61 0 021 Fuse Link FF 3.15 A / 500 V
Note: For analog/digital multimeter M 2005, M 2007, M2008
Storage location: H 107
Order number: 61 0 021
Fuse link FF 3.15 A / 500 V
61 0 200 Crimping Set (Basic Tool)
Minimum set: Measuring and testing equipment
Note: Consisting of case + basic crimping tool
Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 02 02 05 (194)
Order number: 61 0 200
Crimping set (basic tool)
Consisting of
1 = 61 0 201 Plastic case
Note: As storage system for complete set.
2 = 61 0 202 Crimping tool
Note: Basic tool for assorted matrices (crimping insert set)
3 = 61 0 203 Allen key
Note: For securing individual matrices in crimping tool
Scheme 218
61 0 210 Matrix LSK 8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load current contact 8)
SI number: 02 02 05 (194)
Order number: 61 0 210
Matrix LSK 8
Scheme 219
61 0 220 Matrix for SLK 2.8
In conjunction with: 61 0 202 (crimping tool)
Note: (crimping insert set for load contact tube 2.8)
SI number: 02 02 05 (194)
Order number: 61 0 220
Matrix for SLK 2.8
Scheme 220
61 0 230 Stencil For Contacts "DFK 40" and "MAK 8"
In conjunction with: 61 0 202 (crimping tool)
Note: For crimping contacts when replacing passenger compartment fuse box (up to model year 09/2005)
Series: E46, E65, E66, E67, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 02 07 05 233
Order number: 61 0 230
Stencil for contacts "DFK 40" and "MAK 8"
Scheme 221
61 0 300 Releasing Tool (Complete Kit)
Minimum set: Measuring and testing equipment
Note: Replaces from 09/2005 special tool 61 1 150. From 06/2006 extended by tools 61 0 325 - 61 0 331.
Series: E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 2 05 05 (217)
Order number: 61 0 300
Releasing tool (complete kit)
Consisting of
1 = 61 0 301 Release tool for round contacts (diameter 1.5)
Note: Replaces from 09/2005 special tool 61 1 131
2 = 61 0 302 Replacement sleeve D=1.5
Note: Replaces from 09/2005 special tool 61 1 157
In conjunction with: 61 3 301
3 = 61 0 303 Release tool for round systems with D=2.5
Note: Replaces from 09/2005 special tool 61 1 132
4 = 61 0 304 Replacement sleeve (D=2.5)
Note: Replaces from 09/2005 special tool 61 1 156
5 = 61 0 305 Release tool for round contacts (D=3.5)
Note: Replaces from 09/2005 special tool 61 1 133
6 = 61 0 306 Replacement sleeve (D=3.5) for 61 0 305
Note: Replaces from 09/2005 special tool 61 1 155
7 = 61 0 307 Release tool for socket-side round contacts (D=2.5)
8 = 61 0 308 Replacement sleeve for special tool 61 0 307 (D=2.5)
9 = 61 0 309 Release tool for pin-side round contact (D=1.5) manufacturer: Kostal
Note: Replaces from 09/2005 special tool 61 1 139
10= 61 0 311 Replacement sleeve for special tool 61 0 309
Note: Replaces from 09/2005 special tool 61 1 154
11= 61 0 312 Release tool for flat spring contact with a detent lug (1.6 mm)
Note: Replaces from 09/2005 special tool 61 1 134
12= 61 0 313 Release tool for flat spring contacts with a snap-in pin (1.9 mm)
Note: Replaces from 09/2005 special tool 61 1 137
13= 61 0 314 Release tool for flat spring contact with a snap-in pin (2.7 mm)
Note: Replaces from 09/2005 special tool 61 1 135
14= 61 0 315 Release tool for flat spring contacts with double snap-in pin "Micro-Timer 2"
Note: Replaces from 09/2005 special tool 61 1 151
15= 61 0 316 Release tool for flat spring contacts with double snap-in pin "SPT 4.8" "JPT 2.8"
Note: Replaces from 09/2005 special tool 61 1 136
16= 61 0 317 Release tool for LSK 8
Note: Replaces from 09/2005 special tool 61 1 200
17= 61 0 318 Release tool for "Maxi Power Timer 9.5"
Note: Replaces from 09/2005 special tool 61 1 180
18= 61 0 319 Release tool for sensor laminated contacts ("SLK2.8")
Note: Replaces from 09/2005 special tool 61 1 148
19= 61 0 321 Release tool for sensor laminated contacts with unlocking element ("SLK 2.8")
20 = 61 0 322 Release tool for mini laminated contact ("MLK 1.2 mm")
21 = 61 0 323 Release tool for flat spring contacts with a detent lug (MQS)
Note: Replaces from 09/2005 special tool 61 1 152
22 = 61 0 324 Release tool for secondary locking
Note: Universal tool for damage-free opening/removal of secondary locks
23 = 61 0 329 Case with foam inlay without tools
Note: Storage system for release tools from set 61 0 300
24 = 61 0 325 Release tool "JPT"
25 = 61 0 326 Release tool "MQS"
Note: For releasing all micro contacts
26 = 61 0 327 Plug-in aid
Note: For inserting contacts (0.64 - 1.2 mm) in housing
27 = 61 0 328 Plug-in aid
Note: For inserting contacts (2.8 - 4.8 mm) in housing
28 = 61 0 331 Release tool "SLK 5.8"
Note: For releasing "SLK 5.8 mm" contacts
Scheme 222
61 1 150 Releasing tool kit
Note: For circular connector / press-out tool - Contains kits 61 1 130, 61 1 140 and 61 1 180 Replaced by special tool 61 0 300 from 09/2005.
