Removal & Installation - x5 (a5s 360r/390r) BMW X5 E53

Automatic Trans 22 illustrations ~796 words

IDENTIFICATION

Note. For further information, see AUTOMATIC TRANSMISSION article.

Model (Chassis Code)Engine Size (Code)
2001-05
X5 (E53)3.0 L (M54)

VEHICLE IDENTIFICATION

CAUTIONDisconnecting vehicle battery will cancel fault codes of control units. On vehicles with radio codes, after disconnecting battery, radio codes must be re-entered. Obtain radio code card from customer. Note stored stations and restore then after connecting battery. Also, where applicable, initialize sunroof and set steering angle.

AUTOMATIC TRANSMISSION

CAUTIONUse only the approved transmission fluid in this automatic transmission. Failure to comply with this requirement will result in serious damage to the automatic transmission. Catch and dispose properly escaping transmission fluid.

Note. For filling and servicing, see SERVICING - A/T .

Note. Numbers in text refer to numbers in figures.

  1. Disconnect battery negative lead. See INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY.
  2. Remove exhaust system. See REPLACING INTERMEDIATE MUFFLER (M62, M54).
  3. Remove heat shield on right. Unclip cable for oxygen sensors.
  4. Remove reinforcement plate. Remove engine underguard at front.
  5. Release stabilizer and slide forwards. See «STABILIZER»(/bmw/x5/e53-1999-2003/remont/suspension-front/#suspension-front).
  6. Remove front propeller shaft. See REMOVING AND INSTALLING FRONT PROPELLER SHAFT. Unclip vent line from transmission at bracket (engine).
  7. Release screws and remove exhaust bracket (1). (Scheme 222)
  8. Grip clamp bushing (1) and loosen selector lever nut (2). (Scheme 223)
  9. Grip cable (1) at hexagon (2). (Scheme 224) Unfasten nut (3). Pull cable (1) out of holder.
  10. Unlock attachment plug (1) and disconnect. (Scheme 225) Unclip cable (2) from transmission housing.
  11. Release screw (1). (Scheme 226) Withdraw hydraulic lines (2) for automatic transmission fluid cooler from transmission housing.
  12. Assemble Special Tools (00 2 030 / 24 5 301 / 24 5 305). Special Tool (24 5 301) must be provided with an additional bore hole. (Scheme 227) This bore is essential to convert Special Tool (24 5 301) into a stable assembly position. Only in this way is it ensured that transmission unit rests safely on Special Tool (24 5 305) and does not tilt. To do so, insert pivot pin into rear bore of Special Tool (24 5 301). (Scheme 228)
  13. Support transmission and transfer case with Special Tools (00 2 030 / 24 5 301 / 24 5 305). (Scheme 229)
  14. Unclip cable for oxygen sensors on transmission cross-member. Unclip cable from transmission. Unfasten screws and remove transmission crossmember. (Scheme 230)
  15. Unfasten screws. (Scheme 231)
  16. Grip propeller shaft at center bearing and release nuts. (Scheme 232) DO NOT let propeller shaft fall into joints. Joints and rubber sleeve on constant-velocity joint can be damaged. (Scheme 233)
  17. Bend propeller shaft downwards at center bearing. Remove from transmission output flange and tie up to one side with a cord or wire.
  18. Release screw (1). (Scheme 234) Lever out protective cap (2).
  19. Release retaining screws on torque converter with Special Tool (24 1 110). (Scheme 235) Continue cranking engine at central bolt in direction of rotation. Unscrew Special Tool (24 2 300) from torque converter.
  20. Unfasten screws. (Scheme 236) Pull out transmission with transfer case towards rear and lower.
  21. Release transfer case screw connection on transmission and remove transfer case.

