Identifying Fixture. Scheme 272
| In conjunction with | 00 2 510 |
|---|---|
| Note | For checking axial play of drive shaft |
| Transmission | 4 HP 22, 4 HP 24, A5S 310Z, A5S 560Z |
| Storage location | B23 |
| Order number | 24 0 010 |
| Fixture | |
| Consisting of | |
| 1 = 24 0 011 | Dial gauge holder |
| 2 = 24 0 012 | Clamping piece |
FIXTURE - GENERAL SPECIFICATION
Identifying Oil Pressure Test Accessories. Scheme 273
| In conjunction with | 13 3 061 and BMW DIS |
|---|---|
| Note | For pressure gauge 13 3 061 or BMW DIS for checking oil pressure |
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z |
| Storage location | B23, B24, single |
| Order number | 24 0 020 |
| Oil pressure test accessories | |
| Consisting of | |
| 1 = 24 0 021 | Pressure hose with connection |
| Note: Pressure hose 1.7 m, connection M12x1.5 - M14x1.5 external thread/for checking the various converter pressures / Transmission: A4S 310R, A4S 270R | |
| 2 = 24 0 022 | Reducer |
| Note: For checking main pressure (3 HP 22, A5S 310Z) and clutch A (ZF transmissions) /transmission: 3 HP 22, A5S 310Z, A5S 560Z and all ZF transmissions | |
| In conjunction with: 24 0 140 | |
| 3 = 24 0 023 | Pipe bend, 145 mm |
| Note: Extended length 145 mm / Transmission: 4 HP 22, 4 HP 24 | |
| In conjunction with: 136 052 | |
| 4 = 24 0 024 | Pipe bend, 90 mm |
| Note: Extended length 90 mm | |
| In conjunction with: 136 052 | |
| 5 = 24 0 025 | Banjo bolt |
| Note: M20x1.5 - M18x1.5 / For checking converter pressure /Transmission: 3 HP 12 | |
| In conjunction with: 24 0 024 | |
| 6 = 24 0 026 | Reducer |
| Note: M24x1.5 - 20x1.5 / For checking main pressure /Transmission: 3 HP 20 | |
| In conjunction with: 24 0 024 | |
| 7 = 24 0 027 | Reducer |
| Note: M20x1.5 - M18x1.5 / For checking main pressure (3 HP 12) and converter pressure (3 HP 20) / Transmission: 3 HP 12, 3 HP 20 | |
| In conjunction with: 24 0 024 | |
| 8 = 24 0 028 | Screw plug |
| Note: M18x1.5 / For closing off oil supply lines while checking converter pressure / Transmission: 3 HP 20 | |
| 9 = 24 0 029 | Adapter |
| Note: For closing off supply and return lines while checking main pressure / Transmission: 3 HP 22 | |
OIL PRESSURE TEST ACCESSORIES - GENERAL SPECIFICATION
Identifying Adapter. Scheme 274
| In conjunction with | 13 3 061, 24 0 021, 24 0 023 |
|---|---|
| Note | For pressure gauge 13 3 061 / For checking converter pressure |
| Transmission | 4 HP 22 |
| Storage location | B23 |
| Order number | 24 0 030 |
| Adapter | |
ADAPTER - GENERAL SPECIFICATION
Identifying Retaining Fixture. Scheme 275
| Note | For removing and installing disc pack |
|---|---|
| Transmission | 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | C27 |
| Order number | 24 0 040 |
| Retaining fixture | |
| Consisting of | |
| 1 = 24 0 041 | Disc |
| 2 = 240 042 | Ring |
| 3 = 240 043 | Half shells |
RETAINING FIXTURE - GENERAL SPECIFICATION
Extractor grip. Scheme 276
| Note | For sealing plug in bottom section of transmission casing |
|---|---|
| Transmission | 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24 |
| Storage location | A24 |
| Order number | 24 0 050 |
| Extractor grip | |
EXTRACTOR GRIP - GENERAL SPECIFICATION
Identifying Retaining Fixture. Scheme 277
| In conjunction with | 13 3 061 (pressure gauge), 24 0 021, 24 0 023 |
|---|---|
| Note | For checking pump pressure |
| Transmission | 4 HP 22, 4 HP 24 |
| Storage location | B23 |
| Order number | 24 0 070 |
| Adapter | |
ADAPTER - GENERAL SPECIFICATION
Identifying Funnel. Scheme 278
| Note | For filling transmission fluid in transmission |
|---|---|
| Transmission | 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S560G, ZFS5-16 |
| Order number | 24 0 080 |
| Funnel | |
FUNNEL - GENERAL SPECIFICATION
Identifying Drift. Scheme 279
| Note | For driving in radial seal in transmission case front section / Replaced by 24 0 110, November 96 |
|---|---|
| Transmission | 4 HP 22, 4 HP 24 |
| Order number | 24 0 090 |
| Drift | |
DRIFT - GENERAL SPECIFICATION
