Engine - Repair BMW M5 E60/E61

00 Danger Of Poisoning If Oil Is Ingested/Absorbed Through The Skin

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are

1. Headaches
2. Dizziness
3. Stomach aches
4. Vomiting
5. Diarrhoea
6. Cramps/fits
7. Unconsciousness

Protective measures/rules of conduct

1. Pour oil only into appropriately marked containers
2. Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
3. Observe country-specific safety regulations

First aid measures

1. Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.

00 Risk Of Injury If Oil Comes Into Contact With Eyes And Skin

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are

1. Impaired sight
2. Irritation of the eyes
3. Reddening of the skin
4. Rough and cracked skin

Protective measures/rules of conduct

1. Wear protective goggles
2. Wear oil-resistant protective gloves
3. Observe country-specific safety regulations

First aid measures

1. Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
2. Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.

00 Safety Instructions For Handling Oil

Recycling

Observe country-specific waste-disposal regulations.

Measures if oil is unintentionally released

1. Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
2. Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
3. Limiting spread: Use oil blocks to prevent the surface spread of oil.
4. Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.

11 00... Service - engine oil (S85)

Note. On the S85 engine, an oil sump for engine oil is installed with separate oil chambers. At an engine oil service solely the oil quantity from the main oil sump (rear oil chamber) is drained. The engine oil from the front oil chamber is continuously delivered to the main oil sump by a separate oil pump. For this reason, it is necessary to operate the engine for at least one minute at idle speed directly before an engine oil service.

Risk of damage! For this reason the alternator must be covered with suitable materials.

Recycling: Catch and dispose of drained engine oil in a suitable collecting vessel. Observe country-specific waste disposal regulations.

Necessary preliminary tasks

1. Remove underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M6)»(ref-263486-S32577391072007090700000) .
2. M5: Loosen service flaps. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) .
3. M6: Loosen engine guard.

S85 engine with screw plug (up to 03/07).

Explanation of the instrument display

1. Engine oil level OK.
2. Engine oil level at maximum.
3. Engine oil level too high (= 0.5 litres ovefilled).
4. Engine oil level at maximum.
5. Quick measurement is running: engine oil level is being measured.
6. No value can be currently measured (engine oil temperature = 70 °C).

Scheme 84

Run engine at idle speed. Repeatedly press on-board computer button on turn indicator lever until the display for the engine oil level can be read off on the instrument display. Press the on-board computer button for longer than three seconds: displayed value is reset

Run the engine at idle speed until the engine oil level has been remeasured (engine oil temperature = 70 °C). The required engine oil temperature for an engine oil service has therefore been reached. Measuring range from minimum (3) to maximum (2) = 1 liter.

Scheme 85

Release screw plug (1) on oil filter cover (2). Tightening torque 11 42 2AZ. See 11 42 OIL FILTER AND PIPES .

Installation note: Replace sealing ring.

Release oil filter cap (2). Tightening torque 11 42 1AZ. See 11 42 OIL FILTER AND PIPES .

Installation note: Renew oil filter element and all sealing rings.

Scheme 86

Carry out work on the vehicle only when wearing oil- and heat-resistant protective gloves incl. forearm protection, face guard and protective apron.

Loosen screw plug (1) with nut and a long extension (2). Tightening torque 11 13 1AZ. See 11 13 OIL PAN .

Installation note: Replace sealing ring.

Scheme 87

Tilt long extension (1) with nut and screw plug in direction of arrow. Catch and dispose of drained engine oil in a suitable collecting vessel.

Scheme 88

Pour in engine oil.

Park vehicle on a horizontal surface. Start engine and run at idle speed until engine oil temperature = 70 °C. Press the on-board computer button for longer than three seconds: Remeasure the engine oil level.

Measuring range from minimum (3) to maximum (2) = 1 liter.

1. Engine oil level (+ 0.6 liter).
2. Range for maximum.
3. Range for minimum.

The filled quantity of engine oil is 0.6 litres above the permissible minimum. Top-up quantity to be calculated: 1 liter - 0.6 liter (display) = 0.4 litres top-up quantity.

Run engine at operating temperature for one minute at idle speed.

Pre-delivery check / engine replacement Carry out distance reset by only using the diagnosis system.

Service - engine oil Distance RESET can only be carried out using the diagnosis system or instrument cluster. Precise measurement of the filled quantity of engine oil can be read out from the diagnosis system, in the DME in the test module (oil level measurement). Top up engine oil, if necessary.

Engine oil overfilled

Start engine and run at idle speed (engine oil temperature = 70 °C). Run engine at idle speed. Repeatedly press on-board computer button on turn indicator lever until the display for the engine oil level can be read off on the instrument display. Press the on-board computer button for longer than three seconds: displayed value is reset

Run the engine at idle speed until the engine oil level has been remeasured (engine oil temperature = 70 °C). The required engine oil temperature for an engine oil service has therefore been reached

Note. On overfilled level value up to 0.5 litres can be displayed on the instrument cluster. A further overfilling of more than 0.5 litres can only be read out using the diagnosis system. The diagnosis system can display an overfill of up to 3.5 litres. When overfilling is suspected, we recommend correction of the oil filling by using the diagnosis system.

On the diagnosis system select the following steps

1. Complete vehicle
2. Powertrain
3. Engine electronics
4. Oil supply
5. Oil condition sensor

Switch off engine and loosen engine guard. Release screw plug (1) on oil filter cover (2). Tightening torque 11 42 2AZ. See 11 42 OIL FILTER AND PIPES .

Note. Drained oil quantity in the oil filter housing: approx. 0.4 litres Repeat this operation several times as required.

Reassemble the vehicle.

S85 engine with two screw plug (from 03/07).

It is no longer necessary to read out the engine oil level.

Perform engine oil service only when engine is at normal operating temperature (>70 °C engine oil temperature).

Release screw plug (1) on oil filter cover (2). Tightening torque 11 42 2AZ. See 11 42 OIL FILTER AND PIPES .

Installation note: Replace sealing ring.

Release oil filter cap (2). Tightening torque 11 42 1AZ. See 11 42 OIL FILTER AND PIPES .

Installation note: Renew oil filter element and all sealing rings.

Release screw (1). Tightening torque 11 13 1AZ. See 11 13 OIL PAN .

Installation note: Replace sealing ring.

Scheme 89

Carry out work on the vehicle only when wearing oil- and heat-resistant protective gloves incl. forearm protection, face guard and protective apron.

Loosen screw plug (1) with nut and a long extension (2). Tightening torque 11 13 1AZ. See 11 13 OIL PAN .

Installation note: Replace sealing ring.

Tilt long extension (1) with nut and screw plug in direction of arrow. Catch and dispose of drained engine oil in a suitable collecting vessel.

Pour in engine oil. Park vehicle on a horizontal surface. Start engine and run at idle speed until engine oil temperature = 70 °C. Press the on-board computer button for longer than three seconds: Remeasure the engine oil level.

11 00 039 Checking Compression Of All Cylinders (S85)

Special tools required

1. 11 0 224
2. 11 0 235

Disconnect all supply leads from ignition coils (interrupt power supply to ignition coils).

Check Schrader valve on special tool 110 235 for correct seating (engine damage).

The throttle valves cannot be opened by opening the throttle.

A compression check is carried out exclusively by means of the idle actuators.

A compression check is only possible with the diagnosis tester.

Necessary preliminary tasks

1. Remove microfilter housing. See «64 31 061 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT MICROFILTER HOUSING LOWER SECTION»(ref-379401-S13162676242010121300000) or «64 31 061 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT MICROFILTER HOUSING LOWER SECTION (M6)»(ref-202140-S32898856862005102700000) .
2. Release coolant tank and place to one side
3. Remove all spark plugs.
4. Connect diagnosis tester.

1. Service function.
2. Drive.
3. Engine electronics
4. Switch off fuel injection. IMPORTANT: Fuel injectors are switched off.
5. Actuate starter motor for 8 seconds.

Screw special tool 110 235 into spark plug hole.

Check that sealing ring is in perfect condition on special tool 11 0 235.

Connection (1) for diagnosis tester or special tool 11 0 224.

Scheme 90

Connect special tool 110 224 or 25 bar pressure adapter to diagnosis tester.

Compression pressure.

Scheme 91

Now clear the fault memory.

11 00 050 Removing And Installing Engine (S85)

Necessary preliminary tasks

1. Remove underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M6)»(ref-263486-S32577391072007090700000) .
2. Remove both front wheels.
3. Remove fresh air duct. See «64 31 053 REMOVING AND INSTALLING OR REPLACING FRESH AIR DUCT (M5)»(ref-379401-S18323961992010121300000) or «64 31 053 REMOVING AND INSTALLING OR REPLACING FRESH AIR DUCT (M6)»(ref-202140-S39736746612005102700000) .
4. Remove SMG transmission [23]. «23 00 613 REMOVING AND INSTALLING TRANSMISSION (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-trans/#manual-transmission-repair-instructions__23-00-613-removing-and-installing) or «23 00 018 REMOVING AND INSTALLING TRANSMISSION (M6)»(ref-381310-S30168757592010122900000) .
5. Remove front wall. See «41 33 040 REPLACING FRONT WALL (M5)»(/bmw/m5/e60e61-2004-2010/remont/exterior-body-panels/#body-repair__41-33-040-replacing-front-wall) .
6. Remove «oil filter housing»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-42-020-removing-and-installing) .
7. Drain coolant.
8. Remove module carrier with radiator.
9. Remove expansion tank.
10. Detach coolant hose from auxiliary water pump.
11. Draw off hydraulic fluid [32].
12. Remove fluid reservoir with lines for steering gear.
13. Draw off A/C system. «64 50 009 DRAWING OFF, EVACUATING AND FILLING A/C SYSTEM (R 134A) (M5)»(ref-379401-S28478566692010121300000) or «64 50 009 DRAWING OFF, EVACUATING AND FILLING A/C SYSTEM (R 134A) (M6)»(ref-202140-S37151133852005102700000) .
14. Detach lines from A/C compressor. See «64 52 523 REPLACING A/C SYSTEM COMPRESSOR (M5)»(ref-379401-S42063386832010121300000) or «64 52 523 REPLACING A/C SYSTEM COMPRESSOR (M6)»(ref-202140-S34268247112010112400000) .
15. Disconnect all plug connections in electronics box.
16. Remove both intake filter housings. See «13 71 000 REMOVING AND INSTALLING LEFT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) or «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing)
17. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
18. Disconnect hose for crankcase ventilation.
19. Disconnect hose for suction jet pump.
20. Remove heat shield on front axle carrier.
21. Release steering spindle. See «32 31 070 REMOVING AND INSTALLING / REPLACING LOWER SECTION OF STEERING SPINDLE (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-070-removing-and-installing) or «32 31 070 REMOVING AND INSTALLING/REPLACING LOWER SECTION OF STEERING SPINDLE (M6)»(ref-263480-S41654543902007090700000) .
22. Remove left and right «oxygen sensors»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair) .
23. Remove left and right temperature sensors [17, 62].
24. Release grounding strap on engine support arm.
25. Unscrew left and right engine mounts. See «ENGINE SUSPENSION»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-and-transmission-suspension-repair) .
26. Carefully lift out engine with two persons.

11 00 670 Securing Engine In Installation Position (S85)

Special tools required

1. 00 0 200
2. 00 0 202
3. 00 0 204
4. 00 0 208
5. 11 0 020

Observe following instructions relating to special tool

1. Prior to each use, check the special tools for defects, modifications and operational reliability.
2. Damaged/modified special tools must not be used!
3. No changes or modifications may be made to the special tools!
4. Keep special tools dry, clean and free of grease.

Necessary preliminary tasks

1. Secure engine bonnet/hood in service position
2. Remove both intake filter housings. See «13 71 000 REMOVING AND INSTALLING LEFT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) or «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing)
3. Remove tension strut on spring strut dome. See «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-373-removing-and-installingreplacing) or «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME (M6)»(ref-263486-S37271255352007090700000) .

Assemble transverse member 00 0 200 with special tools 00 0 202, 00 0 204, 00 0 208.

Scheme 92

Secure special tool 11 0 020 to spindle 00 0 202.

Attach suitable chains to special tool 11 0 020 and suspend from both engine suspension eyes (2).

Scheme 93

Unscrew nuts (1).

Raise engine approx. 10 mm with transverse member.

Installation

Replace self-locking nuts.

Scheme 94

11 0 091 Installing Replacement Engine (S85)

Necessary preliminary tasks

1. Remove and install «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .

Note. Use a 5W-30 engine oil for the running-in procedure in a replacement engine. Running-in engine oil must be changed at 2000 km for a 10W-60 engine oil incl. engine oil filter.

Installation

Modifying check valves, refer to memory entries in DME.

In engines where it is not possible to connect check valves, replace the vacuum-controlled check valves with self-opening check valves.

Vacuum lines will then no longer be required.

Scheme 95

Engine Identification

Drive in engine numbers at marked surface with impact tool.

M47 / M47TU / M47T2

Scheme 96

M57 / M57TU / M57T2

Scheme 97

M67 / M67TU

Scheme 98

N47

Scheme 99

M52 / M52TU

Scheme 100

M54

Scheme 101

M56

Scheme 102

N40 / N45

Scheme 103

N42 / N46 / N46T

Scheme 104

N51 / N52 / N52K / N53 / N54

Scheme 105

N62

Scheme 106

N73

Scheme 107

S54

Scheme 108

S85

Scheme 109

W10/W11

Scheme 110

W17

Scheme 111

Assemble engine.

Mounting Engine On Assembly Stand (S85)

Special tools required

1. 00 2 300
2. 11 5 260

Necessary preliminary tasks

1. Remove «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .

Secure special tool 11 5 260 to crankcase with bolts (1 and 2).

Tighten screws (1 and 2) uniformly.

Scheme 112

Secure engine with special tool 11 5 260 to special tool 00 2 300.

Scheme 113

11 12 005 Removing And Installing / Sealing Left Cylinder Head Cover (S85)

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Remove «IGNITION COILS (S85)»(/bmw/m5/e60e61-2004-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair__12-13-512-replacing-all-ignition) .
3. Disconnect plug connection for ion control unit.
4. Disconnect plug connection at camshaft sensors.

Release screw (1).

Lay ground strap (2) to one side.

Scheme 114

Release screws along line (1).

