86 10... Adjusting brake system
Proper adjustment of the brake system is only possible if the brake Bowden cables and all brake system moving parts move freely and are ready for operation.
The wheels must be completely fitted and able to rotate freely. Always adjust both brake sides. The left and right sides are adjusted in the same way.
Pull out overrunning equipment (1) fully in direction of arrow.
Scheme 6
Reversing lever (1) must rest directly on inner-lying tow tube of overrunning brake.
Scheme 7
Screw brake linkage (1) into nut (2) until distance (3) (nut (2) - end of brake linkage (1)), is 10 - 15mm. Lock brake linkage (1) in position with nut (4).
Check distance (3) and nuts (2, 4) with brake linkage installed.
Scheme 8
Insert pull rod (1) in brake compensator (2) and screw nut (3) onto pull rod (2).
Tighten nut (3) until pull rod (1) is free of play.
Check pull rod (1) already fitted for zero play.
Scheme 9
Hook tension spring (1) to tension spring mount (2).
Installation
The brake shoes are adjusted in two work steps. In the first step, the distance between the lower half of the brake shoes and the brake drum is adjusted. In the second step, the distance between the upper half of the brake shoes and the brake drum is adjusted.
Scheme 10
Rotate road wheel (1) in direction of travel and simultaneously turn adjusting screw (2) in direction of arrow.
Tighten adjusting screw (2) until road wheel (1) can no longer be turned.
Scheme 11
Turn adjusting screw (1) in direction of arrow and release slowly until road wheel (2) can rotate.
Finish adjustment procedure when slight grinding noises can be heard in lower brake shoe halves.
Scheme 12
Firmly tighten handbrake lever three to five times.
Depending on road wheel side, tighten nut (1) or (2) until slight grinding noises can be heard in upper brake shoe halves.
Scheme 13
86 10... Adjusting spring force accumulator
The spring force accumulator requires no maintenance and generally does not need to be readjusted.
Adjustment dimension, spring force accumulator: distance between end of support tube - internal washer (1) is 90 mm.
Scheme 14
To tension spring force accumulator: turn nut (2) located in support tube (1) clockwise.
To relieve tension on spring force accumulator: turn nut (2) located in support tube (1) counterclockwise.
Scheme 15
86 10... Disassembly of Camlock retaining cam
Unscrew bolts (1).
Scheme 16
86 10... Disassembly of base plate
Note. Disassembly of bar REFER TO 86 10... REPLACING BAR Disassembly of lashing plate REFER TO 86 10... REPLACING LASHING PLATE AND LASHING EYE Disassembly of 12 volt socket REFER TO 86 10... REPLACING 12 VOLT SOCKET Remove plastic bush/metal bush REFER TO 86 10... REMOVING PLASTIC BUSH/METAL BUSH Disassembly of light guard REFER TO 86 10... REPLACING REAR LIGHT Disassembly of front apron REFER TO 86 10... DISASSEMBLY OF FRONT APRON Disassembly of left and right aprons REFER TO 86 10... DISASSEMBLY OF LEFT AND RIGHT APRONS Disassembly of left and right wheel boxes REFER TO 86 10... DISASSEMBLY OF LEFT AND RIGHT WHEEL BOXES Disassembly of rear apron REFER TO 86 10... DISASSEMBLY OF REAR APRON Disassembly of left and right lamp housings REFER TO 86 10... DISASSEMBLY OF LEFT AND RIGHT LAMP HOUSINGS Disassembly of rivet connection, rear support REFER TO 86 10... DISASSEMBLY PROCEDURE OF RIVET CONNECTION, REAR SUPPORT
Unscrew bolts (1).
| CAUTION | Before drilling out rivet heads, drive in rivet pins with a punch. Drill out rivet connections (2). |
Installation
Tightening Torque
Scheme 17
86 10... Disassembly of bracket on platform base
Unscrew bolts (1).
Scheme 18
86 10... Disassembly of front apron
Drill out rivets (1) on lower apron edge.
Scheme 19
Remove sealing compound (1).
Drill out rivets (2).
Installation
Use Sikaflex 221 as sealing compound.
Scheme 20
Press side sections (1) to side in direction of arrow. Tilt center section (2) downwards and remove to side.
Installation
Use Sikaflex 221 as sealing compound.
Scheme 21
86 10... Disassembly of front protection bar
Release screws (1) on cross-member (2).
Installation
Use new self-locking nuts.
Tightening Torque
Installation
Tightening Torque
Scheme 22
Release screws (1) on longitudinal member (2).
Installation
Tightening Torque
Scheme 23
86 10... Disassembly of jockey wheel or jockey wheel mount
Turn clamping lever (1) in direction of arrow and release clamping connection. Open clamping bracket (2) and remove jockey wheel (3). Release screws on mount (4) and remove screws.
Installation
Tightening Torque
Scheme 24
86 10... Disassembly of left and right aprons
Note. Remove position light, REFER TO 86 10... REPLACING POSITION LIGHT. Remove rear light, REFER TO 86 10... REPLACING REAR LIGHT. Remove plastic bush/metal bush REFER TO 86 10... REMOVING PLASTIC BUSH/METAL BUSH.
Drill out rivets (1) on lower apron edge.
Scheme 25
Remove sealing compound (1).
Drill out all rivets (2) along apron edge.
Installation
Use Sikaflex 221 as sealing compound.
Scheme 26
Remove sealing compound (1).
Drill out rivets (2) on lower apron edge.
Installation
Use Sikaflex 221 as sealing compound.
Scheme 27
86 10... Disassembly of left and right lamp housings
Cut through sealing compound (1) and remove.
Drill out rivet connections (2).
Installation
Use Sikaflex 221 as sealing compound.
Scheme 28
Drill out rivet connections (1).
Raise side sections (2, 3).
Pull out lamp housing (4) towards inside in direction of platform.
Scheme 29
86 10... Disassembly of left and right wheel boxes
Remove sealing compound (1).
Drill out rivets (2).
Raise side apron (3). Pull out wheel box (4) towards rear.
Installation
Use Sikaflex 221 as sealing compound.
Scheme 30
86 10... Disassembly of licence plate mounting plate
| CAUTION | Once the connecting screws (1) have been removed, the closing spring of the hinge retracts. Risk of trapping! |
Release screws (1) in loading ramp frame (2) on left and right sides.
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 31
86 10... Disassembly of loading ramp frame/disassembly of rail, left/right
Note. Two persons are required to disassemble the loading ramp frame. Disassembly of license plate mounting plate REFER TO 86 10... DISASSEMBLY OF LICENSE PLATE mounting plate. Disassembly of pull rod
Release screws (1) of loading ramp frame (2) on cross-strut (3).
Installation
Tightening Torque
Scheme 32
Release screws (1, 2) on left and right sides of loading ramp frame (3).
