24 0 010 Fixture
| In conjunction with | 00 2 510 |
|---|---|
| Note | For checking axial play of drive shaft |
| Transmission | 4 HP 22, 4 HP 24, A5S 310Z, A5S 560Z |
| Storage location | B23 |
| Order number | 24 0 010 |
| Fixture | |
| Consisting of | |
| 1 = 24 0 011 | Dial gauge holder |
| 2 = 24 0 012 | Clamping piece |
SPECIAL TOOL DESIGNATION
Scheme 293
24 0 020 Oil pressure test accessories
Minimum set: Mechanical tools
Scheme 294
| In conjunction with | 13 3 061 and BMW DIS |
|---|---|
| Note | For pressure gauge 13 3 061 or BMW DIS for checking oil pressure |
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z |
| Storage location | B23, B24, single |
| Order number | 24 0 020 |
| Oil pressure test accessories | |
| Consisting of | |
| 1 = 24 0 021 | Pressure hose with connection |
| Note | Pressure hose 1.7 m, connection M12x1.5 - M14x1.5 external thread/for checking the various converter pressures / Transmission: A4S 310R, A4S 270R |
| 2 = 24 0 022 | Reducer |
| Note | For checking main pressure (3 HP 22, A5S 310Z) and clutch A (ZF transmissions) / transmission: 3 HP 22, A5S 310Z, A5S 560Z and all ZF transmissions |
| In conjunction with: 24 0 140 | |
| 3 = 24 0 023 | Pipe bend, 145 mm |
| Note | Extended length 145 mm / Transmission: 4 HP 22, 4 HP 24 |
| In conjunction with: 13 6 052 | |
| 4 = 24 0 024 | Pipe bend, 90 mm |
| Note | Extended length 90 mm |
| In conjunction with: 13 6 052 | |
| 5 = 24 0 025 | Banjo bolt |
| Note | M20x1.5 - M18x1.5 / For checking converter pressure / Transmission: 3 HP 12 |
| In conjunction with: 24 0 024 | |
| 6 = 24 0 026 | Reducer |
| Note | M24x1.5 - 20x1.5 / For checking main pressure / Transmission: 3 HP 20 |
| In conjunction with: 24 0 024 | |
| 7 = 24 0 027 | Reducer |
| Note | M20x1.5 - M18x1.5 / For checking main pressure (3 HP 12) and converter pressure (3 HP 20) / Transmission: 3 HP 12, 3 HP 20 |
| In conjunction with: 24 0 024 | |
| 8 = 24 0 028 | Screw plug |
| Note | M18x1.5 / For closing off oil supply lines while checking converter pressure / Transmission: 3 HP 20 |
| 9 = 24 0 029 | Adapter |
| Note | For closing off supply and return lines while checking main pressure / Transmission: 3 HP 22 |
SPECIAL TOOL DESIGNATION
24 0 030 Adapter
| In conjunction with | 13 3 061, 24 0 021, 24 0 023 |
|---|---|
| Note | For pressure gauge 13 3 061 / For checking converter pressure |
| Transmission | 4 HP 22 |
| Storage location | B23 |
| Order number | 24 0 030 |
| Adapter |
SPECIAL TOOL DESIGNATION
Scheme 295
24 0 040 Retaining fixture
| Note | For removing and installing disc pack |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | C27 |
| Order number | 24 0 040 |
| Retaining fixture | |
| Consisting of | |
| 1 = 24 0 041 | Disc |
| 2 = 24 0 042 | Ring |
| 3 = 24 0 043 | Half shells |
SPECIAL TOOL DESIGNATION
Scheme 296
24 0 050 Extractor grip
| Note | For sealing plug in bottom section of transmission casing |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | A24 |
| Order number | 24 0 050 |
| Extractor grip |
SPECIAL TOOL DESIGNATION
Scheme 297
24 0 070 Adapter
| In conjunction with | 13 3 061 (pressure gauge), 24 0 021, 24 0 023 |
|---|---|
| Note | For checking pump pressure |
| Transmission | 4 HP 22, 4 HP 24 |
| Storage location | B23 |
| Order number | 24 0 070 |
| Adapter |
SPECIAL TOOL DESIGNATION
Scheme 298
24 0 080 Funnel
Minimum set: Mechanical tools
| Note | For filling transmission fluid in transmission |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16 |
| Order number | 24 0 080 |
| Funnel |
SPECIAL TOOL DESIGNATION
Scheme 299
24 0 090 Drift
