General Electrical System - Repair BMW X5 E70

12 00 ... INSTRUCTIONS ON STARTING AID

Do not start the engine with help of starting sprays.

Preparation

Conform with the following when starting engine with starting cable.

1. Ensure that jump lead wires are to appropriate cross-section size.
2. Only use fuse-protected jump leads.
3. Check whether the current supplying battery has 12 V voltage.
4. If engine is started from battery of another vehicle, ensure that there is no contact between the bodies of both vehicles.

If the battery in the vehicle supplying power is weak, start the engine of this vehicle and let it run at idling speed.

Carrying out

Always conform with the procedures to avoid injury to persons or damage to parts.

1. On automatic transmission, select "P" setting, apply handbrake.
2. Move the shift lever of vehicles with manual transmission into neutral and apply the parking brake.
3. Ensure that the jump leads cannot get caught in rotating parts, e.g. fan.
4. First connect positive terminals of both batteries with one jump lead (red).
5. Use positive connection point in engine compartment for vehicles with one battery in trunk.
6. Then attach second jump lead (black) to negative terminal of donor battery and to engine ground or body ground on vehicle to be started.

Danger of explosion!

After engine of vehicle to be started has started up, first disconnect the jump lead on the negative terminal/ground connection. Then remove jump lead from positive terminals.

61 00 ... BATTERY

Battery care and maintenance

In low-maintenance batteries, check the acid level at least once a year. If necessary, top up with distilled water up to the top marking.

The increasing number of electronic control units in the car reduces the self-discharging time of the battery (even in standby mode). To maintain the battery service life and to avoid exhaustive discharging, recharge laid-up vehicles every 6 weeks at the latest. The time for self-discharging depends on vehicle type and equipment specification.

Battery test

The battery acid density can be used to measure the charge state. However this test produces uncertainty caused by a design-related range of variation. The acid density e.g. for a charged battery is 1.28 kg/l (in the tropical version the acid density is 1.23 kg/l).

Another interference factor is the acid lamination immediately after filling with distilled water.

Battery wear with partially sulphated and/or heavily contaminated plates will also lead to incorrect acid density test results.

61 00 ... DIAGNOSIS FOR CONDITION BASED SERVICE

Note. Red symbol for pre-delivery check

The vehicle is coded at the end of the assembly line so that the red symbol for the pre-delivery check is shown in the Next Service display (same symbol as vehicle check).

The symbol is a reminder to the Service staff that the pre - delivery check has not yet been carried out on this car.

Note. Do not carry out a reset.

Do not confuse this function with the "Vehicle check" maintenance scope.

Do not carry out a reset via the instrument cluster.

When carrying out the pre-delivery check with the "Transport Mode/Pre-delivery check" service function

The symbol is automatically removed from the display after the service function has been executed.

Scheme 1

Scheme 2

4 service functions are available in the BMW diagnosis system for maintenance

1. Transport Mode/Pre-delivery check
2. CBS Correction Tester Data
3. Reset CBS
4. CBS Correction Vehicle Data

Service function: Transport Mode/Pre-delivery check

To be able to hand over a vehicle to the customer in proper working order, it is essential to execute the "Transport Mode/Pre-delivery check" service function.

The following items are worked through during the pre-delivery check

1. Deactivation of transport mode.
2. An adaptation process must be activated in order to determine the vehicle-specific mileage/kilometrage per week. Transport and immobilization periods before the vehicle is delivered to the customer therefore have no effect on the customer-specific weekly mileage/kilometrage. The weekly mileage/kilometrage is used to control escalation from "green" to "yellow" (approx. 4 weeks before "red") for maintenance scopes with remaining distances. The averaged mileage/kilometrage of the last 6 weeks is taken into account here.
3. Coding or blanking out of the legally prescribed intervals for the statutory vehicle inspection and statutory exhaust emissions test.
4. Input of the target dates for the statutory vehicle inspection and the statutory exhaust emissions test (automatic or manual). Automatic: By input of the date of first registration and of the time interval Manual: By direct input of the target date
5. Entry of local, service-related phone numbers, depending on vehicle equipment specification (e.g. BMW Group Mobile Service, BMW Hotline, customer's home dealer). The country-specific phone numbers are displayed in the BMW diagnosis system as a reference text. The phone numbers can simply be read off during the input prompt.
6. Reference to initialization of TeleService, depending on vehicle equipment specification.
7. Checking and if necessary setting of the on-board date for the vehicle.
8. Entry of the date for first registration of the vehicle.
9. Now clear the fault memory.

Note. Reducing input expenditure. Standardized data are stored in the BMW diagnosis system (for repeated use) in the interests of minimizing the time spent on making inputs in the garage/workshop. The standardized data can be changed with the "CBS Correction Tester Data" service function.

Service function: CBS Correction Tester Data

Data are automatically stored in the vehicle with the "Pre-delivery check" service function.

The standardized data can be changed with the "CBS Correction Tester Data" service function.

The following standardized data can be changed

1. Phone numbers: BMW Group Mobile Service BMW Hotline Customer's home dealer The country-specific phone numbers are contained as reference texts in the BMW diagnosis system (read off during the input prompt). The phone numbers must be input with the international dialling code.
2. Legally prescribed vehicle inspection (country-specific): Coding or blanking out Interval for calculating the target date The target date is calculated on the basis of the date of first registration.
3. Legally prescribed exhaust emissions test (country-specific): Coding or blanking out Interval for calculating the target date The target date is calculated on the basis of the date of first registration.

Note. Automatic function after installation of the BMW diagnosis system. The standardized data are automatically established when the pre-delivery check is carried out for the first time. It is therefore not necessary to input the data separately.

Service function: Reset CBS Condition Based Service

A maintenance scope can be reset with the "Reset CBS Condition Based Service" service function. Even when availability is over 80 %.

The benefit of reset via the BMW diagnosis system is that the on-board date is corrected automatically.

The individual maintenance scopes are displayed in the BMW diagnosis system with service counter and availability.

1. The service counter is reset by one counter on resetting. All service counters are set to "1" on new vehicles. The service counters are used in the Service Acceptance/Reception Module (SAM) on a scope-specific basis for controlling additional work.
2. Availability is set to 100 % on resetting. Availability in % is the wear value of the maintenance scope. The greater the availability, the longer it is to the next maintenance scope. 0 % means that the maintenance measure must be carried out.

Service function: CBS Correction Vehicle Data

The "CBS Correction Vehicle Data" service function is available if a reset has been carried out erroneously . In this way, the availability of a maintenance scope can be corrected to a realistic value.

A data or a mileage/kilometer reading is entered for correction. These data are converted internally into an availability in %. In so doing, the BMW diagnosis system only accepts a smaller value as the current reading in the control unit. In addition, the service counter of the scope is automatically reduced by one counter.

The inputs are used in the Service Booklet to determine the realistic availability. A realistic availability can be reconstructed on a scope-specific basis by means of the last maintenance measure (with mileage/km reading and date).

This does not include correcting the availability for brake pads. The brake pad residual thickness must be measured and input (in millimeters).

Note. Reference for distance-and time-dependent maintenance scopes For a correction, the availability is referred to the distance - and time-dependent calculation.

61 00 ... NOTES ON HANDLING OPTICAL FIBERS

Note. The optical fibers are colored differently as follows: Green= MOST ( M edia O riented S ystems T ransport) optical fibers Yellow= ISIS ( I ntelligent S afety and I ntegration S ystem) optical fibers Orange=repair optical fibers Follow instructions for processing cables and optical fibers. See 61 13... TREATING CABLES AND FIBER-OPTIC CABLES .

61 00 ... REPAIRING AIRBAG CABLES

Safety regulations

Safety regulations for handling components of airbag system. See 72 00 ... SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS .

Instructions for disconnecting and connecting battery. See 12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY .

Procedure for cable repair

In event of non-visible damage to wiring harness

Disconnect plug connection on airbag module or on adapter plug. It is absolutely vital to disconnect the contacts in succession as there is a risk of them being mixed up! Cut through one cable after the other at an appropriate position, do not under any circumstances cut through both cables at the same time. Insulate cables remaining in wiring harness with insulating tape. Now disconnect plug connection on airbag control unit. Unpin contacts. Cut through one cable after the other at an appropriate position and insulate with insulating tape, do not under any circumstances cut through both cables at the same time. Pin contacts of repair cable for airbag control unit in control unit plug, assignment of repair cables is relevant. Lay repair cable in car parallel to existing airbag lead. Now pin in contacts for airbag control unit or contacts of adapter plug, assignment of repair cables is relevant. Cut off excess length of repair cable in proximity (visible area) of airbag module or of adapter plug. Twist open cables. With the connectors and shrink-fit hoses in the Electronic Parts Catalogue (EPC), reconnect the cables with the same cable colors. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

In event of visible damage

Expose cable at damaged areas. Cut through one cable after the other at an appropriate position and insulate cables no longer required in wiring harness with insulating tape, do not under any circumstances cut through both cables at the same time. Now, depending on the scope of work, unpin contacts either on airbag control unit/airbag module or on adapter plug. Cut off unpinned cables. Insulate cables remaining in wiring harness with insulating tape. Now pin in contacts of repair cable, assignment of repair cables is relevant. Lay repair lead in car parallel to existing airbag lead up to cutting point. Cut off excess length of repair lead. Twist open cables. Connect cables with connectors and shrink-fit hoses in Electronic Parts Catalogue (EPC), assignment of repair cables is relevant. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY

Battery acid is highly corrosive

Do not allow any battery acid to come into contact with the eyes, the skin or clothing. Therefore wear protective clothing, gloves and goggles.

Do not tilt the battery, acid may emerge from the vent opening.

In event of contact with acid

If acid is splashed into the eyes, rinse them immediately for several minutes with clear water. You must then consult a doctor without delay.

If acid is splashed onto the skin or clothing, neutralize it immediately with a soapy solution and rinse with lots of water.

Seek medical attention immediately if battery acid is accidentally swallowed.

Explosion hazard

Strictly no flames, sparks, naked light or smoking!

A highly explosive mixture of electrolytic gas is created when batteries are charged. The rooms where charging is carried out must therefore always be well ventilated.

Avoid the formation of sparks when handling cables, wiring and electrical devices.

Turn the ignition lock to the 0 position before disconnecting or connecting the battery.

Do not place tools or any similar object on the battery (danger of short-circuiting and explosion!).

61 12... GENERAL INFORMATION ON INTELLIGENT BATTERY SENSOR (IBS)

Note. Do not connect continuous trickle charger to the cigarette lighter. The cigarette lighter is powered by the rear distribution box via a relay. This relay drops out after terminal 15 OFF. This means that a continuous trickle charger connected to the cigarette lighter is disconnected from the battery. Charge the battery via the jump-start connection points. Only then can the power supply be registered by the vehicle.

Note. Battery draining possible in spite of the intelligent battery sensor IBS being fault-free. A battery can be drained (e.g. with lights or radio switched on) even when the IBS functions perfectly in conjunction with power management. For this reason, only replace the IBS when a corresponding fault is entered in the DME or DDE.

61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS

Special tools required

1. 61 0 300
2. 61 0 400
3. 61 1 150

Abbreviations and what they mean

ABBREVIATIONS MEANINGS

Ultrasonic-welded connectors

Ultrasonic-welded connectors (1) can be identified by the welds (2) on their longitudinal side.

The contacts of these connectors cannot be replaced. Replace plug completely.

Scheme 3

Note. Special tools referred to in the repair instructions below are contained in the following special tool kits

Release and press-out tool 61 1 150

Replaced as from 09/2005 by: 61 0 300

61 0 400

Repair instructions for opening plug housings and removing contacts of different plug systems

For plug contact systems not listed, refer to appropriate Service Information.

Plug system D 1.5/D 2.5

1. Circular plugs, 7 -, 8-pin, System D 2.5
2. Circular plugs, 13-pin, System D 2.5
3. Circular plugs, 20-pin, System D 2.5
4. Circular plugs, 4 -, 7-, 10 -, 12 -, 25-pin, System D 1.5/D 2.5
5. In-line plugs, 15-pin, System D 2.5
6. In-line plugs, 8-, 12-pin, System D 2.5
7. In-line plugs, 30-pin, System D 2.5
8. In-line plugs, 20-pin, System D 2.5

Plug system JPT/MDK/DFK

1. In-line plugs, 2-pin, System JPT ELA
2. In-line plugs, 2-pin, System MDK 3plus 2.8
3. In-line plugs, 4-pin, System DFK ELA

Plug system Elo/Elo-Power

1. In-line plugs, 4-, 10-pin, System Elo
2. In-line plugs, 6-to 50-pin, System Elo
3. In-line plugs, 3-, 6-pin, System Elo-Power 2.8

Plug system MQS/MPQ

1. In-line plugs, 6-, 8-pin, System MQS
2. In-line plugs, 2-pin, System MPQ 2.8
3. Control unit plugs, 25-, 35-, 55-, 83-, 88-pin
4. In-line plugs, 24-pin, Hybrid System MQS/MPQ
5. Socket housing 42-, 43-pin, Hybrid System MQS / MPQ
6. Socket housings 2x21-, 2x27-pin, Hybrid System MQS/MPQ, Elo/Elo-Power
7. In-line plugs, 30-pin, Hybrid System MQS/MPQ
8. Socket housings, 5-, 8-pin, System MQS/MPQ
9. Socket housing (radio plug), Hybrid System MQS/MPQ

61 13.. UNLOCKING AND DISCONNECTING DIFFERENT PLUG CONNECTIONS

Note. Examples of unlocking and disconnecting different plug connections.

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Scheme 4

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Scheme 5

Open clip in direction of arrow and disconnect plug connection in direction of arrow.

Scheme 6

Press lock and disconnect plug connection in direction of arrow.

Scheme 7

Press lock and disconnect plug connection in direction of arrow.

Scheme 8

Press lock and disconnect plug connection in direction of arrow.

Scheme 9

Press lock and disconnect plug connection in direction of arrow.

Scheme 10

Press lock and disconnect plug connection in direction of arrow.

Scheme 11

Press lock and disconnect plug connection in direction of arrow.