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 33
Release screws (1, 2, 3).
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 34
86 10... Disassembly of rear apron
Note. Remove rear light, REFER TO 86 10... REPLACING REAR LIGHT. Remove plastic bush/metal bush REFER TO 86 10... REMOVING PLASTIC BUSH/METAL BUSH.
Cut through sealing compound (1) on left and right and remove.
Drill out rivets (2) on left and right sides on lower apron edge.
Installation
Use Sikaflex 221 as sealing compound.
Scheme 35
Cut through sealing compound (1) and remove.
Drill out rivets (2).
Installation
Use Sikaflex 221 as sealing compound.
Scheme 36
86 10... Disconnecting plug connection, wiring harness, front/rear
Spread levers (1) on socket housing apart in direction of arrow and disconnect female connector (2) in direction of arrow towards bottom.
Scheme 37
86 10... Installation position of BMW lettering
Top edge of lettering at same height as recess for position light (1).
Distance between drawbar member and lettering (2) is 300 mm.
Installation
Remove grease from gluing surfaces.
Scheme 38
86 10... Positioning of multitrailer hood for maintenance and repair work
| IMPORTANT | At least two persons are needed to install and remove the hood from the platform. Before installing and removing the hood, secure the BMW multitrailer and the entire combination against rolling. For this purpose, use the parking brake and the chocks of the BMW multitrailer. The hood can also be set up and lowered with the aid of the universal lift available from BMW in conjunction with the roof racks and the hood adapter. Under no circumstances should work of any kind be carried out below the suspended hood. |
For maintenance and repair work, raise the hood using a lifting platform. Twin-column lifting platforms, body lifting platforms and twin-stamp underfloor platforms are suitable. The seating plates and areas of the lifting platform must be adjustable according to the dimensions of (Scheme 39).
Scheme 39
The lifting platform must conform to the relevant legal provisions of the accident prevention regulations and be serviced as specified. Comply with the lifting platform operating instructions, in particular the safety instructions and the carrying capacity.
Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.
Please comply with the following instructions before raising the hood
- Raise only when it is unloaded
- Ensure sufficient clearance between the seating plates/seating areas and the GFP edge of the hood
- The hood must always be positioned in the middle of the lifting platform.
| IMPORTANT | The hood may only be raised at the pin (1). Under no circumstances may the hood be raised at the GFP edge of the hood (2). (Scheme 173) Exclusively for removal of pin (1), raise the hood in the GFP area. Also refer to: 86 21... REMOVING CENTERING PIN FROM MOUNTING BRACKET. |
Scheme 40
00 00... Raising BMW multi-trailer
| CAUTION | Twin-strut underfloor platforms and twin-pillar lifting platforms are suitable for raising the BMW multi-trailer. Lifting platforms with drive-on surfaces are not suitable for raising in order to carry out maintenance and repair work. |
The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions. It is essential to follow the lifting platform operating instructions, in particular the safety instructions and carrying capacity!
Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.
Before raising the BMW multi-trailer, please observe the following points
- Raise the trailer only when it is unloaded
- Remove a supplied loading ramp from the loading ramp frame so that all chassis areas of the BMW multi-trailer are freely accessible
- There must be sufficient clearance between the carrier arms/flat girder bridges and the GFK aprons or the front guard of the BMW multi-trailer
- The BMW multi-trailer must always be positioned in the middle of the lifting platform.
| CAUTION | You will need special additional supports for the lifting platform in order to bridge the difference in height between longitudinal member and lower edge of GFK side apron or front guard of the BMW multi-trailer. The minimum height of the additional supports is 145 mm. Use only the additional supports approved by the platform manufacturer or specified in these repair instructions. You will find appropriate examples in the repair instructions for the majority of lifting platforms present in BMW workshops. For lifting platforms that are not named, the relevant manufacturers will offer you appropriate additional supports. Please contact directly the manufacturer of the lifting platform used in your dealership. |
| CAUTION | The BMW multi-trailer may only be raised by its longitudinal members. Do not under any circumstances raise the BMW multi-trailer by the GFK aprons. Make sure the additional supports bear the longitudinal members over their entire width and no attachments or wiring harnesses are touched or jammed. Check the securing equipment of the additional supports for correct seating. Under no circumstances should any work be carried out underneath the BMW multi-trailer if it is not adequately secured against slipping off the lifting platform. |
The areas (2) on the longitudinal members (1) marked in the adjacent diagram are the best areas for attaching the additional supports.
Scheme 41
General notes on using twin-pillar lifting platforms
For the twin-pillar lifting platforms described, the BMW multi-trailer is positioned in the direction of travel on the platform. For lifting platforms which do not create sufficient clearance between disk wheel and carrier arms, move the BMW multi-trailer against the direction of travel onto the platform.
Becker & Sohne twin-strut underfloor platform
The BMW multi-trailer can only be raised if it is supported at right angles to the direction of travel. For raising, use the high additional supports (1) of Becker & Sohne.
Scheme 42
| CAUTION | Also lash the BMW multi-trailer to the flat girder bridges of the lifting platform. Flag the protruding tow hitch and the drawbar member of the BMW multi-trailer conspicuously so as to prevent injury, e.g. with a red cloth. |
MAHA twin-pillar lifting platform
The BMW multi-trailer can only be raised if you use the support plate attachment sleeves for transporters (1). Position the axle of the BMW multitrailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.
Scheme 43
Romaico-Lift twin-pillar lifting platform
The BMW multi-trailer can only be raised if you use the 146 mm high attachments (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.
Scheme 44
Working pit
The BMW multi-trailer can be serviced or repaired in conjunction with a working pit if the following measures are taken into consideration. The BMW multi-trailer must be secured against slipping/tilting sideways. The drawbar jockey wheel must be firmly secured against rolling.
86 10... Removing Camlock retaining cam on loading ramp
Drill out rivets (1).
Scheme 45
86 10... Removing Camlock screw cap
Bend back edges (1) of tab washer (2). Remove tab washer (2) over cross pin (3) towards bottom.
Installation
Replace lockplate.
Scheme 46
86 10... Removing and installing or replacing left or right coil spring
Release screw (1) and remove, tilt shock absorber (2) in direction of arrow towards rear.
Installation
Use new self-locking nut.
Hold shock absorber vertically and protective cap points upwards. Completely press in shock absorber once and pull out up to required installation length. Do not tilt shock absorber further than is needed for installation.
Tightening Torque
Scheme 47
The trailing arm folds down once the coil spring on the arm has been released.
No persons should be located underneath trailing arm. Risk of injury!
Release screw (1) between trailing arm (2) and coil spring.
Installation
Tightening Torque
Scheme 48
Remove pressure plate (1) from coil spring (2).
Installation
Use pressure plate with nut.
