64 11... Installing servodrive
Installation
If necessary, align shaft of flap(s) to be actuated to position of servodrive to be installed.
Scheme 1
64 11 206 Removing and installing or replacing heater
Necessary preliminary tasks
- Draw off refrigerant from A/C system. See «64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a)»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-50-009-drawing-off-evacuating) .
- Remove fresh air duct. See «64 31 053 Removing And Installing Or Replacing Fresh Air Duct»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-053-removing-and-installing) .
- Remove trim for instrument panel. See «51 45 030 REMOVING AND INSTALLING INSTRUMENT»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-030-removing-and-installing) .
- Remove temperature sensor for cold-air distributor. See «64 11 916 Replacing Temperature Sensor For Cold-Air Distributor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-916-replacing-temperature-sensor) .
| WARNING | Follow instructions for working on cooling system. See 17 00... INSTRUCTIONS FOR WORKING ON COOLING SYSTEM . |
| WARNING | To avoid injury, cover holder (1) on support tube (2). |
Scheme 2
Unscrew nuts (1).
Installation
Tightening torque, see 64 53 8AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Detach refrigerant line (2) in direction of arrow.
Unclip refrigerant line (3).
Scheme 3
| WARNING | When installing heater, make sure left and right air ducts are correctly seated. Check left and right air ducts for leaks. If necessary, reseal left and right air ducts with butylene tape (sourcing reference: BMW Parts Service). If left and right air ducts are resealed, make sure flaps can move freely. |
Feed out rubber grommet (1).
Installation
Make sure rubber grommet (1) is correctly seated.
Release nut (2) and detach refrigerant lines (3) and (4) in direction of arrow.
Scheme 4
Installation
Tightening torque, see 64 53 7AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Replace sealing rings.
Release nuts (5) on right air duct.
Installation
Tightening torque, see 64 11 4AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Feed out rubber grommet (1).
Installation
Make sure rubber grommet (1) is correctly seated.
Release spring clamps (2) and detach coolant hoses (3).
| IMPORTANT | Carefully blow through aluminum triple pipe to remove remaining coolant from heat exchanger for heating system. |
Scheme 5
Installation
Vent cooling system and check for leaks. See 17 00 005 DRAINING OFF AND TOPPING UP COOLANT .
Release nuts (4) on left air duct.
Installation
Tightening torque, see 64 11 4AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Disconnect rear compartment air duct (1) in direction of arrow.
Installation
Make sure rear compartment air duct (1) is correctly seated.
Scheme 6
Release screws (1).
Remove left air duct (2) in direction of arrow.
Scheme 7
Release screws (1).
Remove right air duct (2) in direction of arrow.
Scheme 8
Carefully lever out locks (1) and (2).
Detach air distributor (3) in direction of arrow.
Installation
Make sure air distributor (3) is correctly seated.
Scheme 9
| IMPORTANT | Follow instructions for handling optical fibers. See 61 00... NOTES ON HANDLING OPTICAL FIBERS . |
Necessary preliminary tasks
- Disconnect all necessary cable ties on support tube.
- Release wiring harnesses/cable ducts and lay to one side.
- If necessary, remove control units/disconnect plug connections.
Installation
Make sure wiring harnesses/cable ducts are correctly routed and secured.
If necessary, remove CD changer (1). See 65 11 072 REMOVING AND INSTALLING/REPLACING CD CHANGER .
Loosen screws (2).
Set fuse-carrier (3) down in footwell.
Scheme 10
Release screws (1).
Installation
Scheme 11
Release screws (1).
Installation
Tightening torque, see 51 71 15AZ in BODY EQUIPMENT - TIGHTENING TORQUES - 525i & 530i .
Scheme 12
Release screws (1).
Installation
Tightening torque, see 51 71 15AZ in BODY EQUIPMENT - TIGHTENING TORQUES - 525i & 530i .
Scheme 13
Unscrew nuts (1).
Installation
Tightening torque, see 51 71 15AZ in BODY EQUIPMENT - TIGHTENING TORQUES - 525i & 530i .
Scheme 14
Unscrew nuts (1).
Detach support tube (2) and remove from vehicle with assistance of a second person.
Installation
Tightening torque, see 51 71 15AZ in BODY EQUIPMENT - TIGHTENING TORQUES - 525i & 530i .
Scheme 15
If necessary, unlock and disconnect plug connections on heater.
Remove heater (1) in direction of arrow.
Installation
Make sure heater (1) is correctly seated.
Scheme 16
Installation
Make sure condensate drain (1) is correctly seated in grommet (2).
Scheme 17
64 11 208 Replacing heater core
Necessary preliminary tasks
- Remove heater. See «64 11 206 Removing And Installing Or Replacing Heater»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-206-removing-and-installing) .
Release screws (1).
Press lock (2) and remove cover (3) in direction of arrow.
Installation
Ensure cover (3) is correctly seated.
Scheme 18
Pull out clips (1) in direction of arrow.
Installation
Make sure clips (1) are correctly and firmly seated.
Pull pipes (2) out of heater core (3).
Installation
Replace sealing rings.
Coat sealing rings with antiseize agent.
Make sure sealing rings are correctly seated.
Pull out heater core (3) in direction of arrow.
Installation
Make sure heater core (3) is correctly seated.
Scheme 19
64 11 213 Removing and installing/replacing heater - A/C unit fan
Necessary preliminary tasks
- Remove storage compartment. See «51 16 200 REMOVING AND INSTALLING STORAGE COMPARTMENT»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-200-removing-and-installing) .
- Remove audio system controller/Car Communication Computer. See «65 12 200 REMOVING AND INSTALLING (REPLACING) AUDIO SYSTEM CONTROLLER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#audio-navigation-anti-theft-and-restraints-repair__65-12-200-removing-and-installing) .
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
- Remove right glovebox with housing. See «51 16 366 REMOVING AND INSTALLING RIGHT GLOVEBOX WITH HOUSING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-366-removing-and-installing) .
Disconnect rear compartment air duct (1) in direction of arrow.
Installation
Make sure rear compartment air duct (1) is correctly seated.
Scheme 20
Release screws (1).
Remove middle function carrier (2) in direction of arrow.
Installation
Make sure Exploded View Of middle function carrier (2) is correctly seated.
Ensure correct cable routing.
Scheme 21
Necessary preliminary tasks
- If necessary, «Remove Temperature Sensor For Cold-Air Distributor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-916-replacing-temperature-sensor) .
Unfasten plug connection (1) and disconnect.
Release clips (2).
Unfasten plug connection (3) and disconnect.
Remove rear compartment air duct (4) in direction of arrow.
Installation
Make sure rear compartment air duct (4) is correctly seated.
Scheme 22
Disconnect left air duct (1) in direction of arrow (2) and (3).
Installation
Make sure right air duct (1) is correctly seated.
Scheme 23
Disconnect right air duct (1) in direction of arrow (2) and (3).
Installation
Make sure right air duct (1) is correctly seated.
Scheme 24
Unlock plug (1) and remove.
Release screws (2).
Remove cover (3) in direction of arrow.
Installation
Ensure correct cable routing.
Make sure seal is correctly seated in cover (3).
Scheme 25
Release screws (1).
Remove fan for heater - A/C unit (2) in direction of arrow.