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E65, E66, E83, E85, R50, R53, RR1
Storage location: K 106
Order number: 61 1 150
Releasing tool kit
Consisting of
61 1 151 Press-out tool
Note: For Power timer contacts / AMP and Bosch Replaced by special tool 61 0 315 from 09/2005.
61 1 152 Press-out tool
Note: For Micro timer contacts Replaced by special tool 61 0 323 from 09/2005.
61 1 153 Releasing tool
Note: For retaining tab of relay holder
61 1 154 Replacement sleeve dia. 1.5 mm for 61 1 139
Note: Order number was temporarily assigned for case inlay in 8/95 on delivery of case Replaced by special tool 61 0 311 from 09/2005.
61 1 155 Replacement sleeve dia. 3.5 mm for 61 1 133
Note: Replaced by special tool 61 0 306 from 09/2005.
61 1 156 Replacement sleeve dia. 2.5 mm for 61 1 132
Note: Replaced by special tool 61 0 304 from 09/2005.
61 1 157 Replacement sleeve dia. 1.5 mm for 61 1 131
Note: Replaced by special tool 61 0 302 from 09/2005.
61 1 158 Case with inlay
Note: Replaced by special tool 61 0 329 from 09/2005.
61 1 159 Operating instructions
61 1 131 Press-out tool
Note: Replaced by special tool 61 0 301 from 09/2005
61 1 132 Press-out tool
Note: For 2.5 mm round contacts Replaced by special tool 61 0 303 from 09/2005.
61 1 133 Press-out tool
Note: For 3.5 mm round contacts Replaced by special tool 61 0 305 from 09/2005.
61 1 134 Press-out tool
Note: For Mini flat spring contacts Replaced by special tool 61 0 312 from 09/2005.
61 1 135 Press-out tool
Note: For standard flat spring contacts Replaced by special tool 61 0 314 from 09/2005.
61 1 136 Press-out tool
Note: For Power timer contacts (G & H) Replaced by special tool 61 0 316 from 09/2005.
61 1 137 Press-out tool
Note: For timer contacts Replaced by special tool 61 0 313 from 09/2005.
61 1 138 Socket wrench
Note: For telltale lamps (instrument cluster)
61 1 139 Press-out tool
Note: Slotted sleeve for Kostal round contacts with dia. 1.5 mm Replaced by special tool 61 0 311 from 09/2005.
61 1 141 Releasing tool
Note: For D 2.5 / ELA, 4-pin, round
61 1 142 Releasing tool
Note: For D 2.5 / ELA, 7-pin, round
61 1 143 Releasing tool
Note: For D 2.5 / ELA, 12 -pin, round
61 1 144 Releasing tool
Note: For D 2.5 / ELA, 25 -pin, round
61 1 145 Releasing tool
Note: For D 1.5 / ELA, 10 -pin, round
61 1 149 Replacement blades
Note: For press-out tool 61 1 148
61 1 148 Press-out tool for SLK
Note: SLK = sensor laminated contacts Replaced by special tool 61 0 319 from 09/2005.
61 1 180 Press-out tool
Note: For load current contacts Replaced by special tool 61 0 318 from 09/2005.
Scheme 223
61 1 190 Pliers
Note: For insulation displacement connectors for repairing ribbon cables
Series: E60, E61, E63, E64, E65, E66, E67, E81, E82, E83, E86, E87, E90, E91, E92, R50, R52, R55, R56, RR1, RR2
SI number: 1 14 01 (766)
Order number: 61 1 190
Pliers
Scheme 224
61 2 250 V-Adapter Lead (Rail Pressure Sensor)
Minimum set: Measuring and testing equipment
Note: For system check of rail pressure control for commen-rail diesel engines. Also suitable for connection to: Crank-/camshaft sensor, boost pressure sensor, particulate filter pressure sensor, swirl flap actuator, oil level sensor etc.
