23 0 000 Attachment
| Note | For car jack, for removing and installing manual and automatic transmissions |
|---|---|
| Order number | 23 0 000 |
| Attachment |
SPECIAL TOOL DESIGNATION
Scheme 116
23 0 020 Holder
Minimum set: Mechanical tools
| Note | For all three- and four-hole flanges during releasing and tightening down |
|---|---|
| Series | E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91 |
| Transmission | A4S 200R, A5S 360R, A5S 390R, GA6 HP19Z, GS6-17BG, diff. type M, S5D 200G, S5D 250G |
| Storage location | A5, B5, C5 |
| Order number | 23 0 020 Holder |
SPECIAL TOOL DESIGNATION
Scheme 117
23 0 030 Support
| Note | For Getrag transmission |
|---|---|
| Transmission | 280/5 Sport |
| Order number | 23 0 030 |
| Support |
SPECIAL TOOL DESIGNATION
Scheme 118
23 0 040 Support
| In conjunction with | 00 2 030 |
|---|---|
| Note | For transmissions for removal and installation. Replaced by 23 0 110. |
| Transmission | S6S 420G, S6S 560G |
| SI number | 1 05 90(207) |
| Order number | 23 0 040 Support |
| Consisting of: 1 = 23 0 041 | Locating cage |
| Note | Transmission: S6S 560G |
| 2 = 23 0 042 | Support bracket |
| Note | Transmission: S6S 420G |
SPECIAL TOOL DESIGNATION
Scheme 119
23 0 050 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For all 4-speed and 5-speed transmissions |
| Transmission | 242/4 |
| Order number | 23 0 050 Support |
SPECIAL TOOL DESIGNATION
Scheme 120
23 0 060 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For Getrag transmission |
| Transmission | 245/5, 245/5 Sport |
| Order number | 23 0 060 Support |
SPECIAL TOOL DESIGNATION
Scheme 121
23 0 070 Mounting bracket
| In conjunction with | 00 1 450 |
|---|---|
| Note | For Getrag transmission |
| Transmission | 265/5, 265/5 Sport |
| Order number | 23 0 070 Mounting bracket |
SPECIAL TOOL DESIGNATION
Scheme 122
23 0 080 Fixture
| Note | For removing 5th gear wheel |
|---|---|
| Transmission | 265/5, 265/5 Sport, 280/5 Sport |
| Order number | 23 0 080 Fixture |
| Consisting of: 23 0 081 | Puller jaws (2) |
SPECIAL TOOL DESIGNATION
Scheme 123
23 0 090 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For ZF and Getrag transmissions |
| Transmission | 240/5, 260/5, ZF S5-16 |
| Order number | 23 0 090 Support |
SPECIAL TOOL DESIGNATION
Scheme 124
23 0 100 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For mounting transmission on assembly stand |
| Transmission | S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S5D 320Z |
| SI number | 1 07 90 (244) |
| Order number | 23 0 100 Support |
SPECIAL TOOL DESIGNATION
Scheme 125
23 0 110 Support
| In conjunction with | 00 2 030 |
|---|---|
| Note | For removing and installing transmission. |
| Transmission | S6S 420G, S6S 560G |
| SI number | 1 02 00(551) |
| Order number | 23 0 110 Support |
| Consisting of: 1 = 23 0 111 | Take-up support |
| Note | Transmission: S6S 560G |
| 2 = 23 0 112 | Locating bracket (not shown) |
| Note | Transmission: S6S 420G |
| In conjunction with: 21 0 111 Take-up support |
SPECIAL TOOL DESIGNATION
Scheme 126
23 0 140 Support
| In conjunction with | 00 2 030 |
|---|---|
| Note | For accommodating transmission during removal and installation. Transmission: F-transmission |
| Transmission | S5D 320Z, S5D 390Z |
| SI number | 1 20 98 (378) |
| Order number | 23 0 140 Support |
SPECIAL TOOL DESIGNATION
Scheme 127
23 0 150 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For accommodating transmission on assembly stand. For ZF transmission. |
| Transmission | ZF S5-16 |
| Order number | 23 0 150 Support |
SPECIAL TOOL DESIGNATION
Scheme 128
23 0 160 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For Getrag transmission |
| Transmission | 262/4 |
| Order number | 23 0 160 Support |
SPECIAL TOOL DESIGNATION
Scheme 129
| In conjunction with | 00 1 450 |
|---|---|
| Note | For Getrag transmission |
| Transmission | 262/4 |
| Order number | 23 0 160 Support |
SPECIAL TOOL DESIGNATION
Scheme 130
23 0 170 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For mounting F-transmission on assembly stand |