Installation
Make sure fan for heater - A/C unit (2) is correctly seated.
Scheme 26
Replacement
Unlock controller for heater - A/C unit fan (1) with a suitable screwdriver (2) and remove.
Unlock plug connections (3) and disconnect.
Installation
Make sure controller for heater - A/C unit fan (1) is correctly seated.
Scheme 27
64 11 225 Replacing controller for heater/air conditioner fan
Operation is described in
- «Removing And Installing/Replacing Heater-A/C Unit Fan»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-213-removing-and-installingreplacing) .
64 11 262 Removing and installing/replacing auxiliary water pump
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Necessary preliminary tasks
- If necessary, remove intake filter housing. See «13 71 000 REMOVING AND INSTALLING INTAKE FILTER HOUSING»(ref-201412-S31740378752005102600000) .
- Disconnect coolant hoses from auxiliary water pump.
Unlock fast-release couplings (1) and detach coolant hoses from auxiliary water pump (4).
Installation
Fill and vent cooling system. See 17 00 005 DRAINING OFF AND TOPPING UP COOLANT .
If necessary, release expander rivet (2).
Unfasten plug connection (3) and disconnect.
Scheme 28
Installation
Ensure correct routing of cables.
Remove auxiliary water pump (4) in direction of arrow.
Replacement
Detach auxiliary water pump fixture (1) in direction of arrow from auxiliary water pump (2).
Installation
Make sure auxiliary water pump (2) is correctly seated in auxiliary water pump fixture (1).
Scheme 29
64 11 274 Replacing water valve for heater
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Necessary preliminary tasks
- Disconnect coolant hoses from water hose for heater.
Unfasten plug connection (1) and disconnect.
Release spring clamps (2) and detach coolant hoses.
Pull out water valve for heater (3) towards top.
Installation
Fill and vent cooling system. See 17 00 005 DRAINING OFF AND TOPPING UP COOLANT .
Scheme 30
Installation
Make sure water valve (1) is correctly seated in grommets (2) and rubber mount (3).
If necessary, replace grommets (2) and rubber mount (3).
Scheme 31
64 11 377 Removing and installing (replacing) control panel for heater - A/C system
Necessary preliminary tasks
- Remove middle trim for instrument panel. See «51 45 310 REMOVING AND INSTALLING (REPLACING) CENTER TRIM FOR INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-310-removing-and-installing) .
Release screws (1).
Unclip control panel for heater - A/C system (2) all round and remove from middle trim for instrument panel (3).
Scheme 32
Replacement
Using BMW scan tool, carry out programming/coding.
64 11 803 Removing and installing/replacing servodrive for left fresh-air/recirculated-air flap
Necessary preliminary tasks
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY.»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing)
- Remove air distributor in footwell and side heating duct/left rear seat area. See «64 11 943 Replacing Evaporator Temperature Sensor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-943-replacing-evaporator-temperature) .
Press lock (2) and pull out servodrive for left fresh air/recirculated-air flap (3) in direction of arrow.
Unfasten plug connection (1) and disconnect.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for left fresh-air/recirculated-air flap (3) must snap audibly into place.
Scheme 33
64 11 808 Removing and installing/replacing servodrive for right fresh-air/recirculatedair flap
Necessary preliminary tasks
- Remove bottom right trim panel from instrument panel. See «51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-181-removing-and-installingreplacing) .
Unfasten plug connection (1) and disconnect.
Press lock (2) and pull out servodrive for right fresh air/recirculated-air flap (3) in direction of arrow.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for right fresh-air/recirculated-air flap (3) must snap audibly into place.
Scheme 34
64 11 830 Replacing servodrive for left ventilation flap
Necessary preliminary tasks
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
- Remove air distributor in footwell and heating duct in rear compartment on left. See «64 11 943 Replacing Evaporator Temperature Sensor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-943-replacing-evaporator-temperature) .
Unfasten plug connection (1) and disconnect.
Press lock (2) and pull out servodrive for left ventilation flap (3) in direction of arrow.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for left ventilation flap (3) must snap audibly into place.
Scheme 35
64 11 832 Replacing servodrive for right ventilation flap
Necessary preliminary tasks
- Remove airbag module on passenger side. See «AIR BAG RESTRAINT SYSTEMS»(ref-170471) .
Unfasten plug connection (1) and disconnect.
Press lock (2) and pull out servodrive for right ventilation flap (3) in direction of arrow.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for right ventilation flap (3) must snap audibly into place.
Scheme 36
64 11 840 Replacing servodrive for left footwell flap
Necessary preliminary tasks
- Remove trim for instrument panel. See «51 45 030 REMOVING AND INSTALLING INSTRUMENT PANEL TRIM»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-030-removing-and-installing) .
Press lock (1) and unclip servodrive for left footwell flap (2) in direction of arrow.
Unfasten plug connection (3) and disconnect.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Scheme 37
64 11 842 Replacing servodrive for right footwell flap
Necessary preliminary tasks
- Remove trim for instrument panel. See «51 45 030 REMOVING AND INSTALLING INSTRUMENT PANEL TRIM»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-030-removing-and-installing) .
Press lock (1) and unclip servodrive for right footwell flap (2) in direction of arrow.
Unfasten plug connection (3) and disconnect.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Scheme 38
64 11 850 Replacing servodrive for rear compartment flap
Necessary preliminary tasks
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
- Remove air distributor in footwell and heating duct in rear compartment on left. See «64 11 943 Replacing Evaporator Temperature Sensor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-943-replacing-evaporator-temperature) .
Unfasten plug connection (1) and disconnect.
Press lock (2) and pull out servodrive for rear compartment flap (3) in direction of arrow.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for rear compartment flap (3) must snap audibly into place.
Scheme 39
64 11 869 Replacing servodrive of stratification flap
Necessary preliminary tasks
- Remove right glovebox with housing. See «51 16 366 REMOVING AND INSTALLING RIGHT GLOVEBOX WITH HOUSING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-366-removing-and-installing) .
Unfasten plug connection (1) and disconnect.
Press lock (2) and pull out servodrive for stratification flap (3) in direction of arrow.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for stratification flap (3) must snap audibly into place.
Scheme 40
64 11 875 Removing and installing/replacing servodrive for defrosting flap
Necessary preliminary tasks
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
- Remove air distributor in footwell and heating duct in rear compartment on left. See «64 11 943 Replacing evaporator temperature sensor»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-943-replacing-evaporator-temperature) .
Press lock (1) and pull out servodrive for defrosting flap (2) in direction of arrow.
Unfasten plug connection (3) and disconnect.
Installation
Follow repair instruction "Installing servodrive". See 64 11... Installing Servodrive .
Servodrive for defrosting flap (2) must snap audibly into place.
Scheme 41
64 11 902 Replacing sensor fan for interior temperature
Necessary preliminary tasks
- Remove control panel for heater - A/C system. See «64 11 377 REMOVING AND INSTALLING (REPLACING) CONTROL PANEL FOR HEATER - A/C system»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-377-removing-and-installing) .
Release screws (1).
Pull out sensor blower for interior temperature (2) in direction of arrow.
Installation
Make sure pins (3) are correctly seated in base (4).
