12 00 ... Instructions on starting aid
Do not start the engine with help of starting sprays.
Preparation
Conform with the following when starting engine with starting cable.
- Ensure that jump lead wires are to appropriate cross-section size.
- Only use fuse-protected jump leads.
- Check whether the current supplying battery has 12 V voltage.
- If engine is started from battery of another vehicle, ensure that there is no contact between the bodies of both vehicles.
| CAUTION | Never touch ignition system components and current - dangerous high tension! |
If the battery in the vehicle supplying power is weak, start the engine of this vehicle and let it run at idling speed.
Carrying out
Always conform with the procedures to avoid injury to persons or damage to parts.
- On automatic transmission, select "P" setting, apply handbrake.
- Move the shift lever of vehicles with manual transmission into neutral and apply the parking brake.
- Ensure that the jump leads cannot get caught in rotating parts, e.g. fan.
- First connect positive terminals of both batteries with one jump lead (red).
- Use positive connection point in engine compartment for vehicles with one battery in trunk.
- Then attach second jump lead (black) to negative terminal of donor battery and to engine ground or body ground on vehicle to be started.
| CAUTION | Never connect second jump lead (black) to negative terminal of battery in vehicle to be started. This would produce explosive gas which could be ignited by sparks. |
Danger of explosion!
After engine of vehicle to be started has started up, first disconnect the jump lead on the negative terminal/ground connection. Then remove jump lead from positive terminals.
61 00 ... BATTERY
Note. Important notes and instructions for handling batteries in the dealership can be found in: Battery master document Disconnecting battery, refer to 12 00 ... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY Battery charging, refer to 61 00 ... BATTERY CHARGING Welding work, refer to 12 00 ... INSTRUCTIONS FOR WELDING WORK (OVERLOAD PROTECTION OF CONTROL UNITS) External jump-starting aid, refer to 12 00 ... INSTRUCTIONS ON STARTING AID
Battery care and maintenance
In low-maintenance batteries, check the acid level at least once a year. If necessary, top up with distilled water up to the top marking.
The increasing number of electronic control units in the car reduces the self-discharging time of the battery (even in standby mode). To maintain the battery service life and to avoid exhaustive discharging, recharge laid-up vehicles every 6 weeks at the latest (refer to battery recharging schedule here, SI 6 10 398 387). The time for self-discharging depends on vehicle type and equipment specification.
Battery test
The battery acid density can be used to measure the charge state. However this test produces uncertainty caused by a design-related range of variation. The acid density e.g. for a charged battery is 1.28 kg/l (in the tropical version the acid density is 1.23 kg/l).
Another interference factor is the acid lamination immediately after filling with distilled water.
Battery wear with partially sulfated and/or heavily contaminated plates will also lead to incorrect acid density test results.
61 00 ... BATTERY CHARGING
If a normal or quick charger is used to charge the battery, the battery must be disconnected from the vehicle electrical system and removed. This prevents damage to paintwork and upholstery.
Ideally, battery charging is performed with BMW-approved charging computers, refer to
SI 2 03 98 350 and
SI 2 06 02 854.
| IMPORTANT | In order to prevent the intelligent battery sensor from malfunctioning, the charging terminals in the engine compartment must be used without fail in vehicles from E60 and should be used if possible in other vehicles. |
| IMPORTANT | Before charging the battery while it is installed, first carry out a closed-circuit current test. Refer to 61 20 ... BATTERY OPEN-CIRCUIT CURRENT TEST . If here the voltage is 10 V or less, one or more of the cells may be faulty or the entire battery may already be damaged. In this case, always remove the battery as escaping gases during charging could damage the interior equipment and trim. Attempt to regenerate faulty cells with low charging current. |
If necessary, open existing plugs on the individual cells.
61 00 ... Safety instructions for handling vehicle battery
Battery acid is highly corrosive
Do not allow any battery acid to come into contact with the eyes, the skin or clothing. Therefore wear protective clothing, gloves and goggles.
Do not tilt the battery, acid may emerge from the vent opening.
In event of contact with acid
If acid is splashed into the eyes, rinse them immediately for several minutes with clear water. You must then consult a doctor without delay.
If acid is splashed onto the skin or clothing, neutralize it immediately with a soapy solution and rinse with lots of water.
Seek medical attention immediately if battery acid is accidentally swallowed.
Explosion hazard
Strictly no flames, sparks, naked light or smoking!
A highly explosive mixture of electrolytic gas is created when batteries are charged. The rooms where charging is carried out must therefore always be well ventilated.
Avoid the formation of sparks when handling cables, wiring and electrical devices.
Turn the ignition lock to the 0 position before disconnecting or connecting the battery.
Do not place tools or any similar object on the battery (danger of short-circuiting and explosion!).
61 13 ... UNLOCKING AND DISCONNECTING DIFFERENT PLUG CONNECTIONS
Note. Examples of unlocking and disconnecting different plug connections.
Press lock and open clip in direction of arrow.
Disconnect plug connection.
Scheme 33
Press lock and open clip in direction of arrow.
Disconnect plug connection.
Scheme 34
Open clip in direction of arrow and disconnect plug connection in direction of arrow.
Scheme 35
Press lock and disconnect plug connection in direction of arrow.
Scheme 36
Press lock and disconnect plug connection in direction of arrow.
Scheme 37
Press lock and disconnect plug connection in direction of arrow.
Scheme 38
Press lock and disconnect plug connection in direction of arrow.
Scheme 39
Press lock and disconnect plug connection in direction of arrow.
Scheme 40
Press lock and disconnect plug connection in direction of arrow.
Scheme 41
For procedure, refer to 61 13 ... UNLOCKING AND DISCONNECTING DIFFERENT PLUG CONNECTIONS .
61 13 ... DME MASTER RELAY CONNECTOR
Unlock locking flap (1) of corresponding cable.
Scheme 42
With special tool 61 1 136 or 61 1 137 (ejector), press back arrester hook (2) of appropriate contact and pull out cable.
Scheme 43
61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS
Special tools required
- 61 1 150
- 61 1 190
- 61 4 320
- 61 8 084
- 61 9 020
- 61 9 029
- 61 9 041
- 61 9 042
- 619 043
- 619 044
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Repair ranges I, II, III for vehicle electrical system
Scheme 44
- Order No.: 81 24 9 408 080
- Order No.: 81 24 9 408 300
- Order No.: 81 24 9 408 400
Sourcing reference: BMW Parts Service.
Note. Operating instructions for the special tools contained in these repair ranges, refer to "Tool for wiring harness repair, repair range I, II, III" special tool 61 8 084.
Repair range IV for vehicle electrical system, special tool 61 9 020
Scheme 45
Contents
- Special tool 61 9 041 (hand pliers)
- Special tool 61 9 042 (matrix)
- Special tool 61 9 043 (wire stripper)
- Special tool 61 9 044 (matrix)
Note. Operating instructions for the special tools contained in the this repair range, refer to "repair range IV for vehicle electrical system (Vol. 1 / Vol. 2 / Vol. 3 / Vol. 4)", special tool 61 9 029.
Special tool 61 9 043 (wire stripper with wire cutter) for cutting and stripping wires.
Scheme 46
Handling
Cutting to length and stripping insulating from cables
Special tool 61 9 041 (hand pliers) with special tool 61 9 042 (matrix) for crimping connectors and contact tubes for fan connectors up to a wire cross-section of 2.5 mm 2 and for pushing on contact tubes for fan connectors.
Scheme 47
Handling
Crimping stop parts (contacts).
Fan connector for retrofitting/repairs.
Special tool 61 9 041 (hand pliers) with special tool 61 9 044 (matrix) for crimping cable guide and strain relief device on antenna elbow plug.
Scheme 48
Handling
Antenna elbow plug on radio receiver. Refer to 61 13 ... ANTENNA ELBOW PLUG ON RADIO RECEIVER .
