checking Fluid Level, Topping Up If Necessary

1. Top up windscreen washer fluid reservoir, if necessary rear window washer fluid reservoir and (depending on equipment specification) intensive cleaning reservoir up to edge or mark.

00 00 005 Interrogate Fault Memories In Diagnosis System

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field.

00 00 105 Standard Scope Of Service

1. Standard scope of service Check Control messages Check telltale and warning lamps

00 00 602 Service - Intake Muffler

1. Change air cleaner element in accordance with repair instructions. See «13 72 001 REPLACING BOTH AIR CLEANER ELEMENTS (N52K)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-repair-n52__13-72-001-replacing-both-air) .
2. Reset CBS display according to factory specification.

Special tools required

1. 11 9 240.

Overfilling the engine with engine oil will result in engine damage .

Checking and drip-off times must be observed.

Risk of damage!

The alternator must therefore be covered with suitable apparatus.

Recycling

Catch and dispose of used oil.

Observe country-specific waste-disposal regulations.

Note. Adhere to the following work steps in sequence

1. Open oil filter cap.
2. Release screw plug in oil sump.

Release oil filter cap with special tool 11 9 240 . Engine oil flows out of the oil filter housing and back into the oil sump.

Remove and insert oil filter element (1) in direction of arrow.

Installation

Replace oil filter element (1) and sealing rings (2).

Installation

Moisten sealing rings (2) with engine oil.

Tightening torque 11 42 2AZ. See 11 42 OIL FILTER AND PIPES .

Open screw plug (1) in oil sump.

Drain engine oil.

Scheme 45

Installation

Replace sealing ring.

Tightening torque 11 13 1AZ. See 11 13 OIL PAN .

Pour in engine oil

Note. Start engine and run at idle until oil pressure warning lamp goes out.

Turn off engine.

Check oil filter cap and screw plug (1) on oil sump for leaks.

Assemble engine.

Checking engine oil level

1. Park vehicle on a horizontal surface
2. Allow engine at normal operating temperature to run for three minutes with increased revs (approx. 1100 RPM)
3. Read off engine oil level in instrument cluster or on Control Display
4. Top up engine oil if necessary

Scheme 46

Scheme 47

00 00 610 Service - Engine Oil (Petrol/Gasoline Vehicles up to 09/2008)

1. Service - engine oil Change engine oil and oil filter. See «00 00 610 Engine Oil Service»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions) . Hand parking brake. See «34 41 006 ADJUSTING PARKING BRAKE»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-41-006-adjusting-parking-brake) . Brake in and check for correct function A/C system or automatic A/C Change microfilter for interior ventilation. See «64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-011-replacing-microfilter-for) . Change microfilter for recirculated air. See «64 31 017 REPLACING RECIRCULATED AIR MICROFILTER»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-017-replacing-recirculated-air) . At every 3rd engine oil change Intake silencer: change air cleaner element. See «13 72 001 REPLACING BOTH AIR CLEANER ELEMENTS (N52K)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-repair-n52__13-72-001-replacing-both-air) . Shorten intervals accordingly for vehicles operated in dusty regions. Change fuel filter. See «13 32 051 REPLACING FUEL FILTER (M57T2)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-repair-n52__13-32-051-replacing-fuel-filter) . Shorten change interval if fuel quality is poor Replace spark plugs. See «12 12 011 REPLACING ALL SPARK PLUGS (N62, N62TU)»(/bmw/x5/e70-2006-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair-n52__12-12-011-replacing-all-spark) . Reset CBS display according to factory specification.

00 00 610 Service - engine oil (petrol vehicles from 03/2009)

1. Service - engine oil Change engine oil and oil filter.. Hand parking brake.. Brake in and check for correct function A/C system or automatic A/C Change microfilter for interior ventilation. Change microfilter for recirculated air. At every 2nd engine oil change Replace spark plugs. Change intake silencer: change air filter element. Shorten change intervals accordingly for vehicles operated in dusty regions. At every 3rd engine oil change (on in vehicles with SA109 Security Plus) Service active stabilizer, valve block, expandable hoses, swivel motor lines. Reset CBS display according to factory specification.