Scheme 42
64 11 912 Removing and installing/replacing temperature sensor for heating unit
Necessary preliminary tasks
- Remove on-board monitor. See «65 82 050 REMOVING AND INSTALLING (REPLACING) ON-BOARD MONITOR»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#audio-navigation-anti-theft-and-restraints-repair__65-82-050-removing-and-installing) .
Unfasten plug connection (1) and disconnect.
Pull out temperature sensor for heating unit (2) in direction of arrow.
Installation
Make sure temperature sensor for heating unit (2) is correctly seated.
Scheme 43
64 11 916 Replacing temperature sensor for cold-air distributor
Necessary preliminary tasks
- Remove audio system controller/Car Communication Computer. See «65 12 200 REMOVING AND INSTALLING (REPLACING) AUDIO SYSTEM CONTROLLER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#audio-navigation-anti-theft-and-restraints-repair__65-12-200-removing-and-installing) .
Release screws (1).
Fold back middle function carrier (2) in direction of arrow.
Installation
Make sure middle function carrier (2) is correctly seated.
Scheme 44
Turn temperature sensor for cold-air distributor (1) through approx. 90° and pull out in direction of arrow.
Unfasten plug connection (2) and disconnect.
Installation
Make sure temperature sensor for cold-air distributor (1) is correctly seated.
Scheme 45
64 11 943 Replacing evaporator temperature sensor
Necessary preliminary tasks
- Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
Release screw (1).
Detach heating duct in rear compartment on left (2) in direction of arrow from air distributor in footwell (3).
Pull out air distributor in footwell (3) in direction of arrow.
Installation
Make sure heating duct in rear compartment on left (2) and air distributor in footwell (3) are correctly seated.
Scheme 46
Unscrew bolt (1).
Pull out heating duct in rear compartment on left (2) in direction of arrow and feed out.
Installation
Make sure heating duct in rear compartment on left (2) is correctly seated.
Scheme 47
Unfasten plug connection (1) and disconnect.
Pull out evaporator temperature sensor (2) in direction of arrow and feed out.
Installation
Ensure evaporator temperature sensor (2) is correctly seated.
Scheme 48
64 11 970 Replacing fogging sensor
Special Tools Required
- 00 9 317
Removal & Installation
Necessary preliminary tasks
- Remove two-part mirror base cover. See «61 35 177 REMOVING AND INSTALLING (REPLACING) RAIN/LIGHT SENSOR»(/bmw/m5/e60e61-2004-2010/remont/horns/#general-electrical-system-repair__61-35-177-removing-and-installing) .
| WARNING | Make sure rooms are well ventilated when working with adhesive remover indoors. |
| IMPORTANT | Do not under any circumstances use paint thinner to clean the bonding surface. |
Unfasten plug connection (1) and disconnect.
Note. If necessary, carefully heat fogging sensor (2) with a hot air blower to approximately 40-60°C.
Lift off fogging sensor (2) with special tool 00 9 317 and slowly pull off from windshield.
Installation
Bonding surface must be dry and free of dust and grease.
Clean bonding surface with adhesive remover (sourcing reference: BMW Parts Service).
After cleaning, do not touch bonding surface with bare hands.
Scheme 49
Pull off protective film completely from fogging sensor (3).
Place mounting template (1) as pictured on rain sensor (2).
Press fogging sensor (3) in direction of arrow with a contact pressure of >=15 N/cm 2 onto inside of windshield.
Note. Firm thumb pressure attains approx. 30 N/cm 2 .
Remove mounting template (1) carefully from fogging sensor (3).
Scheme 50
64 11 991 Removing and installing/replacing sensor for automatic recirculated air control
Unfasten plug connection (1) and disconnect.
Feed out sensor for automatic recirculated air control (2) in direction of arrow and remove.
Installation
Make sure sensor for automatic recirculated air control (2) is correctly seated.
Scheme 51
64 11 992 Removing and installing/replacing solar sensor
Necessary preliminary tasks
- Remove speaker trim from trim for instrument panel at top. See «51 45 115 REMOVING AND INSTALLING SPEAKER FRAME ON PANEL FOR INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-115-removing-and-installing) .
Unlock catches (1) in direction of arrow and remove solar sensor (2) from speaker trim (3).
Installation
Catches (1) on speaker trim (3) must not be damaged.
Make sure solar sensor (2) is correctly seated in speaker trim (3).
Scheme 52
64 12... Initializing independent heating remote control
The following steps are required for initializing a new independent heating remote control or after replacing the Car Access System control unit
- Close and then reopen central locking with vehicle remote control.
- Within 5 seconds: Switch ignition lock from terminal "0" to terminal "R" and then back to terminal "0".
- Press and hold down "OFF" button on independent heating remote control.
- Press "ON" button on independent heating remote control 3 times in succession
The vehicle's central locking closes and opens automatically on successful initialization.
Note. Both independent heating remote controls must be reinitialized after the Car Access System control unit has been replaced.
64 12 021 Removing and installing independent/auxiliary heater
Special Tools Required
- 13 3 010
Necessary preliminary tasks
- Remove left front wheel. See «WHEEL AND TIRES - REPAIR INSTRUCTIONS»(ref-201421) .
- Remove front left wheel arch lining. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) .
- Remove left underbody paneling. See «51 47... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing-left) .
| WARNING | Danger of scalding! Only perform the following tasks on an engine that has cooled down. Follow instructions for working on cooling system. See 17 00... INSTRUCTIONS FOR WORKING ON COOLING SYSTEM . |
Note. Disconnect coolant hoses on independent heater.
Note. Disconnect fuel line on independent heater with special tool 13 3 010.
Scheme 53
Recycling
Fuel escapes when fuel line is detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
Release hose clip (1) and detach fuel line.
Release spring clips (2) and detach coolant hoses.
Installation
Top up coolant and vent cooling system. See 17 00 005 DRAINING OFF AND TOPPING UP COOLANT .
Unscrew nut (3).
Scheme 54
| WARNING | Secure independent heater against falling out. |
Disconnect plug connections (1) and (2).
| IMPORTANT | To avoid damaging the independent heater, it is absolutely essential to adhere to the following connecting sequence for the plug connections during installation |
- Plug connection (1)
- Plug connection (2)
Release screws (3).
Remove independent heater (4) in direction of arrow.
Installation
Make sure exhaust pipe of independent heater (4) is correctly seated in muffler (5).
Scheme 55
64 12 120 Removing and installing/replacing intake muffler for independent/auxiliary heater
Necessary preliminary tasks
- Remove left front wheel. See «WHEEL AND TIRES - REPAIR INSTRUCTIONS»(ref-201421) .
- Remove front left wheel arch lining. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) .
- Remove left underbody paneling. See «51 47... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing-left) .
Disconnect plug connections (1) and (2).
| IMPORTANT | To avoid damaging the independent heater, it is absolutely essential to adhere to the following connecting sequence for the plug connections during installation |
- Plug connection (1)
- Plug connection (2)
Release screws (3).
Fold independent heater (4) in direction of arrow to one side.
Scheme 56
Installation
Make sure exhaust pipe of independent heater (4) is correctly seated in muffler (5).
Detach cable strap (1).
Release spring clip (2) and detach corrugated tube from independent/auxiliary heater.
Remove intake muffler for independent/auxiliary heater (3).
