34 1 050 Fixture
Note: For turning back brake piston when fitting new brake pads, disc brakes front and rear
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E86, E87, E90, E91, E92, E93, RR2
Order number: 34 1 050
Fixture
Scheme 112
34 1 080 Bit insert
Minimum set: Mechanical tools
In conjunction with: Tool holder for 5/16" bit
Note: For loosening and tightening brake caliper bolts
Series: E31, E36, E38, E38/3, E39, E52, E53, E60, E61, E63, E64, E65, E66, E67, RR2
Storage location: B46
SI number: 1 15 99 (483)
Order number: 34 1 080
Bit insert
Scheme 113
34 1 090 Steel wire brush
Note: (1 set = 3 x) For cleaning brake pad guides
Series: All models
SI number: 1 12 00(595)
Order number: 34 1 090
Steel wire brush
Consisting of
1 = 34 1 091 Cleaning brush
Note: (1 x)
Scheme 114
34 1 130 Installation sleeves
Minimum set: Mechanical tools
Note: For mounting dust caps on brake piston
Series: E39, E52, E53, E60, E61, E63, E64, E65, E66, E67
Storage location: A35
SI number: 1 01 97 (173)
Order number: 34 1 130
Installation sleeves
Consisting of
34 1 132 Press-in sleeve
Note: Diameter 58 mm for rear dust cap - Series: E52, E53, E60, E65, E66, E67
34 1 133 Sleeve
Note: For installing dust sleeve on floating caliper of front axle - Series: E53, E65, E60, E66, E67
Scheme 115
34 1 260 Brake lining measuring gauge
Minimum set: Mechanical tools
Note: For measuring brake lining thickness without removing wheels.
Series: E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R56
SI number: 1 12 95 (992)
Order number: 34 1 260
Brake lining measuring gauge
Scheme 116
34 1 280 Sliding caliper
Note: For measuring brake disk thickness.
Series: E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E65, E66, E67, E83, E85, E87, E90, E91, RR2
Order number: 34 1 280
Sliding caliper
Scheme 117
34 3 100 Brake booster tester
Note: For testing vacuum of brake booster
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, R50, R52, R53
Storage location: A15, B15
Order number: 34 3 100
Brake booster tester
Scheme 118
34 3 170 Set of socket wrenches
Minimum set: Mechanical tools
Note: With torque wrench for releasing and tightening union nut on brake line
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E60, E61, E63, E64, E86, E90, RR2
Storage location: C1
SI number: 1 05 95 (932)
Order number: 34 3 170
Set of socket wrenches
Consisting of
1 = 34 3 171 Socket wrench WAF 11
2 = 34 3 172 Socket wrench WAF 12
Scheme 119
34 4 000 Allen key
Note: For removing and installing handbrake shoe retaining spring as well as ABS pulse generator
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
Storage location: A19
Order number: 34 4 000
Allen key
Scheme 120
34 5 100 Bending fixture
Note: For brake lines
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E60, E61, E63, E64, E65, E66, E67, E83, E85, E86, E87, E90, E91, E92, E93
Storage location: A28
Order number: 34 5 100
Bending fixture
Scheme 121
34 6 320 Lever
Minimum set: Mechanical tools
Note: For compressing brake piston on front axle
Series: E38, E52, E60, E61, E63, E64, E65, E66, E67
Storage location: A45, B45
SI number: 1 14 01(766)
Order number: 34 6 320
Lever
