Generators & Regulators BMW X3 E83

Charging System 22 illustrations ~764 words

DESCRIPTION

Bosch or Valeo generators are installed in the X3. They are fitted depending on type of engine and equipment configuration.

Internal Battery Sensor (IBS) is a mechatronic component for monitoring battery condition. The IBS is secured and connected to the negative terminal of the battery. Power supply for IBS is fed across a separate cable. For data transmission, IBS is connected to the Digital Motor Electronics (DME) by way of the Bit-Serial Data (BSD) interface.

GENERATOR & REGULATOR SWITCH

Check for correct connections on fully charged battery, generator and starter motor. Check for good ground connection between engine and body. Check for properly tightened drive belt. Connect DIS tester. Search down through the following menus

  1. FUNCTION SELECTION
  2. COMPLETE VEHICLE
  3. DRIVE
  4. VOLTAGE AND CURRENT REGULATION
  5. VOLTAGE AND CURRENT GENERATION

Work through test modules. To diagnose oscillograms for each fault, see

. If generator is faulty, repair or replace it. To replace, see

under REMOVAL & INSTALLATION.

FaultOscillogram
Fault-Free(Scheme 1)
One Phase Interrupted(Scheme 2)
Internal Fault(Scheme 3)
Open Circuit In Negative Diode(Scheme 4)
Short Circuit In Positive Diode(Scheme 5)
Open Circuit In Positive Diode(Scheme 6)
Open Circuit In Exciter Diode(Scheme 7)

GENERATOR OSCILLOGRAMS

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

CHECKING GENERATOR

Note. Generator with BSD interface can communicate with engine control unit (DME/DDE). Generator is not connected to charge telltale light. Generator can identify various faults.

Note. BSD generator can be recognized by plug connection on generator.

  1. Check for correct corrections on charged battery, generator and starter motor. Make sure of good ground connection between engine and body. Make sure of good tension on ribbed V-belt.
  2. Read out DME/DDE fault memory.
  3. Connect diagnosis tester. Search menus in the following order: FUNCTION SELECTION COMPLETE VEHICLE DRIVE VOLTAGE AND CURRENT REGULATION VOLTAGE AND CURRENT GENERATION Follow instructions in diagnostic program. To diagnose oscillograms for each fault, see «GENERATOR OSCILLOGRAMS»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators) . If generator is faulty, repair or replace it. To replace, see «GENERATOR»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators) under REMOVAL & INSTALLATION.

REMOVAL & INSTALLATION

CAUTIONDisconnecting vehicle battery will cancel fault codes of control units. On vehicles with radio codes, after disconnecting battery, radio codes must be re-entered. Obtain radio code card from customer. Note stored stations and restore then after connecting battery. Also, where applicable, initialize sunroof and set steering angle.

A/C COMPRESSOR DRIVE BELT

Note. If drive belt is to be reused, mark direction of travel and reinstall drive belt in same direction.

  1. If necessary, remove splash guard. On models with hydraulic drive belt and tension jack, remove dust cab, push back belt tensioner at bolt connection of guide pulley and remove drive belt. (Scheme 8) On models with mechanical drive belt and tension jack, press back drive belt tensioner at hexagon head or Torx socket and remove drive belt. (Scheme 9)
  2. Check drive belt for coolant and oil residues. Replace if necessary. To install, reverse removal procedure. Make sure belt is correctly positioned on belt pulleys.

Scheme 8

Scheme 8

Scheme 9

Scheme 9
CAUTIONDisconnecting vehicle battery will cancel fault codes of control units. On vehicles with radio codes, after disconnecting battery, radio codes must be re-entered. Obtain radio code card from customer. Note stored stations and restore them after connecting battery. Also, where applicable, initialize sunroof and set steering angle.

Removal

  1. Retrieve fault codes. Turn off ignition. Disconnect and cover battery negative terminal.
  2. Remove intake filter housing. See «INTAKE FILTER HOUSING»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators). Remove generator drive belt. See «GENERATOR DRIVE BELT»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators__generator-drive-belt).
  3. Disconnect plug connection (1). (Scheme 10) Remove nut (2) and disconnect wire from battery positive lead.
  4. Remove cover from idler pulley (1). (Scheme 11) Remove screw and remove idler pulley (1). Remove screw and remove generator (2).

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Installation

  1. To install, reverse removal procedure. Turning lock of tensioning roller must engage in generator groove. (Scheme 12)
  2. Tighten wire from battery positive lead to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators__torque-specifications).
  3. Interrogate fault memory of DME control unit. Clear fault memory.

Scheme 12

Scheme 12
  1. Depending on generator type, grip shaft with the following: Hexagon Socket Multi-Tooth Socket Torx Socket Wrench Remove nut with Special Tool (12 7 110). (Scheme 13)
  2. To install, reverse removal procedure. Tighten nut to specification. See «TORQUE SPECIFICATIONS»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators__torque-specifications).

Scheme 13

Scheme 13

GENERATOR DRIVE BELT

Note. If drive belt is to be reused, mark direction of travel and reinstall drive belt in same direction.

  1. Remove fan clutch with fan impeller.
  2. Remove A/C compressor drive belt. See «A/C COMPRESSOR DRIVE BELT»(/bmw/x3/e83-2003-2006/remont/charging-system/#generators-regulators__ac-compressor-drive-belt).
  3. Remove cap from tensioning roller. (Scheme 14)
  4. Relieve tension on belt drive. (Scheme 15) Remove drive belt.
  5. Check drive belt for coolant and oil residues. Replace if necessary.
  6. To install, reverse removal procedure. Check that belt is correctly positioned on belt pulleys. (Scheme 16) For version with auxiliary tensioning roller (Scheme 17) Locking device of auxiliary tensioning roller must snap into groove on generator. (Scheme 18)

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18
  1. Turn off ignition. Open clips (1). (Scheme 19) Open retainers (2) on air-mass flow sensor. Remove top section (3) of intake air filter housing.
  2. Unfasten screws and remove intake filter housing (1). (Scheme 20)
  3. To install, reverse removal procedure. Install guide rail (1) on intake filter housing on rubber mount (2). (Scheme 21)

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Pulley33 (45)
Pulley (Ribbed Drive Belt)52 (70)
INCH Lbs. (N.m)
Wires-To-Generator Nuts115 (13)

TORQUE SPECIFICATIONS

Scheme 22

Scheme 22: WIRING DIAGRAMS