Scheme 57
64 12 525 Replacing complete independent heater
Necessary preliminary tasks
- Remove complete independent heater. See «64 12 021 Removing And Installing Independent/Auxiliary Heater»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-12-021-removing-and-installing) .
Detach cable strap (1).
Release spring clip (2).
Detach air intake hose (3).
Loosen screws (4).
Remove holder for independent heater (5).
Scheme 58
Unlock cover (1) and remove in direction of arrow.
Unlock and disconnect plug connection for auxiliary water pump.
Feed cable out of guide.
Scheme 59
Release spring clip (1).
Detach coolant hose (2) together with auxiliary water pump (3) in direction of arrow.
Scheme 60
Installation
Using BMW scan tool, carry out programming/coding.
64 12 570 Replacing auxiliary water pump for independent/auxiliary heater
Necessary preliminary tasks
- Unlock and disconnect plug connection for auxiliary water pump. See «64 12 525 Replacing Complete Independent Heater»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-12-525-replacing-complete-independent) .
Detach cable straps (1).
Release spring clip (2).
Detach auxiliary water pump for auxiliary heater (3).
Disconnect auxiliary water pump for auxiliary heater (3) from mounting for auxiliary water pump (4).
Scheme 61
64 12 577 Replacing changeover valve for independent/auxiliary heater
Necessary preliminary tasks
- Remove front left wheel trim. See «51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-040-removing-and-installingreplacing) .
Note. Disconnect coolant hoses from changeover valve for independent/auxiliary heater.
| WARNING | Danger of scalding! Only perform the following tasks on an engine that has cooled down. Follow instructions for working on cooling system. See 17 00... INSTRUCTIONS FOR WORKING ON COOLING SYSTEM . |
Unfasten plug connection (1) and disconnect.
Release spring clips (2) and detach coolant hoses.
Unscrew nuts (3).
Remove changeover valve for independent/auxiliary heater (4) in direction of arrow.
Installation
Top up coolant and vent cooling system. See 17 00 005 DRAINING OFF AND TOPPING UP COOLANT .
Scheme 62
64 12 590 Removing and installing or replacing muffler
Necessary preliminary tasks
- Remove left underbody paneling. See «51 47... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing-left) .
Unscrew nut (1).
Release screw (2).
Withdraw muffler (3) in direction of arrow from exhaust pipe (4).
Installation
If necessary, replace blind rivet nut (5).
Scheme 63
64 12 600 Removing and installing or replacing fuel pump
Special Tools Required
- 13 3 010
Necessary preliminary tasks
- Remove left underbody paneling. See «51 47... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELING»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-removing-and-installingreplacing-left) .
Seal off water hoses at fuel pump with special tool 13 3 010.
Scheme 64
Recycling
Fuel escapes when fuel lines are detached. Have a suitable collecting container ready.
Catch and dispose of escaping fuel.
Observe country specific disposal regulations.
Unfasten plug connection (1) and disconnect.
Release hose clamps (2) and detach fuel hoses.
Unscrew bolt (3).
Note. Secure fuel pump (4) against falling out.
Remove fuel pump (4) in direction of arrow.
Installation
Observe direction of flow of fuel pump (4).
Replacement
Detach fuel pump (4) from fuel pump holder.
Scheme 65
64 22 137 Removing and installing/replacing left fresh-air grill
This operation is described in
- Removing decorative strip on instrument panel on left (replacement). See «51 45 370 REMOVING AND INSTALLING (REPLACING) LEFT DECORATIVE STRIP ON INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-370-removing-and-installing) .
64 22 138 Removing and installing/replacing right fresh-air grill
Special Tools Required
- 64 1 020
Necessary preliminary tasks
- Remove decorative strip on instrument panel on right. See «51 45 380 REMOVING AND INSTALLING (REPLACING) RIGHT DECORATIVE STRIP ON INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-380-removing-and-installing) .
Lever out catches (1) with special tool 64 1 020 and unclip right fresh-air grill (2) from decorative strip on instrument panel on right (3).
Scheme 66
64 22 162 Removing and installing/replacing fresh air grill center
Necessary preliminary tasks
- Remove decorative strip on instrument panel on right. See «51 45 380 REMOVING AND INSTALLING (REPLACING) RIGHT DECORATIVE STRIP ON INSTRUMENT PANEL»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-380-removing-and-installing) .
Release nuts (1) and remove center fresh-air grill (2) from decorative strip on instrument panel on right (3).
Scheme 67
64 22 191 Removing and installing/replacing rear compartment fresh air grill
Necessary preliminary tasks
- Remove insert in center console at rear bottom. See «51 16... REMOVING AND INSTALLING/REPLACING REAR INSERT (IN STORAGE COMPARTMENT)»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-removing-and-installingreplacing-rear) .
Detach clips (1) in direction of arrow.
Remove rear compartment fresh-air grill (2) in direction of arrow and unlock plug connection (3) underneath.
Installation
Make sure rear compartment fresh-air grill (2) and clips (1) are correctly seated.
Scheme 68
64 22 198 Removing And Installing/Replacing Fresh-Air Grille In Rear Console (Long Version)
Necessary preliminary tasks
- Remove «REAR CONSOLE TRIM»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-268-removing-and-installing)
Remove clips (1).
Remove rear cabin fresh-air grille (2) and disconnect plug connection behind.
Installation
Make sure rear compartment fresh-air grille (2) and clips (1) are correctly seated.
Scheme 69
64 31 010 Replacing microfilter for interior ventilation
If necessary, disconnect plug connection for engine hood contact switch.
Turn quick-release fastener (1) approx. 90° counterclockwise.
Open holder (2) in direction of arrow.
Remove microfilter air duct (3) in direction of arrow.
Installation
Make sure microfilter air duct (3) is correctly seated.
Scheme 70
Lever microfilter for interior ventilation (1) in direction of arrow out of microfilter air duct (2) and remove.
Installation
Make sure microfilter for interior ventilation (1) is correctly seated in microfilter air duct (2).
Scheme 71
64 31 053 Removing and installing or replacing fresh air duct
Necessary preliminary tasks
All models
- Remove microfilter housing lower sections on left and right. See «64 31 061 Removing And Installing/Replacing Left Or Right Microfilter Housing Lower Section»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-061-removing-and-installingreplacing) .
- Remove tension strut on spring strut dome. See «51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME»(/bmw/m5/e60e61-2004-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-373-removing-and-installingreplacing) .
M57 only
- Remove air cleaner element.
Unscrew bolt (1).
Installation
Tightening torque, see 64 31 2AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Loosen screws (2).
Installation
Tightening torque, see 64 31 1AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Turn quick-release fastener (3) approx. 90° counterclockwise.
If necessary, release screw on pipe clamp.
Scheme 72
Installation
Tightening torque, see 64 31 3AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Feed out fresh air duct (4) in direction of arrow and remove.
Installation
If necessary, replace damaged seals.
Make sure fresh air duct (4) is correctly seated.
64 31 061 Removing and installing/replacing left or right microfilter housing lower section
Necessary preliminary tasks
- Remove microfilter air duct. See «64 31 010 Replacing Microfilter For Interior Ventilation»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-010-replacing-microfilter-for) .
Left microfilter housing lower section
Unclip hose.
