Fuel System - Repair BMW M6 E63/E64

13 31...NOTES ON FUEL PRESSURE CHECK (REFERENCE PRESSURE: ENVIRONMENT)

Feature of this version with ambient pressure

The connection for the vacuum hose of the fuel pressure regulator is located between the throttle and the air cleaner or on the air cleaner.

Test precondition

The correct fuel pressure regulator is fitted.

1. Using the EPC, check whether the fuel pressure regulator suitable for the car is fitted: Connect test adapter.

Description of operation

The control function of the fuel pressure regulator must be guaranteed under all operating conditions. The fuel pump must always be able to generate a higher fuel pressure than the pressure regulated by the pressure regulator.

The injection rate is adjusted by means of the injection time; the injection time is controlled by the DME.

Description of operation: fuel return line

When the engine is at a standstill and the ignition key is in position 0, the fuel return line after the pressure regulator is at zero pressure.

Description of operation: pressure retaining function

The pressure regulator closes when the engine is at a standstill and the ignition key is in position 0. The fuel pressure in the delivery line is retained over an extended period. A non-return valve closes in the fuel pump. These measures help to retain the fuel pressure in the fuel system. Extended starting times are thus avoided.

Complaint: drive characteristic faults, lack of power

1. Run engine at idle speed and measure fuel pressure.

If the measured value is less than the nominal value - 0.2 bar

1. Line cross-sections in fuel feed are constricted or fuel filter is clogged, or
2. Fuel pump voltage supply is not O.K.: e.g. as a result of high contact resistance (corrosion) in plug connection between wiring harness and fuel pump.

If the measured value is greater than the nominal value + 0.2 bar

1. Turn off engine stop and then observe measured value.
2. If measured value drops to nominal value, then line cross-sections in fuel return are constricted or clogged.
3. Check the fuel lines for kinks.

If no kinks are visible

1. Replace return lines

If measured value remains too high, then pressure regulator is in all probability faulty.

1. Have a cleaning cloth ready and catch and dispose of escaping fuel.
2. Replace the return line but not the pressure regulator.

Complaint: starting problems

1. Run engine briefly at idle speed and switch off.
2. Note down measured value while engine is stopped.
3. Read off measured value again after approx. 20 to 30 minutes while engine is stopped.

Special tool 13 3 010 (hose clamp) is required for the following test.

If the measured value has dropped by more than 0.5 bar

1. Start engine and wait briefly for a stable pressure increase.
2. Switch off the engine and immediately pinch off the delivery line just before the pressure gauge with the special tool 13 3 010.
3. Note down measured value
4. Read off measured value again after approx. 20 to 30 minutes while engine is stopped

If the measured value has now dropped by less than 0.5 bar, the following faults can be present

1. Fault in delivery lines
2. Fault in in-tank delivery hose
3. Faulty pressure-holding non-return valve in fuel pump Check components. Replace faulty components.

If the measured value has dropped by more than 0.5 bar again

1. Replace pressure regulator

Note. All the fuel hoses and hose clips which were detached within the framework of the checks must be replaced. Interrogate fault memory of DME control unit. Check stored fault messages. Rectify faults. Now clear the fault memory.

13 31 029 CHECK FUEL INITIAL PRESSURE (S85)

Special tools required

1. 13 3 060
2. 13 5 270

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules.
2. Switch off ignition.

Note. Recycling: Catch and dispose of escaping fuel in a suitable container. Observe country-specific waste-disposal regulations.

Release quick-release fastener on fuel feed line. Connect special tool 13 5 270 between fuel feed line (2). Connect pressure sensor (3) of BMW diagnosis and information system. Or connect special tool 13 3 060.

Scheme 91

Measuring fuel pressure

1. Connect pressure sensor to DIS tester.
2. Connect DIS tester to vehicle.
3. Select Drive.
4. Select Engine electronics.
5. Select Fuel supply.
6. Select Fuel pressure sensor.
7. Read off fuel pressure.

Note. The vehicle has different fuel pressures when starting and when idling.

Test pressure, refer to Technical Data.