Scheme 12

61 13... TREATING CABLES AND FIBER-OPTIC CABLES

Special tools required

1. 61 1 190
2. 61 4 320

Note. Special tools referred to in the repair instructions below are contained in the following special tool kits

SPECIAL TOOL KITS REFERENCE

Subject of repair instructions

1. Special tools for wiring harness repairs . See «61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-special-tools-for-wiring)
2. Cutting to length and stripping insulation from cables . See «61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-to-length-and) .
3. Crimping stop parts (contacts) . See «61 13 CRIMPING STOP PARTS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-crimping-stop-parts) .
4. Butt connector for repairing a plug connection . See «61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-butt-connector-for-repairing) .
5. Fan connector for retrofitting/repairs . See «61 13 INSTALLING FAN CONNECTOR FOR RETROFITTING/REPAIRS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-installing-fan-connector-for) .
6. Cutting to length and stripping insulation from optical fibers . See «61 13... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBERS TO LENGTH»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-off-stripping-insulation) .
7. Crimping optical fibers . See «61 13... CRIMPING OPTICAL FIBERS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-crimping-optical-fibers) .
8. Insulation displacement connector for repairing ribbon cables . See «61 13... REPAIRING RIBBON CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-repairing-ribbon-cables) .

61 20 908 PERFORMING BATTERY "POWER RESET" (FOR PROGRAMMING/CODING CONTROL UNIT(S))

The following steps must be carried out for a "power reset"

1. Switch off and disconnect battery charger
2. Switch off ignition Cars with ignition key: Turn ignition key to 0 position Cars with identification sensor: Remove identification sensor from slot Cars with comfort access system: Make sure terminal is in 0 position
3. Disconnect battery negative terminal. See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
4. Reconnect battery negative terminal (to ensure bus activity)
5. Waiting time (5-10 seconds)
6. Disconnect battery negative terminal
7. Waiting time (1 minute)
8. Connect battery negative terminal and tighten. Tightening torque. See «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-tightening-torques) .
9. Connect and switch on battery charger
10. Switch ignition on

Note. Do not connect continuous trickle charger to the cigarette lighter. The cigarette lighter is powered by the rear distribution box via a relay. This relay drops out after terminal 15 OFF. This means that a continuous trickle charger connected to the cigarette lighter is disconnected from the battery. Charge the battery via the jump-start connection points. Only then can the power supply be registered by the vehicle.

Note. Battery draining possible in spite of the intelligent battery sensor IBS being fault-free. A battery can be drained (e.g. with lights or radio switched on) even when the IBS functions perfectly in conjunction with power management. For this reason, only replace the IBS when a corresponding fault is entered in the DME or DDE.

61 12 002 REPLACING BATTERY POSITIVE LEAD (FROM BATTERY TO LUGGAGE COMPARTMENT CONNECTOR)

Necessary preliminary tasks

1. Remove flap in luggage compartment panel on right. See «51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-172-removing-and-installingreplacing) .
2. Disconnect negative battery cable . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .

Disconnect plug connection (1) on safety battery terminal (2).

Open cover and release nut (3).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Open cover (2) and slacken nut underneath.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Using a screwdriver, expand locking bracket (6) at lower end and clip out.

Raise distribution box slightly and remove safety battery terminal.

Scheme 13

Open cover (1).

Slacken nut (2).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect battery positive lead.

Scheme 14

61 12 013 REPLACING BATTERY NEGATIVE LEAD

Necessary preliminary tasks

1. Raise luggage compartment floor trim

Release screws (1).

Remove battery cover (2) upwards.

Scheme 15

Loosen nut (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Remove battery negative lead with IBS.

Disconnect plug connection (2).

Unscrew nut (3).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Scheme 16

61 12 062 REPLACING WIRING HARNESS FOR FRONT BUMPER

Necessary preliminary tasks

1. Remove front bumper trim . See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .

Disconnect plug connections (1) on ultrasonic transducer.

Unclip wiring harness (2) from bumper trim.

Installation

Make sure wiring harness (2) is laid correctly.

Scheme 17

61 12 067 REPLACING WIRING HARNESS FOR REAR BUMPER

Necessary preliminary tasks

1. Remove rear bumper trim . See «51 12 156 REMOVING AND INSTALLING REAR BUMPER TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-12-156-removing-and-installing) .

Disconnect plug connections (1) on ultrasonic transducer.

Unclip wiring harness from bumper trim and remove.

Installation

Make sure wiring harness is correctly laid.

Scheme 18

61 12 200 REPLACING WIRING HARNESS IN LEFT OR RIGHT FRONT DOOR

Necessary preliminary tasks

1. Close front side window completely
2. Remove front door trim . See «51 41 000 REMOVING AND INSTALLING LEFT OR RIGHT FRONT DOOR TRIM PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-41-000-removing-and-installing) .
3. Remove front acoustic insulation . See «51 48 060 REMOVING AND INSTALLING/REPLACING SOUND INSULATION IN LEFT OR RIGHT FRONT DOOR»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair) .

Unlock plug connections (1) and disconnect.

Unclip door wiring harness at points (2).

Installation

Make sure door wiring harness is correctly laid.

Scheme 19

Note. Front side panel shown removed for purposes of clarity. Release screw (1), fold door wiring harness plug on A-pillar (2) downwards slightly and remove. Unlock plug connection behind and disconnect. Pull rubber grommet (3) in direction of arrow out of front door (4). Feed out door wiring harness towards front to A-pillar and remove.

Scheme 20

61 12 210 REPLACING WIRING HARNESS IN LEFT OR RIGHT REAR DOOR

Necessary preliminary tasks

1. Close rear side window completely
2. Remove rear door trim panel . See «51 42 000 REMOVING AND INSTALLING LEFT OR RIGHT REAR DOOR TRIM PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-42-000-removing-and-installing) .
3. Remove rear acoustic insulation . See «51 48 070 REMOVING AND INSTALLING/REPLACING SOUND INSULATION ON LEFT OR RIGHT REAR DOOR»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair) .

Unfasten plug connection (1) and disconnect.

Unclip door wiring harness at points (2).

Installation

Make sure door wiring harness is correctly laid.

Scheme 21

Release screw (1), fold door wiring harness plug on B-pillar (2) downwards slightly and remove.

Unlock plug connection behind and disconnect.

Pull rubber grommet (3) out of rear door.

Feed out door wiring harness towards front to B-pillar and remove.

Scheme 22

61 12 850 Replacing ribbon cable (CAS)

Necessary preliminary tasks

1. Remove «Start/Stop switch»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-014-removing-and-installingreplacing) .
2. Remove trim for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .

Disconnect plug connection (1).

Disconnect Plug Connection (1). Scheme 23

Note. Instrument panel (2) removed for purposes of clarity.

Pull off insulating tape (1) with ribbon cable (3) from instrument panel (2). Installation: Make sure ribbon cable is laid correctly. Secure ribbon cable with new insulating tape to instrument panel (2).

Pull Off Insulating Tape (1) With Ribbon Cable (3) From Instrument Panel (2). Scheme 24

Special tools required

1. 61 0 300
2. 61 0 400
3. 61 1 150

Abbreviations and what they mean

ABBREVIATIONS MEANINGS

Ultrasonic-welded connectors

Ultrasonic-welded connectors (1) can be identified by the welds (2) on their longitudinal side.

The contacts of these connectors cannot be replaced. Replace plug completely.

Note. Special tools referred to in the repair instructions below are contained in the following special tool kits

Release and press-out tool 61 1 150

Replaced as from 09/2005 by: 61 0 300

61 0 400

Repair instructions for opening plug housings and removing contacts of different plug systems

For plug contact systems not listed, refer to appropriate Service Information

Plug system D 1.5/D 2.5

1. Circular plugs, 7 -, 8-pin, System D 2.5
2. Circular plugs, 13-pin, System D 2.5
3. Circular plugs, 20-pin, System D 2.5
4. Circular plugs, 4 -, 7-, 10 -, 12 -, 25-pin, System D 1.5/D 2.5
5. In-line plugs, 15-pin, System D 2.5
6. In-line plugs, 8-, 12-pin, System D 2.5
7. In-line plugs, 30-pin, System D 2.5
8. In-line plugs, 20-pin, System D 2.5

Plug system JPT/MDK/DFK

1. In-line plugs, 2-pin, System JPT ELA
2. In-line plugs, 2-pin, System MDK 3plus 2.8
3. In-line plugs, 4-pin, System DFK ELA

Plug system Elo/Elo-Power

1. In-line plugs, 4-, 10-pin, System Elo
2. In-line plugs, 6-to 50-pin, System Elo
3. In-line plugs, 3-, 6-pin, System Elo-Power 2.8

Plug system MQS/MPQ

1. In-line plugs, 6-, 8-pin, System MQS
2. In-line plugs, 2-pin, System MPQ 2.8
3. Control unit plugs, 25-, 35-, 55-, 83-, 88-pin
4. In-line plugs, 24-pin, Hybrid System MQS/MPQ
5. Socket housing 42-, 43-pin, Hybrid System MQS / MPQ
6. Socket housings 2x21-, 2x27-pin, Hybrid System MQS/MPQ, Elo/Elo-Power
7. In-line plugs, 30-pin, Hybrid System MQS/MPQ
8. Socket housings, 5-, 8-pin, System MQS/MPQ
9. Socket housing (radio plug), Hybrid System MQS/MPQ

Note. Examples of unlocking and disconnecting different plug connections.

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Open clip in direction of arrow and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Scheme 25

Note. The optical fibers are colored differently as follows: Green= MOST ( M edia O riented S ystems T ransport) optical fibers Yellow= ISIS ( I ntelligent S afety and I ntegration S ystem) optical fibers Orange=repair optical fibers Follow instructions for processing cables and optical fibers. . See 61 13... TREATING CABLES AND FIBER-OPTIC CABLES .

Safety regulations

Safety regulations for handling components of airbag system. See 72 00 ... SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS .

Instructions for disconnecting and connecting battery. See 12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY .

Procedure for cable repair

In event of non-visible damage to wiring harness

Disconnect plug connection on airbag module or on adapter plug. It is absolutely vital to disconnect the contacts in succession as there is a risk of them being mixed up! Cut through one cable after the other at an appropriate position, do not under any circumstances cut through both cables at the same time. Insulate cables remaining in wiring harness with insulating tape. Now disconnect plug connection on airbag control unit. Unpin contacts. Cut through one cable after the other at an appropriate position and insulate with insulating tape, do not under any circumstances cut through both cables at the same time. Pin contacts of repair cable for airbag control unit in control unit plug, assignment of repair cables is relevant. Lay repair cable in car parallel to existing airbag lead. Now pin in contacts for airbag control unit or contacts of adapter plug, assignment of repair cables is relevant. Cut off excess length of repair cable in proximity (visible area) of airbag module or of adapter plug. Twist open cables. With the connectors and shrink-fit hoses in the Electronic Parts Catalogue (EPC), reconnect the cables with the same cable colors. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

In event of visible damage

Expose cable at damaged areas. Cut through one cable after the other at an appropriate position and insulate cables no longer required in wiring harness with insulating tape, do not under any circumstances cut through both cables at the same time. Now, depending on the scope of work, unpin contacts either on airbag control unit/airbag module or on adapter plug. Cut off unpinned cables. Insulate cables remaining in wiring harness with insulating tape. Now pin in contacts of repair cable, assignment of repair cables is relevant. Lay repair lead in car parallel to existing airbag lead up to cutting point. Cut off excess length of repair lead. Twist open cables. Connect cables with connectors and shrink-fit hoses in Electronic Parts Catalogue (EPC), assignment of repair cables is relevant. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION

Special tools required

1. 61 0 300
2. 61 9 040

Note. The repair range IV for vehicle electrical system contained the required special tools and individual parts for retrofitting and repair work with the aid of fan connectors. The case can no longer be ordered. Order individual parts for wiring harness repair through BMW Parts Service.

Special tools

Scheme 26

1. Special tool 61 9 040

Choose repair kit.

Example: Repair kit, circular plug system D 2.5.

Scheme 27

Remove following parts

Scheme 28

1. Prepackaged end of cable with requisite wire cross-section
2. Crimp connector for selected wire cross-section
3. Shrink-fit hose

Open secondary lock on housing.

Mark damaged contact (4) with socket number of housing and press it out of housing using relevant special tool contained in special tool kit 61 0 300.

Refer to repair instructions

See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

Scheme 29

Scheme 30

Observe following procedure

1. Cut off wire with faulty contact at point which is easily accessible.
2. Strip wiring-harness wire end (6).
3. Cut preassembled wire end (7) to length and strip insulation.

Refer also to repair instruction

See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Crimp butt connector on preassembled wire end.

Refer to repair instructions

See 61 13 CRIMPING STOP PARTS .

Scheme 31

Push shrink-fit hose (8) onto free wire end.

Scheme 32

Crimp unused wire end to butt connector.

Scheme 33

Pull shrink-on sleeve over butt connector.

Scheme 34

With hot air blower, shrink the shrink-on sleeve on both sides

(9) of shrink-fit hose until glue emerges uniformly all round.

Insert contact in housing.

Close secondary lock on housing.

Scheme 35

61 13 CRIMPING STOP PARTS

Special tools required

1. 12 1 080
2. 12 1 081
3. 12 1 083

Spare parts for in-car electronics (housing and contacts)

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Crimping butt connectors and contact sleeves for fan connectors up to 2.5 mm 2
2. Crimping butt connectors and contact sleeves for fan connectors from 2.5 mm 2
3. Crimping contact sleeves for fan connectors 4 mm 2 and ignition cable contacts Special tool kit 12 1 080 is used to fit ignition cable contacts and to crimp 4 mm 2 contact sleeves for fan connectors. 12 1 081 (hand crimping tool) 12 1 083 (matrix) Refer to repair instructions: See «SPECIAL TOOLS FOR WIRING HARNESS REPAIRS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-special-tools-for-wiring) Unlock special tool 12 1 081: Squeeze grips (1) lightly and push unlocking lever (2) in direction of arrow. Or: Compress handles as far as they will go, tool unlocks automatically. Insert contact sleeve 4 mm 2 in nest with lock (1) as far as it will go. Preload contact by squeezing matrix in crimping tool. Grip contact (1) firmly only, do not crimp. NOTE: Follow procedure for cutting and stripping insulation from cables. See «61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-to-length-and) . Insert stripped end of wire (7) in the contact. Ensure insulation and stripped wire end are correctly laid in contact. Compress crimping tool as far as it will go. Crimping tool unlocks automatically. Take contact out of crimping tool.
4. Checking crimping Check insulation crimp (8) and wire crimp (9) against following illustrations to ensure crimps are correctly located. NOTE: Illustration shows butt connectors and contact sleeves for fan connectors knocked on one side. The crimping procedure is identical here. Correct crimping: Visible conductor end (10). Visible insulation end (11). Incorrect crimping: Conductor end (10) inserted too far. Insulation end (11) in wire crimp. If necessary, repeat crimping with a new contact. Incorrect crimping: Conductor end (10) not visible. Insulation end (11) not visible. If necessary, repeat crimping with a new contact.