| Note | For driving in radial seal in transmission case front section / Replaced by 24 0 110, November 96 |
|---|---|
| Transmission | 4 HP 22, 4 HP 24 |
| Order number | 24 0 090 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 300
24 0 120 Attachment for trolley
| Note | For removing and installing transmission / Replaced by 24 0 130, March 87 |
|---|---|
| Transmission | 4 HP 22 |
| Order number | 24 0 120 |
| Attachment for trolley |
SPECIAL TOOL DESIGNATION
24 0 130 Take-up support for transmission
| In conjunction with | 00 2 030 (not included in minimum kit) |
|---|---|
| Note | For removal and installation |
| Transmission | 4 HP 22, 4 HP 24 |
| SI number | 1 02 87(721) |
| Order number | 24 0 130 |
| Take-up support for transmission |
SPECIAL TOOL DESIGNATION
Scheme 301
24 0 140 Pipe manifold
Minimum set: Mechanical tools
| In conjunction with | 13 3 061, 24 0 021,24 0 022, 13 6 051, 13 6 052, 24 5 190 |
|---|---|
| Note | For pressure gauge 13 3 061 and BMW DIS for measuring oil pressure in transmission |
| Transmission | A4S 270R, A4S 310R, A5S 310Z, A5S 560Z |
| Storage location | C3 |
| SI number | 1 01 92(469) |
| Order number | 24 0 140 |
| Pipe manifold |
SPECIAL TOOL DESIGNATION
Scheme 302
24 0 150 Mounting bracket
| In conjunction with | 00 1 450 |
|---|---|
| Note | For mounting transmission on assembly stand |
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, A4S 270R, A4S 310R, A5S 310Z |
| Order number | 24 0 150 |
| Mounting bracket | |
| Consisting of | |
| 2 = 24 0 152 | Base frame |
| 3 = 24 0 153 | Spindle with rotary handle |
| 6 = 24 0 156 | Spindle |
| Note | With thrust piece, transmission: all |
| In conjunction with: 00 1 450 |
SPECIAL TOOL DESIGNATION
Scheme 303
24 0 170 Support
| In conjunction with | 00 2 030 (not included in minimum kit) |
|---|---|
| Note | For removing and installing transmission |
| Transmission | A5S 560Z |
| SI number | 1 06 92(509) |
| Order number | 24 0 170 |
| Support | |
| Consisting of | |
| 24 0 171 | Adjusting screw |
SPECIAL TOOL DESIGNATION
Scheme 304
24 0 180 Support
| In conjunction with | 00 1 450 |
|---|---|
| Note | For mounting transmission on assembly stand |
| Transmission | A5S 310Z, A5S 325Z, A5S 360R, A5S 440Z, A5S 560Z, GA6 HP26Z |
| SI number | 1 06 92 (509) |
| Order number | 24 0 180 |
| Support | |
| Consisting of | |
| 1 = 24 0 181 | Base frame |
| 2 = 24 0 182 | Pressure spindle with star handle |
| 3 = 24 0 183 | Spindle |
| Note | Replaced by 24 0 184 |
| 4 = 24 0 184 | Spindle, long (2 x) |
SPECIAL TOOL DESIGNATION
Scheme 305
24 0 190 Holding fixture
Minimum set: Mechanical tools
| Note | For output flange of propeller shaft while releasing and tightening slotted nut |
|---|---|
| Transmission | A5S 560Z |
| SI number | 1 06 92(509) |
| Order number | 24 0 190 |
| Holding fixture |
SPECIAL TOOL DESIGNATION
Scheme 306
24 0 250 Take-up support for transmission
| In conjunction with | 24 5 301 and 00 2 030 (not included in minimum tool kit) |
|---|---|
| Note | For removal and installation |
| Transmission | A5S 440Z |
| SI number | 1 08 96(080) |
| Order number | 24 0 250 |
| Take-up support for transmission |
SPECIAL TOOL DESIGNATION
Scheme 307
24 1 010 Installation sleeve
| Note | For removing disc pack (4th gear) as well as fitting needle bearing in oil pump housing (A5S 560Z) |
|---|---|
| Transmission | 4 HP 22, 4 HP 24, A5S 560Z |
| Storage location | A18 |
| Order number | 24 1 010 |
| Installation sleeve |
SPECIAL TOOL DESIGNATION
Scheme 308
24 1 050 Impact bush
| Note | For fitting rotary shaft seal for torque converter in oil pump housing |
|---|---|
| Transmission | 3 HP 20, 3 HP 22 |
| Storage location | C29 |