Installation
Make sure hose is correctly seated.
Right microfilter housing lower section
Installation
Ensure correct cable routing.
Left or right microfilter housing lower section
Partially detach engine compartment gasket (1).
Unscrew bolt (2).
Turn quick-release fasteners (3) approx. 90° counterclockwise.
Feed out microfilter housing lower section (4) in direction of arrow and remove.
Installation
Make sure microfilter housing lower section (4) is correctly seated.
Scheme 73
64 50... Air conditioner test (R 134a)
Before A/C efficiency test, satisfy following conditions
- Provide a MoDiC or DIS.
- Provide a thermometer with separate gauge.
- Compressor load (intake air temperature of approx. 50°C)
Re 1
Connect MoDiC or DIS to car and display evaporator temperature.
Re 2
Position a thermometer with a separate gauge approx. 5 cm below the roofliner at the height of the B-pillar. Lay gauge outwards out of vehicle interior.
Re 3
Heating up vehicle interior
- A/C button is not activated during heating up.
- Close all windows and doors.
- Set recirculated air mode.
- Select air distribution mode for footwell and defrosting.
- Maximum temperature setting.
- Maximum fan stage.
- Run engine at approx. 2000 RPM.
A/C efficiency test
Turn on A/C compressor at a vehicle interior temperature of 50°C.
After 2 of 3 minutes, evaporator sensor temperature must be 10°C.
Draw Off A/C system if this temperature is not reached. Measure amount of refrigerant drawn off.
If drawn-off quantity does not correspond to specified fill quantity: replenish refrigerant. See HEATING AND AIR CONDITIONING - TECHNICAL DATA .
If refrigerant quantity is correct fill A/C system.
Note. A/C systems with uncontrolled compressors only: If necessary, then continue troubleshooting by pressure measurement.
64 50... Leak-testing with leak tester device
| WARNING | Avoid contact with refrigerant. Follow Safety Precautions When Handling Refrigerant . |
Carry out leak-testing with a leak tester device from the workshop equipment catalog following the device manufacturer's operating instructions.
If leaks not to be localized are already identified during evacuation, the A/C system must nevertheless be filled. Then test for leaks with leak tester device.
Note. Refrigerant is heavier than air. Therefore always conduct the leak test below the lines and components to be tested. Shield lines and components against strong blasts of air (wind, drawing off).
Tighten down loose lines, mark leaks.
Then draw off draw off A/C system and seal off or repair leakage points.
Then refill A/C system and test for leaks.
64 50... Safety instructions for handling refrigerant R 134a
| WARNING | Although R 134a at normal temperature is non-toxic, non-flammable and not explosive in air in any mixture ratio, it is still essential to follow various safety precautions. |
The filled refrigerant circuit of the A/C system is subject to gauge pressure. When carrying out repairs on the A/C system, it is absolutely essential to draw off the refrigerant.
Do not weld or solder on filled A/C systems or in rooms into which R 134a may have leaked. Exposure to flames or high temperatures (50°C) may give rise to toxic decomposition products (fluorine gas). For this reason, do not smoke either.
R 134a must be drawn off, cleaned and returned to the A/C system with a service station following the relevant operating instructions.
Avoid all contact with liquid or gaseous R 134a. Wear protective goggles and gloves when working on the refrigerant circuit. R 134a acting on the skin can cause frostbite. Wash off thoroughly with cold water. If R 134a gets into your eyes, likewise rinse with plenty of water and, if necessary, remove contact lenses if worn. Then seek immediate medical attention. Likewise seek immediate medical attention if you experience problems after inhaling R 134a fumes.
As a gas, R 134a is colorless, odorless and heavier than air. If it gets into the atmosphere, this may result especially in workshop pits in an imperceptible danger of asphyxiation or in cardiac palpitations. Ventilate rooms adequately; if necessary, turn on installed extractor systems.
For a properly functioning A/C system, it is essential to have the greatest possible levels of cleanliness when working on the A/C system and the best possible evacuation (at least 30 minutes dehumidification from refrigerant circuit) before each filling of the A/C system.
R 134a absorbs moisture very easily. Therefore seal off opened pipes, condenser, evaporator, compressor and drier bottle immediately with plugs.
With replacement parts, the plugs may only be removed immediately before the lines are connected.
In the event of warranty claims, the old parts must be provided with plugs to be able to determine the cause of the damage.
If an A/C system has been completely drained by leakage, accident or repair, the drier element must be replace as excessive moisture may have entered the system.
Store filled pressurized refrigerant bottles in such a way that they are not exposed to direct sunlight or other heat sources (max. 45°C). Also avoid exposing them to mechanical stress (e.g. by dropping).
In the event of fire, carbon dioxide, extinguisher powder and a sprayed water jet are deemed to be suitable extinguishants. Cool reservoirs at risk with a sprayed water jet (risk of bursting!).
| CAUTION | After each refill of an A/C system, check that protective caps of filling valves are hand-tight. They serve as additional seals. |
64 50... Safety precautions when handling refrigerant oil (for refrigerant R 134a)
| WARNING | Observe the following points when handling refrigerant oil: Wear protective goggles. Wear gloves made from impermeable plastic. Do not swallow. Do not inhale. Action to be taken after contact with refrigerant oil: After contact with eyes, rinse thoroughly with plenty of water and take out contact lenses (if worn). Then seek immediate medical attention. After contact with the skin, wash body parts affected with plenty of soap and water. Do not induce vomiting if oil is swallowed, seek immediate medical attention. If inhaled, introduce the person affected to fresh air. Seek medical attention if problems persist. |
| WARNING | Refrigerant oil is non-combustible and non-explosive at normal temperatures. In spite of this, the following precautions must be observed: Do not store in the vicinity of flames, heat sources or strongly oxidizing materials. Suitable extinguishants: carbon dioxide, dry extinguishant, foam. |
Recycling
Dispose of drawn-off refrigerant oil as hazardous waste.
Observe country-specific waste-disposal regulations.
Absorb escaping refrigerant oil with fluid-binding material.
Notify the relevant authorities if larger amounts of refrigerant oil are discharged into above-ground water supplies, drainage systems or subsoil.
64 50 009 Drawing off, evacuating and filling A/C system (R 134a)
| WARNING | Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant R 134a. Follow Safety Instructions For Handling Refrigerant Oil . |
| IMPORTANT | Risk of damage! |
Restart engine only when A/C system has been correctly filled.
Note. Draw off, evacuate and fill the A/C system in accordance with the operating instructions of the relevant service station.
E60 only
If necessary, to connect service station, use manufacturer's adapter for high-pressure connection (red).
Instructions for drawing off A/C system
To help separation of refrigerant and refrigerant oil, run engine at low speed (800 of 1200 RPM) and with A/C system turned on for a few minutes.
This limits the entrapment of refrigerant oil while it is drawn off.
Drawn-off refrigerant oil must be changed and reintroduced via the service station.
If at the end of the drawing-off procedure the service station moisture indicator shows that the drawn-off refrigerant is excessively moist, clean the refrigerant in accordance with the service station operating instructions.
Recycling
Dispose of drawn-off refrigerant oil as hazardous waste.
Observe country-specific waste-disposal regulations.
Instructions for evacuating off A/C system
The evacuation procedure removes all traces of ambient air, water vapor and any other gases present from the A/C system.