Fit pressure plate (1) according to its shape (3) into pressure spring (2).
Scheme 49
Release screw (1) between coil spring (2) and longitudinal member (3). Remove small pressure plate (4) and large pressure plate (5).
Installation
Use pressure plate without nut.
Fit small pressure plate (4) according to its shape (6) into pressure spring (2).
Tightening Torque
Scheme 50
Installation
Two persons are needed to install the coil spring correctly. One person presses down the pressure plate (2) seated inside the coil spring (1) and tightens the coil spring (1)/trailing arm (3) screw connection. At the same time, the second person levers the coil spring (1) with a screwdriver into its correct seat.
Tightening Torque for coil spring (1)/trailing arm (3)
Scheme 51
86 10... Removing bolt on loading ramp
Insert a drift into hole (1) of bolt (2) and turn clockwise.
Scheme 52
86 10... Removing brake shoes
The wheels of the multi-trailers must be able to rotate freely. Adjust and check brake system after installing brake shoes.
Unhook tension spring (1) from tension spring mount (2).
Scheme 53
| CAUTION | Once nut (1) of pull rod (2) has been released, do not move handbrake lever. Handbrake lever can flick upwards. |
Release nut (1) on pull rod (2) and remove hexagon nut. Slide brake compensator (3) towards rear.
Installation
Use new self-locking nut.
Scheme 54
Grip openings (1) in wheel trim (2) with both hands and pull off wheel trim (2).
Scheme 55
Release wheel bolts (1) and remove disk wheel (2).
Installation
Tightening Torque
Scheme 56
Turn brake shoe adjusting screw (2) on brake carrier (1) in direction of arrow and release fully. The brake shoes do not rest against the drum.
Scheme 57
Lever off cap (1).
Scheme 58
Release nut (1) and remove. Pull off brake hub (2) with both hands.
Installation
Only a new nut is permitted for reinstallation.
Tightening Torque
Do not screw off brake hub under any circumstances.
Scheme 59
To illustrate more clearly the work steps in (Scheme 60), (Scheme 61) and (Scheme 62), the wheel brake has been detached from the axle.
This procedure is not necessary for removing the brake shoes.
Push back cable (1).
Scheme 60
Remove shell (1).
Scheme 61
Remove brake cable (1) from mounting (2).
Scheme 62
Unhook pressure spring (1) from fixed brake shoe (2) and brake carrier (3).
Scheme 63
Remove tension spring (1) from both brake shoe fixtures (2).
Remove brake lever assembly (3).
Installation
The fixed part of the brake lever assembly (3) is seated on the moving brake shoe. The moving part of the brake lever assembly is seated on the fixed brake shoe.
Scheme 64
Pull brake shoes (1) apart in direction of arrow, tilt forward and remove from adjustment device (2).
Installation
Always replace the four shoes and use the same make.
Minimum lining thickness: 1.5 mm
Scheme 65
Check adjustment device (1).
Check wedge (2) and setting pins (3) for ease of movement and wear.
Apply grease if necessary.
Check brake cables for ease of movement and wear.
Scheme 66
86 10... Removing entry profile section on loading ramp, left, right and center
| CAUTION | Before drilling out rivets, drive in rivet pins with a punch. |
Drill out rivets (1). Remove entry profile section (2) towards front.
Scheme 67
86 10... Removing left or right shock absorber
Inspect the shock absorber while installed to ascertain whether it needs to be replaced.
Replace shock absorber if it is leaking. Replace shock absorber if it can be easily pushed in or pulled out when removed.
Release screw (1) and remove. Tilt shock absorber in direction of arrow. Release screw (2) and remove shock absorber.
Installation
Hold shock absorber vertically: protective cap points upwards. Completely press in shock absorber once and pull out up to required installation length. Do not tilt shock absorber further than is needed for installation.
Tightening Torque
Scheme 68
86 10... Removing loading ramp lock
Unscrew bolts (1).
Installation
Tightening Torque
Scheme 69
Pass lever (1) of rotary striker lock (2) out of square hole (3) by twisting from side to side.
Scheme 70
Unscrew bolts (1).
Installation
Opening for securing clip (2) points to front or rear.
Square-head nut (3) rests with its square surface parallel to bearing pedestal (4).
Tightening Torque
Scheme 71
Raise edge (1) of securing clip and slide in direction of arrow towards rear.
Detach bearing pedestal (2).
Scheme 72
Installation
Install bearing pedestal (1) on stub (3) of locking bracket (3).
Off-center bore (4) in bearing pedestal (1) points with short distance (A) to locking bracket (3).
Scheme 73
86 10... Removing mounting bracket sealing cap
Cut out mounting bracket (3) along markings (1, 2) and lever out of apron (4).
Installation
For gluing, use two-component adhesive ICEMA R 101 and hardener 7.
Mixture ratio: ICEMA R 101 7 parts; hardener 7 1 part.
Scheme 74
86 10... Removing mounting bracket, center, left and right
Note. Disassembly of Camlock retaining cam REFER TO 86 10... DISASSEMBLY OF CAMLOCK RETAINING CAM
Unscrew bolts (1).
Installation
Tightening Torque
Scheme 75
86 10... Removing outer pull rod mount, left and right
Release screws (1) and remove pull rod mount (2).
Installation
Tightening Torque
Scheme 76
86 10... Removing overrunning equipment/maintaining or replacing guide bush/installing overrunning equipment
After installing overrunning equipment, readjust brake system
Check the guide bush while installed to ascertain whether it needs to be replaced. Raise ball end area and replace guide bush if play is detected in ball end area.
Note. After installing, readjust and check brake system.
Release round head screws (1) and remove running board (2) towards top.
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 77
Unhook tension spring (1) from tension spring mount (2).
Scheme 78
| CAUTION | Once nut (1) of pull rod (2) has been released, do not move handbrake lever. Handbrake lever can flick upwards. |
Release screw (1) on pull rod (2) and remove hexagon nut. Slide brake compensator (3) towards rear.
Installation
Use new self-locking nut.
Scheme 79
Release screws (1) on jockey wheel mount and remove.
Release wiring harness mount (2) and remove.
Reinstall screw and tighten until hand-tight.
Installation
Tightening Torque for jockey wheel mount (1)
Tightening Torque for wiring harness mount (2)
Scheme 80
Release screw on socket holder (1) and remove. Cut through strap (2) and lay wiring harness to one side. Pull gaiter (3) in direction of arrow.
Installation
Use new self-locking nut.
Tightening Torque
Scheme 81
Remove protective caps (1).
Scheme 82
Release nuts (1) and remove.
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 83
Tilt top reversing housing (1) in direction of arrow towards rear. Slide out top reversing housing (1) and bottom reversing housing with handbrake lever unit (2) in direction of arrow towards rear.
Scheme 84
Remove holder (1) towards bottom.