| Order number | 24 1 050 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 309
24 1 060 Impact bush
| Note | For fitting rotary shaft seal for torque converter in oil pump housing and on output flange |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, A5S 300J, BW 65 |
| Storage location | B29, C29 |
| Order number | 24 1 060 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 310
24 1 070 Impact bush
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal in oil pump housing |
|---|---|
| Transmission | A5S 325Z |
| Storage location | B36 |
| SI number | 1 03 98(303) |
| Order number | 24 1 070 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 311
24 1 080 Bush (aluminum)
Minimum set: Mechanical tools
| In conjunction with | 00 5 010 |
|---|---|
| Note | For fitting on input shaft while removing rotary shaft seal from oil pump housing |
| Transmission | A5S 325Z |
| Storage location | A36 |
| SI number | 1 03 98(303) |
| Order number | 24 1 080 |
| Bush (aluminum) |
SPECIAL TOOL DESIGNATION
Scheme 312
24 1 090 Impact bush
| Note | For installing rotary shaft seal on output flange |
|---|---|
| Transmission | A5S 390G |
| SI number | 1 08 98(333) |
| Order number | 24 1 090 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 313
24 1 100 Impact bush
| Note | For fitting rotary shaft seal for output flange in transmission extension |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22 |
| Order number | 24 1 100 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 314
24 1 110 Socket with magnet
Minimum set: Mechanical tools
| Note | For loosening and tightening converter mounting |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z |
| Storage location | B19 |
| SI number | 1 04 86 (566) |
| Order number | 24 1 110 |
| Socket with magnet |
SPECIAL TOOL DESIGNATION
Scheme 315
24 1 120 Gauge
| Note | For adjusting position switch in "P" position during assembly / Model year: As from 03/96 |
|---|---|
| Transmission | A4S 270R |
| SI number | 1 07 96(068) |
| Order number | 24 1 120 |
| Gauge |
SPECIAL TOOL DESIGNATION
Scheme 316
24 1 170 Pin wrench
Minimum set: Mechanical tools
| Note | For releasing and tightening slotted nut on output flange |
|---|---|
| Transmission | A5S 310Z |
| Storage location | A35 |
| SI number | 1 09 90(282) |
| Order number | 24 1 170 |
| Pin wrench |
SPECIAL TOOL DESIGNATION
Scheme 317
24 1 180 Fixture
Minimum set: Mechanical tools
| In conjunction with | 24 1 080 (A5S 325Z) |
|---|---|
| Note | For removing and installing oil pump |
| Transmission | A5S 310Z, A5S 560Z |
| Storage location | B18 |
| SI number | 1 09 90(282) |
| Order number | 24 1 180 |
| Fixture | |
| Consisting of | |
| 1 = 24 1 181 | Retaining tube |
| 2 = 24 1 182 | Thread spindle |
| 3 = 24 1 183 | Retaining ring, inner |
| Note | (not shown) |
SPECIAL TOOL DESIGNATION
Scheme 318
24 1 190 Drift
Minimum set: Mechanical tools
| In conjunction with | 00 5 500 |
|---|---|
| Note | For fitting rotary shaft seal in front section of transmission casing |
| Transmission | A5S 310Z |
| Storage location | B28 |
| SI number | 1 09 90(282) |
| Order number | 24 1 190 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 319
24 1 200 Installation sleeve
Minimum set: Mechanical tools
| Note | For preventing damage to rotary shaft seal while fitting on gearshift shaft |
|---|---|
| Transmission | A5S 310Z |
| Storage location | B18 |
| SI number | 1 09 90(282) |
| Order number | 24 1 200 |
| Installation sleeve |
SPECIAL TOOL DESIGNATION
Scheme 320
24 1 210 Retaining plate for disc package
| Note | Not required as from transmission No. 11 2 300 |
|---|---|
| Transmission | A5S 310Z |