Switch off engine.

Assemble vehicle and check fuel system for leaks.

13 41 555 REPLACING BOTH IDLE SPEED ACTUATORS (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit
2. Check stored fault messages
3. Switch off ignition
4. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Scheme 92

Release bolt on cable duct (1).

Release nut on cable duct (1).

Tighten to specified torque, see 12 52 3AZ in 52 CONNECTORS, PLUGS .

Unlock plug in V-chamber and disconnect, lay cable duct (1) to one side.

Scheme 93

Release clamp (1) and detach hose from idle speed actuator (2).

Tighten to specified torque, see 13 41 2AZ in 41 STARTER WITH MOUNTING

Unscrew nuts.

Tighten to specified torque, see 13 41 1AZ in 41 STARTER WITH MOUNTING .

Pull idle speed actuator (2) in direction of arrow out of cylinder head.

Scheme 94

Installation

Replace sealing ring (1).

Scheme 95

Note. Now clear the fault memory.

13 53 240 REPLACING COMPLETE INJECTION PIPE (S85)

Special tools required

1. 13 5 281

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules.
2. Switch off ignition.
3. Remove fresh air duct. See «64 31 053 REMOVING AND INSTALLING OR REPLACING FRESH AIR DUCT»(/bmw/m6/e63e64-2005-2010/remont/automatic-hvac-system/#heating-and-air-conditioning-repair__64-31-053-removing-and-installing) .
4. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
5. Remove ignition coil covers.
6. Release cable duct in V-chamber, unlock plug connections and disconnect, lay cable duct to one side.

Recycling

Fuel escapes when fuel line is detached. Catch and dispose of escaping fuel.

Observe country-specific waste-disposal regulations.

Slacken bolts (1)

Unlock and detach fuel line (2).

Unfasten screws.

Unlock plugs on fuel injectors and disconnect.

Remove both injection pipes (3).

Scheme 96

Seal fuel hose with special tool 13 5 281.

Scheme 97

Lever out retainers (1).

Pull fuel injectors out of injection pipe.

Installation

Replace sealing rings on fuel injectors and coat with anti-friction agent.

Scheme 98

Note. Now clear the fault memory.

13 54 010 PERFORMING THROTTLE VALVE BASIC SETTING (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit.
2. Switch off ignition.
3. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Scheme 99

Checking throttle valve basic setting

To ensure that the throttle valve basic setting at the 10th throttle valve assembly can be properly checked, it is necessary to remove cover (2).

Unclip lines (1).

Release bolts and remove cover (2).

Tighten to specified torque, see 13 54 2AZ in 13 54 THROTTLE AND ACTUATOR .

Scheme 100

Gap between stop screw (1) and actuator (2) of throttle valve must be less than 0.05 mm.

To check gap, use a feeler gauge with a thickness of 0.05 mm. Checking gap

1. Pull rod of throttle valve actuator in opening direction of throttle valves.
2. Slide feeler gauge (3) between stop screw (1) and actuator (2) of throttle valve.
3. Return throttle valves slowly to stops.

When correctly adjusted, feeler gauge will jam between stop screw (1) and actuator (2) of throttle valve.

Perform check on each throttle valve assembly.

Performing throttle valve basic setting

A basic setting must be performed if the gap is larger than 0.05 mm at one or more throttle valve assemblies.

Scheme 101

Note. In order to ensure correct throttle valve setting, you must slacken all the screw connections on the actuating levers with the actuating shaft except at throttle valve assemblies 5 and 6. (Replace nuts).

It is not possible to set the throttle valve at throttle valve assemblies 5 and 6.

However, if increased play is ascertained, the corresponding cylinder bank must be reset.

The actuating levers of throttle valve assemblies 5 and 6 are connected to the actuating shaft via fitting screws and fitting bores.

Do not slacken the screw connections of the actuating levers for the long pull rods.

The long pull rods must not be disengaged from the actuating levers for the setting procedure.

To slacken screw connection of actuating lever (1), grip screw (3) and release nut (2). (Replace nuts).

Release screw connections of actuating levers of throttle valve assemblies 1-4 and 7-10.