Scheme 85
Pull drawbar member (1) in direction of arrow and pull out overrunning equipment (2) in direction of arrow towards front.
Scheme 86
Remove spacer tubes (1) and threaded pins (2) from guide bush (3).
Scheme 87
Press pins (1) inwards. Detach counter support (2) and guide bush (3).
Maintenance
Grease tow tube (4) and attach guide bush (3).
Installation
Secure counter support (2) with new clamping sleeves to tow tube (4).
Scheme 88
Insert spacer tubes (1) and threaded pins (2) in guide bush (3).
Make sure spacer tubes (1) are correctly seated in guide bush (3).
Scheme 89
Using a screwdriver, link spacer tubes (1) and shock absorber located in tow tube. This ensures that the shock absorber remains in the correct installation position. Pull drawbar member (2) in direction of arrow and push in overrunning equipment (3) in direction of arrow towards rear.
Scheme 90
86 10... Removing plastic bush/metal bush
Release countersunk metal screws (1).
Scheme 91
Lever out plastic bush/metal bush (1) with a screwdriver.
Scheme 92
86 10... Removing rear supports and bracket
Release screws (1) and remove rear support (2) from bracket (3).
Installation
Tightening Torque
Scheme 93
Remove cable holders (1) from bracket (2). Release screws (3) on left and right sides of bracket (2). Drill out rivets (4) from underside of platform. Drill out rivets (5) from upper side of platform.
Installation
Tightening Torque
Scheme 94
Installation
Feed cable for rear light (1) through opening (2). Fit cable holders (4) in holes (3).
Scheme 95
86 10... Removing reflecting rear light
From rear side of GFK apron, drive out plastic pins (1) with a drift.
Scheme 96
86 10... Removing rest on loading ramp, left, right and center
| CAUTION | Before drilling out rivets, drive in rivet pins with a punch. |
Drill out rivets (1). Remove rest (2) towards front.
Installation
Stick on new sealing tape.
Scheme 97
86 10... Removing shock absorber from overrunning equipment
Check the overrunning equipment shock absorber while installed to ascertain whether it needs to be replaced.
Apply handbrake. Push in and pull out tow ball end by hand. If it is very easy to pull out the tow ball end, the shock absorber must be replaced.
Release screw (1) and remove. Pull out internal shock absorber (2) from opening in tow tube (3) towards rear.
Installation
Tightening Torque
Scheme 98
Push in new shock absorber (1) as shown in illustration through opening in tow tube (2).
Scheme 99
86 10... Removing trailing arm, removing and installing or replacing mounting
Replace bearing in trailing arm if there is play in trailing arm.
Note. Remove brake cable, REFER TO 86 10... REMOVING BRAKE SHOES. Remove shock absorber and coil spring, REFER TO 86 10... REMOVING AND INSTALLING COIL SPRING.
Release screws (1) between wheel brake (2) and trailing arm (3) and remove complete wheel brake (2).
Installation
Do not reuse screws (1). Use only the socket-head cap screws intended for this purpose. Stamped arrow on the reverse side of the brake carrier points in the direction of travel and stands at the 12 o'clock position.
Tightening Torque
Scheme 100
The trailing arm folds down once the coil spring on the arm has been released.
No persons should be located underneath trailing arm. Risk of injury!
Release screws (1, 2). Use assembly hole (3) to release screw connection (2).
Press out screws (1, 2) with a mandrel.
Installation
Use new self-locking nut.
Tightening Torque
Scheme 101
Installation
Mount trailing arms (1) at rear mounts (4) only, viewed in direction of travel, with screws (2, 3).
Scheme 102
Do not damage trailing arm with drill when drilling.
Drill spacer tube (1) with a 4 mm drill at three evenly offset points. Place drill as near as possible to compensating bush (2).
Bores relieve tension on material of spacer tube.
Press out spacer tube (1) and compensating bush (2) with a drift.
Scheme 103
Grease new spacer tube (1) for installation with Syntheso Glep I. Drive new spacer tube (1) with a rubber mallet into trailing arm mount (2).
Installation
Make sure spacer tube (1) is not tilted when driven in.
Scheme 104
Drive compensating bush (1) with a drift into spacer tube (2). Set compensating bush (1) and spacer tube (2) centrally in trailing arm mount (3).
Installation
Make sure compensating bush (1) is not tilted when driven in.
Install coil spring
Scheme 105
86 10... Removing wheel bearing
The angular-contact ball bearings do not require maintenance and have lifetime lubrication. The bearings cannot be readjusted.
Remove brake drum
Lever out both snap rings (1).
Installation
Replace expanded or damaged snap rings (1). Ensure correct seating.
Scheme 106
Press out wheel bearing with special tool 24 1 010.
| CAUTION | Do not reuse old wheel bearing. |
Scheme 107
Place new wheel bearing (1) with lathe-turned end (2) in center of bore in brake drum (3).
Installation
Before pressing in new wheel bearing, check bearing seat for possible damage.
Make sure wheel bearing is not tilted when pressed in.
Scheme 108
Press in new wheel bearing (1) with special tool 23 2 150 and 33 1 374.
Scheme 109
86 10... Removing wooden rest on loading ramp, left, right and center
| CAUTION | Before drilling out rivets, drive in rivet pins with a punch. |
Drill out rivets (1).
Scheme 110
86 10... Replacing 12 volt socket
From underside of platform, cut through cable tie (1) and remove. Disconnect plug with grommet (2) from socket (3) towards bottom.
Installation
Position all seals correctly. Also secure plug with grommet (2) using new cable tie to other socket.
Scheme 111
On upper side of platform, release Phillips screws (1) on mounting bracket (2).
Scheme 112
Remove sealing compound along white marking (1).
Installation
Make sure cable is correctly laid.
Use Sikaflex 221 as sealing compound.
Scheme 113
Grip under mounting bracket (1) with a screwdriver and lever out bracket (1) towards top. Remove bracket (1).
Scheme 114
Release nut (1). Remove socket (2) from mounting bracket (3).
Scheme 115
86 10... Replacing bar
Note. Disassembly of lashing eyes, REFER TO 86 10... REPLACING LASHING PLATE AND LASHING EYE.
Remove lashing eyes (1).
Scheme 116
Remove protective caps (1) on left/right.
Scheme 117
Release hexagon screws (1) and countersunk head screws (2) on left/right.
Remove bar.
Installation
Tightening Torque for hexagon screw
Tightening Torque for countersunk head screw
Scheme 118
86 10... Replacing drawbar members, left and right
Note. Remove complete brake pull rod. Removal of position light cable, REFER TO 86 10... REPLACING LICENSE PLATE LIGHT.
Release screws (1) on cross-member (2). Pull out cross-member (2) towards rear.
Installation
Tightening Torque
Scheme 119
Release countersunk head screws (1) and remove.