This enables subsequent system filling with refrigerant.
A decrease in the vacuum level indicates a leak in the refrigerant circuit.
Instructions for filling A/C system
Before filling with refrigerant, top up the refrigerant oil entrained during drawing off.
Depending on the type of component replaced on the A/C system, it may be necessary to top up the refrigerant oil, even if no measurable losses have occurred during drawing off. Read and comply with the A/C system manufacturer's notes in this regard and the operating instructions of the relevant service station.
Information on the required refrigerant fill quantity for the entire A/C system is contained on the rating plate (1) in the engine compartment.
If necessary, refer to HEATING AND AIR CONDITIONING - TECHNICAL DATA for fill quantities.
Scheme 74
Installation
Reseal refrigerant filler necks on vehicle with sealing caps.
64 51 001 Cleaning evaporator
Special Tools Required
- 64 1 480
Note. For information on cleaning agent and rinsing again, refer to AUTOMATIC HEATING/AIR-CONDITIONING SYSTEM - SERVICE INFORMATION . For information on spraying equipment, refer to AIR CONDITIONING & HEATING - SPECIAL TOOLS .
| WARNING | When handling cleaning agent, observe following protection measures: Wear protective rubber gloves and protective goggles. If cleaning agent comes into contact with eyes or skin, wash immediately with lots of water. |
| IMPORTANT | To avoid dirtying vehicle interior |
- Close all air vents.
- Switch heating - A/C system to recirculated-air mode.
Recycling
Carry out the cleaning operation in a suitable washing bay as the emerging cleaning agent escapes through the drain openings in the transmission tunnel.
After completing cleaning, allow car to drip-dry for approx. 5 minutes.
Necessary preliminary tasks
- Remove fresh air duct. See «64 31 053 Removing And Installing Or Replacing Fresh Air Duct»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-053-removing-and-installing) .
Partially detach transmission underbody protection (6) for draining cleaning fluid
Release screws (2... 4) in rear area and press heat shield (5) away.
Scheme 75
Connect special tool 64 1 480 (spray lance) to spraying equipment.
Insert spray lance (1) through opening (2) to fresh air duct.
By moving spray lance (1) back and forth, spray a uniform amount of cleaning agent onto evaporator.
Scheme 76
Note. After rinsing with water, blow out evaporator with spray lance and air only for approx. 5 minutes. Do this predominantly in the center of the evaporator to dry the fan motor behind. Set heating - A/C system to footwell ventilation and fresh-air mode. Open windows/doors. Start car and run heating - A/C system at maximum fan power for approx. 5 minutes in order to dry heating - A/C system. In order to eliminate the last remnants of cleaning agent, repeat this procedure shortly before handover to the customer.
64 51 525 Removing and installing or replacing expansion valve
Necessary preliminary tasks
- Draw off refrigerant from A/C system. See «64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a)»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-50-009-drawing-off-evacuating) .
- Remove fresh air duct. See «64 31 053 Removing And Installing Or Replacing Fresh Air Duct»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-053-removing-and-installing) .
Feed out rubber grommet (1).
Installation
Make sure rubber grommet (1) is correctly seated.
Unscrew nut (2).
Installation
Tightening torque, see 64 53 7AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Detach refrigerant lines (3) and (4) in direction of arrow.
Installation
Replace sealing rings.
Scheme 77
Release screws (1).
Installation
Tightening torque, see 64 53 9AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Detach expansion valve (2) in direction of arrow.
Installation
Replace sealing rings.
Make sure soundproofing (3) is correctly seated.
Scheme 78
64 51 591 Removing and installing/replacing evaporator
Necessary preliminary tasks
- Remove heater. See «64 11 206 Removing And Installing Or Replacing Heater»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-206-removing-and-installing) .
- Remove heater core. See «64 11 208 Replacing Heater Core»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-208-replacing-heater-core) .
- Remove expansion valve. See «64 51 525 Removing And Installing Or Replacing Expansion Valve»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-51-525-removing-and-installing) .
- Remove rear compartment air duct. See «64 11 213 Removing And Installing/Replacing Heater - A/C Unit Fan»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-213-removing-and-installingreplacing) .
- Remove fan for heater/air conditioner. See «64 11 213 REMOVING AND INSTALLING/REPLACING HEATER - A/C unit fan»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-213-removing-and-installingreplacing) .
- Remove servodrive of left fresh-air/recirculated-air flap. See «64 11 803 Removing And Installing/Replacing Servodrive For Left Fresh-Air/Recirculated-Air Flap»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-11-803-removing-and-installingreplacing) .
Carefully pull off bulkhead seals (1) from heater/air conditioner (2) so that there are no remaining parts left behind.
Installation
Replace bulkhead seals (1).
Scheme 79
Release screws (1).
Press lock (2).
Remove pipe holder (3) complete with pipes (4).
Scheme 80
Release screws (1).
Scheme 81
Release screws (1).
Installation
Make sure flaps (2) are correctly seated in mountings (3).
Scheme 82
Release screws (1).
Remove upper housing section (2) in direction of arrow.
Installation
Make sure upper housing section (2) is correctly seated on lower housing section.
Make sure flaps (3) are correctly seated in mountings (4).
Scheme 83
Release screws (1).
Release clip (2).
Remove cover (3) in direction of arrow.
Installation
Make sure cover (3) is correctly seated.
Scheme 84
| IMPORTANT | Do not bend radiator fins. |
If necessary, clean or straighten radiator fins with slat comb.
Pull evaporator (1) in direction of arrow out of lower housing section (2).
Installation
If necessary, replace seal (3).
Make sure seal (3) is correctly seated in lower housing section (2).
Scheme 85
Replacement
Remove plate (2) and seal (3) from evaporator (3).
Scheme 86
64 52... Instructions for compressor replacement
| IMPORTANT | Compressors with plastic belt pulleys |
- Avoid impacts/knocks to plastic belt pulley (caused by tools, contact with base).
- Return faulty compressors in their original packaging only.
| IMPORTANT | When starting up a new compressor for the first time, it is absolutely essential to carry out the following breaking-in procedure |
- Switch on A/C system
- Set all air vents in instrument cluster to "OPEN"
- Start engine and let it stabilize at idle speed
- Set blower output to min. 75% of max. blower output
- Switch on A/C system and run for at least 2 minutes at idle speed (risk of damage at higher speed!)
When evacuating the air-conditioning system, refrigerant oil is also extracted and collected in the oil separator of the service station.
After evacuation, the refrigerant must be filtered in the service station as the oil separator could still contain a liquid refrigerant/oil mixture. The filtering process gasifies the refrigerant completely and only the previously bound refrigerant oil remains in the oil separator. Measure and note down this quantity of refrigerant oil
refer to Evacuating A/C system. See 64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a) .
Scheme 87
Transfer the refrigerant oil remaining in the previous compressor via the filler plug completely into a measuring container.
Scheme 88
Measure the amount of refrigerant oil collected from the previous compressor.
Scheme 89
Depending on its design, the new compressor is filled at the factory with 120 to 200 g refrigerant oil. Open filler plug and pour entire contents of compressor into a clean container.
Installation
If necessary, replace gasket.
