ENGINE ELECTRONICS FUSE CARRIER
Engine electronics fuse carrier (A8680 or A6009) is located in left rear of engine compartment. (Scheme 1)
Scheme 1
FRONT FUSE HOLDER
For location of front fuse holder and power distribution (A41) (Scheme 2)
For amperage and components covered (Scheme 3)or (Scheme 4).
Scheme 2
Scheme 3
Scheme 4
POWER DISTRIBUTION
For location of power distribution (A41) (Scheme 2) Power distribution contains the following fuses
- F102 - 80 Amp - B+ Potential Distributor
- F104 - 100 Amp - Preheating Control Module
- F105 - 50 Amp - Ignition Switch
- F106 - 50 Amp - Light Switch Cluster, Ignition Switch
- F107 - 50 Amp - Light Switch Cluster, Trailer Module
REAR FUSE BOX (A400)
For location (Scheme 5) Rear fuse box (A400) contains the following fuses
- F108 - 250 Amp - Power Distribution
- F109 - 60 Amp - Rear Fuse Holder
Scheme 5
REAR FUSE HOLDER (A49)
For location (Scheme 6) Rear fuse holder (A49) contains the following fuses
- F80 - 30 Amp - Transfer Box Control Module
- F81 - 30 Amp - Amplifier