00 00 610Service - engine oil (petrol/gasoline vehicles from 10/2008 to 02/2009)

1. Service - engine oil Change engine oil and oil filter. Hand parking brake.. Brake in and check for correct function A/C system or automatic A/C Change microfilter for interior ventilation. Change microfilter for recirculated air. At every 2nd engine oil change Replace spark plugs. At every 3rd engine oil change Intake silencer: change air filter element. Shorten intervals accordingly for vehicles operated in dusty regions. Reset CBS display according to factory specification.

00 00 612 Service - Front Brakes

1. Service - front brakes Change brake pads. See «34 11 000 REMOVING AND INSTALLING/REPLACING BRAKE LININGS ON BOTH FRONT DISC BRAKES»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-11-000-removing-and-installingreplacing) , clean brake air ducts Brake discs. See «34 11 220 REMOVING AND INSTALLING/REPLACING BOTH FRONT BRAKE DISCS»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-11-220-removing-and-installingreplacing) . Check surface and thickness If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake discs if they are below the minimum brake disc thickness. See 34 11 FRONT BRAKE E70 , and if scoring, heat cracks or thickness difference are detected. Apply a thin coat of grease to wheel centering on light alloy wheels, refer to Service Information Operating Fluids. Issue a separate invoice for replacing the brake discs.

00 00 614 Service - Rear Brakes

1. Service - rear brakes Change brake pads. See «34 21 200 REMOVING AND INSTALLING/REPLACING BRAKE LININGS ON BOTH REAR DISC BRAKES (TEVES FLOATING CALIPER)»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-21-200-removing-and-installingreplacing) , clean brake air ducts Brake discs. See «34 21 320 REMOVING AND INSTALLING OR REPLACING BOTH REAR BRAKE DISCS»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-21-320-removing-and-installing) . Check surfaces and thickness. If necessary: Replace Handbrake. See «34 41 220 REMOVING AND INSTALLING/REPLACING ALL HANDBRAKE SHOES»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-41-220-removing-and-installingreplacing) . Check condition, brake lining thickness and function If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake disks if they drop below minimum thickness. See 34 21 REAR BRAKE DISCS E70 , and in event of scoring, heat cracks or thickness difference. Apply a thin coat of grease to wheel centering on light alloy wheels, refer to Service Information Operating Fluids . Issue a separate invoice for replacing the brake discs and handbrake shoes.

00 00 616 Service - Microfilter

1. Service - microfilter Heating/air conditioning: change microfilter / carbon canister. See «64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-011-replacing-microfilter-for) , «64 31 017 REPLACING RECIRCULATED AIR MICROFILTER»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-017-replacing-recirculated-air) . Reset CBS display according to factory specification

00 00 618 Service - Brake Fluid

1. Service - brake fluid Changing brake fluid «34 00 050 REPLACING FLUID IN ABS/ASC+T BRAKE SYSTEM»(/bmw/x5/e70-2006-2010/remont/mechanical-hydraulic/#brakes-repair__34-00-025-replacing-fluid-in) Reset CBS display according to factory specification

00 00 622 Service - Spark Plugs

1. Service - spark plugs Replace spark plugs. See «12 12 011 REPLACING ALL SPARK PLUGS (N62, N62TU)»(/bmw/x5/e70-2006-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair-n52__12-12-011-replacing-all-spark) . Reset CBS display according to factory specification