Special tool 61 1 150 (release and pressing-out tool) for
Scheme 49
- releasing round plug housings
- releasing relay carriers
- pressing out contacts
- removing indicator lights
Handling
Opening plug housings and removing contacts of different plug systems, refer to 61 13 ... OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS
Repair kit for ignition cables and for crimping fan connector receptacles 4 mm 2
Scheme 50
Handling
Crimping stop parts (contacts).
Service Information 1 03 89 (037)
Special tool 61 4 320 (crimping set with pliers) for
Scheme 51
- Cutting to length and stripping insulation from optical fibers, refer to «61 13 ... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBRES TO LENGTH»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-13-cutting-off-stripping)
- Crimping optical fibers, refer to «61 13 ... CRIMPING OPTICAL FIBRES»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-13-crimping-optical-fibres)
- Crimping MPQ contacts, refer to «61 13 ... CRIMPING MICRO POWER QUADLOCK CONTACTS (MPQ)»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-13-crimping-micro-power)
- Crimping MQS contacts, refer to «61 13 ... CRIMPING MICRO QUADLOCK SYSTEM CONTACTS (MQS)»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-13-crimping-micro-quadlock)
Special tool 61 1 190 pliers for insulation displacement connector for repairing ribbon cables.
Scheme 52
Handling
Repairing ribbon cables. Refer to 61 13 ... REPAIRING RIBBON CABLES .
For procedures, refer to 61 13 ... UNLOCKING AND DISCONNECTING DIFFERENT PLUG CONNECTIONS .
61 13 ... ANTENNA ELBOW PLUG ON RADIO RECEIVER
| IMPORTANT | This repair solution is only possible up to model year 10/ 2000. Replace entire antenna cable on affected vehicles. |
Cut off faulty antenna angle plug directly after strain relief.
Carefully and with precision, strip insulation from antenna cable as illustrated (lengths given in mm).
Scheme 53
Brush shield (copper braid) towards rear.
| IMPORTANT | There must be no more copper wire protruding in the direction of the inner conductor on the inner conductor insulation (risk of short circuits). |
Create a loop on inner conductor.
Scheme 54
| IMPORTANT | Cover soldering area extensively in center console all round radio aperture. |
Avoid blobs of melted solder in inside area.
Tin-plate center connection on antenna angle plug and stripped inner conductor.
Scheme 55
Solder inner conductor on center connection with a small soldering iron (max. 50 watts) and matching soldering tip (1).
Gently push insulation forward to soldering point and pay attention to correct position of loop.
Note. The loop must not under any circumstances come into contact with the metal parts of the antenna plug.
Special tool 61 9 041 (hand pliers) in conjunction with special tool 61 9 044 (matrix) is used to crimp antenna angle plug.
Scheme 56
Unlock special tool 61 9 041
Squeeze grips (1) lightly and push unlocking lever (2) in direction of arrow.
OR
Compress handles as far as they will go, tool unlocks automatically.
Scheme 57
Place antenna angle plug with cable guide and strain relief in matrix (1).
Scheme 58
Compress special tool 61 9 041 as far as it will go.
Scheme 59
Special tool 61 9 041 unlocks automatically.
Remove antenna angle plug with antenna cable from special tool 61 9 044.
61 13 ... Base of tab connector housings
Unlock hook (1) with special tool 61 1 360 and slide plug housing downwards out of base.
Scheme 60
61 13 ... CRIMPING MICRO POWER QUADLOCK CONTACTS (MPQ)
Special tools required
- 61 4 320
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
To crimp MPQ contacts, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 325 (2) from crimping set 61 4 320.
Scheme 61
Note. Pliers (1) open automatically as far as they will go when handles are pressed together.
Open pliers (1).
Scheme 62
Note. Place contact (2) with utmost care in designated nest (observe cable cross-section) in crimping head (3). Make sure it is exactly positioned.
Place MPQ contact (2) in crimping head (3).
Close pliers (1) one notch.
Note. Follow procedure for cutting and stripping insulation from cables.
Insert stripped cable (2).
Scheme 63
Close pliers (1) fully.
Open pliers (1) and remove cable (2).
Note. Check contact for correct crimping.
61 13 ... CRIMPING MICRO QUADLOCK SYSTEM CONTACTS (MQS)
Special tools required
- 61 4 320
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
To crimp MQS contacts, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 324 (2) from crimping set 61 4 320.
Scheme 64
Note. Pliers (1) open automatically as far as they will go when handles are pressed together.
Open pliers (1).
Scheme 65
Fold up contact carrier (2).
Insert MQS contact (3) in contact carrier (2).
Fold back contact carrier (2).
Note. Follow procedure for cutting and stripping insulation from cables.
Close pliers (1) one notch.
Scheme 66
Insert stripped cable (2).
Close pliers (1) fully.
Open pliers (1).
Open contact carrier (2) gently and carefully remove MQS contact.
Scheme 67
Note. Check contact for correct crimping.
61 13 ... Crimping annular contacts
Crimpacll crimping pliers from repair kit 1 are used to crimp annular contacts.
Scheme 68
Open crimping pliers (1).
Scheme 69
Note. Place contact (2) in designated nest (observe wire cross-section) with particular care. Make sure it is exactly positioned.
Insert annular contact (2) in crimping pliers (1).
Close crimping pliers (1) gently and keep closed.
Note. Follow procedure for cutting and stripping insulation from cables.
Feed stripped cable (1) into annular contact (2) completely.
Scheme 70
Close crimping pliers (3) fully.
Open crimping pliers (3) and remove cable (2).
Note. Check contact for correct crimping.
61 13 ... CRIMPING OPTICAL FIBRES
Special tools required
- 61 4 320
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
To crimp optical fibres, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 323 (2) from crimping set 61 4 320.
Scheme 71
Note. Pliers (1) open automatically as far as they will go when handles are pressed together.
Move contact guide by means of stop lever (1) into corresponding position (pin contact or jack).
Scheme 72
Open pliers (2).
Place pin contact or jack (1) in crimping head and secure with locking lever (3).
Scheme 73
Note. Follow procedure for cutting and stripping insulation from optical fibres. Refer to 61 13 ... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBRES TO LENGTH .
Insert stripped optical fibre (1) as far as it will go into pin contact or jack (2).
Scheme 74
Close pliers (3) fully.
Open pliers (3) and locking lever (4).
Remove optical fibre (1).
| IMPORTANT | Make sure optical fibre is correctly seated in jack. |
Right (A)
End of optical fibre (1) must be flush with tip of pin contact (2).
Wrong (B)
End of optical fibre (1) is not flush with tip of pin contact (2).
Scheme 75
61 13 ... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBRES TO LENGTH
Special tools required
- 61 4 320
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
To cut off, strip insulation and cut optical fibres to length, use pliers 61 4 321 (1) in conjunction with crimping head 61 4 322 (2) from crimping set 61 4 320.
Note. Pliers (1) open automatically as far as they will go when handles are pressed together.
Scheme 76
Cutting Optical Fibre
Open pliers (1).
Place optical fibre (2) in cutting device (3).
Close pliers (1) and remove optical fibre (2).
Scheme 77
Stripping Insulation From Optical Fibre
Open pliers (1).
Open lever (2) in direction of arrow.
Scheme 78
Slide optical fibre (1) into stripping device (2) until flush at point (3).
Close pliers (4) fully.
Close clamping lever (5) in direction of arrow.
Open pliers (4) by one tooth notch.
Open clamping lever (5) against direction of arrow again and remove optical fibre (1).
Note. A stripping replacement blade set is available under number 61 4 327.
Scheme 79
Cutting Optical Fibre To Length
| IMPORTANT | The cutting blade must be replaced prior to each cutting of the optical fibre. |
Pull pin (1) in direction of arrow.
Scheme 80
Fold up blade retaining link (2) in direction of arrow.
| WARNING | Risk of injury when changing the blade. |
Remove blade (1) and replace.
Scheme 81
Installation
Make sure blade (1) is correctly seated on locating points (2).
Open pliers (3).
Slide optical fibre (1) into cutting device (2) until insulation of optical fibre (1) butts against clamping device.