Scheme 115

Remove spark plug tube (1) in direction of arrow.

Installation

Check rubber on spark plug tube (1) for damage; replace spark plug tube (1) if necessary.

Apply a light coating of engine oil to spark plug tube (1) prior to installation.

Scheme 116

Installation

Replace seal (1).

Align gasket (1) on cylinder head cover groove.

Press in gasket (1) so that it is free from tension.

Scheme 117

Installation

Clean seal residue from sealing surfaces.

Coat contact surfaces of joint (1) with Drei Bond 1209.

Scheme 118

Installation

Check decoupling element (1) for damage and replace if necessary.

Scheme 119

Fit cylinder head cover.

Align spark plug tubes.

Tighten down all retaining elements diagonally from inside to outside.

Assemble engine.

11 12 005 Removing And Installing / Sealing Right Cylinder Head Cover (S85)

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Remove rod-type «ignition coils»(/bmw/m5/e60e61-2004-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair__12-13-512-replacing-all-ignition) .
3. Disconnect plug connection for ion control unit.
4. Disconnect plug connection at camshaft sensors.

Release screw (1).

Lay ground strap (2) to one side.

Release screws along line (1).

Scheme 120

Remove spark plug tube (1) in direction of arrow.

Installation

Check rubber on spark plug tube (1) for damage; replace spark plug tube (1) if necessary.

Apply a light coating of engine oil to spark plug tube (1) prior to installation.

Installation

Replace seal (1).

Align gasket (1) on cylinder head cover groove.

Press in gasket (1) so that it is free from tension.

Installation

Clean seal residue from sealing surfaces.

Coat contact surfaces of joint (1) with Drei Bond 1209 (refer to BMW Parts Service).

Installation

Check decoupling element (1) for damage and replace if necessary.

Fit cylinder head cover.

Align spark plug tubes.

Tighten down all retaining elements diagonally from inside to outside.

Assemble engine.

11 12 105 Removing And Installing Left Cylinder Head (S85)

Special tools required

1. 11 5 210
2. 11 5 220
3. 11 5 352

Necessary preliminary tasks

1. Remove «EXHAUST SYSTEM»(/bmw/m5/e60e61-2004-2010/remont/exhaust/#exhaust-system-repair) .
2. Remove left exhaust manifold. See «18 40 010 REMOVING AND INSTALLING/REPLACING LEFT EXHAUST MANIFOLD (S85)»(/bmw/m5/e60e61-2004-2010/remont/exhaust/#exhaust-system-repair__18-40-010-removing-and-installingreplacing)
3. Unfasten engine wiring harness and lay to one side.
4. Remove left «cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
5. Remove «left inlet camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-032-removing-and-installing) .
6. Remove «left exhaust camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-036-removing-and-installing) .

Attach special tool 11 5 220.

Insert special tool 11 5 210.

Unclip linkage (1).

Scheme 121

Detach hoses (2) from holder (1).

Scheme 122

Release screws (1).

Scheme 123

Cylinder head bolt (1) with shim.

Scheme 124

Do not remove special tool 115 352.

Release cylinder head bolts from outside to inside in sequence (12 to 1).

Scheme 125

Note. Replace cylinder head gasket . Check cylinder head for water leaks.

Installation

Fit new cylinder head screws.

Tighten down cylinder head bolts from inside to outside in sequence (1 to 12).

Tightening torque 11 12 1AZ. See CYLINDER HEAD WITH COVER .

Insert screws (1).

Tightening torque 11 12 1AZ. See CYLINDER HEAD WITH COVER .

Installation

Modifying check valves, refer to memory entries in DME.

In engines where it is not possible to connect check valves, replace the vacuum-controlled check valves with self-opening check valves.

Vacuum lines will then no longer be required.

Assemble engine.

11 12 106 Removing And Installing Right Cylinder Head (S85)

Special tools required

1. 115 210
2. 115 220
3. 115 351

Necessary preliminary tasks

1. Remove «EXHAUST SYSTEM»(/bmw/m5/e60e61-2004-2010/remont/exhaust/#exhaust-system-repair) .
2. Remove «RIGHT»(/bmw/m5/e60e61-2004-2010/remont/exhaust/#exhaust-system-repair__18-40-020-removing-and-installingreplacing) exhaust manifold.
3. Unfasten engine wiring harness and lay to one side.
4. Remove «right»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) cylinder head cover.
5. Remove «Right Inlet Camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-034-removing-and-installing) .
6. Remove «Right Exhaust Camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-038-removing-and-installing) .

Attach special tool 11 5 220.

Insert special tool 115 210.

Unclip linkage (1).

Do not remove special tool 11 5 351.

Note. Remove and install cylinder head with special tool 11 5 351.

Scheme 126

Release screws (1).

Scheme 127

Cylinder head bolt (1) with shim.

Release cylinder head bolts from outside to inside in sequence (12 to 1).

Scheme 128

Note. Replace cylinder head gasket . Check cylinder head for water leaks.

Installation

Fit new cylinder head screws.

Tighten down cylinder head bolts from inside to outside in sequence (1 to 12).

Tightening torque, see 11 12 1AZ in CYLINDER HEAD WITH COVER .

Insert screws (1).

Tightening torque, see 11 12 1AZ in CYLINDER HEAD WITH COVER .

Installation

Modifying check valves, refer to memory entries in DME.

In engines where it is not possible to connect check valves, replace the vacuum-controlled check valves with self-opening check valves.

Vacuum lines will then no longer be required.

Assemble engine.

11 12 112 Replacing Both Cylinder Head Gaskets (S85)

Necessary preliminary tasks

1. Remove «Left Cylinder Head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) .
2. Remove «Right Cylinder Head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
3. Check cylinder head for «leaks»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-729-checking-cylinder-head) .

Installation

If necessary, replace non-return valve with spacer sleeve (1).

Scheme 129

Check dowel sleeves (1) for damage and correct installation position.

Installation

Clean sealing surfaces.

Illustration shows cyl. 6-10.

Scheme 130

Replace head gasket (1).

Note. Illustration shows cyl. 1-5.

Scheme 131

Note. There is no oversize gasket for the S85 engine.

Assemble engine.

11 12 729 Checking Cylinder Head For Water Leaks (S85)

Special tools required

1. 11 5 230
2. 11 5 231
3. 11 5 233
4. 11 5 235
5. 11 5 237

Note. Special tool 115 230 can be used for both cylinder heads.

Necessary preliminary tasks

1. Remove «left cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «right cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
2. Disassemble cylinder head.

Secure special tool 11 5 231 with old cylinder head bolts.

Secure special tool 11 5 235 with special tool 11 5 237.

Secure special tool 11 5 233 with special tool 11 5 237.

Scheme 132

Note. Immerse cylinder head in a water bath.

Test pressure: 4.5 bar.

Check cylinder head for escaping air (cracks).

If necessary, add cleaning agent to water bath.

Assemble engine.

11 13 000 Removing And Installing Or Replacing Oil Sump (S85)

Recycling

Catch and dispose of used oil in a suitable container.

Observe country-specific waste-disposal regulations.

Necessary preliminary tasks

1. Drain «engine oil»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-service-engine-oil) .
2. Secure «engine in installation position»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-670-securing-engine-in) .
3. Lower «FRONT AXLE (M5)»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#front-axle-repair) or «FRONT AXLE (M6)»(ref-263479-S18265746152007090700000) .
4. Remove «ribbed V-belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) .
5. Release 4x transmission bolts.

Release screws (4).

Unfasten hose clip (3).

Remove hose (1).

Unfasten banjo bolt (2).

Installation

Replace sealing rings.

Tightening torque 11 36 3AZ. See VARIABLE CAMSHAFT CONTROL .

Scheme 133

Unscrew nuts (1).

Release oxygen sensor holder (2), remove if necessary.

Scheme 134

Release screw (1) on heat shield on left and right.

If necessary, remove crankshaft sensor.

Scheme 135

Release screw (1) on heat shield on left and right.

Remove heat shield (2) on left and right.

Scheme 136

Disconnect plug connection (2).

Disconnect plug connection (5).

Release cable from holders (1 and 4).

Release screw (5).

Scheme 137

Detach cable from bracket (1).

Scheme 138

Disconnect plug connection (1).

Detach cable from bracket (3).

Release screw (2).

Scheme 139

Disconnect plug connection (3).

Release screws (1).

Remove VANOS pressure accumulator in direction of arrow.

Scheme 140

Release screw (1).

Release screws (3).

Remove belt tensioner (2).

Scheme 141

Release screw (1).

Scheme 142

Release screw (1).

Scheme 143

Note. Illustration shows right return pump. The procedure for the left return pump is identical.

Release screws (1).

Remove electric oil pump (2).

Installation

Replace O-ring.

Scheme 144

Scheme 145

Replace oil sump gasket.

Assemble engine.

11 14 005 Replacing Front Crankshaft Radial Seal (S85)

Special tools required

1. 11 5 331
2. 11 5 332
3. 11 5 333
4. 11 7 231
5. 23 0 490

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove «vibration damper»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-23-010-removing-and-installing) .
3. Remove radiator. See «REMOVING RADIATOR COVER (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__removing-radiator-cover-s85) or «17 11 000 REMOVING AND INSTALLING RADIATOR (M6)»(ref-381314-S33322338112010122900000) .

Lay special tool 11 2 386 on crankshaft.

Scheme 146

Screw special tool 11 6 360 to 80 Nm into radial shaft seal. Release radial seal from housing. Repeat the operation several times if necessary.

Scheme 147

Note. Carefully saw open old radial shaft seal with an iron saw from special tool 11 6 360.

Remove remnants of sealant from sealant outlet (1) on left and right.

Apply Drei Bond 2.1 sealant to sealant outlet (1) on left and right.

Scheme 148

Secure special tool 11 5 331 with screws (1).

Scheme 149

Push special tool 11 7 231 onto special tool 11 5 331 in direction of arrow.

Scheme 150

Installation

Remove support ring from radial shaft seal.

Push radial shaft seal (1) uniformly by way of fitting aid 11 7 231 onto special tool 11 5 331.

Position radial shaft seal approx. 5 mm before crankcase.

Remove special tool 11 7 231.

Scheme 151

Press in radial shaft seal (1) with special tools 11 5 332 and 11 5 333.

Scheme 152

Assemble engine.

Setting time of radial shaft seal approx. 1 hour.

Correct engine oil level if necessary.

11 14 151 Replacing Crankshaft Radial Seal (S85)

Special tools required

1. 11 5 311
2. 11 5 312
3. 11 5 313
4. 23 0 490

Necessary preliminary tasks

1. Remove transmission. See «REMOVING AND INSTALLING TRANSMISSION (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-trans/#manual-transmission-repair-instructions__23-00-613-removing-and-installing) or «REMOVING AND INSTALLING TRANSMISSION (M6)»(ref-381310-S30168757592010122900000) .
2. Remove clutch. See «REMOVING AND INSTALLING/REPLACING CLUTCH (M5)»(/bmw/m5/e60e61-2004-2010/remont/clutches-manual-hydraulic/#clutch-repair__21-21-000-removing-and-installingreplacing) or «REMOVING AND INSTALLING/REPLACING CLUTCH (M6)»(ref-520589-S29637208782013010300000) .
3. Remove «flywheel»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-22-500-removing-and-installingreplacing) .

Drill a 3 mm hole into radial shaft seal.

Screw in special tool 23 0 490.

Drive out radial shaft seal with impact weight.

Scheme 153

Remove remnants of sealant from sealant outlet (1) on left and right.

Apply Drei Bond sealant 1209 to sealant outlet (1) on left and right.

Scheme 154

Mount special tool 11 5 311 with bolts (1).

Scheme 155

Position support ring (1) with radial shaft seal (2) on special tool 11 5 311.

Push radial shaft seal (2) uniformly in direction of arrow over support ring onto special tool 11 5 311.

Scheme 156

Position radial shaft seal (1) approx. 5 mm before crankcase.

Remove support ring (2).

Note. Support ring (2) is no longer needed.

Scheme 157

Press in radial shaft seal (1) with special tools 11 5 312 and 11 5 313.

Scheme 158

Assemble engine.

Settling time of radial shaft seal approx. 1 hour.

Correct engine oil level if necessary.

11 21 500 Replacing Crankshaft (S85)

Special tools required

1. 00 9120
2. 00 9130
3. 11 4 370
4. 11 5 311
5. 11 5 312
6. 11 5 313
7. 11 5 331
8. 11 5 332
9. 11 5 333
10. 11 7 231
11. 11 9 360

Necessary preliminary tasks

1. Remove «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .
2. Mount engine on «assembly stand»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__mounting-engine-on-assembly-stand-s85) .
3. Remove «flywheel»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-22-500-removing-and-installingreplacing) .
4. Remove «oil pan»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
5. Remove «engine oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .
6. Remove «VANOS high-pressure pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-140-removing-and-installing) .
7. Remove «left cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «right cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
8. Remove all «pistons»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-25-530-removing-and-installingreplacing) .
9. Remove «vibration damper»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-23-010-removing-and-installing) .
10. Remove both «timing chains»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-051-replacing-both-timing) .

Release all bearing block bolts (1) from inside outwards.

Installation

Replace fine-mesh strainer (3).

Scheme 159

Release screws (3).

Unfasten screws (2).

Bolts (1) from inside outwards.

Lift out bedplate.

Scheme 160

Lever out crankshaft (1) with aid of a second person in direction of arrow.

Note. Weight of crankshaft approx. 22 kg.

Scheme 161

Replace all bearing shells (1 and 2).

Installation

Replace main bearing shells.

Scheme 162

Remove sealing compound from joint (1).

Carefully clean threads and contact faces in upper and lower sections of crankcase.

Installation

Replace nozzles (2).

Scheme 163

Installation

Apply a light coating of engine oil to bearing shells.

Lay crankshaft (1) with a second person helping in direction of arrow into crankcase.

Note. Weight of crankshaft approx. 22 kg.

Note. There are no more dowel sleeves in the crankcase. Position bedplate on crankcase.

Position lower section diagonally on bearing blocks (1 and 6) using two fit bolts (1).

Join fit bolts (1) to 8 Nm.

Scheme 164

Insert remaining 10 fit bolts (1) and join to 8 Nm.

Scheme 165

Insert all M11 bolts (1).