Scheme 102

Scheme 103

Adjusting a throttle valve assembly

Move actuating lever (1) in direction of arrow, i.e. "close throttle valve", until actuator (2) of throttle valve rests without play on stop screw (3).

Scheme 104

Tighten down screw connection of actuating lever (1) again to actuating shaft. Observe the following instructions in so doing

1. Use nuts only once.
2. When pretightening screw connection (approx. 5 Nm), hold actuating lever (1) of throttle valve in direction of arrow at "close throttle valve".
3. Only turn nut and grip screw.
4. To screw down, use two open-end wrenches which are to be placed at right angles to actuating shaft.
5. In this way, no lever action is exerted on the throttle valve linkage; such torque would impair the quality of adjustment.
6. After pretightening actuating lever, actuate throttle valve several times at full load.

Note. If necessary, carry out adjustment with a second person.

Adjusting throttle valve assemblies 1-4 and 7-10

The previously described procedure applies to adjusting/setting throttle valve assemblies 1-4 and 7 -10.

Adjust throttle valve assemblies 1-4 and 7 -10 in sequence.

After successfully completing throttle valve basic setting and checking, tighten down all screw connections of throttle valve levers to specified torque, see 13 54 1AZ in 13 54 THROTTLE AND ACTUATOR .

Scheme 105

Note. After completing adjustment, it is necessary to check the throttle valve basic setting! If during the checking of one or more throttle valve assemblies excessively large or small play is ascertained, it will be necessary to perform the throttle valve basic setting again!

Note. Check stored fault messages. Then clear fault memory.

13 54 030 REMOVING AND INSTALLING/SEALING THROTTLE VALVE ASSEMBLY (S54)

Special tools required

1. 34 3 171

Necessary preliminary tasks

1. Read out fault memory of DME control unit.
2. Switch off ignition.
3. Follow instructions for disconnecting and connecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) and cover.
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Removing throttle valve assemblies 6-10

Release screws and detach injection pipe (1) from throttle valve assemblies.

Remove pull rod (2).

Unlock plug (3) and remove.

Scheme 106

Unclip lines (1).

Release bolts and remove cover (2).

Tightening to specified torque, see 13 54 2AZ in 13 54 THROTTLE AND ACTUATOR .

Release nuts with special tool 34 3 171.

Remove throttle valve assemblies 6-10.

Scheme 107

Removing throttle valve assemblies 1-5

Release screws and detach injection pipe (1) from throttle valve assemblies.

Remove pull rod (2).

Scheme 108

Unlock plug (1) and remove.

Release wiring harness from retaining clip (2).

Release nut (3) and disconnect starter positive lead.

Tightening to specified torque, see 12 52 2AZ in 52 CONNECTORS, PLUGS .

Unfasten nut.

Carefully raise cable duct (4) slightly.

Scheme 109

Release nuts with special tool 34 3 171.

Remove throttle valve assemblies 1-5.

Scheme 110

Installation

Clean sealing surfaces (1). Note correct position of adapter sleeves (2).

Note. For a better overview, only a removed throttle valve assembly is shown.

Scheme 111

Installation

Clean sealing surfaces on cylinder head.

Replace all O-rings (1) in cylinder head.

Scheme 112

Note. Perform basic throttle valve setting.

13 54 045 REMOVING AND INSTALLING/SEALING A THROTTLE VALVE ASSEMBLY (S85)

Special tools required

1. 34 3 171

Necessary preliminary tasks

1. Read out fault memory of DME control unit
2. Switch off ignition
3. Follow instructions on connecting and disconnecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) and cover.
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Removing throttle valve assembly 6

Unfasten screws. Disconnect injection pipe (1) from throttle valve assembly.

Remove pull rod (2).

Unlock plug (3) and remove.

Unclip lines (1).

Release bolts and remove cover (2).

Tightening to specified torque, see 13 54 2AZ in 13 54 THROTTLE AND ACTUATOR .

Release screw (1).

Release screw connections (2) of actuating levers. Grip screw and turn nut in the process.