Scheme 82
Close pliers (3) fully and keep closed.
Remove optical fibre (1).
61 13 ... OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS
Abbreviations and what they mean
| MDK 3plus | Miniature double flat spring contact |
|---|---|
| JPT ELA | Junior Power Timer flat spring contacts with strand sealing |
| DFK ELA | Double flat spring contacts with strand sealing |
| Elo | Electronic contacts with and without strand sealing Manufacturer: Siemens |
| Elo Power | Electronic contacts for heavy loads with and without strand sealing Manufacturer: Siemens |
| MQS | Micro Quadlock System electronic contacts with and without strand sealing Manufacturer: AMP |
| MPQ | Micro Power Quadlock electronic contacts for heavy loads with and without strand sealing Manufacturer: AMP |
| D 1.5 / 2.5 | Round contacts of 1.5 mm or 2.5 mm diameter |
ABBREVIATIONS
Ultrasonic-welded connectors
Ultrasonic-welded connectors (1) can be identified by the welds (2) on their longitudinal side.
Scheme 83
The contacts of these connectors cannot be replaced. Replace plug completely.
Note. Special tools referred to in the repair instructions below are contained in the following special tool kits
Release and press-out tool 61 1 150
Repair instructions for opening plug housings and removing contacts of different plug systems
Plug system D 1.5/D 2.5
- Circular plugs, 7-, 8-pin, System D 2.5
- Circular plugs, 13-pin, System D 2.5
- Circular plugs, 20-pin, System D 2.5
- Circular plugs, 4-, 7-, 10-, 12-, 25-pin, System D 1.5/D 2.5
- In-line plugs, 15-pin, System D 2.5
- In-line plugs, 8-, 12-pin, System D 2.5
- In-line plugs, 30-pin, System D 2.5
- In-line plugs, 20-pin, System D 2.5
Plug system JPT/MDK/DFK
- In-line plugs, 2-pin, System JPT ELA
- In-line plugs, 2-pin, System MDK 3plus 2.8
- In-line plugs, 4-pin, System DFK ELA
Plug system Elo/Elo-Power
- In-line plugs, 4-, 10-pin, System Elo
- In-line plugs, 6- to 50-pin, System Elo
- In-line plugs, 3-, 6-pin, System Elo-Power 2.8
Plug system MQS/MPQ
- In-line plugs, 6-, 8-pin, System MQS
- In-line plugs, 2-pin, System MPQ 2.8
- Control unit plugs, 25-, 35-, 55-, 83-, 88-pin
- In-line plugs, 24-pin, Hybrid System MQS/MPQ
- Socket housing 42-, 43-pin, Hybrid System MQS / MPQ
- Socket housings, 2x21-, 2x27-pin, Hybrid System MQS/MPQ, Elo/Elo-Power
- In-line plugs, 30-pin, Hybrid System MQS/MPQ
- Socket housings, 5-, 8-pin, System MQS/MPQ
- Socket housing (radio plug), Hybrid System MQS/MPQ
61 13 ... RELAY CARRIER
Place special tool 61 1 153 on relay carrier (1) and carefully pull in direction of arrow until retaining lugs (2) on relay carrier are raised.
Scheme 84
Pull relay carrier (2) in direction of arrow into first catch (3).
Scheme 85
Press down arrester hook (4) of appropriate contact and pull out cable with contact.
Scheme 86
Press out double flat spring contact with special tool 61 1 136 or 61 1 137 (ejector).
61 13 ... REPAIRING RIBBON CABLES
Special tools required
- 61 1 190
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Place ribbon cables (1) in connector housing (2) and close cover (3).
Scheme 87
Place connector housing (1) in pliers (2) 61 1 190.
Scheme 88
Close pliers (2).
61 13 ... Retaining bracket
Pull relevant fuse out of fuse block (1).
Note. Mark positions when removing fuses.
Pull locking slide (2) out of fuse block (1) as far as it will go.
Scheme 89
With special tool 61 1 136 or 61 1 137 (ejector), press back arrester hook (3) of appropriate contact and pull out cable.
Scheme 90
61 13... Socket housing (radio plug), Hybrid System MQS/MPQ
Manufactured by AMP: The following contact types without strand sealing can be fitted in the plug housings
- MQS (Micro Quadlock System)
- MPQ, width 2.8 mm (Micro Power Quadlock)
- MPQ, width 5.2 mm (Micro Power Quadlock)
Removing MPQ contacts from radio plug
Press lock (1) in direction of arrow.
Scheme 91
Detach secondary lock (2) from radio plug.
Feed special tool 61 1 135 past side of contact.
Scheme 92
Press special tool 61 1 135 in direction of arrow.
Pull wire (1) with socket contact out of radio plug (2).
Removing MQS contacts from contact carrier
Press lock (1) in direction of arrow and pull housing (2) out of radio plug.
Scheme 93
Press lock (1) in direction of arrow. Pull contact carrier (2) out of housing (3).
Scheme 94
Note. When the contact carrier is pulled out, the secondary locks of the socket contacts are raised.
Hold down retaining hook (1) of socket contact in opening of contact carrier with a small screwdriver.
Scheme 95
Pull wire with socket contact in direction of arrow as far as secondary lock (2).
Note. The illustration shows an 8-pin socket housing where removal of the contacts is identical.
Hold down arrester hook in secondary lock (1) again. Pull wire with socket contact (2) out of contact carrier (3).
Scheme 96
Removing MPQ contacts from contact carrier
Remove contact carrier (1) with MQS contacts from radio plug.
Scheme 97
Raise lock (2) on radio plug.
Pull contact carrier (3) out of radio plug.
Press lock (1) in direction of arrow.
Scheme 98
Pull secondary lock (2) in direction of arrow completely out of contact carrier (3).
Press special tool 61 1 135 on inside of contact into contact carrier (2).
Pull wire with socket contact (1) out of contact carrier (2).
Scheme 99
12 00... Instructions for disconnecting and connecting battery
Observe safety instructions for handling vehicle battery. Refer to 61 00 ... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY .
Before disconnecting battery
Switch off ignition.
Note. If the ignition is not turned off when the battery is disconnected, fault memories may be set in some control units.
| IMPORTANT | There is a danger of mixing up battery leads: If the battery positive and negative leads are the same color and you are in doubt, follow the polarity to the battery, then mark and cover the leads. On vehicles with radio code: After disconnecting the battery, the radio code must be re-entered. Therefore obtain the radio code card from the customer beforehand. Note stored stations and restore them after connecting the battery. Stored settings of the on-board computer and clock will also be lost. All available central keys must be recoded for cars with first generation infrared transmitter locking systems. |
General notes on disconnecting battery
- Do not disconnect battery leads and leads from alternator and starter motor while engine is running.
- Cars with IBS on battery negative terminal: Do not under any circumstances pull/lever off pole shoes by force. Do not under any circumstances release socket-head cap screw of IBS.
- Detach terminal of battery negative lead from car battery and second battery if fitted. Cover battery negative terminal(s) and secure.
- When work is carried out on the electrical system, faults may be caused in the fault memories of some control units when the battery is connected.
- When fitting terminal for battery negative lead: Tightening torque 61 21 1 AZ. Refer to «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-tightening-torques) .
After connecting battery
| IMPORTANT | After a power supply interruption some equipment is disabled and must be reactivated. Likewise, individual settings are lost and must be activated. Example: Activate sliding sunroof, refer to 54 0 NOTES ON STEEL AND GLASS SLIDE/TILT SUNROOFS (INITIALIZATION/NORMALIZATION/LEARNING OF CHARACTERISTIC CURVE) Vehicles with AFS only: Activate steering angle If necessary, activate power windows If necessary, activate mirror with compass |
Vehicles with a two-battery system
Starter and equipment batteries
A two-battery system has a starter battery circuit and an equipment battery circuit. A secondary control unit monitors both battery circuits. Depending on the situation, the battery circuits are connected to or isolated from the secondary control unit via an isolating relay.
| IMPORTANT | These batteries must not under any circumstances be charged with a voltage in excess of 14.8 V. Rapid programs must not be used either. |
Receiving/giving starting assistance via jump start terminal
The engine can be jump-started with an external voltage supply via the jump start terminal on the right side of the engine compartment.