| Storage location | B22 |
| SI number | 1 09 90(282) |
| Order number | 24 1 210 |
| Retaining plate for disc package |
SPECIAL TOOL DESIGNATION
Scheme 321
24 1 220 Take-up support for drive flange
| In conjunction with | 24 1 170 (A5S 310Z), 24 4 110 (A5S 440Z) |
|---|---|
| Note | When loosening slotted nut |
| Transmission | A5S 310Z, A5S 440Z |
| SI number | 1 09 90(282) |
| Order number | 24 1 220 |
| Take-up support for drive flange |
SPECIAL TOOL DESIGNATION
Scheme 322
24 1 230 Pressing tool
| Note | For removing and installing piston (cover) on brake Ct |
|---|---|
| Transmission | A5S 310Z |
| Storage location | B20 |
| SI number | 1 14 93(718) |
| Order number | 24 1 230 |
| Pressing tool |
SPECIAL TOOL DESIGNATION
Scheme 323
24 1 240 Measuring device
| Note | For determining spacers on brake C |
|---|---|
| Transmission | A5S 310Z |
| Storage location | B20 |
| SI number | 1 14 93(718) |
| Order number | 24 1 240 |
| Measuring device |
SPECIAL TOOL DESIGNATION
Scheme 324
24 1 250 Lifting gear
| Note | For removing and installing brake clutch unit D/G incl. sprag wheel |
|---|---|
| Transmission | A5S 310Z |
| Storage location | B11, C11 |
| SI number | 1 14 93(718) |
| Order number | 24 1 250 |
| Lifting gear |
SPECIAL TOOL DESIGNATION
Scheme 325
24 1 260 Removal and mounting fixture
| Note | For removing and installing cylinder D/E with planetary gear train |
|---|---|
| Transmission | A5S 560Z |
| Storage location | C1, C2 |
| SI number | 1 01 95(892) |
| Order number | 24 1 260 |
| Removal and mounting fixture | |
| Consisting of | |
| 1 = 24 1 261 | Handle |
| 2 = 24 1 262 | Spindle with knurled nut |
| 3 = 24 1 263 | Centering bush |
SPECIAL TOOL DESIGNATION
Scheme 326
24 1 270 Removal and mounting fixture
| Note | For removing and installing clutch A/B/C |
|---|---|
| Transmission | A5S 560Z |
| Storage location | B14, B15, B3 |
| SI number | 1 01 95(892) |
| Order number | 24 1 270 |
| Removal and mounting fixture | |
| Consisting of | |
| 1 = 24 1 271 | Lifting tube with eye bolt |
| 2 = 24 1 272 | Lock pin |
SPECIAL TOOL DESIGNATION
Scheme 327
24 1 280 Removal and mounting fixture
| Note | For removing and installing brake clutch F |
|---|---|
| Transmission | A5S 560Z |
| Storage location | C20 |
| SI number | 1 01 95(892) |
| Order number | 24 1 280 |
| Removal and mounting fixture | |
| Consisting of | |
| 1 = 24 1 281 | Handle with spindle |
| 2 = 24 1 282 | Knurled nut |
| 3 = 24 1 283 | Centering handle |
SPECIAL TOOL DESIGNATION
Scheme 328
24 1 290 Wedges
| Note | For fixing disc pack C in position while securing retainer tabs |
|---|---|
| Transmission | A5S 560Z |
| Storage location | C17 |
| SI number | 1 01 95(892) |
| Order number | 24 1 290 |
| Wedges |
SPECIAL TOOL DESIGNATION
Scheme 329
24 1 300 Impact tool
| Note | For securing retainer tabs on disc pack C |
|---|---|
| Transmission | A5S 560Z |
| Storage location | C17 |
| SI number | 1 01 95(892) |
| Order number | 24 1 300 |
| Impact tool |
SPECIAL TOOL DESIGNATION
Scheme 330
24 1 310 Releasing tool
| Note | For releasing retainer tabs on disc pack C |
|---|---|
| Transmission | A5S 560Z |
| Storage location | C2 |
| SI number | 1 01 95(892) |
| Order number | 24 1 310 |
| Releasing tool | |
| Consisting of | |
| 1 = 24 1 311 | Profile section (slide) |
| 2 = 24 1 312 | Basic body |
SPECIAL TOOL DESIGNATION
Scheme 331
24 1 350 Fixture
| Note | For removing sealing cap for working piston, clutch 4 |
|---|---|
| Series | E36, E39, E46 |
| Transmission | A4S 270R, A4S 310R |
| SI number | 1 04 02(835) |
| Order number | 24 1 350 |
| Fixture | |
| Consisting of | |
| 1 = 24 1 351 | Pliers |