Scheme 166

Scheme 167

Tightening sequence of M11 and fit bolts

Bearing blocks (1 to 6).

Tightening sequence (1 to 12).

Tighten M11 bolts with special tools 00 9 120 and 00 9 130.

Tightening torque 11 11 1AZ. See ENGINE BLOCK .

Observe tightening/torque sequence.

Scheme 168

Tighten fit bolts with special tools 00 9 120 and 00 9 130.

Tightening torque 11 11 2AZ. See ENGINE BLOCK .

Scheme 169

Insert screws (1).

Tightening torque: 11 11 3AZ. See ENGINE BLOCK

Insert screws (2).

Tightening torque: 11 11 4AZ. See ENGINE BLOCK

Insert screws (3).

Tightening torque 11 11 5AZ. See ENGINE BLOCK .

Secure special tool 11 5 331 with bolts (1). Important! Pay attention to dowel pin.

Push special tool 11 7 231 onto special tool 11 5 331 in direction of arrow.

Installation: Remove support ring from radial shaft seal.

Important! Sealing lip of radial shaft seal is highly sensitive. Sealing lip must not be kinked. Do not touch the sealing lip with your fingers.

Push radial shaft seal (1) uniformly by way of fitting aid 11 7 231 onto special tool 11 5 331.

Position radial shaft seal approx. 5 mm before crankcase. Remove special tool 11 7 231.

Press in radial shaft seal (1) with special tools 11 5 332 and 11 5 333.

Important! Pay attention to fitting sleeve. Special tool 11 5 311 must rest flat on crankshaft (pay attention to fitting sleeve). Install special tool 11 5 311 with bolts (1).

Position support ring (1) with radial shaft seal (2) on special tool 11 5 311. Push radial shaft seal (2) uniformly in direction of arrow over support ring onto special tool 11 5 311.

Position radial shaft seal (1) approx. 5 mm before crankcase. Remove support ring (2).

Note. Support ring (2) is no longer needed.

Press in radial shaft seal (1) with special tools 11 5 312 and 11 5 313.

Scheme 170

Drive both injector nozzles with special tool 11 9 360 on left and right into crankcase.

Installation: Always replace injector nozzles.

Scheme 171

Installation: Use primer 1.5 and liquid sealing compound 1.6. Prepare liquid sealing compound (2) in special tool 11 4 370. Screw on nozzle (1) for injecting liquid sealing compound.

Scheme 172

Press sealing compound cartridge (1) in direction of arrow onto nozzle at 90°. Slowly and evenly insert sealing compound (1) with special tool 11 4 370 in direction of arrow.

Scheme 173

Stop (seal off) escaping liquid sealing compound with primer (2) 1.5 at outlet bore (1). The procedure is identical as on the rear radial shaft seal.

Scheme 174

Assemble engine.

11 21 531 Replacing All Crankshaft Main Bearings (S85)

Special tools required

1. 00 2 590

Necessary preliminary tasks

1. «Engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) removed.
2. Remove «crankshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-21-500-replacing-crankshaft-s85) .

Installation

Bearing shell (1) is a guide bearing.

Remove bearing shells (1) and (2).

Observe bearing classification.

Determine bearing play with special tool 00 2 590.

Lay step bearing (1) on 6th bearing block.

Scheme 175

Installation

Bearing shell (1) with lubricant groove must be fitted in crankcase upper section.

Bearing shell (2) without lubricant groove must be fitted in crankcase lower section (bedplate).

Scheme 176

Bearing classification on bedplate bearing block.

Observe color allocation on crankshaft (1 to 6).

V= Violet.

G = Green.

Y= Yellow.

Scheme 177

Bearing classification on crankcase bearing block.

Observe color allocation in crankcase (1 to 6).

V= Violet.

G = Green.

Y= Yellow.

Scheme 178

Lay plastic thread (Plastigage) on crankshaft.

Fit and bolt down bedplate.

Note. Do not twist crankshaft.

Remove bedplate.

Read off bearing play at width of flattened plastic thread and measurement scale.

Crankshaft bearing clearance radial.

Scheme 179

Assemble engine.

11 21 571 Replacing Grooved Ball Bearings In Crankshaft (S85)

Special tools required

1. 00 5 500
2. 11 2 016
3. 11 2 340
4. 11 2 350

Necessary preliminary tasks

1. Remove transmission. See «REMOVING AND INSTALLING TRANSMISSION (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-trans/#manual-transmission-repair-instructions__23-00-613-removing-and-installing) or «REMOVING AND INSTALLING TRANSMISSION (M6)»(ref-381310-S30168757592010122900000) .
2. Remove clutch. See «REMOVING AND INSTALLING/REPLACING CLUTCH (M5)»(/bmw/m5/e60e61-2004-2010/remont/clutches-manual-hydraulic/#clutch-repair__21-21-000-removing-and-installingreplacing) or «REMOVING AND INSTALLING/REPLACING CLUTCH (M6)»(ref-520589-S29637208782013010300000) .

Remove grooved ball bearing with special tool 11 2 340 in conjunction with special tool 11 2 016.

Scheme 180

Installation

Replace guide bearing.

Drive in guide bearing as far as it will go with special tools 11 2 350 and 00 5 500.

Scheme 181

Assemble engine.

11 22 500 Removing And Installing/Replacing Flywheel (S85 6-Speed Manual Gearbox)

Special tools required

1. 11 4 180
2. 11 9 260
3. 11 9 263

Necessary preliminary tasks

1. Remove transmission. See «REMOVING AND INSTALLING TRANSMISSION (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-trans/#manual-transmission-repair-instructions__23-00-613-removing-and-installing) or «REMOVING AND INSTALLING TRANSMISSION (M6)»(ref-381310-S30168757592010122900000) .
2. Remove clutch. See «REMOVING AND INSTALLING/REPLACING CLUTCH (M5)»(/bmw/m5/e60e61-2004-2010/remont/clutches-manual-hydraulic/#clutch-repair__21-21-000-removing-and-installingreplacing) or «REMOVING AND INSTALLING/REPLACING CLUTCH (M6)»(ref-520589-S29637208782013010300000) .

Secure flywheel (1) with special tools 11 9 263 and 11 9 260.

Scheme 182

Installation

Fit new flywheel screws.

Tightening torque 11 22 1AZ. See ENGINE - TIGHTENING TORQUES .

Release flywheel screws with special tool 11 4 180.

Scheme 183

Assemble engine.

11 22 500 Removing And Installing/Replacing Flywheel (S85)

Special tools required

1. 11 4 180
2. 11 9 260
3. 11 9 265

Necessary preliminary tasks

1. Remove transmission. See «REMOVING AND INSTALLING TRANSMISSION (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-trans/#manual-transmission-repair-instructions__23-00-613-removing-and-installing) or «REMOVING AND INSTALLING TRANSMISSION (M6)»(ref-381310-S30168757592010122900000) .
2. Remove clutch. See «REMOVING AND INSTALLING/REPLACING CLUTCH (M5)»(/bmw/m5/e60e61-2004-2010/remont/clutches-manual-hydraulic/#clutch-repair__21-21-000-removing-and-installingreplacing) or «REMOVING AND INSTALLING/REPLACING CLUTCH (M6)»(ref-520589-S29637208782013010300000) .

Secure flywheel with special tools 11 9 265 and 11 9 260.

Release flywheel screws with special tool 11 4 180.

Installation

Fit new flywheel screws.

Tightening torque 11 22 1AZ. See ENGINE - TIGHTENING TORQUES .

Scheme 184

Assemble engine.

11 22 513 Replacing Roller Bearing For Dual-Mass Flywheel

Special tools required

1. 00 5 500
2. 11 2 010
3. 11 2 343
4. 11 2 350

Note. Flywheel removed!

Position special tool 11 2 010 in roller bearing.

Twist out roller bearing with special tool 11 2 343.

Scheme 185

Assemble special tools 11 2 350 and 00 5 500.

Drive in roller bearing with special tools 11 2 350 and 00 5 500 in direction of arrow as far as it will go.

Scheme 186

Assemble engine.

11 23 010 Removing And Installing / Replacing Vibration Damper (S85)

Special tools required

1. 00 9 120
2. 11 0 280
3. 11 9 260
4. 11 9 263

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (S85)»(ref-381314-S13869658542010122900000) .
2. Remove «A/C compressor drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) .
3. Remove «alternator drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) .

Release screw (1).

Remove idler pulley (2).

Release screws (4).

Remove belt pulley (3).

Release screws (5).

Remove belt tensioner (6).

Scheme 187

Release screws (1).

Remove cover (2) with belt pulley (3).

Scheme 188

Note. Engine or transmission removed.

Secure special tool 11 9 260 to flywheel (1).

Screw in special tool 11 9 263 with bolt (2) on crankcase.

Scheme 189

Release screws (2).

Remove vibration damper (1).

Tightening torque 11 23 1AZ. See ENGINE - TIGHTENING TORQUES .

Scheme 190

Note. Engine or transmission installed.

Attach special tool 11 0 280 to vibration damper.

Support special tool 11 0 280 on holder (1).

Release all stress bolts in direction of arrow.

Installation

Replace stress bolts.

Scheme 191

Support special tool 11 0 280 on holder (1).

Tighten stress bolts with special tool 00 9 120.

Tightening torque 11 23 1AZ. See ENGINE - TIGHTENING TORQUES .

Scheme 192

Assemble engine.

11 24 571 Replacing All Connecting Rod Bearings (S85)

Special tools required

1. 00 9 120

Necessary preliminary tasks

1. Remove all «pistons»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-25-530-removing-and-installingreplacing) .

Install new conrod bearing shells.

Installation

Install one blue (1) and one red (2) bearing shell in each conrod.

Install all pistons.

Scheme 193

Note. Check conrod bearing clearance.

Piston in BDC position.

Place special tool 00 2 590 (Plastigage model PG 1) on oil-free crankshaft.

Place bearing caps in position, making sure that matching numbers are paired.

Scheme 194

Use the old conrod bearing bolts to check conrod clearance.

Tighten down conrod bolts with special tool 00 9 120.

Tightening torque 11 24 1AZ. See CONNECTING RODS AND BEARINGS .

Scheme 195

Remove conrod bearing cap and read off bearing clearance at width of pinched plastic thread on measuring scale.

Conrod bearing clearance: Refer to ENGINE - TECHNICAL DATA .

1. Remove plastic thread.
2. Lubricate crankshaft and bearing shells.
3. Install new conrod bolts and tighten down.

Tightening torque 11 24 1AZ. See CONNECTING RODS AND BEARINGS .

Scheme 196

Assemble engine.

11 25 530 Removing And Installing/Replacing All Pistons (S85)

Special tools required

1. 00 9 120
2. 11 4 492
3. 11 5 250
4. 11 5 341
5. 11 5 342
6. 11 5 343
7. 11 5 344
8. 11 9 500
9. 12 2 100

Necessary preliminary tasks

1. Remove «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .
2. Mount «engine on assembly stand»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__mounting-engine-on-assembly-stand-s85) .
3. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
4. Remove «left cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «right cylinder head»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
5. Remove «engine oil sump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
6. Remove «oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .
7. Remove «VANOS high-pressure pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-140-removing-and-installing) .

Do not bend oil nozzle (2) at outlets.

It is not possible to adjust the nozzles.

Oil nozzle (2) must be replaced if it is maladjusted or bent.

Release screws (1).

Oil nozzle (2)

Scheme 197

Release connecting rod bolts (1) with special tool 12 2 100.

Remove connecting rod bearing cap with bearing shell.

Scheme 198

Special tool 11 5 250 without locating rod must be screwed in on the connecting rod at the bottom.

Special tool 11 5 250 with locating rod must be screwed in on the connecting rod at the top.

Scheme 199

Rotate crankshaft (1) in direction of arrow, risk of damage to special tool 11 5 250.

Remove piston with connecting rod and special tool 11 5 250.

Depiction of function on cylinders 1-5.

Scheme 200

Clamp special tool 11 5 341 in a vice.

Note. Piston and piston pin are optimized to each other. There are two different inside diameters on the piston pin.

Screw matching special tool 11 5 342 into special tool 11 5 341.

Scheme 201

Secure piston (1) with conrod to special tool 11 5 341.

Scheme 202

Lever out piston circlip with special tool 11 4 492 in direction of arrow.

Scheme 203

If necessary, replace connecting rods.

Installation

The piston pin must be able to be pressed through the liner by hand with little force and must not display any significant play.

Scheme 204

Measure piston installation clearance

Measure piston diameter with micrometer at measuring point A from bottom edge of piston and offset at 90° to the axis of the piston pin.

Piston diameter at measuring point A.

Scheme 205

Adjust micrometer to cylinder bore of engine block. Set internal caliper on micrometer to zero. Measure bottom, center and top of cylinder bore in direction of travel and direction of engine rotation.

Diameter of cylinder bore.

Piston installation clearance.

Total permissible wear tolerance.

If necessary, replace piston.

Scheme 206

Scheme 207

Make sure the connecting rod is in the correct installation position during preliminary installation.

On cylinders 6-10 the elevation (2) must point forwards with the arrow.

On cylinders 1 -5 the elevation (1) must point rearwards against the arrow.

Valve pockets (E) point to inlet side.

Arrow direction is identical to direction of travel.

Scheme 208

On cylinders 6-10 the elevation must point forwards with the arrow.

On cylinders 1-5 the elevation (1) must point rearwards against the arrow.

Scheme 209

Secure piston (1) with conrod to special tool 11 5 341.

Installation

Insert piston circlip (2) so that opening points to window.

Insert piston circlip (2) into groove (1) of special tool 11 5 343.

Note. Illustration shows N52.

Scheme 210

Position special tool 11 5 343 with window to opening on piston (see arrow).

Scheme 211

Position special tool 11 5 343 with window to opening on piston (see arrow).

Scheme 212

Guide lug and cutout on special tool 11 5 343 must point to piston crown.

When special tools 11 5 343 and 11 5 344 are correctly positioned, the piston circlip must be driven in with a plastic hammer in the direction of the arrow.

Scheme 213

Installation

Piston circlip (1) is correctly installed when the opening points upwards.

It must still be possible for piston pin to moved easily

Scheme 214

Install all piston rings.

Install all bearing shells.

Screw special tool 11 5 250 into connecting rod.