Remove screws from bores.

Installation

1. Use screws and nuts only once.
2. Only turn nuts and grip screws.
3. Tightening to specified torque, see 13 54 1AZ in «13 54 THROTTLE AND ACTUATOR»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-tightening-torques__13-54-throttle-and-actuator) .

Unclip pull rod (3) from actuating lever.

Slide actuating shaft (5) in direction of arrow.

Release nuts (4) with special tool 34 3 171 and remove throttle valve assembly (6).

Installation

Clean sealing surface (1). Note correct position of adapter sleeves (2).

Scheme 113

Installation

Clean sealing face on cylinder head.

Replace O-ring (1) on cylinder head.

Note. Perform basic throttle valve setting

Removing throttle valve assembly 5

Procedure is described in the repair instruction "Removing right Hall sensor".

Removing throttle valve assemblies 1-4 and 7-10

Necessary preliminary tasks

Remove throttle valve assembly

Removing throttle valve assembly 7

Release screw.

Tightening to specified torque, see 13 54 3AZ in 13 54 THROTTLE AND ACTUATOR .

Detach lock washer (1) from actuating shaft.

Release screw connections (2) of actuating levers. Grip screw and turn nut in the process.

Remove screws from bores.

Installation

1. Use screws and nuts only once.
2. Only turn nuts and grip screws.
3. Tightening to specified torque, see 13 54 1AZ in «13 54 THROTTLE AND ACTUATOR»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-tightening-torques__13-54-throttle-and-actuator) .

Unclip pull rod (3) from throttle valve assembly 7.

Detach throttle valve assemblies 6 and 7 with actuating lever from actuating shaft.

Scheme 114

Installation

Actuating lever (1) of throttle valve assembly 6 and actuating lever (2) of pull rod for throttle valve actuator are offset approx. 180° to each other.

Ball ends are turned to each other.

Scheme 115

Removing throttle valve assemblies 8, 9 and 10

Release screw connections (4) of actuating levers. Grip screw and turn nut in the process.

Remove screws from bores.

Installation

1. Use screws and nuts only once
2. Only turn nuts and grip screws.
3. Do not tighten down nuts yet.

Pull throttle valve assemblies 8, 9 and 10 as required in sequence with actuating lever from actuating shaft.

Removing throttle valve assembly 4

Release screw.

Tightening to specified torque, see 13 54 3AZ in 13 54 THROTTLE AND ACTUATOR .

Detach lock washer (1) from actuating shaft.

Release screw connection (2) of actuating shaft. Grip screw and turn nut in the process.

Remove screw from bore.

Installation

1. Use screw and nut only once.
2. Only turn nut and grip screw.
3. Tightening to specified torque, see 13 54 1AZ in «13 54 THROTTLE AND ACTUATOR»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-tightening-torques__13-54-throttle-and-actuator) .

Scheme 116

Unclip pull rod (3) from throttle valve assembly 4.

Detach throttle valve assemblies 5 and 4 with actuating lever from actuating shaft.

Removing throttle valve assemblies 1, 2 and 3

Release screw connections (4) of actuating levers. Grip screw and turn nut in the process.

Remove screws from bores.

Installation

1. Use screws and nuts only once.
2. Only turn nuts and grip screws.
3. Do not tighten down nuts yet.

Detach throttle valve assemblies 1, 2 and 3 as required in sequence with actuating lever from actuating shaft.

Installation

Actuating lever (1) of throttle valve assembly 3 and actuating lever (2) of pull rod for throttle valve actuator are offset approx. 180° to each other.

Ball ends are turned to each other.

Note. Perform throttle valve basic setting.

13 54 544 REMOVING AND INSTALLING/REPLACING LEFT HALL SENSOR (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit
2. Switch off ignition
3. Follow instructions for disconnecting and connecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) lead and cover
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Release nut and remove line (1).

Tighten to specified torque, see 12 52 2AZ in 52 CONNECTORS, PLUGS

Remove cover (2) from control unit for ionic current.

Unlock plug (3) and remove.

Scheme 117

Release screw and remove holder (1).