| 2 = 24 1 352 | Adapter |
| 3 = 24 1 353 | Disc |
SPECIAL TOOL DESIGNATION
Scheme 332
24 2 020 Tool
| Note | For compressing disc spring |
|---|---|
| Transmission | 4 HP 22, 4 HP 24 |
| Storage location | C32 |
| Order number | 24 2 020 |
| Tool |
SPECIAL TOOL DESIGNATION
Scheme 333
24 2 030 Tool
| Note | For compressing disc spring |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | C32 |
| Order number | 24 2 030 |
| Tool |
SPECIAL TOOL DESIGNATION
Scheme 334
24 2 040 Tool
| Note | For compressing disc spring |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | C32 |
| Order number | 24 2 040 |
| Tool |
SPECIAL TOOL DESIGNATION
Scheme 335
24 2 050 Extractor grip
| Note | For sealing plugs in transmission case lower section / Replaced by 24 0 050 |
|---|---|
| Order number | 24 2 050 |
| Extractor grip |
SPECIAL TOOL DESIGNATION
24 2 140 Tensioning tool
| Note | For removing and installing snap ring in front of centering plate of ZF transmissions |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22 |
| Order number | 24 2 140 |
| Tensioning tool |
SPECIAL TOOL DESIGNATION
Scheme 336
24 2 310 Tool kit for removing and installing reverse gear piston
| Note | For disassembling and assembling transmission for "Sealing intermediate plate" job |
|---|---|
| Transmission | A4S 270R, A4S 310R |
| SI number | 1 22 97(239) |
| Order number | 24 2 310 |
| Tool kit for removing and installing reverse gear piston | |
| Consisting of | |
| 1 = 24 2 311 | Pressure plate |
| Note | For removing and installing spring retainer |
| 2 = 24 2 312 | Spindle with pressure plate |
| Note | Spindle M14x1.5, nut M14, pressure plate and washer / For removing and installing spring retainer |
| 3 = 24 2 313 | Guide pin (2) |
| Note | For fixing gaskets and intermediate plates on intermediate housing |
| 4 = 24 2 314 | Slip bush |
| Note | For removing piston in cylinder of intermediate plate |
SPECIAL TOOL DESIGNATION
Scheme 337
24 2 320 Box spanner
| In conjunction with | 24 2 330 |
|---|---|
| Note | For 3/16 "socket head cap screw with 1/4" socket for adjusting brake band |
| Transmission | A4S 270R, A4S 310R |
| SI number | 1 24 97(257) |
| Order number | 24 2 320 |
| Box spanner |
SPECIAL TOOL DESIGNATION
Scheme 338
"24 2 330 1/2" open-ended spanner
| In conjunction with | 24 2 320 |
|---|---|
| Note | For adjusting brake band |
| Transmission | A4S 270R, A4S 310R |
| SI number | 1 24 97(257) |
| Order number | 24 2 330 |
| "1/2" open-ended spanner |
SPECIAL TOOL DESIGNATION
Scheme 339
24 2 360 Drift
Minimum set: Mechanical tools
| Note | For fitting radial seal on torque converter |
|---|---|
| Transmission | GA6 HP26Z, GA6 HP32Z |
| Storage location | B46 |
| SI number | 1 14 01 (766) |
| Order number | 24 2 360 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 340
24 3 040 Gauge
| Note | For adjusting restrictor piston when installing gearshift unit |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22 |
| Order number | 24 3 040 |
| Gauge |
SPECIAL TOOL DESIGNATION
Scheme 341
24 3 050 Gauge
| Note | For aligning hydraulic gearshift unit in transmission |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Order number | 24 3 050 |
| Gauge |
SPECIAL TOOL DESIGNATION
Scheme 342
24 3 140 Drive bush
| Note | For checking smooth movement of oil pump |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A5S 560Z |
| Storage location | A20 |
| Order number | 24 3 140 |
| Drive bush |
SPECIAL TOOL DESIGNATION
Scheme 343
24 3 150 Drive bush
| Note | For checking smooth movement of oil pump |
|---|---|
| Transmission | 3 HP 20, 3 HP 22 |
| Storage location | A20 |
| Order number | 24 3 150 |