Always screw in special tool 11 5 250 with rod to exhaust side.

Preinstall piston with piston rings in special tool 11 9 500.

Scheme 215

Insert piston with conrod in cylinder.

Insert piston so that arrow (direction of travel pointing forwards) on piston crown points to camshaft drive.

Piston cyl. 1-5 right side, cyl. 6-10 left side.

Press in piston with special tool 119 500.

Scheme 216

Scheme 217

Rotate crankshaft (1) in direction of arrow, risk of damage to special tool 11 5 250.

Insert piston with connecting rod and special tool 11 5 250.

Note. Depiction of function on cylinders 1-5.

Moisten conrod bearing shell and crank pin slightly with engine oil.

Assemble conrod and crank pin.

Remove special tool 11 5 250.

Install connecting rod bearing cap with bearing shell.

Secure connecting rod bolts (1) with special tools 12 2 100 and 00 9 120.

Tightening torque 11 24 1AZ. See CONNECTING RODS AND BEARINGS .

Assemble engine.

11 25 671 Replacing Piston Rings On All Pistons (S85)

Necessary preliminary tasks

1. Remove «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .
2. Remove all «pistons»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-25-530-removing-and-installingreplacing) .

Remove piston rings with a piston-ring compressing pliers.

Note. It might not be possible to find the identification on used piston rings. Put aside piston rings in correct sequence and installation position.

Scheme 218

Installation

Piston rings marked with "R" must point to piston crown.

Groove (2), plain compression ring.

Groove (3), stepped ring.

Groove (4), bevel-edged oil control ring.

Scheme 219

Piston ring (1), bevel-edged oil control ring.

Piston ring (2), stepped ring.

Piston ring (3), plain compression ring.

Scheme 220

Installation

Piston rings marked with "R" must point to piston crown.

Plain compression ring is marked with (R).

Stepped ring is marked with (R1).

Scheme 221

Measure axial play.

Scheme 222

Measure end clearance.

Scheme 223

Offset the contact points of the piston rings by approx. 120° to each other but do not position above the piston pin boss.

Scheme 224

Assemble engine.

11 28 010 Replacing Alternator Drive Belt (S85)

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove «drive belt for A/C system»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) .

Press down tensioning device (2) with ratchet in direction of arrow.

Remove drive belt (1).

Installation

Observe direction of rotation if reusing the drive belt.

Ensure drive belt is in correct installation position.

Scheme 225

Assemble engine.

11 28 020 Replacing Tensioning Device For Alternator Drive Belt (S85)

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove «A/C compressor drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) .
3. Remove «alternator drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) .

Release screws (5).

Remove belt tensioner (6).

Installation

Observe the installation direction if the belt tensioner is replaced individually.

The lettering TOP must point upwards.

Assemble engine.

11 28 050 Replacing Drive Belt For A/C Compressor (S85)

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .

Press down tensioning device (1) with ratchet in direction of arrow.

Remove ribbed V-belt (2).

Installation

Observe direction of rotation if reusing the drive belt.

Ensure drive belt is in correct installation position.

Scheme 226

Assemble engine.

11 28 060 Removing And Installing Belt Tensioner For A/C Compressor (S85)

Necessary preliminary tasks

1. Remove fan cowl with electric fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove «A/C compressor drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) .

Release screw (1).

Release screw for power steering high-pressure line.

Release screws (2).

Remove belt tensioner (3) with fixture.

Installation

Observe the installation direction if the belt tensioner is replaced individually.

The lettering TOP must point upwards.

Scheme 227

Assemble engine.

11 31 032 Removing And Installing Or Replacing Left Inlet Camshafts (S85)

Special tools required

1. 11 5 241
2. 11 5 242
3. 11 5 243

Necessary preliminary tasks

1. Remove «left cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing)
2. Remove «left VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-030-removing-and-installing)
3. Remove «left VANOS exhaust gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-144-removing-and-installing)
4. Remove «left VANOS inlet gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-142-removing-and-installing)

To remove and install inlet camshafts, insert special tool 11 5 243 in direction of arrow in special tool 11 5 241.

Scheme 228

Secure special tool 11 5 241 to cylinder head on left with special tool 11 5 242.

Pretension eccentric shaft (1) at hexagon head in direction of arrow.

Lock (2) must snap audibly into place.

Scheme 229

Release screws (1).

Tightening torque 11 31 4AZ. See CAMSHAFT .

E Inlet camshaft.

A Exhaust camshaft.

Installation

Lubricate all bearing points with engine oil.

Scheme 230

Release screws along lines (1).

Tightening torque 11 31 4AZ. See CAMSHAFT .

Note. Illustration does not show special tool 11 5 241.

Scheme 231

Release lock on special tool 11 5 241.

Relieve tension on eccentric shaft (1) at hexagon head in direction of arrow.

Inlet camshaft is pressed upwards by valve springs.

Remove special tool 11 5 241.

Remove inlet camshaft.

Scheme 232

Insert inlet camshaft, cylinders 6-10.

Designation (E2) on Dihedron points upwards.

Cams (1) on 6th cylinder point downwards.

Installation

Lubricate all bearing points with engine oil.

Scheme 233

Installation

All bearing shells are assigned to one cylinder.

E and A from (1 to 10), e.g. E 6= inlet side on 6th cylinder.

Arrow (1) must point in direction of travel to chain drive.

Scheme 234

Installation

Arrangement of bearing shells, cylinders 6 to 10.

Scheme 235

Mount special tool 11 5 241 with special tool 11 5 242.

Pretension eccentric shaft (1) at hexagon head in direction of arrow.

Lock must snap audibly into place.

Install all bearing caps by numbers.

Tightening torque 11 31 4AZ. See CAMSHAFT .

Adjust valve timing.

Assemble engine.

11 31 034 Removing And Installing / Replacing Right Inlet Camshaft (S85)

Special tools required

1. 11 5 241
2. 11 5 242
3. 11 5 243

Necessary preliminary tasks

1. Remove «right cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
2. Remove «right VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-040-removing-and-installing) .
3. Remove «right VANOS exhaust gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-150-removing-and-installing) .
4. Remove «right VANOS inlet gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-148-removing-and-installing) .

To remove and install inlet camshafts, insert special tool 11 5 243 in direction of arrow in special tool 11 5 241.

Secure special tool 11 5 241 to cylinder head on right with special tool 11 5 242.

Rotate eccentric shaft (2) at hexagon head and pretension.

Lock (1) must snap clearly and audibly into place.

Scheme 236

Release screws (1).

Tightening torque 11 31 4AZ. See CAMSHAFT .

E Inlet camshaft.

A Exhaust camshaft.

Installation

Lubricate all bearing points with engine oil.

Scheme 237

Release screws along lines (1).

Tightening torque: 11 31 4AZ. See CAMSHAFT .

Note. Illustration does not show special tool 11 5 241.

Scheme 238

Release lock on special tool 11 5 241.

Relieve tension on eccentric shaft (1) at hexagon head in direction of arrow.

Inlet camshaft is pressed upwards by valve springs.

Remove special tools 11 5 241 and 11 5 242.

Remove inlet camshaft.

Scheme 239

Insert inlet camshaft, cylinders 1-5.

Designation (E1) on dihedron points upwards.

Cams (1) point sideways to exhaust side.

Installation

Lubricate all bearing points with engine oil.

Scheme 240

Installation

All bearing shells are assigned to one cylinder.

E and A from (1 to 10), e.g. E 1 = inlet side on 1st cylinder.

Arrow (1) must point in direction of travel to chain drive.

Scheme 241

Installation

Arrangement of bearing shells, cylinders 1 to 10.

Scheme 242

Mount special tool 11 5 241 with special tool 11 5 242.

Pretension eccentric shaft (1) at hexagon head in direction of arrow.

Lock must snap audibly into place.

Install all bearing caps by numbers.

Tightening torque 11 31 4AZ. See CAMSHAFT .

Adjust valve timing.

Assemble engine.

11 31 036 Removing And Installing / Replacing Left Exhaust Camshaft (S85)

Special tools required

1. 11 5 241
2. 11 5 242
3. 11 5 243

Necessary preliminary tasks

1. Remove «left cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
2. Remove «left VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-030-removing-and-installing) .
3. Remove «left VANOS exhaust gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-144-removing-and-installing)

To remove and install the exhaust camshafts, special tool 11 5 243 is not required and must be removed from special tool 11 5 241.

Secure special tool 11 5 241 to cylinder head on left with special tool 11 5 242.

Pretension eccentric shaft (2) at hexagon head in direction of arrow.

Lock (1) must snap audibly into place.

Scheme 243

Release screws (1).

Tightening torque: 11 31 7AZ. See CAMSHAFT .

E Inlet camshaft.

A Exhaust camshaft.

Remove bearing caps.

Installation

Lubricate all bearing points with engine oil.

Release screws along lines (1).

Tightening torque 11 31 4AZ. See CAMSHAFT .

Installation

Lubricate all bearing points with engine oil.

Note. Illustration does not show special tool 11 5 241.

Scheme 244

Release lock (1) on special tool 11 5 241.

Relieve tension on eccentric shaft at hexagon head in direction of arrow.

Scheme 245

Insert exhaust camshaft, cylinders 6-10.

Designation (A 2) on dihedron points upwards.

Cams (1) on 6th cylinder point upwards.

Installation

Lubricate all bearing points with engine oil.

Scheme 246

Installation

All bearing shells are assigned to one cylinder.

E and A from (1 to 10), e.g. A 6= exhaust side on 6th cylinder.

Arrow (1) must point in direction of travel to chain drive.

Scheme 247

Installation

Arrangement of bearing shells, cylinders 6 to 10.

Mount special tool 11 5 241 with special tool 11 5 242.

Pretension eccentric shaft at hexagon head in direction of arrow.

Lock (1) must snap audibly into place.

Install all bearing caps by numbers.

Tightening torque 11 31 4AZ.. See CAMSHAFT .

Adjust valve timing.

Assemble engine.

11 31 038 Removing And Installing / Replacing Right Exhaust Camshaft (S85)

Special tools required

1. 11 5 241
2. 11 5 242
3. 11 5 243

Necessary preliminary tasks

1. Remove «right cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
2. Remove «right VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-040-removing-and-installing) .
3. Remove «right VANOS exhaust gear»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-150-removing-and-installing) .

To remove and install the exhaust camshafts, special tool 11 5 243 is not required and must be removed from special tool 11 5 241.

Secure special tool 11 5 241 to cylinder head on left with special tool 11 5 242.

Pretension eccentric shaft (2) at hexagon head in direction of arrow.

Lock (1) must snap audibly into place.

Scheme 248

Release screws (1).

Tightening torque: 11 31 4AZ. See CAMSHAFT .

E Inlet camshaft.

A Exhaust camshaft.

Remove bearing caps.

Scheme 249

Installation

Lubricate all bearing points with engine oil.

Release screws along lines (1).

Tightening torque: 11 31 4AZ. See CAMSHAFT .

Installation

Lubricate all bearing points with engine oil.

Note. Illustration does not show special tool 11 5 241.

Scheme 250

Release lock (1) on special tool 11 5 241.

Relieve tension on eccentric shaft at hexagon head in direction of arrow.

Insert exhaust camshaft, cylinders 1-5.

Designation (A 2) on dihedron points upwards.

Installation

Lubricate all bearing points with engine oil.

Scheme 251

Installation

All bearing shells are assigned to one cylinder.

E and A from (1 to 10), e.g. A 1= exhaust side on 1st cylinder.

Arrow (1) must point in direction of travel to chain drive.

Scheme 252

Installation

Arrangement of bearing shells, cylinders 1 to 5.

Mount special tool 11 5 241 with special tool 11 5 242.

Pretension eccentric shaft (1) at hexagon head in direction of arrow.

Lock must snap audibly into place.

Install all bearing caps by numbers.

Tightening torque 11 31 4AZ. See CAMSHAFT .

Adjust valve timing.

Assemble engine.

11 31 051 Replacing both timing chains (S85)

Necessary preliminary tasks

1. Remove cylinder head cover on «left»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) and «right»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
2. Remove «VANOS»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair) gear.
3. Remove «oil sump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
4. Remove «oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .
5. Remove «VANOS high-pressure pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-140-removing-and-installing) .
6. Remove «vibration damper»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-23-010-removing-and-installing) .
7. Remove «radial shaft seal at front»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-14-005-replacing-front-crankshaft) .

Release central screw (1). Remove gear (2) towards front.

Scheme 253

Remove special tool 11 5 352. Remove timing chain, cylinders 6 to 10, towards bottom.

Scheme 254

Remove special tool 11 5 351. Remove timing chain, cylinders 1 to 5, towards bottom.

Scheme 255

Note. Check tensioning and slide rails for wear, replace if necessary. Assemble engine.

11 31 072 Checking Camshaft Timing (S85)

Special tools required

1. 11 5 301
2. 11 5 302
3. 11 5 320

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove «left cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
3. Remove «right cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
4. Remove all spark plugs. See «12 12 011 REPLACING ALL SPARK PLUGS (S85)»(/bmw/m5/e60e61-2004-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair__12-12-011-replacing-all-spark) .

Note. Prepare special tools.

Screw (1) acts as a spacer and is only used to check the timing.

Insert screw (1) in special tools 11 5 301 / E 1-5 and 11 5 302 / E 6-10.

Scheme 256

Crank engine at central bolt until 1st cylinder firing TDC position appears on vibration damper.

Secure vibration damper in position with special tool 11 5 320.

Scheme 257

In camshaft position for cylinders 1-5, the designation E1 must be able to be read on the dihedron.

If necessary, crank engine at central bolt.

Scheme 258

In camshaft position for cylinders 6-10, the designation E2 must be able to be read on the dihedron.

If necessary, crank engine at central bolt.

Scheme 259

Position of camshaft in 1st cylinder firing TDC position.

The cams at the 1st cylinder on the inlet camshaft point upwards at an angle.

The cams at the 1st cylinder on the exhaust camshaft point to the exhaust side at an angle.

Designation E1 must be legible on dihedron (1).

Designation A1 is only legible from above in the 39° position.

Scheme 260

Position of camshaft firing TDC position 1st cylinder at cylinder 6-10.

The cams at the 6th cylinder of the inlet camshaft point downwards and open the engine valves.