Release wiring harness from retaining clip (2).

Disconnect lead (3).

Scheme 118

Unlock plug (1) and remove.

Release screw and carefully raise cable duct (2).

Scheme 119

Release screws and detach Hall sensor (1) towards front.

Installation

Make sure Hall sensor is installed in correct position.

Scheme 120

Note. Check stored fault messages Clear fault memory

13 54 546 REMOVING AND INSTALLING/REPLACING RIGHT HALL SENSOR (S85)

Special tools required

1. 34 3 171

Necessary preliminary tasks

1. Read out fault memory of DME control unit
2. Switch off ignition
3. Follow instructions on connecting and disconnecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) and cover.
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Note. Hall sensor and throttle valve assembly 5 are removed together as a single unit. Release screws and disconnect injection pipe (1). Release screw connections (2) of actuating levers. Grip screw and turn nut in the process. Remove screws from bores.

Installation

1. Use screws and nuts only once.
2. Only turn nuts and grip screws.
3. Tighten to specified torque, see 13 41 3AZ in «41 STARTER WITH MOUNTING»(/bmw/m6/e63e64-2005-2010/remont/gauges-instrument-panels/#engine-electrical-system-tightening-torques) .

Unclip pull rods (3).

Scheme 121

Release screw.

Tightening to specified torque, see 13 54 3AZ in 13 54 THROTTLE AND ACTUATOR .

Slide actuating shaft (1) in direction of arrow towards front and turn through approx. 180°.

Release nuts (2) with special tool 34 3 171.

Scheme 122

Unlock plug (1) and remove.

Release wiring harness from retaining clip (2).

Release nut (3) and disconnect starter positive lead.

Tighten to specified torque, see 12 52 2AZ in 52 CONNECTORS, PLUGS

Unfasten nut.

Tighten to specified torque, see 12 52 3AZ in 52 CONNECTORS, PLUGS

Carefully raise cable duct (4) slightly and remove throttle valve assembly (5).

Release screws and detach Hall sensor (1) from throttle valve assembly.

Installation

Make sure Hall sensor is installed in correct position.

Scheme 123

Installation

Clean sealing surface (1). Note correct position of adapter sleeves (2).

Installation

Clean sealing face on cylinder head.

Replace O-ring (1) on cylinder head.

Note. Perform basic throttle valve setting.

13 62 531 REPLACING COOLANT TEMPERATURE SENSOR (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
4. Release cable duct in V-chamber, unlock plug connections and disconnect, slide cable duct to one side

Recycling

Catch and dispose of escaping coolant.

Observe country-specific waste-disposal regulations.

The coolant temperature sensor is located in the V-chamber on the right.

Release temperature sensor (1).

Installation

Tightening to specified torque, see 13 62 3AZ in 13 62 SENDERS FOR CONTROL UNIT .

If necessary, top up coolant.

Scheme 124

Note. Now clear the fault memory.

13 62 540 REMOVING AND INSTALLING/REPLACING THROTTLE VALVE SERVOMOTOR (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
4. Release positive lead on cable duct at front and rear
5. Remove cover for ion control unit on left and right
6. Remove cover for ignition coils on left and right

Release bolt on cable duct (1).

Release nut on cable duct (1).

Tighten to specified torque, see 12 52 3AZ in 52 CONNECTORS, PLUGS

Unlock plug in V-chamber and disconnect, lay cable duct (1) to one side.

Note. Illustration shows and description refers to the left throttle valve servomotor. The procedure is identical for the right filter housing.

Remove pull rod (1).

Unfasten screws.

Remove throttle valve servomotor (2).

Scheme 125

Note. Check stored fault messages. Now clear the fault memory.

13 62 560 REMOVING AND INSTALLING/REPLACING AIR-MASS FLOW SENSOR (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition

Note. Illustration shows and description refers to the left air-mass flow sensor. The procedure is identical for the right air-mass flow sensor.

Unlock plug (1) and remove.

Unfasten screws.

Pull air-mass flow sensor (2) out of intake filter housing.