| Transmission | S5D 390Z |
| SI number | 1 14 99 (482) |
| Order number | 23 0 170 Support |
| Consisting of: 1 = 23 0 171 | Basic body |
| 2 = 23 0 172 | Spindle (2) |
| Note | With handle |
SPECIAL TOOL DESIGNATION
Scheme 131
23 0 180 Impact ring with slip sleeve
Minimum set: Mechanical tools
| In conjunction with | 23 2 491 |
|---|---|
| Note | For driving in radial shaft seal on drive side - F transmission |
| Transmission | S5D 390Z |
| SI number | 1 14 99 (482) |
| Order number | 23 0 180 Impact ring with slip sleeve |
| Consisting of: 1 = 23 0 181 | Impact ring |
| 2 = 23 0 182 | Slip sleeve |
SPECIAL TOOL DESIGNATION
Scheme 132
23 0 190 Impact bush
Minimum set: Mechanical tools
| Note | For driving in radial shaft seal on output side - F transmission |
|---|---|
| Transmission | S5D 280Z, S5D 320Z, S5D 390Z |
| Storage location | B39 |
| SI number | 1 14 99 (482) |
| Order number | 23 0 190 Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 133
23 0 200 Socket 41 A/F
Minimum set: Mechanical tools
| Note | Long version for releasing and tightening down output flange - F-transmission |
|---|---|
| Transmission | S5D 390Z |
| SI number | 1 14 99 (482) |
| Order number | 23 0 200 Socket 41 A/F |
SPECIAL TOOL DESIGNATION
Scheme 134
23 0 230 Spacer bush
Minimum set: Mechanical tools
| Note | Used in place of left engine mount during removal and installation of manual and automatic transmissions |
|---|---|
| Series | E46/16 |
| SI number | 1 07 00 (576) |
| Order number | 23 0 230 Spacer bush |
SPECIAL TOOL DESIGNATION
Scheme 135
23 0 250 Holder
Minimum set: Mechanical tools
| Note | Assistance in releasing and tightening down output flange |
|---|---|
| Transmission | GS5-39DZ, S5D 280Z, S5D 320Z |
| Storage location | B41 |
| SI number | 1 06 00 (575) |
| Order number | 23 0 250 Holder |
SPECIAL TOOL DESIGNATION
Scheme 136
23 0 490 Extractor
| Note | For removing shaft seal |
|---|---|
| Series | E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E53, E60, E61, E63, E64, E83, E85, E87, E90, E91, R50, R52 |
| Transmission | GS5-39DZ, GS5-65BH, GS6-17BG, GS7S47BG, S5D 200G, S5D 250G, S5D 260Z, S5D 280Z, S5D 310Z, S5D 320Z, S5D 390Z, S6S 420G, S6S 560G |
| Storage location | B6, C6 |
| SI number | 1 15 96 (106) |
| Order number | 23 0 490 Extractor |
| Consisting of: 1 = 23 0 491 | Rod |
| Note | With self-tapping screw |
| 2 = 23 0 492 | Impact weight |
SPECIAL TOOL DESIGNATION
Scheme 137
23 1 000 Fixture
| Note | For pressing-on transmission casing and deep groove ball bearing on transmission input shaft and in transmission casing |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 31 0R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 260Z |
| Storage location | C15, C16 |
| Order number | 23 1 000 Fixture |
| Consisting of: 1 = 23 1 001 | Sleeve |
| 2 = 23 1 002 | Dowel pin (2 x) |
| 3 = 23 1 003 | Thrust piece, long |
| 4 = 23 1 004 | Thrust piece, short |
| 5 = 23 1 005 | Handle |
| 7 =23 1007 | Thrust piece for Getrag transmissions |
SPECIAL TOOL DESIGNATION
Scheme 138
23 1 010 Fixture for removing rear section of transmission casing
| Transmission | 280/5 Sport |
|---|---|
| Order number | 23 1 010 |
| Fixture for removing rear section of transmission casing |
SPECIAL TOOL DESIGNATION
Scheme 139
23 1 020 Fixture for removing transmission casing (front and rear section)
| In conjunction with | 33 1 301 |
|---|---|
| Transmission | 245/5 Sport |
| Storage location | C32 |
| Order number | 23 1 020 |
| Fixture for removing transmission casing (front and rear section) |
SPECIAL TOOL DESIGNATION
Scheme 140
23 1 030 Drift for fitting inner bearing race on countershaft
| Transmission | 245/5, 265/5 |
|---|---|
| Storage location | C22 |
| Order number | 23 1 030 |
| Drift for fitting inner bearing race on countershaft |
SPECIAL TOOL DESIGNATION
Scheme 141
23 1 040 Drift
| Note | For mounting sliding section (5th gear) and driving water pipe out of crankcase Engine: N73 |
|---|---|
| Transmission | 245/5Sport, S5D 200G, S5D 250G |
