61 31 115 Replacing rocker switch for side window operation (front)
Special tools required
- 00 9 341
Carefully lever out rocker switch for side window operation (1) with special tool 00 9 341 at specified points.
Feed rocker switch for side window operation (1) out of front door trim panel (2).
Disconnect associated plug connection and remove rocker switch for side window operation (1).
Scheme 1
Installation
Retaining hooks (1) of rocker switch for side window operation (2) must not be damaged.
Make sure rocker switch for side window operation (2) is correctly seated.
Scheme 2
61 31 116 Replacing rocker switch for side window operation (rear)
Special tools required
- 00 9 317 «00 9 310 ASSEMBLY WEDGES (SET IN PLASTIC CASE)»(ref-265619-S11647016702007092300000)
| IMPORTANT | Comply with the following work steps in order to avoid damaging the door trim panel and rocker switch. To avoid damaging leather armrests, wrap front end of special tool 00 9 317 in fabric adhesive tape. |
Procedure
- Slide special tool 00 9 317 under rocker switch for side window operation (1) (do not lift the switch in the process).
- Slide rocker switch (1) with special tool 00 9 317 towards rear and lever out.
Feed rocker switch (1) out of rear door trim panel (2) and disconnect plug connection.
Scheme 3
Installation
Retaining hooks (1) of rocker switch for side window operation (2) must not be damaged.
Make sure rocker switch for side window operation (2) is correctly seated.
