Propeller Shaft - Removal & Installation BMW X3 E83

Driveshaft & Universal Joints 7 illustrations ~168 words

IDENTIFICATION

Model (Chassis Code)Engine Size (Code)
2004-06
X3 (E83)2.5 L (M54)
X3 (E83)3.0 L (M54)

VEHICLE IDENTIFICATION

CAUTIONDisconnecting vehicle battery will cancel fault codes of control units. On vehicles with radio codes, after disconnecting battery, radio codes must be re-entered. Obtain radio code card from customer. Note stored stations and restore then after connecting battery. Also, where applicable, initialize sunroof and set steering angle.
CAUTIONDo not move car by means of engine power once drive shaft has been removed.

Note. To avoid complaints of humming, before removing propeller shaft, mark cardan universal joint to drive flange of final drive. (Scheme 1) Reinstall joint in this position.

  1. Remove complete exhaust system. See REMOVING AND INSTALLING COMPLETE EXHAUST SYSTEM (M54). Remove heat shield.
  2. Release threaded ring (1) several turns with Special Tool (26 1 040). (Scheme 2)
  3. Unfasten screws. (Scheme 3)
  4. Unfasten screws. (Scheme 4)
  5. Push rear propeller shaft (1) forwards. (Scheme 5)
  6. Grip propeller shaft and release nuts. (Scheme 6) Bend propeller shaft downwards at center bearing (1). Detach propeller shaft from transmission output flange and remove downwards.
  7. Check centering. (Scheme 7) If necessary, replace damaged centering. Grease centering mount.
  8. To install, reverse removal procedure. Tighten fasteners to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/driveshaft-universal-joints/#propeller-shaft-removal-installation__torque-specifications). Tighten threaded ring with Special Tool (26 1 040) to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/driveshaft-universal-joints/#propeller-shaft-removal-installation__torque-specifications).

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Center Mount-To-Body15 (21)
Clamping Ring For Slide After Installation In Car16 (22)
Driveshaft-To-Drive Flange (Rear Axle)
Version, Constant-Velocity Joint: Compression Nut M8 Thread24 (32)
Compression Nut M10 Thread47 (64)
Finned Nut M8 Thread32 (43)
Finned Nut M10 Thread52 (70)
Version, Universal Joint: Compression Nut M10 Thread(1) 47 (64)
Version, Universal Joint: Torx Bolt M10 Thread63 (85)
Flexible Disk On Propeller shaft74 (100)
Flexible Disk_To-Transmission Output Flange66 (90)
(1) Only finned nuts to higher tightening torque.
(1)Only finned nuts to higher tightening torque.

TORQUE SPECIFICATIONS