Note. The starter battery is isolated from the alternators when the engine hood/bonnet is open.
Giving starting assistance via the jump start terminal is thus limited by the capacity of the starter battery when the engine hood/bonnet is open.
Charging starter and equipment batteries via jump start terminal
The starter battery is charged as a matter of priority with a charger connected to the jump start terminal. The voltage at the starter battery is the decisive factor in determining whether the equipment battery is also included in the charging operation. The secondary control unit automatically detects a charging operation at a charging voltage at the starter battery of graterthenequale ace; 13.5 V. The isolating relay is closed and thus the equipment battery is connected in parallel. Both batteries are now charged.
Prerequisite
- Terminal 61 inactive
- Terminal 15 inactive
If terminal 15 becomes "active" during the charging operation, the isolating relay is opened immediately and again only the starter battery is charged.
Note. When the engine hood is open, the isolating relay is also opened in normal operation when the engine is running. A special mode can be set by means of diagnosis for workshop/garage operation. The isolating relay is closed from terminal R in this operating mode. This mode is automatically reset once a distance of 5 km has been driven.
Trickle charging
Increased closed-circuit current consumption can be compensated with the aid of the battery trickle charger (special tool 61 2 410) via the jump start terminal.
| IMPORTANT | The cigarette lighter is isolated from the electrical system after terminal R "OFF" on a timed basis (60 mins.), thereby interrupting charging of the equipment battery via the cigarette lighter. This is prevented if the battery master switch (on the right side of the luggage compartment behind the panel) is turned on and off again twice within 2 seconds. (Cigarette light battery charging function). |
Do not start the engine with help of starting sprays.
Preparation
Conform with the following when starting engine with starting cable.
- Ensure that jump lead wires are to appropriate cross-section size.
- Only use fuse-protected jump leads.
- Check whether the current supplying battery has 12 V voltage.
- If engine is started from battery of another vehicle, ensure that there is no contact between the bodies of both vehicles.
| CAUTION | Never touch ignition system components and current - dangerous high tension! |
If the battery in the vehicle supplying power is weak, start the engine of this vehicle and let it run at idling speed.
Carrying out
Always conform with the procedures to avoid injury to persons or damage to parts.
- On automatic transmission, select "P" setting, apply handbrake.
- Move the shift lever of vehicles with manual transmission into neutral and apply the parking brake.
- Ensure that the jump leads cannot get caught in rotating parts, e.g. fan.
- First connect positive terminals of both batteries with one jump lead (red).
- Use positive connection point in engine compartment for vehicles with one battery in trunk.
- Then attach second jump lead (black) to negative terminal of donor battery and to engine ground or body ground on vehicle to be started.
| CAUTION | Never connect second jump lead (black) to negative terminal of battery in vehicle to be started. This would produce explosive gas which could be ignited by sparks. |
Danger of explosion!
After engine of vehicle to be started has started up, first disconnect the jump lead on the negative terminal/ground connection. Then remove jump lead from positive terminals.
For procedures, refer to 61 00 ... BATTERY .
For procedure, refer to 61 00 ... BATTERY CHARGING .
Battery acid is highly corrosive
Do not allow any battery acid to come into contact with the eyes, the skin or clothing. Therefore wear protective clothing, gloves and goggles.
Do not tilt the battery, acid may emerge from the vent opening.
In event of contact with acid
If acid is splashed into the eyes, rinse them immediately for several minutes with clear water. You must then consult a doctor without delay.
If acid is splashed onto the skin or clothing, neutralize it immediately with a soapy solution and rinse with lots of water.
Seek medical attention immediately if battery acid is accidentally swallowed.
Explosion hazard
Strictly no flames, sparks, naked light or smoking!
A highly explosive mixture of electrolytic gas is created when batteries are charged. The rooms where charging is carried out must therefore always be well ventilated.
Avoid the formation of sparks when handling cables, wiring and electrical devices.
Turn the ignition lock to the 0 position before disconnecting or connecting the battery.
Do not place tools or any similar object on the battery (danger of short-circuiting and explosion!).
61 20 ... Threshold values for battery inspection of all battery (telephone except for telephone battery)
Safety instructions for handling vehicle battery. Refer to 61 00 ... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY .
Test step 1 - before charging the battery
| Charge state (1) | Starting capability (2) | Test result |
|---|---|---|
| Not testable | Charge | |
| Less than 50 % (2) | Charge | |
| More than 50 % | Less than 75 % | Charge |
| More than 50 % | More than 75 % (3) | Charge |
| More than 80 % | More than 75 % | O.K. |
| (1) Charge condition and starting power must always be evaluated together (2) When test charging for more than 5 hours, use charger Gossen CG 32 or Siemens / Gossen VB 801 (3) Fully charge until charge state is more than 80 %. | ||
| (1) | Charge condition and starting power must always be evaluated together |
| (2) | When test charging for more than 5 hours, use charger Gossen CG 32 or Siemens / Gossen VB 801 |
| (3) | Fully charge until charge state is more than 80 %. |
BEFORE CHARGING THE BATTERY
Test step 2 - after charging the battery
| Charge condition (1) | Starting capability (2) | Test result |
|---|---|---|
| Not testable | Defective | |
| Less than 50 % | Less than 75 % | Charge |
| More than 50 % | More than 75 % | Charge |
| (1) Charge condition and starting power must always be evaluated together (2) When test charging for more than 5 hours, use charger Gossen CG 32 or Siemens / Gossen VB 801 | ||
| (1) | Charge condition and starting power must always be evaluated together |
| (2) | When test charging for more than 5 hours, use charger Gossen CG 32 or Siemens / Gossen VB 801 |
AFTER CHARGING THE BATTERY
Note. If battery was checked on the positive terminal in the engine compartment, repeat check directly on battery for sake of safety.
61 20 ... BATTERY OPEN-CIRCUIT CURRENT TEST
Note. Observe safety instructions for handling vehicle battery. Refer to 61 00 ... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY . Observe Service Information Adapter for open-circuit current measurement.
Scheme 100
The open-circuit current test is performed using the Diagnosis and Information System (DIS).
61 31 005 REMOVING AND INSTALLING/REPLACING FIXTURE FOR STEERING COLUMN STALK
| WARNING | Move wheels into straight-ahead position and do not alter this position during the repair work. With steering wheel removed, do not under any circumstances turn/twist fixture for steering column stalk! |
Necessary preliminary tasks
- Remove steering wheel, refer to «STEERING WHEEL»(/bmw/m3/e46-1999-2006/remont/steering-column/#steering-column-repair__steering-wheel)
- Remove lower section of steering column trim, refer to «STEERING COLUMN LOWER TRIM»(/bmw/m3/e46-1999-2006/remont/steering-column/#steering-column-repair)
- Remove top section of steering column casing, refer to «STEERING COLUMN UPPER TRIM»(/bmw/m3/e46-1999-2006/remont/steering-column/#steering-column-repair)
Disconnect plug from ring antenna.
Scheme 101
Disconnect plug from wiper switch.
Scheme 102
Disconnect plug from turn indicator/dipping switch.
Scheme 103
Release screws (1) and remove fixture for steering column stalk.
Scheme 104
| WARNING | When removed, the cover (1) of the fixture for the steering column stalk (2) is secured against turning/twisting by the lock (3). Do not under any circumstances twist the cover (1) out of its centered position against the fixture for the steering column stalk (2). |
Scheme 105
61 31 016 Removing and installing/replacing turn indicator/headlight dipping switch
Necessary preliminary tasks
- Remove fixture for steering column stalk, refer to «61 31 005 REMOVING AND INSTALLING/REPLACING FIXTURE FOR STEERING COLUMN STALK»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-31-005-removing-and-installingreplacing)
- E85 only: Remove cruise control switch
Press locks (1) and feed direction indicator/dipping stalk (2) in direction of arrow out of fixture for steering column stalk (3).
