12 1 200 Torque limiter 30 Nm
Minimum set: Mechanical tools
In conjunction with: 12 1 171, 12 1 172
Note: For tightening spark plugs to torque limit
Engine: M40, M42, M43, M43TU, M44, M50, M52, M52TU, M54, M56, M60, M62, M70, M73, N40, N42, N46, N73, S50US
Storage location: B13
Scheme 1
SI number: 1 05 92(507)
Order number: 12 1 200
Torque limiter 30 Nm
12 1 300 Adapter set for 134-pin module plug
Minimum set: Measuring and testing equipment
In conjunction with: 61 1 459
Note: For diagnosis and troubleshooting on DME and transmission control - from model year 98
Engine: M54, M56, M62, M73, N40, N42, N46, N62, N73
Storage location: N 201, N 202, N 203, N 204
SI number: 2 04 97(248)
Order number: 12 1 300
Adapter set for 134-pin module plug
Scheme 2
Consisting of
12 1 301 Adapter lead 9-pin
12 1 302 Measurement module 24-pin
12 1 303 Measurement module 40-pin
12 1 304 Measurement module 52-pin
Note: Supplied from 08/2004 in conjunction with 12 1 305 (zero-coded cover cap for new SGM control unit in E6x)
12 1 305 Zero-coded cover cap for 52-pin test box (12 1300/304)
Note: New plugs in E61/E61/E63 and E64 on SGM control unit Cover cap 12 1 300/305 for diagnosis on wiring harness. From 08/2004 cover cap will be supplied with test box.
SI number: 2 07 04 (138)
Order number: 12 1 305
Zero-coded cover cap for 52-pin test box (12 1300/304)
12 7 050 Adapter lead
Minimum set: Measuring and testing equipment
Note: For engines with rod-type ignition coils for measuring secondary voltage
Engine: M54, M56, N40, N42, N46, N62, N73, S54
Storage location: F 104
Scheme 3
SI number: 2 01 01 (671)
Order number: 12 7 050
Adapter lead
12 7 060 Antistatic mat (ESD)
Note: ESD (Electro Static Discharge) For protection against ESD during repairs to electronic components. (Replaces the sub-number 12 7 192 from Eprom tool kit 12 7 190)
Series: E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53, RR1
Scheme 4
SI number: 2 06 04 (128)
Order number: 12 7 060
Antistatic mat (ESD)
12 7 110 Socket wrench socket WAF 24
Minimum set: Mechanical tools
Note: For removing and installing pulley on alternator
Engine: M10, M21, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M57, M57TU, M60, M62, M67, M70, M73, N46, N62, N73, S14, S50B30, S50B32
Scheme 5
Storage location: B21
SI number: 1 12 93(701)
Order number: 12 7 110
Socket wrench socket WAF 24
12 7 121 Counterholder wrench
In conjunction with: Socket
Note: Alternator N42 engine
Order number: 12 7 121
Counterholder wrench
12 7 122 Socket
In conjunction with: Counterholder wrench
Note: Hazet 8808 lg10
SI number: 1 28 03 (051)
Order number: 12 7 122
Socket
12 7 190 Eprom tools / ID marking
Note: Set no longer available. Antistatic mat can be ordered using number 12 7 060.
Storage location: J 101
Order number: 12 7 190
Eprom tools / ID marking
Consisting of
1 = 12 7 191 Eprom extractor pliers
Note: No longer available. Antistatic mat can be ordered using special tool number 12 7 060.
2 = 12 7 192 Antistatic mat
Note: Is replaced by main number 12 7 060.
12 7 200 Set of tools
Note: For opening & closing control unit box
Storage location: J 106
Order number: 12 7 200
Set of tools
Consisting of
1 = 12 7 201 Pliers
Note: For bending open tab washers
2 = 12 7 202 Lever
Note: For bending tab washers
3 = 12 7 203 Pliers
Note: For closing tab washers
4 = 12 7 204 Torx socket T20
5 = 12 7 205 Torx socket T10
6 = 12 7 206 Fine pen
Note: Black, waterproof
8 = 12 7 208 Slotted screwdriver 2 mm
9 = 12 7 209 Straightening tool
Note: For Eprom connections
12 7 210 Control unit seal
Storage location: J 106
Order number: 12 7 210
Control unit seal
Consisting of
1 = 12 7 211 Seal marks
2 = 12 7 212 Hole punch
Note: For seal mark dating