The cams at the 6th cylinder of the exhaust camshaft point upwards at an angle.

Designation E2 must be legible on the dihedron (1).

Designation A2 is only legible from above in the 39° position.

Scheme 261

Attach special tool 11 5 301 E 1-5 with bolt (1) to inlet camshaft, 1st cylinder, at dihedron.

Note. The timing is correctly adjusted when special tools 11 5 301 and 11 5 302 rest flat on the cylinder head or protrude by up to 1.5 mm to the inlet and exhaust sides.

Scheme 262

Attach special tool 11 5 302 E 6-10 with bolt (1) to inlet camshaft, 6th cylinder, at dihedron.

Note. The timing is correctly adjusted when special tools 11 5 301 and 11 5 302 rest flat on the cylinder head or protrude by up to 1.5 mm to the inlet and exhaust sides.

Scheme 263

Crank engine at central bolt.

Secure special tool 11 5 320 to vibration damper (1) in the 39° position.

Scheme 264

Attach special tool 11 5 301 (A 1-5) to dihedron of exhaust camshaft, 1st cylinder.

Note. The timing is correctly adjusted when special tools 11 5 301 and 11 5 302 rest flat on the cylinder head or protrude by up to 1.5 mm to the inlet and exhaust sides.

Scheme 265

Attach special tool 11 5 302 (A 6-10) to dihedron of exhaust camshaft, 6th cylinder.

Note. The timing is correctly adjusted when special tools 11 5 301 and 11 5 302 rest flat on the cylinder head or protrude by up to 1.5 mm to the inlet and exhaust sides.

Scheme 266

Remove all special tools.

Assemble engine in reverse sequence to its disassembly.

11 31 094 Removing And Installing / Replacing Left Hydraulic Chain Tensioner (S85)

Necessary preliminary tasks

1. Remove «LEFT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) .
2. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
3. Unfasten «WIRING HARNESS SECTION FOR ENGINE»(/bmw/m5/e60e61-2004-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair__12-51-001-replacing-wiring-harness) and lay to one side.

Release chain tensioner (1).

Installation

Replace sealing ring.

Tightening torque 11 31 1AZ. See CAMSHAFT .

Scheme 267

Assemble engine.

11 31 095 Removing And Installing / Replacing Right Hydraulic Chain Tensioner (S85)

Necessary preliminary tasks

1. Remove air cleaner housing on right. See «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .

Release chain tensioner (1).

Installation

Replace sealing ring.

Tightening torque 11 31 1AZ. See CAMSHAFT .

Note. Illustration shows cylinders 6-10.

Assemble engine.

11 31 575 Adjusting Camshaft Timing (S85)

Special tools required

1. 11 3 302
2. 11 5 100
3. 11 5 301
4. 11 5 302
5. 11 5 320

Necessary preliminary tasks

1. Remove «left VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-030-removing-and-installing) .
2. Remove «right VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-040-removing-and-installing) .

Secure special tool 115 320 to vibration damper in 1st cylinder firing TDC position.

Position of inlet camshaft, cylinders 1-5.

Designation (E1) on dihedron points upwards.

Position of inlet camshaft, cylinders 6-10.

Designation (E2) on dihedron points upwards.

Rotate exhaust camshaft with open-end wrench (1) at hexagon head in direction of arrow until special tool A 11 5 301 can be attached.

Designation (A1) on dihedron points upwards.

Note. Exhaust VANOS gear (2) adjusted in direction of arrow (advance).

Scheme 268

Rotate exhaust camshaft at hexagon head with an open-end wrench (2) in direction of arrow until special tool A 11 3 302 can be attached.

Designation (A2) on dihedron points upwards.

Note. Exhaust VANOS gear (1) adjusted in direction of arrow (advance).

Scheme 269

Remove spacers (1) from special tools E 11 5 301 and E 11 5 302.

Attach cylinder (1-5) special tools A 11 5 301 and E 11 5 301, secure with bolts (2).

Scheme 270

Attach cylinder (6-10) special tools A 11 5 302 and E 11 5 302, secure with bolts (1).

Scheme 271

Release all hexagon socket screws with washers (1 and 2), cylinders 1-5 and 6-10.

Installation

Replace hexagon socket screws with washers (1 and 2).

Note. Illustration shows cyl. 6-10.

Scheme 272

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join hexagon socket screws with washers (3 and 4) to 5 Nm.

Installation

Release hexagon socket screws with washers again through 90°.

Scheme 273

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join hexagon socket screws with washers (3 and 4) to 5 Nm.

Installation

Release hexagon socket screws with washers again through 90°.

Scheme 274

Installation

Both thrust bearing plates (1) on the VANOS adjustment unit can be rotated.

Both thrust bearing plates (1) must be retracted.

Clean sealing surfaces.

Installation

Replace seal.

Scheme 275

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5.

Scheme 276

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 6-10.

Scheme 277

Insert seal.

Position VANOS adjustment unit (4) with both outer bolts (1).

Both VANOS gears (2) are extended.

Align thrust bearing plates (3).

Push VANOS adjustment unit (4) forwards until thrust bearing plates (3) rest against VANOS gears (2).

Installation

There is a visible gap of approx. 8 mm between VANOS adjustment unit and cylinder head.

Scheme 278

Insert hexagon socket screws without washers (1) and join.

Release hexagon socket screws without washers (1) through 90° again.

Screw in bolts (2) of VANOS adjustment unit uniformly in 1/2 turns.

Scheme 279

Installation

Both outer sleeves rotate clockwise and retract approx. 8 mm.

Both inner sleeves with elongated hole must rotate counterclockwise (see arrow).

The procedure is identical for cylinders 1-5 and 6-10.

Installation

Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Scheme 280

Installation

Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Scheme 281

Tighten down accessible hexagon socket screws of all camshafts at cylinders 1-5 and 6-10 with and without washers to 10 Nm.

Installation

Mark all screws which are already tightened down with a colored dot.

Scheme 282

Continue cranking engine at central bolt or with special tool 11 5 100 120° cms until further hexagon socket screws with and without washers can be inserted on the VANOS gear and tighten down to 10 Nm.

Note. First both the inlet camshafts are moved when the engine is cranked.

Both exhaust VANOS gears are moved in the direction of the arrow (retard stop).

Scheme 283

Check timing.

Assemble engine.

11 33 062 Removing And Installing / Replacing All HVCA (Hydraulic Valve Clearance Adjustment) Elements (S85)

Necessary preliminary tasks

1. Remove «left inlet camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-032-removing-and-installing) and «Right Inlet Camshaft»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-034-removing-and-installing) .
2. Remove exhaust camshaft. See «11 31 036 Removing And Installing / Replacing Left Exhaust Camshaft (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-036-removing-and-installing) and «11 31 038 Removing And Installing / Replacing Right Exhaust Camshaft (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-31-038-removing-and-installing)

Set HVCA elements (1) down in a clean and orderly manner.

Scheme 284

Remove HVCA element (1) in upward direction.

Installation

Turning lock (2) on cylinder head.

Scheme 285

Check surface (1) of HVCA element for damage.

Installation

Turning lock (2) on HVCA element.

Scheme 286

Installation

Check valve keys (1) for correct seating.

Check turning lock (2) on cylinder head for damage.

Scheme 287

Assemble engine.

11 34 552 Removing And Installing / Replacing All Valves (S85)

Special tools required

1. 11 5 281
2. 11 5 282
3. 11 5 283
4. 11 9 001
5. 11 9 006
6. 11 9 008
7. 11 9 009

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Remove cylinder head cover on «left»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) and «right»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
3. Remove cylinder head on left or right. See «11 12 105 Removing And Installing Left Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «11 12 106 Removing And Installing Right Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
4. Remove all spark plugs. See «12 12 011 REPLACING ALL SPARK PLUGS (S85)»(/bmw/m5/e60e61-2004-2010/remont/gauges-instrument-panels/#engine-electrical-system-repair__12-12-011-replacing-all-spark) .
5. If necessary, remove and install «engine»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-050-removing-and-installing) .

Note. Place cylinder head (1) on special tool 11 9 001.

Prepare special tool 11 9 006 with special tool 11 9 008.

Scheme 288

Insert aluminum profile rail (1) and align.

Secure eccentric clamping levers (2 and 3).

Scheme 289

Special tool 11 5 281 for removing valve keys.

Special tool 11 5 282 for installing valve keys.

Special tool 11 5 283 for securing valve keys.

Scheme 290

Adjust special tool 11 9 009 so that special tool 11 5 281 can press vertically onto the valve spring.

Scheme 291

Note. Special tool 11 5 281 incorporates a lever (1) which is tensioned with a spring.

Press down valve spring with special tool 11 9 009 and keep pressed.

Pretension lever (1) in direction of arrow.

Release lever (1) in tensioned position.

The valve keys still installed are thus forced out and drop into the working chamber of special tool 11 5 281.

Repeat the operation several times if necessary until all the valve keys are forced out.

Pull back lever on special tool 11 5 281.

Valve keys (1) can now be ejected from the working chamber (2).

Scheme 292

Scheme 293

Remove special tool 11 9 006.

All the engine valves are now accessible.

Installation

Set the engine valves down in neat and tidy order if they are to be reused.

Check valve seat for damage.

Press valve key (1) in direction of arrow into special tool 11 5 283.

Scheme 294

Secure valve keys (1).

Scheme 295

Press valve keys into special tool 11 5 282 with special tool 11 5 283.

Scheme 296

Press valve keys in direction of arrow into special tool 11 5 282 with special tool 11 5 283.

Scheme 297

Make sure valve keys (1) are correctly positioned.

Special tool 11 5 282 is prepared.

Scheme 298

Press down special tool 11 5 282 with special tool 11 9 009 in direction of arrow.

Installation

Both valve keys are now pressed into their initial positions.

Check that valve keys are in correct installation position.

Scheme 299

Installation

Check that valve keys are in correct installation position.

Assemble engine.

11 34 560 Replacing All Valve Stem Seals (S85)

Special tools required

1. 11 1 480
2. 11 5 270

Necessary preliminary tasks

1. Remove cylinder head. See «11 12 105 Removing And Installing Left Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «11 12 106 Removing And Installing Right Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
2. Remove all valve springs.

Remove valve stem seal with special tool 11 1 480 in direction of arrow.

Scheme 300

Installation

Attach the mounting sleeve (1) supplied with the new part to the valve stem.

Scheme 301

Attach valve stem seal (2) over mounting sleeve (1).

Scheme 302

Press on valve stem seal with special tool 11 5 270 in direction of arrow as far as it will go.

Scheme 303

Assemble engine.

11 34 715 Replacing All Valve Springs (S85)

Special tools required

1. 11 5 281
2. 11 5 282
3. 11 5 283
4. 11 9 001
5. 11 9 006
6. 11 9 008
7. 11 9 009

Necessary preliminary tasks

1. Remove cylinder head. See «11 12 105 Removing And Installing Left Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-105-removing-and-installing) or «11 12 106 Removing And Installing Right Cylinder Head (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-106-removing-and-installing) .
2. Remove all «HVCA»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-33-062-removing-and-installing) elements.

Note. Place cylinder head (1) with cylinder head bolts on special tool 11 9 001.

Prepare special tool 11 9 006 with special tool 11 9 008.

Insert aluminum profile rail (1) and align.

Secure eccentric clamping levers (2 and 3) in direction of arrow.

Special tool 11 5 281 for removing valve keys.

Special tool 11 5 282 for installing valve keys.

Special tool 11 5 283 for securing valve keys.

Adjust special tool 11 9 009 so that special tool 11 5 281 can press vertically onto the valve spring.

Note. Lever (1) on special tool 11 5 281 is tensioned with a spring.

Press down valve spring with special tool 11 5 281 and keep pressed.

Pretension lever (1) in direction of arrow.

Release lever (1) in tensioned position.

The valve keys still installed are thus forced out and drop into the working chamber of special tool 11 5 281.

Repeat the operation several times if necessary until all the valve keys are forced out.

Pull back lever on special tool 11 5 281.

Valve keys (1) can now be ejected from the working chamber (2).

Note. Lower spring plate (1). Progressive valve spring (2). Upper spring plate (3).

Installation

Incorrect installation is not possible.

Scheme 304

Insert lower spring plate (1).

Scheme 305

Press valve key (1) in direction of arrow into special tool 11 5 283.

Secure valve keys (1).

Press valve keys into special tool 11 5 282 with special tool 11 5 283.

Press valve keys into special tool 11 5 282 with special tool 11 5 283.

Special tool 11 5 282 is prepared for installation.

Installation

Positioning of valve keys (1).

Press down special tool 11 5 282 with special tool 11 9 009 in direction of arrow.

Installation

Both valve keys are now pressed into their initial positions.

Installation

Check that valve keys (1) are in correct installation position.

Assemble engine.

11 36 030 Removing And Installing / Replacing Left VANOS Adjustment Unit (S85)

Special tools required

1. 11 5 100

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Remove «right cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing) .
3. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
4. Detach «oil line from VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-109-removing-and-installingreplacing) .
5. Remove coolant hose from radiator inlet on right.

If the 6 hexagon socket screws with washers are released by mistake, it will be necessary to readjust the timing.

Scheme 306

Release screws (1).

Crank engine at central bolt until 6 hexagon socket screws of the adjustment unit have been released.

Remove coolant pipe (3).

Release screws (1).

Unfasten screws (2).

Remove VANOS adjustment unit towards front.

Installation

Replace seal (1).

Scheme 307

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5 or 6-10.

Check thrust bearing plates (1) for ease of movement before installing.

Clean sealing surface (2).

Installation

Replace seal.

Insert screws (2).

Insert hexagon socket screws (1) without washers and secure to 10 Nm.

Installation

Mark all screws which are already tightened down with a colored dot.

Continue cranking engine at central bolt or with special tool 11 5 100 through 120° until further hexagon socket screws without washers can be inserted on the VANOS gear.

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Perform VANOS test.

11 36 040 Removing And Installing / Replacing Right VANOS Adjustment Unit (S85)

Special tools required

1. 11 5 100
2. 11 5 320

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Remove «right cylinder head cover»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-12-005-removing-and-installing)
3. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
4. Detach «oil line from VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-109-removing-and-installingreplacing) .
5. Remove coolant hose from radiator inlet on right.

If the 6 hexagon socket screws with washers are released by mistake, it will be necessary to readjust the timing.