| Storage location | C23 |
| Order number | 23 1 040 Drift |
SPECIAL TOOL DESIGNATION
Scheme 142
23 1 050 Puller (Kukko)
| Note | For 5th gear as well as reverse gear wheel |
|---|---|
| Transmission | 240/5, 245/5, 260/5, 265/5Sport, 280/5Sport, ZF S5-16 |
| Order number | 23 1 050 |
| Puller (Kukko) | |
| Consisting of: 1 = 23 1 051 | Link (Kukko 20-20) |
SPECIAL TOOL DESIGNATION
Scheme 143
23 1 060 Fixture
| In conjunction with | 33 1 301 |
|---|---|
| Note | For removing inner bearing race - reverse gear wheel |
| Transmission | 245/5, 265/5 Sport |
| Storage location | B20 |
| Order number | 23 1 060 Fixture |
| Consisting of: 1 = 23 1 061 | Shells (2) |
| 2 = 23 1 062 | Threaded ring |
| 3 = 23 1 063 | Holding sleeve |
SPECIAL TOOL DESIGNATION
Scheme 144
23 1 070 Measuring ring
| Note | For determining shim ring between outer bearing race and circlip of countershaft |
|---|---|
| Transmission | 245/5 |
| Storage location | B28 |
| Order number | 23 1 070 Measuring ring |
SPECIAL TOOL DESIGNATION
Scheme 145
23 1 080 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing outer bearing race in front section of transmission casing/center section of countershaft and of ball bearing in rear section of transmission casing, input shaft |
| Transmission | 245/5, 265/5 |
| Storage location | A28 |
| Order number | 23 1 080 Drift |
SPECIAL TOOL DESIGNATION
Scheme 146
23 1 090 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing outer bearing race of input shaft in front section of transmission casing |
| Transmission | 245/5, 265/5, GS5-65BH |
| Storage location | A28 |
| Order number | 23 1 090 Drift |
SPECIAL TOOL DESIGNATION
Scheme 147
23 1 100 Puller claws
| In conjunction with | 00 7 500 |
|---|---|
| Note | For speedometer gear |
| Transmission | 245/5, 265/5, 280/5Sport |
| Storage location | B29 |
| Order number | 23 1 100 Puller claws |
SPECIAL TOOL DESIGNATION
Scheme 148
23 1 110 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For installing bearing of output shaft in rear section of transmission casing |
| Transmission | 245/5 |
| Storage location | A28 |
| Order number | 23 1 110 Drift |
SPECIAL TOOL DESIGNATION
Scheme 149
23 1 120 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing outer bearing race of countershaft in center section of transmission casing |
| Transmission | 240/5, 245/5, 260/5, 280/5Sport, ZF S5-16 |
| Storage location | A29 |
| Order number | 23 1 120 Drift |
SPECIAL TOOL DESIGNATION
Scheme 150
23 1 130 Drift
| Note | For removing bearing of input shaft and roller bearing in center section of transmission casing |
|---|---|
| Transmission | 245/5,280/5Sport |
| Storage location | A29 |
| Order number | 23 1 130 Drift |
SPECIAL TOOL DESIGNATION
Scheme 151
23 1 160 Drift
| Note | For fitting inner bearing race and bearing sleeve on output shaft (245) - fitting slide (5th gear - 265/5) - mounting output flange -mounting bearing on countershaft (S5D 310Z) - mounting center bearing on propeller shaft, E46 |
|---|---|
| Series | E36, E38, E46, E65, E85, E87, E90 |
| Transmission | 242/4, 245/5, 265/5, 280/5Sport, A5S 310Z, S5D 260Z, S5D 310Z, S5D 320Z |
| Storage location | C22, C23 |
| Order number | 23 1 160 Drift |
SPECIAL TOOL DESIGNATION
Scheme 152
23 1 170 Fixture
| Note | For removing front section of transmission casing |
|---|---|
| Transmission | 265/5 |
| Order number | 23 1 170 Fixture |
| Consisting of: 1 = 23 1 171 | Plate |
| 2 = 23 1 172 | Knurled screw (3) |
SPECIAL TOOL DESIGNATION
Scheme 153
23 1 180 Drift
| In conjunction with | 00 0 500 |
|---|---|
| Note | For fitting rotary shaft seal in guide tube of clutch release mechanism |
| Transmission | 260/5, 265/5, 265/5Sport, 280/5Sport |
| Storage location | A29 |
| Order number | 23 1 180 Drift |
SPECIAL TOOL DESIGNATION
Scheme 154
23 1 190 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing ball bearing of input shaft in front section of transmission casing |
| Transmission | 265/5, 280/5 Sport |
| Order number | 23 1 190 Drift |
SPECIAL TOOL DESIGNATION
Scheme 155
