Complete Vehicle - Overview - 6-series (e63/e64) BMW M6 E63/E64

501, 502 And 503

1951 saw the launch of the BMW 501, known in popular parlance as the "baroque angel." The 502 with V8 engine arrived in 1954. In the same year, the 501 and 502 Coupes were fashioned from these Saloons.

In 1955 BMW made its debut on the international stage in Frankfurt with the 503 Coupe. A V8 engine and every conceivable luxury available at the time such as leather upholstery and power windows established it as a luxury toy for the super-rich. 276 of these 503 Coupes costing roughly 30,000 marks each had been built by 1959.

Scheme 161

In 1961 the famous Italian body stylist Nuccio Bertone was commissioned to design a new BMW V8 Coupe. Clear, smooth lines exuded elegant dynamics. By 1965 Bertone had delivered 603 bodies to BMW, where they were completed - in accordance with individual customer requirements - to create the 3200 CS.

Scheme 162

2000 CS To 3.0 CSi

In mid-1965 BMW presented a new, not quite so selectively targeted Coupe based on the successful new 4-cylinder Saloons. The BMW designers had discovered a new BMW line: compact, sportily elegant and above all distinctive.

Scheme 163

E9

Three years later this 2000 CS Coupe was completely redesigned and equipped with a 6-cylinder engine. The range now stretched from the 2800 CS through to the 3.0 CSi Coupe. The E9 Coupe utilized the technology and engineering of the new top-class 2500 and 2800 Saloons but was closely allied to the 2000 CS in terms of form and shape.

Scheme 164

This Coupe with a 2.5 to 3-liter engine created a stir not only on the boulevards but also on the racetrack. In the guise of the 3.0 CSL lightweight Coupe, these racers with up to 900 bhp under the bonnet and Hans-Joachim Stuck, Brian Redman or Ronnie Petersson behind the wheel ran the competition of Porsche and Ford into the ground.

A total of 44,237 of the 2000 CS and E9 were built in a period of 11 years.

E24

The first BMW Coupe to be called a 6 Series came onto the market in 1976. The oil crisis and burgeoning environmental awareness brought a halt to the rushed explosion of power. But even with an engine developing from 185 to 286 bhp (M version), this Coupe was in no way underpowered.

Scheme 165

Comfort and engine and chassis electronics made the 6 Series a huge international success. By the time production was terminated in 1989, a total of 86,199 had been sold in a period of 14 years: Never before had a BMW Coupe been so successful.

E31

BMW ensured its place in automobile history with the introduction in 1989 of the 8 Series Coupe. Two years after the market launch of the first German 12-cylinder engine since the 1930s in the 750i, this power plant was transplanted into an absolute luxury class Coupe. The latest in engineering, technology and design which BMW was able to offer was just what was needed.

With an 8-cylinder version also introduced later, it was always possible to reach 250 km/h effortlessly (cut-off) whenever one wanted. But what this car also uniquely offered was the sheer pleasure of smooth driving with the reassurance of optimum safety. A total of 31,283 E31 models were built over a period of 10 years.

Scheme 166

E63 Introduction

All the significant innovations of the E65 or E60 are also offered in the 6 Series Coupe. However the E63 also offers new features of its own. The most important of these new features are

Scheme 167

1. Body of composite construction. Doors made of aluminum, hood made of bonded aluminum, side panels made of thermoplastic and trunk lid made of SMC plastic extend far beyond the GRAV (reduced weight aluminum front end) of steel and aluminum already established in the E60.
2. "Panorama" glass sunroof with a comparatively huge surface, whose floating roofliner comes in two parts so that when opened it can be accommodated under the remaining area of the steel roof in front of the rear window. Additional new features introduced on the E63 will migrate to other models.
3. "CCC" Car Communication Computer is the central control unit for all Information/communication systems in the E63
4. "HUD" Head up Display
5. New DWA with improved sensor capability
6. Knee air bags

Scheme 168

Scheme 169

Dimension Comparison

DIMENSION COMPARISON CHART

Aluminum Doors

The E63 has aluminum doors. This feature reduces the weight of the car by 10 kg.

The E63's aluminum doors exceed all internal BMW rigidity and safety requirements. Each door has two reinforcement members with door hooks arranged in a V-shape.

Scheme 170

Hood

As in the E60, the E63's hood is made of aluminum.