| Drive bush |
SPECIAL TOOL DESIGNATION
Scheme 344
24 4 000 Assembly grip (2)
Minimum set: Mechanical tools
| Note | For removing and installing torque converter |
|---|---|
| Transmission | A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z |
| Storage location | C18 |
| Order number | 24 4 000 |
| Assembly grip (2) |
SPECIAL TOOL DESIGNATION
Scheme 345
24 4 070 Fixture
| Note | For checking torque converter for leaks |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, 4 HP 22 |
| Order number | 24 4 070 |
| Fixture |
SPECIAL TOOL DESIGNATION
Scheme 346
24 4 080 Fixture
| Note | For firmly holding torque converter in position while removing and installing transmission |
|---|---|
| Transmission | 4 HP 22, 4 HP 24 |
| Storage location | Single |
| Order number | 24 4 080 |
| Fixture |
SPECIAL TOOL DESIGNATION
Scheme 347
24 4 090 Drift
Minimum set: Mechanical tools
| In conjunction with | 00 5 500 |
|---|---|
| Note | For fitting rotary shaft seal on output end |
| Transmission | A5S 440Z, A5S 560Z |
| Storage location | B28 |
| SI number | 1 06 92(509) |
| Order number | 24 4 090 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 348
24 4 100 Drift
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal on drive side (behind converter) |
|---|---|
| Transmission | A5S 440Z, A5S 560Z |
| Storage location | C29 |
| SI number | 1 06 92(509) |
| Order number | 24 4 100 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 349
24 4 110 Spanner
Minimum set: Mechanical tools
| Note | For releasing and tightening slotted nut on output flange |
|---|---|
| Transmission | A5S 440Z, A5S 560Z |
| Storage location | A23 |
| SI number | 1 06 92(509) |
| Order number | 24 4 110 |
| Spanner |
SPECIAL TOOL DESIGNATION
Scheme 350
24 4 120 Fixture
| Note | For firmly holding torque converter in position while removing and installing transmission. Replaced by 24 4 130. |
|---|---|
| Order number | 24 4 120 |
| Fixture |
SPECIAL TOOL DESIGNATION
Scheme 351
24 4 130 Locating tool
| Note | For firmly holding torque converter in position while removing and installing transmission |
|---|---|
| Transmission | A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP26Z, GA6 HP32Z |
| Storage location | A33 |
| SI number | 1 05 97(181) |
| Order number | 24 4 130 |
| Locating tool | |
| Consisting of | |
| 1 = 24 4 131 | Base unit |
| 2 = 24 4 132 | Blade |
| Note | Transmission: A5S 440Z, GA6HP26Z (N62) |
| 3 = 24 4 133 | Blade |
| Note | Transmission: A4S 310R and A5S 390G |
| 4 = 24 4 134 | Blade |
| Note | Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z |
| 5 = 24 4 135 | Blade |
| Note | Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73) |
| 6 = 24 4 136 | Counter plate |
| 7 = 24 4 137 | Blade |
| Note | Transmission: A5S 360R |
SPECIAL TOOL DESIGNATION
Scheme 352
24 4 200 Drift and slip bush
Minimum set: Mechanical tools
| Note | For driving in shaft seal on drive shaft. |
|---|---|
| Transmission | GACVT16Z |
| Order number | 24 4 200 |
| Drift and slip bush | |
| Consisting of | |
| 1 = 24 4 201 | Drift |
| 2 = 24 4 202 | Slip bush |
SPECIAL TOOL DESIGNATION
Scheme 353
24 5 120 Tool
| Note | For centering converter bell housing with respect to oil pump during assembly |
|---|---|
| Transmission | A4S 270R, A4S 310R |
| Storage location | B2 |
| SI number | 1 04 95(906) |
| Order number | 24 5 120 |
| Tool | |
| Consisting of | |
| 1 = 24 5 121 | Centering bush |
| 2 = 24 5 122 | Centering pin (3) |
SPECIAL TOOL DESIGNATION
Scheme 354
24 5 140 Centering pin
| Note | For transfer plate and gasket to shift unit (2 x) |
|---|---|
| Transmission | A4S 310R |
| Order number | 24 5 140 |