Observe tightening torque, see 64 52 2AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Scheme 90
From this refrigerant oil, pour the same amount (as drained from the previous compressor) + 10 g extra into a clean measuring container and pour again into the new compressor.
Remaining refrigerant oil can be poured into service station tank
refer to Evacuating A/C system, see 64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a). (Scheme 87).
Otherwise the excess refrigerant oil must be disposed of correctly.
On account of its hygroscopic properties, refrigerant oil must not be stored in open containers.
Scheme 91
The refrigerant oil drawn off from the oil separator of the service station and from the previous compressor must not be reused and must be correctly disposed of.
Scheme 92
After installing the new compressor, it is essential before filling the A/C system to pour the same amount of the previously drawn off refrigerant oil into the system again
refer to Evacuating A/C system, see 64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a) .
Scheme 93
Installation
If A/C system is opened for more than 24 hours: Replace drier bottle/drier insert.
64 52 ... Notes/instructions on working on air-conditioning systems
| WARNING | Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant R 134a. See 64 50... Safety Instructions For Handling Refrigerant R 134a . Follow safety instructions for handling refrigerant oil. See 64 50... Safety Instructions For Handling Refrigerant R 134a . Scalding hazard! Work on the cooling system may only be carried out when it has cooled down. |
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. Read and comply with notes on replacing compressor. See 64 52... Instructions For Compressor Replacement . |
Note. If A/C system is opened for more than 24 hours: Replace desiccant insert for A/C system. See 64 53 517 Replacing Desiccant Insert For A/C System .
| IMPORTANT | N52 engine only: Aluminium-magnesium materials. No steel screws/bolts may be used due to the threat of electrochemical corrosion. A magnesium crankcase requires aluminum screws/bolts exclusively. Aluminum screws/bolts must be replaced each time they are released. The end faces of aluminum screws/bolts are painted blue for the purposes of reliable identification. Jointing torque and angle of rotation must be observed without fail (risk of damage). |
64 52 523 Replacing compressor for air conditioner
| IMPORTANT | Risk of damage! |
Follow instructions for compressor replacement without fail. See 64 52... Instructions For Compressor Replacement .
Necessary preliminary tasks
All models
- Draw off refrigerant from A/C system. See «64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a)»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-50-009-drawing-off-evacuating) .
- Remove front underbody protection.
M54 only
- Release coolant expansion tank, disconnect plug connection and place coolant expansion tank to one side.
Version with Dynamic Drive
Do not release pressure lines on active stabilizer.
Press lock (1) on distributor (2) and detach vent line (3) in direction of arrow.
Installation
Make sure vent line (3) is correctly seated in distributor (2).
Lower stabilizer on front axle.
Scheme 94
Version with Dynamic Drive
Release nuts (1) and (2).
Remove retaining fixture (3).
Installation
Make sure retaining fixture (3) is correctly seated.
Scheme 95
All models
Unfasten plug connection (1) and disconnect.
Loosen screws (2).
Installation
Tightening torque, see 64 52 1AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Detach refrigerant lines (3) in direction of arrow.
Installation
Replace sealing rings.
Scheme 96
All models
Note. Secure A/C compressor (2) against falling out.
Release screws (1).
Feed out A/C compressor (2) in direction of arrow.
Scheme 97
64 53... Notes on replacing drier bottle or drier insert
The drier bottle or drier insert does not have to be replaced at regular service intervals in a functioning, leakproof A/C system.
However, the drier bottle or drier insert must be replaced without fail in the event of
- fouling of the refrigerant by filings/shavings (e.g. when the compressor is clamped)
- a leaking A/C system or loss of refrigerant
- the refrigerant circuit being opened for a period exceeding 24 hours, e.g. during repair work.
64 53 517 Replacing desiccant insert for A/C system
Necessary preliminary tasks
- Remove Condenser For A/C System. See «64 53 551 Removing And Installing Or Replacing Condenser For A / C System»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-53-551-removing-and-installing) .
With condenser removed, operation is described in
- Replacing desiccant insert for A/C system (condenser removed), see «64 53 518 Replacing Desiccant Insert For A/C System (Condenser Removed)»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-53-518-replacing-desiccant-insert) .
64 53 518 Replacing desiccant insert for A/C system (condenser removed)
| WARNING | Read and comply with warnings relating to working on A/C systems. See 64 52 ... Notes/Instructions On Working On Air-Conditioning Systems . |
Remove protective cap (1) from condenser for A/C system (2).
Scheme 98
Press sealing cap (1) inwards and remove circlip (2).
Scheme 99
Remove protective cap (2) from condenser for A/C system (3) with aid of an inserted screw (1).
Scheme 100
During installation, replace sealing rings (1) of sealing cap (2) and coat with suitable refrigerant oil.
Scheme 101
Remove desiccant insert for A/C system (1) in direction of arrow from condenser for A/C system (2).
Scheme 102
64 53 520 Replacing safety pressure switch
| WARNING | Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant R 134a. See 64 50... Safety Instructions For Handling Refrigerant R 134a . Follow safety instructions for handling refrigerant oil. See 64 50... Safety Instructions For Handling Refrigerant R 134a . |
Note. The time value given for this work operation does not include drawing off, evacuating and filling the A/C system!
Drain off air conditioner. See 64 50 009 Drawing off, evacuating and filling A/C system (R 134a) .
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. |
Note. If A/C system is opened for more than 24 hours: Replace desiccant insert for A/C system. See 64 53 518 Replacing desiccant Insert For A/C System (Condenser Removed) .
If necessary, release holder for lines (not illustrated). Disconnect plug connection (1). Release safety pressure switch (2). For tightening torque, see 64 53 13AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Scheme 103
64 53 551 Removing and installing or replacing condenser for A/C system
| WARNING | Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant R 134a. See 64 50... Safety Precautions When Handling Refrigerant Oil (For Refrigerant R 134a) . Follow safety instructions for handling refrigerant oil. See 64 50... Safety Precautions When Handling Refrigerant Oil (For Refrigerant R 134a) . |
- Drain off air conditioner. See «64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a)»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-50-009-drawing-off-evacuating) .
| IMPORTANT | Risk of damage! |
Restart engine only when A/C system has been correctly filled.
Note. If A/C system is opened for more than 24 hours: Replace drier insert for A/C system. See 64 53 517 Replacing Desiccant Insert For A/C System .
| IMPORTANT | Do not place front panel center section (2) on jump start terminals. |
Do not kink Bowden cables for engine hood locking.
Release screws (1).
Remove front panel center section (2) in direction of arrow and place to one side.
Scheme 104
Release screws (1).
Remove radiator cover (2) in direction of arrow.
Scheme 105
Release screws (1).
Installation
Tightening torque, see 64 53 6AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES article.
Remove refrigerant lines (2) in direction of arrow and place to one side.
Installation
Replace sealing rings (1) and (2) and coat with suitable refrigerant oil.
Pull out condenser for A/C system (3) in direction of arrow.
Scheme 106
64 53 642 Replacing line from compressor to condenser (S85)
| WARNING | Risk of injury! Refrigerant circuit is under high pressure! Follow safety instructions for handling R 134a refrigerant. Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant oil. |
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. Follow instructions for opening and replacing parts in refrigerant circuit. If A/C system is opened for more than 24 hours: Replace desiccant insert for A/C system |
Necessary preliminary tasks
- Remove right intake filter housing See «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .
| IMPORTANT | Do not place front panel center section (2) on jump start terminals. Do not kink Bowden cables of engine hood/bonnet lock. |
Release screws (1).