23 1 200 Guide bush
| In conjunction with | 23 1 210 |
|---|---|
| Note | For centering wrench socket when releasing and tightening transmission output flange and input flange of rear axle differential |
| Transmission | 265/5 |
| Storage location | B30 |
| Order number | 23 1 200 Guide bush |
SPECIAL TOOL DESIGNATION
Scheme 156
23 1 220 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing roller bearing of countershaft shaft in front section of transmission casing |
| Transmission | 260/5, 265/5, A5S 310Z |
| Storage location | A29 |
| Order number | 23 1 220 Drift |
SPECIAL TOOL DESIGNATION
Scheme 157
23 1 230 Spindle (2)
| In conjunction with | 00 7 500 |
|---|---|
| Note | For removing inner bearing race from input shaft in front section of transmission casing |
| Transmission | 265/5 |
| Order number | 23 1 230 Spindle (2) |
SPECIAL TOOL DESIGNATION
Scheme 158
23 1 270 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing outer bearing race on countershaft in front section of transmission casing as well as for removing seal and needle bearing from oil pump housing (A5S 560Z) |
| Transmission | 240/5, 260/5, A5S 560Z |
| Storage location | A29 |
| Order number | 23 1 270 Drift |
SPECIAL TOOL DESIGNATION
Scheme 159
23 1 300 Fixture
Minimum set: Mechanical tools
| In conjunction with | 23 2 150 |
|---|---|
| Note | For fitting output flange on all manual and automatic transmissions, for installing deep groove ball bearing on transmission output shafts and for fitting input flange on all rear axle differentials |
| Series | E36, E36/2, E36/3, E36/5, E36/7, E36/C, E38, E39, E46, E52, E53, E61, E63, E64, E65, E66, E67, E83, E85, E87, E90, E91 |
| Transmission | HAG 188kom, HAG 220kom, HAG 225kom, HAG Type G, HAG Type K, HAG Type M, S5D 200G, S5D 250G |
| Storage location | B15, B16 |
| Order number | 23 1 300 Fixture |
| Consisting of: 1 = 23 1 301 | Adapter |
| 2 = 23 1 302 | Support disk |
| Note | For pressing drive flange onto rear differential |
| In conjunction with: 33 1 341, 23 1 300 | |
| 3 = 23 1 303 | Mandrel |
SPECIAL TOOL DESIGNATION
Scheme 160
23 1 310 Tool
| Note | For fitting locking device on deflection lever |
|---|---|
| Transmission | 280/5 Sport |
| Order number | 23 1 310 Tool |
SPECIAL TOOL DESIGNATION
Scheme 161
23 1 350 Puller fixture
| In conjunction with | 33 1 301 |
|---|---|
| Note | For rear section of transmission casing |
| Transmission | 265/5 |
| Order number | 23 1 350 Puller fixture |
| Consisting of: 1 = 23 1 351 | Plate |
| 2 = 23 1 352 | Screw, short (2) |
| 3 = 23 1 353 | Screw, long (2) |
SPECIAL TOOL DESIGNATION
Scheme 162
23 1 360 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For fitting rotary shaft seal on transmission input shaft |
| Transmission | 240/5, 245/5, 262/4, ZF S5-16 |
| Storage location | A35 |
| Order number | 23 1 360 Drift |
SPECIAL TOOL DESIGNATION
Scheme 163
23 1 370 Drift
| Note | For fitting rotary shaft seals on transmission output flanges |
|---|---|
| Transmission | 242/4, 262/4, 265/5, 265/5Sport |
| Storage location | B28 |
| Order number | 23 1 370 Drift |
SPECIAL TOOL DESIGNATION
Scheme 164
23 1 380 Drift
| In conjunction with | 00 0 500 |
|---|---|
| Note | For installing roller bearing of countershaft shaft in rear section of transmission casing |
| Transmission | 240/5, 245/5, 260/5, 280/5Sport |
| Storage location | B30 |
| Order number | 23 1 380 Drift |
SPECIAL TOOL DESIGNATION
Scheme 165
23 1 390 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For installing roller bearing of countershaft shaft in rear section of transmission casing |
| Transmission | 265/5, 280/5 Sport |
| Storage location | A29 |
| Order number | 23 1 390 Drift |
SPECIAL TOOL DESIGNATION
Scheme 166
23 1 400 Fixture
| Note | For fitting rotary shaft seal in bush of speedometer pinion |
|---|---|
| Transmission | 242/4, 262/4 |
| Order number | 23 1 400 Fixture |
| Consisting of: 1 = 23 1 401 | Fitting shaft |
| 2 = 23 1 402 | Radial plug |
| 3 = 23 1 403 | Union sleeve |
SPECIAL TOOL DESIGNATION
Scheme 167