Note. Illustration shows 6 to 10.

Release hexagon socket screws without washers (1).

Crank engine at central bolt until 6 hexagon socket screws of the adjustment unit have been released.

Release bolts (1).

Release screws (2).

Remove VANOS adjustment unit towards front.

Installation

Replace seal (1).

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5 or 6-10.

Check thrust bearing plates (1) for ease of movement before installing.

Clean sealing surface (2).

Insert screws (2).

Insert hexagon socket screws (1) without washers.

Continue cranking engine at central bolt or with special tool 11 5 100 through 120° until further hexagon socket screws without washers can be inserted on the VANOS gear.

Tighten all hexagon socket screws without washers (1) to 10 Nm.

Installation

Mark all hexagon socket screws which are already tightened down with a colored dot.

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 36 109 Removing And Installing/Replacing VANOS High-Pressure Oil Line (S85)

Necessary preliminary tasks

1. Remove «drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) from A/C compressor.
2. Remove «drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) from alternator.
3. Release power steering pump (do not remove). See «32 41 060 REMOVING AND INSTALLING/REPLACING VANE PUMP FOR POWER STEERING (M5)»(/bmw/m5/e60e61-2004-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-41-060-removing-and-installingreplacing) or «32 41 060 REMOVING AND INSTALLING/REPLACING VANE PUMP FOR POWER STEERING (M6)»(ref-263480-S13040393342007090700000) .
4. Detach water hoses on right.
5. Remove «oil pan»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
6. Remove «oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .
7. Remove «VANOS high-pressure pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-140-removing-and-installing) .

Only release bolts (2) on water pump bracket.

Release banjo bolt (1).

Tightening torque: 11 36 5AZ. See 36 VARIABLE CAMSHAFT TIMING .

Scheme 308

Release bolt (1).

Remove high-pressure line (2) towards top.

Scheme 309

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 36 140 Removing And Installing / Replacing VANOS High-Pressure Pump (S85)

Special tools required

1. 11 4 350
2. 11 6251
3. 11 6 252
4. 11 6 254

Necessary preliminary tasks

1. Remove «engine oil sump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
2. Remove «oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .

Release banjo bolt (1).

Tightening torque 11 36 4AZ. See 36 VARIABLE CAMSHAFT TIMING .

Release screws (2).

Remove VANOS high-pressure pump (3).

Scheme 310

Note. Engine installed.

Secure piston (1) against falling out; remove if necessary.

Check adapter sleeve (2) for damage and secure seating; replace if necessary.

Scheme 311

Installation

Arrangement, chain tensioner, oil pump.

1. Base valve
2. Spring
3. Piston

Scheme 312

Installation

Replace fine-mesh strainer.

Remove fine-mesh strainer (1) with screwdriver in direction of arrow.

Check adapter sleeve (2) for damage and secure seating; replace if necessary.

Scheme 313

Remove and fine-mesh strainer (1) in direction of arrow.

Clean sealing surface (2).

Installation

Replace fine-mesh strainer.

Scheme 314

Check gear wheel (1) and sprocket wheel for damage, replace if necessary.

Release bolts (7).

Tightening torque 11 36 7AZ. See 36 VARIABLE CAMSHAFT TIMING .

Release screw (2).

Check sliding rail (3) for damage; replace if necessary.

Check timing chain (4) for damage; replace if necessary.

Release bolt (6).

Check tensioning rail (5) for damage; replace if necessary.

Scheme 315

Replacing gearwheels

Necessary preliminary tasks

1. Remove vibration damper.
2. Remove radial shaft seal at front.

Clamping rail (1) of oil pump with visible sleeve (see arrow).

It is not necessary to measure the oil pump chain.

Scheme 316

Clamping rail (1) of oil pump without visible sleeve (see arrow).

On the VANOS high-pressure pump up to 12/05, it is necessary to check the pretension on the oil pump chain.

Scheme 317

Tie back VANOS high-pressure line (2) with cable tie (1).

Install spacer plate (3).

Install spacer (4).

Scheme 318

Position VANOS high-pressure pump (3) on crankcase.

Insert screws (2).

Slide VANOS high-pressure pump in direction of crankshaft until gearwheel (3) has slight play.

Initially tighten VANOS high-pressure pump with special tool 11 4 350 to 2 Nm.

Mount special tool 11 6 254 on crankcase.

Secure special tool 11 6 252 with magnetic base to special tool 11 6 254.

Scheme 319

Align special tool 11 6 251 with its measuring shaft (2) vertically to gearwheel (1).

Rotate high-pressure pump gearwheel (1) up to stop.

Set special tool 11 6 251 to zero.

Scheme 320

Rotate high-pressure pump gearwheel in direction of arrow up to stop.

Scheme 321

Backlash at high-pressure pump min. 0.06 to max. 0.08 mm.

If necessary, correct VANOS high-pressure pump adjustment.

Adjustment of VANOS high-pressure pump (2) with a rubber mallet on pump housing.

Tightening torque 11 36 8AZ. See 36 VARIABLE CAMSHAFT TIMING .

Scheme 322

Installation

Replace all sealing rings.

Install banjo bolt (1).

Tightening torque 11 36 4AZ. See 36 VARIABLE CAMSHAFT TIMING .

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 36 142 Removing And Installing / Replacing Left Inlet VANOS Gear (S85)

Special tools required

1. 11 3 302
2. 11 5 100
3. 11 5 291
4. 11 5 292
5. 11 5 302
6. 11 5 320
7. 11 5 352
8. 11 5 370
9. 11 5 381
10. 11 5 382
11. 11 5 410

Necessary preliminary tasks

1. Remove «left VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-030-removing-and-installing) .

Position of inlet camshaft, cylinders 6-10.

Designation (E2) on dihedron points upwards.

Rotate exhaust camshaft at hexagon head with an open-end wrench (2) in direction of arrow until special tool A 11 3 302 can be attached.

Designation (A2) on dihedron points upwards.

Note. Exhaust VANOS gear (1) adjusted in direction of arrow (advance).

Disconnect inlet and exhaust camshafts.

Attach special tool A 11 5 302.

Attach special tool E 11 5 302 and secure with bolts (1).

Insert M8x18 hexagon socket screw (1) into exhaust VANOS gear.

Scheme 323

Installation

If the hexagon socket screw is released or forgotten by mistake, the gear teeth can be readjusted with special tool 11 5 370.

Screw in special tool 11 5 370 until gearwheel (1) lines up with bore (see arrow) on thread.

Failure to tension the exhaust VANOS gear will result in rattling noises at idle.

Scheme 324

Release hexagon socket screws with washers (1 and 2).

Installation

Replace hexagon socket screws with washers (1 and 2).

Scheme 325

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join hexagon socket screws with washers (3 and 4) to 5 Nm.

Remove left chain tensioner.

Installation

Replace sealing ring.

Tightening torque: 11 31 1AZ. See 31 CAMSHAFT

Remove screw plug for chain rail on left cylinder head.

Installation

Replace sealing ring.

Tightening torque 11 12 9AZ. See CYLINDER HEAD WITH COVER .

Insert special tool 11 5 291.

Secure bearing pin against falling out with special tool 11 5 292.

Scheme 326

Attach special tool 11 5 382.

Fit special tool 11 5 410 with bolts (3).

Note. If the special tool 11 5 410 cannot be fitted due to the hexagon socket screws being unfavorably positioned, it is necessary to remove the two or if necessary four hexagon socket screws.

Release central bolts (1 and 2).

Remove special tool 11 5 410

Scheme 327

Note. If the central bolt is released, the removed hexagon socket screws are reinstalled with a joining torque of 5 Nm.

Installation

Replace central bolts (1 and 2).

Installation

If the VANOS gear is to be reused, the special tool 11 5 382 must not be removed.

VANOS gear is tensioned.

Tilt special tool 11 5 382 in direction of arrow.

If the VANOS gear is to be replaced by a new part, the special tool 11 5 382 can be removed.

Remove VANOS gear with special tool 11 5 382.

Scheme 328

Installation

If the VANOS gear is to be reused, the special tool 11 5 381 must not be removed.

VANOS gear is tensioned.

Set down VANOS gear (1) with special tool (2).

Scheme 329

Remove both VANOS gears.

Insert special tool 11 5 352 into chain drive.

Press sliding rails (1) together.

Pretension timing chain with special tool 11 5 352.

Scheme 330

Installation

Position inlet VANOS gear (1) so that one of the three screws with washers points downwards.

Position exhaust VANOS gear (2) so that one of the three screws with washers points downwards.

M8x18 hexagon socket screw points upwards.

Check that timing chain is in correct installation position.

Insert central bolts (1 and 2) without play.

Installation

Replace central bolts (1 and 2).

Scheme 331

Insert bearing pin with special tool 11 5 291 into sliding rail.

Remove special tools 11 5 291 and 11 5 292.

Install screw plug for chain rail on right cylinder head.

Installation

Replace sealing ring.

Tightening torque 11 12 9AZ. See ENGINE - TIGHTENING TORQUES .

Insert chain tensioner with sealing ring.

Tightening torque 11 31 1AZ. See CAMSHAFT .

Scheme 332

Insert special tool 11 5 382 between outer sleeve and gearwheel.

Fit special tool 11 5 410.

Remove M8x18 hexagon socket screw or special tool 11 5 370.

Tighten central bolts (1 and 2).

Tightening torque 11 36 1AZ. See ENGINE - TIGHTENING TORQUES .

Scheme 333

Remove special tools 11 5 382 and 11 5 410.

Release hexagon socket screws with washers (1 and 2) through 90°.

Installation

Both thrust bearing plates (1) on the VANOS adjustment unit can be rotated.

Both thrust bearing plates (1) must be retracted.

Clean sealing surface (2).

Replace seal.

Installation

VANOS adjustment unit is marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5 or 6-10.

Insert seal.

Position VANOS adjustment unit (4) with both outer bolts (1).

Both VANOS gears (2) are extended.

Align thrust bearing plates (3).

Push VANOS adjustment unit forwards until thrust bearing plates (3) rest against VANOS gears (2).

Installation

There is a visible gap of approx. 8 mm between VANOS adjustment unit and cylinder head.

Note. Illustration shows cyl. 1 to 5.

Insert hexagon socket screws without washers (1) and join.

Release hexagon socket screws without washers (1) through 90° again.

Screw in bolts (2) of VANOS adjustment unit uniformly in 1/2 turns.

Installation

Both outer sleeves rotate clockwise and retract approx. 8 mm.

Both inner sleeves with elongated hole must rotate counterclockwise (see arrow).

Note. Illustration shows cyl. 1 to 5.

Installation

Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Tighten down hexagon socket screws with and without washers to 10 Nm.

Installation

Mark all hexagon socket screws which are already tightened down with a colored dot.

Note. Illustration shows cyl. 1 to 5.

Continue cranking engine at central bolt or with special tool 11 5 100 120° cms until further hexagon sockets screws can be inserted on the VANOS gear and tighten to 10 Nm.

Note. First both the inlet camshafts are moved when the engine is cranked.

Both exhaust VANOS camshafts are moved in the direction of the arrow (retard stop).

Illustration shows cyl. 1 to 5.

Check timing.

Assemble engine.

11 36 144 Removing And Installing / Replacing Left Exhaust VANOS Gear (S85)

Special tools required

1. 11 5 100
2. 11 5 302
3. 11 5 320
4. 11 5 370
5. 11 5 382
6. 11 5 410

Necessary preliminary tasks

1. Remove «left VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-030-removing-and-installing) .

Secure special tool 11 5 320 to vibration damper in 1st cylinder firing TDC position.

Position of camshafts, cyl. 6-10, in 1st cylinder firing TDC position.

Dihedron of camshafts is vertical to cylinder axis, lettering of camshaft points upwards (E2).

Rotate exhaust camshaft at hexagon head with an open-end wrench (2) in direction of arrow until special tool A 11 5 302 can be attached.

Designation (A2) on dihedron points upwards.

Note. Exhaust VANOS gear (1) adjusted in direction of arrow.

Disconnect inlet and exhaust camshafts.

Note. Rotate exhaust camshaft at hexagon head, attach special tool A 11 5 302.

Attach special tool E 11 5 302 and secure with bolts (1).

Insert M8x18 hexagon socket screw (1) into VANOS gear.

Installation

If the hexagon socket screw is released or forgotten by mistake, the gear teeth can be readjusted with special tool 11 5 370.

Screw in special tool 11 5 370 until gearwheel (1) lines up with bore (see arrow) on thread.

Failure to tension the VANOS gear will result in rattling noises at idle.

Release hexagon socket screws with washers (1 and 2).

Installation

Replace hexagon socket screws with washers (3 and 4).

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join hexagon socket screws with washers (3 and 4) to 5 Nm

Attach special tool 11 5 382.

Fit special tool 11 5 410 with bolts (3).

Note. If the special tool 11 5 410 cannot be fitted due to the hexagon socket screws being unfavorably positioned, it is necessary to remove the two or if necessary four hexagon socket screws.

Release central bolts (2).

Remove special tool 11 5 410.

Note. If the central bolt is released, the removed hexagon socket screws are reinstalled with a joining torque of 5 Nm.

Installation

Replace central bolt (2).

Installation

If the VANOS gear is to be reused, the special tool 11 5 382 must not be removed.

VANOS gear is tensioned.

Tilt special tool 11 5 382 in direction of arrow.

If the VANOS gear is to be replaced by a new part, the special tool 11 5 382 can be removed.

Remove VANOS gear with special tool 11 5 382.

Installation

If the VANOS gear is to be reused, the special tool 11 5 382 must not be removed.

VANOS gear is tensioned.

Set down VANOS gear (1) with special tool (2).

Install exhaust VANOS gear (2) in position.

Installation

M8x18 hexagon socket screw points upwards.

One of the three screws points downwards.

Insert central bolt, join slightly and then release again through 90°.

Remove M8x18 hexagon socket screw or special tool 11 5 370.

Insert special tool 11 5 382 between outer sleeve and gearwheel.

Fit special tool 11 5 410.

Tighten central bolt (2).

Tightening torque 11 36 1AZ. See ENGINE - TIGHTENING TORQUES .

Remove special tools 11 5 410 and 11 5 382.

Release hexagon socket screws with washers (1 and 2) through 90°.