| Centering pin |
SPECIAL TOOL DESIGNATION
24 5 150 Centering pin with thread (2)
| Note | For centering gearshift unit in transmission during assembly |
|---|---|
| Transmission | A4S 270R, A4S 310R |
| Storage location | A2 |
| SI number | 1 03 90(184) |
| Order number | 24 5 150 |
| Centering pin with thread (2) |
SPECIAL TOOL DESIGNATION
Scheme 355
24 5 160 Centering pins
| Note | For centering main housing with respect to intermediate and converter housing (2) |
|---|---|
| Transmission | A4S 270R, A4S 310R |
| Storage location | A2, B2 |
| SI number | 1 03 93(663) |
| Order number | 24 5 160 |
| Centering pins |
SPECIAL TOOL DESIGNATION
Scheme 356
24 5 190 Adapter
| In conjunction with | 13 3 061, 13 3 067, 24 0 021, 24 0 023, 24 0 140 |
|---|---|
| Note | For pressure gauge 13 3 061 for checking oil pressure in transmission |
| Transmission | A4S 270R, A4S 310R |
| Storage location | C20 |
| SI number | 1 03 90(184) |
| Order number | 24 5 190 |
| Adapter |
SPECIAL TOOL DESIGNATION
Scheme 357
24 5 200 Impact bush
| Note | For driving in radial seal of selector lever shaft / Replaced by 24 5 360 |
|---|---|
| Transmission | A4S 270R, A4S 310R |
| SI number | 1 03 90(184) |
| Order number | 24 5 200 |
| Impact bush |
SPECIAL TOOL DESIGNATION
Scheme 358
24 5 210 Holder
| Note | For loosening and tightening gearshift cable |
|---|---|
| Transmission | 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 310Z |
| Storage location | B19 |
| SI number | 1 04 91(372) |
| Order number | 24 5 210 |
| Holder |
SPECIAL TOOL DESIGNATION
Scheme 359
24 5 220 Holder
| Note | For loosening and tightening gearshift cable |
|---|---|
| Transmission | A5S 300J, A5S 310Z |
| Storage location | B19 |
| SI number | 1 04 91(372) |
| Order number | 24 5 220 |
| Holder |
SPECIAL TOOL DESIGNATION
Scheme 360
24 5 230 Assembly ring
Minimum set: Mechanical tools
| Note | For fitting rotary shaft seal on gearshift shaft |
|---|---|
| Transmission | 4 HP 22, 4 HP 24, A5S 310Z |
| Storage location | B19 |
| SI number | 1 04 91(372) |
| Order number | 24 5 230 |
| Assembly ring |
SPECIAL TOOL DESIGNATION
Scheme 361
24 5 240 Holder
| Note | For releasing and tightening gearshift cable / transmission with position switch |
|---|---|
| Transmission | A5S 310Z, A5S 560Z |
| Storage location | B19 |
| SI number | 1 06 92(509) |
| Order number | 24 5 240 |
| Holder |
SPECIAL TOOL DESIGNATION
Scheme 362
24 5 250 Bush
Minimum set: Mechanical tools
| In conjunction with | 24 5 490 |
|---|---|
| Note | For fitting rotary shaft seal on selector shaft |
| Transmission | A5S 310Z, A5S 560Z |
| Storage location | B19 |
| SI number | 1 02 95(896) |
| Order number | 24 5 250 |
| Bush |
SPECIAL TOOL DESIGNATION
Scheme 363
24 5 260 Extractor tool
Minimum set: Mechanical tools
| Note | For removing rotary shaft seal of selector shaft / transmission with position switch |
|---|---|
| Transmission | A5S 310Z, A5S 440Z, A5S 560Z |
| Storage location | B19 |
| SI number | 1 02 95 (896) |
| Order number | 24 5 260 |
| Extractor tool | |
| Consisting of | |
| 1 = 24 5 261 | Insert |
| 2 = 24 5 262 | Bushing |
SPECIAL TOOL DESIGNATION
Scheme 364
24 5 270 Bush
Minimum set: Mechanical tools
| In conjunction with | 24 5 490 |
|---|---|
| Note | For fitting rotary shaft seal on selector shaft |
| Transmission | A5S 440Z |
| Storage location | B18 |
| SI number | 1 08 96(080) |
| Order number | 24 5 270 |
| Bush |
SPECIAL TOOL DESIGNATION
Scheme 365
24 5 350 Take-up support for automatic transmission
| Note | Miscellaneous: Japan and South Africa only |
|---|---|
| Transmission | A5S 300J |
| Order number | 24 5 350 |