Installation
Tightening Torque
Scheme 120
Remove cable holder (1) and remove wiring harness (2) from drawbar member (3).
Scheme 121
Remove cable (1) from position light housing (2). Pull out cable (1) through drawbar member aperture (3).
Scheme 122
Release all screws on cross-member (1) and remove cross-member (1).
If necessary, release screws on mounting brackets (2) and remove cross-members (3).
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 123
Unscrew bolt (1). Grip nut from rear through assembly hole (2) in cross-member.
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 124
Tilt drawbar member (1) down in direction of arrow A and pull out towards rear in direction of arrow B.
Scheme 125
86 10... Replacing gaiter
Position brake lever fully towards rear.
Release screws (1) and (2) and remove. Pull off towing attachment (3) in direction of arrow.
Installation
Tightening Torque
Scheme 126
Pull off gaiter (1) in direction of arrow.
Scheme 127
86 10... Replacing holder for chock
Pull bar (1) down in direction of arrow A. Pull out chock (2) in direction of arrow B at an angle towards bottom.
Scheme 128
Release and unscrew cheese head tapping screws (1) on holder (2).
Scheme 129
86 10... Replacing lashing plate and lashing eye
Releasing lashing eye
Pull spring bar (1) upwards in direction of arrow A. Slide lashing eye (3) in direction of arrow B and remove from lashing plate (2).
Scheme 130
Release countersunk head screws (1) and remove lashing plate.
Installation
Tightening torque
Scheme 131
Locking lashing eye
Position lashing eye (1) on circular openings on lashing plate (2). Press lashing eye (1) in direction of arrow A into lashing plate (2). In this position, slide lashing eye (1) in direction of arrow B. Spring bar (3) snaps in, anchors and secures lashing eye (1) in lashing plate (2).
Scheme 132
86 10... Replacing license plate light
Release screws (1) and remove license plate light (2) from mounting.
Scheme 133
Disconnect flat connector (1) in direction of arrow.
Scheme 134
86 10... Replacing position light
Unclip cover (1) on side recess (arrow).
Scheme 135
Pull flat connector (1) from flat contact.
Scheme 136
Pull out cable (1) completely.
| CAUTION | Before drilling out rivet heads, drive in rivet pins with a punch. Drill out rivet heads (2) and remove position light housing from front. |
Scheme 137
86 10... Replacing rear light
Release thumb screws (1), slide light guard (2) in direction of middle of car and tilt out towards rear.
Scheme 138
Turn handwheel (1) counterclockwise in direction of arrow and remove base (2).
Scheme 139
Release nuts (1) and press rear light (2) out towards front.
Installation
Use new self-locking nuts.
Tightening Torque
Scheme 140
86 10... Troubleshooting on multi-trailer
| Fault | Cause | Remedy |
|---|---|---|
| Trailer already brakes when foot is taken off accelerator | Shock absorber of overrunning equipment faulty | Replace shock absorber of overrunning equipment |
| Reversing sluggish or not possible | Brake system adjusted too strongly | Adjust brake system |
| NOTE: When automatic reversing is activated, there is a residual braking torque caused by the design. This results | Brake shoes jammed | Free brake shoes, replace complete brake shoes with brake shoe carrier if necessary |
| In slightly heavier overrunning. | Cables overtensioned | Adjust brake system |
| Handbrake effect too weak | Faulty adjustment | Adjust brake system |
| Faulty spring force accumulator | Adjust spring force accumulator | |
| Brake cables heavily contaminated, corroded or kinked | Free cables, replace if necessary | |
| Wheel brakes overheating | Brake system incorrectly adjusted | Adjust brake system |
| Overrunning equipment is sluggish | Lubricate overrunning equipment | |
| Brake cables heavily contaminated, corroded or kinked | Free cables, replace if necessary | |
| Cables overtensioned | Adjust brake system | |
| Wheel brakes contaminated | Clean wheel brakes | |
| Reversing lever of overrunning equipment jammed | Remove reversing lever, clean and grease with conventional BMW lubricants | |
| Braking effect too weak | Excessive play in brake system | Adjust brake system |
| Brake linings glazed, fouled by oil, damaged or worn | Replace complete brake shoes, clean brake drums, replace if necessary | |
| Overrunning equipment is sluggish | Lubricate overrunning equipment | |
| Brake cables heavily contaminated, corroded or kinked | Free cables, replace if necessary | |
| Jolting braking or starting off | Excessive play in brake system | Adjust brake system |
| Shock absorber of overrunning equipment faulty | Replace shock absorber of overrunning equipment | |
| Brake shoes jammed | Replace complete brake shoes with brake shoe carrier | |
| Brakes squeal or rattle | Wheel brakes contaminated or worn | Clean wheel brakes, replace brake shoes and/or brake drums if necessary |
| Out-of-round or banging brake drum | Replace brake drums | |
| Pad loose | Replace brake shoes | |
| Wheel-bearing play excessive | Replace wheel bearings | |
| Brakes pull to one side | Tire pressure incorrect | Correct tire pressure |
| Brake linings glazed, fouled by oil, damaged or worn | Replace complete brake shoes, clean brake drums, replace if necessary | |
| Suspension shock absorber has no effect | Replace suspension shock absorber | |
| Brake pads worn at angle | Wheel-bearing play excessive | Replace wheel bearings |
| Pads worn to less than minimum thickness | Replace brake shoes | |
| Towing attachment fails to engage after connection | Internal attachment parts contaminated | Clean and lubricate attachment |
| NOTE |
|---|
| When automatic reversing is activated, there is a residual braking torque caused by the design. This results |
MULTI-TRAILER TROUBLESHOOTING CHART
86 21... Adjusting hood pretension - Camloc fastener with spacers
Note. At least two persons are needed to install and remove the hood. Before installing and removing the hood, secure the BMW multitrailer and the entire combination against rolling. For this purpose, use the parking brake and the chocks of the BMW multitrailer. To help adjust the hood pretension, you will need four blocks with a minimum height of 60 mm.
Installation
Before attaching the hood, thoroughly clean the top side of the GFP apron of the BMW multitrailer.
It is particularly important to clean the contact surface of the GFP apron (1) (marked in gray) on which the rubber seal of the hood rests.
Scheme 141
The following text describes how to adjust the hood pretension as an example at one support area of the platform or at one hood fastener. The pretension is adjusted at the other support areas and fasteners in the same sequence.
The hood must be fixed on the platform in such a way that the rubber seal of the hood is placed under pretension or compressed. Only with this pretension is it possible to obtain a tight seal between hood and platform. Pretension is achieved with the Camloc fasteners and by using spacers.
Two different types of spacers (2) are available for each Camloc fastener (1): one thick and one thin. You can fit one, two or no spacer (2) on the Camloc fastener (1).