Installation

Both thrust bearing plates (1) on the VANOS adjustment unit can be rotated.

Both thrust bearing plates (1) must be retracted.

Clean sealing surface (2).

Replace seal.

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5 or 6-10.

Insert seal.

Position VANOS adjustment unit (4) with both outer bolts (1).

Both VANOS gears (2) are extended.

Align thrust bearing plates (3).

Push VANOS adjustment unit (4) forwards until thrust bearing plates (3) rest against VANOS gears (2).

Installation

There is a visible gap of approx. 8 mm between VANOS adjustment unit and cylinder head.

Note. Illustration shows cyl. 1 to 5.

Insert hexagon socket screws (1) without washers and join to 5 Nm.

Release hexagon socket screws (1) without washers through 90° again.

Screw in bolts (2) of VANOS adjustment unit uniformly in 1/2 turns.

Installation

Both outer sleeves rotate clockwise and retract approx. 8 mm.

Both inner sleeves with elongated hole must rotate counterclockwise (see arrow).

Installation

Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Tighten down hexagon socket screws with and without washers to 10 Nm.

Installation

Mark all screws which are already tightened down with a colored dot.

Note. Illustration shows cyl. 1-5.

Continue cranking engine at central bolt or with special tool 11 5 100 120° cms until further hexagon sockets screws can be inserted on the VANOS gear and tighten to 10 Nm.

Note. First both the inlet camshafts are moved when the engine is cranked.

Both exhaust camshaft gears are moved in the direction of the arrow (retard stop).

Check timing.

Assemble engine.

11 36 148 Removing And Installing / Replacing Right Inlet VANOS Gear (S85)

Special tools required

1. 11 5 100
2. 11 5 291
3. 11 5 292
4. 11 5 301
5. 11 5 320
6. 11 5 351
7. 11 5 370
8. 11 5 381
9. 11 5 410

Necessary preliminary tasks

1. Remove «right VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-040-removing-and-installing) .

Secure special tool 11 5 320 to vibration damper in 1st cylinder firing TDC position.

Position of inlet camshaft, cylinders 1-5.

Designation (E1) on dihedron points upwards.

Rotate exhaust camshaft with open-end wrench (1) at hexagon head in direction of arrow until special tool A 11 5 301 can be attached.

Designation (A1) on dihedron points upwards.

Note. Exhaust VANOS gear (2) adjusted in direction of arrow (advance).

Disconnect inlet and exhaust camshafts.

Attach special tool A 11 5 301.

Attach special tool E 11 5 301 and secure with bolts (2).

Insert M8x18 hexagon socket screw (2) into exhaust VANOS gear.

Scheme 334

Installation

If the hexagon socket screw is released or forgotten by mistake, the gear teeth can be readjusted with special tool 11 5 370.

Screw in special tool 11 5 370 until gearwheel (1) lines up with bore (see arrow) on thread.

Failure to tension the exhaust VANOS gear (1) will result in rattling noises at idle.

Release all hexagon socket screws with washers (1 and 2).

Installation

Replace hexagon socket screws with washers (1 and 2).

Note. Illustration shows cyl. 6-10.

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join hexagon socket screws with washers (3 and 4) to 5 Nm.

Remove right chain tensioner.

Installation

Replace sealing ring.

Tightening torque: 11 31 1AZ. See 11 31 CAMSHAFT .

Note. Illustration shows cyl. 6-10.

Remove screw plug for chain rail on right cylinder head.

Installation

Replace sealing ring.

Tightening torque 11 12 9AZ. See ENGINE - TIGHTENING TORQUES .

Insert special tool 11 5 291.

Secure bearing pin against falling out with special tool 11 5 292.

Scheme 335

Attach special tool 11 5 381.

Fit special tool 11 5 410 with bolts (3).

Note. If the special tool 11 5 410 cannot be fitted due to the hexagon socket screws being unfavorably positioned, it is necessary to remove the two or if necessary four hexagon socket screws.

Release central bolts (1 and 2).

Remove special tool 11 5 410.

Note. If the central bolt is released, the removed hexagon socket screws are reinstalled with a joining torque of 5 Nm.

Installation

Replace central bolts (1 and 2).

Scheme 336

Installation

If the VANOS gear is to be reused, the special tool 11 5 381 must not be removed.

VANOS gear is tensioned.

Tilt special tool 11 5 381 in direction of arrow.

If the VANOS gear is to be replaced by a new part, the special tool 11 5 381 can be removed.

Remove VANOS gear with special tool 11 5 381.

Scheme 337

Installation

If the VANOS gear is to be reused, the special tool 11 5 381 must not be removed.

VANOS gear is tensioned.

Set down VANOS gear (1) with special tool (2).

Remove both VANOS gears.

Insert special tool 11 5 351 into chain drive.

Press sliding rails (1) together.

Pretension timing chain with special tool 11 5 351.

Scheme 338

Installation

Position inlet VANOS gear (2) so that one of the three screws with washers points downwards.

Position exhaust VANOS gear (1) so that one of the three screws with washers points downwards.

M8x18 hexagon socket screw points upwards.

Check that timing chain is in correct installation position.

Insert central bolts (1 and 2) without play.

Installation

Replace central bolts (1 and 2).

Scheme 339

Insert bearing pin with special tool 11 5 291 into sliding rail.

Tightening torque 11 31 2AZ. See 11 31 CAMSHAFT .

Remove special tools 11 5 291 and 11 5 292.

Install screw plug for chain rail on right cylinder head.

Installation: Replace sealing ring.

Tightening torque: 11 12 9AZ. See 11 12 CYLINDER HEAD WITH COVER .

Insert chain tensioner with sealing ring. Tightening torque: 11 31 1AZ. See 11 31 CAMSHAFT .

Note. Illustration shows cyl. 6-10.

If necessary, remove transportation lock from VANOS gear. Insert special tool 11 5 381 between outer sleeve and gearwheel. Fit special tool 11 5 410. Remove M8x18 hexagon socket screw or special tool 11 5 370.

Tighten central bolts (1 and 2). Tightening torque: 11 36 1AZ. See 11 36 VARIABLE CAMSHAFT CONTROL .

Scheme 340

Remove special tools 11 5 381 and 11 5 410. Release hexagon socket screws with washers (1 and 2) through 90°.

Scheme 341

Installation: Both thrust bearing plates (1) on the VANOS adjustment unit can be rotated. Both thrust bearing plates (1) must be retracted. Clean sealing surface (2). Replace seal.

Installation: VANOS adjustment unit is marked to avoid being mixed up. The lettering EIN (1) must point to the inlet camshaft. Cylinder assignment (2), cyl. 1-5 or 6-10.

Insert seal. Position VANOS adjustment unit (4) with both outer bolts (1). Both VANOS gears (2) are extended. Align thrust bearing plates (3). Push VANOS adjustment unit forwards until thrust bearing plates (3) rest against VANOS gears (2).

Installation: There is a visible gap of approx. 8 mm between VANOS adjustment unit and cylinder head.

Insert hexagon socket screws without washers (1) and join. Release screws without washers (1) through 90° again.

Screw in bolts (2) of VANOS adjustment unit uniformly in 1/2 turns.

Installation: Both outer sleeves rotate clockwise and retract approx. 8 mm. Both inner sleeves with elongated hole must rotate counterclockwise (see arrow).

Installation: Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Tighten down hexagon socket screws with and without washers to 10 Nm.

Installation: Mark all screws which are already tightened down with a colored dot.

Continue cranking engine at hexagon head or with special tool 11 5 100 120° camshaft until further hexagon sockets screws can be inserted on the VANOS gear and tighten to 10 Nm.

Note. First both the inlet camshafts are moved when the engine is cranked. Both exhaust VANOS camshafts are moved in the direction of the arrow (retard stop). Illustration shows cyl. 1 to 5.

Check timing. Assemble engine.

11 36 150 Removing And Installing / Replacing Right Exhaust VANOS Gear (S85)

Special tools required

1. 11 5 100
2. 11 5 301
3. 11 5 320
4. 11 5 370
5. 11 5 381
6. 11 5 410

Necessary preliminary tasks

1. Remove «right VANOS adjustment unit»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-36-040-removing-and-installing) .

Secure special tool 11 5 320 to vibration damper in 1st cylinder firing TDC position.

Position of camshafts, cyl. 1-5, in 1st cylinder firing TDC position.

Dihedron of camshafts is vertical to cylinder axis, lettering of camshaft points upwards (E1).

Rotate exhaust camshaft with open-end wrench (1) at hexagon head in direction of arrow until special tool A 11 5 301 can be attached.

Designation (A1) on dihedron points upwards.

Note. Exhaust VANOS gear (2) adjusted in direction of arrow (advance).

Disconnect inlet and exhaust camshafts.

Attach special tool A 11 5 301.

Attach special tool E 11 5 301 and secure with bolts (2).

Insert M8x18 hexagon socket screw (2) into exhaust VANOS gear.

Installation

If the hexagon socket screw is released or forgotten by mistake, the gear teeth can be readjusted with special tool 11 5 370.

Screw in knurled screw on special tool 11 5 370 until gearwheel (1) lines up with bore (see arrow) on thread.

Failure to tension the exhaust VANOS gear (1) will result in rattling noises at idle.

Release hexagon socket screws with washers (1 and 2).

Installation

Replace hexagon socket screws with washers (1 and 2).

Illustration shows cyl. 6-10.

Pull VANOS gear with outer sleeve forwards until inner sleeves (1 and 2) with elongated holes are at left stop.

Join screws (3 and 4) to 5 Nm.

Attach special tool 11 5 381.

Fit special tool 11 5 410 with bolts (3).

Note. If the special tool 11 5 410 cannot be fitted due to the hexagon socket screws being unfavorably positioned, it is necessary to remove the two or if necessary four hexagon socket screws.

Release central bolt (1).

Remove special tool 11 5 410.

Note. If the central bolt is released, the removed hexagon socket screws are reinstalled with a joining torque of 5 Nm.

Installation

Replace central bolt (1).

Installation

If the VANOS gear is to be reused, the special tool 11 5 381 must not be removed.

VANOS gear is tensioned.

Tilt special tool 11 5 381 in direction of arrow.

If the VANOS gear is to be replaced by a new part, the special tool 11 5 381 can be removed.

Remove VANOS gear with special tool 11 5 381.

Installation

If the VANOS gear is to be reused, the special tool 11 5 381 must not be removed.

VANOS gear is tensioned.

Set down VANOS gear (1) with special tool (2).

Install exhaust VANOS gear (1) in position.

Installation

M8x18 hexagon socket screw points upwards.

One of the three screws points downwards.

Insert central bolt, join slightly and then release again through 90°.

Remove M8x18 hexagon socket screw or special tool 11 5 370.

Insert special tool 11 5 381 between outer sleeve and gearwheel.

Fit special tool 11 5 410.

Tighten central bolt (1).

Tightening torque 11 36 1AZ. See 11 36 VARIABLE CAMSHAFT CONTROL .

Remove special tools 11 5 410 and 11 5 381.

Release hexagon socket screws with washers (1 and 2) through 90°.

Installation

Both thrust bearing plates (1) on the VANOS adjustment unit can be rotated.

Both thrust bearing plates (1) must be retracted.

Clean sealing faces (2).

Replace seal.

Installation

VANOS adjustment units are marked to avoid being mixed up.

The lettering EIN (1) must point to the inlet camshaft.

Cylinder assignment (2), cyl. 1-5 or 6-10.

Insert seal.

Position VANOS adjustment unit (4) with both outer bolts (1).

Both VANOS gears (2) are extended.

Align thrust bearing plates (3).

Push VANOS adjustment unit (4) forwards until thrust bearing plates (3) rest against VANOS gears (2).

Installation

There is a visible gap of approx. 8 mm between VANOS adjustment unit (4) and cylinder head.

Insert hexagon socket screws without washers (1) and join to 5 Nm.

Release hexagon socket screws without washers (1) through 90° again.

Screw in bolts (2) of VANOS adjustment unit uniformly in 1/2 turns.

Installation

Both outer sleeves rotate clockwise and retract approx. 8 mm.

Both inner sleeves with elongated hole must rotate counterclockwise (see arrow).

Installation

Check seal for correct seating.

Secure VANOS adjustment unit with screws (1 and 2).

Tighten down hexagon socket screws with and without washers to 10 Nm.

Installation

Mark all screws which are already tightened down with a colored dot.

Continue cranking engine at central bolt or with special tool 11 5 100 120° cms until further hexagon sockets screws can be inserted on the VANOS gear and tighten to 10 Nm.

Note. First both the inlet camshafts are moved when the engine is cranked.

Both exhaust camshaft gears are moved in the direction of the arrow (retard stop).

Check timing.

Assemble engine.

11 36 512 Checking Oil Pressure Of VANOS Adjustment Unit (S85)

Special tools required

1. 11 5 361
2. 11 5 362
3. 11 5 363
4. 11 5 364

Necessary preliminary tasks

1. Run engine up to normal operating temperature.
2. Connect diagnosis tester.
3. Work through "VANOS control pressure banks 1 and 2" test module.
4. All setpoint values are stored in the test module.

VANOS oil pressure measurement can be carried out exclusively with the Group Tester One (GT1) in conjunction with the Measurement Interface Box (MIB).

Note. Measurement at central line (VANOS oil pressure).

Release banjo bolt (1).

Tightening torque: 11 36 2AZ. See 11 36 VARIABLE CAMSHAFT CONTROL .

Installation

Replace all sealing rings.

Scheme 342

Screw in special tool 11 5 361 with ring connection.

Tightening torque 11 36 2AZ. See 11 36 VARIABLE CAMSHAFT CONTROL .

Secure special tool 11 5 364 at ring connection to 25 Nm.

Screw down (400 bar) pressure sensor (1) at special tool 11 5 364 to 25 Nm.

Installation

New sealing rings must be used between the pressure lines and the ring connection.

Note. Illustration shows intake air manifold removed.

Follow diagnosis instructions.

Scheme 343

Note. Selective bank (1 and 2) measurement

Follow diagnosis instructions.

Disconnect VANOS high-pressure line from cylinder head.

Screw in special tool 11 5 362 with sealing ring on cylinder head.

Tighten special tool 11 5 362 to 25 Nm.

Bolt banjo bolt (1) with VANOS high-pressure line to special tool 11 5 363.