Scheme 106
61 31 033 Removing and installing light switch unit
Unclip left wooden finisher, refer to 51 16 221 REPLACING A CLIPPED-IN TRIM (DECORATIVE STRIP ON PANEL FOR INSTRUMENT PANEL, FRONT OR REAR DOOR) .
Remove left glovebox, refer to 51 16 350 REMOVING AND INSTALLING LEFT GLOVE BOX .
Release screws (1).
Scheme 107
Press switch unit up a little through glovebox aperture and then slide back.
Scheme 108
Unlock plug and remove.
Scheme 109
61 31 036 Removing and installing/replacing operating unit for light switch unit
- Unclip left trim, refer to «51 16 221 REPLACING A CLIPPED-IN TRIM (DECORATIVE STRIP ON PANEL FOR INSTRUMENT PANEL, FRONT OR REAR DOOR)»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-221-replacing-a-clipped-in) .
- Remove left glovebox, refer to «51 16 350 REMOVING AND INSTALLING LEFT GLOVE BOX»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-350-removing-and-installing) .
- Remove light switch unit, refer to «61 31 033 REMOVING AND INSTALLING LIGHT SWITCH UNIT»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-31-033-removing-and-installing) .
Unclip operating unit.
Scheme 110
Pull off connectors.
Scheme 111
61 31 040 Removing and installing/replacing switch for windshield wipers
Necessary preliminary tasks
- Remove fixture for steering column stalk, refer to «61 31 005 REMOVING AND INSTALLING/REPLACING FIXTURE FOR STEERING COLUMN STALK»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-repair__61-31-005-removing-and-installingreplacing)
Press locks (1) and windshield wiper stalk (2) in direction of arrow out of fixture for steering column stalk (3).
Scheme 112
61 31 055 REMOVING AND INSTALLING/REPLACING SWITCH FOR SMG TRANSMISSION (PROGRAM SELECTOR SWITCH)
Special tools required
- 64 1 020
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
M3
Unclip trim for storage tray (1) sideways and lift.
Scheme 113
Disconnect plug connection (1).
Scheme 114
Unclip switch for SMG transmission (2) in direction of arrow from trim for storage tray (3) and remove.
All
Unclip trim for storage tray (1) with special tool 64 1 020 and raise in direction of arrow.
Scheme 115
Disconnect plug connection (1).
Scheme 116
Unclip switch for SMG transmission (2) in direction of arrow from trim for storage tray (3) and remove.
61 31 057 REMOVING AND INSTALLING SWITCH UNIT IN CENTER CONSOLE
Version with SMG transmission only
Remove trim for storage tray. Refer to 61 31 055 REMOVING AND INSTALLING/REPLACING SWITCH FOR SMG TRANSMISSION (PROGRAM SELECTOR SWITCH) .
Version with automatic transmission only
Remove finisher for preselector lever.
All
Remove trim for center console. Refer to 51 16 211 REMOVING AND INSTALLING/REPLACING FOR STORAGE TRAY .
Remove insert in function carrier. Refer to 51 16 ... REMOVING AND INSTALLING/REPLACING CARRIER IN STORAGE TRAY .
In version with on-board monitor, remove heater controls. Refer to 64 11 748 REMOVING AND INSTALLING HEATER CONTROLS (A/C CONTROL) , 64 11 749 REMOVING AND INSTALLING HEATER CONTROLS (AUTOMATIC AIR CONDITIONING) or 64 11 750 REMOVING AND INSTALLING HEATING CONTROL (HEATER) .
Loosen screws (1).
Scheme 117
Loosen screws (1).
Pull out function carrier for switch center (2) in direction of arrow.
Scheme 118
Disconnect plug connections (1) and (2) and remove function carrier for switch center (3).
Scheme 119
61 31 058 Replacing switch unit in center console
Remove and install switch unit in center console. Refer to 61 31 057 REMOVING AND INSTALLING SWITCH UNIT IN CENTER CONSOLE .
Loosen screws (1).
Scheme 120
Remove switch unit (2) from function carrier for switch center (3) in direction of arrow.
61 31 079 Replacing switch for hazard warning system/central locking
Necessary preliminary tasks
- Version with sequential M transmission only
Remove storage compartment trim, refer to 61 31 055 REMOVING AND INSTALLING/REPLACING SWITCH FOR SMG TRANSMISSION (PROGRAM SELECTOR SWITCH)
Version without sequential M transmission only
Unclip gaiter (1) at side and force upwards over gear lever knob (2).
Scheme 121
All
Release screws (1).
Scheme 122
Fold storage compartment floor (2) up at rear and place to one side.
Scheme 123
Raise storage compartment (1) at front slightly.
Press side catches and press switch for hazard warning system/central locking from below out of storage compartment (1).
Disconnect plug connection and remove switch for hazard warning system/central locking.
Scheme 124
61 31 101 Removing and installing/replacing switch for backrest width adjustment (M3)
Detach outer cover on front seat and lay to one side. Refer to 52 16 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (SPORTS/ELECTRIC) .
Disconnect plug connection (1).
Unclip switch for backrest width adjustment (2) and remove towards outside of cover (3).
Scheme 125
61 31 104 Removing and installing/replacing shifters for SMG transmission (both)
Necessary preliminary tasks
- Remove AIRBAG unit, refer to «DRIVER-SIDE AIR BAG MODULE»(ref-170470-S33095963622005011000000)
Disconnect plug connections (2).
Scheme 126
Release screws (1).
Remove both shifters for SMG transmission (4) forwards from sports steering wheel (3).
Installation
Make sure electrical leads are correctly routed.
Make sure both turning locks (1) of each shifter for SMG transmission (2) are correctly seated in the respective mounts.
Scheme 127
61 31 115 Replacing rocker switch for side-window operation
Version with SMG transmission only
Remove trim for storage tray. Refer to 61 31 055 REMOVING AND INSTALLING/REPLACING SWITCH FOR SMG TRANSMISSION (PROGRAM SELECTOR SWITCH) .
All
Unclip gaiter (1) sideways and force upwards over shift knob (2).
Scheme 128
Loosen screws (1).
Scheme 129
Raise base of storage tray (2).
Unlock retaining clips and unclip rocker switch for window operation.
Scheme 130
Disconnect plug.
Scheme 131
61 31 204 Replacing switch combination for seat adjustment
This operation is described in
"Removing outer cover on front seat". Refer to 52 14 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (NORMAL/ELECTRIC) or 52 16 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (SPORTS/ELECTRIC) .
All models except Convertible
Carry out programming/coding. Refer to Diagnosis Programming/Coding .
61 31 208 Removing and installing/replacing switch for front lumbar support
This operation is described in
"Removing outer cover on front seat". Refer to 52 13 040 REMOVING AND INSTALLING / REPLACING OUTER COVER ON LEFT OR RIGHT FRONT SEAT BACK-REST (NORMAL / MANUAL) or 52 16 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (SPORTS/ELECTRIC) .
61 31 224 Replacing switch on impact cushion for left or right AIRBAG
Remove AIRBAG unit from steering wheel. Refer to DRIVER-SIDE AIR BAG MODULE .
Illustration shows removal of switch on impact cushion for AIRBAG on left
Disconnect plug connection (1).
Scheme 132
Loosen screws (2).
Remove switch on impact cushion for AIRBAG (3) in direction of arrow.
61 31 228 Replacing switch on sport steering wheel (with connected AIRBAG unit)
Necessary preliminary tasks
- Remove AIRBAG unit. Refer to «DRIVER-SIDE AIR BAG MODULE»(ref-170470-S33095963622005011000000) .
Note. There 2 screw variants: Self-tapping screws Screws with insert nuts (secure against falling out)
Release screws (1) and (2).
Scheme 133
Unclip complete trim (4) in direction of arrow from fixtures (3).
Disconnect plug connection underneath.
Release screws (1).