00 00 625 Service - Vehicle Check

1. Service - vehicle check Diagnostic brief test. See «00 00 ... Diagnostic Brief Test»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-diagnostic-brief-test) . Check horn, headlight flashers and hazard warning system. See «00 00 ... Checking Horn, Headlight Flashers And Hazard Warning System»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions) . Check instrument and indication field lighting and heater blower. See «00 00 ... Checking Instrument And Indication Field Lighting, Heater Blower»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions) . Check lighting system. See «00 00 ... Checking Lighting System»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-checking-lighting-system) . Seat belts: check condition of belt strap, function of inertia reel mechanism, locking reel and belt buckle. See «00 00 ... Seat belts: Checking Condition Of Belt Strap, Function Of Inertia Reel Mechanism, Locking Reel, Belt Buckle»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions) . Check windscreen wash/wipe system. See «00 00 ... Windscreen Washer System: Checking Fluid Level, Topping Up If Necessary»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-windscreen-washer-system) . Body: Check for corrosion (except cavities). See «00 00 ... Body: Check For Corrosion (Except Cavities)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-body-check-for) . Tires: Check tread depth, pattern, external condition and inflation pressure and correct if necessary (compact wheel as well). See «00 00 ... Tires: Checking Inflation Pressure, Correcting If Necessary (Incl. Spare Wheel), Checking External Condition, Tread Depth, Pattern»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-tires-checking-inflation) . Initialize Run Flat Indicator. See «36 11 500 INITIALIZING RUN FLAT INDICATOR (RPA)»(/bmw/x5/e70-2006-2010/remont/wheel-tire-system/#wheel-and-tires-repair__36-11-500-initializing-run-flat) . Check battery. See «00 00 ... Battery: Checking Display. If Necessary, Recharge Battery.»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-battery-checking-display) . (magic eye), if necessary recharge battery (issuing a separate invoice for this work) Check display (magic eye) If necessary: Charge battery Steering fluid reservoir: Check fluid level. See «00 00 ... Steering Fluid Reservoir: Check Oil Level.»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-steering-fluid-reservoir) . Check coolant level and concentration, top up if necessary. See «00 00 ... Checking Coolant Level And Concentration, Correcting If Necessary»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-checking-coolant-level) . Windscreen washer system: Check fluid level, top up if necessary. See «00 00 ... Windscreen Washer System: Checking Fluid Level, Topping Up If Necessary»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-windscreen-washer-system) . Brake lines and connections: Check for leaks, damage and correct position. See «00 00 ... Brake Lines And Connections: Visual Inspection For Leaks, Damage And Correct Position»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-brake-lines-and) . Underbody incl. all visible components: check for damage, leaks, corrosion. See «00 00 ... Body and Underbody: Checking For Corrosion And Damage»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-body-and-underbody) . Steering components: check for zero clearance, leaks, damage and wear. See «00 00 ... Steering Components: Checking For Zero Clearance, Leaks, Damage And Wear»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions) . Check roadworthiness (test drive): See «00 00 ... Checking Roadworthiness (Test Drive)»(/bmw/x5/e70-2006-2010/remont/oem-general-information/#maintenance-and-general-information-repair-instructions__00-00-checking-roadworthiness-test) . Brakes Steering Shock absorbers Transmission Reset CBS display according to factory specification

00 11 ... Checking/Topping Up Oil Level In Rear Differential

Undo oil filler plug (1).

Check oil level.

If necessary, pour in rear differential oil up to lower edge of opening for oil filler plug (1).

Installation

Replace oil filler plug (1) with O-ring.

Tightening torque 33 11 2AZ. See 33 11 REAR DIFFERENTIAL CASE WITH COVER .

Scheme 48

00 11 500 Checking/topping Up Fluid Level In Automatic Transmission (GA6HP26Z)

Installation

Tighten down filler plug using

Scheme 49

1. Hexagon wrench 8 A/F
2. torque wrench
3. Socket 8 A/F

Topping up transmission fluid after a repair

Stand vehicle on a level surface and secure against rolling off.

Undo filler plug (1).

Installation

Replace sealing ring.

Top up transmission fluid until it emerges from filling orifice.

Start engine.

Replenish transmission fluid until it emerges from filling orifice.

Screw in filler plug (1).

Tightening torque: 24 11 7AZ. See 24 11 TRANSMISSION HOUSING, TRANSMISSION OIL SUMP .