Scheme 142
Access to hood lighting plug (1)
Right side lid.
Open out spring-loaded cap (2) on socket (3) and remove hood lighting plug (1). Close cap (2). Insert hood lighting plug (1) into plug receptacle (4).
Scheme 143
Unlocking Camloc fastener
Wing (1) of Camloc fastener (2) is parallel to outer edge of hood. Turn Camloc fastener (2) counterclockwise until it is heard and felt to unlock.
Locking
Press hood in lid frame downwards by hand. Turn Camloc fastener clockwise until it is heard and felt to lock into place. Wing (1) of Camloc fastener is parallel to outer edge of hood.
Scheme 144
Raise hood and place block (1) between centering pin (2) and platform. Lower hood and position centering pin (2) on block (1).
Scheme 145
Remove spring nut (1) from Camloc fastener (2).
Installation
Use new spring nut.
Scheme 146
Remove Camloc fastener (1) from locating hole (2).
Installation
Press Camloc fastener (1) downwards until contact is made with hood stop. Wing (3) of Camloc fastener points to middle of hood.
Scheme 147
Replacing spacer
Remove spacer (1) from Camloc fastener (4) by aligning opening (2) over lateral pin (3).
Reducing pretension
Reduce spacer thickness, replace spacer or install Camloc fastener without spacer.
Increasing pretension
Fit a thicker spacer or two spacers.
Installation
Place spacer (1) on Camloc fastener (4) and turn until it is in a secure position.
Scheme 148
Check that hood seal is correctly seated.
Check that Camloc fasteners are locked. Lift hood by handle recesses. Hood must not be able to move with respect to platform of BMW multitrailer.
86 21... Adjusting rear lid to fit
Note. The following text describes how to adjust the rear lid to fit at one mounting point as an example. Proceed in the same way for the other mounting points.
Height adjustment of rear lid
Release screws (1) and move rear lid in direction of arrows.
Depth adjustment of rear lid
Release screws (2) and move rear lid in direction of arrows.
Installation
Tightening Torque, height adjustment
Tightening Torque, depth adjustment
Scheme 149
Adjust gap (A) evenly all around without displacement and correct if necessary.
Scheme 150
Check lid in transition (B) to hood for displacement and correct if necessary (flush).
Scheme 151
To align lid in transverse direction, you can install or remove plastic washers (3) between hinge bracket (1) and mounting bracket (2).
Installation
There must always be a plastic washer (3) fitted on left and right sides of mounting bracket (2). Plastic washers are available in thicknesses of 1 mm and 3 mm.
Scheme 152
Check lid in transition (C) to hood (flush) and correct if necessary. Correction is made by inserting or omitting plastic washers (Scheme 152)
Scheme 153
86 21... Adjusting rotary striker lock
The following text describes how to adjust the rotary striker lock on the rear lid as an example. Proceed in the same way for the side lids. Adjust the lock while the lid is open.
Release screws (1) and adjust rotary striker lock (2) in elongated hole area in direction of arrows.
Installation
Tightening Torque
Scheme 154
86 21... Adjusting side lid to fit
Note. The following text describes how to adjust the side lid to fit at one mounting point as an example. Proceed in the same way for all other mounting points.
Height adjustment of side lid
Release screws (1) and move side lid in direction of arrows.
Installation
Tightening Torque
Scheme 155
Depth adjustment of side lid
Release screws (1) and move side lid in direction of arrows.
Installation
Tightening Torque
Scheme 156
Adjust gap (A) evenly all around and correct if necessary.
Scheme 157
Check lid in transition (B) to hood for displacement and correct if necessary (flush).
Scheme 158
To align lid in direction of travel, you can install or remove a spacer plate (3) between mounting bracket (1) and hinge (2).
Scheme 159
Check lid in transition (C) to hood for displacement and correct if necessary (flush). Correction is made by inserting or omitting spacer plates (Scheme 159)
Scheme 160
86 21... Attaching/replacing BMW badge
Position of attachment: inside of rear lid
Remove plastic cover (1) from bore holes (2).
Scheme 161
Inserting a set of pointed pliers through bore holes (1), detach retaining washers (2) from pins of BMW badge.
Installation
Use only new retaining washers.
Scheme 162
| CAUTION | Instruction for removing BMW badge: Slide a blunt object (e.g. a wooden wedge) under the BMW badge and carefully lever off the badge. |
Position of attachment: outside of rear lid
The BMW badge must be attached at room temperature.
Degrease bonding area with petroleum ether.
Rub down bonding area with a dry cloth.
Peel off protective film on BMW badge (1).
Insert BMW badge (1) with pin (2) into bore hole (3). If bore holes (3) are considerably larger than pin (2), optically align BMW badge (1) exactly.
Press down BMW badge (1) firmly.
Scheme 163
Position of attachment: inside of rear lid
By inserting a 1/4" ratchet with extension and socket wrench insert (7 mm A/F) through bore holes (2), attach a retaining washer (1) in each case to pin of BMW badge. In so doing, press down on outside of rear lid with one hand on BMW badge and grip.
Push on relevant retaining washer (1) as far as it will go.
Scheme 164
Position of attachment: inside of rear lid
Insert plastic cover (1) in bore holes (2).
Scheme 165
86 21... Fitting BMW logo
Distance between hood edge and lower edge of BMW logo (1) is 100 mm.
Distance between middle of lock and lettering (2) is 300 mm.
Installation
Degrease bonding areas with benzine. Rub down bonding area with a dry cloth.
Position of BMW logo (1): parallel to lower edge.
Scheme 166
86 21... Installing hood seal
Note. Removing old seal: In a straight area of hood, grip old seal piping with a pair of pliers and pull off horizontally. Grip detached seal with both hands and uniformly pull away from hood ridge.
Push seal piping (1) by hand onto hood ridge (2). Using a rubber hammer, gently tap seal piping (1) as far as it will go onto hood ridge (2). Make sure piping is evenly positioned especially in radii of hood ridge.
Installation
Position end face of seal at front end of hood in a straight area. Lay seal from front to rear.
Scheme 167
86 21... Installing rubber roof strip
Note. Pull off old rubber roof strip and remove remaining traces of adhesive with universal cleaner, refer to BMW Operating Fluids. Rub down with a dry cloth.
Select rubber roof strip according to length of roof recess (1). Arrange chamfered ends of rubber roof strip to match shape of roof recess (1).
Installation
Pretreat bonding area and stick on rubber roof strip according to manufacturer's instructions.
Scheme 168
86 21... Installing seal for rear lid and side lid
Note. The following text describes how to install the seal for the rear lid as an example. Proceed in the same way for the side lids. Removing old seal: Open lid. Grip seal piping with both hands and pull seal off hood ridge. Remove old seal over lid.