Scheme 134
Detach switch on sport steering wheel (3) in direction of arrow from trim (2).
Installation
Ensure gap dimension is uniform between trim (2) and switch on sport steering wheel (3).
61 31 255 Replacing switch for door mirror
Detach control knob (1) upwards from switch for door mirror (2).
Scheme 135
| IMPORTANT | When detaching switch for door mirror (2): Pull upwards only, do not press sideways. |
Using a pair of pointed pliers, pull door mirror switch (2) upwards slightly at rod (1) and lift out completely by hand.
Scheme 136
Disconnect plug connections (1) and remove switch for door mirror (2).
Scheme 137
61 31 295 Replacing clutch switch for cruise control system
- Remove trim panel for pedal assembly. Refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
- Press clutch pedal with pedal support down to flow and lock in position.
Disconnect plug connection (1).
Scheme 138
Withdraw sleeve (3) in direction of arrow up to stop.
Press both retaining clips together at front end and pull out switch (2) in direction of arrow towards rear.
Installation
- Slowly move clutch pedal to initial position.
61 31 299 Removing and installing/replacing clutch switch module
Necessary preliminary tasks
- Remove trim panel for pedal assembly. Refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
Note. Clutch master cylinder (2) is removed for purposes of clarity.
Lever out clutch switch module (1) from clutch master cylinder (2) with screwdriver.
Scheme 139
Unlock plug (4) and disconnect from housing (3).
Installation
Clutch switch module is protected against incorrect installation.
Clutch switch module must snap audibly into place.
Scheme 140
61 31 310 Replacing brake light switch
Necessary preliminary tasks
- Remove trim panel for pedal assembly. Refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
Unfasten plug connection (1) and disconnect.
Scheme 141
Pull brake light switch (2) in direction of arrow out of brake light switch holder (4).
Installation
- Press brake pedal (3) to floor.
- Slide brake light switch (2) as far as it will go into brake light switch holder (4).
- Grip brake light switch holder (4), slowly return brake pedal (3) to starting position and pull back to stop.
Note. Removing brake light switch holder (4): Press brake pedal (3). Press catches together and unclip brake light switch holder (4) from brake pedal (3).
61 31 313 Replacing a brake lining sensor
Necessary preliminary tasks
- Remove wheel, refer to «36 10 300 REMOVING OR INSTALLING FRONT OR REAR WHEEL»(/bmw/m3/e46-1999-2006/remont/wheel-tire-system/#wheel-and-tires-repair__36-10-300-removing-or-installing)
Open plug housing (1).
Scheme 142
Unclip lead of brake lining sensor (2) from plug housing (1).
Disconnect associated plug connection of lead from brake lining sensor (2).
Feed lead from brake lining sensor (2) out of fixtures.
Press clip (1) together and detach brake lining sensor (2) in direction of arrow from brake caliper (3).
Scheme 143
Installation
Make sure clip (1) and brake lining sensor (2) are correctly seated in brake caliper (3).
61 31 348 Replacing microswitch for unlocking rear lid
Remove strip handle (on rear lid). Refer to 51 13 402 REMOVING AND INSTALLING HANDLE STRIP (ON TRUNK LID) .
Remove clip (1) in direction of arrow.
Scheme 144
Installation
Make sure clip (1) is correctly seated.
Remove switch for unlocking rear lid (2) in direction of arrow from fixtures (3).
Cut wires on switch for unlocking rear lid (2) to length and strip insulation.
Crimp stop parts.
61 31 492 REPLACING LEVEL SWITCH FOR WINDSHIELD WASHER SYSTEM (M3, M3 CSL)
Necessary preliminary tasks
- Remove cover on right, refer to «51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (M3, M3 CSL)»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-000-removing-and-installing)
Note. Drain fluid reservoir for windshield washer system (3).
Scheme 145
Unfasten plug connection (1) and disconnect.
Turn level switch for windshield washer system (2) in direction of arrow and remove towards bottom from water reservoir for windshield washer system (3).
61 31 996 Carry out steering angle sensor adjustment
| IMPORTANT | In vehicles with active front steering, steering angle sensor adjustment is integrated in the service function "Initial operation/adjustment for active front steering" and must not be carried out separately! |
Note. Steering angle sensor adjustment must be carried out: after adjustment work on the front axle/steering after all mechanical work on the steering system after the following components have been replaced/coded: Steering column switch cluster DSC control unit ARS control unit
Connect vehicle to BMW diagnosis system. Select and carry out steering angle sensor adjustment under Service functions.
61 35 ... Note on replacing codable/programmable control units
Replacement
Carry out coding/programming.
Observe following IDC specifications
Scheme 146
- Programming
- Coding
61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
Special tools required
- 12 7 060
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Note. Electrical components which are particularly sensitive to electrostatic discharge (electronic control units, sensors, etc.) are marked with the ESD warning symbol.
E- Electro
S- Static
D- Discharge
For further information on this subject, please refer to Service Information SWZ 2 06 04 (128).
Statically charged persons can discharge by touching electrical components.
Scheme 147
Note. Humans can only detect a discharge starting from a level of approx. 3000 V.
The danger threshold for electrical components already starts from a level of approx. 100 V.
Scheme 148
| IMPORTANT | Do not touch pins or multi-pin connectors directly! Touch electrical components by their housings only. |
| IMPORTANT | To prevent electrical components from being damaged or destroyed by electrostatic discharge, it is absolutely essential to comply with the following instructions: When replacing electrical components, leave the replacement components in their original packaging until immediately before they are to be installed If necessary, always return a removed component in its original packaging (always pack the component away immediately) Read and comply with user information on using the associated ESD special tool 12 7 060 |
61 35 175 Removing and installing/replacing rain sensor
Up to 09/2001
Version with rain sensor.
Necessary preliminary tasks
Remove inside rearview mirror. Refer to 51 16 060 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (OVERVIEW) and 51 16 063 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (WITH REMOTE CONTROL) .
Pull out retaining clips (2) in each case in direction of arrow and remove.
Scheme 149
Unclip rain sensor (3) at bottom in direction of arrow.
Disconnect plug connection (1) and remove rain sensor (3).
Installation
Do not damage optical element below rain sensor (3).
If necessary, initialize rain sensor. Refer to 61 35 680 INITIALIZING RAIN SENSOR .
From 09/2001
Version with rain/light sensor.
Expand two-part mirror base cover (1) by pressing from below and detach.
Scheme 150
Feed out two-part mirror base cover (1) and remove.
Disconnect plug connection (3).
Scheme 151
Press locks (1) in direction of arrow and remove rain/light sensor (2) towards bottom.
Installation
Do not damage optical element below rain/light sensor (2). If necessary, initialize rain/light sensor. Refer to 61 35 680 INITIALIZING RAIN SENSOR .
61 35 680 INITIALIZING RAIN SENSOR
Note. Initialization is necessary: After replacing windscreen When installing a used rain sensor
Note. Connect BMW diagnosis system Initializing rain sensor
61 35 795 Removing and installing (replacing) control unit for adaptive directional headlights
Necessary preliminary tasks
- Remove right glovebox, refer to «51 16 360 REMOVING AND INSTALLING RIGHT GLOVE BOX»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-360-removing-and-installing)
Unfasten plug connection (1) and disconnect.
Scheme 152
Press catch (2) and remove control unit for adaptive directional headlights (3).
Replacement
Carry out coding/programming.
Observe following IDC specifications
- Programming
- Coding
- If necessary, car & key memory
- CD "CIP"
61 35 900 Removing and installing/replacing ring antenna of electronic immobilizer
Special tools required
- 613 300
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Necessary preliminary tasks
- Remove upper section of steering column trim. Refer to «STEERING COLUMN UPPER TRIM»(/bmw/m3/e46-1999-2006/remont/steering-column/#steering-column-repair) .
- E46 only: Remove lower section of steering column trim. Refer to «STEERING COLUMN LOWER TRIM»(/bmw/m3/e46-1999-2006/remont/steering-column/#steering-column-repair) .