23 1 410 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For fitting ball bearing of output shaft in rear section of transmission casing and roller bearing of output shaft in center section of transmission casing |
| Transmission | 260/5, 265/5 |
| Storage location | A29 |
| Order number | 23 1 410 Drift |
SPECIAL TOOL DESIGNATION
Scheme 168
23 1 420 Fixture
| In conjunction with | 33 1 301 |
|---|---|
| Note | For removing slide (5th gear) |
| Transmission | 265/5 |
| Storage location | C31 |
| Order number | 23 1 420 Fixture |
| Consisting of | 23 1 421 Clamping screw |
SPECIAL TOOL DESIGNATION
Scheme 169
23 1 430 Thrust piece
| Note | For fitting 5th gear wheel |
|---|---|
| Transmission | 265/5, 280/5 Sport |
| Storage location | A35 |
| Order number | 23 1 430 Thrust piece |
SPECIAL TOOL DESIGNATION
Scheme 170
23 1 440 Holding sleeve
| Note | For fitting bearing bush and inner bearing race on output shaft as well as for removing bearing on output shaft (S5D 310Z) |
|---|---|
| Transmission | 265/5, 265/5Sport, 280/5Sport, S5D 310Z |
| Storage location | C22, C23 |
| Order number | 23 1 440 Holding sleeve |
SPECIAL TOOL DESIGNATION
Scheme 171
23 1 450 Guide pins (2 x)
| Note | For fitting bearing bush in locking device of guide sleeve |
|---|---|
| Transmission | 245/5, 265/5 |
| Storage location | C3 |
| Order number | 23 1 450 Guide pins (2 x) |
SPECIAL TOOL DESIGNATION
Scheme 172
23 1 480 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing deep groove ball bearing in front section of transmission casing |
| Transmission | 240/5, 242/4, 260/5, 280/5Sport |
| Storage location | A29 |
| Order number | 23 1 480 Drift |
SPECIAL TOOL DESIGNATION
Scheme 173
| In conjunction with | 00 5 500 |
|---|---|
| Note | For removing and installing deep groove ball bearing in front section of transmission casing |
| Transmission | 240/5, 242/4, 260/5, 280/5Sport |
| Storage location | A29 |
| Order number | 23 1 480 Drift |
SPECIAL TOOL DESIGNATION
Scheme 174
23 1 490 Fixture
| Note | For removing gear wheels |
|---|---|
| Transmission | 240/5, 260/5, 280/5Sport, S5D 200G, ZF S5-16 |
| Order number | 23 1 490 Fixture |
| Consisting of: 23 1 491 | Spacer |
SPECIAL TOOL DESIGNATION
Scheme 175
23 2 000 Rillex ball bearing extractor 6206
| Note | 9 balls with steel cage - for removing deep groove ball bearing of transmission input shaft |
|---|---|
| Order number | 23 2 000 Rillex ball bearing extractor 6206 |
| Consisting of: 1 = 23 2 001 | Claw for Rillex 6206 (9 x) |
| 2 = 23 2 002 | Union sleeve |
| 3 = 23 2 003 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 176
23 2 010 Rillex ball bearing extractor 6206 E
| Note | 8 balls with plastic cage - for removing deep groove ball bearing of transmission input shaft |
|---|---|
| Transmission | 242/4, 245/5Sport, 265/5 |
| Order number | 23 2 010 |
| Rillex ball bearing extractor 6206 E | |
| Consisting of: 1 = 23 2 011 | Claw for Rillex 6206 E (8) |
| 2 = 23 2 012 | Union sleeve |
| 3 = 23 2 013 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 177
| Note | 8 balls with plastic cage - for removing deep groove ball bearing of transmission input shaft |
|---|---|
| Transmission | 242/4, 245/5Sport, 265/5 |
| Order number | 23 2 010 |
| Rillex ball bearing extractor 6206 E | |
| Consisting of: 1 = 23 2 011 | Claw for Rillex 6206 E (8) |
| 2 = 23 2 012 | Union sleeve |
| 3 = 23 2 013 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 178
23 2 020 Rillex ball bearing extractor
| Note | 7 balls - for removing deep groove ball bearing of transmission input shaft |
|---|---|
| Transmission | 245/5 Sport, 265/5 Sport |
| Order number | 23 2 020 |
| Rillex ball bearing extractor | |
| Consisting of: 1 = 23 2 021 | Claw for Rillex (7) |
| 2 = 23 2 022 | Union sleeve |
| 3 = 23 2 023 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 179
23 2 050 Rillex ball bearing extractor 6205
| Note | For removing deep groove ball bearing of transmission countershaft and transmission output shaft |
|---|---|