Scheme 222

Scheme 222
Scheme 222

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230

Scheme 231

Scheme 231
Scheme 231

Scheme 232

Scheme 232
Scheme 232

Scheme 233

Scheme 233
Scheme 233

Scheme 234

Scheme 234
Scheme 234

Scheme 235

Scheme 235
Scheme 235

Scheme 236

Scheme 236
Scheme 236
CAUTIONOil cooler and lines must always be flushed before a replacement transmission is installed.
CAUTIONWhen joining up engine and transmission, ensure ease of movement of torque converter.
  1. To install, reverse removal procedure. If replacing transmission, fit shift lever, bracket for cable and retainers for oxygen sensor cable from old transmission to new transmission.
  2. Install transfer case to transmission. Pay attention to dowel sleeves (1). (Scheme 237) Replace damaged dowel sleeves. Apply a thin coat of WEICON ANTISIZE grease or equivalent to splines. Tighten transfer case screw connection on transmission to specification. See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  3. Note dowel sleeves. (Scheme 238) Replace damaged dowel sleeves.
  4. Screw Special Tool (24 2 300) into tapped hole (1). (Scheme 239)
  5. Turn torque converter until Special Tool (24 2 300) is flush with bore in driving disk. (Scheme 240) Flange automatic transmission to engine.
  6. Bore (1) in driving disk must be accessible from aperture in oil sump. (Scheme 241)
  7. Tighten transmission-to-engine screws to specification. (Scheme 236) See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  8. Tighten torque converter-to-flywheel screws to specification. (Scheme 235) See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  9. Center bearing must be aligned at right angles to propeller shaft. (Scheme 232) Tighten nuts of center mount-to-body to specification. See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  10. Replace self-locking nuts of flexible disk-to-propeller shaft and transmission output flange. (Scheme 231) Grip each screw and tighten down nut. This prevents flexible coupling from being subjected to torsion stress. Tighten to specification. See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  11. Tighten crossmember screws to specification. (Scheme 230) See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  12. Replace sealing rings on hydraulic lines.
  13. Install nut for selector lever cable to specification. See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  14. Grip clamping sleeve (1). (Scheme 242) Slacken nut (2). Press shift lever (3) forwards into park position. Press cable (4) in direction of arrow and release again. Grip clamping sleeve (1) and tighten nut (2) to specification. See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  15. Install front propeller shaft. See REMOVING AND INSTALLING FRONT PROPELLER SHAFT.
  16. To install reinforcement plate, torque screws (2) to specification. (Scheme 243) See «TORQUE SPECIFICATIONS»(/bmw/x5/e53-1999-2003/remont/automatic-trans/#removal-installation-x5-a5s-360r390r__torque-specifications).
  17. After completion of work, check transmission fluid level of transmission and transfer case. Top up if necessary.

Scheme 237

Scheme 237
Scheme 237

Scheme 238

Scheme 238
Scheme 238

Scheme 239

Scheme 239
Scheme 239

Scheme 240

Scheme 240
Scheme 240

Scheme 241

Scheme 241
Scheme 241

Scheme 242

Scheme 242
Scheme 242

Scheme 243

Scheme 243
Scheme 243

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Bowden Cable On Shift Tower/Transmission11 (15)
Center Mount-To-Body15 (21)
Flexible Disk-To-Front Axle Differential44 (60)
Flexible Disk On Propeller Shaft47 (64)
Flexible Disk-To-Propeller Shaft & Transmission Output Flange
M10 8.8 Thread35 (48)
M10 10.9 Thread47 (64)
M12 10.9 Thread74 (100)
Reinforcement Plate-To-Front Axle Support/Engine Carrier
Step 141 (56)
Step 2Additional 90°
Step 3Additional 15°
Torque Converter-To-Flywheel33 (45)
Transfer Case Filler Plug17 (23)
Transfer Case-To-Transmission32 (43)
Transmission Cross-Member-To-Body30 (41)
Transmission Cross-Member-To-Rubber Mounts55 (74)
Transmission-To-Engine
Hex Screws
M8 Thread18 (24)
M10 Thread33 (45)
M12 Thread60 (82)
Torx Bolts
M8 Thread15 (21)
M10 Thread31 (42)
M12 Thread53 (72)
INCH Lbs. (N.m)
Clamping Screw On Shift Lever89 (10)