Series: E39, E46, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93
SI number: 02 01 06 283
Order number: 61 2 250
V-adapter lead (rail pressure sensor)
Scheme 225
61 2 410 Battery Trickle Charger
Note: Will in future be replaced by the battery trickle charger "Acctiva easy". Order number 81 39 0 409 468 (Europe version) and 81 39 0 409 471 (USA version)
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1
Storage location: Single
SI number: 2 02 00 (545)
Order number: 61 2 410
Battery trickle charger
Consisting of
1 = 61 2 411 Trickle charger
Note: Including connection cable (ribbon cable) for cigarette lighter socket
3 = 61 2 413 Adapter cable
Note: for direct connection to battery or terminal point
9 = 61 2 419 Operating instructions
Scheme 226
61 2 440 System Connecting Cable (Country-Specific)
Note: System connecting cable for battery trickle charger 61 2 410
Order number: 61 2 440
System connecting cable (country specific)
Consisting of
1 = 61 2 441 System connecting cable (country specific)
Note: Algeria / Armenia / Belarus / Belgium / Brazil / Denmark / Dubai / Egypt / Finland / France / Germany / Greece / Korea / Luxembourg / Martinique / Morocco / Norway / Saudi Arabia / Sweden / Spain and others
2 = 61 2 442 System connecting cable (country specific)
Note: Australia / New Zealand
3 = 61 2 443 System connecting cable (country specific)
Note: Italy
4 = 61 2 444 System connecting cable (country specific)
Note: Bahrain / Brunei Dar es Salaam / England / Hong Kong / India / Kuwait / Nigeria / Northern Ireland / Oman / Qatar / Singapore / Sri Lanka (Ceylon)
5 = 61 2 445 System connecting cable (country specific)
Note: Switzerland
6 = 61 2 446 System connecting cable (country specific)
Note: Argentina / Barbados / Canada / China / Guam / Honduras / Jamaica / Mexico / Panama / Philippines / Tahiti / Taiwan / USA
7 = 61 2 447 System connecting cable (country specific)
Note: Japan
61 3 080 V-Adapter Lead For Transfer Case - ECU E83 (8-pin)
Minimum set: Measuring and testing equipment
Note: For checking function of engine at transfer box (X3)
Series: E83
SI number: 02 08 03 (045)
Order number: 61 3 080
V-adapter lead for transfer case - ECU E83 (8-pin)
Scheme 227
61 3 090 V-Adapter Lead DXC Control Unit E83 (6 -pin)
Minimum set: Measuring and testing equipment
Note: For checking function of DXC control unit in X3
Series: E83
SI number: 02 08 03 (045)
Order number: 61 3 090
V-adapter lead DXC control unit E83 (6 - pin)
Scheme 228
61 3 130 I-Adapter Lead Airbag Control Unit E83 (75-pin)
Minimum set: Measuring and testing equipment
In conjunction with: Test box 61 4 380
Note: For checking function of airbag control unit in X3
Series: E83
SI number: 02 08 03 (045)
Order number: 61 3 130
I-adapter lead airbag control unit E83 (75-pin)
Scheme 229
61 4 300 Adapter Lead For OBD Socket
Note: For connecting diagnosis system to OBD socket from 06/2000.
Storage location: Single
SI number: 2 04 00 (561)
Order number: 61 4 300
Adapter lead for OBD socket
Scheme 230
61 4 320 Crimping Set With Pliers
Minimum set: Measuring and testing equipment
Note: For repairing fibre optics conductors and cables. Universal crimp head 61 4 328 added as from 06/2006.
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 1 14 01 (766)
Order number: 61 4 320
Crimping set with pliers
Consisting of
1 = 61 4 321 Pliers without crimping head
2 = 61 4 322 Crimping head
Note: For stripping insulation and cutting fibre optic cable to length
3 = 61 4 323 Crimping head
Note: For crimping fibre optic cable contacts
4 = 61 4 324 Crimping head
Note: For crimping MQS contacts
5 = 61 4 325 Crimping head
Note: For crimping MPQ contacts
6 = 61 4 326 Substitute blade
Note: For face-cutting fibre optic cables
7 = 61 4 327 Substitute blade
Note: With tool for replacing blade in cable stripping unit. Must be ordered separately, not included in 61 4 320 delivery specification!
8 = 61 4 328 Universal crimping head
Note: For crimping contacts (without seal) and cable cross-sections of 0.35 - 2.5 mm.