Remove front panel center section in direction of arrow and place to one side.
Scheme 107
Release screw (1).
Installation
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 52 1AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Scheme 108
Undo screw (1) and feed out refrigerant line (2).
Installation
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 53 6AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Scheme 109
After installation
- Evacuate and fill A/C system
64 53 691 Replacing line from evaporator to condenser (S85)
| WARNING | Risk of injury! Refrigerant circuit is under high pressure! Follow safety instructions for handling R 134a refrigerant. Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant oil. |
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. Follow instructions for opening and replacing parts in refrigerant circuit. If A/C system is opened for more than 24 hours: Replace desiccant insert for A/C system |
Necessary preliminary tasks
- Remove fresh air duct . See «64 31 053 Removing And Installing Or Replacing Fresh Air Duct»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-053-removing-and-installing) .
- Remove right intake filter housing . See «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .
- Detach fluid reservoir for power steering and place to one side.
Feed out rubber grommet (1).
Release nut (2) and detach refrigerant lines (3,4) in direction of arrow.
Installation
Make sure rubber grommet (1) is correctly seated.
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 53 7AZ. in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Scheme 110
| IMPORTANT | Do not place front panel center section (2) on jump start terminals. Do not kink Bowden cables for engine hood locking. |
Release screws (1).
Remove front panel center section (2) in direction of arrow and place to one side.
Scheme 111
Undo screw (1) and feed out refrigerant line (2).
Installation
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 53 6AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Replacement
Modify safety pressure switch.
Scheme 112
After installation
- Evacuate and fill A/C system
64 53 702 Replacing line from evaporator to compressor (S85)
| WARNING | Risk of injury! Refrigerant circuit is under high pressure! Follow safety instructions for handling R 134a refrigerant. Avoid contact with refrigerant and refrigerant oil. Follow safety instructions for handling refrigerant oil. |
| IMPORTANT | Risk of damage! Restart engine only when A/C system has been correctly filled. Follow instructions for opening and replacing parts in refrigerant circuit. If A/C system is opened for more than 24 hours: Replace desiccant insert for A/C system |
Necessary preliminary tasks
- Remove fresh air duct . See «64 31 053 Removing And Installing Or Replacing Fresh Air Duct»(/bmw/m5/e60e61-2004-2010/remont/automatic-hvac-system/#heating-air-conditioning-repair__64-31-053-removing-and-installing) .
- Remove right intake filter housing . See «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m5/e60e61-2004-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .
- Detach fluid reservoir for power steering and place to one side.
Feed out rubber grommet (1).
Release nut (2) and detach refrigerant lines (3,4) in direction of arrow.
Installation
Make sure rubber grommet (1) is correctly seated.
Replace sealing rings and moisten with refrigerant oil.
Tightening torque 64 53 7AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Release nuts (1) and remove bracket.
Release screw (2) and remove refrigerant line (3).
Tightening torque 64 53 6AZ in AIR CONDITIONING & HEATING - TIGHTENING TORQUES
Feed out refrigerant line (3).
Installation
Replace sealing rings and moisten with refrigerant oil.
Scheme 113
After installation
- Evacuate and fill A/C system
See also:
• 51 45 030 REMOVING AND INSTALLING INSTRUMENT
• AIR CONDITIONING & HEATING - TIGHTENING TORQUES
• 61 00... NOTES ON HANDLING OPTICAL FIBERS
• 65 11 072 REMOVING AND INSTALLING/REPLACING CD CHANGER
• BODY EQUIPMENT - TIGHTENING TORQUES - 525i & 530i
• 51 16 200 REMOVING AND INSTALLING STORAGE COMPARTMENT
• 65 12 200 REMOVING AND INSTALLING (REPLACING) AUDIO SYSTEM CONTROLLER
• 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY
• 51 16 366 REMOVING AND INSTALLING RIGHT GLOVEBOX WITH HOUSING
• 51 45 310 REMOVING AND INSTALLING (REPLACING) CENTER TRIM FOR INSTRUMENT PANEL
• 51 45 181 REMOVING AND INSTALLING/REPLACING BOTTOM RIGHT TRIM FOR INSTRUMENT PANEL
• 65 82 050 REMOVING AND INSTALLING (REPLACING) ON-BOARD MONITOR
• 61 35 177 REMOVING AND INSTALLING (REPLACING) RAIN/LIGHT SENSOR
• 51 45 115 REMOVING AND INSTALLING SPEAKER FRAME ON PANEL FOR INSTRUMENT PANEL
• 51 71 040 REMOVING AND INSTALLING/REPLACING FRONT LEFT OR RIGHT WHEEL ARCH COVER
• 51 47... REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT UNDERBODY PANELING
• 51 45 370 REMOVING AND INSTALLING (REPLACING) LEFT DECORATIVE STRIP ON INSTRUMENT PANEL
• 51 45 380 REMOVING AND INSTALLING (REPLACING) RIGHT DECORATIVE STRIP ON INSTRUMENT PANEL
• 51 16... REMOVING AND INSTALLING/REPLACING REAR INSERT (IN STORAGE COMPARTMENT)
• REAR CONSOLE TRIM
• 51 71 373 REMOVING AND INSTALLING/REPLACING TENSION STRUT ON SPRING STRUT DOME
• AUTOMATIC HEATING/AIR-CONDITIONING SYSTEM - SERVICE INFORMATION
• AIR CONDITIONING & HEATING - SPECIAL TOOLS
• 13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)
• 64 50 009 Drawing Off, Evacuating And Filling A/C System (R 134a)
• 64 31 053 Removing And Installing Or Replacing Fresh Air Duct
• 64 11 916 Replacing Temperature Sensor For Cold-Air Distributor
• 64 11 206 Removing And Installing Or Replacing Heater
• Removing And Installing/Replacing Heater-A/C Unit Fan
• 64 11 943 Replacing Evaporator Temperature Sensor
• 64 11... Installing Servodrive
• 64 11 377 REMOVING AND INSTALLING (REPLACING) CONTROL PANEL FOR HEATER - A/C system
• 64 12 021 Removing And Installing Independent/Auxiliary Heater
• 64 12 525 Replacing Complete Independent Heater
• 64 31 061 Removing And Installing/Replacing Left Or Right Microfilter Housing Lower Section
• 64 31 010 Replacing Microfilter For Interior Ventilation
• Safety Precautions When Handling Refrigerant
• Follow Safety Instructions For Handling Refrigerant Oil
• 64 11 208 Replacing Heater Core
• 64 51 525 Removing And Installing Or Replacing Expansion Valve
• 64 11 803 Removing And Installing/Replacing Servodrive For Left Fresh-Air/Recirculated-Air Flap
• 64 52... Instructions For Compressor Replacement
• 64 53 517 Replacing Desiccant Insert For A/C System
• 64 53 551 Removing And Installing Or Replacing Condenser For A / C System
• 64 53 518 Replacing Desiccant Insert For A/C System (Condenser Removed)
• 64 52 ... Notes/Instructions On Working On Air-Conditioning Systems