61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES

Stripped length

STRIPPED LENGTH SPECIFICATION

61 13 INSTALLING FAN CONNECTOR FOR RETROFITTING/REPAIRS

Special tools required

1. 61 9 040
2. 61 9 041
3. 61 9 042

Note. The repair range IV for vehicle electrical system contained the required special tools and individual parts for retrofitting and repair work with the aid of fan connectors. The case can no longer be ordered. Order individual parts for wiring harness repair through BMW Parts Service.

Special tools

1. special tool 61 9 040

Choose contact sleeve (up to 4 mm 2 ) in accordance with wire cross-section.

Scheme 45

Alternatively

Choose contact sleeves (up to 2.5 mm 2 ) for fan connectors.

Scheme 46

Cut through wire loop in wiring harness at established point.

Strip insulation from both wire ends.

Refer to repair instructions

CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES

Crimp contact sleeves on both wire ends. See 61 13 CRIMPING STOP PARTS .

Note. If using repair kit for contact sleeves, refer to repair instruction BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Scheme 47

Crimp connecting cable for retrofitting likewise with contact sleeve.

Scheme 48

Cut required number of poles to length for fan connectors.

Scheme 49

Special tool 61 9 041 (hand crimping tool) in conjunction with 61 9 042 (matrix) are used for pushing contact sleeves onto fan connectors.

Refer to repair instructions

SPECIAL TOOLS FOR WIRING HARNESS REPAIRS

Scheme 50

Unlock special tool 61 9 041

Squeeze grips (1) lightly and push unlocking lever (2) in direction of arrow.

Or

Compress handles as far as they will go, tool unlocks automatically.

Scheme 51

Insert prepared fan connector (3) in special tool 61 9 041 / 61 9 042.

Scheme 52

Attach wire with contact sleeve to fan connector.

Scheme 53

Press crimping tool together and slide contact sleeve firmly home.

Scheme 54

Push on further contact sleeves for potential branching.

Scheme 55

Installation in wet area (engine compartment, wheel arch)

Apply sealing compound on both sides and press into contacts (1).

Fit shrink-fit hose and heat up with hot air blower (2) (approx. 250°C).

Scheme 56

Note. Ensure that fan connector has sufficient contact surface on mounting point. Do not heat shrink-fit hose on edges of fan connector too strongly, risk of cracking.

Allow shrink-fit hose to cool down until hand-warm. Then press sealing material again into contacts and onto edges of fan connector.

If necessary, carefully heat shrink-fit hose again.

Installation in dry area (interior, luggage compartment)

Slide assembled fan connector into insulation housing until it locks into place.

Scheme 57

Special tools required

1. 61 0 300
2. 61 0 400
3. 61 1 150

Abbreviations and what they mean

ABBREVIATIONS MEANINGS

Ultrasonic-welded connectors

Ultrasonic-welded connectors (1) can be identified by the welds (2) on their longitudinal side.

The contacts of these connectors cannot be replaced. Replace plug completely.

Note. Special tools referred to in the repair instructions below are contained in the following special tool kits

Release and press-out tool 61 1 150

Replaced as from 09/2005 by: 61 0 300

61 0 400

Repair instructions for opening plug housings and removing contacts of different plug systems

For plug contact systems not listed, refer to appropriate Service Information

Plug system D 1.5/D 2.5

1. Circular plugs, 7 -, 8-pin, System D 2.5
2. Circular plugs, 13-pin, System D 2.5
3. Circular plugs, 20-pin, System D 2.5
4. Circular plugs, 4 -, 7-, 10 -, 12 -, 25-pin, System D 1.5/D 2.5
5. In-line plugs, 15-pin, System D 2.5
6. In-line plugs, 8-, 12-pin, System D 2.5
7. In-line plugs, 30-pin, System D 2.5
8. In-line plugs, 20-pin, System D 2.5

Plug system JPT/MDK/DFK

1. In-line plugs, 2-pin, System JPT ELA
2. In-line plugs, 2-pin, System MDK 3plus 2.8
3. In-line plugs, 4-pin, System DFK ELA

Plug system Elo/Elo-Power

1. In-line plugs, 4-, 10-pin, System Elo
2. In-line plugs, 6-to 50-pin, System Elo
3. In-line plugs, 3-, 6-pin, System Elo-Power 2.8

Plug system MQS/MPQ

1. In-line plugs, 6-, 8-pin, System MQS
2. In-line plugs, 2-pin, System MPQ 2.8
3. Control unit plugs, 25-, 35-, 55-, 83-, 88-pin
4. In-line plugs, 24-pin, Hybrid System MQS/MPQ
5. Socket housing 42-, 43-pin, Hybrid System MQS / MPQ
6. Socket housings 2x21-, 2x27-pin, Hybrid System MQS/MPQ, Elo/Elo-Power
7. In-line plugs, 30-pin, Hybrid System MQS/MPQ
8. Socket housings, 5-, 8-pin, System MQS/MPQ
9. Socket housing (radio plug), Hybrid System MQS/MPQ

61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS

Special tools required

1. 12 1 080
2. 61 0 200
3. 61 0 210
4. 61 0 220
5. 61 0 230
6. 61 0 300
7. 61 0 400
8. 61 1 190
9. 61 4 320
10. 61 9 041
11. 61 9 044

Repair range, vehicle electrical system

Release and press-out tool

1. Special tool 61 0 300
2. Special tool 61 0 400 (MINI N12/N14)

Handling

1. Opening plug housings and removing contacts of different plug systems. See «61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-opening-plug-housings-and) .

Scheme 58

Cutting to length and stripping insulation from cables

Handling

1. Cutting to length and stripping insulation from cables . See «61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-to-length-and) .

Crimping stop parts (small contacts)

Scheme 59

1. Special tool 61 4 320 Tool without crimping head Crimping head ( stripping insulation and cutting fiber-optic cables to length ) Crimping head ( crimping fiber-optic cable contacts ) Crimping head ( crimping MQS contacts ) Crimping head ( crimping MPQ contacts ) Replacement blade (face-cutting fiber-optic cables) Replacement blade with tool (insulation stripping unit) Universal crimping head ( SI 2 04 06 293 )

Crimping stop parts (large contacts)

1. Special tool 61 0 200 (crimping set)
2. Special tool 61 0 210 (matrix set LSK 8)
3. Special tool 61 0 220 (matrix set SLK 2.8)
4. Special tool 61 0 230 (matrix set MAK 8 / DFK4)

Scheme 60

Crimping antenna elbow plugs

1. Special tool 61 9 041 (hand crimping tool)
2. Special tool 61 9 044 (matrix)

Handling

Scheme 61

1. Antenna elbow plug on radio receiver

Repair kit for ignition cables and for crimping fan connector receptacles 4 mm 2

1. Special tool 12 1 080

Handling

Scheme 62

1. Crimping stop parts (contacts) . See «61 13 CRIMPING STOP PARTS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-crimping-stop-parts) .

Repairing ribbon cables

1. Special tool 61 1 190

Handling

Scheme 63

1. Repairing ribbon cables

61 13.. REMOVING AND INSTALLING/REPLACING FIBER - OPTIC CABLE CONNECTOR

Necessary preliminary tasks

1. Remove side section on rear seat backrest on left. See «52 26 008 REMOVING AND INSTALLING/REPLACING LEFT/RIGHT SIDES OF BACKREST ON REAR SEAT BACKREST (THROUGH-LOADING)»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-26-008-removing-and-installingreplacing) .

Remove fiber optic cable (1) from holder (2).

Unlock fiber optic cable plug (3) and remove.

Scheme 64

Carefully raise cover cap (1) and remove from fiber optic cable plug (2).

Scheme 65

Carefully raise lock (1) and pull fiber optic cable (2) out of fiber optic cable plug (3).

Scheme 66

Note. Examples of unlocking and disconnecting different plug connections.

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Press lock and open clip in direction of arrow.

Disconnect plug connection.

Open clip in direction of arrow and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

Press lock and disconnect plug connection in direction of arrow.

61 13... BASE OF TAB CONNECTOR HOUSINGS

Unlock hook (1) with special tool 61 1 360 and slide plug housing downwards out of base.

Scheme 67

61 13... CRIMPING MICRO POWER QUADLOCK CONTACTS (MPQ)

Special tools required

1. 61 4 320

To crimp MPQ contacts, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 325 (2) from crimping set 61 4 320.

Note. Pliers (1) open automatically as far as they will go when handles are pressed together.

Scheme 68

Open pliers (1).

Note. Place contact (2) with utmost care in designated nest (observe cable cross-section) in crimping head (3). Make sure it is exactly positioned.

Place MPQ contact (2) in crimping head (3).

Close pliers (1) one notch.

Scheme 69

Note. Follow procedure for cutting and stripping insulation from cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Insert stripped cable (2).

Close pliers (1) fully.

Open pliers (1) and remove cable (2).

Note. Check contact for correct crimping.

Scheme 70

61 13... CRIMPING MICRO QUADLOCK SYSTEM CONTACTS (MQS)

Special tools required

1. 61 4 320

To crimp MQS contacts, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 324 (2) from crimping set 61 4 320.

Note. Pliers (1) open automatically as far as they will go when handles are pressed together.

Scheme 71

Open pliers (1).

Fold up contact carrier (2).

Insert MQS contact (3) in contact carrier (2).

Fold back contact carrier (2).

Scheme 72

Note. Follow procedure for cutting and stripping insulation from cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Close pliers (1) one notch.

Insert stripped cable (2).

Close pliers (1) fully.

Scheme 73

Open pliers (1).

Open contact carrier (2) gently and carefully remove MQS contact.

Note. Check contact for correct crimping.

Scheme 74

61 13... CRIMPING ANNULAR CONTACTS

Special tools required

1. 61 4 320

Crimping annular contacts

Special tool 61 4 320

61 13... CRIMPING OPTICAL FIBERS

Special tools required

1. 61 4 320

To crimp optical fibers, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 323 (2) from crimping set 61 4 320.

Note. Pliers (1) open automatically as far as they will go when handles are pressed together.

Scheme 75

Move contact guide by means of stop lever (1) into corresponding position (pin contact or jack).

Scheme 76

Open pliers (2).

Place pin contact or jack (1) in crimping head and secure with locking lever (3).

Scheme 77

Note. Follow procedure for cutting and stripping insulation from optical fibers. See 61 13... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBERS TO LENGTH .

Insert stripped optical fiber (1) as far as it will go into pin contact or jack (2).

Close pliers (3) fully.

Open pliers (3) and locking lever (4).

Remove optical fiber (1).

Scheme 78

Right (A)

End of optical fiber (1) must be flush with tip of pin contact (2).

Wrong (B)

End of optical fiber (1) is not flush with tip of pin contact (2).

Scheme 79

61 13... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBERS TO LENGTH

Special tools required

1. 61 4 320

To cut off, strip insulation and cut optical fibers to length, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 322 (2) from crimping set 61 4 320.

Note. Pliers (1) open automatically as far as they will go when handles are pressed together.

Scheme 80

Cutting optical fiber

Open pliers (1).

Place optical fiber (2) in cutting device (3).

Close pliers (1) and remove optical fiber (2).

Scheme 81

Stripping insulation from optical fiber

Open pliers (1).

Open lever (2) in direction of arrow.

Scheme 82

Slide optical fiber (1) into stripping device (2) until flush at point (3).

Close pliers (4) fully.

Close clamping lever (5) in direction of arrow.

Open pliers (4) by one tooth notch.

Open clamping lever (5) against direction of arrow again and remove optical fiber (1).

Note. A stripping replacement blade set is available under number 61 4 327.

Scheme 83

Cutting optical fiber to length

Pull pin (1) in direction of arrow.

Fold up blade retaining link (2) in direction of arrow.

Scheme 84

Remove blade (1) and replace.

Installation

Make sure blade (1) is correctly seated on locating points (2).

Scheme 85

Open pliers (3).

Slide optical fiber (1) into cutting device (2) until insulation of optical fiber (1) butts against clamping device.

Close pliers (3) fully and keep closed.

Remove optical fiber (1).

Scheme 86

61 13... IN-LINE PLUGS, 30-PIN, HYBRID SYSTEM MQS/MPQ

Manufactured by AMP: The following contact types without strand sealing can be fitted in the plug housings

1. MQS (Micro Quadlock System)
2. MPQ, width 2.8 mm (Micro Power Quadlock)
3. MPQ, width 5.2 mm (Micro Power Quadlock)

Socket housing

Raise lock (1) on housing (2).

Push contact carrier (3) from rear out of housing (2).

Note. Pushing out the contact carrier releases the secondary locks of the socket contacts.

Scheme 87

Hold down retaining hook (1) of socket contact in opening of contact carrier with a small screwdriver.

Pull wire with socket contact in direction of arrow as far as secondary lock (2).

Scheme 88

Hold down retaining hook in secondary lock (1) again and pull cable with socket contact (2) completely out of contact carrier (3).

Scheme 89

Pin housing

Contacts 1... 13 and 19... 27

Raise locking slide (1) on both sides (2) of housing and detach.

Note. Detaching the locking slide releases the secondary locks of the pin contacts.

Scheme 90

Contacts 14... 18 and 28... 30

Pull slide (1) outwards completely.

Raise lock (2) on housing.

Pull contact carrier (3) out of housing.

Note. Pulling out the contact carrier releases the secondary locks of the pin contacts.

Scheme 91

The pin contacts are pulled out of a contact carrier as described under "Socket housing".

61 13... PLUG HOUSING, LCC CONTACT (LOAD CURRENT CONTACT)

Special tools required

1. 61 0 317

Socket housing

Press lock (1) with suitable tool (2) in direction of arrow out of socket housing (3).

Scheme 92

Pull lock (1) out of socket housing (2).

Scheme 93

Insert special tool 61 0 317 into socket housing (1) and pull out lead with LCC contact (2) in direction of arrow.

Scheme 94

Pin housing

Unlock locking slide (1) of pin housing (2) with suitable tool (3) in direction of arrow.

Scheme 95

Insert special tool 61 0 317 into pin housing (1) and pull out lead with LCC contact (2) in direction of arrow.