Installation

Check sealing ring between air-mass flow sensor and intake filter housing for damage, replace if necessary.

Note. Check stored fault messages. Now clear the fault memory.

Scheme 126

13 62 601 REPLACING PULSE GENERATOR ON LEFT INLET CAMSHAFT (S85)

(cylinder bank 6 to 10)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove «left intake filter housing»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing)
4. Remove left ignition coil cover

Release plug connector (1) and pull off.

Release screw.

Remove pulse generator (2).

Installation

Replace sealing ring and coat with antiseize agent.

Scheme 127

Note. Now clear the fault memory.

13 62 602 REPLACING PULSE GENERATOR ON RIGHT INLET CAMSHAFT (S85)

(cylinder bank 1 to 6)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove «right intake filter housing»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing)
4. Remove right ignition coil cover

Release plug connector (1) and pull off.

Release screw.

Remove pulse generator (2).

Installation

Replace sealing ring and coat with antiseize agent.

Scheme 128

Note. Now clear the fault memory.

13 62 604 REPLACING PULSE GENERATOR ON LEFT EXHAUST CAMSHAFT (S85)

(cylinder bank 6 to 10)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove «left intake filter housing»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing)
4. Remove left ignition coil cover

Release plug connector (1) and pull off.

Release screw.

Remove pulse generator (2).

Installation

Replace sealing ring and coat with antiseize agent.

Scheme 129

Note. Now clear the fault memory.

13 62 605 REPLACING PULSE GENERATOR ON RIGHT EXHAUST CAMSHAFT (S85)

(cylinder bank 1 to 6)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove «right intake filter housing»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing)
4. Remove right ignition coil cover

Release plug connector (1) and pull off.

Release screw.

Remove pulse generator (2).

Installation

Replace sealing ring and coat with antiseize agent.

Scheme 130

Note. Now clear the fault memory.

13 62 610 REPLACING CRANKSHAFT SENSOR (S85)

Necessary preliminary tasks

1. Remove underbody protection
2. Remove right heat shields.

Unlock plug (1) and remove. Release screw (2). Remove crankshaft sensor.

Scheme 131

13 62 660 REPLACING LEFT OR RIGHT IONIC CURRENT CONTROL UNIT (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules
2. Switch off ignition
3. Remove «left intake filter housing»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) , «RIGHT INTAKE FILTER HOUSING)»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .

Note. Illustration shows and description refers to the left ionic current control unit. The procedure is identical for the right ionic current control unit.

Unfasten screws.

Remove cover (1).

Scheme 132

Release plug connector (1) and pull off.

Unfasten screws.

Remove ionic current control unit (2).

Scheme 133

Note. Now clear the fault memory.

13 64 541 REPLACING ALL FUEL INJECTORS

This is described in removing complete injection pipe .

Necessary preliminary tasks

1. Read out fault memory of DME control unit.
2. Switch off ignition.
3. Follow instructions for disconnecting and connecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) and cover.
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Release nut and remove line (1).

Tighten to specified torque, see 12 52 2AZ in 52 CONNECTORS, PLUGS .

Remove cover (2) from control unit for ionic current.

Unlock plug (3) and remove.

Release screw and remove holder (1).

Release wiring harness from retaining clip (2).

Disconnect lead (3).

Unlock plug (1) and remove.

Release screw and carefully raise cable duct (2).

Release screws and detach Hall sensor (1) towards front.

Installation

Make sure Hall sensor is installed in correct position.

Note. Check stored fault messages Clear fault memory

Special tools required

1. 34 3 171

Necessary preliminary tasks

1. Read out fault memory of DME control unit
2. Switch off ignition
3. Follow instructions on connecting and disconnecting battery. See «12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__12-00-instructions-for-disconnecting) .
4. Disconnect «BATTERY NEGATIVE LEAD»(ref-201427-S15912339152005102600000) and cover
5. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Note. Hall sensor and throttle valve assembly 5 are removed together as a single unit.

Release screws and disconnect injection pipe (1).

Release screw connections (2) of actuating levers. Grip screw and turn nut in the process.

Remove screws from bores.

