Heating and Air Conditioning - Special Tools BMW X3 E83

0496300 645127 Adapter MW

Note. (Evaporator test adapter) E85, E86 [released]

SI number

01 04 08 (435)

Scheme 114

0496087 645107 Adapter MW

Note. (Sealing adapter) For closing off the line for the leakage test for E81, E87, E90, E91, E92, E93 (included in delivery from 02/2007) [discontinued]

01 09 07 (360)

Scheme 115

0493317 645101 Adapter MW

Replaced by: 0495257

Note. (Filling adapter) Is replaced by 64 5 105 (from 01/2005) Replaced by 64 5 105 (0 495 257) [Replaced]

Scheme 116

0496182 645108 Adapter MW

Note. (Seal adapter) For closing off the line during the evaporator leakage test on the E70 (included in the delivery specification from 02/2007) [Discontinued]

01 09 07 (360)

Scheme 117

0496259 645124 Adapter MW

Note. (Evaporator test adapter) PL2, formerly 64 5 107 [released]

01 04 08 (435)

Scheme 118

0493319 645103 Adapter MW

Note. (Sealing adapter) For closing the suction connection on the compressor [Discontinued]

Scheme 119

0496260 645125 Adapter MW

Note. (Evaporator test adapter) E46, E83, E70, R55, R56 (formerly 64 5 108) [Released]

Scheme 120

0493318 645102 Adapter MW

Note. (Seal adapter) For closing off the intake pipe [Discontinued]

Scheme 121

0496224 645122 Adapter MW

Note. (A/C condenser test adapter) [Released]

01 04 08 (435)

Scheme 122

0493900 641457 Adapter MW

Note. Series: E46 integrated automatic heating / air conditioning system / R Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 123

0495257 645105 Adapter MW

Note. (Filling adapter) For closing off the pressure line and connection to connecting hose (has replaced special tool 64 5 101 since 01/2005) [Discontinued]

Scheme 124

0493150 645100 Adapter MW

Note. (Sealing adapter set) For closing off the line flange of air conditioning components (evaporator, capacitor, compressor) during a leak test. Special tool 64 5 101 replaced by 64 5 105 (from 01/2005). [Discontinued]

01 17 98 (359)

Consisting of

0495257

0495258

0496087

0496182

0493317

0493318

0493319

0493320

Scheme 125

0495258 645106 Adapter MW

Note. (Sealing adapter) Sealing adapter for closing off the line for the leakage test (included in delivery specification from 01/2005) [Discontinued]

Scheme 126

0496299 645126 Adapter MW

Note. (Evaporator test adapter) E60, E61, E63, E64 [Released]

01 04 08 (435)

Scheme 127

0496222 645120 Adapter Minimum set: Mechanical tools MW

Note. (Test adapter set A/C components) [Released]

01 04 08 (435)

Consisting of

0496223

0496224

0496258

0496259

0496260

0496299

0496300

Scheme 128

0493065 641150 Device MW

Note. For drill out of heating discs. Other: Canada, Japan and USA only [discontinued]

image not available

0493896 641453 Drill bit MW

Note. (Quick-helix drill) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 129

0493898 641455 Gauge MW

Note. (Positioning) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 130

0493897 641454 Guide MW

Note. Series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 131

0493681 641020 Hook Minimum set: Mechanical tools MW

Note. (release hook) For releasing and removing fresh air grille. For removing various covers. [Released]

Storage Location

A3

B3

01 15 99 (483)

Scheme 132

0496223 645121 Hose MW

Note. (Connection hose with clamp) [released]

01 04 08 (435)

Scheme 133

0493320 645104 Hose MW

Note. (Connecting hose) For connecting the pressure cylinder to the filler adapter [Discontinued]

Scheme 134

0496258 645123 Plug MW

Note. (Air conditioning condenser seal plug) [released]

01 04 08 (435)

Scheme 135

0493901 641458 Plug MW

Note. (Seal plug) Model series: E46 integrated automatic heating / air conditioning system / R Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 136

0493899 641456 Screw MW

Note. (Mounting bolt) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 137

0493893 641450 Spray lance MW

Note. (Sprayer) For cleaning and disinfecting the air conditioning evaporator [Released]

01 22 00 (648)

Consisting of

Scheme 138

1. = 0493894 Spray lance NOTE: Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
2. = 0493895 Template NOTE: (Drilling template) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
3. = 0493896 Drill bit NOTE: (Quick-helix drill) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
4. = 0493897 Guide NOTE: Series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
5. = 0493898 Gauge NOTE: (Positioning) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
6. = 0493899 Screw NOTE: (Mounting bolt) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
7. = 0493900 Adapter NOTE: Series: E46 integrated automatic heating / air conditioning system / R Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]
8. = 0493901 Plug NOTE: (Seal plug) Model series: E46 integrated automatic heating / air conditioning system / R Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

0493894 641451 Spray lance MW

Note. Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 139

0493895 641452 Template MW

Note. (Drilling template) Model series: E39, E53 IHKA Remaining inventories will be sold off, followed by discontinuation and then no longer available individually but as part of complete tool set 64 1 450 = 0493893 only. [Discontinued]

Scheme 140
