17 0 000 Tester
| Note | For checking cooling system for leaks and function of pressure relief valve in radiator cap. Replaced by 17 0 100 |
|---|---|
| Storage location | A43, C17 |
| Order number | 17 0 000 |
| Consisting of: 1 =17 0 001 | Adapter |
| Note: For checking pressure relief valve in radiator cap / model series: all, except E28 | |
| 2 = 17 0 002 | Tester without adapter |
| Note: Pressure range 0...2.5 bar / model series: all, except E28 | |
| 3 =17 0 003 | Screw neck |
| Note: For screw-on radiator caps (normal thread)/ model series: E28, E30, E31, E32 Engine: all, except M51 | |
| 4 = 17 0 004 | Adapter |
| Note: For screw-on radiator caps (normal thread) / model series: E28, E30, E32 / Engine: M51 | |
| 5 = 17 0 005 | Screw neck |
| Note: For screw-on radiator caps (buttress thread) / model series: E31, E32, E34, E36, E38, E39 | |
| 7 = 17 0 007 | Adapter |
| Note: For checking expansion tank cap / model series: E31, E32, E34, E36, E38, E39 | |
| 8 = 17 0 008 | Pressure hose |
| 9 =17 0 009 | Adapter for radiator expansion tank |
| Note: Model series: E36 / Model: M3 US Engine W10 |
TESTER
Scheme 1
17 0 030 Pliers
Minimum set: Mechanical tools
| Note | For releasing fasteners on transmission oil cooler |
|---|---|
| Series | E46, E53, E60, E61, E63, E64, E65, E66, E85, R50, R53 |
| Storage location | B46 |
| SI number | 1 14 01(766) |
| Order number: 17 0 030 | |
| Pliers |
PLIERS
Scheme 2
17 0100 Tester
Minimum set: Mechanical tools
Scheme 3
| Note | For checking engine cooling system for water leaks. For checking radiator cap. |
|---|---|
| Series | E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E83, E85, E87, R50, R52, R53, RR1 |
| Engine | M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11, W17 |
| SI number | 01 07 02 (884) |
| Order number | 17 0 100 |
| Consisting of | |
| 1 = 170 101 | Pump |
| 2 =17 0 102 | Hose with quick-connect coupling |
| 3 = 17 0 103 | Adapter |
| Note: For radiator cap (normal thread) | |
| 4 = 17 0 104 | Adapter |
| Note: For radiator cap (normal thread) | |
| 5 = 17 0 105 | Adapter |
| Note: For radiator cap (sawtooth thread) | |
| 6 = 17 0 106 | Adapter |
| Note: For radiator cap (sawtooth thread) | |
| 7 = 17 0 107 | Adapter |
| Note: For radiator cap R50 / W10 | |
| 8 = 17 0 108 | Adapter |
| Note: For radiator cap R50 / W10 | |
| 9 = 17 0 109 | Adapter |
| Note: For radiator connection R53/W11, R50/W17 Adapter corresponds to 17 0 051 | |
| 10 = 170 111 | Adapter |
| Note: For radiator cap R53/W11, R50/W17 Adapter corresponds to 17 0 052 | |
| 11 = 17 0 112 | Case |
| 12 = 17 0 113 | Adapter |
| Note: For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988) | |
| 13= 17 0 114 | Adapter |
| Note: For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988) |
TESTER
17 0 130 Set of adapters
| In conjunction with | 17 0 101,17 0 102 |
|---|---|
| Note | For connecting adapters from 17 0 000 to pump 17 0 101 and hose 17 0 102. |
| SI number | 01 07 02 (884) |
| Order number | 17 0 130 of adapters |
| Consisting of | |
| 1 = 17 0 131 | Adapter |
| Note: For connecting pump 17 0 101 and hose 17 0 102 to adapter from 17 0 000 | |
| 2 = 17 0 132 | Hose with coupling connection |
| Note: For connecting pump 17 0 101 to adapter 17 0 007 | |
| 3 = 17 0 133 | Hose clamp |
| Note: For hose 17 0 132 |
SET OF ADAPTERS
Scheme 4
Scheme 5
| Note | For oil dispensers for flushing oil coolers of automatic transmissions |
|---|---|
| Transmission | A4S 31 0R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 440Z, A5S 560Z, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z |
| SI number | 1 12 96(103) |
| Order number | 17 2 010 Set of adapters |
| Consisting of | |
| 1 = 17 2 011 | Adapter |
| Note: For connecting oil cooler lines to oil dispensing unit - transmission: A5S 310Z, A5S 560Z, A5S 325Z In conjunction with: 17 2 015, 17 2 016, 172017, 172018, 172019 | |
| 1 = 17 2 021 | Retaining plate |
| Note: For Adapter 17 2 011 - transmission: A5S 325Z | |
| 2 =17 2 012 | Adapter (2 x) |
| Note: For connecting oil cooler lines to oil dispensing unit - transmission: A4S 310R In conjunction with: 17 2 015, 17 2 016, 17 2 017, 17 2 01, 17 2 018, 17 2 019 | |
| 3 = 17 2 013 | Banjo bolt (2 x) |
| Note: M18 x 1.5 thread with nut and seal for connecting oil cooler lines to oil dispensing unit - transmission: A5S 440Z In conjunction with: 17 2 012, 17 2 015, 17 2 016, 17 2 017, 17 2 018, 17 2 019 | |
| 4 = 17 2 014 | Banjo bolt (2 x) |
| Note: M16x1.5 thread with nut, seal and threaded piece for connecting oil cooler lines to oil dispensing unit - transmission: A5S 300J In conjunction with: 17 2 012, 17 2 015, 17 2 016, 17 2 017, 17 2 018, 17 2 019 | |
| 5 =17 2 015 | Connecting piece |
| Note: For Tecalemit oil dispensing unit | |
| 6 = 17 2 016 | Connecting piece |
| Note: For Horn oil dispensing unit | |
| 7 = 17 2 017 | Coupling (2 x) |
| 8 = 17 2 018 | Hose, long |
| 9 = 17 2 019 | Hose, short |