Installation

1. Use screws and nuts only once.
2. Only turn nuts and grip screws.
3. Tighten to specified torque, see 13 41 3AZ in «41 STARTER WITH MOUNTING»(/bmw/m6/e63e64-2005-2010/remont/gauges-instrument-panels/#engine-electrical-system-tightening-torques) .

Unclip pull rods (3).

Release screw.

Tightening to specified torque, see 13 54 3AZ in 13 54 THROTTLE AND ACTUATOR .

Slide actuating shaft (1) in direction of arrow towards front and turn through approx. 180°.

Release nuts (2) with special tool 34 3 171.

Unlock plug (1) and remove.

Release wiring harness from retaining clip (2).

Release nut (3) and disconnect starter positive lead.

Tighten to specified torque, see 12 52 2AZ in 52 CONNECTORS, PLUGS

Unfasten nut.

Tighten to specified torque, see 12 52 3AZ in 52 CONNECTORS, PLUGS

Carefully raise cable duct (4) slightly and remove throttle valve assembly (5).

Release screws and detach Hall sensor (1) from throttle valve assembly.

Installation

Make sure Hall sensor is installed in correct position.

Installation

Clean sealing surface (1). Note correct position of adapter sleeves (2).

Installation

Clean sealing face on cylinder head.

Replace O-ring (1) on cylinder head.

Note. Perform basic throttle valve setting.

13 71 000 REMOVING AND INSTALLING LEFT INTAKE FILTER HOUSING (S85)

Necessary preliminary tasks

1. Switch off ignition

Unlock plug (1) and remove.

Release clamp (2).

Unclip lines (3).

Disengage coolant filler neck (4).

Open retainers.

Remove intake filter housing cover (5).

Remove air filter insert.

Scheme 134

Unscrew nut (1).

Release screw (2).

Unlock lug (3).

Remove intake filter housing (4) towards top.

Scheme 135

13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)

Necessary preliminary tasks

1. Switch off ignition

Unlock and detach vent hose (1).

Release clamp (2).

Unlock plug (3) and remove.

Open retainers.

Remove intake filter housing cover (4).

Scheme 136

Unscrew nuts.

Unlock lug (1).

Remove intake filter housing (2) towards top.

Scheme 137

13 72 002 REPLACING BOTH AIR CLEANER INSERTS (S85)

Necessary preliminary tasks

1. Switch off ignition.

Unlock plug (1) and remove.

Release clamp (2).

Unclip lines (3).

Disengage coolant filler neck (4).

Open retainers.

Remove intake filter housing cover (5).

Unlock and detach vent hose (1).

Release clamp (2).

Unlock plug (3) and remove.

Open retainers.

Remove intake filter housing cover (4).

Note. Illustrations show and descriptions refer to the left air filter element. The procedure is identical for the right filter housing. Remove air cleaner element (1).

Installation

Clean upper and lower sections of intake filter housing from inside.

Install new air cleaner element.

Scheme 138

13 90 500 REPLACING TANK VENTING VALVE (S85)

Necessary preliminary tasks

1. Read out fault memory of DME control unit; if necessary, work through test schedules.
2. Switch off ignition.
3. Remove intake air manifold. See «11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .

Note. The tank venting valve is fitted under the intake air manifold.

Note. Illustration shows and description refers to the left tank venting valve. The procedure is identical for the right tank venting valve.

Unlock plug (1) and remove.

Unlock hose (2) on tank venting valve and disconnect.

Release clamp (3), detach hose.

Release screw.

Remove tank venting valve (4).

Scheme 139

Note. Now clear the fault memory.

See also:
• 11 61 050 REMOVING AND INSTALLING AIR INTAKE MANIFOLD (S85)
• 52 CONNECTORS, PLUGS
• 64 31 053 REMOVING AND INSTALLING OR REPLACING FRESH AIR DUCT
• 13 54 THROTTLE AND ACTUATOR
• 12 00... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY
• 13 62 SENDERS FOR CONTROL UNIT
• left intake filter housing
• right intake filter housing
• removing complete injection pipe