| Take-up support for automatic transmission |
SPECIAL TOOL DESIGNATION
Scheme 366
24 5 400 Drift
| In conjunction with | 00 5 500 |
|---|---|
| Note | For drive shaft seal. |
| Transmission | GACVT16Z |
| Order number | 24 5 400 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 367
24 5 490 Slip sleeve (5)
Minimum set: Mechanical tools
| Note | For preventing damage to rotary shaft seal while fitting on gearshift shaft |
|---|---|
| Transmission | A5S 310Z, A5S 440Z, A5S 560Z |
| SI number | 1 02 95 (896) |
| Order number | 24 5 490 |
| Slip sleeve (5) |
SPECIAL TOOL DESIGNATION
Scheme 368
24 6 000 Test cable, 8-pin
| In conjunction with | Test box 88-pin 614410 |
|---|---|
| Note | For automatic transmission (EH transmission) |
| Transmission | 4 HP 22, 4 HP 24 |
| Storage location | A 101 |
| SI number | 2 03 91 (313) |
| Order number | 24 6 000 |
| Test cable, 8-pin |
SPECIAL TOOL DESIGNATION
Scheme 369
24 6 010 Test cable, 9-pin
| In conjunction with | Test box 88-pin 614410 |
|---|---|
| Note | For automatic transmission (EH transmission) |
| Transmission | A4S 270R, A4S 310R |
| Storage location | A 102 |
| SI number | 2 03 91 (313) |
| Order number | 24 6 010 |
| Test cable, 9-pin |
SPECIAL TOOL DESIGNATION
Scheme 370
24 6 020 Test cable, 14-pin
| In conjunction with | Test box 88-pin 614410 |
|---|---|
| Note | For automatic transmission (EH transmission) |
| Transmission | A5S 310Z |
| Storage location | A 103 |
| SI number | 0 02 99 (399) |
| Order number | 24 6 020 |
| Test cable, 14-pin | |
| Consisting of | |
| 24 6 029 | Operating instructions |
SPECIAL TOOL DESIGNATION
Scheme 371
24 6 060 Test cable, 16-pin
| Note | For automatic transmission (EH transmission) |
|---|---|
| Transmission | A5S 310Z, A5S 560Z |
| Storage location | A 106 |
| SI number | 2 02 93 (650) |
| Order number | 24 6 060 |
| Test cable, 16-pin |
SPECIAL TOOL DESIGNATION
Scheme 372
24 6 070 Test cable, 20-pin
Minimum set: Measuring and testing equipment
| In conjunction with | 61 1 459 |
|---|---|
| Note | For automatic transmission GM5 |
| Transmission | A5S 360R |
| Storage location | A 107 |
| SI number | 2 01 99 (468) |
| Order number | 24 6 070 |
| Test cable, 20-pin |
SPECIAL TOOL DESIGNATION
24 6 080 Test lead, 16-pin
Minimum set: Measuring and testing equipment
| In conjunction with | 61 1 459 |
|---|---|
| Transmission | GA6 HP26Z |
| Storage location | L204 |
| SI number | 2 06 01 (763) |
| Order number | 24 6 080 |
| Test lead, 16-pin |
SPECIAL TOOL DESIGNATION
Scheme 373
24 8 100 Adapter
Minimum set: Mechanical tools
| Note | For filling automatic transmission |
|---|---|
| Transmission | GACVT16Z |
| SI number | 1 05 01 (718) |
| Order number | 24 8 100 |
| Adapter |
SPECIAL TOOL DESIGNATION
Scheme 374
24 8 110 Drift
Minimum set: Mechanical tools
| In conjunction with | 00 5 500 |
|---|---|
| Note | For driving shaft seal onto drive flange |
| Transmission | GACVT16Z |
| SI number | 1 02 02 (823) |
| Order number | 24 8 110 |
| Drift |
SPECIAL TOOL DESIGNATION
Scheme 375
24 8 120 Rubber profile
Minimum set: Mechanical tools
| Note | For protecting shaft seal in transmission when installing output shafts. |
|---|---|
| Transmission | GACVT16Z, GS5-65BH, GS6-85BG, GS6-85DG |
| SI number | 1 02 02 (823) |
| Order number | 24 8 120 |
| Rubber profile |
SPECIAL TOOL DESIGNATION
Scheme 376
24 8 130 Drift
| In conjunction with | 00 5 550 |
|---|---|
| Note | For driving in shaft seal on input shaft. |
| Transmission: CVT automatic transmission Replaced by 24 4 200 | |
| Transmission | GACVT16Z |
| SI number | 1 02 02 (823) |
| Order number | 24 8 130 |
| Drift |
SPECIAL TOOL DESIGNATION