Scheme 96

61 13... RELAY CARRIER

Place special tool 61 1 153 on relay carrier (1) and carefully pull in direction of arrow until retaining lugs (2) on relay carrier are raised.

Scheme 97

Pull relay carrier (2) in direction of arrow into first catch (3).

Scheme 98

Press down arrester hook (4) of appropriate contact and pull out cable with contact.

Press out double flat spring contact with special tool 61 1 136 or 61 1 137 (ejector).

Scheme 99

61 13... REPAIRING RIBBON CABLES

Special tools required

1. 61 1 190

Place ribbon cables (1) in connector housing (2) and close cover (3).

Scheme 100

Place connector housing (1) in tool (2) 61 1 190.

Close tool (2).

Scheme 101

61 13... RETAINING BRACKET

Pull relevant fuse out of fuse block (1).

Note. Mark positions when removing fuses.

Pull locking slide (2) out of fuse block (1) as far as it will go.

Scheme 102

With special tool 61 1 136 or 61 1 137 (ejector), press back arrester hook (3) of appropriate contact and pull out cable.

Scheme 103

61 13... SOCKET HOUSING (RADIO PLUG), HYBRID SYSTEM MQS/MPQ

Manufactured by AMP : The following contact types without strand sealing can be fitted in the plug housings

1. MQS (Micro Quadlock System)
2. MPQ, width 2.8 mm (Micro Power Quadlock)
3. MPQ, width 5.2 mm (Micro Power Quadlock)

Removing MPQ contacts from radio plug

Press lock (1) in direction of arrow.

Detach secondary lock (2) from radio plug.

Scheme 104

Feed special tool 61 1 135 past side of contact.

Press special tool 61 1 135 in direction of arrow.

Pull wire (1) with socket contact out of radio plug (2).

Scheme 105

Removing MQS contacts from contact carrier

Press lock (1) in direction of arrow and pull housing (2) out of radio plug.

Scheme 106

Press lock (1) in direction of arrow. Pull contact carrier (2) out of housing (3).

Note. When the contact carrier is pulled out, the secondary locks of the socket contacts are raised.

Scheme 107

Hold down retaining hook (1) of socket contact in opening of contact carrier with a small screwdriver.

Pull wire with socket contact in direction of arrow as far as secondary lock (2).

Note. The illustration shows an 8-pin socket housing where removal of the contacts is identical.

Hold down arrester hook in secondary lock (1) again. Pull wire with socket contact (2) out of contact carrier (3).

Removing MPQ contacts from contact carrier

Remove contact carrier (1) with MQS contacts from radio plug.

Raise lock (2) on radio plug.

Pull contact carrier (3) out of radio plug.

Scheme 108

Press lock (1) in direction of arrow.

Pull secondary lock (2) in direction of arrow completely out of contact carrier (3).

Scheme 109

Press special tool 61 1 135 on inside of contact into contact carrier (2).

Pull wire with socket contact (1) out of contact carrier (2).

Scheme 110

Special tools required

1. 61 1 190
2. 61 4 320

Note. Special tools referred to in the repair instructions below are contained in the following special tool kits

SPECIAL TOOL KITS REFERENCE

Subject of repair instructions

1. Special tools for wiring harness repairs . See «61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-special-tools-for-wiring)
2. Cutting to length and stripping insulation from cables . See «61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-to-length-and) .
3. Crimping stop parts (contacts) . See «61 13 CRIMPING STOP PARTS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-crimping-stop-parts) .
4. Butt connector for repairing a plug connection . See «61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-butt-connector-for-repairing) .
5. Fan connector for retrofitting/repairs . See «61 13 INSTALLING FAN CONNECTOR FOR RETROFITTING/REPAIRS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-installing-fan-connector-for) .
6. Cutting to length and stripping insulation from optical fibers . See «61 13... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBERS TO LENGTH»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-cutting-off-stripping-insulation) .
7. Crimping optical fibers . See «61 13... CRIMPING OPTICAL FIBERS»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-crimping-optical-fibers) .
8. Insulation displacement connector for repairing ribbon cables . See «61 13... REPAIRING RIBBON CABLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-13-repairing-ribbon-cables) .

61 13 042 REPLACING DISTRIBUTION BOX (LUGGAGE COMPARTMENT)

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove flap in luggage compartment panel on right . See «51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-172-removing-and-installingreplacing) .

Release expansion rivet (1).

Remove insulating mat (2).

Scheme 111

Disconnect plug connection (1).

Release bolts (2).

Disengage distribution box in direction of arrow.

Disengage emergency actuator (3).

Scheme 112

Disconnect plug connection (1).

Scheme 113

Disconnect plug connection (1).

Remove distribution box.

Scheme 114

Replacement

Remove fuses and relays.

61 13 050 REMOVING AND INSTALLING/REPLACING INTERIOR FUSE BOX

Necessary preliminary tasks

1. Remove trim for instrument panel, bottom left . See «51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-181-removing-and-installingreplacing) .
2. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .

Release screws (1).

Remove air duct (2).

Scheme 115

Release screw (1).

Slacken wiring harness in cable holder (2).

Scheme 116

Disconnect plug connection (1).

Release screw (2).

Scheme 117

Lever holders (1) at bulkhead out of fuse box (2) in direction of arrow.

Lower fuse box (2).

Scheme 118

Disconnect plug connection (1).

Scheme 119

Turn fuse box (1) and disconnect plug connections (2).

Detach plug connections (1) on back of fuse box (2).

Replacement

Remove fuses and relays.

Remove junction box electronics . See 61 35 107 REMOVING AND INSTALLING/REPLACING JUNCTION BOX ELECTRONICS .

Scheme 120

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove flap in luggage compartment panel on right . See «51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-172-removing-and-installingreplacing) .

Release expansion rivet (1).

Remove insulating mat (2).

Disconnect plug connection (1).

Release bolts (2).

Disengage distribution box in direction of arrow.

Disengage emergency actuator (3).

Disconnect plug connection (1).

Disconnect plug connection (1).

Remove distribution box.

Replacement

Remove fuses and relays.

61 14 010 REMOVING AND INSTALLING/REPLACING DISTRIBUTION BOX (ON BATTERY)

Necessary preliminary tasks

1. Disconnect negative battery cable . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .

Disconnect plug connection (1).

Fold up covers (2).

Release nut (3) and remove cable shoe.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Fold up covers (5).

Unscrew nuts (4).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Using a screwdriver, expand locking bracket (6) at lower end and clip out.

Remove distribution box (2) towards top.

Scheme 121

12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY

Observe safety instructions for handling vehicle battery . See 61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY .

Before disconnecting battery

Turn off the ignition and other electrical loads/consumers to prevent sparking when reconnecting.

Note. If the ignition is not turned off when the battery is disconnected, fault memories may be set in some control units.

General notes on disconnecting battery

1. Do not disconnect battery leads and leads from alternator and starter motor while engine is running.
2. Cars with IBS on battery negative terminal: Do not under any circumstances pull/lever off pole shoes by force. Do not under any circumstances release socket-head cap screw of IBS.
3. Detach terminal of battery negative lead from car battery and second battery if fitted. Cover battery negative terminal(s) and secure. See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
4. When work is carried out on the electrical system, faults may be caused in the fault memories of some control units when the battery is connected.
5. When installing battery terminal.

After connecting battery

Vehicles with a two-battery system

Starter and equipment batteries

A two-battery system has a starter battery circuit and an equipment battery circuit. A secondary control unit monitors both battery circuits. Depending on the situation, the battery circuits are connected to or isolated from the secondary control unit via an isolating relay.

Two AGM batteries, whose design and properties are described in AGM batteries, are used as a storage battery.

Receiving/giving starting assistance via jump start terminal

The engine can be jump-started with an external voltage supply via the jump start terminal on the right side of the engine compartment.

Note. The starter battery is isolated from the alternators when the engine hood/bonnet is open.

Giving starting assistance via the jump start terminal is thus limited by the capacity of the starter battery when the engine hood/bonnet is open.

Charging starter and equipment batteries via jump start terminal

The starter battery is charged as a matter of priority with a charger connected to the jump start terminal. The voltage at the starter battery is the decisive factor in determining whether the equipment battery is also included in the charging operation. The secondary control unit automatically detects a charging operation at a charging voltage at the starter battery of > or = 13.5 V. The isolating relay is closed and thus the equipment battery is connected in parallel. Both batteries are now charged.

Prerequisite

1. Terminal 61 inactive
2. Terminal 15 inactive

If terminal 15 becomes "active" during the charging operation, the isolating relay is opened immediately and again only the starter battery is charged.

Note. When the engine hood is open, the isolating relay is also opened in normal operation when the engine is running. A special mode can be set by means of diagnosis for workshop/garage operation. The isolating relay is closed from terminal R in this operating mode. This mode is automatically reset once a distance of 5 km has been driven.

Trickle charging

The increased closed-circuit current consumption can be compensated for via the jump-start connection point with the aid of the "Acctiva easy" battery trickle charger (Service Information 2 03 05 205 ).

Do not start the engine with help of starting sprays.

Preparation

Conform with the following when starting engine with starting cable.

1. Ensure that jump lead wires are to appropriate cross-section size.
2. Only use fuse-protected jump leads.
3. Check whether the current supplying battery has 12 V voltage.
4. If engine is started from battery of another vehicle, ensure that there is no contact between the bodies of both vehicles.

If the battery in the vehicle supplying power is weak, start the engine of this vehicle and let it run at idling speed.

Carrying out

Always conform with the procedures to avoid injury to persons or damage to parts.

1. On automatic transmission, select "P" setting, apply handbrake.
2. Move the shift lever of vehicles with manual transmission into neutral and apply the parking brake.
3. Ensure that the jump leads cannot get caught in rotating parts, e.g. fan.
4. First connect positive terminals of both batteries with one jump lead (red).
5. Use positive connection point in engine compartment for vehicles with one battery in trunk.
6. Then attach second jump lead (black) to negative terminal of donor battery and to engine ground or body ground on vehicle to be started.

Danger of explosion!

After engine of vehicle to be started has started up, first disconnect the jump lead on the negative terminal/ground connection. Then remove jump lead from positive terminals.

32 00... TEACHING IN CENTRE POSITION FOR POWER STEERING (ACTIVE FRONT STEERING) (FROM 03/2007)

Note. Carry out the following procedure after disconnecting the battery or disconnecting electrical plug connections on the steering column switch cluster.

Turn on ignition, start engine if necessary.

Turn steering wheel twice in both directions to full lock.

Scheme 122

Battery care and maintenance

In low-maintenance batteries, check the acid level at least once a year. If necessary, top up with distilled water up to the top marking.

The increasing number of electronic control units in the car reduces the self-discharging time of the battery (even in standby mode). To maintain the battery service life and to avoid exhaustive discharging, recharge laid-up vehicles every 6 weeks at the latest. The time for self-discharging depends on vehicle type and equipment specification.

Battery test

The battery acid density can be used to measure the charge state. However this test produces uncertainty caused by a design-related range of variation. The acid density e.g. for a charged battery is 1.28 kg/l (in the tropical version the acid density is 1.23 kg/l).

Another interference factor is the acid lamination immediately after filling with distilled water.

Battery wear with partially sulphated and/or heavily contaminated plates will also lead to incorrect acid density test results.

Safety regulations

Safety regulations for handling components of airbag system. See 72 00 ... SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS .

Instructions for disconnecting and connecting battery. See 12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY .

Procedure for cable repair

In event of non-visible damage to wiring harness

Disconnect plug connection on airbag module or on adapter plug. It is absolutely vital to disconnect the contacts in succession as there is a risk of them being mixed up! Cut through one cable after the other at an appropriate position, do not under any circumstances cut through both cables at the same time. Insulate cables remaining in wiring harness with insulating tape. Now disconnect plug connection on airbag control unit. Unpin contacts. Cut through one cable after the other at an appropriate position and insulate with insulating tape, do not under any circumstances cut through both cables at the same time. Pin contacts of repair cable for airbag control unit in control unit plug, assignment of repair cables is relevant. Lay repair cable in car parallel to existing airbag lead. Now pin in contacts for airbag control unit or contacts of adapter plug, assignment of repair cables is relevant. Cut off excess length of repair cable in proximity (visible area) of airbag module or of adapter plug. Twist open cables. With the connectors and shrink-fit hoses in the Electronic Parts Catalogue (EPC), reconnect the cables with the same cable colors. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

In event of visible damage

Expose cable at damaged areas. Cut through one cable after the other at an appropriate position and insulate cables no longer required in wiring harness with insulating tape, do not under any circumstances cut through both cables at the same time. Now, depending on the scope of work, unpin contacts either on airbag control unit/airbag module or on adapter plug. Cut off unpinned cables. Insulate cables remaining in wiring harness with insulating tape. Now pin in contacts of repair cable, assignment of repair cables is relevant. Lay repair lead in car parallel to existing airbag lead up to cutting point. Cut off excess length of repair lead. Twist open cables. Connect cables with connectors and shrink-fit hoses in Electronic Parts Catalogue (EPC), assignment of repair cables is relevant. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.

Instructions for cutting off, insulating, crimping cables, installing and removing contacts

Cutting off and insulating cables. See 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES .

Repairing a plug connection using connectors. See 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION .

Installing and removing contacts. See 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS .

Battery acid is highly corrosive

Do not allow any battery acid to come into contact with the eyes, the skin or clothing. Therefore wear protective clothing, gloves and goggles.

Do not tilt the battery, acid may emerge from the vent opening.

In event of contact with acid

If acid is splashed into the eyes, rinse them immediately for several minutes with clear water. You must then consult a doctor without delay.

If acid is splashed onto the skin or clothing, neutralize it immediately with a soapy solution and rinse with lots of water.

Seek medical attention immediately if battery acid is accidentally swallowed.

Explosion hazard

Strictly no flames, sparks, naked light or smoking!

A highly explosive mixture of electrolytic gas is created when batteries are charged. The rooms where charging is carried out must therefore always be well ventilated.

Avoid the formation of sparks when handling cables, wiring and electrical devices.

Turn the ignition lock to the 0 position before disconnecting or connecting the battery.

Do not place tools or any similar object on the battery (danger of short-circuiting and explosion!).

Note. Do not connect continuous trickle charger to the cigarette lighter. The cigarette lighter is powered by the rear distribution box via a relay. This relay drops out after terminal 15 OFF. This means that a continuous trickle charger connected to the cigarette lighter is disconnected from the battery. Charge the battery via the jump-start connection points. Only then can the power supply be registered by the vehicle.