| Transmission | 245/5 Sport, 262/4, 265/5 Sport |
| Order number | 23 2 050 |
| Rillex ball bearing extractor 6205 | |
| Consisting of: 1 = 23 2 051 | Claw for Rillex 6305 (8) |
| 2 = 23 2 052 | Union sleeve |
| 3 = 23 2 053 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 180
23 2 060 Rillex ball bearing extractor 6306
| Note | For removing deep groove ball bearing of input and output shaft |
|---|---|
| Transmission | 242/4,262/4 |
| Order number | 23 2 060 |
| Rillex ball bearing extractor 6306 | |
| Consisting of: 1 = 23 2 061 | Claw for Rillex 6306 (8) |
| 2 = 23 2 062 | Union sleeve |
| 3 = 23 2 063 | Pressure spindle |
SPECIAL TOOL DESIGNATION
Scheme 181
23 2 080 Adapter
| Note | For removing guide sleeve - 2nd/3rd gear |
|---|---|
| Transmission | 260/5 |
| Storage location | C21 |
| Order number | 23 2 080 Adapter |
SPECIAL TOOL DESIGNATION
Scheme 182
23 2 100 Pliers
| Note | For removing and installing circlip on transmission output shaft |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 31 0R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S560G, ZFS5-16 |
| Order number | 23 2 100 Pliers |
SPECIAL TOOL DESIGNATION
Scheme 183
23 2 150 Pressure sleeve
| In conjunction with | 23 1 300 |
|---|---|
| Note | For fitting deep groove ball bearing of transmission output shaft (260/5, 245/5), for fitting front tapered roller bearing on drive pinion in all rear axle differentials as well as for mounting cover of countershaft (S5D 310Z) |
| Transmission | 245/5Sport, 260/5, S5D 260Z, S5D 310Z, S5D 320Z |
| Storage location | B29 |
| Order number | 23 2 150 Pressure sleeve |
SPECIAL TOOL DESIGNATION
Scheme 184
23 2 160 Impact bush
| Note | For rotary shaft seal in rear section of transmission housing - output shaft |
|---|---|
| Transmission | 280/5Sport, ZF S5-16 |
| Storage location | B28 |
| Order number | 23 2 160 Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 185
23 2 170 Fixture
| Note | For tensioning transmission leaf spring |
|---|---|
| Transmission | ZF S5-16 |
| Order number | 23 2 170 Fixture |
SPECIAL TOOL DESIGNATION
Scheme 186
23 2 180 Guide bush
| Note | For mounting front section of transmission casing on selector shaft |
|---|---|
| Transmission | ZF S5-16 |
| Order number | 23 2 180 Guide bush |
SPECIAL TOOL DESIGNATION
Scheme 187
23 2 200 Circlip pliers (straight)
| Note | For removing and installing external circlips on transmission shafts |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 31 0R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 31 0Z, S6S 420G, S6S560G, ZFS5-16 |
| Order number | 23 2 200 Circlip pliers (straight) |
SPECIAL TOOL DESIGNATION
Scheme 188
23 2 210 Circlip pliers (straight)
| Note | For removing and installing internal circlips in transmission casings when replacing deep groove ball bearings |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 31 0R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S560G, ZFS5-16 |
| Order number | 23 2 210 Circlip pliers (straight) |
SPECIAL TOOL DESIGNATION
Scheme 189
23 2 220 Drift
| Note | For bearing of countershaft shaft in front and rear section of transmission casing |
|---|---|
| Transmission | ZF S5-16 |
| Order number | 23 2 220 Drift |
SPECIAL TOOL DESIGNATION
Scheme 190
23 2 230 Disc
| In conjunction with | 00 7 500 |
|---|---|
| Note | For removing guide sleeve from gear wheel or output shaft with toothed lock washer |
| Transmission | 280/5 Sport |
| Order number | 23 2 230 Disc |
SPECIAL TOOL DESIGNATION
Scheme 191
23 2 250 Bracket
| Note | For tensioning main shaft to countershaft |
|---|---|
| Transmission | S5D 310Z |
| Storage location | C20, C24 |
| SI number | 1 07 90(244) |
| Order number | 23 2 250 Bracket |
SPECIAL TOOL DESIGNATION
Scheme 192
23 2 260 Installation drift
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal on selector shaft of rear section of transmission casing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | A20 |
| SI number | 1 07 90(244) |
| Order number | 23 2 260 Installation drift |
SPECIAL TOOL DESIGNATION
Scheme 193
