Removal & Installation
Operation is identical to replacing radial shaft seal for front axle output. See RADIAL SHAFT SEAL FOR FRONT AXLE OUTPUT (500 X-DRIVE) .
Remove reinforcement plate. Remove front propeller shaft. Press out output shaft (1) with a suitable tool (2) in direction of arrow. (Scheme 23)
Scheme 23
Remove protective cap (1) with a screwdriver in direction of arrow. (Scheme 24)
Scheme 24
Drive a hole into radial shaft seal (2) using a center punch (1). (Scheme 25)
Note. Do not use a drill as drillings may result in transmission malfunction.
Scheme 25
Install special tool (23 0 490). Drive out radial shaft seal (1) with impact weight (2). (Scheme 26)
Scheme 26
Drive in radial shaft seal with a suitable special tool (27 1 420). (Scheme 27) Add final details to vehicle. Check oil level.
Scheme 27
Detach plug (1,2) from resistor. Release screw (3) and remove resistor. (Scheme 28)
Scheme 28
Disconnect plugs (1, 2). Release screws and remove servomotor from transfer box. (Scheme 29)