Note. Battery draining possible in spite of the intelligent battery sensor IBS being fault-free. A battery can be drained (e.g. with lights or radio switched on) even when the IBS functions perfectly in conjunction with power management. For this reason, only replace the IBS when a corresponding fault is entered in the DME or DDE.

Necessary preliminary tasks

1. Raise luggage compartment floor trim

Release screws (1).

Remove battery cover (2) upwards.

Loosen nut (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Remove battery negative lead with IBS.

Disconnect plug connection (2).

Unscrew nut (3).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

61 20... THRESHOLD VALUES FOR BATTERY INSPECTION OF ALL BATTERY (TELEPHONE EXCEPT FOR TELEPHONE BATTERY)

Safety instructions for handling vehicle battery . See 61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY .

Test step 1 - before charging the battery

THRESHOLD VALUES FOR BATTERY INSPECTION - BEFORE CHARGING BATTERY

Test step 2 - after charging the battery

THRESHOLD VALUES FOR BATTERY INSPECTION - AFTER CHARGING BATTERY

Note. If battery was checked on the positive terminal in the engine compartment, repeat check directly on battery for sake of safety.

Scheme 123

Introduction

In September 2002 so-called VRLA batteries, better known as AGM batteries , were introduced.

(VRLA stands for Valve Regulated Lead Acid, i.e. lead acid battery with pressure relief valve; AGM stands for A bsorbent G lass M at, i.e. absorbent glass fiber fleece)

AGM batteries are fitted in models with electrical loads/consumers which have a high energy demand.

With the option SA 146 (2nd battery), the AGM battery (70 Ah) is fitted as the 2nd battery.

The constantly increasing energy demand of modern vehicle electrical systems calls for ever more powerful battery solutions. Today, up to 100 servomotors, which have to be electrically powered, operate in a modern luxury-class motor vehicle. Added to these are safety, environmental and comfort and convenience elements which are increasingly becoming standard features, such as e.g. Anti-lock Brake System (ABS), Dynamic Stability Control (DSC), electric steering effort assistance (EPS), heated catalytic converter, electronic chassis and suspension control, air conditioning and navigation system.

The power consumption is considerable even when the vehicle is parked.

The somewhat higher price compared with a battery of similar size is fully balanced by the following benefits

1. Significantly longer service life
2. Increased starting reliability at low temperatures
3. Safe starting of engines with high starting current demands, e.g. high-performance diesel engines
4. 100 % freedom from maintenance
5. Low risk in event of an accident (reduced risk to the environment)

Service life of AGM battery

Scheme 124

Unlike the previously used lead calcium batteries, the sulphuric acid contained in batteries with fleece technology is not self-contained in the battery housing.

Instead, the sulphuric acid is 100 % bound up in glass fiber fleece mats (separators). Thus, no acid can escape if the battery housing is damaged. In addition, the AGM battery is sealed gas-tight. This is possible because the gases are converted back into water as a result of the separator permeability.

Brief description of components

An AGM battery can be recognized by its black housing and the lack of a so-called "Magic Eye".

Scheme 125

Design

The AGM battery differs from the conventional lead calcium battery as follows

1. Larger plates: Larger plates provide for a 25 % higher power density.
2. Separators made of glass fiber fleece: These provide for up to 3 times higher cycle reliability. This in turn improves cold starting performance, current consumption and service life.
3. Gas-tight housing with pressure relief valve (see also mode of operation): The cell plugs are welded and cannot be opened.
4. Acid bound up in the glass fiber fleece: The acid is not as previously self-contained in the housing, but 100 % bound up in the glass fiber fleece. This provides increased protection against acid leakage and thus represents a reduced risk to the environment.

Mode of operation

The AGM battery differs from conventional batteries in its non-polluting and substance-retaining behavior during charging.

When vehicle batteries are charged, the two gases oxygen and hydrogen are released by electrolysis.

1. In a conventional wet lead calcium battery, the two gases hydrogen and oxygen are dissipated into the atmosphere.
2. In an AGM battery, the two gases are converted back into water: The oxygen which is created at the positive electrode during charging passes through the permeable glass fiber fleece to the negative electrode. At the negative electrode the oxygen reacts with the arriving hydrogen ions in the electrolyte to form water (oxygen cycle).

In this way, the gas and thus also the electrolyte are not lost.

Only in the event of an excessively heavy buildup of gas, i.e. excessively high pressure buildup (20 to 200 mbar), does the pressure relief valve discharge the gas. In this process, the pressure relief valve does not allow any oxygen in the air to enter. Because a valve regulates the pressure in the battery, the AGM battery is also known as a VRLA battery (Valve Regulated Lead Acid).

Notes and instructions for service personnel

It is necessary when handling an AGM battery to observe some particular points pertaining to battery changing and installation location.

Charging

Installation location

Housing

Battery changing

Any conventional lead calcium battery can always be replaced by an AGM battery.

Using an AGM battery does not require any alterations to be made to the vehicle electrical system.

Note. The AGM battery is recommended for "problem customers". "Problem customers" encounter a high energy throughput through their batteries. This high energy throughput is caused by stationary loads/consumers (TV, independent heating, etc.) and a bad use profile for the battery ("chauffeur operation", short-distance driving, "stop-and-go"). The use of an AGM battery is recommended for these problem customers.

61 20... BATTERY CHARGING

If a normal or quick charger is used to charge the battery, the battery must be disconnected from the vehicle electrical system and removed. This prevents damage to paintwork and upholstery.

Ideally, battery charging is performed with BMW-approved charging computers.

If necessary, open existing plugs on the individual cells.

61 20... BATTERY OPEN-CIRCUIT CURRENT TEST

Note. Observe safety instructions for handling vehicle battery . See 61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY .

Scheme 126

The open-circuit current test is performed using the Diagnosis and Information System (DIS).

61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD

Necessary preliminary tasks

1. Raise luggage compartment floor trim

Release screws (1).

Remove battery cover (2) upwards.

Loosen nut (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect battery negative lead (2) with IBS and secure at side.

Scheme 127

The following steps must be carried out for a "power reset"

1. Switch off and disconnect battery charger
2. Switch off ignition Cars with ignition key: Turn ignition key to 0 position Cars with identification sensor: Remove identification sensor from slot Cars with comfort access system: Make sure terminal is in 0 position
3. Disconnect battery negative terminal
4. Reconnect battery negative terminal (to ensure bus activity)
5. Waiting time (5-10 seconds)
6. Disconnect battery negative terminal
7. Waiting time (1 minute)
8. Connect battery negative terminal and tighten. Tightening torque. See «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-tightening-torques) .
9. Connect and switch on battery charger
10. Switch ignition on

Necessary preliminary tasks

1. Raise luggage compartment floor trim

Release screws (1).

Remove battery cover (2) upwards.

Loosen nut (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Remove battery negative lead with IBS.

Disconnect plug connection (2).

Unscrew nut (3).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Necessary preliminary tasks

1. Raise luggage compartment floor trim

Release screws (1).

Remove battery cover (2) upwards.

Loosen nut (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect battery negative lead (2) with IBS and secure at side.

The following steps must be carried out for a "power reset"

1. Switch off and disconnect battery charger
2. Switch off ignition Cars with ignition key: Turn ignition key to 0 position Cars with identification sensor: Remove identification sensor from slot Cars with comfort access system: Make sure terminal is in 0 position
3. Disconnect battery negative terminal
4. Reconnect battery negative terminal (to ensure bus activity)
5. Waiting time (5-10 seconds)
6. Disconnect battery negative terminal
7. Waiting time (1 minute)
8. Connect battery negative terminal and tighten, tightening torque. Tightening torque. See «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-tightening-torques) .
9. Connect and switch on battery charger
10. Switch ignition on

61 21 010 REMOVING AND INSTALLING/REPLACING BATTERY

Necessary preliminary tasks

1. Disconnect negative battery cable . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove distribution box . See «61 13 042 REPLACING DISTRIBUTION BOX (LUGGAGE COMPARTMENT)»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair) .

Detach vent (1) in direction of arrow.

Unlock positive terminal cover (2).

Slacken nut (3) of safety battery terminal.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Detach safety battery terminal towards top, lay to one side and secure.

Release threaded pin (4).

Release screw (6) and remove holder.

Release screw (5) and remove holder.

Lift out battery.

Scheme 128

Installation

Make sure battery is correctly seated in associated fixture.

Replacement

Version with Intelligent Battery Sensor

1. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) . Code Car Access System (CAS) and delete fault memory entries relating to battery replacement in engine control unit.

32 41... REPLACING LEVEL SWITCH FOR DYNAMIC DRIVE FLUID RESERVOIR

Unscrew nuts.

Remove shims.

Installation

Replace self-locking nuts.

Scheme 129

Note. Raise and/or turn fluid reservoir in order to gain better access to plug connection.

Disconnect plug connection (1).

Turn level switch (2) through approx. 45° and remove towards bottom.

Scheme 130

Scheme 131

61 31 008 REMOVING AND INSTALLING OR REPLACING STEERING COLUMN SWITCH CLUSTER

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove steering wheel . See «32 33 000 REMOVING AND INSTALLING/REPLACING STEERING WHEEL»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-33-000-removing-and-installingreplacing) or «32 33 010 REMOVING AND INSTALLING/REPLACING SPORT STEERING WHEEL»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-33-010-removing-and-installingreplacing) .
3. Remove lower section of steering column trim . See «32 31 020 REMOVING AND INSTALLING / REPLACING LOWER SECTION OF STEERING COLUMN TRIM»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-020-removing-and-installing) .
4. If necessary, remove switch for steering column adjustment . See «61 31 035 REMOVING AND INSTALLING/REPLACING SWITCH FOR STEERING COLUMN ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-035-removing-and-installingreplacing) .

Scheme 132

Disconnect plug connections (1) from rear on steering column switch cluster.

Scheme 133

Release screws (1).

Remove steering column switch cluster in direction of arrow.

Installation

Note. Carry out steering angle sensor adjustment. See 61 31 996 CARRY OUT STEERING ANGLE SENSOR ADJUSTMENT .

On vehicles with active front steering, steering angle sensor adjustment is performed by means of initial operation / adjustment of active front steering. See 32 10 005 ADJUSTMENT FOR ACTIVE FRONT STEERING .

Scheme 134

Replacement

1. Remove volute spring cassette . See «61 31 011 REMOVING AND INSTALLING/REPLACING VOLUTE SPRING CASSETTE»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-011-removing-and-installingreplacing) .
2. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .
3. Carry out steering angle sensor adjustment . See «61 31 996 CARRY OUT STEERING ANGLE SENSOR ADJUSTMENT»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-996-carry-out-steering) or adjustment for active steering . See «32 10 005 ADJUSTMENT FOR ACTIVE FRONT STEERING»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-10-005-adjustment-for-active) .

61 31 011 REMOVING AND INSTALLING/REPLACING VOLUTE SPRING CASSETTE

Necessary preliminary tasks

1. Remove steering column switch cluster . See «61 31 008 REMOVING AND INSTALLING OR REPLACING STEERING COLUMN SWITCH CLUSTER»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-008-removing-and-installing) .

Unlock catch (1) and remove volute spring cassette (2) in direction of arrow from steering column switch cluster (3).

Scheme 135

Installation

Marking (2) must line up with marking (3).

Scheme 136

Installation

Drive pin (1) of volute spring (2) must line up correctly with opening (3) in inner ring of steering column switch cluster.

Scheme 137

61 31 014 REMOVING AND INSTALLING/REPLACING START/STOP SWITCH

Necessary preliminary tasks

1. Remove decorative strip on instrument panel, driver's side, on right . See «51 45 374 REMOVING AND INSTALLING/REPLACING DECORATIVE STRIP ON INSTRUMENT PANEL ON DRIVER'S SIDE ON RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-374-removing-and-installingreplacing) .

Release screws (1).

Pull out Start/Stop switch (2) a little.

Scheme 138

Disconnect plug connection (1).

Scheme 139

61 31 035 REMOVING AND INSTALLING/REPLACING SWITCH FOR STEERING COLUMN ADJUSTMENT

Necessary preliminary tasks

1. Remove lower section of steering column trim . See «32 31 020 REMOVING AND INSTALLING / REPLACING LOWER SECTION OF STEERING COLUMN TRIM»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-020-removing-and-installing) .

Unclip steering column adjustment switch (1) in direction of arrow.

Scheme 140

Disconnect plug connection (1).

Scheme 141

61 31 037 REMOVING AND INSTALLING/REPLACING LIGHT CONTROL UNIT

Necessary preliminary tasks

1. Remove left fresh-air grille . See «64 22 135 REMOVING AND INSTALLING/REPLACING LEFT/RIGHT FRESH-AIR GRILLE»(/bmw/x5/e70-2006-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-22-135-removing-and-installingreplacing) .

Press out light control unit (1) from inside.

Scheme 142

Disconnect plug connection (1).

Remove light control unit.

Installation

Make sure retainers (2) are correctly seated on trim of light control unit.

If necessary, replace faulty retainers.

Scheme 143

Replacement

Release screws (1).

Remove light control unit (2) from trim (3).

Scheme 144

61 31 043 REMOVING AND INSTALLING OR REPLACING ROOF SWITCH CENTRE

Special tools required

1. 00 9 317
2. 00 9 340

Carefully lever out trim (1) with special tool 00 9 340.

Scheme 145

Unlock retaining clip (1).

Lever out roof switch center with special tool 00 9 317.

Disconnect plug connections underneath.

Installation

Before installing, fit trim on roof switch center.

Make sure trim is correctly seated.

Position roof switch cluster at an angle of 90° with respect to the headliner and attach.

Scheme 146

Replacement

1. If necessary, modify bulbs . See «63 99 431 REPLACING BULB FOR FRONT CEILING LIGHT»(/bmw/x5/e70-2006-2010/remont/exterior-lights/#lights-repair__63-99-431-replacing-bulb-for) .
2. If necessary, remove hands-free microphone.
3. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .
4. If necessary, initialize slide/tilt sunroof . See «54 0 ... NOTES ON PANORAMA GLASS ROOF (INITIALIZATION/NORMALIZATION/LEARNING OF CHARACTERISTIC CURVE)»(/bmw/x5/e70-2006-2010/remont/sun-rooft-topconvertible-top/#slidetilt-roof-repair) .