However, a new manufacturing process is used. For the first time in a BMW vehicle, the inner and outer skin panels of the bonnet are joined with a 2-component adhesive as an underlining. This turns the two skin panels into a single structural unit.

This manufacturing procedure helps to keep both aluminum skin panels thin, a factor which reduces the bonnet weight by 12 kg. Even the acoustic behavior is improved. The increased rigidity prevents the bonnet from vibrating almost completely at high speeds. This vibration is normally absorbed without being noticed and can disturb the driver's concentration while driving.

The hood of the E63 can be moved into a service position. A special tool is needed for this purpose.

The gap dimensions to the side panel and to the bumper are adjusted via elongated holes. These elongated holes are situated on the hinges and on the bonnet lock.

Front Fenders

For the first time in a vehicle built by the BMW Group, a thermoplastic (in this instance "Noryl GTX" from GE Plastics) has been used for the large-scale manufacture of a side panel.

The decision to use a thermoplastic was made for 3 primary reasons

Scheme 171

1. The E63 as a luxury-class car should be distinct in terms of design from the E60 mass-produced model. However, the level of remodeling required for this purpose cannot be accomplished in steel or aluminum and the same argument applies to integrating the direction indicator and the chrome trim bar in the side panel.
2. The weight-reducing potential of thermoplastic is 50% compared with a side panel made of sheet steel; in this particular case 2 kg per side panel of thermoplastic as against 4 kg per side panel of sheet steel.
3. Increased buckling resistance as the primary customer benefit for reducing minor damage and the corrosion-resistant properties of the material.
4. Because plastic expands or contracts in direct response to the outside temperature, the side panel is mounted in a "floating" manner. This means that the front side panels are attached in such a way as to allow the material to expand or contract without incurring damage. The connection to the body is established by means of 3 screw connections on the A pillar, 2 screwing points in the sill area and 8 screwing points on the reduced-weight aluminum front end (GRAV). To allow linear expansion as a function of the climatic conditions, the screwing points on the GRAV are designed to be "floating." A maximum linear expansion of 2.5 mm is possible in the vehicle longitudinal direction; in the event of further expansion, the side panel assumes a block setting.

Trunk Lid

This trunk lid made of SMC (Sheet Moulding Compound) saves approx. 25% weight compared with a corresponding component made of steel.

The trunk lid of the E63 incorporates the aerials for the telephone and the navigation system. This is also an E63 innovation.

Like the thermoplastic front side panels, the SMC trunk lid can also expand slightly under the effects of heat. It is therefore extremely important for the lid to be correctly adjusted.

Surface damage in the form of scratches can be repaired with the BMW repair spatula kit. In the event of fractures or cracks, the complete component must be replaced.

Scheme 172

Panorama Sunroof

The panorama glass sunroof comprises a glass roof, a two-part floating roofliner, two electric motors and the casing housing the mechanism.

The system is controlled by means of a switch and a control unit which is mounted behind the glovebox. The front electric motor moves the glass roof. The glass roof can only be tilted and cannot be opened fully. The rear electric motor moves the two-part floating roofliner. The roofliner in the E63 is in two parts as there would not be enough space between the rear edge of the sunroof and the front edge of the rear window for a single undivided component.

Both the glass roof and the roofliner have anti-trapping protection.

Scheme 173

Scheme 174

The 6 Series E64 Convertible is based on the E63 Coupe. External dimensions for the Convertible are the same as the Coupe. Trunk volume is reduced from 450 L to 350 L (with the top up) and 300 L (with the top down).

Empty weight is increased by 200kg, to 1815kg.

Scheme 175

Convertible Body

The E64 body has been reinforced in the following areas

Scheme 176

1. The A pillar has increased support at the base.
2. The windshield frame is made from high-strength steel.
3. Additional aluminum extruded bracing is added to the doors.
4. The sill rail and crashbox are made from high-strength steel.
5. The seat cross member was strengthened; additional bracing has been added for side impact protection.
6. The crossmember in the back seat floor area is strengthened.
7. The rear seat back area was strengthen and braced for the additional roll over protection.
8. The rear decklid construction is the same as the E63, however the shape and overall size of the decklid is smaller.
9. The soft top boot is also constructed with SMC.
10. Roll down rear quarter windows have been added.
11. E46 Style Convertible seats with integral seat belts are used.