Push seal piping (1) by hand onto hood ridge (2). Using a rubber hammer, gently tap seal piping (1) as far as it will go onto hood ridge (2). Make sure piping (1) is evenly positioned especially in radii of hood ridge.
Installation
Always position end face of seal in a straight area only
e.g. on cross-member or on upper hood ridge of rear lid.
Suitable areas on side lids
Upper and lower hood ridge.
Scheme 169
Sealing lip of seal must point outwards.
After installing from inside and outside, check correct seating between lid seal and lid. Lid must rest without air on lid seal.
86 21... Installing sponge rubber seal
Note. Removing old sponge rubber seal: Pull off old sponge rubber seal. Remove remaining traces of adhesive with universal cleaner.
Sponge rubber seal runs along area marked gray (1).
Scheme 170
Lay sponge rubber seal (1) in middle of hood contact surface (2).
Installation
Degrease contact surface (2) with benzine and rub down with a dry cloth. Stick on sponge rubber seal (1) according to manufacturer's instructions. Position end face of seal (1) in a straight area.
Scheme 171
| IMPORTANT | At least two persons are needed to install and remove the hood from the platform. Before installing and removing the hood, secure the BMW multitrailer and the entire combination against rolling. For this purpose, use the parking brake and the chocks of the BMW multitrailer. The hood can also be set up and lowered with the aid of the universal lift available from BMW in conjunction with the roof racks and the hood adapter. Under no circumstances should work of any kind be carried out below the suspended hood. |
For maintenance and repair work, raise the hood using a lifting platform. Twin-column lifting platforms, body lifting platforms and twin-stamp underfloor platforms are suitable. The seating plates and areas of the lifting platform must be adjustable according to the dimensions of (Scheme 172).
Scheme 172
The lifting platform must conform to the relevant legal provisions of the accident prevention regulations and be serviced as specified. Comply with the lifting platform operating instructions, in particular the safety instructions and the carrying capacity.
Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.
Please comply with the following instructions before raising the hood
- Raise only when it is unloaded
- Ensure sufficient clearance between the seating plates/seating areas and the GFP edge of the hood
- The hood must always be positioned in the middle of the lifting platform.
| IMPORTANT | The hood may only be raised at the pin (1). Under no circumstances may the hood be raised at the GFP edge of the hood (2). (Scheme 173) Exclusively for removal of pin (1), raise the hood in the GFP area. Also refer to: 86 21... REMOVING CENTERING PIN FROM MOUNTING BRACKET. |
Scheme 173
86 21... Removing ball pivot
Note. Remove gas spring, REFER TO 86 21... REMOVING GAS SPRING.
Note. The following text describes how to remove the ball pivot from the hinge retaining bracket on the rear lid as an example. Proceed in the same way for the other ball pivots. Make sure the attachments are reinstalled in the correct sequence. Only in this way will the gas springs open and close properly.
Grip ball pivot (1) at hexagon mount (2) and release nut (3).
Installation
Use new self-locking nut.
Tightening Torque
Scheme 174
86 21... Removing centering pin from mounting bracket
Note. Exclusively for removal of pin, raise the hood in the GFP area. For raising, use a wooden block with a maximum width of 35 mm and a height of 45 mm. The length must be selected depending on the lifting platform securing point. Ensure the hood is secure on the blocks.
Position block (1) so that it is only located in area of sponge rubber seal (2).
Scheme 175
Insert a mandrel into hole (1) of pin (2) and turn counterclockwise.
Scheme 176
86 21... Removing gas spring
Only remove the gas spring while the lid is open. The gas spring will then not be subjected to load and the spring piston will not jump out of the spring housing. Prop the lid open with one hand to prevent it dropping closed. Remove the gas spring with your other hand.
Note. Side lids are each fitted with a gas spring. Rear lid is fitted with two gas springs. The following text describes how to remove the gas spring at one mounting point as an example. Proceed in the same way for all other mounting points. Rear lid: Replace gas springs in pairs only.
Lever out retaining clip (1) in recess (2) and push on gas spring head (3) in direction of arrow. Detach spring head (3) from ball pivot.
Installation
Push retaining clip (1) back into its original position. Press spring head (3) onto ball pivot until spring head (3) snaps audibly into place.
Scheme 177
86 21... Removing gas spring retaining bracket
Note. Remove gas spring, REFER TO 86 21... REMOVING GAS SPRING. Remove ball pivot, REFER TO 86 21... REMOVING BALL PIVOT.
Release screws (1) and remove gas spring retaining bracket (2) from mounting bracket (3).
Installation
Install retaining bracket so that it is centered in elongated holes.
Tightening Torque
Scheme 178
86 21... Removing hinge bracket on rear lid
Note. Remove rear lid, REFER TO 86 21... REMOVING LID. Remove gas spring, remove gas spring on hinge side only, REFER TO 86 21... REMOVING GAS SPRING.
Raise edge (1) of retaining clip (2) and slide in direction of arrow towards rear.
Scheme 179
Remove plastic washer (1). Pull hinge bracket (2) in direction of arrow out of mounting bracket (3).
Installation
There must always be a plastic washer (1) fitted on left and right sides of mounting bracket (3).
Scheme 180
86 21... Removing lid
Note. Adjusting side lid to fit, REFER TO R8621... ADJUSTING SIDE LID TO FIT. Adjusting rear lid to fit, REFER TO R8621... ADJUSTING REAR LID TO FIT.
Note. The text describes how to remove the lid at one rear lid mounting point as an example. Proceed in the same way for the side lids. Spare part lids are always supplied without complete locking systems.
Two persons are required for this task.
Note. Open lid.
Loosen screws (1). Remove lid (2).
Installation
Rear lid: shoulder (3) points to middle of hood.
Side lid: shoulder (3) points to outside of hood.
Tightening Torque
Scheme 181
86 21... Removing lock barrel
Note. The following text describes how to remove the lock barrel on the rear lid as an example. Proceed in the same way for the side lids. Remove the lock barrel while the lid is open. Remove cover, spring nut and pull rod, REFER TO 86 21... REMOVING ROTARY STRIKER LOCK.
Slide retainer (1) in direction of arrow away from lock barrel (2). Remove lock barrel (2).
Installation
Examine rubber backing for damage and replace if necessary. When replacing lock barrel, make sure coding of new lock barrel matches coding of fitted lock barrel (simultaneous closing).
Scheme 182
86 21... Removing lock striker fixture on rear lid
Grip rubber seal on seal piping (1) and pull off in area of lock striker fixture (2). Grip lid seal (3) on seal piping (4) and pull off in area of lock striker fixture (2).
Scheme 183
| CAUTION | Before drilling out rivets, drive in rivet pins with a punch. Drill out rivets (1+2) and remove lock striker fixture (3). |
Installation
Rivets (1) have black heads and long shanks. Rivets (2) have silver heads and short shanks.