61 31 052 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE SWITCH CLUSTER

Necessary preliminary tasks

1. Remove middle trim for instrument panel . See «51 45 310 REMOVING AND INSTALLING (REPLACING) CENTER TRIM FOR INSTRUMENT PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-310-removing-and-installing) .

Disconnect plug connection (1) and expose ribbon cable up to center console switch cluster (2).

Unclip center console switch cluster (2) at retaining points (3).

Remove center console switch cluster (2) in direction of arrow from instrument panel trim.

Scheme 147

61 31 079 REMOVING AND INSTALLING/REPLACING SWITCH FOR HAZARD WARNING FLASHERS/CENTRAL LOCKING

Special tools required

1. 00 9 340

Lever out switch for hazard warning system/central locking (1) with special tool 00 9 340 and pull back.

Disconnect associated plug connection and remove switch for hazard warning system/central locking (1).

Scheme 148

61 31 091 REMOVING AND INSTALLING/REPLACING SWITCH FOR LEFT OR RIGHT SEAT HEATING (REAR)

Special tools required

1. 00 9 340

Unclip trim with special tool 00 9 340.

Scheme 149

Disconnect plug connection (1).

Press locks (2) together and press switches for seat heating out of trim (3).

Scheme 150

61 31 116 REPLACING ROCKER SWITCH FOR SIDE WINDOW OPERATION (REAR)

Special tools required

1. 00 9 317

Lever rocker switch (1) with special tool 00 9 317 upwards out of armrest.

Disconnect plug connection.

Scheme 151

Installation

Retaining hooks (1) of rocker switch (2) must not be damaged.

Make sure rocker switch (2) is correctly seated.

Scheme 152

61 31 117 REMOVING AND INSTALLING/REPLACING POWER WINDOW SWITCH (DRIVER'S SIDE)

Special tools required

1. 00 9 317

Lever rocker switch (1) with special tool 00 9 317 upwards out of armrest.

Scheme 153

Disconnect plug connection (1).

Installation

Make sure retainers (2) are correctly seated on power window switch.

Scheme 154

61 31 118 REMOVING AND INSTALLING/REPLACING POWER WINDOW SWITCH (PASSENGER SIDE)

Special tools required

1. 00 9 317

Lever rocker switch (1) with special tool 00 9 317 upwards out of armrest.

Disconnect plug connection.

Scheme 155

Installation

Retaining hooks (1) of rocker switch (2) must not be damaged.

Make sure rocker switch (2) is correctly seated.

61 31 133 REMOVING AND INSTALLING/REPLACING AUX CONNECTION SOCKET

Special tools required

1. 00 9 323

Necessary preliminary tasks

1. Open storage box

Unclip trim (1) with special tool 00 9 323 at retaining points (2).

Disconnect associated plug connections.

Scheme 156

Press locks (1) together and press AUX connection socket (2) out of trim (3).

Scheme 157

61 31 135 REMOVING AND INSTALLING/REPLACING HEADPHONES CONNECTION SOCKET

Special tools required

1. 00 9 340

Unclip trim (1) with special tool 00 9 340.

Scheme 158

Disconnect plug connection (1).

Press locks (2) together and press switches for seat heating out of trim (3).

Scheme 159

61 31 172 REMOVING AND INSTALLING/REPLACING SWITCH FOR ELECTROMECHANICAL PARKING BRAKE

Necessary preliminary tasks

1. Remove knob for controller . See «61 31 192 REPLACING KNOB FOR CONTROLLER»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-192-replacing-knob-for) .
2. Remove center console trim . See «51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-160-removing-and-installingreplacing) .

Release screws (1).

Unclip parking brake with trim (2) towards top.

Scheme 160

Disconnect plug connection (1).

Release screws (2).

Remove parking brake button (3) from trim.

Scheme 161

61 31 192 REPLACING KNOB FOR CONTROLLER

Special tools required

1. 00 9 317
2. 00 9 323

Engage special tools 00 9 323 and 00 9 317 as pictured.

Lever out knob for controller (1) and remove towards top.

Scheme 162

Installation

Fit knob for controller (1) so that guides (2) are correctly seated in mountings (3).

Scheme 163

61 31 193 REMOVING AND INSTALLING/REPLACING BUTTON UNIT (MENU/VOICE INPUT)

Necessary preliminary tasks

1. Remove center console trim . See «51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-160-removing-and-installingreplacing) .

Unclip button unit (1) at retaining points (2) and pull out.

Scheme 164

Disconnect plug connection (1).

Scheme 165

61 31 195 REMOVING AND INSTALLING (REPLACING) FRONT CONTROLLER

Necessary preliminary tasks

1. Remove center console trim . See «51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-160-removing-and-installingreplacing) .

Release screws (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Raise controller (2) and disconnect plug connection underneath.

Scheme 166

Replacement

1. Remove button unit . See «61 31 193 REMOVING AND INSTALLING/REPLACING BUTTON UNIT (MENU/VOICE INPUT)»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-193-removing-and-installingreplacing) .
2. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .

61 31 203 REPLACING SWITCH COMBINATION FOR SEAT ADJUSTMENT

Necessary preliminary tasks

1. Remove cover from front seat . See «52 17 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON LEFT OR RIGHT FRONT SEAT»(/bmw/x5/e70-2006-2010/remont/seats/#seats-repair__52-17-040-removing-and-installingreplacing) .

Release screws (1).

Raise switch combination for seat adjustment (2).

Scheme 167

Disconnect plug connection (1).

Scheme 168

61 31 214 REMOVING AND INSTALLING/REPLACING SWITCH FOR ELECTRONIC DAMPER CONTROL (SPORT BUTTON)

Necessary preliminary tasks

1. Remove gear selector switch trim . See «61 31 336 REMOVING AND INSTALLING/REPLACING TRIM FOR GEAR SELECTOR SWITCH»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-31-336-removing-and-installingreplacing) .

Release screws (1).

Raise trim (2) slightly.

Scheme 169

Disconnect plug connection (1).

Unlock switch (2) and remove towards bottom.

Scheme 170

61 31 221 REMOVING AND INSTALLING/REPLACING BOTH MULTIFUNCTION STEERING WHEEL SWITCHES

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove airbag unit . See «32 34 020 REMOVING AND INSTALLING/REPLACING AIRBAG UNIT»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-34-020-removing-and-installingreplacing) .

Note. Illustration shows steering wheel removed.

Release screws (1).

Scheme 171

Note. Both multifunction steering wheel switches (1) are connected to each other by the wiring harness.

Disconnect plug connections (2).

Feed wiring harness (3) out of steering wheel.

Pull multifunction steering wheel switches (1) in direction of arrow out of steering wheel.

Scheme 172

Installation

Make sure electrical leads are correctly routed.

61 31 229 REMOVING AND INSTALLING/REPLACING BOTH SWITCHES ON SPORT STEERING WHEEL

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove airbag unit . See «32 34 020 REMOVING AND INSTALLING/REPLACING AIRBAG UNIT»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-34-020-removing-and-installingreplacing) .

Note. Illustration shows steering wheel removed.

Release screws (1).

Scheme 173

Note. Both sport steering wheel switches (1) are connected to each other by the wiring harness.

Disconnect plug connections (2).

Pull switches (1) with design cover (3) in direction of arrow out of steering wheel.

Installation

Make sure electrical leads are correctly routed.

Scheme 174

Release screws (1).

Feed wiring harness (3) out of design cover (4).

Remove switches (2) from design cover (4).

Installation

Make sure electrical leads are correctly routed.

Scheme 175

61 31 241 REMOVING AND INSTALLING/REPLACING ENGINE HOOD CONTACT SWITCH

Necessary preliminary tasks

1. Remove right bonnet/hood lock . See «51 23 100 REMOVING AND INSTALLING/REPLACING RIGHT ENGINE HOOD/BONNET LOCK»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-23-100-removing-and-installingreplacing) .

Release screw (1).

Remove bonnet/hood contact switch (2) from bonnet/hood lock (3).

Scheme 176

61 31 255 REPLACING SWITCH FOR DOOR MIRROR

Operation is described in

Replacing power window switch. See 61 31 117 REMOVING AND INSTALLING/REPLACING POWER WINDOW SWITCH (DRIVER'S SIDE) .

61 31 310 REPLACING BRAKE-LIGHT SWITCH

Necessary preliminary tasks

1. Remove trim panel for pedal assembly . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .

Note. Brake light switch (2) is situated above the brake pedal.

Disconnect plug connection (1).

Pull brake light switch (2) in direction of arrow out of brake light switch holder (3).

Press catches (4) together and unclip brake light switch holder (3) from brake pedal.

Scheme 177

Installation

Depress brake pedal.

Slide brake light switch (2) as far as it will go into brake light switch holder (3).

Grip brake light switch holder (3), slowly return brake pedal to starting position and pull back to stop.

61 31 333 REMOVING AND INSTALLING/REPLACING SWITCH FOR UNLOCKING GLOVEBOX

Necessary preliminary tasks

1. Remove decorative strip from middle fresh-air grille . See «51 45 377 REMOVING AND INSTALLING/REPLACING DECORATIVE STRIP ON MIDDLE FRESH-AIR GRILLE»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-377-removing-and-installingreplacing) .

Unlock catches (1).

Press switch (2) out of decorative strip.

Scheme 178

61 31 334 REMOVING AND INSTALLING OR REPLACING GRIP TRIM FOR GEAR SELECTOR SWITCH

Special tools required

1. 64 1 030

Turn end ring (1) in direction of ring and lower.

Scheme 179

Insert special tool 64 1 030 from below into trim (1) and carefully pull off trim (1).

Remove symbol plate (2).

Installation

To facilitate fitting, secure pushbutton (3) with adhesive tape on trim (1).

Scheme 180

61 31 336 REMOVING AND INSTALLING/REPLACING TRIM FOR GEAR SELECTOR SWITCH

Necessary preliminary tasks

1. Remove center console trim . See «51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-160-removing-and-installingreplacing) .

Release screws (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Unclip parking brake with trim (2) towards top.

Scheme 181

Disconnect plug connection (1).

Replacement

Release screws (2).

Remove parking brake button (3) from trim.

61 31 342 REMOVING AND INSTALLING/REPLACING GEAR SELECTOR SWITCH

Necessary preliminary tasks

1. Remove center console trim . See «51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-160-removing-and-installingreplacing) .

Release screws (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Raise gear selector switch carrier (2) a little.

Disconnect associated plug connections.

Scheme 182

Remove gear selector switch trim. . See 61 31 336 REMOVING AND INSTALLING/REPLACING TRIM FOR GEAR SELECTOR SWITCH .

Release screws (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Feed gear selector switch (2) out of carrier.

Scheme 183

Replacement

Carry out programming/coding. . See VEHICLE PROGRAMMING AND CODING .

61 31 382 REPLACING COOLANT LEVEL SWITCH

Turn coolant level switch (1) and pull downwards out of coolant expansion tank (2).

Disconnect plug connection from coolant level switch.

Scheme 184

Note. For purposes of clarity, illustration shows coolant expansion tank (2) removed.

Turn coolant level switch (1) in direction of arrow, pull out of expansion tank (2) and remove.

Scheme 185

61 31 492 REPLACING LEVEL SWITCH FOR WINDSCREEN WASHER SYSTEM

Necessary preliminary tasks

1. Remove trim from wheel arch at front right . See «51 71 470 REMOVING AND INSTALLING/REPLACING TRIM ON FRONT LEFT OR RIGHT WHEEL ARCH»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-470-removing-and-installingreplacing) .
2. Partially detach rear section of wheel arch cover at front and pull forwards. See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .

Disconnect plug connection (1).

Turn level switch for windscreen washer system (2) in direction of arrow and remove towards bottom from fluid reservoir for windscreen washer system (3).

Scheme 186

61 31 996 CARRY OUT STEERING ANGLE SENSOR ADJUSTMENT

Note. Steering angle sensor adjustment must be carried out: after adjustment work on the front axle/steering after all mechanical work on the steering system after replacement / coding / programming of the following components: Fixture for switches of steering column / switch cluster / steering angle sensor Dynamic Stability Control (DSC) control unit Control unit active anti-roll stabilization (ARS)

Connect vehicle to BMW diagnosis system or

Software Service Station.

Select and carry out steering angle sensor adjustment under Service functions.

61 34... REMOVING AND INSTALLING/REPLACING POWER SOCKET IN STORAGE COMPARTMENT

Necessary preliminary tasks

1. Remove rear center console trim . See «51 16 163 REMOVING AND INSTALLING/REPLACING REAR CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-163-removing-and-installingreplacing) .

Unlock plug connection (1) and remove.

Press switch trim (2) out of rear center console trim (3).

Scheme 187

Press power sockets (1) out of switch trim (2).

Scheme 188

61 33 050 REMOVING AND INSTALLING/REPLACING LEFT FANFARE HORN

Necessary preliminary tasks

1. Remove front bumper trim . See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .

Release nut (1) and feed out holder (2) with fanfare horn.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect associated plug connection.

Remove fanfare horn (2).

Scheme 189

61 33 050 REMOVING AND INSTALLING/REPLACING RIGHT FANFARE HORN

Necessary preliminary tasks

1. Remove grille in bumper trim on right . See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .

Tape off edges (1) of bumper trim.

Scheme 190

Release nut (1) and feed out holder (2) with fanfare horn.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect associated plug connection.

Remove fanfare horn (2).

Scheme 191

Necessary preliminary tasks

1. Remove rear center console trim . See «51 16 163 REMOVING AND INSTALLING/REPLACING REAR CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-163-removing-and-installingreplacing) .

Unlock plug connection (1) and remove.

Press switch trim (2) out of rear center console trim (3).

Press power sockets (1) out of switch trim (2).

32 43 010 REMOVING AND INSTALLING/REPLACING CONTROL UNIT FOR ACTIVE FRONT STEERING

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove front left wheel arch cover (rear section) . See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .

Release nut (1) and disconnect ground cable.

Disconnect plug connections (2).

Unclip cable holder (3).

Installation

Replace damaged cable holder.

Scheme 192

Release nuts (1, 2).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Remove active front steering control unit (3).

Scheme 193

After installation

1. Replacement only: Carry out coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .
2. Only when replacing / programming / coding: Carry out adjustment for active front steering . See «32 10 005 ADJUSTMENT FOR ACTIVE FRONT STEERING»(/bmw/x5/e70-2006-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-10-005-adjustment-for-active) .