Slide in special tool 61 3 300 with flattened end (A) facing ring antenna and lever out ring antenna.
Scheme 153
61 35 910 Removing and installing/replacing control unit of electronic immobilizer
| IMPORTANT | Read and comply with notes on protection against electrostatic damage (ESD protection). Refer to 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE) . |
Necessary preliminary tasks
- Disconnect battery negative lead
- Remove trim panel for pedal assembly, refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-45-185-removing-and-installingreplacing) .
Unfasten plug connection (1) and disconnect.
Scheme 154
Note. Secure control unit of electronic immobilizer (3) against falling out.
Release screws (2) and remove control unit of electronic immobilizer (3).
Replacement
Carry out programming/coding. Refer to Diagnosis Programming/Coding .
Diagnosis Programming/Coding
- Document type: Select SI Diagnosis Coding.
- Index number 11: Select Programming Information to display the table of contents.
- Select the current IDC for the appropriate vehicle.
For procedure, refer to 61 13 ... DME MASTER RELAY CONNECTOR .
For procedure, refer to 61 13 ... RELAY CARRIER .
61 61 010 Checking/adjusting approach angle of windshield wiper arms on front windscreen
Note. Wiping quality is increased if the approach angle of the windshield wiper arms is precisely adjusted.
Place special tool 00 9 331 next to center of rotation of windshield wiper blade on windshield.
Scheme 155
Note. To prevent scratching of wiper arm, cover wiper arm with fabric adhesive tape.
If the approach angle is too large (light gap at top between gauge and wiper blade), grip wiper arm special tool 00 9 332 and turn with special tool 00 9 333 in direction of arrow.
Scheme 156
Note. To prevent scratching of wiper arm, cover wiper arm with fabric adhesive tape.
If the approach angle is too small (light gap at bottom between gauge and wiper blade), grip wiper arm special tool 00 9 332 and turn with special tool 00 9 333 in direction of arrow.
Scheme 157
61 61 041 Replacing both windshield wiper blades
Press retaining spring in direction of arrow. Pull windshield wiper blade towards wiper arm and feed out.
Scheme 158
61 61 100 Removing and installing/replacing both windshield wiper arms
Special tools required
- 616 060
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Take off cap.
Scheme 159
Unfasten nut.
Scheme 160
Installation
- Observe tightening torque 61 61 10AZ. Refer to «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES - 3-SERIES (E46)»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-tightening-torques) .
| IMPORTANT | Do not bend windshield wiper arm during removal (risk of breakage). |
Detach windshield wiper arm with special tool 61 6 060.
Scheme 161
Installation
Check that sleeve (1) is firmly seated.
Scheme 162
If sleeve (1) is loose, it must be replaced.
A sleeve (1) firmly seated in the windshield wiper arm can be reused.
Windshield wiper arm with firmly seated sleeve (1)
Return windshield wiper system to rest position. Push wiper arm (2) with firmly seated sleeve (1) onto shaft and tighten down.
Scheme 163
Observe tightening torque 61 61 10AZ. Refer to GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES - 3-SERIES (E46) .
Check setting of wiper arm (2).
To correct setting, replace sleeve (1).
Windshield wiper arm with new sleeve (2)
Return windshield wiper system to rest position.
Push wiper arm (1) with sleeve (2) onto shaft and tighten until hand-tight.
Scheme 164
Set position of relevant wiper arm to rest position and then tighten down wiper arm.
Scheme 165
Adjustment dimensions
| Measurement 1 [mm] | Measurement 2 [mm] |
|---|---|
| 24 | 44 |
ADJUSTMENT DIMENSIONS
Observe tightening torque 61 61 10AZ. Refer to GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES - 3-SERIES (E46) .
61 61 270 Removing and installing complete wiper console
Necessary preliminary tasks
- Remove cowl panel cover. Refer to «51 13 115 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-13-115-removing-and-installingreplacing) .
- Remove heater bulkhead. Refer to «51 71 080 REMOVING AND INSTALLING/REPLACING HEATER BULKHEAD»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-71-080-removing-and-installingreplacing) .
Unfasten plug connection (1) and disconnect. Unscrew bolt (2).
Scheme 166
Installation
- Tightening torque 61 61 6AZ. Refer to «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES - 3-SERIES (E46)»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-tightening-torques) .
Installation
Scheme 167
- Fit rubber grommet (1) of wiper console on pin (2).
Release nuts and feed out complete wiper console through opening in heater bulkhead.
Scheme 168
Installation
- Tightening torque 61 61 5AZ. Refer to «GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES - 3-SERIES (E46)»(/bmw/m3/e46-1999-2006/remont/horns/#general-electrical-system-tightening-torques) .
61 67 010 REMOVING AND INSTALLING/REPLACING WASHER PUMP FOR HEADLIGHT CLEANING SYSTEM (M3)
Note. Drain fluid tank for windshield washer system
Remove cover on right. Refer to 51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (M3, M3 CSL) .
Remove hose clip (1) in direction of arrow.
Scheme 169
Detach hose (2) in direction of arrow from washer pump for headlight cleaning system (4).
Disconnect plug connection (3).
Turn washer pump of headlight cleaning system (4) in direction of arrow and lift out of water reservoir for windshield washer system (5).
Installation
Replace sealing ring/strainer of washer pump.
Coat sealing ring of washer pump with antiseize agent.
Ensure hose is laid without kinks.
Fill fluid tank for windshield washer system.
61 67 040 ADJUSTING SPRAY NOZZLES FOR HEADLIGHT CLEANING SYSTEM
Special tools required
- 00 9100
- 64 1 020
For further information on special tools, refer to GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46) .
Low-beam headlamp
The spray contact point must be located in the center of the low-beam headlamp.
Scheme 170
To adjust, slowly pull out spray nozzle fully with aid of special tool 64 1 020 and adjust spray contact point with special tool 00 9 100.
High-beam headlamp
The spray contact point must be located in the center of the high-beam headlamp.
Scheme 171
To adjust, slowly pull out spray nozzle fully with aid of special tool 64 1 020 and adjust spray contact point with special tool 00 9 100.
Note. After checking the contact points, turn ignition off and on again before repeating the spray procedure. The function of the headlight cleaning system is otherwise disabled for approx. 3 minutes. Refer to function description in Diagnosis and Information System.
61 67 045 Removing and installing/replacing spray nozzles for left or right headlight cleaning system
Note. Drain fluid tank for windshield washer system
Lever out spray nozzle with telescopic nozzle and pull out up to stop.
Scheme 172
Hold telescopic nozzle and pull off spray nozzle.
Allow telescopic nozzle to slowly slide back again.
Installation
Make sure spray nozzle engages correctly on telescopic nozzle.
Scheme 173
Installation
Do not confuse spray nozzles.
Pay attention to R and L markings on underside of spray nozzles.
Scheme 174
Replacement only
Converting spray nozzle finisher
Unclip both retaining hooks at bottom.
Scheme 175
Remove spray nozzle finisher upwards from spray nozzle.
Scheme 176
Installation
Adjust spray nozzles of headlight cleaning system. Refer to 61 67 040 ADJUSTING SPRAY NOZZLES FOR HEADLIGHT CLEANING SYSTEM .
61 71 004 Adjusting windshield washer spray nozzles
Note. The sprays must strike in the center of the area. Measurements apply to LHD models. Measurements are mirror-inverted for RHD models. Reference edge: windshield seal.
Scheme 177
Mark points of contact with adhesive tape.
Adjust spray nozzles using special tool 00 9 200.
Scheme 178
61 71 061 Replacing fluid reservoir for windshield washer system (M3, M3 CSL)
Necessary preliminary tasks
- Drain fluid reservoir for windshield washer system
- Remove front bumper, refer to «51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (M3, M3 CSL)»(/bmw/m3/e46-1999-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-11-000-removing-and-installing)
- If necessary, remove right front fog lamp, refer to «63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE)»(/bmw/m3/e46-1999-2006/remont/exterior-lights/#lights-repair__63-17-030-removing-and-installingreplacing)
Unlock plug connections and disconnect.