In conjunction with: in conjunction with 61 4 321
Scheme 231
61 4 370 V-Adapter Lead (2-Pin), Zero-Coded
Minimum set: Measuring and testing equipment
Note: Can be used on different plug housings in engine wiring harness (e.g. from Kostal - "SLK 2.8", Tyco" Junior-Power-Timer" or Bosch) with different codings.
Series: E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91, R50, R52, R53, RR1
SI number: 02 01 05 186
Order number: 61 4 370
V-adapter lead (2-pin), zero-coded
Scheme 232
61 4 380 Measuring Box, 105-Pin, Complete
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 61- to 105-pin plug connections
Series: E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R56, RR1
Storage location: G 110, S 205, U 202, U 205
SI number: 2 04 01(710)
Order number: 61 4 380
Measuring box, 105-pin, complete
Consisting of
1 = 61 4 381 Measuring box, 105-pin
Note: Without accessories
2 = 61 4 382 Test lead, black
Note: 2 mm system, lead length: 750 mm
3 = 61 4 383 Test lead, red
Note: 2 mm system, lead length: 750 mm
4 = 61 4 384 Test lead set
Note: 2/4 mm system, lead length: 200 mm
5 = 61 4 385 Earth/ground cable
Note: For shield pick-off, lead length: 1.5 m
Scheme 233
61 4 390 Measuring Box, 60-Pin
Minimum set: Measuring and testing equipment
Note: For connecting all adapter cables with 27 - to 60-pin plug connections
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E87, E90, E91, E92, E93, R50, R52, R53, R56, RR1
Storage location: T 210
SI number: 2 02 98(308)
Order number: 61 4 390
Measuring box, 60-pin
Scheme 234
61 6 060 Universal Wiper Arm Puller
Minimum set: Mechanical tools
Note: For removing windscreen wiper arm from drive shaft
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E81, E82, E83, E85, E86, E87, E90, E91, RR1, RR2
Storage location: B40
SI number: 1 10 99 (433)
Order number: 61 6 060
Universal wiper arm puller
Consisting of
1 = 61 6 061 Basic body
2 = 61 6 062 Claw, left/right
3 = 61 6 063 Spindle
4 = 61 6 064 Thrust piece
Scheme 235
61 6 100 Angle Measuring Instrument
Minimum set: Mechanical tools
Note: For measuring contact/approach angle of wiper blades to window (angle when setting wiper arms)
Series: E36, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R55, R56, RR1, RR2
SI number: 1 21 05 220
Order number: 61 6 100
Angle measuring instrument
Scheme 236
61 6 210 Wiper Arm Puller
Minimum set: Mechanical tools
Series: E52, E53, E60, E61, E63, E64, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53
SI number: 1 01 05 (172)
Order number: 61 6 210
Wiper arm puller
Scheme 237
61 8 081 Additions To Repair Kit I
Note: Order through BMW EPC (Electronic Parts Catalogue), (order numbers: 12 52 1 706 059" 12 52 1 706 068" 12 52 1 706 069" 61 13 1 352 607" 61 31 1 378 942)
Storage location: K 108
Order number: 61 8 081
Additions to repair kit I
61 8 082 Additions To Repair Kit II
Note: Order through BMW EPC (Electronic Parts Catalogue), (order numbers: 61 13 1 368 534" 61 13 1 369 747" 61 13 1 374 225" 61 13 1 378 722)
Storage location: K 108
Order number: 61 8 082
Additions to repair kit II
61 8 083 Additions To Repair Kit III
Note: Order through BMW EPC (Electronic Parts Catalogue), (order numbers: 61 13 1 378 110" 61 13 1 378 130" 61 13 1 378 136" 61 13 1 378 137" 61 13 1 378 138" 61 13 1 378 139" 61 13 1 378 908" 61 13 1 378 944" 61 13 1 378 987)
Storage location: K 108
Order number: 61 8 083
Additions to repair kit III
61 9 040 Set Of Tools For Repair Kit IV
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E83, E85, E87, E90, E91, E92, R50, R52, R53
Storage location: K 108
SI number: 2 02 92(505)
Order number: 61 9 040
Set of tools for repair kit IV
Consisting of
1 = 61 9 041 Hand pliers without crimper
2 = 61 9 042 Crimper
Note: For crimping butt connectors and contact sleeves for strip connectors
3 = 61 9 043 Cable stripper with wire cutter
4 = 61 9 044 Crimper
Note: For crimping antenna connector (antenna cable/radio plug connection)
Scheme 238
61 9 045 Female Die
In conjunction with: 61 9 041 Crimping tool
Note: For crimping 2.5 mm (dia.) sleeves
Order number: 61 9 045
Female die