Scheme 194

61 35... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)

Special tools required

1. 12 7 060

Note. Electrical components which are particularly sensitive to electrostatic discharge (electronic control units, sensors, etc.) are marked with the ESD warning symbol.

E -Electro

S -Static

D -Discharge

Statically charged persons can discharge by touching electrical components.

Note. Humans can only detect a discharge starting from a level of approx. 3000 V.

The danger threshold for electrical components already starts from a level of approx. 100 V.

Scheme 195

Example

Mechatronic control unit.

Scheme 196

Scheme 197

61 35 001 REMOVING AND INSTALLING (REPLACING) TRAILER MODULE

Necessary preliminary tasks

1. Remove flap in luggage compartment panel on right . See «51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-172-removing-and-installingreplacing) .

Lift back insulating mat.

Disconnect plug connection (1).

Unlock catch (2) and remove trailer module (3) from device carrier (4).

Scheme 198

Replacement

Carry out programming/coding . See VEHICLE PROGRAMMING AND CODING .

61 35 015 REMOVING AND INSTALLING (REPLACING) CONTROL UNIT FOR CAR ACCESS SYSTEM

Note. The comfort access system is a radio-based system and can be interfered with by radio waves from other systems (e.g. mobile phone).

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove trim panel for pedal assembly

Disconnect plug connection (1).

Release catches (2) and pull out control unit for Car Access System (3) in downward direction.

Scheme 199

Replacement

Carry out programming/coding . See VEHICLE PROGRAMMING AND CODING .

Version with independent heating

Initialize Telestart hand transmitter . See 64 12 ... INITIALIZING TELESTART HAND TRANSMITTER .

61 35 080 REMOVING AND INSTALLING/REPLACING CONTROL UNIT/MODULE FOR LEFT OR RIGHT SEAT ADJUSTMENT

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .

Note. To facilitate installation/removal of control unit, move seat upwards fully.

Disconnect all plug connections on control unit for seat adjustment (1).

Scheme 200

Unlock retaining tabs (1) towards front and remove control unit for seat adjustment (2) in direction of arrow.

Installation

Make sure control unit for seat adjustment (2) is correctly seated in mounting.

Scheme 201

Replacement

Carry out programming/coding . See VEHICLE PROGRAMMING AND CODING .

61 35 107 REMOVING AND INSTALLING/REPLACING JUNCTION BOX ELECTRONICS

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove trim for instrument panel, bottom left . See «51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-181-removing-and-installingreplacing) .

Release screws (1).

Remove air duct (2).

Release screw (1).

Slacken wiring harness in cable holder (2).

Release screw (1).

Scheme 202

Lever holders (1) at bulkhead out of fuse box (2) in direction of arrow.

Lower fuse box (2).

Disconnect plug connection (1).

Release screws (1).

Pull junction box electronics (2) out of fuse box.

Installation

Make sure junction box electronics (2) is correctly seated in fuse box plug connection.

Scheme 203

Replacement

1. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .

61 35 115 REMOVING AND INSTALLING/REPLACING FOOTWELL MODULE

Necessary preliminary tasks

1. Disconnect battery negative lead . See «61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-20-900-disconnecting-and-connecting) .
2. Remove footwell side trim panel on A-pillar, left . See «51 43 070 REMOVING AND INSTALLING/REPLACING SIDE TRIM PANEL, FOOTWELL, ON A-PILLAR, LEFT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-070-removing-and-installingreplacing) .

Fold back carpet (1) in area of A-pillar a little.

Disconnect plug connection (2).

Release plastic nuts (3).

Pull footwell module (4) forwards a little.

Disconnect plug connection (5).

Scheme 204

Replacement

Carry out programming/coding . See VEHICLE PROGRAMMING AND CODING .

61 35 679 INITIALIZING RAIN/LIGHT SENSOR

Note. Initialization is necessary: After replacing windshield When installing a used rain/light sensor

Note. Connect BMW diagnosis system Initialize rain/light sensor.

61 35 683 REPLACING OPTICAL ELEMENT FOR SOLAR RAIN/LIGHT SENSOR

Necessary preliminary tasks

Remove solar rain/light sensor . See 61 35 685 REPLACING RAIN/LIGHT SOLAR SENSOR .

Optical element can only be replaced in the following equipment specifications

1. E70 without head-up display

Carefully expand catches (1) of solar rain/light sensor (2).

Remove optical element (3).

Installation

Remove protective cover from replacement optical element.

Catches (1) of solar sensor (2) must not be damaged.

Observe laser marking (4) of fitting aid.

Scheme 205

Carry out initialization . See 61 35 679 INITIALIZING RAIN/LIGHT SENSOR .

Carry out programming/coding if installing a different windscreen type. See VEHICLE PROGRAMMING AND CODING .

61 35 685 REPLACING RAIN/LIGHT SOLAR SENSOR

Expand two-part mirror base cover (1) by pressing from below and detach.

Feed out two-part mirror base cover (1) and remove.

If necessary, remove interior rearview mirror . See 51 16 060 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (WITH RAIN SENSOR) .

Note. Catches of two-part mirror base cover (1) must not be damaged.

Scheme 206

Disconnect plug connection (1).

Unlock metal spring (3) in direction of arrow.

Pull off solar rain/light sensor (2) from windscreen.

Installation

Connect plug (1) only after fitting sensor.

Pull off protective cover from new solar rain/light sensor.

Align solar rain-light sensor (2) and press firmly on windscreen.

Pay attention to mechanical coding (6).

Press metal spring (3) centrally to ensure that retaining element (5) engages correctly in both hooks (4).

Scheme 207

Clean windscreen in area (A) of fastening element and remove residues of silicone.

Scheme 208

Replacement

1. Carry out programming/coding . See «VEHICLE PROGRAMMING AND CODING»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__vehicle-programming-and-coding) .
2. Carry out initialization. . See «61 35 679 INITIALIZING RAIN/LIGHT SENSOR»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-35-679-initializing-rainlight-sensor) .

61 35 950 REMOVING AND INSTALLING/REPLACING CONTROL UNIT FOR COMFORT ACCESS SYSTEM (PASSIVE GO)

Necessary preliminary tasks

1. Remove flap in luggage compartment panel on right . See «51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-172-removing-and-installingreplacing) .

Lift back insulating mat (1).

Disconnect plug connection (3).

Unlock catch (2) and remove control unit for Comfort Access

System (4) from device carrier (5).

Scheme 209

Replacement

Carry out programming/coding . See VEHICLE PROGRAMMING AND CODING .

61 35 953 REMOVING AND INSTALLING/REPLACING INTERIOR ANTENNA FOR COMFORT ACCESS SYSTEM

Necessary preliminary tasks

1. Remove Car Communication Computer . See «65 83 010 REMOVING AND INSTALLING/REPLACING CAR COMMUNICATION COMPUTER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#audio-navigation-anti-theft-and-restraints-repair__65-83-010-removing-and-installingreplacing) .

Release screw (1).

Release screw (2) through opening (3).

Pull out interior antenna for comfort access system (4).

Disconnect plug connection.

Scheme 210

61 35 954 REMOVING AND INSTALLING/REPLACING INTERIOR ANTENNA FOR COMFORT ACCESS SYSTEM (REAR CENTRE CONSOLE)

Necessary preliminary tasks

1. Remove rear center console trim . See «51 16 163 REMOVING AND INSTALLING/REPLACING REAR CENTRE CONSOLE TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-163-removing-and-installingreplacing) .

Unlock retaining hook (1) and remove interior antenna for comfort access system (2).

Scheme 211

61 35 958 REMOVING AND INSTALLING/REPLACING INTERIOR ANTENNA FOR COMFORT ACCESS SYSTEM ON LEFT OR RIGHT

Necessary preliminary tasks

1. Fold back luggage compartment floor trim panel

Release expansion rivet (1).

Fold back luggage compartment tray (2) slightly.

Scheme 212

Disconnect plug connection (1).

Release screws (2).

Remove interior antenna (3).

Scheme 213

61 35 975 REMOVING AND INSTALLING/REPLACING BUMPER ANTENNA FOR COMFORT ACCESS SYSTEM

Reach behind bumper trim and disconnect plug connection (2).

Press catches (1) and pull out bumper antenna for Comfort Access System (3) in direction of arrow.

Scheme 214

VEHICLE PROGRAMMING AND CODING

Select menu item (1).

Select corresponding procedure from selection list.

Example

Scheme 215

1. Preparation and subsequent evaluation of vehicle programming
2. Start a Program session
3. Sequence of BMW/MINI vehicle programming and coding
4. BMW/MINI Car & Key Memory
5. BMW/MINI initialization
6. BMW/MINI service functions in Progman

Note. In order to avoid incorrect programming procedures and error messages, it is essential when working with the Progman programming system always to use the latest Progman version.

Place special tool 61 1 153 on relay carrier (1) and carefully pull in direction of arrow until retaining lugs (2) on relay carrier are raised.

Pull relay carrier (2) in direction of arrow into first catch (3).

Press down arrester hook (4) of appropriate contact and pull out cable with contact.

Press out double flat spring contact with special tool 61 1 136 or 61 1 137 (ejector).

Scheme 216

61 36 540 REMOVING AND INSTALLING/REPLACING AIR SUPPLY UNIT RELAY

After completing work

1. Clear fault memory

Necessary preliminary tasks

1. Remove ignition key.
2. Remove trim panel for instrument panel at bottom right. See «51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-181-removing-and-installingreplacing) .

Release screw (1) and fold down fuse box.

Pull relay (1) from fuse box.

Scheme 217

Scheme 218

61 61 01. ADJUSTING LEFT OR RIGHT WINDSCREEN WIPER

Special tools required

1. 61 6 100

Correctly adjusting the contact angle of the wiper arms on the windscreen increases wiping quality. For adjustment, refer to the vehicle-specific repair instruction.

Scheme 219

A/B = Distance between windscreen wiper blade (2) and trim panel on cowl panel (1)

Note. Measurement is taken at the height of the locators (3) for the windscreen wiper arms

C= Contact angle between wiper blade center plane and windscreen

When adjusting with special tool 61 6 100, set the scale value in accordance with the following table.

For RHD cars, change the preceding sign of the scale values.

1. LHD cars, scale range 0 to-10
2. RHD cars, scale range 0 to +10

WINDSCREEN WIPER ADJUSTING VALUE

61 61 010 CHECKING/ADJUSTING CONTACT ANGLE OF WINDSCREEN WIPER ARMS ON WINDSCREEN

Special tools required

1. 00 9 220
2. 61 6 100

Note. Wiping quality is increased if the approach angle of the windscreen wiper arms is precisely adjusted.

Adjusting dimensions of wiper arms. See WINDSCREEN WIPER ADJUSTING VALUE

Reference points (A, B) are the mountings of the wiper blades on the wiper arms to the sealing lip (1) of the cowl panel.

Contact angle (C) is the angle between wiper blade center plane (2) and windscreen.

Scheme 220

Remove wiper blade (1) from wiper arm (2).

Pin (3) is locator for special tool 61 6 100.

Scheme 221

Slide special tool 61 6 100 onto pin (1).

Place special tool 61 6 100 on windscreen (2) and read off value in degrees on scale.

Note. LHD vehicles are covered by the scale range of 0 to-10 and RHD vehicles by the scale range of 0 to +10.

Scheme 222

If the specified number in degrees is not correct, the wiper arm (1) must be bent with special tool 00 9 220 at the point shown.

Scheme 223

61 61 041 REPLACING BOTH WINDSCREEN WIPER BLADES

Fold wiper arm (1) away from windscreen.

Turn windscreen wiper blade (2) at an angle of 90° and remove from windscreen wiper arm (1).

Scheme 224

61 61 081 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT WINDSCREEN WIPER ARM

Special tools required

1. 61 6 060

Remove wiper arm cover caps (1) towards top.

Release nut underneath.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Scheme 225

Detach wiper arm (1) with special tool 61 6 060.

Scheme 226

Installation

Adjust position of wiper arm in question in rest position (measured between wiper lip and top edge of cowl panel cover).

Then tighten down wiper arm and check adjustment dimensions of relevant wiper arm again.

Reference points (A, B) are the mountings of the wiper blades on the wiper arms to the sealing lip (1) of the cowl panel.

Contact angle (C) is the angle between wiper blade center plane (2) and windscreen.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

61 61 270 REMOVING AND INSTALLING BRACKET FOR WINDSCREEN WIPER SYSTEM COMPLETELY WITH MOTOR

Necessary preliminary tasks

1. Remove cover for cowl panel . See «51 13 116 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-13-116-removing-and-installingreplacing) .

Release screws (1).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Disconnect plug connection (2).

Feed out bracket for windscreen wiper system (3) in upward direction.

Installation

Rubber guide (4) must be correctly seated in guide (5).

Scheme 227

Installation

Before installing wiper arms, allow wiper motor to return to its rest position.

To ensure the wiper system works properly, check and correct the contact angle of the wiper arms. See 61 61 010 CHECKING/ADJUSTING CONTACT ANGLE OF WINDSCREEN WIPER ARMS ON WINDSCREEN .

Scheme 228

61 62 020 REMOVING AND INSTALLING/REPLACING REAR WINDOW WIPER BLADE

Fold wiper arm (1) away from rear window.

Pull off window wiper blade (2) in direction of arrow.

Scheme 229

Installation

Make sure guide (1) is correctly seated in wiper blade (2).

Scheme 230

61 62 030 REMOVING AND INSTALLING/REPLACING WIPER ARM ON REAR WINDOW

Special tools required

1. 61 6 060

Fold up cover cap (1) in direction of arrow.

Release nut underneath.

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Scheme 231

Press off wiper arm (1) with special tool 61 6 060 and remove.

Scheme 232

Installation

Before fitting wiper arm, allow wiping system to run two wipe cycles into park position.

Adjust measurement (A) between wiper arm and rear window edge.

Scheme 233

61 62 060 REMOVING AND INSTALLING/REPLACING REAR WINDOW WIPER MOTOR

Necessary preliminary tasks

1. Remove wiper arm for rear window wiper . See «61 62 030 REMOVING AND INSTALLING/REPLACING WIPER ARM ON REAR WINDOW»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair__61-62-030-removing-and-installingreplacing) .
2. Remove trim for rear lid at bottom . See «51 49 000 REMOVING AND INSTALLING/REPLACING PANEL FOR REAR LID»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-49-000-removing-and-installingreplacing) .

Disconnect plug connector (1).