Scheme 184
86 21... Removing plug for inside light
Note. Two different types of plugs are used for the inside light. Both types function in the same way, only their designs are different.
Type 1
Release screw (1) and separate housing plug (2).
Scheme 185
Release screws (1) and disconnect cables (2) from screw clamp.
Scheme 186
Type 2
Release screw (1) and separate housing plug (2).
Scheme 187
Remove contact parts (1+2).
Installation
When installing, make sure contact parts (1+2) are in correct installation position.
Scheme 188
86 21... Removing roof railing
Note. The text describes how to remove the roof railing at one mounting point as an example. Proceed in the same way for the other mounting points.
Open cover (1) and fold down.
Scheme 189
Unscrew bolt (1).
After releasing three retaining screws, lift off roof railing (2).
Installation
Check molded sealing parts for faults and replace if necessary. Pay attention to identification of molded sealing parts and position accordingly.
Check butylene tape seal.
Use new screws. Coat all screws with OKS 90 thread locking adhesive.
First screw down railing adapter in middle. Then press roof railing downwards with a force of approx. 50 N. Then screw down railing adapter at front and rear.
Tightening Torque for roof railing at front and rear
Tightening Torque for roof railing in middle
Scheme 190
86 21... Removing roof railing adapter
Note. Removing roof railing, REFER TO 86 21... REMOVING ROOF RAILING
Remove molded sealing part (1).
Installation
All molded sealing parts must rest flat on hood. Molded sealing parts are marked according to their position.
Scheme 191
Cut butylene tape (1) out of railing adapter (2) along dotted line (3) with a knife.
Installation
Use butylene tape, 5 mm round, for sealing railing adapter on hood roof.
Scheme 192
Railing adapters at front and rear: Release screws (1) from inside of hood. Pull out railing adapter (2) and spacer plate (3) towards bottom.
Installation
Use new screws. Coat all screws with OKS 90 thread locking adhesive. Install spacer plate (3) in its original position.
Tightening Torque for railing adapters at front and rear
Scheme 193
Railing adapter in middle: Release screws (1) from inside of hood. Twist out railing adapter from outside.
Installation
Use new screws. Tightening Torque for railing adapter in middle
Scheme 194
86 21... Removing rotary striker lock
The following text describes how to remove the rotary striker lock on the rear lid as an example. Proceed in the same way for the side lids. Remove the lock while the lid is open.
Release screws (1) and remove cover (2). On rear lid, remove red cap (3).
Installation, rear lid only
Place red cap back on pull rod. Red cap serves to indicate rear lid emergency unlocking facility.
Scheme 195
Remove spring nut (1) from pull rod (2).
Installation
Use new spring nut.
Scheme 196
Unhook pull rod (1) from rocker (2).
Scheme 197
Release screws (1) and remove rotary striker lock (2) from opening (3).
Installation
Tightening Torque
Use new Stover nuts.
Scheme 198
Detach spring nut (1) from pull rod (2). Remove pull rod (2) from rotary striker lock (3).
Installation
Use new spring nut.
Scheme 199
86 21... Removing side lid hinge
Note. Remove side lid, REFER TO 86 21... REMOVING LID. Remove gas spring, remove gas spring on hinge side only, REFER TO 86 21... REMOVING GAS SPRING.
Unscrew bolt (1). Remove hinge (2). If fitted, remove spacer plate(s) (3).
Installation
Pass screws (1) again through spacer tubes. Reinstall existing spacer plate(s) in its/their original position(s). Use new self-locking nuts.
Tightening Torque
Scheme 200
86 21... Replacing inside light
Unclip cover (1) at side recess (arrowed) and remove towards bottom.
Scheme 201
Unclip lamp housing (1) at side recess (arrowed).
Scheme 202
Disconnect flat connector (1) from flat connector contact.
Scheme 203
| CAUTION | Before drilling out rivets, drive in rivet pins with a punch. Drill out rivets (1). Pull off inside light mounting bracket (2) over flat connector (3). |
Scheme 204
86 21... Replacing inside light power cable
Note. Remove inside light cover and lamp housing, REFER TO 86 21... REPLACING INSIDE LIGHT. Remove inside light plug, REFER TO 86 21... REMOVING INSIDE LIGHT PLUG.
Carefully remove adhesive bonds of power cable (1) from hood surface.
Installation
Carefully remove traces of old adhesive with a scraper. Use standard heat gun adhesive as adhesive.
Scheme 205
Carefully remove adhesive bonds of power cable (1) from hood surface.
Installation
Carefully remove traces of old adhesive with a scraper. Use standard heat gun adhesive as adhesive.
Scheme 206
Remove flat connectors (1). Strip cable ends (2) and connect to a new cable. Feed cable connection through opening (3).
Scheme 207
Lay new power cable with old power cable through duct (1).
Scheme 208
See also:
• REFER TO TIGHTENING TORQUE 86 10 32AZ.
• REFER TO 86 10... REPLACING BAR
• REFER TO 86 10... REPLACING LASHING PLATE AND LASHING EYE
• REFER TO 86 10... REPLACING 12 VOLT SOCKET
• REFER TO 86 10... REMOVING PLASTIC BUSH/METAL BUSH
• REFER TO 86 10... REPLACING REAR LIGHT
• REFER TO 86 10... DISASSEMBLY OF FRONT APRON
• REFER TO 86 10... DISASSEMBLY OF LEFT AND RIGHT APRONS
• REFER TO 86 10... DISASSEMBLY OF REAR APRON
• REFER TO 86 10... DISASSEMBLY PROCEDURE OF RIVET CONNECTION, REAR SUPPORT
• REFER TO 86 10... REPLACING POSITION LIGHT.
• REFER TO 86 10... DISASSEMBLY OF LICENSE PLATE
• 86 21... REMOVING CENTERING PIN FROM MOUNTING BRACKET
• REFER TO 86 10... DISASSEMBLY OF CAMLOCK RETAINING CAM
• REFER TO 86 10... ADJUSTING BRAKE SYSTEM
• REFER TO 86 10... REMOVING BRAKE SHOES.
• REFER TO 86 10... REMOVING AND INSTALLING COIL SPRING.
• REFER TO 86 10... REPLACING LICENSE PLATE LIGHT.
• REFER TO 86 21... REMOVING GAS SPRING.
• REFER TO 86 21... REMOVING BALL PIVOT.
• REFER TO 86 21... REMOVING LID.
• REFER TO R8621... ADJUSTING SIDE LID TO FIT.
• REFER TO R8621... ADJUSTING REAR LID TO FIT.
• REFER TO 86 21... REMOVING ROOF RAILING
• REFER TO 86 21... REPLACING INSIDE LIGHT.
• REFER TO 86 21... REMOVING INSIDE LIGHT PLUG.
