Specifications & Procedures: Specifications BMW 7 series E65/E66 facelift

Wheel Alignment 5 illustrations

RIDE HEIGHT SPECIFICATIONS

ApplicationIn. (mm)
17" Rim25.2 (640)
18" Rim25.7 (653)
19" Rim26.2 (666)
20" Rim26.7 (679)

RIDE HEIGHT SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Control Arm To Rear Axle Support Toe-In Adjustment48 (65)
Spring Strut Mount To Wheel House25 (34)
Swinging Arm To Rear Axle Support Camber Adjustment122 (165)
Tie Rod Clamping Nut38 (51)

TORQUE SPECIFICATIONS

WHEEL ALIGNMENT SPECIFICATIONS

ApplicationPreferredRange
Total Toe
Front.17°.03 To .30°
Rear.17°0 To .33°
Camber (1)
Front.10°.43 To .23°
Rear1.5°1.83 To -1.17°
Track Differential Angle With 20° Lock On Inside Wheel (1)1.45°1.95 To -.95°
Caster (1)
With -10 To 10° Wheel Lock7.65°7.15 To 8.15°
With -20 To 20° Wheel Lock7.93°7.43 To 8.43°
Front Wheel Displacement.25 To .25°
Rear Geometrical Axis Deviation.2 To .2°
Maximum Wheel Lock
Inside WheelAbout 40.7°N/A
Outside WheelAbout 33.5°N/A
Turning Circle
745iAbout 39.9 Ft. (12.13 M)N/A
745Li & 760LiAbout 41.3 Ft. (12.6 M)N/A
(1) Difference between left and right is maximum .5°.
(1)Difference between left and right is maximum .5°.

WHEEL ALIGNMENT SPECIFICATIONS

Scheme 1

Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5