Release bolts (2).

Tightening torque. See GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES .

Pull rear window wiper motor out of rear window grommet.

Installation

Check wiper shaft grommet for signs of damage.

Scheme 234

61 62 115 REPLACING SPRAY NOZZLE FOR REAR WINDOW WASHER UNIT

Necessary preliminary tasks

1. Remove auxiliary brake light . See «63 25 000 REMOVING AND INSTALLING/REPLACING AUXILIARY BRAKE LIGHT»(/bmw/x5/e70-2006-2010/remont/exterior-lights/#lights-repair__63-25-000-removing-and-installingreplacing) .

Disconnect hose connection (1).

Expand catch (2) and pull spray nozzle (3) out of auxiliary brake light.

Scheme 235

61 62 150 REMOVING AND INSTALLING/REPLACING WINDOW WASHER PUMP FOR REAR WINDOW WASHER SYSTEM

Necessary preliminary tasks

1. Remove trim panel for cover on frame side member on right. See «51 71 447 REMOVING AND INSTALLING OR REPLACING PANEL FOR COVER ON LEFT OR RIGHT SIDE MEMBER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-447-removing-and-installing) .
2. Remove wheel arch trim at front right. See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .
3. Drain fluid reservoir for windscreen washer system

Release screws

Press off side panel slightly.

Scheme 236

Note. Side panel shown removed for purposes of clarity.

Disconnect plug connection (1).

Pull windscreen washer pump (2) in direction of arrow out of fluid reservoir for windscreen washer system.

Disconnect hose plug connection (3) from windscreen washer pump (2).

Installation

Coat sealing ring (4) of windscreen washer pump (2) with antiseize agent.

Ensure hose is laid without kinks.

Scheme 237

Scheme 238

61 67 010 REMOVING AND INSTALLING/REPLACING WASHER PUMP OF HEADLIGHT WASHER SYSTEM

Necessary preliminary tasks

1. Remove trim panel for cover on frame side member on right. See «51 71 447 REMOVING AND INSTALLING OR REPLACING PANEL FOR COVER ON LEFT OR RIGHT SIDE MEMBER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-447-removing-and-installing) .
2. Remove wheel arch trim at front right. See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .
3. Drain fluid reservoir for windscreen washer system

Release bolts.

Press off side panel slightly.

Note. Side panel shown removed for purposes of clarity.

Disconnect plug connection (1).

Pull washer pump (2) in direction of arrow out of fluid reservoir for windscreen washer system.

Disconnect hose plug connection (3) from washer pump (2).

Installation

Coat sealing ring (4) of washer pump (2) with antiseize agent.

Ensure hose is laid without kinks.

Scheme 239

61 67 100 REMOVING AND INSTALLING/REPLACING HIGH - PRESSURE NOZZLE OF HEADLIGHT WASHER SYSTEM ON LEFT (OR RIGHT)

Special tools required

1. 00 9 340

Necessary preliminary tasks

1. Remove front bumper trim . See «51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-156-removing-and-installing) .

Lever out cover (1) with special tool 00 9 340.

Scheme 240

Slowly pull out spray nozzle (1) by cover (2).

Unclip cover (2) and remove.

Allow nozzle (1) to slide back slowly.

Scheme 241

Pull back clasp (1) and disconnect plug connection (2).

Unlock catch (3) in direction of arrow.

Pull out high-pressure nozzle (4) towards rear.

Installation

Make sure retaining lugs (3) engage correctly.

Scheme 242

Scheme 243

Scheme 244

Mark tolerance range (2) with crepe tape (A=500 mm / B=200 mm).

Actuate washer system.

Contact points (1) must be in tolerance range (2).

If necessary, adjust left or right spray nozzle (1) by way of screw (2).

Scheme 245

61 71 015 REMOVING AND INSTALLING/REPLACING A SPRAY NOZZLE IN WINDSCREEN WASHER SYSTEM

Unlock retaining clip for water hose (1) and detach water hose in direction of arrow.

Disconnect plug connection (2) and detach in direction of arrow.

Press spray nozzle (3) in direction of arrow (A) and remove at top in direction of arrow (B).

Scheme 246

Installation

Scheme 247

1. Retaining lugs (1) must not be damaged.
2. Check adjustment of spray nozzles and correct if necessary. See «61 71 004 ADJUSTING WINDSCREEN WASHER SPRAY NOZZLES»(/bmw/x5/e70-2006-2010/remont/horns/#general-electrical-system-repair) .

61 71 061 REPLACING (REMOVING AND INSTALLING) FLUID RESERVOIR FOR WINDSCREEN WASHER UNIT

Necessary preliminary tasks

1. Remove trim panel for cover on frame side member on right. See «51 71 447 REMOVING AND INSTALLING OR REPLACING PANEL FOR COVER ON LEFT OR RIGHT SIDE MEMBER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-447-removing-and-installing) .
2. Remove wheel arch trim at front right. See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .
3. Remove auxiliary direction indicator light at front right. See «63 13 200 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT AUXILIARY DIRECTION INDICATOR»(/bmw/x5/e70-2006-2010/remont/exterior-lights/#lights-repair__63-13-200-removing-and-installingreplacing) .
4. Drain fluid reservoir for windscreen washer system

Release screw (1).

Twist filler duct (2) in direction of arrow out of fluid reservoir (3).

Scheme 248

Release screws.

Press off side panel slightly.

Note. Side panel shown removed for purposes of clarity.

Remove washer pump of headlight washer system (1) . See 61 67 100 REMOVING AND INSTALLING/REPLACING HIGH - PRESSURE NOZZLE OF HEADLIGHT WASHER SYSTEM ON LEFT (OR RIGHT) .

Remove washer pump for rear window washer system (2)). See 61 62 150 REMOVING AND INSTALLING/REPLACING WINDOW WASHER PUMP FOR REAR WINDOW WASHER SYSTEM .

Disconnect plug connection (3) and unclip wiring harness.

Remove windscreen washer pump (4) . See 61 71 100 REMOVING AND INSTALLING/REPLACING WINDSCREEN WASHER PUMP .

Remove level switch (5) for windscreen washer system . See 61 31 492 REPLACING LEVEL SWITCH FOR WINDSCREEN WASHER SYSTEM .

Unclip high-pressure line (6) from fluid reservoir.

Scheme 249

Release screw (1).

Feed out fluid reservoir (2) towards front.

Scheme 250

Installation

Fluid reservoir (1) must be correctly seated in lug (2).

Coat sealing rings of washer pump with anti-friction agent.

Ensure hose is laid without kinks.

Scheme 251

61 71 100 REMOVING AND INSTALLING/REPLACING WINDSCREEN WASHER PUMP

Necessary preliminary tasks

1. Remove trim panel for cover on frame side member on right. See «51 71 447 REMOVING AND INSTALLING OR REPLACING PANEL FOR COVER ON LEFT OR RIGHT SIDE MEMBER»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-447-removing-and-installing) .
2. Remove wheel arch trim at front right. See «51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)»(/bmw/x5/e70-2006-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-039-removing-and-installingreplacing) .
3. Drain fluid reservoir for windscreen washer system

Release bolts.

Press off side panel slightly.

Note. Side panel shown removed for purposes of clarity.

Disconnect plug connection (1).

Pull windscreen washer pump (2) in direction of arrow out of fluid reservoir for windscreen washer system.

Disconnect hose plug connection (3) from windscreen washer pump (2).

Scheme 252

Installation

Coat sealing ring (4) of windscreen washer pump (2) with antiseize agent.

Ensure hose is laid without kinks.

See also:
• 72 00 ... SAFETY REGULATIONS FOR HANDLING COMPONENTS WITH GAS GENERATORS
• GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES
• 51 47 172 REMOVING AND INSTALLING/REPLACING FLAP IN LUGGAGE COMPARTMENT TRIM, LEFT OR RIGHT
• 51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM
• 51 12 156 REMOVING AND INSTALLING REAR BUMPER TRIM
• 51 41 000 REMOVING AND INSTALLING LEFT OR RIGHT FRONT DOOR TRIM PANEL
• 51 48 060 REMOVING AND INSTALLING/REPLACING SOUND INSULATION IN LEFT OR RIGHT FRONT DOOR
• 51 42 000 REMOVING AND INSTALLING LEFT OR RIGHT REAR DOOR TRIM PANEL
• 51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS
• 52 26 008 REMOVING AND INSTALLING/REPLACING LEFT/RIGHT SIDES OF BACKREST ON REAR SEAT BACKREST (THROUGH-LOADING)
• 51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL
• 32 10 005 ADJUSTMENT FOR ACTIVE FRONT STEERING
• 54 0 ... NOTES ON PANORAMA GLASS ROOF (INITIALIZATION/NORMALIZATION/LEARNING OF CHARACTERISTIC CURVE)
• 67 62 ... NOTES ON INITIALIZING POWER WINDOW UNIT IN FRONT DOOR
• 51 16 ... CALIBRATING COMPASS IN INTERIOR REARVIEW MIRROR
• 32 33 000 REMOVING AND INSTALLING/REPLACING STEERING WHEEL
• 32 33 010 REMOVING AND INSTALLING/REPLACING SPORT STEERING WHEEL
• 32 31 020 REMOVING AND INSTALLING / REPLACING LOWER SECTION OF STEERING COLUMN TRIM
• 51 45 374 REMOVING AND INSTALLING/REPLACING DECORATIVE STRIP ON INSTRUMENT PANEL ON DRIVER'S SIDE ON RIGHT
• 64 22 135 REMOVING AND INSTALLING/REPLACING LEFT/RIGHT FRESH-AIR GRILLE
• 63 99 ... INSTRUCTIONS FOR REPLACING LIGHT BULBS (INTERIOR LIGHTS)
• 63 99 431 REPLACING BULB FOR FRONT CEILING LIGHT
• 51 45 310 REMOVING AND INSTALLING (REPLACING) CENTER TRIM FOR INSTRUMENT PANEL
• 51 16 160 REMOVING AND INSTALLING/REPLACING CENTRE CONSOLE TRIM
• 52 17 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON LEFT OR RIGHT FRONT SEAT
• 32 34 020 REMOVING AND INSTALLING/REPLACING AIRBAG UNIT
• 51 23 100 REMOVING AND INSTALLING/REPLACING RIGHT ENGINE HOOD/BONNET LOCK
• 51 45 377 REMOVING AND INSTALLING/REPLACING DECORATIVE STRIP ON MIDDLE FRESH-AIR GRILLE
• 51 71 470 REMOVING AND INSTALLING/REPLACING TRIM ON FRONT LEFT OR RIGHT WHEEL ARCH
• 51 71 039 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (REAR SECTION)
• 51 16 163 REMOVING AND INSTALLING/REPLACING REAR CENTRE CONSOLE TRIM
• 64 12 ... INITIALIZING TELESTART HAND TRANSMITTER
• 51 43 070 REMOVING AND INSTALLING/REPLACING SIDE TRIM PANEL, FOOTWELL, ON A-PILLAR, LEFT
• 51 16 060 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (WITH RAIN SENSOR)
• 65 83 010 REMOVING AND INSTALLING/REPLACING CAR COMMUNICATION COMPUTER
• 51 13 116 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER
• 51 49 000 REMOVING AND INSTALLING/REPLACING PANEL FOR REAR LID
• 63 25 000 REMOVING AND INSTALLING/REPLACING AUXILIARY BRAKE LIGHT
• 51 71 447 REMOVING AND INSTALLING OR REPLACING PANEL FOR COVER ON LEFT OR RIGHT SIDE MEMBER
• 63 13 200 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT AUXILIARY DIRECTION INDICATOR
• 61 13... TREATING CABLES AND FIBER-OPTIC CABLES
• 12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY
• 61 13 CUTTING TO LENGTH AND STRIPPING INSULATION FROM CABLES
• 61 13 BUTT CONNECTOR FOR REPAIRING A PLUG CONNECTION
• 61 13 OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS
• 61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS
• 61 13 CRIMPING STOP PARTS
• 61 13 INSTALLING FAN CONNECTOR FOR RETROFITTING/REPAIRS
• 61 13... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBERS TO LENGTH
• 61 13... CRIMPING OPTICAL FIBERS
• 61 13... REPAIRING RIBBON CABLES
• 61 00... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY
• 61 20 900 DISCONNECTING AND CONNECTING BATTERY NEGATIVE LEAD
• Start/Stop switch
• 61 35 107 REMOVING AND INSTALLING/REPLACING JUNCTION BOX ELECTRONICS
• 61 31 996 CARRY OUT STEERING ANGLE SENSOR ADJUSTMENT
• VEHICLE PROGRAMMING AND CODING
• 61 31 035 REMOVING AND INSTALLING/REPLACING SWITCH FOR STEERING COLUMN ADJUSTMENT
• 61 31 011 REMOVING AND INSTALLING/REPLACING VOLUTE SPRING CASSETTE
• 61 31 008 REMOVING AND INSTALLING OR REPLACING STEERING COLUMN SWITCH CLUSTER
• 61 35... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
• 61 31 192 REPLACING KNOB FOR CONTROLLER
• 61 31 193 REMOVING AND INSTALLING/REPLACING BUTTON UNIT (MENU/VOICE INPUT)
• 61 31 336 REMOVING AND INSTALLING/REPLACING TRIM FOR GEAR SELECTOR SWITCH
• 61 31 117 REMOVING AND INSTALLING/REPLACING POWER WINDOW SWITCH (DRIVER'S SIDE)
• 61 35 685 REPLACING RAIN/LIGHT SOLAR SENSOR
• 61 35 679 INITIALIZING RAIN/LIGHT SENSOR
• 61 61 010 CHECKING/ADJUSTING CONTACT ANGLE OF WINDSCREEN WIPER ARMS ON WINDSCREEN
• 61 62 030 REMOVING AND INSTALLING/REPLACING WIPER ARM ON REAR WINDOW
• 61 67 100 REMOVING AND INSTALLING/REPLACING HIGH - PRESSURE NOZZLE OF HEADLIGHT WASHER SYSTEM ON LEFT (OR RIGHT)
• 61 62 150 REMOVING AND INSTALLING/REPLACING WINDOW WASHER PUMP FOR REAR WINDOW WASHER SYSTEM
• 61 71 100 REMOVING AND INSTALLING/REPLACING WINDSCREEN WASHER PUMP
• 61 31 492 REPLACING LEVEL SWITCH FOR WINDSCREEN WASHER SYSTEM