Tightening torque 11 36 2AZ.. See 11 36 VARIABLE CAMSHAFT CONTROL .

Scheme 344

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this can result in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 36 715 Removing And Installing / Replacing Solenoid Valves On Left VANOS Adjustment Unit (S85)

Special tools required

1. 11 5 400

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove coolant hose from radiator inlet.

Disconnect plug connection (3).

Plug connections (3) for inlet and exhaust solenoid valves are identified with flags on the wiring harness.

Solenoid valve (1), inlet adjustment.

Solenoid valve (2), exhaust adjustment.

Scheme 345

Release screw connection on solenoid valve with special tool 11 5 400.

Scheme 346

Installation

Sealing rings (1) cannot be replaced.

If one of the sealing rings (1) is damaged, the solenoid valve must be replaced.

Lightly lubricate sealing rings (1) with engine oil.

Scheme 347

Installation

Replace sealing ring (1).

Secure sealing ring (1) in groove; if necessary, secure against falling out with grease.

Scheme 348

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 36 720 Removing And Installing / Replacing Solenoid Valves On Right VANOS Adjustment Unit (S85)

Special tools required

1. 11 5 400

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove coolant hose from radiator inlet.

Disconnect plug connection (1) on solenoid valve for exhaust adjustment.

Disconnect plug connection (2) on solenoid valve for inlet adjustment.

Plug connections (1 and 2) for inlet and exhaust solenoid valves are identified with flags on the wiring harness.

Scheme 349

Release screw connection (1) on solenoid valve with special tool 11 5 400.

Scheme 350

Installation

Sealing rings (1) cannot be replaced.

If one of the sealing rings (1) is damaged, the solenoid valve must be replaced.

Lightly lubricate sealing rings (1) with engine oil.

Installation

Replace sealing ring (1).

Secure sealing ring (1) in groove; if necessary, secure against falling out with grease.

Assemble engine.

There is air in the VANOS system once it is opened.

In the first few seconds after startup this results in a clearly discernible "rattling noise".

This rattling noise does "not" indicate incorrect assembly.

The rattling noise will disappear as soon as the oil pressure has built up and the system has vented.

Carry out venting procedure with diagnosis tester.

Perform VANOS test.

11 41 000 Removing And Installing / Replacing Oil Pump (S85)

Necessary preliminary tasks

1. Removing «oil pan»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .

Release screws (1).

Installation

Replace screws.

Clean threads before installation.

Scheme 351

Release screw (1).

Release screw (2).

Detach oil pipes from oil pump.

Scheme 352

Installation

Replace sealing ring (1).

To aid installation, apply a thin coat of engine oil to sealing ring (1).

Clean all sealing surfaces.

Scheme 353

Release screw (2).

Fold sliding rail (3) downwards.

Unscrew nut (1).

Remove sprocket wheel from shaft.

Installation

If reusing the sprocket wheel, check dihedron for damage and if necessary replace.

Scheme 354

Remove piston (1) in direction of arrow.

Installation

Arrangement, chain tensioner, oil pump.

1. Base valve
2. Spring
3. Piston

Release screw (1) on oil pump.

Scheme 355

Release screws (1).

Remove oil pump (2).

Installation

Check dihedron on oil pump shaft (3) for damage, replace oil pump if necessary.

Clean thread of oil pump shaft (3) with suitable means.

Scheme 356

Place sprocket wheel (1) with chain (3) on oil pump shaft (2).

Rotate oil pump shaft (2) with a screwdriver in direction of arrow until dihedrons of oil pump shaft and sprocket wheel are flush.

Coat thread (2) with Loctite 648.

Scheme 357

Tighten nut(1).

Tightening torque 11 41 1AZ. See ENGINE - TIGHTENING TORQUES .

Installation

Check tensioning travel of chain tensioner.

Slide caliper gauge (1) as far as it will go on reverse side of sliding rail.

Adjust caliper gauge (1) to tensioning rail.

Note. Checking dimension: 72.5 to 80 mm.

If the dimension 80 mm is exceeded, shims must be fitted on the VANOS high-pressure pump.

Scheme 358

Assemble engine.

11 41 532 Replacing transmission oil pump (GS7S47BG SMG)

Necessary preliminary tasks

1. Unscrew and remove splash guard.
2. Remove reinforcement plate. See «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE (M5)»(/bmw/m5/e60e61-2004-2010/remont/axle-shafts/#front-axle-repair__31-10-010-removing-and-installingreplacing) or «31 10 010 REMOVING AND INSTALLING/REPLACING REINFORCEMENT PLATE (M6)»(ref-263479-S39582832342007090700000) .
3. Remove heat shields.
4. Drain transmission oil.

Disconnect connector (1).

Scheme 359

Release bolts (1). Installation: Replace screws.

Tightening torque 23 41 21AZ. See 11 41 OIL PUMP WITH STRAINER AND DRIVE .

Scheme 360

11 42 020 Removing And Installing, Sealing/Replacing Complete Main Flow Oil Filter (S85)

Recycling

Catch and dispose of engine oil with suitable equipment.

Note national regulations.

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove front underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M6)»(ref-263486-S32577391072007090700000) .
3. Remove front right wheel arch trim. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) or «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M6)»(ref-263486-S41950279912007090700000) .
4. Remove right air duct.
5. Remove oil drain plug (1).

Installation

Replace sealing ring.

Tightening torque 11 13 2AZ. See ENGINE - TIGHTENING TORQUES .

Release nuts (1 and 2).

Tightening torque: 11 42 3AZ. See 11 42 OIL FILTER AND PIPES .

Detach lines (3 and 4).

Installation

Replace O-rings.

Scheme 361

Slacken nut (2).

Release nuts (3 and 4).

Detach lines (1 and 5).

Installation

Replace O-rings.

Scheme 362

Unscrew nuts (1).

Lift out oil filter housing.

Installation

Check rubber mount for damage.

Scheme 363

Assemble engine.

Park vehicle on a horizontal surface.

Allow engine at normal operating temperature to run for 3 minutes with increased revs (min. 1000 / max. 1500 RPM).

Read off engine oil level in instrument cluster or on Control Display.

Top up engine oil if necessary.

11 42 080 Removing And Installing / Replacing Oil Pressure Hose (Feed) (S85)

Recycling

Catch and dispose of emerging engine oil with suitable equipment.

Note national regulations.

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove front underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(ref-263486-S32577391072007090700000)
3. Remove «tensioning device»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-060-removing-and-installing) for A/C compressor.
4. Remove front right wheel arch trim. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) or «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M6)»(ref-263486-S41950279912007090700000) .
5. Remove right air duct.

Unscrew nut (2).

Unscrew nuts (3).

Detach pressure line (1).

Release screws (1).

Detach pressure line (2).

Scheme 364

Assemble engine.

Park vehicle on a horizontal surface.

Allow engine at normal operating temperature to run for 3 minutes with increased revs (min. 1000 / max. 1500 RPM).

Read off engine oil level in instrument cluster or on Control Display.

11 42 080 Removing And Installing / Replacing Oil Pressure Hose (Return) (S85)

Recycling

Catch and dispose of emerging engine oil with suitable equipment.

Note national regulations.

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove front underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M6)»(ref-263486-S32577391072007090700000) .
3. Remove «tensioning device»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-060-removing-and-installing) for A/C compressor.
4. Remove A/C compressor. See «64 52 523 REPLACING A/C SYSTEM COMPRESSOR (M5)»(ref-379401-S42063386832010121300000) or «64 52 523 REPLACING A/C SYSTEM COMPRESSOR (M6)»(ref-202140-S34268247112010112400000) .
5. Remove front right wheel arch trim. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) or «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER (M6)»(ref-263486-S41950279912007090700000) .
6. Remove right air duct.

Unscrew nut (2).

Unscrew nuts (4).

Detach pressure line (5).

Release screws (2).

Detach pressure line (1).

Installation

Replace seal.

Scheme 365

Release screw (1).

Scheme 366

Assemble engine.

Park vehicle on a horizontal surface.

Allow engine at normal operating temperature to run for 3 minutes with increased revs (min. 1000 / max. 1500 RPM).

Read off engine oil level in instrument cluster or on Control Display.

11 42 095 Removing And Installing / Sealing Or Replacing Connecting Flange (S85)

Recycling

Catch and dispose of emerging engine oil with suitable equipment.

Note national regulations.

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove front underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) or «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION (M6)»(ref-263486-S32577391072007090700000) .
3. Remove «tensioning device»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-060-removing-and-installing) for A/C compressor.
4. Disconnect «pressure line»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-42-080-removing-and-installing) (feed).
5. Remove «engine oil sump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-13-000-removing-and-installing) .
6. Remove «engine oil pump»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-41-000-removing-and-installing) .

Release screws (1).

Detach pressure line (2).

Installation

Replace O-ring.

Release screws (2).

Installation

Replace seal.

Scheme 367

Assemble engine.

Park vehicle on a horizontal surface.

Allow engine at normal operating temperature to run for 3 minutes with increased revs (min. 1000 / max. 1500 RPM).

Read off engine oil level in instrument cluster or on Control Display.

11 51 000 Removing And Installing / Replacing Water Pump (S85)

Necessary preliminary tasks

1. Remove fan cowl with electronic fan. See «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__17-11-035-removing-and-installingreplacing) or «17 11 035 REMOVING AND INSTALLING/REPLACING FAN COWL WITH ELECTRIC FAN (M6)»(ref-381314-S13869658542010122900000) .
2. Remove radiator. See «REMOVING RADIATOR COVER (M5)»(/bmw/m5/e60e61-2004-2010/remont/cooling-system-mechanical/#cooling-system-repair__removing-radiator-cover-s85) or «17 11 000 REMOVING AND INSTALLING RADIATOR (M6)»(ref-381314-S33322338112010122900000) .
3. Remove «A/C compressor drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-050-replacing-drive-belt) .
4. Remove «alternator drive belt»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) .
5. Remove «belt tensioner»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-28-060-removing-and-installing) for A/C compressor.

Release screw (1).

Remove idler pulley (2).

Release screws (4).

Remove belt pulley (3).

Scheme 368

Release screw (1) of VANOS high-pressure line.

Release banjo bolt (1).

Installation

Replace all sealing rings.

Tightening torque 11 36 5AZ. See ENGINE - TIGHTENING TORQUES .

Release screws (2).

Pull bracket (1) with VANOS high-pressure line upwards until coolant pump (3) is freely accessible.

Insert bolts (2) of coolant pump (3).

Screw in bolts (2) uniformly in 1/2 turns.

Remove coolant pump (3) towards front.

Scheme 369

Assemble engine.

Vent cooling system and check for leaks.

11 53 000 Removing And Installing/Replacing Coolant Thermostat (S85)

Necessary preliminary tasks

1. Remove «intake air manifold»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-61-050-removing-and-installing) .
2. Drain coolant.

Release bolt on hose bracket (2).

Unlock and detach water hoses (1).

Unfasten banjo bolt (3).

Installation

Replace sealing rings.

Release screws (4).

Scheme 370

Remove thermostat housing with thermostat in upward direction.

Remove connecting pipes (2).

Installation

Replace all O-rings on connecting pipes (2).

Clean sealing surface (3).

Scheme 371

Remove thermostat (1) in direction of arrow.

Check rubber section (2) for damage.

Scheme 372

Assemble engine.

Vent cooling system and check for leaks.

11 61 050 Removing And Installing Air Intake Manifold (S85)

Note. See 11 61 050 Removing And Installing Air Intake Manifold (S85) .

11 61 050 Removing And Installing Air Intake Manifold/Plenum (S85)

Special tools required

1. 32 1 260

Necessary preliminary tasks

1. Remove trailing links. See «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME (M5)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-373-removing-and-installingreplacing) or «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME (M6)»(ref-263486-S37271255352007090700000) .
2. Remove air filter housing on left and right. See «13 71 000 REMOVING AND INSTALLING LEFT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-000-removing-and-installing) or «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .
3. Remove microfilter housing. See «64 31 061 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT MICROFILTER HOUSING LOWER SECTION»(ref-379401-S13162676242010121300000) or «64 31 061 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT MICROFILTER HOUSING LOWER SECTION (M6)»(ref-202140-S32898856862005102700000) .

Note. Illustrations show bank 1 (cylinders 1 to 5).

Release spring clamps (2).

Detach hose (3) in direction of arrow.

Scheme 373

Unlock and detach hose (5) from fastener (1).

Unlock and detach hose (3) from fastener (2).

Release spacer (4).

Scheme 374

Unlock hose (1) from fastener (5) and detach in direction of arrow.

Unlock hose (2) from fastener (4) and detach in direction of arrow.

Detach hoses (1 and 2) retaining fixture (3).

Scheme 375

Installation

Each hose clamp on the decoupling element is exactly positioned.

A marking (1) is provided in each case on the air intake manifold to ensure that all hose clamps are accessible.

Release all hose clamps.

Note. Illustration shows hose clamps (2 and 3).

Scheme 376

Disengage cable duct (2) with holder (1) from air intake manifold on right.

Scheme 377

Lift air intake manifold slightly.

Disconnect hose connection (2) from cylinder head cover.

Installation

Each hose clamp (1) has one installation position for improved installation and removal.

Replace faulty hose clamps.

Scheme 378

Decoupling element (2).

Guide lug (3) for installation position.

Retainer (1) for securing hose clamps.

Scheme 379

Opening (1) for positioning decoupling element.

Installation

Snap into groove (2) when fitting decoupling element.

Do not use any antiseize agents or lubricants when fitting.

Scheme 380

Secure ear clamps (2) with special tool 32 1 260.

Scheme 381

Note. Assemble engine. Check function of DME.

11 78 530 Replacing Left Oxygen Control Sensor (S85)

Special tools required

1. 11 7 030
2. 11 9 150

Necessary preliminary tasks

1. Read out fault memory in Digital Motor Electronics (DME).
2. Remove transmission underbody protection.
3. Remove bottom left wheel arch trim.

Remove oxygen control sensor (1) with special tools 11 7 030 and 11 9 150.

Installation

When using special tools 11 7 030 and 11 9 150, 47 Nm on torque wrench scale corresponds to an actual tightening torque of 50 Nm.

If the oxygen control sensor is reused, apply a thin and even coat of Never Seez Compound to the thread only.