Press brake pedal to floor and shift through all gears several times at idle speed. Then shift to "P" position (Park).

Then check fluid level.

Checking fluid level

Scheme 50

1. Call up Service functions (Drive) in BMW diagnosis system
2. Carry out fluid level check in accordance with instructions

00 11 259 Oil Change In Rear Differential Incl. Used Oil Disposal

Note. The oil does not need to be changed in rear differentials carrying the "Life-Time-Oil" sticker. Only change oil when rear differential is at normal operating temperature.

Recycling: Observe country-specific waste-disposal regulations

Undo oil filler plug (1).

Drain and dispose of differential oil.

Add differential oil up to lower edge of opening for oil filler plug (1); if necessary, refer to Technical Data for necessary fill quantity. See 33 10 REAR AXLE DIFFERENTIAL E60, E61, E63, E64, E81, E82, E86, E87, E90, E91, E92, E9 .

Installation: Replace oil filler plug (1) with O-ring. Tightening torque 33 11 2AZ. See 33 11 REAR DIFFERENTIAL CASE WITH COVER .

11 00 Removing and Installing/Replacing Ignition Coil Cover (N52K)

Necessary preliminary tasks

1. Remove air filter housing. See «13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K)»(/bmw/x5/e70-2006-2010/remont/fuel-system/#fuel-system-repair-n52__13-71-000-removing-and-installingreplacing) .

Release screws (arrow).

Tightening torque 11 12 6AZ. See 11 12 CYLINDER HEAD WITH COVER .

Remove ignition coil cover (1) towards top.

61 00 ... Notes on Handling Wiring Harnesses And Cables

In general

To avoid damage, observe the following instructions

1. Avoid compressive and tensile loads
2. Make sure cables are laid without kinks or abrasions
3. Ensure non-contacting routing at sharp-edged body parts; use muckets if necessary
4. Secure additionally laid cables/leads with cable ties

In addition

Shielded cables (coaxial cables)

1. This may lead to indifferences in noise radiation and interference immunity at contact points in the shield
2. To satisfy the requirements of the type approval, it is essential to replace shielded cables completely

Fibre-optic cables

Note. Fibre-optic cables are colored differently as follows

1. Green = MOST ( M edia O riented S ystems T ransport) fibre-optic cables
2. Yellow = ISIS (Integrated S ervice and I nformation S erver) fibre-optic cables
3. Orange=repair fibre-optic cables

Treating cables and fibre-optic cables. See 61 13... TREATING CABLES AND FIBER-OPTIC CABLES .

Airbag cables

Repairing airbag cables. See 61 00 ... REPAIRING AIRBAG CABLES .

Ribbon cables

Repairing ribbon cables. See 61 13... REPAIRING RIBBON CABLES .

86 10 ... Positioning of Multitrailer Hood For Maintenance And Repair Work

For maintenance and repair work, raise the hood using a lifting platform. Twin-column lifting platforms, body lifting platforms and twin-stamp underfloor platforms are suitable. The seating plates and areas of the lifting platform must be adjustable according to the dimensions of (Scheme 51).

Scheme 51

The lifting platform must conform to the relevant legal provisions of the accident prevention regulations and be serviced as specified. Comply with the lifting platform operating instructions, in particular the safety instructions and the carrying capacity.

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Please comply with the following instructions before raising the hood

1. Raise only when it is unloaded
2. Ensure sufficient clearance between the seating plates/seating areas and the GFP edge of the hood
3. The hood must always be positioned in the middle of the lifting platform.