Scheme 179
Unhook wiring harness (5) from mounting (4).
Turn windshield washer pump (3) in direction of arrow, lift out of fluid reservoir for windshield washer system and place to one side.
Turn level switch for windshield washer system (2) in direction of arrow, remove downwards from fluid reservoir for windshield washer system and place to one side.
Version with headlight cleaning system
Turn washer pump of headlight cleaning system (1) in direction of arrow, lift out of fluid reservoir for windshield washer system and place to one side.
Note. Shown without fanfare horn for purposes of clarity.
Release screws (1) and remove fluid reservoir for windshield washer system (2) in direction of arrow.
Scheme 180
Installation
Make sure hoses are laid without kinks.
61 71 062 Replacing fluid reservoir for windshield washer system (M3 / lightweight bumper)
Drain fluid reservoir for windshield washer system.
Remove front bumper trim. Refer to 51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM (M3 / LIGHTWEIGHT DESIGN) .
Remove level switch for windshield washer system. Refer to 61 31 492 REPLACING LEVEL SWITCH FOR WINDSHIELD WASHER SYSTEM (M3, M3 CSL) .
Detach windshield washer pump from fluid reservoir for windshield washer system and place to one side. Refer to 61 71 100 REMOVING AND INSTALLING/REPLACING WINDSHIELD WASHER PUMP(M3) .
If necessary, detach washer pump of headlight cleaning system from fluid reservoir for windshield washer system and place to one side. Refer to 61 67 010 REMOVING AND INSTALLING/REPLACING WASHER PUMP FOR HEADLIGHT CLEANING SYSTEM (M3) .
Detach hose (1) and filler duct (2) from fluid reservoir for windshield washer system (4).
Scheme 181
If necessary, unhook wire harness from bracket on fluid reservoir for windshield washer system (4).
Release screws (3) and remove fluid reservoir for windshield washer system (4) in direction of arrow.
Installation
Make sure hoses are laid without kinks.
61 71 100 REMOVING AND INSTALLING/REPLACING WINDSHIELD WASHER PUMP (M3)
Note. Drain fluid tank for windshield washer system.
Remove cover on right. Refer to 51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (M3, M3 CSL) .
Detach hose (1) in direction of arrow from windshield washer pump (3)
Scheme 182
Disconnect plug connection (2)
Turn windshield washer pump (3) in direction of arrow, lift out of water reservation for windshield washer system (4)
Installation
Replace sealing ring/strainer of washer pump.
Coat sealing ring of washer pump with antiseize agent.
Ensure hose is laid without kinks.
Fill fluid tank for windshield washer system.
See also:
• 12 00 ... INSTRUCTIONS FOR WELDING WORK (OVERLOAD PROTECTION OF CONTROL UNITS)
• GENERAL ELECTRICAL SYSTEM - SPECIAL TOOLS - 3-Series (M54/E46)
• GENERAL ELECTRICAL SYSTEM - TIGHTENING TORQUES
• 54 0 NOTES ON STEEL AND GLASS SLIDE/TILT SUNROOFS (INITIALIZATION/NORMALIZATION/LEARNING OF CHARACTERISTIC CURVE)
• STEERING WHEEL
• STEERING COLUMN LOWER TRIM
• 51 16 221 REPLACING A CLIPPED-IN TRIM (DECORATIVE STRIP ON PANEL FOR INSTRUMENT PANEL, FRONT OR REAR DOOR)
• 51 16 350 REMOVING AND INSTALLING LEFT GLOVE BOX
• 51 16 211 REMOVING AND INSTALLING/REPLACING FOR STORAGE TRAY
• 51 16 ... REMOVING AND INSTALLING/REPLACING CARRIER IN STORAGE TRAY
• 64 11 748 REMOVING AND INSTALLING HEATER CONTROLS (A/C CONTROL)
• 64 11 749 REMOVING AND INSTALLING HEATER CONTROLS (AUTOMATIC AIR CONDITIONING)
• 64 11 750 REMOVING AND INSTALLING HEATING CONTROL (HEATER)
• 52 16 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (SPORTS/ELECTRIC)
• 52 14 040 REMOVING AND INSTALLING/REPLACING OUTER COVER ON FRONT LEFT OR RIGHT SEAT (NORMAL/ELECTRIC)
• 52 13 040 REMOVING AND INSTALLING / REPLACING OUTER COVER ON LEFT OR RIGHT FRONT SEAT BACK-REST (NORMAL / MANUAL)
• 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY
• 36 10 300 REMOVING OR INSTALLING FRONT OR REAR WHEEL
• 51 13 402 REMOVING AND INSTALLING HANDLE STRIP (ON TRUNK LID)
• 51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (M3, M3 CSL)
• 51 16 060 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (OVERVIEW)
• 51 16 063 REMOVING AND INSTALLING/REPLACING INTERIOR REARVIEW MIRROR (WITH REMOTE CONTROL)
• 51 16 360 REMOVING AND INSTALLING RIGHT GLOVE BOX
• 51 13 115 REMOVING AND INSTALLING/REPLACING COWL PANEL COVER
• 51 71 080 REMOVING AND INSTALLING/REPLACING HEATER BULKHEAD
• 63 17 030 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOGLAMP INSERT (M/AERODYNAMICS PACKAGE)
• 51 11 156 REMOVING AND INSTALLING FRONT BUMPER TRIM (M3 / LIGHTWEIGHT DESIGN)
• 12 00 ... INSTRUCTIONS FOR DISCONNECTING AND CONNECTING BATTERY
• 61 00 ... BATTERY CHARGING
• 12 00 ... INSTRUCTIONS ON STARTING AID
• 61 20 ... BATTERY OPEN-CIRCUIT CURRENT TEST
• 61 13 ... UNLOCKING AND DISCONNECTING DIFFERENT PLUG CONNECTIONS
• 61 13 ... ANTENNA ELBOW PLUG ON RADIO RECEIVER
• 61 13 ... OPENING PLUG HOUSINGS AND REMOVING CONTACTS OF DIFFERENT PLUG SYSTEMS
• 61 13 ... CUTTING OFF, STRIPPING INSULATION AND CUTTING OPTICAL FIBRES TO LENGTH
• 61 13 ... CRIMPING OPTICAL FIBRES
• 61 13 ... CRIMPING MICRO POWER QUADLOCK CONTACTS (MPQ)
• 61 13 ... CRIMPING MICRO QUADLOCK SYSTEM CONTACTS (MQS)
• 61 13 ... REPAIRING RIBBON CABLES
• 61 13 SPECIAL TOOLS FOR WIRING HARNESS REPAIRS
• 61 00 ... BATTERY
• 61 31 005 REMOVING AND INSTALLING/REPLACING FIXTURE FOR STEERING COLUMN STALK
• 61 31 033 REMOVING AND INSTALLING LIGHT SWITCH UNIT
• 61 31 055 REMOVING AND INSTALLING/REPLACING SWITCH FOR SMG TRANSMISSION (PROGRAM SELECTOR SWITCH)
• 61 31 057 REMOVING AND INSTALLING SWITCH UNIT IN CENTER CONSOLE
• Diagnosis Programming/Coding
• 61 35 680 INITIALIZING RAIN SENSOR
• 61 35 ... NOTES ON ESD PROTECTION (ELECTRO STATIC DISCHARGE)
• 61 13 ... DME MASTER RELAY CONNECTOR
• 61 13 ... RELAY CARRIER
• 61 67 040 ADJUSTING SPRAY NOZZLES FOR HEADLIGHT CLEANING SYSTEM
• 61 31 492 REPLACING LEVEL SWITCH FOR WINDSHIELD WASHER SYSTEM (M3, M3 CSL)
• 61 71 100 REMOVING AND INSTALLING/REPLACING WINDSHIELD WASHER PUMP(M3)
• 61 67 010 REMOVING AND INSTALLING/REPLACING WASHER PUMP FOR HEADLIGHT CLEANING SYSTEM (M3)
