22 11 001 REPLACING RIGHT ENGINE MOUNT (S85)
Necessary preliminary tasks
- Secure engine in installation position. See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-670-securing-engine-in) .
- Remove both front wheels.
- Lower front axle carrier.
Observe safety instructions on raising the vehicle. Read and follow operating instructions for lifting platform. Before driving onto a lifting platform, make sure there is sufficient ground clearance between the lifting platform and the car. The vehicle may only be raised with the lifting platform at the four jacking points. See 00...... LIFTING VEHICLE WITH A LIFTING PLATFORM (5-SERIES) or 00..... LIFTING VEHICLE WITH A LIFTING PLATFORM (6-SERIES) .
Release screws (1).
Remove engine mount.
Tighten to specified torque, see 22 11 1AZ in 22 11 ENGINE MOUNTING .
Installation
Replace screws.
Scheme 386
Installation
Lug (1) of engine mount must point to middle of vehicle.
Engine mount designations
Right engine mount
- Even component number
Left engine mount
- Odd component number
Scheme 387
22 11 011 REPLACING LEFT ENGINE MOUNT (S85)
Necessary preliminary tasks
- Secure engine in installation position. See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-670-securing-engine-in) .
- Remove both front wheels.
- Lower front axle carrier.
Observe safety instructions on raising the vehicle. Read and follow operating instructions for lifting platform. Before driving onto a lifting platform, make sure there is sufficient ground clearance between the lifting platform and the car. The vehicle may only be raised with the lifting platform at the four jacking points. See 00...... LIFTING VEHICLE WITH A LIFTING PLATFORM (5-SERIES) or 00..... LIFTING VEHICLE WITH A LIFTING PLATFORM (6-SERIES) .
Release screws (1).
Remove engine mount.
Tighten to specified torque, see 22 11 1AZ in 22 11 ENGINE MOUNTING .
Installation
Replace screws.
Scheme 388
Installation
Lug (1) of engine mount must point to middle of vehicle.
Engine mount designations
Right engine mount
- Even component number
Left engine mount
- Odd component number
Scheme 389
22 11 100 REPLACING RIGHT ENGINE SUPPORT ARM (S85)
Necessary preliminary tasks
- Secure engine in installation position. See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-670-securing-engine-in) .
- Remove both front wheels.
- Lower front axle carrier.
Observe safety instructions on raising the vehicle. Read and follow operating instructions for lifting platform. Before driving onto a lifting platform, make sure there is sufficient ground clearance between the lifting platform and the car. The vehicle may only be raised with the lifting platform at the four jacking points. See 00...... LIFTING VEHICLE WITH A LIFTING PLATFORM (5-SERIES) or 00..... LIFTING VEHICLE WITH A LIFTING PLATFORM (6-SERIES) .
Release screws (1).
Remove engine support arm (2).
Tighten to specified torque, see 22 11 3AZ in 22 11 ENGINE MOUNTING .
Scheme 390
22 11 110 REPLACING LEFT ENGINE SUPPORT ARM (S85)
Necessary preliminary tasks
- Secure engine in installation position. See «11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S85)»(/bmw/m5/e60e61-2004-2010/remont/mechanical/#engine-repair__11-00-670-securing-engine-in) .
- Remove both front wheels.
- Lower front axle carrier.
Observe safety instructions on raising the vehicle. Read and follow operating instructions for lifting platform. Before driving onto a lifting platform, make sure there is sufficient ground clearance between the lifting platform and the car. The vehicle may only be raised with the lifting platform at the four jacking points. See 00...... LIFTING VEHICLE WITH A LIFTING PLATFORM (5-SERIES) or 00..... LIFTING VEHICLE WITH A LIFTING PLATFORM (6-SERIES) .
Unfasten screws.
Remove engine support arm (1).
Tighten to specified torque, see 22 11 3AZ in 22 11 ENGINE MOUNTING .
Scheme 391
22 31 001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING
Necessary preliminary tasks
- Remove underbody protection
- Remove complete exhaust system. See «EXHAUST SYSTEM - REPAIR (5-SERIES)»(ref-297461) or «EXHAUST SYSTEM - REPAIR (6-SERIES)»(ref-522731) .
- If necessary, remove exhaust system bracket
- Support transmission with hydraulic lifter.
If necessary, remove heat shield (1) on left and right.
Scheme 392
Release screws (1) and nuts (2) and remove transmission crossmember.
Remove transmission mount from transmission crossmember.
Tighten to specified torque. Transmission cross-member to body M10 thread 42 Nm; M8 thread 19 Nm. Transmission mount to transmission support bracket/transmission cross-member 19 Nm.
Note. Illustration similar.
Scheme 393
(M47)
Release screws and nut (1).
Remove cross member.
Tighten to specified torque. Transmission cross-member to body M10 thread 42 Nm; M8 thread 19 Nm. Transmission mount to transmission support bracket/transmission cross-member 19 Nm.
Scheme 394
(M47)
Unscrew nut (1).
Exchange rubber mount.
Tighten to specified torque. Transmission mount to transmission support bracket/transmission cross-member 19 Nm.
Scheme 395
22 31 001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING (S85)
Necessary preliminary tasks
- Remove underbody protection.
- Remove complete exhaust system. See «EXHAUST SYSTEM - REPAIR»(/bmw/m5/e60e61-2004-2010/remont/exhaust/#exhaust-system-repair) .
- Remove heat shields.
- Support transmission with hydraulic lifter.
Release screws (1) and nuts (2) and remove transmission crossmember.
Remove rubber mount from transmission crossmember.
Tighten to specified torque. Transmission cross-member to body M10 thread 42 Nm; M8 thread 19 Nm. Transmission mount to transmission support bracket/transmission cross-member 19 Nm.
Scheme 396
22 31050 REPLACING CROSSMEMBER FOR TRANSMISSION MOUNTING
Note. Operations are identical to Replacing rubber mount for transmission mounting. See 22 31 001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING (S85) .
Note. Operations are identical to Replacing rubber mount for transmission mounting. See 22 31 001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING (S85) .