Scheme 52

See also:
• 00 MAINTENANCE AND GENERAL INFORMATION
• 61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY
• BATTERY CHARGING
• 61 61 01. ADJUSTING LEFT OR RIGHT WINDSCREEN WIPER
• 61 61 010 CHECKING/ADJUSTING CONTACT ANGLE OF WINDSCREEN WIPER ARMS ON WINDSCREEN
• 61 61 041 REPLACING BOTH WINDSCREEN WIPER BLADES
• 61 71 015 REMOVING AND INSTALLING/REPLACING A SPRAY NOZZLE IN WINDSCREEN WASHER SYSTEM
• 34 41 006 ADJUSTING PARKING BRAKE
• 34 00 012 PARKING BRAKE FUNCTION CHECK
• 34 41 ... OVERVIEW OF PARKING BRAKE
• 24 34 ... MANUAL EMERGENCY RELEASE OF TRANSMISSION LOCK
• 72 11 ... CHECKING AUTOMATIC SAFETY BELT
• 36 11 500 INITIALIZING RUN FLAT INDICATOR (RPA)
• 1.0 GENERAL INFORMATION ON PRESERVATION MEASURES
• 13 72 001 REPLACING BOTH AIR CLEANER ELEMENTS (N52K)
• 11 42 OIL FILTER AND PIPES
• 11 13 OIL PAN
• 64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION
• 64 31 017 REPLACING RECIRCULATED AIR MICROFILTER
• 13 32 051 REPLACING FUEL FILTER (M57T2)
• 12 12 011 REPLACING ALL SPARK PLUGS (N62, N62TU)
• 34 11 000 REMOVING AND INSTALLING/REPLACING BRAKE LININGS ON BOTH FRONT DISC BRAKES
• 34 11 220 REMOVING AND INSTALLING/REPLACING BOTH FRONT BRAKE DISCS
• 34 11 FRONT BRAKE E70
• 34 21 200 REMOVING AND INSTALLING/REPLACING BRAKE LININGS ON BOTH REAR DISC BRAKES (TEVES FLOATING CALIPER)
• 34 21 320 REMOVING AND INSTALLING OR REPLACING BOTH REAR BRAKE DISCS
• 34 41 220 REMOVING AND INSTALLING/REPLACING ALL HANDBRAKE SHOES
• 34 21 REAR BRAKE DISCS E70
• 34 00 050 REPLACING FLUID IN ABS/ASC+T BRAKE SYSTEM
• 34 00 ... GENERAL INFORMATION
• 33 11 REAR DIFFERENTIAL CASE WITH COVER
• AUTOMATIC TRANSMISSION - OPERATING FLUIDS
• 24 11 TRANSMISSION HOUSING, TRANSMISSION OIL SUMP
• 33 10 REAR AXLE DIFFERENTIAL E60, E61, E63, E64, E81, E82, E86, E87, E90, E91, E92, E9
• 13 71 000 REMOVING AND INSTALLING/REPLACING INTAKE FILTER HOUSING (N52K)
• 11 12 CYLINDER HEAD WITH COVER
• 61 13... TREATING CABLES AND FIBER-OPTIC CABLES
• 61 00 ... REPAIRING AIRBAG CABLES
• 61 13... REPAIRING RIBBON CABLES
• 86 21 ... REMOVING CENTERING PIN FROM MOUNTING BRACKET
• 00 Danger of Poisoning If Oil Is Ingested/Absorbed Through The Skin
• 00 Risk of Injury If Oil Comes Into Contact With Eyes And Skin
• 00 00 610 Engine Oil Service
• 00 00 ... Diagnostic Brief Test
• 00 00 ... Checking Lighting System
• 00 00 ... Windscreen Washer System: Checking Fluid Level, Topping Up If Necessary
• 00 00 ... Body: Check For Corrosion (Except Cavities)
• 00 00 ... Tires: Checking Inflation Pressure, Correcting If Necessary (Incl. Spare Wheel), Checking External Condition, Tread Depth, Pattern
• 00 00 ... Battery: Checking Display. If Necessary, Recharge Battery.
• 00 00 ... Steering Fluid Reservoir: Check Oil Level.
• 00 00 ... Checking Coolant Level And Concentration, Correcting If Necessary
• 00 00 ... Brake Lines And Connections: Visual Inspection For Leaks, Damage And Correct Position
• 00 00 ... Body and Underbody: Checking For Corrosion And Damage
• 00 00 ... Checking Roadworthiness (Test Drive)