23 2 270 Fixture
| Note | For centering selector shaft while mounting front section of transmission casing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | C30 |
| SI number | 1 07 90(244) |
| Order number | 23 2 270 Fixture |
SPECIAL TOOL DESIGNATION
Scheme 194
23 2 280 Puller plate
| In conjunction with | 33 1 301 |
|---|---|
| Note | For front section of transmission casing |
| Transmission | S5D 310Z |
| Storage location | C31 |
| SI number | 1 07 90(244) |
| Order number | 23 2 280 Puller plate |
SPECIAL TOOL DESIGNATION
Scheme 195
23 2 290 Fixture
| Note | For mounting front section of transmission casing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | C18 |
| SI number | 1 07 90(244) |
| Order number | 23 2 290 |
| Fixture Consisting of: 1 = 23 2 291 | Base frame |
| 2 = 23 2 292 | Support |
| 3 = 23 2 293 | Ring |
| 4 = 23 2 294 | Set of shells |
SPECIAL TOOL DESIGNATION
Scheme 196
23 2 300 Drift
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal of output shaft in rear section of transmission casing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | B28 |
| SI number | 1 07 90(244) |
| Order number | 23 2 300 Drift |
SPECIAL TOOL DESIGNATION
Scheme 197
23 2 310 Fixture
| Note | For removing 3rd and 4th gear wheel from countershaft |
|---|---|
| Transmission | S5D 310Z |
| Storage location | C30 |
| SI number | 1 07 90(244) |
| Order number | 23 2 310 Fixture |
SPECIAL TOOL DESIGNATION
Scheme 198
23 2 320 Socket for socket wrench WAF 36
Minimum set: Mechanical tools
| Note | For loosening and tightening flanged nut |
|---|---|
| Transmission | S5D 310Z, S6S 420G, S6S 560G |
| Storage location | B30 |
| SI number | 1 07 90(244) |
| Order number | 23 2 320 Socket for socket wrench WAF 36 |
SPECIAL TOOL DESIGNATION
Scheme 199
23 2 330 Fixture
| Note | For installing complete gear train in rear section of transmission housing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | C18 |
| SI number | 1 07 90(244) |
| Order number | 23 2 330 Fixture |
SPECIAL TOOL DESIGNATION
Scheme 200
23 2 340 Drift
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal in front section of transmission casing |
|---|---|
| Transmission | S5D 310Z |
| Storage location | B29, C29 |
| SI number | 1 07 90(244) |
| Order number | 23 2 340 Drift |
SPECIAL TOOL DESIGNATION
Scheme 201
23 2 350 Drift
| Note | For fitting sealing cover for notch pin of selector shaft |
|---|---|
| Transmission | S5D 310Z |
| Storage location | B14, C14 |
| SI number | 1 07 90(244) |
| Order number | 23 2 350 Drift |
SPECIAL TOOL DESIGNATION
Scheme 202
23 2 360 Drift
| Note | For fitting end cover for notch pin |
|---|---|
| Transmission | S5D 310Z |
| Storage location | B14, C14 |
| SI number | 1 07 90(244) |
| Order number | 23 2 360 Drift |
SPECIAL TOOL DESIGNATION
Scheme 203
23 2 370 Fixture
| In conjunction with | 23 1 050 |
|---|---|
| Note | For removing gear train |
| Transmission | S5D 310Z |
| Storage location | C30 |
| SI number | 1 02 91(330) |
| Order number | 23 2 370 Fixture |
SPECIAL TOOL DESIGNATION
Scheme 204
23 2 380 Installation sleeve
| Note | For retaining ring on input shaft |
|---|---|
| Transmission | S5D 310Z |
| Storage location | A5 |
| SI number | 102 91(330) |
| Order number | 23 2 380 Installation sleeve |
SPECIAL TOOL DESIGNATION
Scheme 205
23 2 470 Impact bush
| Note | For fitting tab washer of securing nut on output flange |
|---|---|
| Transmission | S6S 420G, S6S 560G |
| Storage location | A25 |
| SI number | 1 10 93(689) |
| Order number | 23 2 470 Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 206
23 2 480 Impact bush
| Note | For installing radial seal on output shaft |
|---|---|
| Transmission | S6S 420G, S6S 560G |
| Storage location | A19 |
| SI number | 1 10 93(689) |
| Order number | 23 2 480 Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 207
23 2 490 Impact bush and slip sleeve
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal on input shaft |
|---|---|
| Transmission | GS5-65BH, S6S 420G, S6S 560G |
| Storage location | C29 |
