31 2 100 Fixture
Minimum set: Mechanical tools
Note: For detaching drive flange from all rear differentials
Series: E28, E30, E31, E32, E36, E36/7, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
Transmission: Rear diff. 188kom, rear diff. 220kom, rear diff. type G, rear diff. type K, rear diff. type M
Storage location: C7
Order number: 31 2 100
Fixture
Consisting of
1 = 31 2 101 Spindle
Note: All rear differentials
2 = 31 2 102 Frame
Note: All rear differentials
3 = 31 2 103 Pull-off plate
Note: Model series: E28
4 = 31 2 104 Pull-off plate
Note: Model series: E30 and all rear differentials
6 = 31 2 106 Thrust piece
Note: Model series: E31, E32, E36
Scheme 192
31 2 210 Socket wrench socket WAF 21
Minimum set: Mechanical tools
Note: For releasing shock absorber threaded connection (front axle with EDC)
Series: E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53
Storage location: C18
SI number: 1 06 94 (801)
Order number: 31 2 210
Socket wrench socket WAF 21
Scheme 193
31 2 220 Support plate
In conjunction with: 00 2 030 (not included in minimum kit)
Note: For supporting front axle and exhaust system during installation work
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, R50, R53, RR1
Storage location: B37
SI number: 1 06 94 (801)
Order number: 31 2 220
Support plate
Scheme 194
31 2 230 Socket
Minimum set: Mechanical tools
Note: For expanding steering knuckle during spring strut removal
Series: E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93
Storage location: C47
SI number: 1 05 03 (969)
Order number: 31 2 230
Socket
Scheme 195
31 3 030 Press-in and press-out tool
Minimum set: Mechanical tools
Note: For rubber bearings on trailing arm
Series: E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E87, E90, E91, E92, E93
Storage location: B46
SI number: 1 14 01 (766)
Order number: 31 3 030
Press-in and press-out tool
Consisting of
1 = 31 3 031 Thrust piece
2 = 31 3 032 Bushing
Scheme 196
31 3 140 Pin wrench
Note: For loosening and tightening McPherson strut threaded connection when replacing shock absorber
Model: 2002
Order number: 31 3 140
Pin wrench
Scheme 197
31 3 340 Spring tensioner
Minimum set: Mechanical tools
Note: For tensioning coil springs when removing and installing spring strut. Used only in conjunction with repair instructions.
Series: E31, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R56
Storage location: Single
SI number: 1 11 99 (438)
Order number: 31 3 340
Spring tensioner
Consisting of
1 = 31 3 341 Spring tensioner, individual
2 = 31 3 342 Replacement pin
Scheme 198
31 3 350 Spring holder
Minimum set: Mechanical tools
In conjunction with: 31 3 340 and 31 3 360
Note: For locating coil springs during tensioning. No. 31 3 350 reserved for consecutive sub-number spring tensioner 31 3 340.
Series: E31, E36, E36/7, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, R50, R52, R53, R56
Storage location: Single
SI number: 1 11 99 (438)
Order number: 31 3 350
Spring holder
Consisting of
1 = 31 3 351 Spring retainer (2 x)
Note: For use only with repair instructions
2 = 31 3 352 Spring retainer (2 x)
Note: For use only with repair instructions
3 = 31 3 353 Spring retainer (2 x)
Note: For use only with repair instructions
4 = 31 3 354 Spring retainer ring
Note: For use only with repair instructions
5 = 31 3 355 Spring retainer
Note: For use only with repair instructions
6 = 31 3 356 Centering ring
Note: For use only with repair instructions
7 = 31 3 357 Spring retainer (2 x)
Note: For use only with repair instructions.
In conjunction with: 31 3 340
8 = 31 3 381 Spring retainer ring
Note: For use only with repair instructions.
Scheme 199
9 = 31 3 382 Spring retainer
Note: For use only with repair instructions.
10 = 31 3 358 Insert ring
Note: For use only with repair instructions. For insertion in spring retainer ring 31 3 354. Model series: E87
11 = 31 3 383 Spring retainer
Note: To be used with repair instructions only.
31 3 358 Insert ring
Note: For inserting spring retainer ring 31 3 354 model series (PL2)
Order number: 31 3 358
Insert ring
31 3 360 Protective inserts
Minimum set: Mechanical tools
Note: For spring retainer
Series: E36, E38, E39, E52, E61, E63, E64, E65, E66
Storage location: Single
SI number: 1 11 99(438)
Order number: 31 3 360
Protective inserts
Consisting of
1 = 31 3 361 Protective insert
Note: For spring retainer 31 3 351.
2 = 31 3 362 Protective insert
Note: For spring retainer 31 3 352.
3 = 31 3 363 Protective insert
Note: For spring retainer 31 3 353.
4 = 31 3 364 Protective insert
Note: For spring retainer 31 3 382
5 = 31 3 365 Protective insert
Note: For spring retainer 31 3 355
7 = 31 3 367 Protective insert
Note: For spring retainer 31 3 352
8 = 31 3 368 Protective insert (2 x)
Note: For spring retainer 31 3 357
In conjunction with: 31 3 340
9 = 31 3 369 Protective insert (2 x)
Note: For spring retainer 31 3 352
31 4 010 Axle support set
In conjunction with: 00 2 030, 00 2 040
Note: For lowering or removing and installing front axle support
Series: E60, E61, E63, E64, E65, E66, E67
SI number: 1 14 01 (766)
Order number: 31 4 010
Axle support set
Consisting of
1 = 31 4 011 Take-up fixture 1 + 2
2 = 31 4 012 Take-up fixture 3 + 4
Note: Model series: E60, E65, E66, E67
Scheme 200
31 5 250 Universal axle bracket
In conjunction with: 00 2 030
Note: For accommodating all front and rear axles during removal and installation.
Series: E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93, RR1
SI number: 1 24 06 (309)
Order number: 31 5 250
Universal axle bracket
Consisting of
1 = 31 5 251 Basic unit
2 = 31 5 252 Telescopic supports (4 x)
3 = 31 5 253 Mounting adapter, U-profile (2 x)
4 = 31 5 254 Mounting adapter (2 x)
5 = 31 5 255 Mounting adapter for bores (2 x)
6 = 31 5 256 Mounting adapter for bores (2 x)
7 = 31 5 257 Tensioning strap