| SI number | 1 10 93(689) |
| Order number | 23 2 490 Impact bush and slip sleeve |
| Consisting of: 1 = 23 2 491 | Impact bush |
| 2 = 23 2 492 | Slip sleeve (2-part) |
SPECIAL TOOL DESIGNATION
Scheme 208
23 3 010 Fixture
| Note | For fitting output flange on output shaft |
|---|---|
| Transmission | S6S 420G, S6S 560G |
| Storage location | A26 |
| SI number | 1 10 93(689) |
| Order number | 23 3 010 Fixture |
| Consisting of: 1 = 23 3 011 | Adapter spindle |
| 2 = 23 3 012 | Pressure sleeve |
| 3 = 23 3 013 | Pressure nut with bearing |
SPECIAL TOOL DESIGNATION
Scheme 209
23 3 020 Mounting sleeve
| Note | For installing gaiter of selector rod |
|---|---|
| Transmission | S6S 560G |
| Storage location | A14, B14 |
| SI number | 1 10 93(689) |
| Order number | 23 3 020 Mounting sleeve |
SPECIAL TOOL DESIGNATION
Scheme 210
23 3 110 Drift
| Note | For driving in guide bushings for catch pins on manual transmissions. |
|---|---|
| Transmission | GS5-39DZ, S5D 280Z, S5D 320Z, S5D 390Z |
| SI number | 1 12 02(918) |
| Order number | 23 3 110 Drift |
SPECIAL TOOL DESIGNATION
Scheme 211
23 3 160 Set of tools
Minimum set: Mechanical tools
| Note | Removing and installing shaft seal on output shaft |
|---|---|
| Transmission | GS6-37BZ, GS6-51BZ |
| SI number | 01 10 02 (907) |
| Order number | 23 3 160 Set of tools |
| Consisting of: 1 = 23 3 161 | Extractor |
| 2 = 23 3 162 | Drift |
SPECIAL TOOL DESIGNATION
Scheme 212
23 3 169 Set of tools
Minimum set: Mechanical tools
| Note | Removing and installing shaft seals on output side |
|---|---|
| Transmission | GS6-37BZ |
| Order number | 23 3 169 Set of tools |
SPECIAL TOOL DESIGNATION
23 3 200 Extractor
Minimum set: Mechanical tools
| Note | For removing shaft seal on drive shaft |
|---|---|
| Transmission | GS6-53BZ, GS6-53DZ |
| Storage location | A49, A50 |
| SI number | 1 11 04 (093) |
| Order number | 23 3 200 Extractor |
SPECIAL TOOL DESIGNATION
Scheme 213
23 3 210 Extractor
Minimum set: Mechanical tools
| Note | For removing shaft seal on output shaft |
|---|---|
| Transmission | GS6-53BZ, GS6-53DZ |
| Storage location | A50 |
| SI number | 1 11 04 (093) |
| Order number | 23 3 210 Extractor |
SPECIAL TOOL DESIGNATION
Scheme 214
23 3 220 Drift
Minimum set: Mechanical tools
| Note | For driving in shaft seal on drive shaft (G- transmission) |
|---|---|
| Transmission | GS6-53BZ, GS6-53DZ |
| Storage location | A49 |
| SI number | 1 11 04 (093) |
| Order number | 23 3 220 Drift |
SPECIAL TOOL DESIGNATION
Scheme 215
23 3 230 Drift
Minimum set: Mechanical tools
| Note | For driving in shaft seal on output shaft (G- transmission) |
|---|---|
| Transmission | GS6-53BZ, GS6-53DZ |
| Storage location | A49 |
| SI number | 1 11 04(093) |
| Order number | 23 3 230 Drift |
SPECIAL TOOL DESIGNATION
Scheme 216
23 4 000 Drift set
Minimum set: Mechanical tools
| In conjunction with | 00 5 500 |
|---|---|
| Note | For driving shaft seal into transmission |
| Transmission | GS6-85BG |
| Storage location | A49, B84 |
| SI number | 1 02 02(823) |
| Order number | 23 4 000 Drift set |
| Consisting of: 1 = 23 4 001 | Drift dia. 67 mm |
| 2 = 23 4 002 | Drift dia. 53 mm |
SPECIAL TOOL DESIGNATION
Scheme 217
23 4 010 Removal tool
Minimum set: Mechanical tools
| Note | For pressing connector out of transmission |
|---|---|
| Transmission | GS6-85BG |
| Storage location | B83 |
| SI number | 1 02 02 (823) |
| Order number | 23 4 010 Removal tool |
SPECIAL TOOL DESIGNATION
Scheme 218
23 4 020 Drifts
| Note | For driving in bearing bushings for locking pins, 5th and reverse gears. |
|---|---|
| Transmission | GS5-39DZ, S5D 320Z |
| Storage location | B49 |
| SI number | 1 03 04 (070) |
| Order number | 23 4 020 Drifts |
| Consisting of: 1 = 23 4 021 | Drift |
| Note | For driving in cover caps on gear notch, 5th and reverse gears. |
| 2 = 23 4 022 | Drift |
| Note | For driving in bearing bushing for locking pin, 5th gear. |
| 3 = 23 4 023 | Drift |
| Note | For driving in bearing bushing for locking pin, reverse gear. |
SPECIAL TOOL DESIGNATION
